Professional Series
™
Ionic Breeze GP
®
Silent Air Purifier
with Ultraviolet
Germicidal Protection
SI830 Instructions
Read and save these instructions.
SI830 IM_v1 0804 5/9/05 3:56 PM Page 1
SI830 IM_v1 0804 5/9/05 3:56 PM Page 2
Dear Sharper Image Customer,
Thank you for your purchase of a Sharper Image product. We appreciate
your business very much.
This item was created by Sharper Image Design, our company’s own
product development group. Please accept my personal assurance of your
complete satisfaction with this product’s quality and performance. We offer
generous return privileges and excellent warranties on all our products.
For more than 25 years, The Sharper Image has shared the fun of
discovering innovative products that make life better and more enjoyable. We’ve been in business a long time because we are an exciting
place to shop and — just as importantly — we strive to deliver great
customer service that exceeds your expectations.
Enjoy your purchase!
Respectfully,
Richard Thalheimer
Founder, Chairman and Chief Executive Officer
Call 1-800-344-4444 for 24-7 ordering and customer service,
or go to , our complete online store.
SI830 IM_v1 0804 5/9/05 3:56 PM Page 3
SI830 IM_v1 0804 5/9/05 3:56 PM Page 4
Warnings....................................................................................6
Caution ......................................................................................8
Frequently Asked Questions .......................................................9
Setup and Operation................................................................10
Cleaning the Collection Grid ....................................................12
Thorough Cleaning...................................................................14
Additional Information .............................................................15
Germicidal Lamp Replacement ................................................15
Statement of FCC/DHHS Compliance ......................................17
Table of Contents
SI830 IM_v1 0804 5/9/05 3:56 PM Page 5
Warning: To reduce the risk of fire, electric shock, or injury
when using any electrical appliance, basic precautions should
always be observed, including the following:
•This appliance operates at 110-120V AC and 60Hz only.
•Connect to a properly grounded outlet only.
•Use indoors only.
•Unplug from outlet when not in use and before servicing.
•Do not allow the appliance to be used as a toy. Close attention
is necessary when the appliance is operated near children.
•Use only as described in this user manual.
•Do not use if cord or plug appears to be damaged. If the
appliance is not working properly or has been dropped,
damaged, left outdoors, or dropped into water, return it
to a service center or to the original place of purchase.
•Do not pull, lift or carry by the power cord. Do not use the
cord as a handle, close a door on the cord, or pull the cord
around or against sharp edges or corners.
•Keep the cord away from heated surfaces.
Warnings
6
SI830 IM_v1 0804 5/9/05 3:56 PM Page 6
•A damaged power cord must be replaced by qualified service
personnel only. There are no user-serviceable parts inside the
unit. Any attempt to open the unit will void the warranty and
could lead to serious damage to the unit and/or personal injury
to the user.
•Before unplugging unit from the outlet, turn off all the controls.
•Do not unplug by pulling the cord. Grasp the plug itself, not
the cord, when unplugging from an outlet.
•Do not handle the plug or appliance with wet hands.
•Do not put any object into openings. Do not continue to use
with any opening blocked. Keep all openings free of dust, lint,
hair or anything that may reduce airflow.
•Keep hair, loose clothing, fingers and all parts of the body away
from openings.
•Do not operate the unit in areas where flammable or combustible
products or vapors may be present.
READ AND SAVE THESE INSTRUCTIONS
Warnings
7
SI830 IM_v1 0804 5/9/05 3:56 PM Page 7
This product generates invisible ultaviolet light. To avoid overexposure when the lamp is on, persons must stay at least one foot
away from the unit if the total duration of exposure to the unit
will be more than 30 minutes per day. Shorter duration of exposure
at close proximity is safe. If the enclosure is damaged, do not use
the product.
Never stare at the U.V. lamp or place your face directly against
the front or rear grill during operation.
Failure to follow these warnings can result in direct exposure to
germicidal light, which can cause temporary or chronic damage
to your eyesight, or may even result in blindness.
The collection grid has many edges and areas that can trap water.
If running water is used to clean the grid, allow the collection grid
to dry completely.
If candles or oil lamps are burned, the collection grid must be
cleaned immediately or the collected soot may be released back
into the room. In any area where this product will be subjected
to heavy pollution it will be necessary to clean the collection grid
more frequently.
Caution
8
SI830 IM_v1 0804 5/9/05 3:56 PM Page 8
How often is cleaning required?
At least every two weeks or anytime the Ionic Breeze
®
makes an
audible sound or the cleaning indicator lights.
How should it be cleaned?
Wipe the removable collection grid with a damp cloth, paper
towel or sponge. It is very important that the collection grid be
allowed to dry completely before returning it to the main housing.
What is the clean fresh scent I smell?
This scent is ozone (O
3
), a combination of three oxygen atoms.
(The U.S. government has set safe standards for ozone and the
Ionic Breeze complies with those standards.)
Which power setting should I use?
If the odor of ozone is strong (for instance in a smaller room),
you may prefer to have the power setting on medium or low.
Please read this product instruction manual for important
safety information and operating instructions.
Frequently Asked Questions
9
SI830 IM_v1 0804 5/9/05 3:56 PM Page 9
Place the Professional Series™
Ionic Breeze GP
®
at least twelve
inches from the wall and in a
location where children cannot
stare directly into the unit at a
close range.
Plug into a grounded 110V
outlet. (Read Warnings for details.)
Switch the MODE CONTROL
to the desired setting:
ON - The unit will clean and
circulate the air but the germicidal lamp is not activated.
ON/G.P. - Air is also passed
through the UV light produced
by a germicidal lamp.
10
Setup and Operation
Blue Glow
coming from
within the
unit indicates
that the
germicidal
lamp is
operating.
12"
Mode
Control
SI830 IM_v1 0804 5/9/05 3:56 PM Page 10
Switch the POWER CONTROL
to the desired HI, MED or LO
setting:
Normal operation at all power
levels involves a preprogrammed
cycle of altering high and low
air movement.
To override the POWER CONTROL
setting and to run the unit at
maximum power for five minutes,
press BOOST/IONS until the button
turns blue.
Your previously selected power
level resumes after five minutes.
To activate the Negative-Ion Feature™, press BOOST/IONS
until the button turns green. This feature adds millions of negative ions to the airflow to freshen your indoor environment. To
cancel, press the button again.
Setup and Operation
11
Power
Control
Boost/Ions
SI830 IM_v1 0804 5/9/05 3:56 PM Page 11
Note: Use of this feature increases negative-ion output and
may increase soot buildup near the product.
Cleaning the Collection Grid
Clean the grid every one or two weeks. As a reminder, the cleaning
indicator light turns amber after two weeks. If the cleaning indicator
light turns red, the unit has shut down because of excessive dirt or
circuitry problems. In most cases, a thorough cleaning returns the
unit to normal operation.
Before cleaning, unplug the unit.
Remove the collection grid by
releasing the latch and pulling
the grid from the top of the unit.
Setup and Operation
12
Collection
Grid Release
Latch
SI830 IM_v1 0804 5/9/05 3:56 PM Page 12
Use a dry or slightly damp towel
or sponge to quickly wipe the
dust from each of the three
collection bars.
Before replacing the grid, invert
the entire unit two or three times.
2X
Cleaning the Collection Grid
13
SI830 IM_v1 0804 5/9/05 3:56 PM Page 13
If the unit makes noise during operation, a thorough cleaning of
the grid and ionizing wires may be required.
Remove the collection grid by
pulling it from the top of the unit.
Wash the grid with warm soapy
water, rinse and allow to dry for
24 hours before returning to unit.
Use a compressed gas dusting
product to remove any accumulated particles from the ionizing
wires and to blow out any dust
that is settled in the base of the
unit. (Because of the dust, it is
advisable to do this outside.) The
Professional Series™ Ionic Breeze
GP
®
also features a rear grill that
slides off for easy cleaning.
Thorough Cleaning
14
SI830 IM_v1 0804 5/9/05 3:56 PM Page 14
The exterior of the unit can be cleaned using a cloth or sponge
and a solution of one part household bleach to five parts water
or any bleach-based spray cleaner.
Before plugging the unit back into an outlet, allow the surface to
dry completely.
The unit will not function while the collection grid is removed
and/or the germicidal lamp cover is removed.
The Ionic Breeze
®
complies with U.S. safety standards for low
ozone emission (less than 50 parts per billion). We recommend that
individuals with a history of respiratory disease consult with their
doctor about possible heightened sensitivity to very low ozone.
Germicidal Lamp Replacement
To order replacement lamps directly from The Sharper Image,
call 1-800-344-4444 and order item number SI922.
Lamps are effective for about 12 months of continuous use. To
maintain maximum performance, the lamp should be wiped free
of particles every three months.
Additional Information
15
SI830 IM_v1 0804 5/9/05 3:56 PM Page 15
Oil from fingers will reduce the germicidal performance of the
U.V. lamp. If possible, use gloves or handle only by the metal
area of the lamp. Otherwise, clean the lamp after installing to
remove fingerprints and oils.
To clean: Wipe the lamp, using a paper towel lightly dampened
with rubbing alcohol or an ammonia-based cleaner (such as
Windex brand).
Remove the cover by lifting up
on the RELEASE TAB at the bot-
tom of the cover and sliding the
the cover upward.
Turn the lamp 1/4 turn (two
“clicks”) and slide it from its
fixture. Replace with a new
one of the same type.
Dispose of used fluorescent
lamps in accordance with local
regulations.
Germicidal Lamp Replacement
16
Release
Tab
SI830 IM_v1 0804 5/9/05 3:56 PM Page 16
17
WARNING: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This product complies with DHHS Rule 21 subchapter J
at date of manufacture.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Statement of FCC/DHHS Compliance
SI830 IM_v1 0804 5/9/05 3:56 PM Page 17
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
assistance.
Statement of FCC/DHHS Compliance
18
SI830 IM_v1 0804 5/9/05 3:56 PM Page 18
SI830 IM_v1 0804 5/9/05 3:56 PM Page 19
What Is Covered
This warranty covers any defects in materials or workmanship, with the exceptions stated below.
How Long Coverage Lasts
This warranty runs for five years from the date of original purchase.
What Is Not Covered
This warranty does not cover damage caused by misuse or use other than as intended and described in the
product instruction manual, or loss or damage to batteries or removable parts.
What The Sharper Image Will Do
The Sharper Image will repair any defects in materials or workmanship. In the event repair is not possible,
The Sharper Image will either replace this product with one of similar features and price, or refund the full
purchase price of the product, whichever you prefer.
How to Obtain Service
Return the product and receipt, along with a brief explanation of the problem, to:
T.S.I. - Returns Department
2901-A West 60th Street
Little Rock, AR 72209
If you have questions please feel free to contact our customer service representatives at 1-800-344-5555 or
by email at care@web.sharperimage.com.
This warranty gives you specific legal rights, and you may have other legal rights that vary from state to state.
© 2004, 2005 Sharper Image Corporation
Sharper Image Corporation
650 Davis St., San Francisco, CA 94111
(415) 445-6000
Shop online:
Due to continuing improvements, actual product may differ slightly from the product described herein.
V2 08/04
Full Five-Year Warranty
SI830 IM_v1 0804 5/9/05 3:56 PM Page 20
Loading...
