Declaration of conformity.................................................................... 18
1
What the symbols mean
Batteries charge level
Whenever this shows ‘nearly empty’ (), put the handset on the base unit to charge the
batteries. While the batteries are being charged, the level shown will keep changing.
Outside call
You are connected to an outside call.
Intercom call
You are connected to an intercom call.
Phone book
Show the names and numbers of stored record.
Mute
Your handset's microphone is muted.
Up and down arrows
To browse through the programming menu for more options.
Speakerphone
Your handset’s loudspeaker is on.
Signal level
Shows the strength of the signal between the handset and base unit, and flashes when you are
out of range of the base unit, when the level is low, or the symbol is flashing, move closer to
base unit.
Missed call
You have new missed call.
2
eca
butto
The Handset and Base Unit
MENU/ Mute button
Press to enter menu mode
and enter sub-menu. Use
the key "
unlock the keypad.
Press during a call to mute
the microphone
Speakerphone button
" to lock or
PHONEBOOK/OK/R
In standby mode, press to enter
phonebook mode.
Press to confirm selection.
You can activate Recall function if
your phone is connected to a PABX,
or if you use Select Services.
Press to transfer an outside call to
another phone.
INT button
ll
n
Press to turn the
speakerphone ON/OFF
Call button
Press to begin, answer
Press to begin and
and end a telephone call.
answer the call
UP/DOWN button
In standby mode, press
to show phonebook list;
Press during
programming to move
through the menu. Press
during a call to change
the volume in the
earpiece.
Press to make an intercom call (if you
have more than one handset)
Clear / On-Off /End button
Press and hold (2-3 seconds) to switch
the handset on and off. Press during
programming to go back to the
previous option, or to clear digits one
by one from the display.
Press to end the call.
IN USE light
The IN USE light comes on when you
have a connection to the telephone line.
HANDSET LOCATOR button
Press this to make the handset ring,
if you cannot remember where you put it.
Press it again to stop the handset ringing.
Before you can use the handset to make
calls for the first time, you will need to
fit and fully charge the battery for 15
hours.
3
Setting up your telephone
Connection and conditions for use
You can connect your SD3101 to a direct exchange line (DEL), a line connected to a local
exchange, with its own phone number; to an extension socket connected to a DEL; or to an
extension on an approved compatible PBX. Do not connect the SD3101 as an extension to a
payphone.
How many phones can you connect?
The ringer equivalence numbers (RENs) of all instruments (phones, fax machines, etc.)
connected to an exchange line must not add up to more than 4, otherwise, one or more of
them may not ring and/or answer calls correctly. The SD3101 has a REN of 1, and most
other telephones have a REN of 1 unless marked otherwise.
Radio signals between handset and base unit
To use your handset and base unit together, you must be able to establish a radio link
between them. Be aware that:
• Sitting the base unit as high as possible will give better results, in a two-storey house,
the best position may be on the first-floor landing.
• Any large metal object, like a fridge, a mirror or a filing cabinet, between the handset
and base unit may block the radio signal.
• Other solid structures, like walls, may reduce the signal strength.
Choosing a site for the base unit
The base unit should be placed on a level surface, in a position where:
• The mains adapter plug will reach a 230-V AC switched mains supply socket; never
try to lengthen the mains power cable.
• The telephone cable will reach your telephone line socket or extension socket.
• It is not close to another telephone, this can cause radio interference.
• It is not close to a sink, bath or shower, or anywhere else where it might get wet.
• It is not close to other electrical equipment, fridges, washing machines, microwave
ovens, TVs, fluorescent lights, etc.
What's in this pack
Please check the box contents for completeness.
If any parts are missing, return complete box to your supplier.
• The cordless handset
• The base unit
• Rechargeable AAA batteries
• A telephone line cable (different from country to country)
• A mains power lead and adaptor (different from country
to country)
• Charger pods (not available for single handset)
• User manual
Note: Keep your proof of purchase to support any
Guarantee claim
4
Installation
1. Choose a suitable site for the handset unit
Make sure it is not near to another telephone, nor to other electrical equipment.
2. Plug the mains power lead into the power jack on the base unit and plug the
telephone line cord into the telephone port.
3. Plug the mains adapter into a 230V AC, 50 Hz mains socket, with the switch on
the socket set to OFF
Note: The illustration of adaptor may vary from country to country.
4. Switch on mains power at the socket
5. Fit the battery in the handset(s)
Insert the battery pack as shown. Fit the battery compartment cover,
Sliding it until it clicks firmly into position.
6. Connect the base unit to the telephone line
5
