Sharp SHV33 User Guide

BasicManual

CellphoneandPHSoperatorscollectandrecycleunused
telephones,batteriesandbatterychargersatstoresbearing
thelogoregardlessofbrandandmanufacturertoprotect
theenvironmentandreusevaluableresources.

濡れた状態での充電は、
異常な発熱・焼損などの
原因となり大変危険です。

CustomerServiceCenter

Forinquiries,call:

Forgeneralinformation,charges,andoperationassistance

(tollfree)

Fromfixed-linephones: Fromaucellphones:

areacodenotrequired

areacodenotrequired

Fromfixed-linephones: Fromaucellphones:

Incaseabovenumbersarenotavailable,calltoll-free:

0120-977-033

(exceptOkinawa)

0120-977-699(Okinawa)

Forservicecancelationprocedureincaseoflossortheft

(tollfree)

onyouraucellphone.

KeitaiGuaranteeServiceCenter

Forloss,theftordamage(tollfree)

Fromfixed-linephones/aucellphones:

Businesshours:9:00to21:00(7daysaweek)

Businesshours:9:00to20:00(7daysaweek)

Businesshours:24hours(7daysaweek)

0120-925-919

• The company names and product names appearing in this manual are
trademarks or registered trademarks of their respective holders.

• For exemptions, refer to “Notes on Usage” available on the au homepage.

December2015,1stEdition
Soldby:KDDICORPORATION,

OKINAWACELLULARTELEPHONECOMPANY

Manufacturedby:SHARPCORPORATION

Preface

Thank you for buying the “AQUOS SERIE mini SHV33” (simply called the
“SHV33” or the “product” from here on).
Before using the product, be sure to read the “Basic Manual” (this manual) and
“Notes on Usage”/“Setting Guide” available on the au homepage to ensure
correct use. After you have finished reading the manuals, be sure to keep them
accessible and store the printed manuals (“取扱説明書” (Basic Manual), “ご利
用にあたっての注意事項” (Notes on Usage) and “設定ガイド” (Setting Guide))
(Accessories) in safe places so that you can refer to them whenever you need
them. If you lose the printed manuals (Accessories), contact an au shop or
Customer Service Center.

List of Packaged Items

Before you start using the product, make sure that you have all the following
packaged items with the product.

保証書 (Warranty)

(Japanese)

SHV33

• 取扱説明書 (Basic Manual) (Japanese)

• ご利用にあたっての注意事項 (Notes on Usage) (Japanese)

• 設定ガイド (Setting Guide) (Japanese)

The following items are not included in the package.

• microSD memory card

• AC adapter

• Earphone

• microUSB cable

• Purchase a specified charger (sold separately).

◎ The battery is built into the product.
◎ Illustrations of cell phones in this manual are only for reference. They may

look different from the actual product.

Operating Instructions

■ “Basic Manual” and “Setting Guide”

The “Basic Manual” (this manual) and “Setting Guide” available on the au
homepage describe basic operations of major functions.
For detailed descriptions of various functions, refer to the “Instruction Manual
application” (Japanese version) that can be used on the product or “Full
Instruction Manual” (Japanese) available on the au homepage:

(http://www.au.kddi.com/english/support/manual/)

■ “Instruction Manual Application” (Japanese/English

Version)

You can use the “Instruction Manual application” (Japanese version) on the
product to check detailed operational procedures.
Also, you can activate intended functions from an explanation screen
depending on the functions.
On the home screen, “Apps Sheet” [[取扱説明書] (Instruction Manual).
Also, you can use the “Instruction Manual application” (English version) on the
product to check operational procedures.
On the home screen, “Apps Sheet” [[Basic Manual] after switching the
display language to English (zP.14).

• To use the application for the first time, you need to download and install it by

following on-screen instructions.

1

Cell Phone Etiquette

■ Use of cell phones is not allowed in the following

places!

• Do not listen to music or watch videos/TV while driving a car or riding a

motorbike or bicycle. Use of a cell phone while driving a car or riding a
motorbike is prohibited by law. (Use of a cell phone while riding a bicycle
may be punishable by some regulations.) Be attentive to traffic around you
while walking. Not being able to hear surroundings or looking only at the
display may cause a traffic accident. Be careful especially at train crossings,
on station platforms, and at crosswalks.

• Since using the product on airplanes is restricted, follow the instructions

given by the respective airlines.

■ Be considerate of people around you

• Do not make calls in theaters, museums, libraries, and other similar places.

Turn power off or turn on manner mode so as not to disturb others around
you with your ringtones.

• Do not use the cell phone outside in town where you might hinder other

pedestrians.

• Viewing a cell phone screen while walking is a serious hazard. Do not

suddenly stop to talk on/operate the cell phone or do so while walking.

• Move to areas where you will not inconvenience others on bullet trains, in

hotel lobbies, etc.

• Refrain from talking in a loud voice.

• Check whether sound from earphones, etc. is audible when near others on a

train.

• Obtain the permission of other people before you take their photos with the

cell phone's camera.

• Some people close to you in crowded places such as packed trains may be

using a cardiac pacemaker. Turn on “Airplane mode” or turn the cell phone
off in such places.

• Abide by the rules of hospitals and other medical institutions where it is

forbidden to use or carry cell phones.

Using au Disaster Countermeasure
Application

au Disaster Countermeasure is an application in which you can use Disaster
Message Board, Emergency Rapid Mail (Earthquake Early Warning, Disaster
and Evacuation Information, and Tsunami Warning), Disaster Voice Messaging
Service and Disaster Information.

A On the home screen, “Apps Sheet” [[au災害対策] (au

Disaster Countermeasure).

The au Disaster Countermeasure menu screen is displayed.
When you activate this for the first time, an agreement screen regarding
the use or an initial setting screen is displayed.
Follow the on-screen instructions.

■ Using Disaster Message Board

Disaster Message Board is a service to enable customers in disaster areas to
register their safety information via LTE NET when large-scale disasters, such
as an earthquake whose Japan seismic scale is approximately 6-lower or
more, occur. The registered safety information can be checked by customers
using au phones, and also from other carriers' cell phones, PCs, etc.
For details, refer to “Disaster Message Board Service” on the au homepage.

A On the au Disaster Countermeasure menu screen, [災害用

伝言板] (Disaster Message Board).

Follow the on-screen instructions for registration/confirmation.

◎ To register the safety information, an e-mail address (〜ezweb.ne.jp) is

required. Set the e-mail address in advance.

◎ Deletion of the safety information and configurations for Safety

Notification Mail are not available during wireless LAN (Wi-Fi
connection.

◎ The Company does not guarantee the quality of this service. The

Company, regardless of the cause, shall not be liable for any problems
related to registration of safety information due to the concentration of
access to this service or equipment errors, any loss due to the damage,
ruination, etc. of safety information or any loss arising from registered
safety information.

®

)

2

■ Using Emergency Rapid Mail

Emergency Rapid Mail is a service to collectively deliver Earthquake Early
Warning and Tsunami Warning provided by the Japan Meteorological Agency,
and Disaster and Evacuation Information provided by the national government
or the local governments to au phones in the specified areas.

• At the time of purchase, receiving setting of Emergency Rapid Mail

(Earthquake Early Warning, and Disaster and Evacuation Information) is set
to “受信する” (Receive). You can receive Tsunami Warning by setting 災害・
避難情報 (Disaster and Evacuation Information).
When receiving Earthquake Early Warning, secure your safety and act
composedly according to the surrounding situations.
When receiving Tsunami Warning, leave sea coasts immediately and
evacuate to safe places such as hills and strongly-built tall buildings.

A On the au Disaster Countermeasure menu screen, [緊急速

報メール] (Emergency Rapid Mail).

The inbox is displayed.
Select a mail to check to display the details of the mail.

削除 (Delete) Delete received mails.
設定 (Settings) 緊急地震速報 (Earthquake Early Warning), 災害・避難

◎ This service is available only in Japan (Not available overseas).
◎ Emergency Rapid Mail is free of both information charges and

communication charges.

◎ Emergency Rapid Mail cannot be received while the power is turned off.
◎ Emergency Rapid Mail may not be received when you are in a place

where the signal cannot be received (e.g. tunnels and basements) or the
signal is weak, even within the service area.

◎ Emergency Rapid Mail which failed to be received will not be able to be

received again.

◎ When you receive Emergency Rapid Mail, you will be notified by the

dedicated alarm tone and the vibrator. The alarm tone cannot be
changed.

* When you receive E arthquake Early Warning, you will be notified by the alar m

tone, voice (“地震です” (Jishin-desu)) meaning that an earthquake has
occurred and the vibrator.

* When you receive Ts unami Warning, you will be notified by the alarm tone,

voice (“津波です” (Tsunami-desu)) meaning that a tsunami has occurred and
the vibrator.

◎ The alarm tone does not ring if Emergency Rapid Mail is received during

a call.

◎ Information intended for the areas of other than your present location may

be received.

◎ As for this service, the Company shall not be liable for any damage

incurred on the users resulted from failure or delay of information delivery
due to communication disturbance or system failure, contents of the
information or other problems that are not supposed to be blamed on the
Company.

◎ For details on Earthquake Early Warning and Tsunami Warning provided

by the Japan Meteorological Agency, refer to the agency's homepage.

(http://www.jma.go.jp/jma/indexe.html)

Earthquake Early Warning

◎ Earthquake Early Warning notifies areas where a strong shaking (Japan

seismic scale 4 or more) is expected when an earthquake whose
maximum Japan seismic scale is predicted of 5-lower or more has been
detected.

情報 (Disaster and Evacuation Information)

• 受信設定 (Receive setting): Set whether to receive

Earthquake Early Warning, Disaster and
Evacuation Information, and Tsunami Warning.

• Tap [受信する] (Receive)/[受信しない] (Not

receive).

• 音量 (Volume): Set the volume of the receiving

sound.

• マナー時の鳴動 (Linkage to the manner mode): Set

whether to make the product ring at the time of
reception while the manner mode is applied.

• バイブ (Vibrator): Set whether to activate the

vibrator at the time of reception.

• 受信音／バイブ確認 (Check receiving sound/

vibrator): Play back and check set volume/vibrator.

3

◎ This service detects an earthquake (P-wave, preliminary tremors) near

the seismic center immediately after the earthquake occurs and
automatically calculates its location, scale and predicted strength of the
shaking. After that, you will be notified of the earthquake as soon as
possible within a few seconds to dozens of seconds before a strong
shaking from the earthquake (S-wave, principal shock) occurs.

◎ In the vicinity of the seismic center, a strong shaking may reach you

before Earthquake Early Warning.

◎ The Earthquake Early Warning distribution system provided by this

service is different from that provided by TV, radio and other
communication media and thus the arriving time of Earthquake Early
Warning may be different among those media.

Tsunami Warning

◎ Tsunami Warning notifies areas including target sea coasts of Major

Tsunami Warning and Tsunami Warning provided by the Japan
Meteorological Agency.

Disaster and Evacuation Information

◎ Disaster and Evacuation Information notifies information related to the

safety of citizens, such as evacuation advisories, evacuation orders or
various alarms delivered by the national government or the local
governments.

■ Using Disaster Voice Messaging Service

Disaster Voice Messaging Service is a service to record voices with a
smartphone and deliver them as a voice message to people to whom you want
to deliver the information that you are safe when large-scale disasters occur.

A On the au Disaster Countermeasure menu screen, [災害用

音声お届けサービス] (Disaster Voice Messaging Service).

◎ To use this service via Wi-Fi®, making initial settings via 4G (LTE/WiMAX

2+) networks is required.

◎ Voice messages can be recorded for up to 30 seconds.
◎ Voice messages can be exchanged among au phones as well as other

carriers' cell phones and PHS devices.

◎ Voices may not be heard when the media sound volume is set to low or

the manner mode is applied.

◎ When no free space is left on the internal memory, voice messages may

not be saved or played.

◎ Some cell phones cannot receive voice messages. For details, refer to

the au homepage.

■ Using Disaster Information

You can check histories of Disaster and Evacuation Information delivered by
the local governments, disaster related information portal, etc.

A On the au Disaster Countermeasure menu screen, [災害関

連情報] (Disaster Information).

B Follow the on-screen instructions.

4

Illustrations and Descriptions in This
Manual

■ Note on Key Illustrations

In this manual, the key illustrations are simplified as shown below.

■ Description of Operations for Selecting Item/Icon/Key

etc.

In this manual, operation procedures are described as below.

Description Explanation

On the home screen,
“Apps Sheet” [[Phone]

[Enter “141”
[[CALL].

f (hold down for at
least 2 seconds).

* Tapping is to sel ect a key or icon displayed on the screen by li ghtly tapping it with

your finger.

■ Notes on Illustrations/Screenshots

Screenshots and operations in this manual are based on the product with an
au Nano IC Card 04 installed.
Screenshots may differ from actual screen. Portions of the screen are
sometimes omitted.

In this manual, part of the
screen such as icons are
omitted.

Slide/flick the Feel Home screen to switch to the
Apps Sheet, and then tap “ Phone”. Continue
by tapping “ ”, “ ”, and “ ”, and
finally “ ”.
Hold f down for at least 2 seconds.

Actual screen

◎ Explanations of this manual are based on the case when the color of the

main unit is “Scarlet” as an example.

◎ Explanations of this manual are based on the case when the product is

held vertically. If you hold it horizontally, menu items/icons/on-screen
keys etc. may be different.

◎ Descriptions in this manual are based on operation in Feel Home.

Operations may be different if home applications have been changed (by
using “Home applications”, etc.).

◎ Menu items, layers and icons described in this manual may be different

according to functions being used and conditions.

◎ In this manual, “m icroSD™ memory card (commercially available)”,

“microSDHC
memory card (commercially available)” are abbreviated as “microSD
memory card” or “microSD”.

◎ All of the indicated amounts exclude tax unless otherwise specified.

™

memory card (commercially available)” and “microSDXC™

In this manual

5

Names and Functions of Parts

■ Front/Left Side/Right Side

A External connection jack

Use when connecting the common AC adapter 05 (sold separately), the
microUSB cable 01 (sold separately), USB cable for peripherals
(commercially available), etc. to the product.
When you connect the common AC adapter 05 (sold separately), the
microUSB cable 01 (sold separately), etc. to the product, some applications
may not function properly since the geomagnetic sensor is affected by the
magnetism of connected devices. Use the product after removing the
cable.

B au Nano IC Card 04/microSD memory card cover
C IMEI tra y

Allows you to confirm the product's IMEI.

D au Nano IC Card 04 tray slot
E microSD memory card slot
F Grip sensor

By setting “Grip magic”, holding the product (touch the sensor areas on
both sides at the same time) turns the screen on or minimizes the volume
and makes the product vibrate when a call is arriving or for an incoming call
or notification.

• Even if you release your hand from the sensor areas, the screen is not
turned off immediately.

G Strap eyelet
H Earpiece (Receiver)
I Proximity sensor/Light sensor

Proximity sensor prevents inadvertent operations of the touch panel during
a call.
Light sensor detects the ambient brightness and adjusts the brightness of
display.

J f Power key

Turn the screen on/off.
Hold it down to turn on/off the power, set the manner mode, etc.

K ud Volume up/down key

Adjust the volume.
Hold down u on the Welcome Sheet (Lock Screen) to turn on the mobile
light.
Hold down d on the Welcome Sheet (Lock Screen) to set/disable the
manner mode.

L Display (Touch panel)
M In camera lens

6

■ Back/Top and Bottom

N Out camera lens
O & mark

Hold it over a reader/writer when using Osaifu-Keitai

P Internal antenna
Q TV antenna

®

/Bluetooth®/GPS antennas

R Wi-Fi
S Mobile light
T Sub microphone
U Earphone/Microphone jack
V Charging/Incoming indicator
W Mouthpiece (Microphone)
X Speaker

◎ The back cover of the product cannot be removed. Removing it forcibly

may cause damage or a fault.

◎ The battery is built into the product, and cannot be removed by the

customer. To force the power off, refer to “Turning the Power Off Forcibly”
(zP. 13).

IMEI tray

◎ An IMEI (international mobile station equipment identity) is a special

identification code assigned to each phone. You can pull the IMEI tray out
to confirm the IMEI of the product.

◎ The IMEI is information required when requesting servicing or repairs.
◎ The IMEI tray cannot be removed from the main unit. Take care not to

apply force when handling.

◎ You can also operate the product to confirm the IMEI.

On the home screen, “Apps Sheet” [[Settings] [[About phone]
[[Status] [[SIM status] and confirm the IMEI field.

Grip sensor

◎ The sensor may not work properly and prevent you from using Grip magic

in the following cases. This may also cause malfunction.

• Operation with gloved hands

• Operation while the product is equipped with a cover etc.

• Operation while the product is wet

• Operation while a metallic object touches the sensor

• When you put a cover on/off the product with Grip magic set to “ON”.

* Depending on the cover, y ou may be able to use Grip sensor with the product

equipped with it. Set “Putting cover setting” to “Cover ed” after equipping the
product with the cover.

Display (Touch panel)

◎ If the product is equipped with a commercially available corresponding

flip cover, you can turn the display on/off by opening/closing the flip
cover. If you close the equipped flip cover obliquely, the display may not
be turned off.

Proximity sensor/Light sensor, earpiece (receiver), mouthpiece
(microphone), speaker, sub microphone

◎ Placing stickers, etc. over proximity sensor/light sensor may prevent the

product from operating properly.

◎ Covering earpiece (receiver), mouthpiece (microphone), speaker or sub

microphone with stickers, fingers, etc. may hinder product performance.

TV antenna, internal antenna, Wi-Fi®/Bluetooth®/GPS antennas

◎ Antennas are built into the product. Do not cover with hand during calls or

data communication. Doing so may affect call/communication quality.

®

/NFC.

*

7

Using the au Nano IC Card 04

IC (metal) part

au Nano IC Card 04

Front Back

au Nano IC Card
04 tray

au Nano IC Card 04 tray

au Nano IC Card 04

IC (metal) part up

Notches

au Nano IC Card
04 tray slot

Metal parts

au Nano IC Card 04

The au Nano IC Card 04 records your personal information such as phone
numbers.
Any au IC card other than au Nano IC Card 04 cannot be used with the product.

◎ Make sure to unplug the microUSB plug of the common AC adapter 05

(sold separately) etc. from the product when attaching or removing the au
Nano IC Card 04.

Attaching the au Nano IC Card 04

Before attaching the au Nano IC Card 04, turn the product off.

A Open the au Nano IC Card 04/microSD memory card cover.
B Slowly pull the au Nano IC Card 04 tray straight out by

hooking a finger on it.

C Put the au Nano IC Card 04 on the au Nano IC Card 04 tray.

Make sure the notches on the au Nano IC Card 04 and au Nano IC Card
04 tray face the proper orientation and put the card slowly on the tray.

D Slowly insert the au Nano IC Card 04 tray into the au Nano

IC Card 04 tray slot, taking care not to let the tray be
caught on the metal parts on both sides of the slot.

Confirm the position of the au Nano IC Card 04 tray slot and the orientation
of the au Nano IC Card 04 tray carefully, and insert the tray all the way into
the slot in the direction of the arrow. Inserting the tray forcibly may
damage the tray.

8
