Showtec Titan strobe User Manual
Titan Strobe
ORDERCODE 40222
Congratulations!
You have bought a great, innovative product from Showtec.
The Showtec Titan Strobe brings excitement to any venue. Whether you want simple plug-&-play action
or a sophisticated DMX show, this product provides the effect you need.
You can rely on Showtec, for more excellent lighting products.
We design and manufacture professional light equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: iwant@showtec.info
You can get some of the best quality, best priced products on the market from Showtec.
So next time, turn to Showtec for more great lighting equipment.
Always get the best -- with Showtec !
Thank you!
1
2
2
3
4
5
5
5
6
6
6
7
9
9
9
9
9
9
10
Showtec
Showtec Titan Strobe™ Product Guide
Warning..…...................................................................................………………………………………...............…....
Safety-instructions………………………………………………………………………………………….…................
Operating Determinations……………………………………………………………………………………..............
Rigging………………………………………………………………………………………………………….................
Description..…..............................................................................……….………………………………..................…
Features and Overview ………………………………...….……………….………….………………….…..............
Backside…………………………………………………...…...….……………….…………………...….….................
Installation...............................................................................…...…………………………………….…....................
Installing the Lamp ........................................................………………………………………..…………..............
Set Up and Operation.....................................................................……..……………………………….…................
DMX Settings.......................……………………………………………………………………….....................................
Maintenance...................................................................................………..………….…….………………...............
Changing the Lamp........................................................................…………………….…………………............
Replacing the Fuse........................................................................…………………….…………………..............
Troubleshooting............................................................................………………….………………….…....................
No Light.........................................…………………………………...………………….…………………..................
No Response to DMX ....................................................................………………….………………….................
Product Specifications.................................................................……………….…….…………………....................
2
WARNING
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this device has to:
- be qualified
- follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the nonobservance of this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never run the device without lamp!
Never ignite the lamp if the objective-lens or any housing-cover is open, as discharge lamps may
expose and emit a high ultraviolet radiation, which may cause burns.
Never look directly into the light source.
Never leave any cables lying around.
Never modify, bend, mechanically strain, put pressure on, pull or heat up the power cord.
Never strain the cable insert or the female part in the device. There must always be sufficient
cable going to the device. Otherwise, the cable will be damaged, which can cause serious
damage.
Never operate the stroboscope without protective shield! When the shield is cracked, replace it
before using the device again.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the lamp’s life.
Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
