Showtec SM-16-2 FX Service Manual
SM-16/FX V1
Highlite Interna t ional B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 50702
MANUAL
ENGLISH
Ordercode: 50702
SM-16/2 FX
Table of contents
Overview ............................................................................................................................................................................. 2
Specifications ................................................................................................................................................................ 2
Installation ........................................................................................................................................................................... 3
Safety instructions ......................................................................................................................................................... 3
Connection with the mains......................................................................................................................................... 5
Description of the device ................................................................................................................................................. 7
Front panel ..................................................................................................................................................................... 7
Back panel ..................................................................................................................................................................... 8
Glossary ........................................................................................................................................................................... 9
Patching ............................................................................................................................................................................10
Patch Fixture ................................................................................................................................................................10
View the patching ......................................................................................................................................................10
Controlling fixtures ...........................................................................................................................................................10
Selecting fixtures for control ......................................................................................................................................10
Changing channel values of the selected fixtures ..............................................................................................10
Off function ..................................................................................................................................................................10
Shapes ...............................................................................................................................................................................11
Use shapes ...................................................................................................................................................................11
Shape parameters ......................................................................................................................................................11
Record a running shape onto a playback fader .................................................................................................12
Edit a Running shape .................................................................................................................................................12
Delete a shape ...........................................................................................................................................................12
Playback parameters ................................................................................................................................................12
Scene .................................................................................................................................................................................13
Creating a scene ........................................................................................................................................................13
Using shapes in Scenes ..............................................................................................................................................13
HTP and LTP channels ................................................................................................................................................13
Playback a scene .......................................................................................................................................................14
Editing a scene ............................................................................................................................................................14
Include function ..........................................................................................................................................................14
Copy a scene ..............................................................................................................................................................14
Delete a scene ............................................................................................................................................................15
Time ...............................................................................................................................................................................15
Chase .................................................................................................................................................................................16
Programming a chase ...............................................................................................................................................16
Running a chase .........................................................................................................................................................16
Connecting a chase to the controls .......................................................................................................................16
Setting speed and crossfade ...................................................................................................................................16
Add a step ...................................................................................................................................................................17
Re-edit a chase ...........................................................................................................................................................17
Delete a chase ............................................................................................................................................................17
The global time of a chase .......................................................................................................................................18
Set separate time for a step .....................................................................................................................................18
Advanced options......................................................................................................................................................19
1
Ordercode: 50702
SM-16/2 FX
DMX512 channel numbers
256
Fixture
16
Channels for each fixture
32
Playback
80
Playback to run simultaneously
16
Total Chase steps
100
Time control of Scenes
HTP, LTP
Shapes for each Scene
2
Scene and dimmer by slider
Yes
Flash Scene
Yes
Shape generator
Shapes of Dimmer, Pan/Tilt, RGB and Color
Shapes to run simultaneously
10
Real time blackout
Yes
X/Y value by wheel
Yes
Chase speed by wheel
Yes
Dimmer by slider
Yes
USB Memory
FAT32 supported
Setup ..................................................................................................................................................................................19
Patch .............................................................................................................................................................................19
Language Select i on ...................................................................................................................................................19
Data backup and loading .......................................................................................................................................19
Wipe ..............................................................................................................................................................................19
System information .....................................................................................................................................................19
Update ...............................................................................................................................................................................19
Maintenance ....................................................................................................................................................................20
Troubleshooting ...............................................................................................................................................................20
No Light .........................................................................................................................................................................20
No Response to DMX..................................................................................................................................................20
Product Specifications ....................................................................................................................................................21
Dimensions ........................................................................................................................................................................22
Overview
The SM-16/2 FX DMX controller can control 16 fixtures simultaneously. It is equipped with built-in shape
effects of pan/tilt circle, RGB rainbow and varieties of chases etc. Also 16 playbacks and 10 built-in
shapes can be output simultaneously. Faders can be used to output scenes, chases, shapes and adjust
the intensity of the dimmer channels in the chases.
Specifications
2
Ordercode: 50702
SM-16/2 FX
Your shipment includes:
Installation
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
● Showtec SM-16/2 FX
● IEC Power cable 1,5 m
● Manual
Optional Accessories:
● D7401
Flight case
Safety instructions
Every person involved with the installation, operation and maintenance of this device has to:
• be qualified
• follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
3
Ordercode: 50702
SM-16/2 FX
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
• Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the device and do not modify the device.
• Never use anything to cover the ground contact.
• Never leave any cables lying around.
• Do not insert objects into air vents.
• Do not connect this device to a dimmerpack.
• Do not switch the device on and off in short intervals, as this would reduce the device’s life.
• Do not shake the device. Avoid brute force when installing or operating the device. Never use the
device during thunderstorms, unplug the device immediately.
• Only use device indoor, avoid contact with water or other liquids.
• Do not touch the device’s housing bare-handed during its operation (housing becomes hot).
• Only operate the device after having familiarized with its functions.
• Avoid flames and do not put close to flammable liquids or gases.
• Always keep case closed while operating.
• Always allow free air space of at least 50 cm around the unit for ventilation.
• Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power-cord by the plug. Never pull out the plug by tugging the power-cord.
• Make sure that the device is not exposed to extreme heat, moisture or dust.
• Make sure that the available voltage is not higher than stated on the rear panel.
• Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
• If the external cable is damaged, it has to be replaced by a qualified technician.
• If the glass is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
• If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
• If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
• If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
• For adult use only. Lighteffect must be installed out of the reach of children. Never leave the unit
running unattended.
• For replacement use fuses of same type and rating only.
• Allow time to cool down, before replacing lamp.
• The user is responsible for correct positioning and operating of the SM-16/2 FX. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
• This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
• During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
• Repairs, servicing and electric connection must be carried out by a qualified technician.
• WARRANTY: Till one year after date of purchase.
4
Ordercode: 50702
SM-16/2 FX
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Operating Determinations
• This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
• The maximum ambient temperature ta = 45°C must never be exceeded.
• The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
• If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
• Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
5
Ordercode: 50702
SM-16/2 FX
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail aftersales@highlite.nl
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
and request an RMA prior to shipping the fixture.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any shortcomings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.
6
Ordercode: 50702
SM-16/2 FX
Fig. 01
Description of the device
Features
The 50702 SM-16/2 FX is a light controller from Showtec.
• Intelligent light DMX controller
• 256 DMX512 channel numbers
• Patchable channels for each fixture
• Ready-to-use Shape Engine
• Show backup on USB flash drive (FAT32 supported)
• Power Supply: 230VAC (50Hz)
• Fixtures: 16 (each 32 channels)
• 16 Playbacks to run simultaneously
• HTP and LTP Time control of Scenes
• 2 Shapes for each Scene
• Operate scene, chase and dimmer by fader
• Flash scene
• Shape generator (shapes of Dimmer, Pan/Tilt, RGB and Color)
• 10 Shapes to run simultaneously
• Real time blackout
• X/Y value by wheel
• Chase speed by wheel
• Scenes: 80 (5 banks)
• Chases: 80 (5 banks)
• Total Chase Step s: 100
• Run mode: Auto, Manual
• Patch mode: Each fixture free assignable channels
• Output: DMX-512 standard
• Output connector: 3 and 5 pole XLR female
• Dimensions: 483 x 220 x 75 mm (LxWxH)
• Weight: 3,8 kg
Front panel
01) Fixture button: When the indicator <Fixture> lights up, you can control the fixtures 1-16 with the Unit
Buttons.
02) Channel page: To select page 1 (channel 1-16) or page 2 (channel 17-32). Indicator lights up when
on page 2.
03) Unit buttons: To select the fixtures or playbacks. The indicator <Fixture> lights up on the selected
fixtures or playbacks. The Unit buttons are also used for programming a scene or chase.
7
Loading...
