Shiro 1.3,SX User Manual

SX MP3 Digital Audio
Player (USB 2.0)

User Guide

Version 1.3

1

Table of Contents

Notice 1
Operation Buttons, Packages Includes, Power On & Off 2
Minimum System Requirements, LCD Information 3
Menu Functions 4
Music Operation, Voice Operation, Recording Settings 5
FM Operation 6
Deleting Files, Setting Equalizer, Setting Repeat Mode 7
Setting A-B Clipping, Firmware Upgrade, Connecting Player to Computer, 8
Troubleshooting Guide
Technical Specifications 9

Notice

1. If the player is not used for a long duration, please remove the battery to avoid battery leakage.

2. Unlock the lock switch before using the player.

3. Under normal volume condition, the player can last up to 8 hours on a single AAA battery. Please
take note this battery lifespan will vary depending on the condition & manufacturer of the

battery. Please replace the battery when the battery icon is

or the unit turns off and

cannot be powered up at all.

2

Operation Buttons

HOLD Button

Package Includes

Installation CD, USB Cable, Earphone, User Guide, AAA Battery, Line-In Cable

Power On & Off

To power on the player, press Play/Pause.
To power off the player, press and hold Play/Pause.

VOLUME + or -

FORWARD or REWIND

MENU

Insert the SD/MMC Card according to the orientation shown
Connect the USB cable from here to the Computer USB port

3

Minimum System Requirements

Operating System: Windows 98® /98SE/ME/2000/XP or MacintoshTM OS 10.x
Hardware: 20MB of free disk space, 4x CD-ROM or higher, USB port

LCD Information

The loop mode includes Normal, Repeat Track, Repeat All, Shuffle, Shuffle Repeat mode.

Loop Mode

A

-B Clipping

Volume Hold/Locked

Battery

Equalizer

Current Mode

Current

Music/Total Music

Playing Time

Singer Detail

File Name
