1 Scope

The purpose of this document is to provide a guide for integrating the Spark-100 into the target hardware in an easy and fast way to shorten and simplify the development process. The guide is divided into two parts, the first guide you through the integration process, giving design samples based on the CB-50 development board (schematics can be provided by Shiratech via

support@shiratech.com ), the second part provides a more detailed description of the Spark-100

system.

In order to simplify the integration process we recommend the following process:

1. Read through the integration guide about the required interfaces.

2. Use Shiratech’s Pin configuration tool to define the solution

3. Use the CB-50 as a reference design and schematics to shorten the development process.

For more details if needed, review the Cyclone V user manual.

1.1 SoM introduction

The Spark-100 is an industrial embedded System-On-Module (SoM) based on Altera new Cyclone V SoC. The Spark-100 offers a unique combination of a high performance ARM core containing one or two Cortex-A9 cores combined with a large FPGA offering up to 110KLE.

The Spark-100 enables the end user to create a tailored solution made of the ARM processor variety of interfaces combined with additional "Soft Core" interfaces based on the FPGA. The unique interconnection between the FPGA and ARM core enables the ARM processor to access the FPGA based interfaces as regular slave interfaces.

The Spark-100 supports the SMARC standard developed by SGET (www.sget.org) utilizing a 314 interface connector providing a rich and flexible interface towards the carrier board.

The module has several configuration options for supporting the various Altera SOC sizes and variations along with different memory sizes to support the various project's needs.

4 | Spark-100 HW user manual v1.3

1.2 Block diagram

The following diagram provides an overview of the SOM. The following paragraphs will provide detailed description of the various parts of the SOM and how to use them in order to build a product around it.

Figure 1 – SOM main building blocks

5 | Spark-100 HW user manual v1.3

1.1V, 4A Core

1.5V, 4A

DDR3

2.5V 1A

3.3V

0.6A

1.8V

0.6A

Programmable VCCPD

2.5V, 3.3V 0.6A

Vin 5V

HPS Core

FPGA VCC

HPS DDR3

FPGA I/O

FPGA PLL, OSC, I/O

Peripherals

FPGA I/O

Peripherals

FPGA I/O

FPGA VCCPD Bank 3B, 4A

FPGA I/O Bank 3B

FPGA I/O Bank 4A

Programmable VCCIO

1.8V, 2.5V, 3.3V 0.6A

Programmable VCCIO

1.8V, 2.5V, 3.3V 0.6A

2 Spark-100 Integration guide

The HW integration guide covers all the hardware issues related to how to connect the SoM to the target device starting from power connectivity, connector details, pin-out options, description of the various interfaces along with a reference design for most of the interfaces. By using the same design as the reference board you can shorten the BSP development phase and reduce the risk of mistakes. The reference design is based on the CB-50.

2.1 Power considerations

The Spark-100 uses a single 5V power input from which all the other required voltages are taken.?. The Inlet power should be

 Rise time: <= 3ms  Input voltage range: 5V +/- 5%

2.1.1 VCCBAT - FPGA Encryption Key power

The Altera SOC has an option to maintain an encryption key for FPGA configuration even if the system power is down. For that pin S147 of the SMARC interface should be connected to a power source (between 1.2V - 3V). If the option is not used connect pin S147 to 2.5V. The interface is connected to VCCBAT(D7) pin of the SOC.

2.1.2 Spark Power scheme

The SPARK-100 has flexible power architecture to support the ARM core and the FPGA's power requirements. The following figure describes the power architecture:

6 | Spark-100 HW user manual v1.3

FPGA bank

Number of I/O

Voltage supported

Remarks

Bank 3A

1.8V or 3.3V

The default configuration 1.8V.

For other options contact

sales@shiratech.com

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V

The selection is done by hardware and cannot be changed during operation.

Bank 4A

1.5V, 1.8V, 2.5V, 3.3V

The selection is done by hardware and cannot be changed during operation.

Bank 5A

1.8V

Fix

Bank 5B 7 3.3V

Fix

Bank 8A 6 1.8V

Fix

HPS bank

Voltage supported

Remarks

Bank 6

1.5v

Internal bank for DDR

1.8V

Various interfaces,

7B, 7C

3.3V

Various interfaces, like SD and USB

Figure 2 – SOM internal power scheme

The SOM uses both fixed and configurable power converters for powering the HPS and FPGA IO banks. The following table describes the power levels of available for each I/O bank:

FPGA IO banks:

HPS IO banks:

2.1.3 Bank 3B and 4A - Programmable Power levels

The power of banks 3B and 4A can be programmed according to the design requirements. Each bank in the FPGA has a VCCPD and a VCCIO that control the banks power level. Banks 3B and 4A share a single

7 | Spark-100 HW user manual v1.3

VCCPD

Bank 3B

Bank 4A

Set to 3.3V

3.3V only

Set to 2.5V

1.5V, 2.5V or 1.8V

DC to DC

3.3, 2.5, 1.8V

1.5V FPGA

Power

Switch

Power

Switch

Programmable VCCIO

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V 0.6A

1 2

VCCIO Bank 3B

DC to DC

3.3, 2.5, 1.8V

1.5V FPGA

Power

Switch

Power

Switch

Programmable VCCIO

Bank 4A

1.5V, 1.8V, 2.5V, 3.3V 0.6A

1 4

VCCIO Bank 4A

VCCPD (FPGA architecture) while each bank has its own VCCIO. This adds some limitation to the banks power levels options. The following table describes the various possibilities:

The power option required can be set in two ways either via switches located on the SOM (can be used for debug and prototype) or via pins on the SMARC interface – this option must be used in production.

Note - the pins cannot be based on I/Os set by software the pin state should be stable at power up and cannot be changed after power up!

8 | Spark-100 HW user manual v1.3

Figure 3 - Bank 3B/4A Power Switching scheme

Port

(SMARC)

3.3V

2.5V

1.8V

1.5V

3B - Select 0

P73

Ground

Open

3B - Select 1

P74

Open

Ground

4A - Select 0

P76

Ground

Open

4A - Select 1

P81

Open

Ground

VCCPD_SEL_C

S77

Open

Ground

Programmable VCCPD

Bank 3B, 4A

2.5V, 3.3V 0.6A

1 2 3 4

3.3 V

Programmable VCCIO

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V 0.6A

Programmable VCCIO

Bank 4A

1.5V, 1.8V, 2.5V, 3.3V 0.6A

1 2 3 4

Only 3.3 V

MUST

2.1.3.1 Setting the power levels via the SMARC connector

The following table describes the setting of each pin for any available operation voltage. Note that all ports have internal pull up on the SOM.

2.1.3.2 Setting the power levels via the internal switches

The power levels of ports 3B and 4A can be set by dip switches located on the SPARK-100 board (SW2). There is a single switch that sets the VCCPD power for both banks and two switches that set the power of the VCCIO for each bank.

The following figures describe how to set the switch to the various options:

 The following figures describe power schemes where the VCCPD is set to 3.3V.

Figure 4 - Bank 3B and 4A VCCPD is 3.3V

 The following figures describe power schemes where the VCCPD is set to 2.5V.

9 | Spark-100 HW user manual v1.3

Programmable VCCPD

Bank 3B, 4A

2.5V, 3.3V 0.6A

1 2 3 4

2.5 V

Programmable VCCIO

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V 0.6A

Programmable VCCIO

Bank 4A

1.5V, 1.8V, 2.5V, 3.3V 0.6A

1 2 3 4

2.5 V

1.8 V

1 2 3 4

1.5 V

1.8 V

Programmable VCCIO

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V 0.6A

Programmable VCCIO

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V 0.6A

Figure 5 - Bank 3B and 4A VCCPD is 2.5V

When the VCCPD is set to 2.5V, each I/O can be separately set to 1.5V, 1.8V or 2.5V. Figure 5 describes two configurations in which the VCCPD is set to 2.5V.

In the top configuration Bank 3B's VCCIO is set to 2.5V and Bank 4A's VCCIO is set to 1.8V. In the bottom configuration Bank 3B's VCCIO is set to 1.8V and Bank 4A's VCCIO is set to 1.5V.

2.1.4 Bank3A and Bank4A Vref

Bank3B and Bank4A can support an external DDR3 interface assembled on the carrier board. The DDR requires reference voltage from the FPGA. These signals are available through the SMARC connector VREF_3B (P104) and VREF_4B (P105). If this option is not used these pins should be tied to ground.

2.2 Reset sources

The SPARK-100 supports three reset sources:

 Cold reset (RESET_IN# – P127 on the SMARC interface)

 Warm reset (FORCE_RECOV# - S155 on the SMARC interface)

 Debug Reset

10 | Spark-100 HW user manual v1.3

o Used to ensure the HPS is placed in a default state sufficient for software to boot o Triggered by a power-on reset and other sources e.g. push buttons on carrier board o Resets all HPS logic that can be reset o Affects all reset domains o This Reset is provided to the carrier board via P126

o Occurs after HPS has already been through a cold reset o Used to recover system from a non-responsive condition o Resets a subset of the HPS state reset by a cold reset o Only affects the system reset domain, which allows debugging (including trace) to

operate through the warm reset

o Occurs after HPS has already been through a cold reset o Used to recover debug logic from a non-responsive condition o Only affects the debug reset domain

The cold and warm resets are controlled by voltage supervisors which guarantee the reset duration. Both signals are available on the SMARC connector.

The FPGA can also be reset by the SOC ARM core or by an IO pin on the FPGA fabric.

When using the 128 MB QSPI Flash memory as a boot source the warm reset does not work automatically due to configuration issues of the QSPI memory. For more details:

http://www.rocketboards.org/foswiki/Documentation/SocBoardQspiBoot

For 32MB QSPI Flash memory configuration the problem is resolved.

11 | Spark-100 HW user manual v1.3

HPS

USB PHY

OTG

(USB3300)

Data[0..7]

Ctrl

USB Switch

(USB3740)

USB

USB HUB

(USB2422)

OTG

Host

USB_HUB_OTG_SEL (U19)

Module Carrier

2.3 HPS Interfaces

The Spark-100 offers a variety of interfaces from the HPS (SOC ARM core) such as USB, Ethernet, I2C, SPI, UART and more. The following paragraphs describe the various interfaces available along with recommendations on how to connect them to the carrier board.

2.3.1 USB

The SPARK-100 uses a single Host/Device (USB1) of the HPS. The USB port on the HPS features the following:

 Supports USB 2.0 host and device operation  Dual-role device (device and host functions)  High-speed (480 Mbps)  Full-speed (12 Mbps)  Low-speed (1.5 Mbps)  Supports USB 1.1 (full-speed & low-speed)  Integrated descriptor-based scatter-gather DMA (SGDMA)  Up to 16 bidirectional endpoints, including control endpoint  Up to 16 host channels  Supports generic root hub  Automatic ping capability  Configurable to OTG 1.3 and OTG 2.0

The card has two possible configurations for the USB usage based on internal USB switch (see figure 6):

 A single OTG port.  Two host ports using an internal HUB.

The selection is done using IO pin 0-0 of the I2C I/O expender.

Figure 6 - HPS USB Interfaces

A USB PHY device (USB3300 Microchip) is used to convert the HPS ULPI interface into a USB OTG interface. The USB OTG output is then connected to an analog USB switch (USB 3740). The switch connects the USB OTG interface directly to the SAMRC interface or to an internal USB HUB. The internal USB HUB (USB2422) is a two ports HUB providing two USB Host interfaces over the SMARC connector.

12 | Spark-100 HW user manual v1.3

HPS

Micrel

ksz9031

RGMII

4 x TX

4 x RX

Controls

125 Mhz

25M

Int. NReset

LEDS

GE Analog

CarrierModule

The default configuration of the USB switch enables the USB HUB interface. Each of the USB interfaces provides control signals (Power_EN, Over_Current) for controlling an external USB power distributer located on the carrier board.

2.3.2 Ethernet port

The SPARK-100 supports a single 10/100/1000 Ethernet interface from the HPS (RGMII 1). The Ethernet Phy in connected via an RGMII interface to the HPS. The following figure describes the Giga Ethernet interface.

Figure 8 - Giga Ethernet & Fast Ethernet Interfaces

The Ethernet PHY is KSZ9031 by Micrel. It uses an RGMII interface running at 125MHz. The 125 MHz clock is generated by the Ethernet PHY.

The Ethernet PHY analog signals (TX+/-, RX+/-) are connected the SMARC edge connector. Two LED signals from the GE PHY are also connected to the SMARC edge connector. MDC/MDIO - The Ethernet MDC/MDIO signals are connected to the internal phy and are not available on the SMARC connector.

2.3.3 UART

The SOM offer one or two UARTs. Each UART includes Rx, Tx , CTS and RTS. The HPS supports up to two UART interfaces. UART 0 is usually used for Linux CLI interface. Some of the UART signals share the same pins as the SPI interfaces which available on the SMARC connector.

 Programmable character properties, such as number of data bits per character, optional parity

bits, and number of stop bits.

 Programmable baud rate.  Automatic flow control mode per 16750 standard.  The maximum UART baud rate is 6.25 mega symbols per second.

2.3.4 CAN

The HPS offers up to two CAN controllers based on the Bosch® D_CAN controller and offer the following features:

13 | Spark-100 HW user manual v1.3

 Compliant with CAN protocol specification 2.0 part A & B.  Programmable communication rate up to 1 Mbps.  Holds up to 128 messages.  Supports 11-bit standard and 29-bit extended identifiers.  Programmable interrupt scheme.  Direct access for host processor.  DMA controller may be used for large transfers.

2.3.5 I2C overview

The Spark-100 uses two I2C buses of the HPS. The HPS offers the following I2C support:

- Maximum clock speed of up to 400 Kbps.

- 7- or 10-bit addressing.

- Mixed read and write combined-format transactions in both 7-bit and 10-bit addressing mode.

- Bulk transmit mode.

- Transmit and receive buffers.

- Handles bit and byte waiting at all bus speeds.

- DMA handshaking interface.

On the SPARK the I2C buses are used as follows:

 I2C0 is expanded to four I2C interfaces in order to meet the SMARC requirements providing

I2C_Cam, I2C_GP, I2C_PM and I2C_LCD buses.

o The buses can be used for any other application according need. o There are pull-up resistors on each bus, so there no need to put pull-up resistors on the

carrier board.

o The expansion is done using TI TCA9548A (8 channel I2C switch). Buses 0-3 of the device

are connected to the SAMRC connector, the other buses are unused.

 I2C1 is connected to the I2C controlled chips on the SOM and is not available externally. There

are several devices located on I2C1 bus:

o An I2C I/O expender using TI TCA6416A, for providing additional GPIOs for control and

monitor

o An E2PROM device Atmel AT24C01C, used for system parameters storage. o Control interface for the advanced clock distributor, the CDCM6208 by TI (assembled

only for SOM with Altera SX device) .

o A Digital Temperature Sensor for monitoring system temperature. The device used is TI

TMP108.

14 | Spark-100 HW user manual v1.3

Port

Signals

Description

I2C_CAM_D I2C_CAM _C

Enables access to I2C devices on Carrier I2C_CAM in SMARC standard

I2C_GP_D I2C_GP _C

Enables access to I2C devices on Carrier I2C_GP in SMARC standard

I2C_PM_D I2C_PM _C

Enables access to I2C devices on Carrier I2C_PM in SMARC standard

I2C_LCD_D I2C_LCD _C

Enables access to I2C devices on Carrier I2C_LCD in SMARC standard

4-7

Not Connected

HPS

Temp

Sens

Clk

Gen.

I/O

Exp.

EEP

ROM

I2C

Expander

I2C0

I2C1

CarrierModule

I2C_CAM

I2C_GP

I2C_PM

I2C_LCD

EXP

Figure 9 - SPARK-100 I2CInterfaces

2.3.6 I2C Mapping

2.3.6.1 I2C0 Expander Ports Allocation

The HPS I2C0 interface is connected to an I2C bus expander. The following table describes the I2C expender ports allocation.

15 | Spark-100 HW user manual v1.3

Port

Signal

Type

Description

0-0

USB_HUB_OTG_SEL

Out

Select between USB OTG and USB HUB "0" – OTG "1" – HUB

0-1

Main_CLK_SEL

Out

Do not use leave as input!

0-2

REF_CLK_SEL

Out

Select the clock generator source clock . "0" – Primary (internal) "1" – Secondary (external)

0-3

CLK_SYNC

Out

Synchronize the clock generator

0-4

CLK_PDN

Out

Disable the clock generator(clock generator ) "0" – Disable "1" – Enabled

0-5

CLK_RESETN

Out

Reset the clock generator(clock generator) "0" – Reset "1" – Normal

0-6 0-7

Not in Use

1-0 – 1-5

Connected to SMARC connector as GPIOs

Out

User define

1-6

SATA_ACT#

Out

SATA is active (When available) "0" – Off "1" – on

1-7 INT1_A

Out

On board debug Led "0" – off "1" – On

1 1 1 0 0 0 0

The I2C expander address is

0xE1 Read 0xE0 Write

2.3.6.2 I2C1 I/O Expander

The HPS I2C1 interface is connected to an I/O expander to enable more GPIO for control. The following table provides mapping of the I/Os:

2.3.6.3 I2C Address table

The following table describes the I2C addresses mapping:

16 | Spark-100 HW user manual v1.3

Ref.

Chip

I2C Port

Address A

Port

Address B

Description

PCA9548

0 1 1 1 0 0 0 0 RW I2C Interface Expander

SMARC

0 1 1 1 0 0 0 0 RW 0 X X X X X X X

RW I2C_CAM

0 1 1 1 0 0 0 0 RW 1 X X X X X X X

RW I2C_GP

0 1 1 1 0 0 0 0 RW 2 X X X X X X X

RW I2C_PM

0 1 1 1 0 0 0 0 RW 3 X X X X X X X

RW I2C_LCD

TCA6416A

1 0 1 0 0 0 0 0 RW

20 H I2C I/O Expander

Temp Sens

1 1 0 0 1 0 0 0 RW

48 H

Temperature Sensor

CLK_Gen

1 1 0 1 0 1 0 0 RW

54 H

Clock Generator

EEPROM

1 1 0 1 0 0 0 0 RW

50 H

EEPROM

Note: In some cases the SW handler will see the address space as a 7 bits range and so the address has to shift right one bit to match.

2.3.7 SPI

The SPARK-100 supports up to two SPI interfaces. Each port offers:

 Single CS signal for each SPI interface.  Programmable master serial bit rate up to 50 MHZ.  Serial master  Programmable data item size of 4 to 16 bits

Note – When the SPI interfaces are not in use, the pins can be configured as a GPIOs.

2.3.8 JTAG

The SPARK-100 integrates an optional on board 10 pins JTAG connector. The JTAG signals are also connected to the SMARC connector, an analog switch selects between the JTAG connector and the SMARC connector. The selection is done by a switch located on the SOM (SW3).

17 | Spark-100 HW user manual v1.3

Analog

Switch

TS3A5015

HPS

FPGA

Analog

Switch

TS3A5015

ModuleCarrier

JTAG_I/O

JTAG

I/O

TDI

TDO

SW - 2

SW - 1

The left pin is JSEL 1, the Lower side is off - '0'

The following figure describes the JTAG chain:

Figure 12 - SPARK-100 JTAG chain

A second switch can set the JTAG chain to include the HPS and FPGA or just the HPS. Both switches are located in SW3 (see picture below)

The switches options are as follows:

JSEL0 0 FPGA in Chain (default) 1 FPGA not in chain JSEL1 0 JTAG connector (default) 1 SMARC connector

Note: For production, the SOM provided without the JTAG connector; in that case the JTAG interface will be available only on the SMARC interface.

18 | Spark-100 HW user manual v1.3

Fan Out

Buffer

HPS CLK1 HPS CLK2

FPGA CLK1

FPGA

CLKIN1

High Speed Single PLL Clock Generator

CLKIN2

Bank

SMARC CONNECTOR

HPS

FPGA CLK2

CLKI0_p CLKI1_p

CLKI0_n/p CLKI1_n/p CLKI2_n/p CLKI4_n/p Transceiver CLKI Transceiver CLKI

Single ended 25 MHz

4 x Differential or 8 x Single ended Any Frequency / Any Voltage

100, 125, 150 MHz Differential

Any Clock Differential

25 MHZ

Local OSC 25 MHZ

CLKI3_n/p

CLK CLK

CLKI5_n/p

CLKI6_n/p

CLKI7_n/p

Basic Clock

High End Clock

Any Clock Differential or Single Ended

Same Pin

2.4 Clocks scheme

The SPARK-100 supports two clock schemes Basic – available when SOC SE devices are assembled or Advanced – available when SOC SX devices are assembled.

2.4.1 Basic clock architecture – SE SOC devices

This option is provided for SE devices. In that case an internal 25 MHz clock is used for driving the HPS clock inputs, it also provides two clock sources for the FPGA. These clocks are connected to CLK1P_V12 (pin V12 of the SOC) and to CLK0P (pin V11 of the SOC).

If additional clocks are required for the FPGA, they can be provided via the SMARC interface directly to the FPGA.

2.4.2 Advance clock Configuration – SX SOC assembly only

For applications that require enhanced clocking mechanism, the Spark offers an additional clock distributor device. The additional device used is CDCM6208 by TI, offering:

 Low Noise Synthesizer (265 fs-rms Typical < 1 ppm Frequency Error and Eliminates Jitter) or Low

Noise Jitter Cleaner (1.6 pSec - need for Crystal Oscillators and Other rms Typical Jitter).

 Any frequency using FPLL up to 800 MHz.  Support single ended or differential output.  Support several voltage levels, including a mix of levels.  4x Integer Down-divided Differential Clock.  4x Fractional or Integer Divided Differential.

The following figure describes the clock architecture:

19 | Spark-100 HW user manual v1.3

Figure 12 – Spark – clock scheme

Clock input

Clock source

Remarks

SEC_REFP – Pin 11

SMARC interface V5PCIE_C_REFCK+ Pin P80

Reference clock from SMARC connector

PRI_REFP – Pin 8

25Mhz internal

I/O

expender

port

Signal

Type

Description

0-2

REF_CLK_SEL connected to Pin 6 of the clock distributor

Out

Select the clock generator source. "0" – Primary (internal) "1" – Secondary

0-3

CLK_SYNC connected to Pin 42 of the clock distributor

Out

Synchronize the clock generator clocks For the clock device

0-4

CLK_PDN connected to Pin 43 of the clock distributor

Out

Disable the clock generator(clock device) "0" – Disable "1" – Enabled

0-5

CLK_RESETN connected to Pin 44 of the clock distributor

Out

Reset the clock generator(clock device) "0" – Reset "1" – Normal

Clock output

Clock destination

Remarks

Y0_P – Pin 14

Altera device - REFCLK0LP – Pin V5

Reference clock for the transceivers

Y0_N – Pin 15

Altera device - REFCLK0LN – Pin V4

Reference clock for the transceivers

Y1_P – Pin 17

SMARC interface PCIE_A_REFCK+ - Pin P83

Clock out to carrier board

Y1_N – Pin 16

SMARC interface PCIE_A_REFCK- - Pin P84

Clock out to carrier board

The Clock distributor has two clock sources either the internal 25 MHz clock or an external clock from the SMARC interface, the following table sum up the clock source options:

The selection between the clocks sources can be either automatic or using the REF_SEL pin (pin 6), the selection is done via the I2C I/O expender(located on I2C1 of the HPS)see table below:

The CDCM6208 offers 8 clock outputs, the following table sums up the available out clocks of the device:

20 | Spark-100 HW user manual v1.3

Y2_P – Pin 20

Altera device – REFCLK1LP – Pin P8

Reference clock for the transceivers

Y2_N – Pin 21

Altera device – REFCLK1LN – Pin N8

Ref clock for the transceivers

Y3_P – Pin 20

SMARC interface PCIE_B_REFCK+ - Pin S84

Clock out to carrier board

Y3_N – Pin 21

SMARC interface PCIE_B_REFCK- - Pin S85

Clock out to carrier board

Y4_P – Pin 26

Altera device – CLK0P – Pin V11

FPGA clock input. If a single ended clock is needed, use the P pin only!

Y4_N – Pin 25

Altera device – CLK0N – Pin W11

FPGA clock input.

Y5_P – Pin 29

Altera device – CLK1P – Pin V12

FPGA clock input. If a single ended clock is needed, use the P pin only!

Y5_N – Pin 28

Altera device – CLK1N – Pin W12

FPGA clock input.

Y6_P – Pin 32

Altera device – CLK2P – Pin Y13

FPGA clock input. If a single ended clock is needed, use the P pin only!

Y6_N – Pin 33

Altera device – CLK2N – Pin AA13

FPGA clock input.

Y7_P – Pin 35

Altera device – CLK4P – Pin Y24

FPGA clock input. If a single ended clock is needed, use the P pin only!

Y7_N – Pin 36

Altera device – CLK4N – Pin W24

FPGA clock input.

Note: If a single ended clock is required only the P line of the clock should be used.

21 | Spark-100 HW user manual v1.3

PIN_H4

GND

PIN_H5

GND

PIN_H6

GND

PIN_K8

GND

PIN_L8

GND

PIN_L9

GND

PIN_L10

GND

PIN_W19

Not connected, leave open

PIN_W20

GND

PIN_W21

GND

PIN_W24

GND

PIN_W25

Not connected, leave open

PIN_Y24

GND

2.5 FPGA

The Spark 100 offer a range of FPGA sizes starting from 25KLEs and up to 110KLEs. The FPGA offers 145 I/Os and optionally additional 6 high speed transceivers.

2.5.1 FPGA IOs variation

The Spark-100 support several SOC variations starting from 25KLE and up to 110KLE for both SE and SX series.

Altera offers the same package for all variations however there are differences between the pin out of the different FPGA sizes. The 110KLE and 85KLE share the same pin out while the 40KLE and 25KLE share different pin out.

The Spark was designed based on the 110/85 KLE (A6/A5) pin out which means that all the pins of the FPGA in that configuration are supported and available on the SMARC interface.

However when the A2 or A4(25KLEs or 40KLEs) devices are used the following pins are not available and should be handled as follows:

The following pins are tied to ground and are not available in the SMARC interface, since this is their functionality in the A5/A6 devices and so these pins should not be enabled in the FPGA when using an A2/A4 device:

The following pins are available for the A6 and A5 when using an A2 orA4 device they should be connected as follows:

22 | Spark-100 HW user manual v1.3

FPGA bank

Number of I/O

Voltage supported

Bank 3A

1.8V

Bank 3B

1.5V, 1.8V, 2.5V, 3.3V

Bank 4A

1.5V, 1.8V, 2.5V, 3.3V

Bank 5A

1.8V

Bank 5B 7 3.3V

Bank 8A 6 1.8V

An additional variation is between the SX and SE devices, the difference is the transceivers which are available on the SX devices. When using a Spark with SE device the following should be done:

 The transceivers received lines should be tied to ground.  The transmit lines should be left open.

2.5.2 FPGA IOs

The I/Os available are divided to banks according to the following table:

Note: All FPGA GPIO which can be differential pairs are routed as pairs to the SMARC connector.

2.5.3 Transceivers

The CycloneV SX family provides 6 transceivers at 3.125 Gigabits per second (Gbps). These transceivers comply with a wide range of protocols and data rate standards.

On the Spark the transceivers are routed as differential pairs to support high speed applications. The Spark also provide optional low jitter differential clock using a build in clock generator, with an option to provide differential clocks.

2.5.4 FPGA configuration

The FPGA can be configured in several ways:

2.5.4.1 Configuration via byte blaster

The Spark has an option for a build in JTAG connector for connecting the byte blaster (for development boards only), alternatively a byte blaster can be connected via the SMARC interface. For more details see the paragraph 2.3.8 on JTAG interface.

2.5.4.2 Configuration via Software

The FPGA can be easily configured via Software. The FPGA file should be placed in the FAT part of the SD used for software. The FPGA file should be in FPP 16(Fast parallel 16 bits), security disable, compression disable, RBF format, the file should be called fpga.rbf. The FPGA will be programed by the boot software,

23 | Spark-100 HW user manual v1.3

The left pin is MSEL 1, the upper side is off '0'

which means that FPGA download can be done without any customization of the SW thus ot provides total decoupling between the SW and HW development.

2.5.4.3 Supported configurations schemes

Note that the card support only FPP 16 mode if security and/ or compression are required these modes can be enabled via SW1 which controls MSEL 0 and MSEL 1. MSEL 4-2 are set to '0'.

The following MSEL modes are supported:

- 00000 Fast Parallel 16 bits

- 00001 Fast Parallel16 bits /Security enabled

- 00010 Fast Parallel16 bits /Compressed enabled

- 00011 Fast Parallel/Security enabled /Compressed enabled

2.6 HPS Memories scheme

The SPARK-100 includes several options for non-volatile memories for booting and data storage, including:

- A QSPI NOR memory (32MB or 128MB), can be used for a small footprint Linux version or RTOS.

- Internal eMMC device of 4GB up to 8GB, used for both software and storage.

- A small I2C memory 128x8 EEPROM, used for card details and can be used for system

parameters.

24 | Spark-100 HW user manual v1.3

HPS

eMMC

4-8GB

QSPI

1Gb

SDIO MUX

(TXS02612)

EEPROM

Authentication

QSPI

D[0..3]. Ctrl

I2C1

MMC

D[0..3], Ctrl

D[4..7]

uSD Card

Module Carrier

Select

Figure 6 – SPARK-100 Non-Volatile Memory

2.6.1 QSPI NOR memory

The Spark supports a QSPI NOR memory. The memory is connected to the QSPI interface of the HPS offering:

 4 bits Data bus.  Up to 108MHz clock.  Two ordering option 128Mbytes and 32Mbytes.

2.6.2 EEPROM

The Spark-100 is supports an internal I2C memory device Atmel AT24C01Ce, located on I2C1 bus of the HPS offering:

 1Kbit I2C memory.  Can be used as secure boot.  Can be used as MAC address for the GE interface.

Note: part of the memory is used for card ID.

2.6.3 eMMC (iNAND)

The Spark supports a 4GByte eMMC device offering:

 Up to 8 data bits.  Up to 50 MHz clock.

25 | Spark-100 HW user manual v1.3

Bsel value

Boot source

Support

000

Reserved

Not supported

001

FPGA (HPS-to-FPGA bridge)

Supported both pins should be set '0'

010

1.8 V NAND flash memory

Not supported

011

3.0 V NAND flash memory

Not supported

100

1.8 V SD/MMC flash memory with external transceiver

Not supported

101

3.0 V SD/MMC flash memory with internal transceiver*

Supported, Bsel 1 should be tight to '0'

110

1.8 V SPI or quad SPI flash memory

Not supported

111

3.0 V SPI or quad SPI flash memory

Supported, both pins should be left open

An 8GByte option is available as an ordering option.

2.6.4 SD/eMMC interface

The SPARK-100 has a single SD/MMC bus connected to the HPS. The HPS is connected via an internal multiplexer (TXS02612 - SDIO Port Expander by TI) to either an internal 4/8 bits wide eMMC or to an external 4 bits SD interface.

The control of the mux is done by GPIO44 of the HPS, ‘0’ – eMMC, ‘1’ - external SD. The mux can be controlled also via an external pin P123 in the SMARC interface.

The pin can be tight to the required mode or alternatively in order to leave the control to the software connect to an external pull up or pull down according to the required mode.

2.6.5 Boot options

The Altera SOC offers several boot options. These options are selected according to three pins (bsel 2-0). The Spark support only part of these options due to that bsel 0 is tight to '1' internally . The other two pins are connected to the SMARC interface, Bsel1 1 is P124 Bsel2 – P125 offering the following options:

* Note: If SD/eMMC mode is selected then the selection between SD and eMMC can be done as described in section 2.6.4.

2.6.6 DDR memory

The SPARK-100 integrates 32 bit wide DDR3 running at 400 MHz. The basic configuration is two chips of 256MBx16 (1GB solution). There is also an ordering options for 128MBx16 (512MB solution) and 512MBx16(2GB solution).

The DDR solution supports an 8 bit ECC option – special ordering option, contact sales@shiratech.com for more details.

26 | Spark-100 HW user manual v1.3

Signal

I/O

Description

Remarks

SD_MMC_SEL

GPIO44

Select between eMMC on SOM and uSD on carrier

0 – eMMC 1 - uSD

SD_PWR_EN

GPIO37

Enable power to the carrier uSD card

Active High

SD_CD#

GPIO9(in)

uSD card detect

0 – Card in 1 – No card

SD_WP#

GPIO0(out)

SD card write protect

Active Low

GE Interrupt

GPIO35(in)

Giga Ethernet Interrupt from PHY

Active Low

TEMP_ALM

GPI3(in)

Temperature Sensor Alarm

Active Low

IO_INT

GPI2(in)

I2C expander interrupt

Active Low

HPS

FPGA

DDR3

16 Bits

DDR3

16 Bits

DDR3

16 Bits ECC

DDR3

16 Bits (Optional)

Module Carrier

D[0..15]

D[16..31]

D[32..40]

Figure 7– SPARK-100 DDR support

2.7 Interrupt & I/O Table

The following table describes the role of the various HSP IO used on the Spark:

2.8 Temperature sensor

The Spark has a build in temperature sensor based on TI Digital Temperature Sensor TMP 108. The device is controlled via I2C1 bus.

2.9 Pin assignment

The connector offers 314 pins which are used for:

 Power  GPIOs

27 | Spark-100 HW user manual v1.3

 Fixed interfaces like GE and USB  RFU - unused pins reserved for future use.

The full pin out of the Spark is available in a dedicated document “SPARK pin out definition” available on the Shiratech web site.

28 | Spark-100 HW user manual v1.3

2.10 Mechanical considerations

The mechanical dimensions are according to the SMARC standard, the full details are available at

http://www.sget.org/standards/smarc.html .

The following figures are taken from the standard to show the physical dimensions of the module and the required layout of the carrier board. Note that the Spark is using the smaller option of 82x50.

29 | Spark-100 HW user manual v1.3

Vendor

Vendor P/N

Stack Height

Body Height

Contact Plating

Foxconn

AS0B821-S43B - *H

1.5mm

4.3mm

Flash

Black

Foxconn

AS0B821-S43N - *H

1.5mm

4.3mm

Flash

Ivory

Foxconn

AS0B826-S43B - *H

1.5mm

4.3mm

10 u-in

Black

Foxconn

AS0B826-S43N - *H

1.5mm

4.3mm

10 u-in

Ivory

Foxconn

AS0B821-S55B - *H

2.7mm

5.5mm

Flash

Black

2.10.1 SMARC connector

The SMARC connector is available from several vendors, below are the part list from Foxconn, other part numbers from other vendors are available in the SMARC HW specification.

30 | Spark-100 HW user manual v1.3

Foxconn

AS0B821-S55N - *H

2.7mm

5.5mm

Flash

Ivory

Foxconn

AS0B826-S55B - *H

2.7mm

5.5mm

10 u-in

Black

Foxconn

AS0B826-S55N - *H

2.7mm

5.5mm

10 u-in

Ivory

Foxconn

AS0B821-S78B - *H

5.0mm

7.8mm

Flash

Black

Foxconn

AS0B821-S78N - *H

5.0mm

7.8mm

Flash

Ivory

Foxconn

AS0B826-S78B - *H

5.0mm

7.8mm

10 u-in

Black

Foxconn

AS0B826-S78N - *H

5.0mm

7.8mm

10 u-in

Ivory

31 | Spark-100 HW user manual v1.3

Chip

Vendor

Details

CDCM6208

2:8 clock generator , jitter cleaner with fractional dividers

TCA9548A

Low Voltage 8-Channel I2C Switch With Reset

MT29F1G01AAADD

Micron

NOR Flash Memory - Serial Peripheral Interface (SPI)

TXS02612

SDIO port expander with voltage level translation

AT24C01C

Atmel

I2C-Compatible (2-wire) Serial EEPROM 1-Kbit (128 x 8)

USB3300

Microchip

High speed USB host device or OTG phy

USB3740

Microchip

High Speed USB 2.0 Switch with ESD Protection and Low Standby Current

TMP108

Low Power Digital Temperature Sensor With Two-Wire Serial Interface in WCSP

TCA9548A

Low voltage 8-channel I2C switch

USB2422

Microchip

2-Port USB 2.0 Hi-Speed Hub Controller

KSZ9031RN

Micrel

1G Ethernet Physical layer chip

Appendix 1 - Hardware devices used on the SOM

32 | Spark-100 HW user manual v1.3

Appendix 2 – Qsys parameters for the Spark

The following paragraph provides the HPS configuration used in the demo version provided for the Spark.

33 | Spark-100 HW user manual v1.3

The user can modify the configuration according to need. Care must be taken for interfaces which are connected to hardware devices located on the module like USB, GE, I2C etc…

For interfaces which are connected directly connected to Spark interface, the configuration is open, can should be taken to the power level provided to these interfaces.

34 | Spark-100 HW user manual v1.3
