Shure Microflex Specification Sheet

MICROFLEX® WIRELESS SYSTEMS
Microflex® Wireless Systems
Microflex® Wireless microphone systems bring modern design and vivid, lifelike sound to signature boardrooms and AV conferencing environments. This enterprise-scale platform encompasses a system of advanced conferencing products that includes intelligent rechargeable microphone transmitters and charging stations, discreet wireless access point transceivers, flexible audio network interfaces, and comprehensive software tools for remote adjustment and monitoring of system settings.
Premium Conferencing Audio for Elite Boardrooms
Vivid Lifelike Sound, Versatile Microphone Selection, Discreet Designs, Scalable Solutions
Networked Digital Wireless for Enterprise-Scale Environments
Dante Compatible, Microflex Wireless Control Software
Intelligent Performance, Simplified Setup & Operation
Advanced Rechargeable Power Management, Automated Frequency Coordination, Encrypted Wireless, Assignable RF output power
Trusted Shure Experience
Wireless Expertise, Signature Audio, Reliable Product Support
Digital Audio Networking, Ethernet Connectivity, Control System
APPLICATIONS
Boardrooms
Corporate Theaters
AV Conferencing Spaces
Training/Seminar Centers
PRODUCT HIGHLIGHTS
Vivid, lifelike sound
Stylish, versatile wire­less microphone options
Digital audio networking over Ethernet
Microflex Wireless Control Software
AES256 encryption
®
System Specifications
Features
• Vivid, lifelike sound: Performance-tested Microflex® microphone elements flawlessly capture full range audio for clear, detailed communication
• Versatile microphone selection: Wireless boundary, gooseneck, bodypack, and handheld models are available to fit any conferencing application
• Discreet designs: With elegant aesthetics and a low-profile footprint, Microflex Wireless systems are designed to install easily and disappear into AV environments
• Scalable solutions: 2, 4 and 8 channel systems can be combined support configurations of up to 40 compatible channels (80 in Europe and select countries). Adjustable power limits enable additional channels to operate in separate rooms
digital audio networking: Integrated solution for transporting low latency, uncompressed audio over standard
• Dante Ethernet networks
• Ethernet connectivity: All Microflex Wireless networking components connect via Cat5e cable for simplified installation
• Corporate network ready: Connect to corporate networks and third party control systems using standard networking protocols, for remote management and campus-wide implementation
• Microflex Wireless Control Software: Browser-based control software that offers comprehensive remote monitoring and control of all settings and status parameters over the web, a corporate network or an AV local area network
• Control system compatible: Third party control and automation systems (AMX®, Crestron®) are fully compatible with Microflex Wireless, enabling the creation of custom interfaces on touchscreen panels
• Advanced rechargeable power management: Smart lithium-ion rechargeable batteries deliver up to 9 hours of continuous use, enable remote status monitoring while in the charger and provide remaining runtime in hours and minutes while in use via networked control systems
• Automated frequency coordination: Microflex Wireless systems actively scan the available spectrum and coordinate clean, compatible frequencies for every microphone channel. While in use, systems automatically move away from unexpected interference
• Encrypted wireless: Audio transmission is protected by AES-256 encryption - the same secure standard used in top government applications
• Selectable transmit power: Select the appropriate wireless output power per room to optimize spectrum usage, range, and battery life
Specifications (subject to change)
RF Carrier Frequency Range USA, Canada, Mexico: 1920–1930 MHz
Working Range 50 m (160 ft)
Audio Frequency Response 50 Hz – 20 kHz (+1, -3 dB)
Dynamic Range >99 dB, A-weighted
System Gain
MXWANI through Dante)
Latency 18 ms, nominal
System Audio Polarity Positive pressure on microphone diaphragm (or positive voltage on pin 3 of TA4M con-
Radio Transmission Time Division Multiple Access (TDMA), Gaussian Frequency Shift Keying (GFSK), 365 kHz
RF Sensitivity -87 dBm, minimum
Power 19 dBm (80 mW) maximum, See Frequency Range and Output Power table
Cable Requirements Cat 5e or higher, shielded, 100 m maximum between network devices
Network Addressing Capability DHCP, link-local, static
Operating Temperature Range 0°C (32°F) to 49°C (120°F)
Storage Temperature Range -29°C (-20°F) to 74°C (165°F)
(Mic gain @ 0dB to line level output on
Europe, Asia, Middle East: 1880–1900 MHz
Note: Actual range depends on RF power setting and signal absorption, reflection and interference.
Note: Dependent on microphone type
+50 dB
nector) produces a positive voltage on pin 2 of the ANI (with respect to pin 3 of the low­impedance output).
max. deviation
Frequency Range and Microphone Transmitter Output Power
Band Frequency Range (MHz) Region Power (mW)
Z10 1920 to 1930 USA, Canada, Mexico Low = 0.63
Z11 1880 to 1900 Europe, Asia, Middle East Low = 0.63
Medium = 3.16 High = 15.85 Maximum = 79.43
Medium = 3.16 High = 15.85 Maximum = 79.43
www.shure.com ©2017 Shure Incorporated
MXW1 Bodypack Transmitter
Top view of bodypack
Ground
5VDC
Audio Input
Active Load
Overview
The MXW1 is a hybrid bodypack transmitter compatible with Microflex® Wireless systems. It offers both an integrated omnidirectional microphone and an input jack for connecting an ear-worn or lavalier style microphone. The integrated microphone is perfect for picking up speech while the bodypack is on a lanyard or tucked into a shirt pocket, and a belt clip is included for attachment to clothing.
Features
• Compact, low-profile design: Fits comfortably into a shirt pocket or attached to clothing
• Integrated omnidirectional mic: Clearly captures full range audio without connecting an external microphone
• External microphone input: For connecting multiple styles of ear-worn or lavalier condenser microphones
• Bi-directional wireless: Enables return channel audio and real time remote control of all wireless microphone settings
• Earphone output: Listen to audio from a return channel for translation, cueing, or program material
• Programmable mute button: Customize local or remote muting behavior per application, with options including push-to­talk, push-to-mute, and external control.
• Standby mode: Enabled remotely during breaks or periods of inactivity to significantly extend battery life when not in use
• Wide working range: Reliable wireless coverage extends up to 160 feet (50 meters)
• Out of range alert: Emits beeping sound when range limit is exceeded
• Wide frequency response: Captures full range audio for clear voice transmission
• Easy transmitter linking: Assign the microphone to an Access Point channel by simply docking it into a Networked Charging Station and pressing “link”
• Encrypted wireless: AES 256-bit encryption for secure transmission.
• Advanced Li-ion batteries: Smart lithium-ion internal batteries provide up to 9 hours of continuous use, charge to full in 2 hours, and enable remote monitoring over the network of remaining runtime and charge status in hours and minutes
• USB charging: Connects to any standard USB power source for “always on” usage
Specifications (subject to change)
Gain Adjustment Range -25 to +15 dB (in 1 dB steps)
Maximum Input Level
Headphone Output 3.5 mm (1/8"), dual mono (will drive stereo phones)
Maximum Headphone Output Power
(1kHz @ 1% distortion, peak power, @16Ω)
Antenna Type Internal, Spacial Diversity, Linear Polarization
Battery Type Rechargeable Li-Ion
Battery Life Up to 9 hours
Charge Connector USB 3.0 Type A
Housing Molded Plastic
Recommended Storage Temperature Range 0 °C (32 °F) to 25 °C (77 °F)
Microphone Connector 4-Pin male mini connector (TA4M), See drawing for details
Input Impedance
Internal Microphone Omnidirectional (20 Hz – 20 kHz)
Dimensions 22 mm × 45 mm × 99 mm (0.9 in. × 1.8 in. × 3.9 in.) H × W × D
Weight 85 g (3.0 oz.) with batteries, without microphone
Available Models
MXW1/O MXW bodypack transmitter (without lavalier microphone)
Optional Accessories
SBC-USB USB Plug-in Charger
SB901A Replacement Battery for MXW1, MXW6, and MXW8 Transmitters
See table on right Lavalier microphone
(Mic gain @ -16 dB) −9 dBV
17.5 mW
Calculated with a new battery. Runtimes vary depending on battery health.
(@ 1 kHz) >20 kΩ
MXW1 Bodypack Transmitter
TA4M Connector
499
100
10μF
39
1μF
Top view of bodypack
Ground
5VDC
Audio Input
Active Load
39
156
Lavalier Options
MX150B/O-TQG Microflex 5mm Subminiature
MX150B/C-TQG Microflex 5mm Subminiature
MX153B/O-TQG Microflex Omnidirectional
MX153T/O-TQG Microflex Omnidirectional
MX153C/O-TQG Microflex Omnidirectional
WL183 Microflex 1cm Omnidirectional
WL184 Microflex 1cm Supercardioid
WL185 Microflex 1cm Cardioid Lavalier,
WL93 Omnidirectional Condenser
WCB6B Countryman, 3mm Subminiature
WCE6B Countryman, Omnidirectional Rigid
WCE6T Countryman, Omnidirectional Rigid
Lavalier, Omnidirectional, Black
Lavalier, Cardioid, Black
Subminiature Earset, Black
Subminiature Earset, Tan
Subminiature Earset, Cocoa
Lavalier, Black
Lavalier, Black
Black
Miniature Lavalier, Black
Omnidirectional Lavalier, Black
Earset Microphone, Black
Earset Microphone, Tan
5VDC
Active Load
Audio Input
Ground
www.shure.com ©2017 Shure Incorporated
MXW2 Handheld Transmitter
Overview
The MXW2 is a handheld transmitter compatible with Microflex® Wireless Systems. With lightweight but durable construction and integrated diversity antennas, the MXW2 delivers vivid lifelike sound, intelligent wireless performance, encrypted transmission, and advanced rechargeability for presentation and conferencing applications. Available with trusted Shure microphone cartridges, including the legendary SM58
Features
• Interchangeable microphone cartridges: Available with the SM58®, SM86, Beta® 58A and VP68 signature Shure microphones
• Dual transmit antennas: Maximizes transmission strength depending on hand placement
• Bi-directional wireless: Enables real time remote control of all wireless microphone settings
• Programmable mute button: Customize local or remote muting behavior per application, with options including push-to-talk, push-to-mute, and external control.
• Standby mode: Enabled remotely during breaks or periods of inactivity to significantly extend battery life when not in use.
• Wide working range: Reliable wireless coverage extends up to 160 feet (50 meters)
• Range warning alert: Emits beeping sound when range limit is exceeded
• Easy transmitter linking: Assign the microphone to an Access Point channel by simply docking it into a Networked Charging Station and pressing “link”
• Encrypted wireless: AES 256-bit encryption for secure transmission.
• Advanced Li-ion batteries: Smart lithium-ion internal batteries provide up to 15 hours of continuous use, charge to full in 3 hours, and enable remote monitoring over the network of remaining runtime and charge status in hours and minutes
• USB charging: Connects to any standard USB power source for “always on” usage.
Specifications (subject to change)
Gain Adjustment Range
Maximum Input Level
Antenna Type Internal, Spacial Diversity, Linear Polarization
Battery Type Rechargeable Li-Ion
Battery Life Up to 15 hours
Charge Connector USB 3.0 Type A
Housing Molded Plastic
Recommended Storage Temperature Range 0 °C (32 °F) to 25 °C (77 °F)
Microphone Capsule SM58
Configuration Unbalanced
Input Impedance
Dimensions 226 mm × 51 mm (8.9 in. × 2.0 in.) L × Dia. including SM58 microphone capsule
Weight 323 g (11.4 oz.) with batteries, including SM58 microphone capsule
(Mic gain @ -16 dB)
(@ 1 kHz) >20 kΩ
25 to +15 dB (in 1 dB steps)
9 dBV
Calculated with a new battery. Runtimes vary depending on battery health
®
, SM86, Beta® 58A, VP68
®
.
MXW2 Handheld Transmitter
Available Models
MXW2/SM58 Wireless Handheld Transmitter with SM58® Microphone
MXW2/SM86 Wireless Handheld Transmitter with SM86 Microphone
MXW2/BETA58 Wireless Handheld Transmitter with Beta
MXW2/VP868 Wireless Handheld Transmitter with VP68 Microphone
®
58A Microphone
Optional Accessories
®
®
58A
RPW112 Cartridge, Housing Assembly and Matte Grille for Wireless SM58
RPW114 Cartridge, Housing Assembly and Matte Grille for Wireless SM86
RPW118 Cartridge, Housing Assembly and Matte Grille for Wireless Beta
RPW124/VP68 Cartridge, Housing Assembly and Matte Grille for Wireless VP68
SBC-USB USB Plug-in Charger
SB902 Replacement Battery for MXW2 Transmitter
www.shure.com ©2017 Shure Incorporated
MXW6 Boundary Transmitter
Overview
The Shure MXW6 is a boundary microphone transmitter compatible with Microflex® Wireless Systems. With a low-profile design and cardioid or omnidirectional polar pattern options, the MXW6 allows flexible placement with excellent audio capture on any surface in front of one or multiple speakers. All Microflex Wireless transmitters deliver pristine audio quality, intelligent wireless performance, encrypted transmission, and advanced rechargeability for conferencing and presentation applications.
Features
• Coverage options: Available in cardioid or omnidirectional polar patterns
• Wide frequency response: Full range audio for clear voice transmission
• Microflex capsules: Well known and trusted Microflex sound signature
• Bi-directional wireless: Enables return channel audio and real time remote control of all wireless microphone settings
• Earphone output: Listen to audio from a return channel for translation, cueing, or program material
• Concealed power switch: Prevents accidental powering off
• Programmable mute button: Customize local or remote muting behavior per application, with options including push-to­talk, push-to-mute, and external control
• Encrypted wireless: AES 256-bit encryption for secure transmission
• Wide working range: Reliable wireless coverage extends up to 160 feet (50 meters)
• Out of range alert: Emits beeping sound when range limit is exceeded
• Easy wireless linking: Assign the microphone to an Access Point channel by simply docking it in a Networked Charging Station and pressing “link”
• Advanced Li-ion batteries: Smart lithium-ion internal batteries provide up to 9 hours of continuous use, charge to full in 2 hours, and enable remote monitoring over the network of remaining runtime and charge status in hours and minutes
• Standby mode: Enabled remotely during periods of inactivity to significantly extend battery life when not in use
• Low-battery LED: Visually alerts when there is 30 minutes of charge remaining
• USB charging: Connects to any standard USB power source for “always on” usage
Specifications (subject to change)
Gain Adjustment Range −25 to +15 dB (in 1 dB steps)
Maximum Input Level
Headphone Output 3.5 mm (1/8"), dual mono (will drive stereo phones)
Maximum Headphone Output Power
(1kHz @ 1% distortion, peak power, @16Ω)
Antenna Type Internal, Spacial Diversity, Linear Polarization
Battery Type Rechargeable Li-Ion
Battery Life Up to 9 hours
Charge Connector USB 3.0 Type A
Housing Molded Plastic
Recommended Storage Temperature Range 0 °C (32 °F) to 25 °C (77 °F)
Microphone Capsule MXW6/O: R183B
Dimensions 23 mm × 44 mm × 114 mm (0.9 in. × 1.75 in. × 4.5 in.) H × W × D
Weight 108 g (3.8 oz.) with batteries
(Mic gain @ -16 dB) −9 dBV
17.5 mW
Calculated with a new battery. Runtimes vary depending on battery health
MXW6/C: R185B
MXW6 Boundary Transmitter
Available Models
MXW6/O Wireless Boundary Transmitter, Omnidirectional
MXW6/C Wireless Boundary Transmitter, Cardioid
Optional Accessories
SBC-USB USB Plug-in Charger
SB901A Replacement Battery for MXW1, MXW6, and MXW8 Transmitters
www.shure.com ©2017 Shure Incorporated
MXW8 Gooseneck Base Transmitter
Overview
The MXW8 is a gooseneck base transmitter compatible with Microflex® Wireless Systems. With a stylish, contoured design and minimal footprint it complements any conference setting. The MXW8 accepts Microflex gooseneck microphones available in multiple lengths with polar pattern and LED options. All Microflex Wireless transmitters deliver pristine audio quality, intelligent wireless performance, encrypted transmission, and advanced rechargeability for conferencing and
presentation applications.
Features
• Gooseneck options: Compatible with a wide variety of length, LED light ring, and polar pattern variations of Microflex Gooseneck Microphones
• Wide frequency response: Full range audio for clear voice transmission
• Concealed power switch: Prevents accidental powering off
• Bi-directional wireless: Enables return channel audio and real time remote control of all wireless microphone settings including light ring indication
• Earphone output: Listen to audio from a return channel for translation, cueing, or program material
• Programmable mute button: Customize local or remote muting behavior per application, with options including push-to­talk, push-to-mute, and external control
• Encrypted wireless: AES 256-bit encryption for secure wireless transmission
• Wide working range: Reliable wireless coverage extends up to 160 feet (50 meters)
• Out of range alert: Emits beeping sound when range limit is exceeded
• Easy wireless linking: Assign the microphone to an Access Point channel by simply docking it in a Networked Charging Station and pressing “link”
• Advanced Li-ion batteries: Smart lithium-ion internal batteries provide up to 9 hours of continuous use, charge to full in 2 hours, and enable remote monitoring over the network of remaining runtime and charge status in hours and minutes
• Standby mode: Enabled remotely during periods of inactivity to significantly extend battery life when not in use
• Low-battery LED: Visually alerts when there is 30 minutes of charge remaining
• USB charging: Connects to any standard USB power source for “always on” usage
MXW8 Gooseneck Base Transmitter
Specifications (subject to change)
Gain Adjustment Range −25 to +15 dB (in 1 dB steps)
Maximum Input Level
Headphone Output 3.5 mm (1/8"), dual mono (will drive stereo phones)
Maximum Headphone Output Power
(1kHz @ 1% distortion, peak power, @16Ω)
Antenna Type Internal, Spacial Diversity, Linear Polarization
Battery Type Rechargeable Li-Ion
Battery Life Up to 9 hours
Charge Connector USB 3.0 Type A
Housing Molded Plastic
Recommended Storage Temperature Range 0 °C (32 °F) to 25 °C (77 °F)
Microphone Connector 6-pin connector for Shure MX405/10/15
Configuration Unbalanced
Input Impedance
Gooseneck Options See accessories list
Dimensions 36 mm × 71 mm × 124 mm (1.4 in. × 2.8 in. × 4.9 in.) H × W × D
Weight 193 g (6.8 oz.) with batteries, without microphone
(Mic gain @ -16 dB) −9 dBV
17.5 mW
Calculated with a new battery. Runtimes vary depending on battery health
(@ 1 kHz) >20 kΩ
Available Models
MXW8 MXW gooseneck base transmitter (without gooseneck microphone)
Optional Accessories
SBC-USB USB Plug-in Charger
SB901A Replacement Battery for MXW1, MXW6, and MXW8 Transmitters
See table on right Gooseneck microphone
Gooseneck Microphone Options
MX405LP/C Cardioid, 5" (12.7 cm), bi-color status
MX405LP/S Supercardioid, 5" (12.7 cm), bi-color status
MX405RLP/N No microphone cartridge, 5" (12.7 cm), light
MX410LP/C Cardioid, 10" (25.4 cm), bi-color status
MX410LP/S Supercardioid, 10" (25.4 cm), bi-color status
MX410RLP/N No microphone cartridge, 10" (25.4 cm),
MX415LP/C Cardioid, 15" (38.1 cm), bi-color status
MX415LP/S Supercardioid, 15" (38.1 cm), bi-color status
MX415RLP/N No microphone cartridge, 15" (38.1 cm),
indicator, less preamp
indicator, less preamp
ring, less preamp
indicator, less preamp
indicator, less preamp
light ring, less preamp
indicator, less preamp
indicator, less preamp
light ring, less preamp
www.shure.com ©2017 Shure Incorporated
MXWAPT2, MXWAPT4, MXWAPT8 Access Point Transceivers
Overview
The MXWAPT is a 2- 4- or 8-channel wireless access point compatible with Microflex® Wireless microphone systems. It uses automated frequency coordination to assign clean frequencies to wireless microphones and manages two-way wireless transmission of encrypted audio and control signals. Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation, and the supplied mounting plate and paintable cover allow discreet placement in boardrooms and conference rooms where low visibility is preferred.
Features
• Slim profile: Lightweight, discreet unit with paintable cover to match interior room colors and blend into AV environments
• Easy installation: Includes wall/ceiling mounting plate and connects to the system over single Ethernet cable (PoE compatible)
• Plenum rated: Meets rigorous fire safety test standards for installation above drop ceiling tiles
• Scalable configurations: Available in 2, 4 or 8 channel models to fit varying channel count requirements, and multiple units can be combined support configurations of up to 40 compatible channels (80 in Europe and select countries)
• Bi-directional wireless: Provides return channel audio to wireless transmitters and enables real time remote control of all wireless microphone settings
• Automated frequency coordination: Automatically scans available spectrum, coordinates clean frequency assignments, and moves channels away from unexpected interference
• Dante™ digital networked audio: Transports low latency digital audio received from wireless microphones over Cat5e cable to any other Dante-equipped device
• Encrypted wireless: AES 256-bit encryption for secure transmission
• Selectable output power: Optimize spectrum usage by selecting the appropriate wireless output power for the desired operating range
• Diagnostic LEDs: Provide easy visual reference to system activity and indicate power, wireless connection, and network audio status
Specifications (subject to change)
Network Interface RJ45: Gigabit Ethernet, Dante digital audio
Plenum Rating UL 2043
Power Requirement Power over Ethernet (PoE) Class 0, 6.5W
Antenna Type Internal, Spacial Diversity, Circular Polarization
Housing Molded Plastic, Cast Zinc
Dimensions 24 mm × 170 mm × 170 mm (1.35 in. × 6.7 in. × 6.7 in.), H × W × D
Weight APT8 856 g (1.9 lbs)
Without mounting plate or cover
APT4 845 g (1.9 lbs) APT2 845 g (1.9 lbs) Paintable Cover 85 g (0.2 lbs) Mounting Bracket 68 g (0.15 lbs)
MXWAPT Access Point Transceiver
Available Models
MXWAPT8 8-Channel Access Point Transceiver
MXWAPT4 4-Channel Access Point Transceiver
MXWAPT2 2-Channel Accses Point Transceiver
www.shure.com ©2017 Shure Incorporated
MXWANI4, MXWANI8 Audio Network Interface
Overview
The MXWANI is a 4- or 8-channel Audio Network Interface compatible with Microflex™ Wireless microphone systems that enables easy out-of-the-box system setup with no additional networking hardware required. With per channel analog outputs and a versatile 4-port gigabit switch, it is the central point for connecting and distributing Microflex Wireless systems to conference room AV networks. Front panel controls offer quick adjustments locally, or adjust system settings remotely from a networked PC or Mac through the Microflex Wireless Control Software.
MXWANI4 Audio Network Interface Front Panel
MXWANI4 Audio Network Interface Rear Panel
MXWANI8 Audio Network Interface Front Panel
MXWANI8 Audio Network Interface Rear Panel
Features
• Analog connections: 4 or 8 block connector channel outputs, with 1 or 2 block connector inputs (model dependent)
• Four port gigabit switch: Optimized port configurations for connection to the Access Point Transceiver and Networked Charging Stations, third party control systems, and corporate networks
• Ethernet connectivity: Send audio and control signals over long cable runs of up to 300 feet or anywhere over a corporate network
• Power over Ethernet: Port 1 of the rear panel switch supplies power over Ethernet to the Access Point Transceiver for simplified installation
• Corporate uplink mode: Link to the corporate network for remote control of system settings while keeping audio off the network for security and to reduce bandwidth
• Front panel controls: Mute or solo channels and set input/output levels easily from the front panel
• PC/Mac software control: Access the Microflex Wireless Control Software from a networked computer for input/output levels and port configuration
• Dante™ networking: Transports low latency digital audio received from wireless microphones over Ethernet to any other Dante-equipped device
• Headphone output: Solo audio signal on any channel
www.shure.com ©2017 Shure Incorporated
Specifications (subject to change)
Audio Frequency Response 20 Hz to 20 kHz (+1, −1.5 dB)
Dynamic Range
(20 Hz to 20 kHz, A-weighted, typical)
Output Noise
(20 Hz to 20 kHz, A-Weighted, typical)
THD+N
(20 Hz to 20 kHz@ +4dBu analog input,
−10 dBFS digital input)
Polarity Non-inverting, any input to any output
Dimensions 44 mm × 483 mm × 366 mm (1.7 in. × 19.0 in. × 14.4 in.), H × W × D
Weight MXWANI4 3.1 kg (6.9 lbs)
Housing Steel; Extruded aluminum
Power Requirements 100 to 240 V AC, 50–60 Hz, 1 A
Operating Temperature Range −18°C (0°F) to 63°C (145°F)
Storage Temperature Range −29°C (-20°F) to 74°C (165°F)
Analog Connections - Outputs
Configuration Active Balanced
Impedance 310 Ω
Clipping Level
(minimum)
Analog Connections - Input(s)
Configuration Active Balanced
Impedance 10.6 kΩ
Clipping Level
(minimum)
Analog-to-Dante: 113 dB Dante-to-Analog: 110 dB
Line: −84.5 dBV Aux: −95.2 dBV Mic: −106.5 dBV
<0.05%
MXWANI8 3.2 kg (7.1 lbs)
Line: +26.2 dBV Aux: +16.2 dBV Mic: −3.8 dBV
Line: +23.8 dBV Aux: +10.8 dBV
Headphone Output 6.35 mm (1/4") TRS, 100 mW, 350 Ω, dual mono (will drive stereo phones)
0 dBV=1 V RMS 0 dBu=0.775 V RMS 0 dBV=2.2 dBu
Digital Signal Processing
AD/DA Converter 24-bit, 48 kHz
Latency
(Estimated Nominal, ±0.1 ms)
Analog-to-Dante: 0.21 ms Dante-to-Analog: 0.24 ms + TN
TN = Network latency in milliseconds, as set in Dante Controller. Note: Dante network latency is typically associated with the receiving device.
Networking
Network Interface Four-Port Gigabit Ethernet Switch, Dante digital audio
Uplink Port (Port 4) Selectable, blocks multicast traffic
Power over Ethernet (PoE) Provided on Port 1 to power MXWAPT
Cable Requirements Cat 5e or higher, shielded, 100 m maximum between network devices
Network Addressing Capability DHCP, link-local, static
Available Models
MXWANI8 8-Channel Audio Network Interface
MXWANI4 4-Channel Audio Network Interface
Optional Accessories
90A20082 Hardware Kit
95B8389 IEC Cable
www.shure.com
MXWNCS2, MXWNCS4, MXWNCS8 Networked Charging Station
Overview
The MXWNCS is a 2, 4 or 8 port Networked Charging Station compatible with Microflex® Wireless microphone systems. Designed to complement boardroom aesthetics, Networked Charging Stations easily connect between conference room credenzas and AV rack closets over Ethernet via a single Cat5e cable. The front panel displays battery charge in 5 segment LED’s, and remaining runtime and charge levels in hours and minutes can be monitored from any networked computer via the control software. Handheld, bodypack and boundary transmitter styles each occupy one docking space while gooseneck bases require two spaces to dock.
Features
• Versatile microphone docking: Each station accepts all Microflex Wireless transmitters
• Charge status indicators: 5-segment LED’s on the unit display charge status individually for every docked microphone
• Remote charge status monitoring: Ethernet connection to the system enables remote monitoring of battery charge status in hours and minutes via the control software or third party control systems
• Easy transmitter linking: Assign docked wireless microphones to channels on an Access Point Transceiver by simply pressing “link”
• Rapid charge times: Reaches 50% charge in one hour and fully charges transmitters in two hours
• Overcharge protection: Smart recharging circuitry safeguards against battery damage and extends life cycles
Specifications (subject to change)
Charge Time MXW1, MXW6, MXW8:
MXW2:
Network Interface 10/100 Mbps Ethernet
Power Requirement 15 V DC @ 3.3 A maximum, supplied by external power supply (tip positive)
Housing Molded Plastic, Cast Zinc
Dimensions NCS8: 68 mm × 343 mm × 184 mm (2.7 in. × 13.5 in. × 7.25 in.), H × W × D
Weight NCS8 2.9 kg (6.4 lbs)
NCS4: 68 mm × 191 mm × 184 mm (2.7 in. × 7.5 in. × 7.25 in.), H × W × D NCS2: 48 mm × 102 mm × 154 mm (1.9 in. × 4.0 in. × 6.1 in.), H × W × D
NCS4 1.7 kg (3.7 lbs) NCS2 0.8 kg (1.8 lbs)
50%=1 hour; 100%=2 hours 50%=1.5 hour; 100%=3 hours
MXWNCS2 Networked Charging Station shown with MXW2/SM58 and MXW6
MXWNCS4 Networked Charging Station
Available Models
MXWNCS8 Networked Charging Station, 8 Port
MXWNCS4 Networked Charging Station, 4 Port
MXWNCS2 Networked Charging Station, 2 Port
MXWNCS8
Networked Charging Station
www.shure.com ©2017 Shure Incorporated
Loading...
