SHARP SP1927 Technical Report

Date: Sep. 6, 1995

COPIER : SF-2050

1. Handling the RADF as a service option.

1.Model name: SF-2050
(Destinations)Republic of Pakistan, Republic of the Philippines, T aiwan, Kingdom of

No. : SP-1927

1. HANDLING THE RADF AS A SERVICE OPTION.

2. IMPROVEMENT OF THE TRANSPORT CLUTCH DURABILITY.

3. PREVENTION OF IMPERFECT (PARTIAL) ATTACHMENT OF PAPER EXIT
REVERSING UNIT UPPER PAWL FIXING PLATE.

Saudi Arabia, Greece, Republic of Lebanon, Republic of Iran, Republic of Iraq, Federal
Republic of Nigeria, Republic of Turkey, Egypt, Hashemite Kingdom of Jordan, Syria,
Republic of Tunisia, Kingdom of Morocco, Democratic and People’s Republic of Algeria,
West Africa, Republic of South Africa, Special country, Northern Yemen, Republic of
Cyprus, Sultanate of Oman, State of Qatar, United Arab Emirates, State of Bahrain,
Kuwait, Republic of Indonesia, STCL People’s Republic of Bangladesh, Republic of
India.

2.General: In accordance with requests from the markets, the RADF which had previously been
issued as standard equipment is now being offered as a service option for the market
destinations listed above.

3.Description:

.

Added OC cover unit CCOVH0206FC31 (for model SF-2035).

.

Change in packing materials.
Top packing cushio n C L
SP AKA5217FCZZ.
Top packing cushion A
SPAKA5215FCZZ

(P/G )

48 -4

Top packing cus h io n CR
SPAKA5218FCZZ.

ADF protect sheet
SPAKA4527FCZZ.

(P/G ) Discontinuance

Tray protect packing cushion
SPAKA5210FCZZ.

RADF protect sheet
SPAKA4693FCZZ.

48 -10

48 -14

(P/G ) Discontinuance

48 -120

(P/G ) Discontinuance

(P/G )

(P/G )

48 -5

48 -6

SHARP CORPORATION Reprography Division

1/3

Green

C

OC protect packing cushion
SPAKA4693FCZZ.

(P/G ) Added

48 -13

4.Action: From the start of 1995 July production.

2. Improvement of the transport clutch durability.

1.Model name: SF-2050

2.General: The clutch drive shaft and the material from which the gears are made has been

changed in order to improve the durability of transport clutch 48T, used in the transport
drive unit.

3.Description: Drive shaft color: gold → silver
Gear color: white → gray

4.Action: From 1995 mid-June production.

3. Prevention of imperfect (partial) attachment of paper exit reversing unit upper pawl
fixing plate.

1.Model name: SF-2050

2.General: The upper pawl fixing plate in the paper exit reversing unit is sometimes only partially

attached (free-turning). To alleviate this problem, the fixing screws have been changed.

3.Description: P/G M3 x 5 XBPSD30P05KS0 (Q’ty: 2) → M3 x 6 LX-BZ3006SC0M (Q’ty: 2).

20 -14

4.Action: From the start of 1995 June production.
