ДОМАШНИЙ ХОЛОДИЛЬНИК
С МОРОЗИЛЬНОЙ КАМЕРОЙ
ИНСТРУКЦИЯ ПО
ЭКСПЛУАТАЦИИ
SJ-T401R
SJ-CT401R
СОДЕРЖАНИЕ
• ПРЕДУПРЕЖДЕНИЕ ................................ 2
• ОСТОРОЖНО............................................ 2
• УСТАНОВКА .............................................. 2
• ОПИСАНИЕ............................................... 3
• ХРАНЕНИЕ ПРОДУКТОВ ......................... 3
• УХОД И ЧИСТКА....................................... 4
• ЧТО ДЕЛАТЬ, ПРЕЖДЕ ЧЕМ ОБРАТИТЬСЯ
В СЕРВИСНУЮ СЛУЖБУ ................................ 4
Для бытового использования
Отдельно стоящий
aa
REFRIGERATOR - FREEZER
OPERATION MANUAL
CONTENTS
• WARNING .................................................. 5
• CAUTION ................................................... 5
• INSTALLATION........................................... 5
• DESCRIPTION ........................................... 6
• STORING FOOD........................................ 6
• CARE AND CLEANING.............................. 7
• WHAT TO DO BEFORE YOU CALL
FOR SERVICE........................................... 7
РУССКИЙ ENGLISH
SJ-T361R
SJ-T401R
SJ-CT361R
SJ-CT401R
Household use only
Free standing type
aa
Thank you very much for buying this SHARP product. Before using your SHARP refrigerator, please read this operation
60
manual to ensure that you gain the maximum benefit from it.
WARNING
■ Highly volatile and flammable materials such as ether,
petrol, propane gas, adhesive agents and pure alcohol
etc. are liable to explode. Do not store these materials in
the refrigerator.
■ Dust deposited on the power plug may cause fire. Wipe
it off carefully.
■ Do not attempt to change or modify this refrigerator. This
may result in fire, electric shock or injury.
■ Ensure that the refrigerator presents no danger to
children while being stored for disposal. (e.g. remove the
door to prevent child entrapment.)
■ This refrigerator should be disposed appropriately. Take
the refrigerator to a recycling plant for flammable
insulation blowing gases.
CAUTION
■ Do not touch the compressor unit or its peripheral parts,
as they become extremely hot during operation and the
metal edges may cause injury.
■ Do not touch foods or metal containers in the freezer
compartment with your wet hands. This may cause
frostbite.
■ Do not use an extension cord or adapter plug.
■ Do not place bottled and canned drinks in the freezer as
they may crack when frozen.
INSTALLATION
WARNING
■ Do not install the refrigerator in a damp or wet
location as this may cause damage to the
insulation and a leak. Condensation may also
build on the outer cabinet and cause rust.
Keep adequate ventilation space around the
1
refrigerator.
The figure shows the minimum required space for
•
installing the refrigerator. It differs from the space in
the measurement condition of the amount of power
consumption.
It is possible to use the refrigerator with a less amount
•
of power consumption by keeping greater space.
If using the refrigerator in the space below dimension
•
of the figure, it may cause the temperatures in the unit
to rise, loud noise, and failure.
mm
90 mm
or more
60 mm
or more
Using the two front adjustable feet, ensure that the
2
refrigerator is positioned firmly and level on the floor.
Remove the 2 screws of the cabinet lower part, and
3
use these to fit the foot covers. (supplied inside the
refrigerator compartment)
or more
1310 mm
1140 mm
■ Make sure that the power cord has not been damaged
during installation or moving. If the power plug or cord is
loose, do not insert the power plug. There is a risk of
electric shock or fire.
■ Disconnect from the mains electricity supply by
removing the mains plug from the electricity supply
socket. Do not remove by pulling the mains lead. This
may cause electric shock or fire.
■ The refrigeration system behind and inside the
refrigerator contains refrigerant. Do not allow any sharp
objects to come into contact with the refrigeration
system.
■ Should the flexible supply cord be damaged, it must be
replaced by service agent approved by SHARP as a
special cord is required.
■ In case of gas leak, ventilate the area by opening a
window, etc. Do not touch the refrigerator or the power
outlet.
■ Do not place objects containing liquid or unsteady
objects on top of refrigerator.
■ This refrigerator is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the refrigerator by a person
responsible for their safety. Young children should be
supervised to ensure that they do not play with the
refrigerator.
Adjustable foot
Foot cover
NOTE
• Position your refrigerator so that the plug is accessible.
• Keep your refrigerator out of direct sunlight.
• Do not place next to heat generating appliance.
• Do not place directly on the ground.
Provide suitable stand.
When transporting
• Using the casters, it is possible to move back and forth.
• Carry the refrigerator by holding the handles located on
the rear and bottom.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm water.
If soapy water is used, wipe it off thoroughly with water.
ENGLISH
5
DESCRIPTION
1. Freezer shelf
14
2. Ice cube maker
(SJ-T361R, SJ-T401R)
Ice cube tray
(SJ-CT361R, SJ-CT401R)
3. Ice cube box
4. Fresh case & door
5. Refrigerator light
6. Freezer temp. control knob
7. Refrigerator temp. control
knob
8. Refrigerator shelf
9.
Hybrid cooling panel
(Aluminum panel)
(Only for SJ-T361R, SJ-T401R)
10. Fruit and vegetable shelf
11. Fruit and vegetable crisper
10
11
12
13
1
2
3
4
5
6
7
8
9
SJ-T401R
15
16
17
18
19
20
21
22
16
14
Controlling temperature
Adjustable by turning each knob.
(for refrigerator) (for freezer)
Hybrid cooling panel (Aluminum panel)
The panel is cooled from the rear, thus indirectly cooling
the refrigerator compartment. In this way, food is
refrigerated gently, without exposing it to cold air flow.
12. Divider
13. Adjustable feet & cover
(2 pcs.)
14. Magnetic door seal (2 pcs.)
15. Freezer bar
16. Door pocket
2
17. Refrigerator pocket
(2 pcs.)
18. Egg holder
SJ-CT361R, SJ-CT401R
(2 pcs.)
19. Utility pocket
20.
Utility pocket (large)
(Only for SJ-T401R, SJ-CT401R)
• Do not replace the right and left
position of the utility pocket and
the utility pocket (large).
(2 pcs.)
SJ-T361R, SJ-CT361R
21. Bottle pocket
22. Tube stand
(Only for SJ-T361R, SJ-T401R)
Hints when making ice
Do not over fill the Ice cube trays; otherwise the ice
1
cubes will be joined together when frozen.
SJ-T361R, SJ-T401R
2
When the ice cubes are made,
turn the lever clockwise to
empty the ice into the Ice cube
box.
SJ-CT361R, SJ-CT401R
When the ice cubes are made,
hold the Ice cube tray upside
down whilst twisting either end
in opposite directions, allowing
the ice cubes to drop out.
NOTE
To prevent damage to the Ice cube
box, do not make ice in the Ice cube box or pour oil into it.
Lever
Ice cube box
Ice cube tray
19
Deodorizing unit
Deodorizing catalyst is installed on the routes of cold air.
No operation and cleaning are required.
STORING FOOD
Refrigeration reduces the rate of food spoilage. To
maximize the shelf life of perishable food products, ensure
that the food is the freshest possible quality. The following
is a general guide to help promote longer food storage.
• Ensure all cooked food is wrapped securely or placed in
an airtight container.
• To minimize moisture loss, fruit and vegetables should
be loosely enclosed in a plastic material e.g. wrap, bags
(do not seal) and place in the fruit and vegetable crisper.
• Eggs should be stored in the Egg holder.
• Evenly place the food on the shelves to allow the cooling
air to circulate efficiently.
• Hot foods should be cooled before storing. Storing hot
foods increases the temperature in the unit and
increases the risk of food spoilage.
• Do not block the outlet and inlet of the cool air circulating
circuit with foods or containers; otherwise the foods will
not be evenly cooled throughout the refrigerator.
• Keep the door securely closed.
Tube stand
Prevents bottles etc. from falling.
Stick-type food products can also be
stored inside.
For best freezing
• Quality of foods should be fresh.
• Freeze small quantities of food at a
time to freeze them quickly.
• Food should be properly stored or
covered and the air should be
removed to seal tightly.
• Evenly place the food in the freezer.
• Label bags or containers to keep an
inventory of freezing food.
6
CARE AND CLEANING
WARNING
■ Unplug the refrigerator first to prevent electric
shock.
■ Do not splash water directly on the outer cabinet
or the interior. This may lead to rusting and
deterioration of the electrical insulation.
IMPORTANT
To prevent cracking on inside surfaces and plastic
components, follow these tips.
• Wipe any food oils adhered to plastic components.
• Some household chemicals may cause damage, so use
only diluted washing-up liquid (soapy water).
• If undiluted detergent is used or soapy water is not wiped
off thoroughly, cracking of plastic parts can result.
Remove the shelves and pockets from the cabinet and
1
door. Wash them in warm soapy dishwashing water;
rinse in clean water and dry. (Only fruit and vegetable
shelf is not removable.)
Clean the inside with a cloth soaked in warm soapy
2
dishwashing water. Then, use cold water to wipe off
soapy water.
Wipe the exterior with a soft cloth each time it is soiled.
3
Clean the Magnetic door seal with a toothbrush and
4
warm soapy dishwashing water.
NOTE
• To prevent damage to your refrigerator, do not use heavy
duty cleansers or solvents (lacquer, paint, polishing powder,
benzine, boiled water, etc.).
• If the power supply is disconnected, please wait for at least
5 minutes before re-connecting power.
• The glass shelves weigh approximately 2 kg each. Hold
firmly when removing from the cabinet or carrying.
• Do not drop objects inside the refrigerator or strike the inner
wall. This may cause the inner surface to crack.
Defrosting
Defrosting is fully automatic due to a unique energy saving
system.
When the compartment light is blown
Contact the service agent approved by SHARP to request
a replacement compartment light. The compartment light
is not to be removed other than by qualified service
personnel.
Switching off your refrigerator
If you switch your refrigerator off when you are going away
for an extended period, remove all food, clean the interior
thoroughly. Remove the power cord plug from the power
socket and leave all doors open.
WHAT TO DO BEFORE YOU CALL FOR SERVICE
Before you call for service, check the following points.
Problem Solution
The outside of a cabinet is hot when
touched.
When there is refrigerator noise. It is normal for the refrigerator to produce the following sounds.
Frosting or dew generation occurs
inside or outside the refrigerator.
It is normal. The hot pipe is in the cabinet in order to prevent dew generation.
• Loud noise produced by the compressor when operation starts
--- Sound becomes quieter after a while.
• Loud noise produced once a day by the compressor
--- Operating sound produced immediately after automatic defrost
operation.
• Sound of flowing fluid (gurgling sound, fizzing sound)
--- Sound of refrigerant flowing in pipes (sound may become louder from
time to time).
• Cracking or crunching sound, squeaking sound
--- Sound produced by expansion and contraction of inner walls and internal
parts during cooling.
This may occur in one of the following cases. Use a wet cloth for wiping frost
and a dry cloth for wiping dew.
• When the ambient humidity is high.
• When the door is frequently opened and closed.
• When foods containing plenty of moisture are stored. (Wrapping is required.)
ENGLISH
The foods in the refrigerator
compartment freeze.
It smells in the compartment. • Wrapping is required for the foods with strong smell.
IF YOU STILL REQUIRE SERVICE
Refer to your nearest service agent approved by SHARP.
• Is the refrigerator operated for a long time with temp. control set at MAX?
• Low ambient temperature may cause placed foods to freeze even if
refrigerator temp. control is set to MIN.
• Deodorizing unit cannot remove all of smell.
7
SJ-T361R-(SL, BE, WH)
SJ-CT361R-(SL, BE, WH)
SJ-T401R-(SL, BE, WH)
SJ-CT401R-(SL, BE, WH)
SJ-T361R-(SL, BE, WH)
SJ-CT361R-(SL, BE, WH)
SJ-T401R-(SL, BE, WH)
SJ-CT401R-(SL, BE, WH)
SHARP CORPORATION
Напечатано в Таиланде / Printed in Thailand
TINS-A850CBRZ 07LK TH 1
Loading...
