contents
1. let’s get loud
(turning on your shoX vibe + button control)
2. blinky light thingy
(a guide to the colourful blinky light thingy)
3. hook a brother up
(pairing different devices)
4. get wired
(using the 3.5mm aux cable)
5. look ma, no hands
(using shoX vibe as a hands-free device)
6. power up
(charging your shoX vibe)
1. lets get loud
(turning on your shoX vibe + button control)
alright, let’s get going shall we? to turn your shoX vibe on,
just press the “on” button on the top of your speaker to
the far right and you should hear shoX vibe’s sweet
start-up tone letting you know you’re all set and ready to
go. you should also see the blinky light thingy flashing
red.
now more about those trendy track control buttons:
play or pause your beats and even take hands-free calls
skip to the next track/pump up the volume
return to the previous track/turn down the volume
power on/off and source control
keep calm… you’ll be listening to the crisp, defined sound
of the shoX vibe in no time
2. blinky light thingy
(a colourful guide to the blinky light thingy)
ok, before we start, let’s take a look at the blinky light
thingy
on the top panel
• Is flashing red – you’re in Bluetooth pairing mode
• Is glowing solid red – you’ve just heard the sweet tone
of successful pairing from your shoX vibe. press
and hold the mode button to disconnect from Bluetooth
mode
on the side panel
• is flashing red and green – you’re in “power up” mode
(charging your shoX vibe)
• is flashing green – your shoX vibe is fully charged
3. hook a brother up
(pairing different devices)
first of all, make sure your blinky light thingy is flshing red
– now you’re in Bluetooth pairing mode. make sure your
device and your shoX vibe are within 1 metre of each
other
iphones & ipads
• go to general -> Bluetooth & gracefully swipe it to the
“on” position
• shoX vibe will become discoverable, touch to connect
• now is the blinky light thingy off? houston, we have lift
off!
other cellphones & tablets
• turn your Bluetooth on and search for “shoX vibe”
• if you’re prompted for a password, enter “0000”
• check your Bluetooth device list & connect with your
shoX vibe
(flip the page over
to continue...)
pure Bluetooth bliss
Brought to you by:
0861 77 88 88
www.tevo.co.za | info@tevo.co.za
• when the blinky light thingy glows red, sit back like a
boss!
pc or notebooks*
• activate your Bluetooth connectivity and “search new
device”
• once shoX vibe has become discoverable, click on it to
connect
• if a password is required, enter “0000”
• is the blinky light thingy glowing red? It is? sweet
success!
*may not work with all pc’s and notebooks. connection
depends on chip sets & Bluetooth drivers installed
macs
• turn your Bluetooth on and scroll down to “set up
Bluetooth device”
• click on “shoX vibe” and continue
• if you’re asked for a password, use the always famous
password of “0000”
• now open system preferences and click “sound”
• click the output tab and select shoX vibe
• click the input tab and select shoX vibe
• when the blinky light thingy turns red it’s time for an air
punch!
Note: once you have successfully paired a device, shoX
vibe’s intuitive machine brain will remember this device
and you won’t have to pair the device again, nifty. to pair
your shoX vibe with another device, turn off the Bluetooth
on your current device and begin the pairing process with
the new device.
4. get wired
(using the 3.5mm aux cable)
to link a device using the 3.5mm auxiliary cable, turn on the
shoX vibe, plug the cable into your device and into the
speaker and you are good to go!
5. look ma, no hands
(using shoX vibe as a hands-free device)
if one of your “peeps” drops you a line your music will
fade out and your ringtone will play, simply press the call
button to accept the call or press and hold the call button
to reject the call.
6. power up
(charging your shoX vibe)
the volume of your shoX vibe will start to decrease when
you have low battery. plug the usb cable into the back of
your shoX vibe to charge it up. the blinky light thingy will
flash red and green while charging. when the blinky light
thingy flashes green, your shoX vibe is fully charged and
ready to go.
that’s all folks! keep me safe in case you forget any of this
stuff
VIBE
use with:
user manual
TRENDZ
series
