RPB2313BTLS
River Pro B2313BTLS
Bundles Required:
RPB2313BTLS-_ _
69082 Literature Bag - Brakes - Trailers
3310050 Jack - 800 lb. Swivel
80558-- Frame Bundle
*ST185/80R13C Tire/Dir Rim
66520 Bag w/Chains - No Coupler
TA0991-_ _ Winch Stand Kit - 9” w/Mtg Hardware
69319-_ _ Tongue Assy w/UFP Disc 5x3x78
*Check with your dealer/customer service representative for current tire/rim assembly part number.
ShoreLand’r offers its product line in painted nishes. When
ordering parts, it is important that you specify the nish or
color you have on your product. The 5-digit number along
with a 2-digit space _ _, note that the parts can be purchased
in various nishes.
03 .........Black
33 .........Galvanized w/ Black Plastic Components
RPB2313BTLS Specications
Capacity 2300 lbs.
GVWR: 2960 lbs.
GAWR: 2960 lbs.
Ship Wt: 505 lbs.
Frm Size: 2X4 (10 Ga.)
Tire Size: ST185X80R13C
Rim Size: 13 x 4.5 “J”
Brake: Surge Hydraulic (Disc)
Coupler: 2” Class II
Tongue Size: 3X5X78”
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 1 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 2 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 3 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 4 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 5 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 6 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 7 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 8 10/18/07
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 9 10/18/07
Tire Size and Carrying Capacity Chart
Tire Size ............................ST185/80R13-C
GVWR ...............................2960
Carrying Capacity ..............2300 lbs.
Axle....................................10” Disc Brake
Refer to the tire side wall for correct tire pressure.
Consumer / Owner:
Your River Pro trailer is designed, assembled and pre-ad-
justed to t your boat. If properly maintained it will give your
boat maximum support and many years of care free service.
Follow these instructions before using your trailer:
Read your ShoreLand’r Owner’s Guide and all safety decals on the trailer.
Tire and Wheel Assemblies
Mount the tire and wheel assemblies using the 1/2” ne
threaded tapered lug nuts provided. Tighten to 80-90 ft/lb.
of torque using the rotation pattern as shown in the Shore-
Landr’s Owners Manual. Re-torque the lug nuts after 50
miles of driving and then periodically thereafter.
Brakes:
Refer to the ShoreLand’r Brake Service Manual for brake
bleeding procedure, service and maintenance.
Wash and wax your trailer regularly. Always rinse your trailer
after each use, especially when boating in salt or brackish
water.
Re-check all fasteners for tighteness before towing.
Contact your authorized ShoreLand’r dealer if you experience a problem with your trailer. To locate a dealer, please
use www.shorelandr.com - dealer locator feature.
For further information or assistance, contact ShoreLand’r
at 1-800-859-3028 or visit www.shorelandr.com.
Midwest Industries, Inc. Ida Grove, IA 51445 800.859.3028 www.shorelandr.com 0003884
Page 10 10/18/07
