Date :Dec. 25, 1997
Copier SF-2050
1.Model Name:
No. :SP-2228
1. Prevention of harness damage
2. Change of screws which combine the fixture frame
3. Increase of strength margin of hinge fixing area of
front cabinet (left)
4. Change of wire saddle to heat-resistant type
5. Change of vendor of AC cord (productivity improvement)
1. Prevention of harness damage
SF-2050
2.General:
In order to prevent the harness of the fixture heater lamp from being damaged since it
interferes with the edge of the lamp support plate, the harness guide is added to the
support plate of the heater lamp.
Fixture harness guide
3.Action:
SHARP CORPORATION Copying Machine Division
On the way of production in April, 1995
1/4
Green
C
2. Change of screws which combine the fixture frame
1.Model Name:
2.General:
SF-2050
The screws which combine the upper and lower fixture frames are changed to the step
type.
Screws changed
3.Action:
1.Model Name:
2.General:
First product in June, 1995
3. Increase of strength margin of hinge fixing area of front cabinet (left)
SF-2050
The wire saddle used on the fixture unit is changed to the heat-resistant type.
2/4
A bit is added
Screws changed
3.Action:
1.Model Name:
2.General:
3.Action:
1.Model Name:
2.General:
On the way of production in June, 1995
4. Change of wire saddle to heat-resistant type
SF-2050
The wire saddle used on the fixture unit is changed to the heat-resistant type.
First product in June, 1995
5. Change of vendor of AC cord (productivity improvement)
SF-2050
In order to improve the productivity, the vendor of AC cord is changed.
(AC cord ø4.8, 2P only)
3.Action:
First product in November, 1996
3/4
Ref.
Model
No.
name
1
2 16 -26 XBBS240P08000 LX-BZ0784FCZZ AC SCREW
3
SF-2050
4 16 -28 LHLDW1262FCZZ LHLDW1262FCZ1 AE WIRE HOLDER
5
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones
for maintaining the safety and performance of the set.
Version P/G No.
16 - PSHEP4023FCZZ AE
All
2 -16 CCAB-0823FC01 CCAB-0823FC02 BD
2 -17 XEBSE40P10000 XBPSF40P10KS0 AA SCREW
Area
where AC
cord ø4.8
2P is used
43 -4 QACCV6420QCZZ QACCV6420QCN2 AU AC CORD
Current parts New parts
Parts code Parts code
5. Interchangeable if replaced with same types of related
6. Others.
Price
rank
parts in use.
Parts name
FUSING
HARNESS
GUIDE SHEET
FRONT
EXTERIOR
Effec-
tive
time
Mid’95/4
1st lot
’95/6
Mid’95/6
1st lot
’95/6
1st lot
’96/11
change-
ability
Inter-
6
1
5
1
Note
Quantity
:2
4/4
