Shiro DX User Manual

AS MP3 Digital
Audio Player
(USB 2.0)

User Guide

Version 1.0

Table of Contents

Notice 1
Operation Buttons, Package Includes 2
Power On & Off, Minimum System Requirements,
Menu Mode 3
Music Operation, Voice Operation 4
FM Operation 5
Sport Operation 6
System Settings, Setting Equalizer, Setting Repeat Mode 7
Connecting Player to Computer, Troubleshooting Guide 8
Technical Specifications 9

Notice

1. The player battery can last up to 10 hours.

2. To charge your unit, connect your unit to the computer
using the USB cable provided.
Note: It takes approximately 2 hours to recharge the
battery completely. Recharging is still ongoing while
downloading/uploading files.

3. Switch the HOLD switch in the icon direction to enable
Hold status. Unlock the player to turn it on.

1

4. Press RESET hole at the side using a pin if the player

j

cannot operate normally.

Operation Buttons

VOL +

Power On/Off,
Play/Pause

Hook
Earphone

ack/USB port

VOL -

Left/Previous Right/Next

MENU

Package Includes

Installation CD(Optional), USB Cable, Earphone, User Guide

Hold

Microphone/
Reset

2

Power On & Off

To power on/off the player, press and hold Play/Pause.

Minimum System Requirements

• Operating System: Windows® 98/98SE/ME/2000/XP or

Macintosh™ OS 10.x

Hardware: 20MB of free disk space, 4x CD-ROM or higher,

•

USB port

Menu Mode

1. By default you will enter Music playback mode. Press Menu

to enter into Main menu. To enter sub-menu, press the
Play/Pause again. To go back to previous menu, press Menu.

2. You can choose the item by pressing VOL+/VOL-. Press

Play/Pause to enter.

3. You can select Browse, Radio, Record, Sport, Setting,

About.

4. Choose Browse to view or delete the music, recorded FM

and Voice files.

5. Choose Radio to enter radio mode.

6. Choose Record to enter voice-recording mode.

3
