Sharper Image DX-2 User Manual

RECHARGEABLE 2.4GHz - DX-2 STUNT DRONE

12+

Getting to Know Your Drone

PLEASE READ ALL WARNINGS AND INSTRUCTIONS PRIOR TO USE. KEEP THIS DOCUMENT AS IT CONTAINS IMPORTANT INFORMATION ABOUT YOUR DRONE.

1. PREPARE FOR FLIGHT

• Drone must be charged before each use (Cable included)

• Indicator light will turn off once fully charged

• Install batteries in remote

2. PAIR YOUR DRONE

Before each flight pair the remote with the drone:

1. Turn your drone on and place on a flat, level surface

2. Turn on the remote on and move the left joystick down, then up, then down again

3. The beep will indicate successful pairing

3. DIRECTIONAL LIGHTS

1. Turn your drone on and place on a flat, level surface

2. Turn on the remote on and move the left joystick down, then up, then down again

3. The beep will indicate successful pairing

4. REMOTE CONTROL OVERVIEW

Practice flying your drone below 10 feet and at low speeds until comfortable with all controls to avoid unnecessary damage or injury

• Left joystick:

• Up/Down controls elevation

• Left/Right controls spin

• Right joystick: controls flight direction

• Direction Trim: use to eliminate drift To cut power to drone, move left joystick to down position

QUESTIONS OR CONCERNS?

PLEASE GIVE US A CALL ... WE’RE HERE TO HELP

ADULT ASSEMBLY, CHARGING, AND

BATTERY INSTALLATION IS REQUIRED.

ADULT SUPERVISION IS REQUIRED.

CUSTOMER SERVICE

(800) 374-2744

Before calling please locate the 10-digit code printed on the back of your remote

CHOKING HAZARD -

Not for Children under 3 years.

WARNING:

Small Parts.

1-800-374-2744.

The artwork and design of this manual are protected by US copyright law and may not be reproduced, distributed, displayed, published or used for any purpose without prior written permission. It is not permitted to alter, remove or reproduce any trademarks or copyright notice from this manual.

Printed in China.

KEEP THIS INSTRUCTION MANUAL AS IT CONTAINS IMPORTANT INFORMATION FOR FUTURE REFERENCE.

Due to continuous product improvements, the picture on the manual may differ slightly from the actual product.

PATENT PENDING

RECHARGEABLE 2.4GHz - DX-2 STUNT DRONE

INTRODUCTION

Congratulations on your purchase of the Rechargeable 2.4 GHz DX-2 Stunt Drone. Get ready to soar to new heights. Master the art of drone flying and stunting with remote control maneuverability. This lightweight stunting drone will provide hours of fun.

TABLE OF CONTENTS

SPECIFICATIONS

Drone Battery: 350 mAh Li-po

Remote Controller Battery: 6 x 1.5V AA

Charging Time: Approximately 60 minutes

Maximum Recommended Altitude 115 ft.

General Warnings Page 1 Contents, Remote Battery Installation, Battery Warnings Page 2 Charging LiPo Battery and Installing Blade Guards Page 3 Remote Overview Page 4 Operating Drone Page 5 Modes, Replacing Propellers, and Tips Page 6

iPrinted in China.

RECHARGEABLE 2.4GHz - DX-2 STUNT DRONE

READ ALL WARNINGS AND PRECAUTIONS BEFORE USE

• Not recommended for children under 12 years of age. As with all electrical products, precaution should be observed during handling and use to reduce the risk of electrical shock.

• Adult supervision is required at all times.

• Before each use, an adult should review the product and battery to determine that no damage or hazards exist.

• DO NOT TOUCH SPINNING PROPELLERS

• Do not allow anything to intentionally make contact in any way with spinning propellers

o Prevent contact with spinning blades by turning off remote prior to handling drone

• Use caution and pay attention to your surroundings while operating drone

• Do not fly drone into animals, people, or inanimate objects

• Keep drone away from power lines, buildings, trees, public areas, and any other potentially hazardous areas.

• Do not operate in rain, heavy wind, and or any type of severe weather.

• Do not land drone on wet surfaces.

• Never touch or allow others to touch drone while it is flying.

• Always turn drone off when it is not in use.

• Always fly drone in large open areas.

• Never fly drones above or near people, sudden changes in wind or other conditions could lead to unexpected crashes.

• Always use caution when flying drone vehicles, obey relevant laws, respect the privacy and property rights of others.

• The drone shall never be modified or used for anything except its intended purpose.

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Fly-aways are the responsibility of the individual pilot and will not be replaced by the manufacturer.

This drone weighs .08 lbs. As of December 21, 2015, the Federal Aviation Administration (FAA) only requires registration on unmanned aircrafts weighing more than .55 lbs. Visit www.faa.gov/uas/registration/ for more information. Although the FAA does not require this drone to be registered, ongoing compliance with federal, state, and local laws is an owner’s sole responsibility. Always fly safely and respect the privacy of others.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

TROUBLESHOOTING:

When remote switch is turned on, the remote light does not illuminate:

1) Check that batteries in the remote are installed correctly OR

2) Replace with new batteries

When the remote is switched on, the remote LED is flashing and remote is beeping:

1) Remote batteries are low; replace them with new batteries

Drone and remote properly pair, but the drone will not lift-off:

1) Drone Li-Po needs charging. Use charging cable to connect the drone to power source.

After trimming the drone, the drone flight is very unstable and cannot fly properly:

1) One or more blades are most likely damaged;

2) Turn off the drone and remote.

3) Replace with the proper number replacement blade and try flying again.

After impact, the drone is unstable:

1) Put the left remote control lever to the left bottom and put the right remote control lever to the right bottom at the same time which connected to the drone (diagram to right).

2) If the above does not resolve the issue, reboot the drone and controller and pair again.

Remote Controller and Drone can not be paired:

1) Check Point: Remote Controller must be closed to Drone, not exceed 4 meters.

Note: If there are 2 sets of Drones within 4 meters for Pairing, you must pair one successfully before pairing the second set.

DIRECTIION

SPIN

TRIM

1Printed in China.
