Shure FP23 User Manual

Model FP23 User Guide

Microphone Preamplifier

General Description

The Shure FP23 is a portable, battery-powered microphone pre­amplifier with phantom power. Designed for high bandwidth 96k/24
digital production, this studio-quality mic preamp is ideal for critical
radio, television, and film production applications.

With its rugged mechanical and electrical construction, compact
size, and high-quality components, the FP23 is extremely durable
and easy to use. This highly reliable mic preamp will provide years
of superb audio performance under the most punishing field condi­tions.

Features

Audio performance

• Maximum of 66 dB of gain, adjustable in eleven discrete
steps for accurate, repeatable gain settings.

• Dynamic range exceeding 120 dB.

• 20 Hz to 50 kHz audio bandwidth.

• High immunity to RF interference due to transformers, RF

filtering, and all-metal construction.

• High current line output driver capable of driving very long
cable runs.

Transformer balanced

• Premium-quality input transformer provides superior sonic
quality and freedom from interference problems.

• Custom-designed output transformer provides line driving
ability with freedom from interference problems.

Limiter

• Extended range peak limiter uses dual opto-isolators,
making the unit virtually “unclippable.”

Battery power

• Internal battery power (two AA) for convenient, low cost
power.

• Battery life greater than 24 hours.

Durable mechanical construction

• High strength extruded aluminum chassis with protective
metal end rails to withstand punishing field conditions.

• Easy access battery compartment for quick battery
changes.

Phantom power

• Selectable 48-volt and 12-volt phantom power for
condenser microphones.

High pass filter

• Two corner frequency settings.

Specifications

Gain

0 dB to 66 dB input to output, switch selectable

Gain Accuracy

+0.6, –0.1 dB with reference to front panel gain markings
(150 Ω source, 100k Ω load impedances)

Frequency Response (see graph below)

20 Hz – 22 kHz, +0.1, –0.5 dB
–1 dB at 50 kHz
(relative to 1 kHz level with 150 Ω source)

Equivalent Input Noise

–126 dBu (–128 dBV) maximum
(150 Ω source, flat weighting, 22 Hz – 22 kHz bandwidth for gain settings
of 36 dB or greater)

Output Clipping Level

+22 dBu minimum with 100 kΩ load
+20 dBu minimum with 600 Ω load

Input Clipping Level

+4 dBu minimum at the 0 or +18 dB gain setting

Dynamic Range

122 dB minimum at the +18 dB gain setting

THD + Noise

0.05% maximum
(from 50 Hz to 22 kHz @ +4 dBu output level,
22 Hz – 22 kHz filter bandwidth, +46 dB gain setting)

Common Mode Rejection Ratio:

100 dB minimum at 80 Hz
60 dB minimum at 10 kHz

Input

Transformer-balanced, 2000 Ω input impedance

Output

Transformer-balanced, 130 Ω output impedance

Low Cut

80 Hz or 160 Hz (switch selectable), 6 dB per octave

Phantom Power

12V or 48V (switch selectable) per DIN 45 596

Limiter

Limits to +17 dBu output level
10:1 limiting ratio
5 ms attack time, 100 ms release time
Amber/Red LED indicates limiting/clipping

Internal Voltage Rails

+15 V and –15 V, regulated

Power

2 AA batteries, 24 hours life typical with +4 dBu signal into 600 Ω, no
phantom power

Power LED

Green indicates power and good battery.
Red indicates power and low battery. LED turns red when approximately
4 hours of battery life remain.

Polarity

Mic input to line output is non-inverting

Operating Temperature Range

–18 to 57 degrees C
0 to 135 degrees F

2000, Shure Incorporated
27A8726 (TI)

Printed in U.S.A.

Dimensions

43 mm x 94 mm x 140 mm (H x W x D)
(1.7” x 3.7” x 5.5”)

Weight (unit only)

0.56 kg

1.24 lbs.

+1
+0
–1

d

–2
B
u

–3

–4

–5

–6

10 100k20 50 100 200 500 1k 2k 5k 10k 20k 50k

High Pass (Low Cut)

80 Hz

160 Hz

Weight (packaged)

0.86 kg

1.90 lbs.

Certification

Meets FCC Part 15 Class B, Eligible to bear CE mark (see conformance
statement)

Hz

FREQUENCY RESPONSE

Figure 1

46

42

36

FLAT

80

160

28

18

0

GAIN (dB)

ON ON

LIMITER POWER

50

54

58

62

66

123 4 56

Front Panel Controls and Indicators

1 LIMITER/Peak LED

Bi-color LED illuminates amber to indicate limiter activi­ty; illuminates red at 3 dB below clipping.

2 LIMITER Switch

Activates the peak limiter. Limits to +17 dBu output.

3 High Pass Filter Switch

Three-position switch inserts an 80 Hz or 160 Hz corner
frequency filter, 6 dB per octave. Center position of
switch removes the filter from the signal path.

4 Rotary GAIN Switch

Selects the amount of gain from input to output, adjust­able in 11 increments.

5 POWER Switch

Powers the unit when switch is in the up position.

6 POWER LED

Bi-color LED illuminates green when the unit is pow­ered and changes to red when approximately four
hours of battery life remain.

BATTERIES

FREQUENCY RESPONSE

Figure 2

Back Panel Connectors and Controls

7 Battery Compartment

Requires two AA batteries for operation. Insert positive
(+) end of battery first.

8 LINE OUT

Transformer balanced XLR line-level output. +22 dBu
peak output level.

9 PHANTOM Power Switch

Three-position switch selects either 48-volt or 12-volt
phantom power. Center position turns phantom power
off.

10 MIC IN

Transformer-balanced XLR input accepts microphone
level signals.

PHANTOM

48 V

OFF

12 V

MIC INLINE OUT

78910

2

Operational Notes

Transformers

The FP23 uses input and output transformers with premium
magnetic core material to achieve high signal handling capability,
especially at low frequencies. This keeps distortion to a minimum.

Transformers offer superior isolation from the adverse and un­controlled environments of field production. Unlike other balancing
techniques, transformers “transform” signals magnetically without
any direct electrical connection, providing complete galvanic isola­tion from the driving source. And their inherently high common
mode impedance provides exceptional common-mode noise re­jection.

Balanced and Unbalanced Connections

Both the input and output of the FP23 accept balanced or unbal­anced connections. Y ou can convert either the input or output to un­balanced operation by grounding pin 3 to pin 1. No change in gain
will occur.

Phantom Power

Use one of the two phantom power settings on the FP23 for mi­crophones that require it. Some microphones need the 48-volt set­ting, or they will suffer a loss of headroom and an increase in distor­tion. The 12-volt setting, however, lengthens battery life, and
electret-condenser microphones rated for operation at 12 V or less
generally receive no performance benefit from the 48-volt setting.
Consult your microphone documentation.

Dynamic microphones do not require phantom power. A properly
connected balanced, dynamic microphone is not affected by the
presence of phantom power and does not draw any current. How­ever, poorly or incorrectly wired microphone cable can cause audi­ble artifacts in the microphone signal (phantom power can be an
excellent cable tester). It is good practice to turn phantom power o ff
when not needed.

Limiter

The limiter switch on the front panel activates two peak­responding limiters within the FP23. The first acts on the input sig­nal, while the second one limits the output to +17 dBu. This enables
the FP23 to limit in excess of 50 dB, making it very difficult to clip
the unit, regardless of the gain setting. The limiter LED on the front
panel illuminates in proportion to the amount of limiting.

Batteries

Two AA alkaline cells can power the FP23 for approximately 26
hours (with typical signals, phantom power OFF). The audio perfor­mance of the FP23 does not vary throughout the life of the batter­ies.

Many factors affect battery life, including battery chemistry, am­bient temperature of operation, phantom voltage, microphone cur­rent draw, and output drive level. Use the chart below to estimate
battery life. Experimentation can help determine the battery life for
each individual setup.

NOTE: Nickel-Cadmium batteries are not recommended. These
batteries have lower energy per cell than other types and result in
very short service.

Battery

Type

Duracell AA

Microphone

Type

Battery

Life

Dynamic handheld 26 hrs.

MN 1500

Duracell AA

MN 1500

Duracell AA

MN 1500

(Test conditions: 70 degrees F, 42 dB of gain with an acoustic

music source, 600 Ω load, +4 dBu output)

Electret condenser,

12-volt phantom

Studio condenser, 48-volt

phantom

18 hrs.

5 hrs.

High Pass Filter

Use either of the two high pass (low cut) filter settings on the
FP23 to remove excess low frequency energy in the audio signal.
Use the 80 Hz position for most applications, such as recording
speech, music, and ambient sound. The 160 Hz position is useful
for enhancing speech clarity. The high pass filter is a single pole de­sign, 6 dB per octave.

When possible, equalize at the sound source with microphone
selection, placement, use of a windscreen, and onboard micro­phone filtering. A high pass filter on the microphone and a high pass
filter on the FP23 gives an additive effect, increasing the slope of
the filter.

3

Certification

Authorized under the DECLARATION OF CONFORMITY provision of FCC part 15 as a Class B digital device. Tested to comply with FCC standards. FOR HOME OR OFFICE USE. This product complies
with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna
 Increase the separation between the equipment and the receiver
 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
 Consult the dealer or an experienced radio/TV technician for help

This class B digital apparatus complies with Canadian ICES–003.
Eligible to bear CE marking.
Conforms to European EMC directive 89/336/EEC: Professional Audio Products Standard EN 55103 (1996); Part 1 (emissions) and Part 2 (immunity). The FP23 is intended for use in environments E1

(residential) and E2 (light industrial) as defined in European EMC standard EN 55103. It meets the applicable tests and performance criteria found in the standard for these environments. EMC conformance
is based on the use of shielded interconnecting cables.
