Zigbee W ater Sensor Manual
ShenzhenYongchangdaElectronicsCo,Ltd
Zigbee Water Sensor
Model:OJB-LS712-Z
Operation instructions
Product Feature s:
Compatible with internationally accepted smart home
standards of Zigbee HA1.2 protocol
Use standard IEEE802.15.4 wireless communication
protocol;
Adopt ZigBee Technology,High Stability,effectively
eliminate co-channel problem
High stability Sensor
High quality water -retardant materials
Color: different color : golden ,grey ,white
Technical parameters
1.Size: 6.2cm diameter,4.5cm high
2Power supply: 3VDC(button cell battery)
3. Alarm: buzzer alarming,red light flashing,
4. . Networking model: zigbee HA1.2
5. Alarm Volume: ≥65dB
Power dissipation:
7. Static Current: ≤1μA
8. Alarm Current: 30mA～70mA
9. Working Temperature: -10 ℃～+60 ℃
10. Standby Time: 1～2 years
Network
Join network :
Automatically join:
After power on ,it will automatically within
30seconds time to search the network, if no network,
every 15 minutes will search one time until successfully
join to the network ;
Manually join :
Or short circuit CD(mark on the back) in a short
period of time (within 1 second) will try to searching
and join the networking
Leave network:
short circuit CD(mark on the back) in a period of
time last about 5 seconds and then release them ,
operate this step to make this device to leave from the
network
AB symbols is for water sensor
Zigbee W ater Sensor Manual
Precautions
1, As wireless communications, don’t put the product in
a metal box to work,
in case of signal is masked;
2, ambient temperature range from -10 to + 80 ;℃℃
3, avoid using in environments with chemical or
flammable gases,saturated smoke, high humidity or
other abnormal environments for a long time,
4.the medium have no enough gas and dust to corrode
metal Metal and damage the insulation.Also no danger
of explosion.
Warranty
1, About product quality problems, within 7 days free
returning, within one month free replace of same type
products;
2, The free warranty of company's products is one
year.(except appearance parts and damage caused by
personal wrong use), lifelong dimension Protection;
The following situations will not be in the range of free
warranty
1, disassemble or repair the machine by a
non-authorized service center;
2, Damage caused by flood, fire, lightning, etc natural
disasters;
3, Damage due to fall, extrusion, immersion,moisture
and others caused by human activity;
4, The products’ malfunction caused by using which
not in consistency with product parameters (voltage,
etc.) as instructions(Shell is not in warranty).
Special Note
This product should be coordinated with the gateway,
APP's Download and use details, pls check manual.
Shenzhen Yongchangda Electronics Co., Ltd.
To dear users:
Hello! Thank you for using OuJiabao smart home
products, we are dedicated to provide you the best
service.
FCC Statement
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions
(1)this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation
Service Center
Shenzhen Yongchangda Electronics Co,Ltd
ADD:, 3/F, Block 28, Gonghe First Industrial
Zone, Shajing, Bao'an, ShenZhen, Gu angdon
g, China
