Date: Oct. 17, 1995
COPIER : SF-2116
No. : SP-1928
1.REGARDING PROBLEMS WITH THE LENS
ISOLATION SHEET.
2.REGARDING JAMS CAUSED BY IMP ROPER
FUNCTIONING OF THE PAPER DETECTOR.
1. Regarding problems with the lens isolation sheet.
1.Model Name: SF-2116/ 21 18/1016/1018
2.General: When the optical unit lens moves into position for magnification, the lens isolation sheet
may be pulled out of alignment towards the zoom base, or come loose from the dark
box cover. In order to prevent this problem, the following changes have been made.
3.Description: A bow had been added to the lens isolation sheet but the direction of its bend tended to
change under pressure. Therefore, other improvements have been made to the part.
Lens shield sheet
Portion with glue
Center of the thick part of the carriage
(measured by eye)
4.Action: From the middle of June, 1995 production on.
Base (Rear part of the resin)
Additional part (Attached)
(Lens mylar R)
Lens shield sheet
SHARP CORPORATION Reprography Division
1/3
Green
C
![](/html/d8/d835/d83510140f9ce434fa08d6d5971d86a8591a8a479028878f11ef1554d24af752/bg2.png)
2. Regarding jams caused by improper functioning of the paper detector.
1.Model Name: SF-2116/ 21 18/1016/1018/CM15
2.General: The following changes are being carried out to prevent paper jams caused by problems
with the paper detector in the PID PWB and the DPPD PWB.
3.Description: (1) To raise the sensitivity of the sensor, a resistor is being added to the back of the
PWB.
PID PWB P/G
DPPD PWB P/G
10 -48
17 -7
23 -5
(2) We are also planning improvements to the sensor detector IC which is in the motor
control PWB for the DPPD sensor in the 2-4 cassettes.
4.Action: (1) From the middle of July, 1995 production on.
(2) From the middle of Aug., 1995 production on.
Resistor (VRD-HT2HY202J)
Resistor (VRD-HT2HY202J)
