LCD MONITOR
TOUCH PANEL SETTINGS TOOL
OPERATION MANUAL
Version 1.0
Applicable models (as of March 2014)
PN-L703A/PN-L703B/PN-L603A/PN-L603B/PN-70TA3/PN-70TB3/PN-60TA3/PN-60TB3
(Available models differ according to region.)
![](/html/b1/b193/b19353f63a9c5a6a5641538d0a9e0c4286e003c39fd178dff34313b1c56a58a0/bg2.png)
Contents
Introduction ......................................................................3
System Requirements ..................................................3
Setting up the PC .............................................................4
Install ............................................................................4
Touch Panel Settings .......................................................5
How to congure settings .............................................5
Calibration ....................................................................6
Properties .....................................................................6
Uninstall ............................................................................8
Important Information
• This software has been shipped after strict quality control and product inspection. If, however, you nd any failure or
malfunction, contact your product dealer.
• Please understand that SHARP CORPORATION bears no responsibility for errors made during use by the customer or a
third party, nor for any other malfunctions or damage to this software arising during use, except where indemnity liability is
recognized under law.
• Transcribing or duplicating part or all of this manual and/or this software without permission from our company is not
permitted.
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for
product improvement without prior notice.
• The contents or details may vary depending on the screen conguration and OS version, etc.
• This manual does not contain basic operating instructions for Windows.
Trademarks
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
• Intel, Celeron, and Intel Core 2 Duo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the U.S.A.
and other countries.
• AMD, AMD Sempron, AMD Athlon, and combinations thereof are trademarks of Advanced Micro Devices, Inc.
• All other brand and product names are trademarks or registered trademarks of their respective holders.
![](/html/b1/b193/b19353f63a9c5a6a5641538d0a9e0c4286e003c39fd178dff34313b1c56a58a0/bg3.png)
Introduction
This software is used to congure touch action settings in order to perform touch action on a computer connected to an
applicable model.
To perform touch action on a computer connected to an applicable model, this software must be installed on the computer.
System Requirements
OS
CPU
Memory At least 2 GB
Free space on hard drive At least 100 MB
USB port USB (2.0 compliant)
TIPS
• Depending on the application software, touch operation may not be possible (for example, if the application processes mouse
and other operations independently).
Windows 7 (32-bit or 64-bit version),
Windows 8 (32-bit or 64-bit version), Windows 8.1 (32-bit or 64-bit version)
Intel Celeron or AMD Sempron 1.6 GHz or faster
Intel Core 2 Duo or AMD Athlon II X2 2.8 GHz or faster recommended
