Models 101C; 101E; 102C; 102E; 103
General: Model "100" series Communications type
Microphones are pressure-actuated diaphragm type carbon microphones designed especially for efficient reproduction of speech.
The microphones fit naturally and comfortably in the
palm of the hand. They are light and compact, take
minimum space in portable equipment. The sturdy die
cast case has a durable baked enamel finish.
The Model "100" series microphones are equipped
with a heavy-duty, push-to-talk switch and are available
in a variety of switching circuits. (See Figure A). The
Models 101C, 102C and 103 are supplied with a stranded
copper conductor "Coiled-Cord" cable. The Models
101E and 102E are supplied with a tinsel conductor
"Coiled-Cord" cable.
DATA SHEET
MODEL 100 SERIES
CARBON MICROPHONES
Application:
especially designed for military, police, mobile equipment, and other uses where ruggedness and dependability are vital factors. The frequency response is
designed to produce clear, crisp, voice response.
Model "100" series microphones are
Installation: The microphones are provided with a
bracket for permanent placement in portable or mobile
equipment. The bracket has mounting holes with clear-
ance for No. 6 screws. (See Figure C).
Connection:
connections of Model "100" series microphones are
shown in Figure A. Models 101C, 101E and 103 have a
single pole normally open switch in the relay circuit.
Models 102C and l02E have a double pole normally
open switch to control both the cartridge circuit and the
relay circuit.
Internal switch connection and cable
Operation: A typical operating circuit is shown in
Figure D. Also shown in Figure D is a table of voltages
and corresponding resistances to limit the operating current through the carbon button to 50 milliamperes. The
resistance value shown in the table includes the D.C.
resistance of the transformer primary and other wiring
components. The microphone will operate satisfactorily
with currents up to 50 milliamperes. However, no dam-
age will result if currents rise to 100 milliamperes. The
resistance of the carbon button is 70 to 100 ohms with 50
milliamperes flowing through button.
The Model "100" series microphone will operate
satisfactorily in all ordinary conditions of temperature
and humidity.
Specification:
volt for 100 microbar signal at microphone grill. Voltage
measured across 100 ohm load.
MODELS 101C; 101E; 102C; 102E; 103
Dimensions..........................
Finish...............................
Net Weight . . . . . . . . . . . . . . . . . . . . . . . .
Shipping Weight . . . . . . . . . . . . . . . . . . . . .
Code Words . . . . . . . . . . . . . . . . . . . . . . . . . 102C — RUCEM
Voltage sensitivity 5 db. below I
See Fig. B.
Baked Enamel
1 lb.
1 lb. 6 oz.
101C — RUCEG
101E — RUCAD
102E — RUCAF
103 — RUCAM
Recommended Load Impedance:
50 to 100 ohms.
Guarantee: Each microphone is guaranteed to be
free from electrical and mechanical defects for a period
of one year from date of shipment from the factory, pro-
vided all instructions are complied with fully. In case of
damage, return the microphone to the factory for repairs.
Our guarantee is voided if the microphone case is
opened.
Copyright, 1953, Shure Brothers, Inc.
27-08 (5-57)
Printed in U.S.A.
FIG A. INTERNAL CONNECTIONS
FIG. A-1
FIG. A-4
Model 100 Series Carbon Communication Hand Microphones
MODEL No.
MODEL 101C:
MODEL 101E:
MODEL 102C:
MODEL 102E: (See Fig. A-3)
MODEL 103:
INTERNAL
CONNECTIONS
(See Fig. A-1) Stranded coil cord.
(See Fig. A-2)
(See Fig. A-3)
(See Fig. A-4) Stranded coil cord with Amphenol MC4M plug (in line keying).
FIG. A-2
FIG. A-5
FIG. A-6
TYPE OF CABLE
Tinsel coil cord with Amphenol MC4M plug (offset keying).
Stranded coil cord.
Tinsel coil cord with spade lugs.
FIG. A-3
Shure Carbon Hand Microphones are widely used with mobile communication equipment.
Listed below are several communica-
tion equipment manufacturers, the Shure microphone used by them, and the recommended replacement, with wiring instructions.
EQUIPMENT
MANUFACTURER USED
GENERAL ELECTRIC
GENERAL ELECTRIC
GENERAL ELECTRIC
PLATT MFG. CO.
MOTOROLA
MOTOROLA
MOTOROLA
LINK RADIO
LINK RADIO
LINK RADIO
R. C. A.
SHURE
MODEL No.
CB10B
CB10D
CB10E
CB10F
CB12D
CB12E
CB12F
CB14
CB14A
I-393
CB15D
EQUIPMENT
MANU-
FACTURER
MODEL No.
4MKA2A2
4MKA2A4
4MKA2A5
180-1133
59B84298
and
Kit No. P255A
50B890923
50C822727
CB14
CB14A
N-48A10376
Ml-31544
TYPE OF
CABLE USED
Stranded Coiled Cord
Stranded Coiled Cord
Tinsel Coiled Cord
Stranded Coiled Cord
Stranded Coiled Cord
Tinsel Coiled Cord
Tinsel Coiled Cord
Straight Cord
Stranded Coiled Cord
Stranded Coiled Cord
REPLACEMENT
MODEL No.
101C
101C
101E
101C
102C
102E
CB12F
None — See Note
None — See Note
None — See Note
101C
SHURE REPLACEMENT MICROPHONE AND METHOD OF WIRING
TO MATCH ORIGINAL INSTALLATION
CONNECT AS INDICATED BELOW
Attach Amphenol MC4M plug as shown in Fig. A-2*
Attach Amphenol MC4M plug as shown in Fig. A-2*
Direct Replacement—Use as Supplied. See Fig. A-2*
Attach Amphenol MC4M plug as shown in Fig. A-6*
Attach Amphenol MC4M plug as shown in Fig. A-5*
Direct Replacement—Use as Supplied. See Fig. A-3
Not illustrated. Use as supplied
Attach Spade Lugs Supplied. See Fig. A-1
R. C. A.
NOTE: Special Assembly. Available only from Link Radio
CB15F
MI-31544A
Stranded Coiled Cord
103
Direct Replacement, Use as Supplied. Fig. A-4
*IMPORTANT — Observe Location of No. 1 Pin with Respect to Key on Plug Shell
Cable and switch replacements for Shure "100" and "CB" Series Microphones vary from model to model. For specific models see listing below.
MODEL CABLE
CB10
CB10B
CB10D
CB10E
CB10F
CB12
CB12A
CB12C
CB12D
CB12E
CB12F
CB15
CB15B
C15C
C15C
C15C
C16C
C15C
C15C
C15C
C15C
C18C
C17C
C19C
C15C
C15C
SWITCH
94-08
94-08
94-08
94-08
94-08
90A235
90A235
90A235
90A235
90A235
90A235
94-08
94-08
MODEL
CB15C
CB15D
CB15F
101A
101B
101C
101E
102A
102B
102C
102E
103
CABLE
C15C
C15C
C18C
C15C
C15C
C15C
C16C
C15C
C15C
C15C
C17C
C18C
SWITCH
94-08
94-08
94-08
94-08
94-08
94-08
94-08
90A235
90A235
90A235
90A235
94-08
FIG. B.
FIG. C. MOUNTING BRACKET
FIG. D. CIRCUIT DIAGRAM
