Sharp VL-AH130U User Manual
LIQUID CRYSTAL DISPLAY CAMCORDER
OPERATION MANUAL
Operation Summary
MODEL
VL-AH130U
Preparation
Camera Recording
Basic Operations
Basic Operations
Playback
Useful Features
NTSC
Please read this operation manual
carefully before using the VIEWCAM.
Important
For assistance in reporting the theft or
this product, record on the line
model number and serial number which
are located on the bottom of the unit.
Please retain this information.
Model No.:
Serial No.:
• See page 54 for use of Demo mode.
loss of
below the
Advanced Features
References
Thank you for purchasing this VIEWCAM from SHARP.
The VIEWCAM will enhance your home video enjoyment and allow you to capture those
special moments. Please read this operation manual to familiarize yourself with the
VIEWCAM’s features, so that you will get the most out of it. The video techniques section will
help you fully enjoy the many features this VIEWCAM offers, and expand your video world.
Important Information for Consumers in the U.S.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol warns the user of uninsulated voltage within the
unit that can cause dangerous electric shocks.
This symbol alerts the user that there are important operating
and maintenance instructions in the literature accompanying
this unit.
CAUTION
(applies to the supplied AC adapter)
TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
If the AC adapter is misplaced or
needs to be replaced, obtain the
same type of adapter from a SHARP
service center of your dealer.
PRODUCT DISPOSAL
This Product utilizes tin-lead solder, and a fluorescent lamp containing a small
amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your
local authorities or the Electronics Industries Alliance: www.eiae.org.
BATTERY DISPOSAL
CONTAINS NICKEL-METAL HYDRIDE RECHARGEABLE BATTERY. MUST BE
RECYCLED OR DISPOSED OF PROPERLY. CONTACT LOCAL AGENCIES FOR
INFORMATION ON RECYCLING AND DISPOSAL PLANS IN YOUR AREA.
i
WARNING—FCC Regulations state that any unauthorized changes or
modifications to this equipment not expressly approved by the manufacturer could
void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON LITHIUM BATTERY (MEMORY BACKUP BATTERY)
If a battery is reversed (positive end where the negative end belongs and vice
versa), it can overheat and rupture. This has happened when young children install
not
batteries backwards. Warn children
to take out batteries or install them.
should install the lithium battery in the VIEWCAM.
Parents
Your VIEWCAM is designed to record in SP mode only. It will not perform normal
playback for programs prerecorded in LP mode.
This VIEWCAM does not have a PCM recording or playback function. PCM recordings made using
other VCRs or audio dubbing cannot be played back on this unit.
If you record on a tape on which PCM sound has already been recorded, the audio track of the
new VIEWCAM recording may not come out if the tape is played back on a PCM-capable VCR. If
this occurs, set the VCR’s audio monitor select switch to the “STANDARD” position.
COPYRIGHT WARNING: It is the intent of SHARP that this unit be used in full compliance with the
copyright laws of the United States and that prior permission be
obtained from copyright owners whenever necessary.
NOTE
The VIEWCAM’s LCD panel is a very high technology product with close to 90,000 thin-film
transistors*, giving you fine picture detail. Occasionally, a pixel may appear on the screen as a
fixed point of blue, green, red, or black. Please note that this does not affect your VIEWCAM’s
performance.
*Specifications are subject to change without notice.
ii
IMPORTANT SAFEGUARDS
1. Read Instructions—All the safety and
operating instructions should be read
before the product is operated.
2. Retain Instructions—The safety and
operating instructions should be
retained for future reference.
3. Heed Warnings—All warnings on the
product and in the operating instructions should be adhered to.
4. Follow Instructions—All operating and
use instructions should be followed.
5. Cleaning—Unplug this product from the
wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
6. Attachments—Do not use attachments
not recommended by the product
manufacturer as they may cause
hazards.
7. Water and Moisture—Do not use this
product near water—for example, near
a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near
a swimming pool; and the like.
8. Accessories—Do not place this product
on an unstable cart, stand, tripod,
bracket, or table. The product may fall,
causing serious injury to a child or
or table recommended by the manufacturer, or sold with the product. Any
mounting of the product should follow
the manufacturer’s instructions, and
should use a mounting accessory
recommended by the manufacturer.
9. A product and cart
combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces
may cause the product
and cart combination to overturn.
10. Ventilation—Slots and openings in the
cabinet are provided for ventilation and
to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be
blocked or covered. The openings
iii
should never be blocked by placing the
adult, and
serious damage
to the product.
Use only with a
cart, stand,
tripod, bracket,
product on a bed, sofa, rug, or other
similar surface. This product should not
be placed in a built-in installation such
as a
bookcase
or rack
unless
proper
ventilation is
provided or the manufacturer’s instruc-
tions have been adhered to.
11. Power Sources—This product should
be operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supply to your home, consult your
product dealer or local power company.
For products intended to operate from
battery power, or other sources, refer to
the operating instructions.
12. Grounding or Polarization—This product
may be equipped with a polarized
alternating-current line plug (a plug
having one blade wider than the other).
This plug will fit into the power outlet
only one way. This is a safety feature. If
you are unable to insert the plug fully
into the outlet, try reversing the plug. If
the plug should still fail to fit, contact
your electrician to replace your obsolete
outlet. Do not defeat the safety purpose
of the polarized plug.
13. Power-Cord Protection—Power-supply
cords should be routed so that they are
not likely to be walked on or pinched by
items placed upon or against them,
paying particular attention to cords at
plugs, convenience receptacles, and
the point where they exit from the
product.
14. Lightning—For added protection for this
product during a lightning storm, or
when it is left unattended and unused
for long periods of time, unplug it from
the wall outlet and disconnect the
antenna or cable system. This will
prevent damage to the product due to
lightning and power-line surges.
15. Power Lines—An outside antenna
system should not be located in the
vicinity of overhead power lines or other
electric light or power circuits, or where
it can fall into such power lines or
circuits. When installing an outside
antenna system, extreme care should
be taken to keep from touching such
power lines or circuits as contact with
them might be fatal.
16. Overloading—Do not overload wall
outlets, extension cords, or integral
convenience receptacles as this can
result in a risk of fire or electric shock.
17. Object and Liquid Entry—Never push
objects of any kind into this product
through openings
as they may touch
dangerous
voltage points or
short-out parts
that could result in
a fire or electric shock. Never spill liquid
of any kind on the product.
18. Servicing—Do not attempt to service
this product yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified service
personnel.
19. Damage Requiring Service—Unplug
this product from the wall outlet and
refer servicing to qualified service
personnel under the following conditions:
a. When the power-supply cord or plug
is damaged,
b. If liquid has been spilled, or objects
have fallen into the product,
c. If the product has been exposed to
rain or water,
d. If the product does not operate
normally by following the operating
instructions. Adjust only those
controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often
require extensive work by a qualified
technician to restore the product to
its normal operation,
e. If the product has been dropped or
damaged in any way, and
f. When the product exhibits a distinct
change in performance—this
indicates a need for service.
20. Replacement Parts—When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have
the same characteristics as the original
part. Unauthorized substitutions may
result in fire, electric shock, or other
hazards.
21. Safety Check—Upon completion of any
service or repairs to this product, ask
the service technician to perform safety
checks to determine that the product is
in proper operating condition.
22. Wall or Ceiling Mounting—The product
should be mounted to a wall or ceiling
only as recommended by the manufacturer.
23. Heat—The product should be situated
away from heat sources such as
radiators, heat registers, stoves, or
other products (including amplifiers)
that produce heat.
iv
Precautions
• When the VIEWCAM is not in use,
remember to remove the cassette tape,
turn off the power, and disconnect the
VIEWCAM from the power source.
• Do not aim the lens at the sun.
Do not allow direct sunlight to strike the
VIEWCAM lens or LCD monitor screen,
whether or not recording is in progress, as it
may damage the CCD sensor or LCD screen
surface. Be particularly careful when
recording outside.
• When shooting in dark places, avoid sudden
brightly lit objects or light sources, such as
the sun. Otherwise, the image may white out.
Should this happen, point the lens in a
different direction until the picture returns to
normal.
• Avoid magnetic
sources.
Using the VIEWCAM
near strong fluorescent
lights, motors,
televisions, or other
magnetic sources may adversely affect
recorded images.
• Using the VIEWCAM near a broadcasting
station or other powerful transmission
source may cause buzzing or picture
deterioration.
• Avoid shocks and
dropping.
Do not drop or otherwise
subject the VIEWCAM to hard
shocks or strong vibrations.
Bumping or striking the unit
during recording will
generate noise in the
recorded image.
• Avoid placing the
VIEWCAM in close
proximity to lighting
equipment.
The heat from
incandescent lights
may deform the
VIEWCAM, or cause it
to malfunction.
• Always respect prohibitions or restrictions
on the use of electronic equipment on
commercial flights or in other sensitive
areas.
• Be aware of the temperature and humidity.
You can use your VIEWCAM at 0 C to 40 C
(32F to 104F), and at 30% to 80% relative
humidity. Do not store the unit in an
unventilated car in the
summer, in direct
sunlight, or near strong
heat sources; this can
result in severe damage
to the unit casing and
circuitry.
• Avoid situations where water, sand, dust or
other foreign matter could get on or inside
the VIEWCAM, and do not use or leave
your VIEWCAM in areas with excessive
smoke, steam or moisture.
Such environments can
cause malfunctions or
cause mildew to form
on the lenses. Be sure
to keep the unit in a
well-ventilated location.
• Some small, portable
tripods may be difficult to
attach and may not be
sturdy enough to support
your VIEWCAM. Be sure to
use only a strong, stable
tripod.
• When using your VIEWCAM in a cold
environment, the LCD monitor screen often
appears less bright immediately after the
power is turned on. This is not a
malfunction. To prevent the VIEWCAM from
becoming too cold, wrap it in a thick cloth
(a blanket, etc.).
v
About Y our VIEWCAM
Recording Format
Hi8 is a high-performance extension of the
ordinary 8 mm format. It uses advanced
technology to achieve even higher resolution
and picture quality. Use a video cassette with
the mark for high-quality recording and
playback, or with the mark to enjoy ordinary
8 mm recording and playback.
• When you load a Hi8 tape, recording is in Hi8
format. (The indicator appears on the
LCD screen.) When you load a normal 8 mm
tape, recording is in ordinary 8 mm format.
(The indicator does not appear.)
• During playback, the recorded format is
automatically detected.
• Video equipment not for use with Hi8 is
unable to play back a tape recorded in Hi8
format.
• If you want to record with a Hi8 tape in normal
8 mm format, set the menu item to
“OFF” on the (MENU 1) screen (Camera
mode) before recording. (See page 25 for
operation of the menu screen.)
LCD Monitor Screen
The VIEWCAM is equipped with a large LCD
monitor screen that allows you to record
scenes while comfortably holding the
camcorder. The LCD monitor screen can be
rotated for easy recording at high or low
angles. It also functions as a handy playback
monitor so you can enjoy what you have just
recorded.
Cautions:
• Do not apply pressure to the screen.
• Do not expose the screen to shocks, as it may
break.
• Do not place the VIEWCAM with the screen
facing down.
Note:
• Use a soft cloth to clean the screen.
vi
Supplied Accessories
Battery pack
*BT-H22
CR2025 type
lithium battery
*Note: The part numbers for the AC adapter and battery pack supplied with this VIEWCAM are valid
only in the U.S. and Latin America. If this VIEWCAM was purchased outside of these areas, the part
numbers may be different. Please refer to the part numbers printed on the labels of the supplied AC
adapter and battery pack.
AC adapter
*UADP-0312TAZZ
Shoulder strap
UBNDS0010TASA
Infrared remote control
RRMCG0084TASA
Lens cap
GCOVH1225TASA
Audio/video cable
QCNW-1448TAZZ
or QCNW-1295TAZZ
AA battery for
remote control 2
vii
Optional Accessories
Standard type
battery pack
BT-H22
Tripod adapter
for 180° recording
VR-33FAN
Note: The listed model names are for U.S. accessories.
For optional and additional accessories, contact your local dealer, call the Sharp
Accessories and Supply Center at 1-800-642-2122, or visit SHARP’s website
(http://www.sharp-usa.com).
Extended type
battery pack
BT-H32
Sun hood
VR-60BFN
Accessory
shoe adapter
VR-30ADN
viii
Contents
Operation Summary Part Names .......................................................... 3
Quick Reference Index ........................................ 5
Warning Indicators ............................................... 6
Preparation
Basic Operations
Inserting and Removing the Battery Pack ........... 7
Charging the Battery Pack ................................... 8
Powering the VIEWCAM from an AC Outlet........... 9
Inserting and Removing a Cassette .................. 10
Installing the Lithium Memory Battery ................ 11
Selecting the Language for the On-screen
Display ............................................................. 12
Setting the Date and Time ................................. 16
Using the Hand Strap and the Lens Cap........... 17
Attaching the Shoulder Strap ............................. 17
Camera Recording
Easy Camera Recording with Full Auto Mode ... 18
Zooming ............................................................. 19
Tips on Recording Positions .............................. 19
Remaining Recording Time Display .................. 20
Remaining Battery Power Display ..................... 20
Playback
Playback ............................................................ 21
Volume Control ................................................... 21
Watching the Playback on a TV ......................... 22
Video Search...................................................... 23
Still...................................................................... 23
Slow.................................................................... 23
1
Operation Summary
Useful Features
Advanced Features
Operations of the On-screen Controls
Using the Control Buttons............................... 24
Selecting the Mode/Menu Screens ................ 24
Adjusting the Menu Settings........................... 25
Recording the Date and Time ............................ 26
Fade In and Fade Out ........................................ 27
Quick Review ..................................................... 28
Quick Return ...................................................... 29
Edit Search......................................................... 29
Gamma Brightness Compensation .................... 30
Gain-up (Cat’s Eye)............................................ 31
Wide Screen (16:9) ........................................... 32
Macro Shots ....................................................... 32
Removing the Lens Hood .................................. 32
Self Recording ................................................... 33
Setting the VIEWCAM to Full Auto Mode ........... 35
Program Search ................................................. 36
Tape Counter Feature ........................................ 37
Using the Remote Control .................................. 39
Digital Picture Effects ......................................... 40
Scene Menu (Program AE) ................................ 41
Superimposing a Title ........................................ 42
Changing the Preset Titles ................................. 43
Auto/Manual Focus ............................................ 44
White Balance Lock ........................................... 45
Manual Exposure ............................................... 46
Picture/Backlight Adjustments ........................... 47
Gamma Playback............................................... 48
Turning Off the LCD Monitor Backlight .............. 48
Editing ................................................................ 49
Preparation
Camera Recording
Basic Operations
Basic Operations
Playback
Useful Features
References Useful Information .............................................. 50
Demonstration Mode.......................................... 54
Before Requesting Service ................................ 55
Specifications..................................................... 57
• Guía de operación rápida en español ..........................................................58
Advanced Features
References
2
Operation Summary
Part Names
For details on the use of each part, refer to the page number indicated in the
brackets.
Operation Summary
Front view
Terminal cover
Microphone
Zoom lens
AUDIO/VIDEO jack
[pp. 22, 49]
DC IN jack [pp. 8, 9]
Speaker
When the cassette compartment door is open
Cassette holder [p. 10]
Lens hood [p. 32]
Cassette compartment door
[p. 10]
3
Cassette compartment door
release [p. 10]
Shoulder strap loop
[p. 17]
Lithium battery holder
[p. 11]
Rear view
Operation Summary
RECord START/STOP button [p. 18]
Remote sensor
[p. 39]
CHARGE indicator
[p. 8]
MENU button
[p. 24]
Operation buttons [p. 24]
Bottom view
LCD monitor screen
DISPLAY button [p. 24]
Power Zoom Wide angle/
Telephoto control [p. 19]
VOLume control [p. 21]
Shoulder strap
loop [p. 17]
FADE button [p. 27]
Hand strap [p. 17]
Power switch (CAMERA/VCR
select switch) [pp. 18, 21]
Battery compartment door release
[p. 7]
Battery compartment door
[p. 7]
Tripod socket
4
Operation Summary
Quick Reference Index
This index lists some example uses of the VIEWCAM’s features.
Operation Summary
• To record with a Hi8 tape in normal 8 mm format.
—See page vi (
• To quickly check what you have just recorded.
—See page 28 (Quick Review)
• To quickly return the tape to the end of the last recorded scene after playback.
—See page 29 (Quick Return)
• To locate the point on the tape where to begin recording while in Camera mode.
—See page 29 (Edit Search)
• To record a backlit subject.
—See page 30 (Gamma Brightness Compensation) or page 46 (Manual
Exposure)
Recording Format)
• To record in a dark or poorly-illuminated location.
• To record yourself while monitoring the shot.
• To record a short video message for somebody.
• To find the beginning of a recorded scene to be played back.
• To display the elapsed recording or playback time.
• To focus on an off-centered subject.
• To increase the brightness of the subject during playback.
—See page 31 (Gain-up)
—See page 33 (Self Recording)
—See page 34 (Self-recording Message)
—See page 36 (Program Search)
—See page 37 (Tape Counter Feature)
—See page 44 (Manual Focus)
—See page 48 (Gamma Playback)
5
Warning Indicators
Operation Summary
Displayed for the first
3 seconds
Displayed after
3 seconds
Description of warning
The video cassette is defective and should be
removed (see page 10).
Dew has formed inside the VIEWCAM. Wait for a few
hours until the dew disappears (see page 51).
About 10 seconds after this warning appears, the
VIEWCAM automatically turns off.
The battery is almost depleted. Replace it with a
fully charged battery pack (see page 7).
The video heads are clogged and should be
cleaned (see page 51).
There is no video cassette in the VIEWCAM. Insert a
cassette (see page 10).
The erasure protect tab on the video cassette has
been slid to the record-protect position, preventing
recording (see page 53).
The tape is about to end. Prepare a new cassette
(see page 10).
The tape has reached the end. Replace it with a
new cassette (see page 10).
Note: indicates a flashing display.
In Self Recording mode, all warnings will be
indicated by displayed in the center of the
monitor. To check the type of warning, rotate the
monitor back to the normal position.
6
Preparation
Preparation
Preparation
Inserting and Removing the
Battery Pack
Inserting the Battery Pack
1 Make sure that the Power switch is set
to OFF.
Preparation
Power switch
2 Slide the battery compartment door
release on the bottom of the VIEWCAM
in the direction of the arrow to open the
battery compartment door.
Battery
compartment
door release
4 Close the door, pressing it firmly in the
center until it clicks.
Removing the Battery Pack
1 Perform steps 1 and 2 above.
2 Press the battery release as shown to
remove the battery pack.
Battery release
3 Insert the battery pack into the com-
partment as shown, and push it in completely until it locks into place.
Caution:
• Do not force the battery pack into the
battery compartment if it does not go in
easily.
7
Cautions:
• BEFORE REMOVING THE BATTERY PACK,
ALWAYS STOP THE TAPE AND TURN THE
POWER OFF. If you remove the battery pack
during recording or playback, the tape will
remain wound around the video head drum,
potentially causing damage to the tape.
• Make sure the battery compartment door is
closed firmly during operation. If it is not, the
battery pack may fall out or VIEWCAM operation
may fail because of the poor contact pressure.
• Remove the battery pack from the VIEWCAM if
the VIEWCAM will not be used for a long period
of time.
• When removing the battery pack, do not tilt
the VIEWCAM so that the battery compartment faces down. The battery pack may fall
out.
• Do not expose the battery compartment door to
strong force, as it may come off.
• Use only SHARP model BT-H22 or BT-H32
battery packs with this VIEWCAM. Use of other
batteries may present a risk of fire or explosion.
Charging the Battery Pack
Power switch
CHARGE indicator
Charging time and maximum continuous
recording and playback times
Battery
pack
BT-H22
BT-H32
Charging
time
approx.
3 hr.
approx.
6 hr.
Max.
continuous
recording
time
approx.
1 hr. 35 min.
approx.
3 hr. 10 min.
Max.
continuous
playback
time
approx.
1 hr. 35 min.
approx.
3 hr. 10 min.
Preparation
1 Insert the battery pack into the VIEWCAM
(see page 7). Make sure that the Power
switch is set to OFF.
• The battery pack will not charge when the
Power switch is set to CAMERA or VCR.
2 Insert the AC plug of the AC adapter into a
power outlet.
3 Open the terminal cover on the VIEWCAM
and insert the DC plug of the AC adapter
into the DC IN jack on the VIEWCAM.
• The CHARGE indicator will light up in red.
Terminal cover
DC IN jack
To power
outlet
4 When the battery is fully charged, the
CHARGE indicator will light up in green.
Remove the DC plug from the VIEWCAM,
and close the terminal cover.
Notes:
• Using the zoom (see page 19) and other
functions or turning the power on and off
frequently will increase power consumption.
This may result in a decrease of more than 50%
in the actual recording time compared to the
maximum continuous recording time listed
above.
• The charging time and recording time may vary
depending on the ambient temperature and the
condition of the battery pack.
• It is recommended that you have enough battery
packs on hand to provide two to three times your
estimated recording time.
• See page 52 for more information on using the
battery pack.
Caution:
• Charge only SHARP model BT-H22 or BT-H32
battery packs. Other types of battery packs may
burst, causing personal injury and damage.
Caution:
• When removing the plugs, grasp the plug, not the
cable.
8
Preparation
Powering the VIEWCAM from
an AC Outlet
Caution:
• The supplied AC adapter is specially designed
for use with this VIEWCAM, and should not be
used as a power supply for other camcorders.
Preparation
Power switch
1 Insert the AC plug of the AC adapter into
a power outlet.
2 Make sure that the Power switch is set
to OFF.
3 Open the terminal cover and insert the
DC plug of the AC adapter into the DC
IN jack on the VIEWCAM.
Terminal cover
Cautions:
• BEFORE REMOVING THE DC PLUG, ALWAYS
STOP THE TAPE AND TURN THE POWER OFF.
If you remove the DC plug during recording or
playback, the tape will remain wound around the
video head drum, potentially causing damage to
the tape.
• Remove the DC plug from the VIEWCAM if you
will not use the VIEWCAM for a long period of
time.
• When removing the plugs, grasp the plug, not
the cable.
Note:
• Close the terminal cover after use.
To power
outlet
4 Hold down the Lock
button and slide the
Power switch to
CAMERA or VCR.
9
DC IN jack
Lock button
Inserting and Removing a
Cassette
Inserting a Cassette
4 Wait for the cassette holder to fully
retract. Close the compartment door by
pressing the center until it clicks into
place.
1 Supply power to the VIEWCAM, then
slide the release and open the cassette
compartment door.
• The cassette holder extends and opens
automatically.
Cassette compartment
door release
2 Insert the cassette fully with the window
facing outwards, and with the erasure
protect tab facing upwards.
Erasure protect tab
3 Press the PUSH mark gently until the
cassette holder clicks into place.
• The cassette holder retracts
automatically.
PUSH mark
Preparation
Removing a Cassette
Perform step 1 above, then take out the
cassette.
Cautions:
• Do not try to close the cassette compartment
door while the cassette holder is extending or
retracting.
• Be careful not to get your fingers caught in the
cassette holder.
• Do not apply force to the cassette holder except
when pressing the PUSH mark to close it.
• Do not tilt the VIEWCAM or hold it upside down
when you are inserting or removing a cassette. It
may damage the tape.
• Remove the cassette if you will not use the
VIEWCAM for a long period of time.
• If you do not correctly close the cassette holder
in step 3, the VIEWCAM’s cassette protection
mechanism might eject the cassette. If this
happens, repeat the insertion procedure.
• Do not attempt to pick up the VIEWCAM by the
cassette compartment door.
Notes:
• If the battery power is too low, you may not be
able to eject the cassette. Replace the battery
pack with a fully charged one.
• See page 53 for more information on the video
cassette tapes for use with this VIEWCAM.
10
Preparation
Installing the Lithium
Memory Battery
The supplied lithium battery is used to store the
memory of the date and time settings.
1 Slide the cassette compartment door
release and open the cassette
compartment door.
Preparation
Cassette compartment
door release
Note: The cassette holder will extend and
open when the VIEWCAM is connected to a
power source. Be sure to close the cassette
holder before proceeding to the next step
(see page 10).
2 Pull out the lithium battery holder using
a pointed object such as the tip of a
ballpoint pen.
5 Close the cassette compartment door by
pressing the center until it clicks into
place.
Removing the Lithium Battery
Perform steps 1 and 2 above, then lift out the
battery from the battery holder.
Note:
• Replace the battery with a new CR2025 battery
when the date and time indicator starts to fall
behind the correct time.
Notes on the Use of the Lithium
Battery
REPLACE BATTERY WITH TOSHIBA,
MATSUSHITA OR HITACHI MAXELL TYPE
CR2025 ONLY. USE OF A DIFFERENT
BATTERY MAY PRESENT A RISK OF FIRE OR
EXPLOSION.
WARNING KEEP THIS BATTERY AWAY FROM
CHILDREN. IF SWALLOWED, CONSULT A
PHYSICIAN IMMEDIATELY FOR EMERGENCY
TREATMENT.
CAUTION BATTERY MAY EXPLODE IF MIS-
USED OR INSTALLED WITH POLARITY
REVERSED. DO NOT RECHARGE, DISASSEMBLE OR DISPOSE OF IN FIRE.
Lithium battery holder
3 Insert the lithium battery
into the battery holder with
the ` side of the battery
facing the j side of the
holder.
4 Push the battery holder back
into position.
11
• Do not short-circuit, recharge, disassemble,
or heat the lithium battery.
• Should the lithium battery leak, wipe the
battery compartment and holder clean, and
then insert a new battery.
• The lithium battery will last about one year of
normal usage.
j mark
Selecting the Language for
the On-screen Display
This VIEWCAM allows you to choose from
among English, French or Spanish for the onscreen display language.
Power switch
MENU button
Operation buttons
Setting the Language
When using the VIEWCAM for the first time,
select the desired language for the on-screen
display by performing the procedure below.
1 Hold down the Lock
button and slide the
Power switch to
CAMERA.
• The language selection
screen appears.
Lock button
2 Press the or button (C or D) (Q)
to select the desired language, then
press the SET (REGLAGE or AJUSTE)
button (B) (W).
Changing the Language
1 In Recording Standby mode, press the
MENU button until
appears.
2 Press the PAGE (PAGE or PAGINA)
button (
) to display MENU 1.
3 Press the or button (Q) to select
“LANGUAGE” (“LANGUE” or “IDIOMA”),
then press the SET (REGLAGE or
AJUSTE) button (B) (W).
• The language selection screen appears.
MENU
1
SET
FADE
REMOTE
DEMO MODE O FF
LANGUAGE
SET
NORMAL
AUTO
ON
PIC
PAGETURE
4 Press the or button (C or D) (Q)
to select the desired language, then
press the AJUSTE (SET or REGLAGE)
button (B) (W).
• The menu screen is displayed in the
language selected.
IDIOMA
AJUS
TE
ENGL I SH
FRANÇAIS
ESPAÑOL
Preparation
SET
LANGUAGE
ENGL I SH
FRANÇAIS
ESPAÑOL
PIC
EFF
SET
GAMA
EFF
EF
IMA
5 Press the DISPLAY button to turn off the
menu screen.
Note:
• The operation procedures in the following
sections of this operation manual are based
on the use of on-screen displays in English.
QK
REW
EF
GAM
REV
RAP
12
Preparation
English On-screen Displays
The following on-screen displays appear when “ENGLISH” is selected as the on-screen
display language (see page 12).
Camera Mode
Preparation
1
GAMA
PIC
EFF
COU
NTER
-
-
TI
RE
TLE
TURN
16 9
EFF
-
WH I TE EXPO
BAL.
SCENE
MENU
QK
SUREFOCUS
REW
MENU
FADE
REMOTE
DEMO MODE O FF
LANGUAGE
DATE
DI SPLAY OFF
SELECT DATE T IME
SETTING
12H 24H
NORMAL
AUTO
ON
-
PIC
SET
MENU
2
TIME/
/
SET
JA
12 AM00
12H
+
N 1 2000
-
PIC
PAGETURE
PAGETURE
VCR Mode
REW PLAY STOP STI LLFF
-
COU
GAMA
NTER
EFF.
13
Note: See pages 24 and 25 for the procedure to display the desired screen.
SE
ARCH
-
ED I T
REMOTE
MENU
SET
OFF
AUTO
ON
PIC
TURE
-
