Shen Zhen MTC 20071228001 User Manual

USER MANUAL

ATSC CONVERTER BOX

CHANNEL

ON
OFF

AT2016

AT2016

Please read this User Manual carefully to ensure proper use of this product and
keep this manual for future reference.

Table of Contents

Important Safety Instructions....................................................................1

1. Introduction.........................................................................................4

1.1 Remote control ..................................................................................5

1.1.1 Installing the batteries......................................................................6

1.1.2 Using the remote control ..................................................................6

1.2 Front Panel and Rear Panel Illustration ............................................... 7

1.2.1 Front Panel.....................................................................................7

1.2.2 Rear Panel .....................................................................................7

1.3 Connecting your Atsc Converter Box.................................................... 8

1.3.1 Connecting Antennas.......................................................................8

1.3.2 Connecting to a TV Set.....................................................................9

1.3.3 Connecting to an Audio System....................................................... 10

2.On-Screen Menus................................................................................11

2.1 Auto Program....................................................................................11

2.2 Manual Channel Set..........................................................................12

2.3 Password ........................................................................................ 12

2.4 Parental control ................................................................................ 12

2.5 Advanced Closed Caption.................................................................. 13

2.6 Language......................................................................................... 14

2.7 Auto Power Down Timer.................................................................... 14

2.8 Smart Antenna.................................................................................. 14

3. Troubleshooting ................................................................................ 15

4. Specifications ................................................................................... 16

5. Glossary............................................................................................ 17

Important Safety Instructions

1

This symbol indicatesthat this product incorporates
double insulation betweenhazardous mains voltage
and user accessible parts. When servicing use only
identical replacement parts.
WARNING: To reduce therisk of fire or electricshock,
do not exposethis apparatus to rain orcords.

1. The apparatus shall not be exposedto dripping
or Splashing and that no objects filledwith liquids,
such as Vases, shall be placedthe apparatus.

2. The mains plug is used as the disconnect device,
the disconnect device shall remain readily operable.

3. To be completely disconnect the power input,
the mains plugof apparatus shall be disconnected
from the mains.

4. The mains plug of apparatus should not be
obstructed or should be easily accessed during
intended use.

5. The battery (battery or batteries or battery pack)
shall not beexposed to excessive heat such as
sunshine, fire orthe like.

1. Read these Instructions.

2

2. Keep these Instructions.

3. Heed all Warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

Clean only with dry cloth.

6.

7. Do not block any of the ventilation openings. Install in accordance with the

manufacturers instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding - type plug.

A polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade or the third

prong are provided for your safety. When the provided plug does not fit into your

outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid injury from tip-over.

Portable Cart Warning

13. Unplug this apparatus during lightning storms or when unused for long

periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture , does not operate normally,

or has been dropped.

Note:

3

1. Important safety instructions shall be provide will each appliance.
These safety instructions may be in the form of a separate booklet, separate
sheet, or part of the instruction manual.

2. If included in the instruction manual, the safety instructions shall be located
before any operating instructions. 3. These instructions shall be entitled

IMPORTANT SAFETY INSTRUCTIONS .

4. The safety instructions shall include, as applicable to the particular apparatus,
the information and warnings listed before. The wording is capable of being
supplements, although not replaced, by drawing or cartoons.

5. The symbol shall be shown adjacent to the text of Important Safety Instructions

Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the users authority to operate the
equipment.

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

- Reorient or relocate the receiving antenna,

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

- Consult the dealer or an experienced radio TV technician for help.

,

4

Introduction

Thank you for purchasing this product which has been designed and manufactured
to give you many years of service.

About This User Guide

This user guide contains all the information you need to know about how to setup
and watch available digital TV channels using this ATSC Converter Box.

What's ATSC?

Advanced Television system committee, an international organization
establishing broadcasting standards for digital (including high-defimtion
and data broadcasting) television.

What's Digital Television?

Digital television (DTV) is a new way of transmitting high quality video and audio
to your TV set. Using DTV, broadcasters can transmit high definition TV (HDTV)
images, Dolby digital surround audio, and new services such as multiplexing
(transmitting more than one program on the same TV channel) and datacasting
(providing electronic program guides and interactive television). Several of these
services can be combined into a single digital broadcast.

How to View Digital Television?

DTV is broadcast from transmitters and received via a rooftop aerial. It works like
traditional TV, but because the signals are Digital you need an Atsc Converter Box
to convert them. There are three ways to watch DTV: an external DTV Atsc
Converter Box receiver to a DTV-ready television or an integrated digital TV with
a built-in digital television tuner or personal computer (PC) tuner cards and
computer monitors. An Atsc Converter Box receiver is the most popular case.

Look out for this symbol. It indicates useful and important tips
