Sharp PN-455 User Manual

PN-455

LCD MONITOR

ENGLISH

IMPORTANT:
To aid reporting in case of loss or theft, please
record the product’s model and serial numbers in
the space provided. The numbers are located in
the rear of the product.

ENGLISH

Model No.:

Serial No.:

U.S.A. ONLY

IMPORTANT INFORMATION

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning flash with arrowhead

CAUTION

RISK OF ELECTRIC
SHOCK
DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT
REMOVE COVER.
NO USER-SERVICEABLE
PA RTS INSIDE.
REFER SERVICING TO QUALI­FIED SERVICE PERSONNEL.

symbol, within an equilateral triangle, is
intended to alert the user to the pres­ence of uninsulated “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.

The exclamation point within a triangle
is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product.

1

E

IMPORTANT INFORMATION (Continued)

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equip-

ment not expressly approved by the manufacturer could void the user’s authority to
operate this equipment.

U.S.A. ONLY

CAUTION: Use the supplied AC cord as it is.

INFORMATION:

This equipment has been tested and found to comply with the limits for Class A digital equipment,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encour­aged to try to correct the interference by one or more of the following measures:

• Relocate or adjust the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con­nected.

• Consult an authorized dealer or experienced radio/TV technician for help.

U.S.A. ONLY

CAUTION

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type

recommended by the manufacturer.

Dispose of used batteries according

to local regulations.

This product utilizes fluorescent tubes containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the Electronic Industries Alliance:
www.eia.org

E

2

DEAR SHARP CUSTOMER

Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of
trouble-free operation of your product, please read the Safety Precautions carefully before using
this product.

SAFETY PRECAUTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD product, please read the following
precautions carefully before using the product.

1. Read instructions — All operating instructions must be read and understood before the product is

operated.

2. Keep this manual in a safe place — These safety and operating instructions must be kept in a safe

place for future reference.

3. Observe warnings — All warnings on the product and in the instructions must be observed closely.

4. Follow instructions — All operating instructions must be followed.

5. Cleaning — Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth

to clean the product. Do not use liquid cleaners or aerosol cleaners.

6. Attachments — Do not use attachments not recommended by the manufacturer. Use of inadequate

attachments can result in accidents.

7. Water and moisture — Do not use the product near water, such as bathtub, washbasin, kitchen sink

and laundry tub, swimming pool and in a wet basement.

8. Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on

an unstable base can cause the product to fall, resulting in serious personal injuries as well as dam­age to the product.

9. Ventilation — The vents and other openings in the cabinet are designed for ventilation.

Do not cover or block these vents and openings since insufficient ventilation can cause
overheating and/or shorten the life of the product. Do not place the product on a bed,
sofa, rug or other similar surface, since they can block ventilation openings. Do not
place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer’s instructions are followed.

10. Power cord protection — The power cords must be routed properly to prevent people
from stepping on them or objects from resting on them.

11. The LCD panel used in this product is made of glass. Therefore, it can break when the product is
dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the LCD
panel breaks.

12. Overloading — Do not overload AC outlets or extension cords. Overloading can cause fire or electric
shock.

13. Entering of objects and liquids — Never insert an object into the product through vents or openings.
High voltage flows in the product, and inserting an object can cause electric shock and/or short
internal parts.
For the same reason, do not spill water or liquid on the product.

14. Servicing — Do not attempt to service the product yourself. Removing covers can expose you to high
voltage and other dangerous conditions. Request a qualified service person to perform servicing.

15. Repair — If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.

Do not touch the controls other than those described in the operating instructions. Improper
adjustment of controls not described in the instructions can cause damage, which often requires
extensive adjustment work by a qualified technician.

ENGLISH

3

E

SAFETY PRECAUTIONS (Continued)

e. When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product

indicates that the product needs servicing.

16. Replacement parts — In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteristics
and performance as the original parts. Use of unauthorized parts can result in fire, electric shock
and/or other danger.

17. Safety checks — Upon completion of service or repair work, request the service technician to per­form safety checks to ensure that the product is in proper operating condition.

18. Wall or ceiling mounting — When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.

19. Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and
other heat-generating products (including amplifiers).

20. Power source —This product must operate on a power source specified on the specification label. If
you are not sure of the type of power supply used in your home, consult your dealer or local power
company.
For units designed to operate on batteries or another power source, refer to the operating instruc­tions.

WARNING:

This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.

WARNING:

To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.

E

4

TIPS AND SAFETY PRECAUTIONS

ENGLISH

- The TFT color LCD panel used in this monitor is

made with the application of high precision
technology. However, there may be minute
points on the screen where pixels never light or
are permanently lit. Also, if the screen is viewed
from an acute angle there may be uneven colors
or brightness. Please note that these are not
malfunctions but common phenomena of LCDs
and will not affect the performance of the moni­tor.

- Do not display the same image on the screen

for a long period of time, as this may cause an
afterimage to remain.

- The quality of the computer signal may influ-

ence the quality of the display. We recommend
using a computer able to perform high quality
video signals.

-Never rub or tap the monitor with hard objects.

- Please understand that Sharp Corporation

bears no responsibility for errors made during
use by the customer or a third party, nor for any
other malfunctions or damage to this product
arising during use, except where indemnity
liability is recognized under law.

- This monitor and its accessories may be up-

graded without advance notice.

- Do not use the monitor where ventilation is poor,

where there is a lot of dust, where humidity is
high, or where the monitor may come into
contact with oil or steam, as this could lead to
fire.

- Ensure that the monitor does not come into

contact with water or other fluids. Ensure that no
objects such as paper clips or pins enter the
monitor as this could lead to fire or electric
shock.

- Do not place the monitor on top of unstable

objects or in unsafe places. Do not allow the
monitor to receive strong shocks or to strongly
vibrate. Causing the monitor to fall or topple
over may damage it.

- Do not use in places where the monitor will be

subject to direct sunlight, near heating equip­ment or anywhere else where there is likelihood
of high temperature, as this may lead to genera­tion of excessive heat and outbreak of fire.

The Power Cord

- Do not damage the power cord nor place heavy
objects on it, stretch it or over bend it. Also, do
not add extension cords. Damage to the cord
may result in fire or electric shock.

- Use only the power cord supplied with the
monitor.

- Insert the power plug directly into the AC outlet.
Adding an extension cord may lead to fire as a
result of overheating.

- Do not remove or insert the power plug with wet
hands. Doing so could result in electric shock.

Manual Scope

- In this manual, Microsoft Windows XP will be
referred to as “Windows XP”, and Microsoft
Windows 2000 as “Windows 2000”.
When there is no need to distinguish between
programs, the term “Windows” will be used.

- Microsoft and Windows are registered trade­marks of Microsoft Corporation.

- All other brand and product names are trade­marks or registered trademarks of their respec­tive holders.

- Language of OSD menu used in this manual is
English by way of example.

- Illustrations in this manual may not exactly
represent the actual product or display.

Fluorescent Tubes

● The fluorescent tubes in this product have a

limited lifetime.

* If the screen gets dark, flashes, or does not turn on,

change the fluorescent tubes with new exclusive ones.

*For more information, please contact your product

dealer.

● Because of the property of fluorescent tubes,

the screen may flash during the initial period of
use. If this happens, please turn off the main
power switch on the top of the monitor and turn
on again to confirm operation.

5

E

Contents

Introduction

IMPORTANT INFORMATION .................................................................................... 1

DEAR SHARP CUSTOMER ..................................................................................... 3

SAFETY PRECAUTIONS ......................................................................................... 3

TIPS AND SAFETY PRECAUTIONS........................................................................ 5

Features.................................................................................................................... 7

Supplied Accessories ............................................................................................. 8

Part Names - Display ............................................................................................... 9

Front view .............................................................................................................. 9

Rear view ............................................................................................................ 10

Part Names - Remote Control Unit ....................................................................... 11

Removing the battery cover ................................................................................ 12

Remote control operation range ......................................................................... 12

Connection and Installation

Connecting Peripheral Equipment....................................................................... 13

Connecting External Speakers............................................................................. 18

Connecting the AC Cord ....................................................................................... 19

Connecting Multiple Monitors .............................................................................. 20

Mounting Precautions ........................................................................................... 21

Mounting the Temporary Stands .......................................................................... 22

Bundling Cables .................................................................................................... 22

Attaching the Carrying Handles ........................................................................... 23

Basic Operation

Turning on Power................................................................................................... 24

Main power switch............................................................................................... 24

Tu r ning power on/off using remote control .......................................................... 24

Remote Control Unit .............................................................................................. 25

Menu Items ............................................................................................................. 26

Menu option selection ......................................................................................... 26

Menu screen explanation .................................................................................... 28

Initialization (Reset)/Functional Restriction Setting .......................................... 29

Settings and Adjustments .................................................................................... 30

Screen display for adjustments (INPUT2) ........................................................... 36

Set-up information (INPUT1 / INPUT2)............................................................... 37

PC Operation

PC Operation .......................................................................................................... 38

PC connection..................................................................................................... 38

Communication conditions .................................................................................. 39

Communication procedure .................................................................................. 40

RS-232C command table.................................................................................... 47

Troubleshooting and Specifications

Troubleshooting..................................................................................................... 52

Specifications ........................................................................................................ 54

Appendix

PC Digital/Analog Signal Input Compatibility Chart ........................................... 56

Connector Compatibility Charts .......................................................................... 57

Dimensional Drawings .......................................................................................... 58

Menu Option Reference Chart .............................................................................. 59

E

6

Features

● HIGH-DEFINITION (HD) LCD PANEL

•A large, flat LCD panel with 1920 x 1080 pixels lets you enjoy a detailed, high-definition picture.

● ASV*LOW-REFLECTION BLACK TFT LCD PANEL

• SHARP’s unique ASV* low-reflection BLACK TFT LCD panel provides higher luminance, higher
contrast, and a wider viewing angle. This reduces reflection in the monitor when it is placed near a
window, and ensures brighter, more vivid image reproduction. With a wide viewing angle of 170
degrees, both horizontally and vertically, the image is beautiful, even when viewed off axis.

* ASV: Advanced Super View

● EQUIPPED WITH A VARIETY OF TERMINALS

• PC digital RGB input terminal (See pages 10 and 13.)

• PC analog RGB input terminal (See pages 10 and 14.)

• Component input terminal (See pages 10 and 15)

• Composite Video input terminal (See pages 10 and 16.)

• S-video input terminal (See pages 10 and 16.)

• RS-232C input terminal (See pages 10 and 21.)

ENGLISH

● ENLARGEMENT FUNCTION

• Allows output of enlarged images for 4- or 9-screen (“2 x 2” or “3 x 3”) setups, without using special­purpose external equipment. (See page 33.)

● CHAIN CONNECTION OF MULTIPLE MONITORS

• Enables chain connection of monitors using PC analog RGB output terminal. (See page 20.)

• Enables individual control via PC of multiple sets connected in a daisy chain using RS-232C cables.
(See pages 21 and 39.)

● EXTERNAL CONTROL AND STATUS MONITORING FROM A PC

• The monitor can be controlled in various ways from a PC. (See page 38.)

• Multiple monitors can be individually controlled by connecting them in a daisy chain. (See pages 21
and 39.)

● EXTERNAL SPEAKERS CAN BE CONNECTED

• Compatible speakers: L/R, 6 Ω, 10W or larger (See page 18.)

● CONTROL LOCK FUNCTIONS

• The monitor is equipped with various operation lock functions to prevent unintended operation or
mischief. (See page 29.)

7

E

Supplied Accessories

Make sure the following accessories are provided with the product.

Liquid Crystal Display (1)

INPUT

AC cord (1) CD-ROM (1)

(0PEQACCU1026M)

(Utility Disk for
Windows)

Temporary stand (2)

●Temporary stand
mounting screw (2)

“AA” size battery (2) Remote control unit (1) Carrying handle (2)

P
O

W

E
R

IN

P
U

T

M

U
T

E

M

E

N

U
B
R
IG

H
T

­B

R
IG

H

T
+

D
IS

LA

Y

M

O
D

E

S
IZ

E

REMOTE CONTROL

LC-450F

RRMCG1004MPPZ

●Carrying handle
mounting screw
(4) / Spacer (4)

Cable clamp (2)

AC cord clamp (1)

● Operation manual (1) ● Video connection cable (1)
(0PE1S8022411/)

● Component connection cable (1)
(0PEQCNW-1165M)

•You are advised to retain the carton in case the monitor needs to be transported.

• Sharp Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without
permission.

E

8

Part Names - Display

INPUT

Front view

Liquid Crystal Display panel

Remote control sensor

(See page 12.)
* When using the remote control,

point it towards here.

Input button

(See page 25.)
* Press with a sharp object such as a pen.

ENGLISH

INPUT

Power button

(See page 24.)
* Press with a sharp object such as a pen.

Power LED

(See page 24.)

9

E

Part Names - Display (Continued)

Rear view

Main power switch

VESA holes

(M6, 15mm in depth
x 6 holes)

INPUT3

Pb
Cb

Pr
Cr

Y

Component input
terminal <INPUT3>

(See page 15.)

AC input terminal

(See page 19.)

RS-232C

INPUT4
(VIDEO)

AC

OUTPUT

SPEAKER

R L

Composite Video input
terminal <INPUT4>

(See page 17.)

* The S-video terminal

has priority over the
video input terminals.

RS-232C output terminal

(See pages 21 and 39.)

External speaker terminals (right)

(See page 18.)

External speaker terminals (left)

(See page 18.)

PC analog RGB input terminal <INPUT2>

(See page 14.)

INPUT2

(RGB)

Audio output terminals

(See page 17.)

OUTPUT

(RGB)

RS-232C

INPUT

INPUT1

(DVI)

PC digital RGB input terminal <INPUT1>

(See page 13).

RS-232C input terminal

(See pages 21 and 39.)

PC analog RGB output terminal

(See pages 17 and 20.)

PC audio input terminal

(See pages 13 and 14.)

AUDIO OUT

INPUT4

R L

(S-VIDEO)

AUDIO IN

PC AUDIO

R L

IN

Audio input terminals

(See pages 15, 16 and 17.)

S-video input terminal <INPUT4>

(See page 16.)

E

10

Part Names - Remote Control Unit

POWER button

(See page 24.)

MUTE button

(See page 25.)

DISPLAY button

(See page 25.)

MODE button

(See page 25.)

VOL buttons

(See page 25.)

BRIGHT buttons

(See page 25.)

INPUT button

(See page 25.)

Signal transmitter

MENU button

(See page 26.)

SIZE button

(See page 25.)

Cursor control
( / / / ) buttons (See page 26.)

* You can use this button when

the menu is not displayed.

* You can use this button when

the menu is not displayed.

* You can use this button when

the menu is displayed.

Remote control unit

ENGLISH

11

E

Part Names - Remote Control Unit (Continued)

Removing the battery cover

Gently hold down and press in
the arrow direction.

Cautions regarding remote control unit

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to
liquids, and do not place it in an area with high humidity.

• The remote control unit may not work properly if the remote control sensor is under direct sunlight or
strong lighting. In such cases, change the angle of the lighting or the monitor, or operate the remote
control unit closer to the remote control sensor.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
Replace with new batteries at the earliest opportunity.

• If you will not use the remote control for a long time, remove the batteries.

• If the remote control does not work, even with new batteries, take the batteries out, check whether they
are facing the right way, then replace them.

• Do not use rechargeable (Nickel-metal-hydride) batteries.

Remote control operation range

Operation range of the remote control unit is approx. 7 m (23 ft.) and an angle of approx. 10° from the
center to the top/bottom/right/left of the remote control sensor.

Remote control sensor

13.1 feet (4 m)

10°

DISPLA

Y

R

E
M

O
T

E
C

O
N

T
R

M
U

BR
IG

H
T

-

V
O

L

-

MODE

SIZ

E

O
L

PO

W
ER

IN
P

U

T
T
E

M
V
O

EN
L
+

U

B
R

IG
H

T
+

16.4 feet
(5 m)

10°

13.1 feet
(4 m)

If the remote control unit does not work well:

• Objects between the remote control unit and the remote control sensor may prevent proper operation.

• Replace the batteries when they run low as this may shorten the remote control’s operation range.

• If a fluorescent light is illuminated near the remote control unit, it may interfere with proper operation.

• Do not use it with the remote control of other equipment such as air conditioner, stereo components, etc.

E

12

Connecting Peripheral Equipment

The various terminals on the LCD panel are described below.

INPUT1 (PC DIGITAL)

• Connect with the digital RGB output terminal on your computer using a digital signal cable (commer­cially available).

* Connection with computers that have an output terminal (DVI-D 24 pin or DVI-I 29 pin) conforming to DVI is

possible. (However, images may not display properly depending on the computer.)

• Connect with an audio output jack on your computer using a PC audio cable (commercially avail­able).

▼ Rear view

Output terminals on

connected equipment

Audio Digital RGB

PC digital
RGB input terminal

PC audio input
terminal

ENGLISH

Digital signal cable

* See page 56 for compatible signals.

PC audio cable

INPUT1

(DVI)

PC AUDIO

IN

13

E

Connecting Peripheral Equipment (Continued)

INPUT2 (PC ANALOG)

• Connect with the display connector on your computer using a RGB cable (commercially available).

• Connect with an audio output jack on your computer using a PC audio cable (commercially avail­able).

▼ Rear view

Output terminals on

connected equipment

Audio

Display

connector

PC analog
RGB input terminal

INPUT2

(RGB)

PC audio input terminal

PC AUDIO

IN

RGB cable

PC audio cable

*1 Auto-detects sync signal type.
*2 Sync signal presence is detected in the order: Composite Sync, Separate Sync and Sync-on-green. If for

some reason Composite Sync and Separate Sync are not input, the system will operate assuming that the
signal is a Sync-on-green (i.e. that the sync signal is contained in the G signal of RGB). This may result in
an unstable image, depending on the video signal.

*3 See page 56 for compatible signals.

E

14

INPUT3 (COMPONENT)

• Connect with component output terminals using a component cable (commercially available).

• Connect with an audio output terminal using an audio (RCA) cable (commercially available).

▼ Rear view

Output terminals on

connected equipment

Component

video

Audio - Right
Audio - Left

Audio input
terminals

AUDIO IN

R L

ENGLISH

(Red) (White) (Red) (White)

(Y)

(Pb/

Cb)

(Pr/

Cr)

Component cable

Audio cable

Component connection cable(*1)

(Y)
(Pb/Cb)
(Pr/Cr)

INPUT3

Pb
Cb

Pr
Cr

Y

Component
input terminal

*1 When you connect the monitor with equipment that has a component output terminal, you can use the

supplied component connection cable as shown in the illustration above.

15

E

Connecting Peripheral Equipment (Continued)

INPUT4 (S-VIDEO/VIDEO)

• Connect with equipment that has an S-video output terminal using an S-video cable (commercially
available).*

• Connect with equipment that has a video output terminal using a video (BNC) cable (commercially
available).*

• Connect with an audio output terminal using an audio (RCA) cable (commercially available).

▼ Rear view

Output terminals on

connected equipment

Audio - Right
Audio - Left

S-video

S-video
input terminal

Audio input

terminals

S-video cable

Audio cable

Compatible S-video signal NTSC (3.58 MHz)

* S-video input will have priority over composite video when connected.

(Red) (White)(Red) (White)

INPUT4

(S-VIDEO)

AUDIO IN

R L

E

16

▼ Rear view

ENGLISH

Output terminals on

connected equipment

Audio - Right
Audio - Left

Video

Composite video input terminal

INPUT4
(VIDEO)

Audio input
terminals

AUDIO IN

R L

Video connection cable (*2)

(Red) (White)

Video cable

(Red) (White)

Audio cable

Compatible video signal NTSC (3.58 MHz)

*1 S-video input will have priority over composite video when connected.
*2 When you connect the monitor with equipment that has a video output terminal, you can use the supplied

video connection cable as shown in the illustration above.

PC ANALOG RGB OUTPUT TERMINAL

• Video signal from INPUT2 (PC analog) is output. Use when connecting multiple monitors in a daisy
chain via RGB cables (commercially available). See page 20 for a detailed connection example.

AUDIO OUTPUT TERMINAL

•Audio from the equipment connected to the audio input terminal or PC audio input terminal is output.
Connect to the audio input terminal of the connected equipment using an audio (RCA) cable (com­mercially available) or a PC audio cable (commercially available).

• The terminal for which audio is output differs by screen mode.

- When input mode is INPUT1 or 2, the audio from the PC audio input terminal will be output.

- When input mode is INPUT3 or 4, the audio from the audio input terminal will be output.

17

E

Connecting External Speakers

Be sure to use external speakers with an impedance of 6 ohms and a rated input of at least 10 W.

▼ Rear view

Black

Red

SPEAKER

Red

R L

External speaker terminals (right)

External speaker terminals (left)

Connecting the speaker cables

1. While pushing the tab, insert the tip of the cable.

2. Release the tab.

1.

2.

Make sure to connect the speaker jack and cable polarity ( , ) properly.

The speaker jacks have plus and minus polarity. Plus is red and minus is black.
The speaker cables are also divided into plus and minus.
When connecting the left/right speakers, be sure to connect the plus/minus jacks with the correct cables.

E

18

Connecting the AC Cord

Be sure to turn the main power switch off when connecting the cord.

Main power switch

▼ Rear view

Plug (to the AC input terminal)

AC input terminal

Turn off the main power switch on the top of the monitor.

AC cord

Plug (to power outlet)

ENGLISH

Power outlet

Connecting the AC cord

1. Plug the AC cord into the AC input terminal of the monitor.

2. Plug the AC cord into the AC power outlet.

19

E

Connecting Multiple Monitors

Multiple monitors can be connected in a daisy chain using the input/output terminals for video signals.

Connection example

PC analog RGB
input terminal

▼ First monitor

PC analog RGB
output terminal

INPUT2

OUTPUT

(RGB)

(RGB)

RGB cable

PC analog RGB
input terminal

▼ Second monitor

INPUT2

(RGB)

shows the
signal flow.

To PC analog RGB output terminal

*1 Multiple monitors cannot be connected in a daisy chain for audio. Connect the external audio amplifier to the

audio output terminals.

*2 The length of RGB cable or surrounding environment may affect the image quality.

E

20

Connection example for RS-232C

Monitors can be externally controlled using the RS-232C interface (COM port) of a PC, and, in this case
too, multiple monitors can be connected in a daisy chain. By assigning each monitor an ID number (see
page 46), you can perform input switching, adjustment and status monitoring of individual monitors.

ENGLISH

▼ PC

RS-232C
output terminal

To COM port

▼ First monitor

RS-232C
OUTPUT

RS-232C

output terminal

input terminal

RS-232C

RS-232C

INPUT

RS-232C straight cable

▼ Second monitor

RS-232C
OUTPUT

RS-232C
input terminal

RS-232C

INPUT

Mounting Precautions

• Special techniques are required to mount this monitor, so be sure to rely on an authorized Sharp dealer
for installation work. You should never perform any of this work yourself. Our company will bear no respon­sibility for accidents or injuries caused by improper mounting or handling.

•Moving or installing the monitor must be done by two or more people.

•Keep the monitor surface perpendicular to a level surface or tilt up to a maximum of 20 degrees down­ward.

• This monitor is equipped with two temporary stands when shipped from the factory. Please note that
these stands are for temporary use only until the monitor is properly mounted.

• Be sure to use a stand or a wall-mount/ceiling-mount bracket designed or designated for mounting the
monitor.

• Do not lay the monitor display-side down or up as this could lead to a malfunction.

• When mounting the monitor, the following amount of open space is required to clear the ventilation for the
monitor; at least 7.9 inch (20 cm) above, 1.97 inch (5 cm) right/left/below, and 2.76 inch (7 cm) behind the
monitor. Do not block any ventilation openings. If the temperature inside the monitor rises, this could lead
to a malfunction.

21

E

Mounting the Temporary Stands

Please note that the temporary stands are for temporary use only until the monitor is properly mounted.
Attach each temporary stand to the bottom of the monitor as shown below.

▼ Rear view

Temporary

Screw

stand

Bundling Cables

The AC cord can be fastened using the supplied AC cord clamp. This will prevent the AC cord from falling
off.
Also, the cables connected to the terminals on the back of the monitor from the external equipment can be
neatly bundled using the supplied cable clamps as shown in the illustration below. This will prevent stray or
disorganized cables at the back of the monitor.

▼ Rear view

123

Hole for the

Band

Fastened
part

AC cord clamp

Fastening the AC cord

1. Attach the supplied AC cord clamp to the AC cord, making sure the AC cord clamp is circular hole-side

down.

2. Insert the tip of the band into the hole for the AC cord clamp.

3. While holding the tail of the band, slide the fastened part toward the AC input terminal.

E

22

Attaching the Carrying Handles

When carrying the monitor, attach the two carrying handles to the top of the monitor as shown below.

Screw

Spacer

▼ Rear view

ENGLISH

* After mounting the monitor, remove the carrying handles from the monitor.

23

E

Turning on Power

IN

P
U

T

Before turning on power, make sure that peripherals, external speakers, and the AC cord are connected
properly.
There are two power supply switches: Main power switch on the top of the monitor and POWER button
on the remote control unit.
If the monitor is connected to a computer, turn on the monitor first before turning on the computer.

Main power switch

When the main power switch is off, the monitor is not turned on with the POWER button on the remote
control unit.

Main power switch

Turn on the main power switch on the top of the monitor.

▼ Rear view

When switching the main power switch off and back on, always wait for
at least 5 seconds. Rapid switching may result in a malfunction.

Turning power on/off using remote control

▼ Remote control unit

Press the POWER button to turn the power ON/OFF.

Power “On”: Power LED lights up green.
Power “Off”: Power LED lights up orange. (Standby mode)

▼ Front view

Power LED

INPUT

• After turning on the power, if there is no video signal, the backlight of the monitor is turned off. (Waiting
mode)

• In waiting mode, the power LED blinks green.

• In waiting mode, if you press the POWER button on the remote control unit, the monitor will be turned off.

• If the remote control is not available, you can turn on/off by pressing the POWER button beside the power
LED with a sharp object.

E

24

Remote Control Unit

Generally the monitor is operated using the remote control unit.

INPUT (Input selection)

Each time you press this button, the mode changes in the following order:

• INPUT1 (DIGITAL) ➞ INPUT2 (ANALOG) ➞ INPUT3 (COMPONENT) ➞
INPUT4 (VIDEO) ➞ INPUT1 (DIGITAL)...

* If the remote control is not available, you can change the mode by

pressing the input button beside the remote control sensor with a sharp
object.

MUTE

Tu r ns off the volume temporarily.
Press the MUTE button again to turn the sound back to the previous level.

MENU

Displays and turns off the menu screen (see page 30).

VOL (Volume adjustment)

Displays the VOLUME menu when the menu screen is not displayed.

VOLUME 15

ENGLISH

Press to increase the volume, and to decrease the volume.
* If you do not press any buttons for about 4 seconds, the VOLUME menu

automatically disappears.
Sound is muted when volume is set to “0”.

BRIGHT (Backlight adjustment)

Displays the BRIGHT menu when the menu screen is not displayed.

*41/06 #

Press to increase the brightness of the screen, and to decrease
the brightness of the screen.
* If you do not press any buttons for about 4 seconds, the BRIGHT menu

automatically disappears.

SIZE (Screen size selection)

Each time you press this button, the screen size changes in the following
order (see page 35):

• WIDE ➞ ZOOM1 ➞ ZOOM2 ➞ NORMAL ➞ Dot by Dot ➞ WIDE...

MODE (Screen mode selection)

Each time you press this button, the screen mode changes in the following
order:

• STD ➞ OFFICE (Power saving mode) ➞ VIVID ➞ STD...

DISPLAY

Displays monitor status such as INPUT, SIZE, etc.
Press the DISPLAY button again to exit.

25

E

Menu Items

Menus can be displayed on the screen to enable video and audio adjustment and the setting of various
functions using the remote control unit. For more information, refer to the pages where each topic is
explained.

Menu option selection

MENU button

• Displays and turns off the menu screen.

• Switches menu screens.

Cursor control (UP/DOWN/LEFT/RIGHT)

• / : Selects a desired item on the screen.

• / : Adjusts the selected item.

Pressing increases a value.

Pressing decreases a value.

Example of menu operation: Adjusting CONTRAST (video) in the GAIN CON­TROL menu.

1. Press

MENU

to display the menu screen.

 























     

E

26

2. Press

MENU

to display the GAIN CONTROL menu.

  



 



ENGLISH









3. Press to select CONTRAST.

  



 





4. Press (or ) to adjust the setting.

  



 



     







     







5. Press



MENU

more than once to close the menu screen.

     

The menu screen will close automatically if no operation is performed for about 15 seconds.

• The menu displayed when you press the MENU button will differ depending on the type of input signal.

27

E

Menu Items (Continued)

Menu screen explanation

Item: Select using the MENU button.

  



Settings:

Setting names and
their status

Yellow: Current setting
Blue: Selectable items
Gray: Items that cannot be selected
* There are various reasons why items cannot be selected, but the main reasons are as follows:

• There is no signal.

• The function is not compatible with the current input signal.

 











     

Input signal:

Displays the type of signal
currently being input.

Highlight:

The currently selected
item will be highlighted.

Screen resolution,
vertical frequency, and
horizontal frequency:

Displays the screen
resolution, vertical fre­quency, and horizontal
frequency of the current
input signal.

Menu screen duration

• The menu screen will revert to the normal screen if there is no operation for about 15 seconds while
the menu screen is displayed.

• The menu item illustrations in this operation manual are for explanation purposes only and may vary
slightly from what is actually displayed.

E

28

Initialization (Reset)/Functional Restriction Setting

In the FUNCTION 1 screen, you can return contrast, image quality, and other settings to their factory­preset values, specify whether LEDs lights, and enable control via RS-232C (see page 38) among other
functions.

1. After pressing

SIZE

for about 5 seconds, press , , , and in that order.

The FUNCTION 1 screen will appear.

FUNCTION 1

ALL RESET

ADJUSTMENT LOCK

OSD DISPLAY

LED

RS-232C

LOCKED

ON

ON

LOCKED

ALL RESET

UNLOCKED

OFF

OFF

UNLOCKED

2. Select and set the items you want.

[ALL RESET]

Function Returns all settings to their factory preset values. After initialization (reset),

turn the main power switch off and then back on.

[ADJUSTMENT LOCK]

Function Specifies whether to lock settings such as ADJUSTMENT and WHITE BALANCE.

While locked, the remote control unit cannot perform operations other than turning

power on/off (POWER button) and displaying the FUNCTION 1 screen.
Default UNLOCKED
LOCKED Locks the setting.
UNLOCKED Unlocks the setting.

[OSD DISPLAY]

Function Hides/shows menus. The FUNCTION 1 screen cannot be hidden.
Default ON
ON Displays the menus.
OFF Hides the menus.

[LED]

Function Specifies whether to light LEDs.
Default ON
ON Lights LEDs.
OFF Does not light LEDs.

[RS-232C]

Function Specifies whether to allow control (see page 38) via RS-232C.
Default UNLOCKED
LOCKED Disables control via RS232C.
UNLOCKED Enables control via RS-232C.

ENGLISH

3. Press

MENU

to return to the normal screen.

29

E

Settings and Adjustments

■ ADJUSTMENT (INPUT2)

[MANUAL / AUTO]

Function Adjusts CLOCK, PHASE, H-POS (horizontal positioning), and V-POS (vertical

positioning) are adjusted.

Adjustable range MANUAL/AUTO
MANUAL The CLOCK, PHASE, H-POS, and V-POS are manually adjusted. You can use the

adjustment pattern on the supplied CD-ROM to adjust each parameter.

See page 41 for more information on the screen display for making adjustments.

AUTO The CLOCK, PHASE, H-POS, and V-POS are automatically adjusted.

[MANUAL (CLOCK)]

Function Adjusts frequency for sampling clock for applicable video.

Adjust when there is flickering in the form of vertical stripes.

When using the adjustment pattern (see page 36), make adjustments so that no

vertical stripe noise appears in it.

Adjustable range 0 - 255
Default 127
+ direction Clock frequency increases.
– direction Clock frequency decreases.

[MANUAL (PHASE)]

Function Adjusts sampling clock phase for applicable video.

Useful when small characters appear with low contrast and/or there are flickers at

corners. When using the adjustment pattern (see page 36), make adjustments so

that no horizontal stripe noise appears in it.

Adjustable range 0 - 255
Default 127
+ direction Advances clock phase.
– direction Delays clock phase.

[MANUAL (H-POS)]

Adjustable range 0 - 255
Default 127
+ direction Image shifts right.
– direction Image shifts left.

[MANUAL (V-POS)]

Adjustable range 0 - 255
Default 127
+ direction Image shifts up.
– direction Image shifts down.

E

30

■ GAIN CONTROL (INPUT2)

[MANUAL / AUTO]

Function Adjusts BLACK LEVEL and CONTRAST.
Adjustable range MANUAL / AUTO
MANUAL The BLACK LEVEL and CONTRAST are manually adjusted.
AUTO The BLACK LEVEL and CONTRAST are automatically adjusted.

[MANUAL (BLACK LEVEL)]

Adjustable range 0 - 31
Default 15
+ direction Brightens entire video signal.
– direction Darkens entire video signal.

[MANUAL (CONTRAST)]

Adjustable range 0 - 31
Default 15
+ direction For more contrast
– direction For less contrast

ENGLISH

■ WHITE BALANCE

[THRU / COOL / • / STD / • / WARM / USER] (INPUT1 / INPUT2)

Adjustable range THRU / COOL / • / STD / • / WARM / USER
Default STD
THRU Displays the input signal level as it is. This item is only selectable for INPUT1.
COOL Color tone bluer than standard

• Color tone slightly bluer than standard
STD Color tone standard setting

• Color tone slightly redder than standard
WARM Color tone redder than standard
USER Allows you to individually adjust R-CONTRAST, G-CONTRAST, and

B-CONTRAST.

[COPY to USER] (INPUT1 / INPUT2)

Adjustable range OFF / SET
SET Copies the values set for COOL / • / STD / • / WARM to USER settings.

[USER (R-CONTRAST)] (INPUT1 / INPUT2)

Adjustable range 0 - 255

+ direction Brightens red component.
– direction Darkens red component.

[USER (G-CONTRAST)] (INPUT1 / INPUT2)

Adjustable range 0 - 255
+ direction Brightens green component.
– direction Darkens green component.

[USER (B-CONTRAST)] (INPUT1 / INPUT2)

Adjustable range 0 - 255
+ direction Brightens blue component.
– direction Darkens blue component.

31

E

Settings and Adjustments (Continued)

[CONTRAST] (INPUT3 / INPUT4)

Adjustable range 0 - 31
Default 15
+ direction For more contrast
– direction For less contrast

[BLACK LEVEL] (INPUT3 / INPUT4)

Adjustable range 0 - 31
Default 15
+ direction Brightens entire video signal.
– direction Darkens entire video signal.

[TINT] (INPUT3 / INPUT4)

Adjustable range 0 - 31
Default 15
+ direction Changes skin tone closer to magenta.
– direction Changes skin tone closer to green.

[COLORS] (INPUT3 / INPUT4)

Adjustable range 0 - 31
Default 15
+ direction For more color intensity
– direction For less color intensity (Monochrome at “0”)

[SHARPNESS] (INPUT3 / INPUT4)

Adjustable range 0 - 31
Default 15
+ direction For more sharpness
– direction For less sharpness

[WHITE BALANCE] (INPUT3 / INPUT4)

Adjustable range COOL / • / STD / • / WARM
Default STD
COOL Color tone bluer than standard

• Color tone slightly bluer than standard
STD Color tone standard setting

• Color tone slightly redder than standard
WARM Color tone redder than standard

E

32

■ MODE SELECT 1

[480 LINES] (INPUT2)

Function Manually selects input resolution.
Adjustable range 852 / 848 / 640
Default 640

[768 LINES] (INPUT2)

Function Manually selects input resolution.
Adjustable range 1366 / 1360 / 1280 / 1024
Default 1024

[ENLARGE] (INPUT1/INPUT2)

Function Sets the image enlargement ratio to be enlarged.
Adjustable range OFF / 2 x 2 / 3 x 3
Default OFF

[ENLARGE POS] (INPUT1 / INPUT2)

Function Sets the part of the original image to be enlarged.
Adjustable range (2 x 2) 0 - 3
Adjustable range (3 x 3) 0 - 8
Default 0

[MULTI ZOOM] (INPUT1 / INPUT2)

Function Adjusts the enlarged screen.
IMAGE ZOOM Adjusts the scale of enlargement.
H-POS Adjusts the horizontal position.
V-POS Adjusts the vertical position.

ENGLISH

■ Enlarge

You can set up 4 or 9 monitors and integrate them into a single screen to display video. Each monitor
displays an enlargement of 1/4 or 1/9 of the original image.

How to use the “Enlarge” feature

• 4 screen monitor set-up • 9 screen monitor set-up

012

345

678

01

32

01

012
345
678

32

33

E

Settings and Adjustments (Continued)

■ MODE SELECT 2

[OFF TIMER]

Function Specifies the remaining time before turning off the power.
Adjustable range 0 - 23
Default 0

[OSD H-POSITION]

Function Adjusts the horizontal display position of menu screen.
How to adjust Use / to move menu screen.
Default Center

[OSD V-POSITION]

Function Adjusts the vertical display position of menu screen.
How to adjust Use / to move menu screen.
Default Center

[LANGUAGE]

Function Switches the OSD language.
Available languages
Default ENGLISH

[ID NO SET]

Function Assigns ID numbers to monitors connected in a daisy chain (see page 39), using

Adjustable range 0 - 255
Default 0
Note The numbers 1 to 255 are available for ID numbers. (If “0” is set, the system

Use / to increase or decrease values.

ENGLISH / DEUTSCH / FRANÇAIS / ITALIANO / ESPAÑOL

RS-232C cables.

regards this as the state where no ID number is set.) Although numbers up to 255
can be used for monitor IDs, the number of connectable monitors varies depending
on the length of RS-232C cables and the installation environment.

E

34

■ Switching the screen size (INPUT1 / INPUT2)

ENGLISH

WIDE ZOOM 1

Displays image so it fills the
entire screen.

NORMAL

Displays image so it fills the
screen vertically, while
maintaining the original
aspect ratio.

Displays edge portion of
the image which is normally
cut off.

Dot by Dot

Detects the resolution of
the signal and displays an
image with the same
number of pixels on the
screen. (See page 56.)

ZOOM 2

Use this size if ZOOM1
cuts off the subtitles.

■ Switching the screen size (INPUT3 / INPUT4)

The desired screen size can be selected to suit the input signal.

WIDE ZOOM 1

In this mode the image is
progressively stretched
toward each side of the
screen.

NORMAL

For 4:3 “Standard” pictures.
A side bar appears on each
side.

Displays edge portion of
the image which is normally
cut off.

Dot by Dot

Detects the resolution of
the signal and displays an
image with the same
number of pixels on the
screen.

ZOOM 2

Use this size if ZOOM1
cuts off the subtitles.

35

E

Settings and Adjustments (Continued)

• Using this monitor’s screen size switching function to compress or expand the screen for commercial or
public viewing in establishments like cafes or hotels may infringe on the rights of the creators, as
protected by Copyright Law, so please be careful.

• When set to “Enlarge” (i.e. with a “2 x 2” or “3 x 3” setting), the screen size is fixed in “WIDE” mode.

• When using the screen size selection function of this monitor, the appearance of the original video may
change if you select a screen size with a different aspect ratio than the original image (i.e. TV broadcast
or video input from external equipment). Please consider this point when selecting the screen size.

• When an ordinary non-wide image (4:3) is viewed with the whole screen using the screen size switching
function of this monitor, the edge of the image may be lost or appear distorted. If you wish to respect the
creator’s intentions, set the screen size to “NORMAL”.

• When playing commercial software, parts of the image (like subtitles) may be cropped. In this case
select the optimal screen size using “Wide Mode” and adjust the vertical position (see “Position” on
page 30). With some software, there may be noise or distortion at the edges or top of the screen. This is
due to the characteristics of the software, and is not a malfunction.

• Depending on the original image size (i.e. CinemaScope size), black bands may remain at the top and
bottom of the screen.

Screen display for adjustments (INPUT2)

Before making adjustments in the ADJUSTMENT menu (see page 30), display an image to brighten the
entire screen.
If you are using a Windows PC, use the adjustment pattern on the supplied CD-ROM.

Retrieving the adjustment pattern

This explanation assumes you are using Windows 2000/XP and your CD-ROM drive is the “D” drive.

1. Connect the monitor and computer.

2. Load the supplied CD-ROM into the computer’s CD-ROM drive.

3. Open the CD-ROM in [My Computer].

4. Double-click [Adj_uty.exe] to start the adjustment program.
The adjustment pattern will appear.

<Adjustment pattern>

5. When adjustment is finished, press the [ESC] on the computer’s keyboard to quit the adjustment
program.

• If the display mode on the computer you are using is 65,000 colors, the color levels in the color pattern
may appear differently or grayscale may appear to be colored. (This is due to the specifications of the
input signal and is not a malfunction.)

E

36

Set-up information (INPUT1 / INPUT2)

Depending on the type of computer or OS, you may need to install monitor set-up information on your
system. If so, follow the steps below to install monitor set-up information. (Depending on the type of
computer or OS, command names and methods may differ. Please follow the computer’s own operation
manual while reading this.)

Installing set-up information

For Windows 2000

This explanation is for installing and setting monitor set-up information on a Windows 2000 computer,
and it assumes your CD-ROM drive is the “D” drive.

1. Connect the monitor and computer.

2. Load the supplied CD-ROM into the computer’s CD-ROM drive.

3. Click the [Start] button. From [Settings], choose [Control Panel].

4. Double-click [Display].

5. Click [Settings], [Advanced], and [Monitor].

6. Click [Properties], [Driver], and [Update Driver].

7. When the [Upgrade Device Driver Wizard] appears, click [Next].

8. Select [Display a list of the known drivers for this device so that I can choose a specific driver]
and click [Next].

9. When [Models] is displayed, click [Have disk], confirm that [Copy manufacturer’s files from:] is
[D:], and click [OK].

10. Select the monitor from the list displayed and click [Next].

11. Click [Next], confirm that the monitor’s name appears on the screen, and click [Finish]. If [The
Digital Signature Not Found] appears, click [Yes].

12. Click [Close] to close [Display Properties].

13. Click [OK] to close the window.

14. Eject the CD-ROM from the CD-ROM drive.

ENGLISH

For Windows XP

This explanation is for installing and setting monitor set-up information on a Windows XP computer,
and it assumes your CD-ROM drive is the “D” drive.

1. Connect the monitor and computer.

2. Load the supplied CD-ROM into the computer’s CD-ROM drive.

3. Click the [Start] button. Choose [Control Panel].

4. Click [Appearance and Themes] and [Display].
When using Classic View, double-click [Display].

5. Click [Settings], [Advanced], and [Monitor].

6. Click [Properties], [Driver], and [Update Driver].
The [Hardware Update Wizard] appears.
When you are asked whether to search Windows Update for the device driver, select [No, not this
time] and click [Next].

7. Select [Install from a list or specific location] and click [Next].

8. Select [Don’t search. I will choose the driver to install.] and click [Next].

9. Click [Have Disk], confirm that [Copy manufacturer’s files from:] is [D:], and click [OK].

10. Select the monitor from the list displayed and click [Next].
If [has not passed Windows Logo testing...] appears, click [Continue Anyway].

11. Confirm that the monitor’s name appears on the screen and click [Finish].

12. Click [Close] to close [Screen Properties].

13. Click [OK] to close the window.

14. Eject the CD-ROM from the CD-ROM drive.

37

E

PC Operation

PC connection

1. One-to-one connection with a PC...... Basic operation

Connect with RS-232C straight cable between the PC COM port (RS-232C connector) and the RS­232C input terminal on the back of monitor.

▼ Rear view

RS-232C
input terminal

RS-232C

INPUT

To RS-232C
input terminal

RS-232C straight cable

▼ PC

To COM port

E

38

2. Daisy chain connection from a single PC...... Advanced operation

Connect with RS-232C straight cable between the PC COM port (RS-232C connector) and the RS­232C input terminal on the back of monitor.
Next, connect RS-232C straight cable to the first monitor’s RS-232C output terminal and to the
second monitor’s RS-232C input terminal. Connect in the same way to the third and subsequent
monitors. The number of connectable monitors varies depending on the length of the cable used and
the surrounding environment.

ENGLISH

▼ PC

RS-232C
output terminal

To COM port

▼ First monitor

RS-232C
OUTPUT

RS-232C
input terminal

RS-232C

INPUT

RS-232C
output terminal

RS-232C straight cable

▼ Second monitor

RS-232C
input terminal

RS-232C
OUTPUT

RS-232C

INPUT

Communication conditions

Set the RS-232C communication settings on the PC to match the monitor’s communication settings.

Baud rate 9,600 bps

Data length 8 bits

Parity bit None

Stop bit 1 bit

Flow control None

39

E

PC Operation (Continued)

Communication procedure

Basic operation

<Command format>

When a command is sent from the PC to the monitor, the monitor operates according to the received
command, and sends a response message to the PC.

Carriage return code

C1 C2 C3 C4 P1 P2 P3 P4

Command field

(4 prescribed

alphanumerical

characters)

Example: VOLM0030

POWR 1 (“ ” indicates a space.)
* Be sure to input 4 characters for the parameter. Pad with spaces if necessary.

✕ VOLM30

●● VOLM 30 (“ ” indicates a space. “ ” is the carriage return code (0DH, 0AH or 0DH).)

Parameter field

(4 character string

comprised of:

0-9, +, -, space, ?)

If a command has “R” listed for “DIRECTION” in the “RS-232C Command table” on page 52, the current
value can be returned by using “?” as the parameter.

Example: 1. If an ID number has not been set:

VOLM???? ← From PC to monitor (Current volume setting: ?)
30 ← From monitor to PC (Current volume setting: 30)

2. If an ID number has been assigned (For example, ID number = 001)
VOLM ? ← From PC to monitor (“ ” indicates a space.)
30 001 ← From monitor to PC (“ ” indicates a space.)

<Response code format>

■ When a command has been executed correctly

OK

Carriage return code

H

, 0AH)

(0D

This is returned when execution of the command
is finished.

■ When a command has not been executed correctly*

Carriage return code

H

, 0AH)

RRE

(0D

■ If execution of the command is taking some time

Carriage return code

IWTA

(0DH, 0AH)

■ If RS-232C is locked

Carriage return code (0DH, 0AH)

ECDKOL

E

40

* This is returned when there is no such com-

mand, or when the command cannot be used in
the current state of the monitor (i.e. video auto­adjustment with video display).

* If there is a bad connection between the PC

and monitor, or if communication has not been
established, nothing is returned (not even
ERR).

If a command takes some time to execute, WAIT
may be returned as the return value. Wait for a
moment, and OK or ERR will be returned. New
commands cannot be received during this time,
even if they are sent.

If RS-232C control has been locked with the
operation lock (see page 29), LOCKED is re­turned as the returned value.

Advanced operation

This section explains commands for daisy chain connection. The basic communication procedure is the
same as in the “Basic operation” section.

<ID numbers>

You can assign a unique ID number to each monitor (see page 34). This allows you to control a particular
monitor in a daisy chain of monitors.
Up to about 20 monitors can be connected, depending on the length of RS-232C cables and installation
environment.
You can assign ID numbers either from the menu screen (via remote control or the control buttons on the
monitor) or from the PC using RS-232C cable.

[Example]

PC ID number: 1 ID number: 2 ID number: 3 ID number: 4

ENGLISH

If monitors are connected as shown above, you can execute commands like “Set the volume of the
monitor with ID 4 to 20”.

When controlling monitors linked in a daisy chain by designating ID numbers, you should basically avoid
any duplication of ID numbers.
If the same ID number is assigned to multiple monitors, only the monitor closest to the PC can be con­trolled with that ID number.
If monitors are connected as shown below, only the monitor (1) can be accessed with ID number 2.
Monitor (2) cannot be controlled using that ID number.

[Example]

PC ID number: 1 ID number: 2 ID number: 2 ID number: 3

(1) (2)

ID numbers do not have to be assigned in ascending order starting from the PC. They can also be con­nected as shown below.

[Example]

PC ID number: 3 ID number: 2 ID number: 4 ID number: 1

41

E

PC Operation (Continued)

<Commands for ID control>

The command examples shown on this page assume the following connection and ID number set up.

PC ID number: 1 ID number: 2 ID number: 3 ID number: 4

IDST......A monitor receiving this command sets its own ID number in the parameter field.

Example: IDST0001

OK_001 ← The ID number of this monitor is set to 1.

Note

After linking monitors, you can automatically assign ID numbers by using the IDST command with
the Repeater control (see “Repeater control” on page 49).

[Example]

PC Set 1 Set 2 Set 3 Set 4

If you connect monitors as shown above, and use the command “IDST001+”, ID numbers will be set
automatically, as shown below.

[Example]

PC ID number: 1 ID number: 2 ID number: 3 ID number: 4

IDST001+ ← ID setting command with repeater control
WAIT
OK 001 ← ID = “OK” response from ID number=1
OK 002 ← ID = “OK” response from ID number=2
OK 003 ← ID = “OK” response from ID number=3
OK 004 ← ID = “OK” response from ID number=4 (End)

E

42

IDSL....... The parameter of this command sets the ID number indicating the monitor subject to the

next command.

Example:

IDSL0002 ← The next command is for the monitor with ID number=2.
WAIT ← Searching for monitor with ID number=2
OK_002 ← Found monitor with ID number=2
VOLM0030 ← Sets volume of monitor with ID number=2 to 30.
WAIT ← Processing
OK_002 ← OK response from monitor with ID number=2
VOLM0020 ← Sets volume to 20.
OK_001 ← The volume of the monitor with ID number=1

(the one directly connected to the PC) is set to 20.

The IDSL command is
effective only once, for the
immediately succeeding
command.

IDLK....... The parameter of this command sets the ID number indicating the monitor subject to all

subsequent commands.

Example:

IDLK0002 ← Following commands are for the monitor whose ID number is “2”.
WAIT ← Searching for monitor with ID number=2
OK_002 ← Found monitor with ID number=2
VOLM0030 ← Sets volume of monitor with ID number=2 to 30.
WAIT ← Processing
OK_002
VOLM0020 ← Sets volume of monitor with ID number=2 to 20.
WAIT

The IDLK command remains
effective until it is canceled, or
power is shut off.

OK_002
IDLK0000 ← Canceling ID number setting
WAIT ← Canceling IDLK
OK_002 ← Cancelation complete
VOLM0010
OK_001 ← The volume of the monitor with ID number=1

(the one directly connected to the PC) is set to 10.

ENGLISH

IDCK ...... Provides screen display of the ID number currently assigned to a monitor, and the ID num-

ber currently set for IDLK (if any).

Example:

(After executing IDLK0002)
IDCK0000 ← (Parameter has no meaning.)
ID:001 IDLK:002 ← Returned response. The ID number is also displayed on the monitor screen.
IDCK000+ ← Repeater control

(If a command is used with repeater control, ID designation using IDSL or

IDLK is canceled.)
WAIT
ID:001 IDLK:002
ID:002 IDLK:002
ID:003 IDLK:002
ID:004 IDLK:002

43

E

PC Operation (Continued)

<Repeater control>

This system has a function to allow setting of multiple monitors connected in a daisy chain using a
single command. This function is called repeater control.
The number of connectable monitors varies depending on the length of the cable used and the surround­ing environment.
You can use Repeater control function without assigning ID numbers.

[Example]

PC Set 1 Set 2 Set 3 Set 4

If monitors are connected as shown above, you can execute a command like “Set all monitors’ input
settings to INPUT1”.

<Repeater control command>

Repeater control is achieved by setting the FOURTH CHARACTER of the parameter to “+”.

Example:

VOLM030+ ← Sets volume of all monitors to 30.

In repeater control, responses are returned by all the connected monitors.*
If you want to determine that a value has been returned by a specific set, assign ID numbers to
each monitor in advance.
If no response is returned, this may be because the monitor has not received (or is still processing)
the command, so it is possible that new commands may not be executed even if they
are sent.
* If power is turned “OFF” using Repeater control, only the monitor closest to the PC returns a re-

sponse.

Example:

(When 4 monitors are connected, and assigned ID numbers 1 through 4)
VOLM030+
WAIT
OK_001
OK_002
OK_003
OK_004 ← If 4 monitors are connected in a chain, reliable operation can be ensured by sending

a new command only after a reply has been returned by 4th (last) monitor.

Repeater control can also be used for reading settings.

Example:

VOLM???+
WAIT
10 001
20 002
30 003
40 004

E

44

Volume settings for all monitors are returned.

• If repeater control is used during ID designation (IDSL, IDLK), the ID designation is canceled.

<Response format in Advanced operation >

■ Normal response

• Response when no ID number has been set

Carriage return code

OK

(0DH, 0AH)

• Response when an ID number has been set

A response is returned when execution of the
pertinent command is finished.

ENGLISH

Space (20H)

OKSPC 0 0 1

ID number of responding monitor

Carriage return code

(0D

H

, 0AH)

■ When a command has not been executed correctly*

• Response when no ID number has been set

Carriage return code

H

, 0AH)

RRE

(0D

• Response when an ID number has been set

Space (20H)

RRE SPC 0 0 1

ID number

* This is returned when there is no such command, or when the command cannot be used in the current state of

the monitor (i.e. video auto-adjustment with video display).

* If communication has not been established for reasons like a bad connection with the monitor, nothing is returned

(not even ERR).

* If no monitor has been assigned the designated ID number (e.g. if the command IDSL0002 is used, but no

monitor with ID=002 is found), no response is returned.

Carriage return code

(0D

H

, 0AH)

45

E

PC Operation (Continued)

■ If execution of the command is taking some time

Carriage return code

IWTA

(0DH, 0AH)

If execution of a command takes some time,
WAIT may be returned as the returned value. In
this case, a value will be returned if you wait a
while. During this time, new commands will not
be received, even if they are sent.

No ID number is attached to WAIT response.

• Cases where WAIT is returned

- When repeater control is used

- When an IDSL or IDLK command is used

- When one of the following commands is used: RSET, INPS, ASNC, WIDE, EMAG, EPOS, PXSL,
POWR

■ When control via RS-232C is locked (to prevent use) using the operation lock function (see
page 34)

Carriage return code

(0D

ECDKOL

H, 0AH)

■ If a timeout occurs while waiting for a command

Carriage return code

UETOMTI

(0DH, 0AH)

■ If a timeout occurs while waiting for a command (when the monitor waiting for the command
is assigned an ID number = 001 in the following example)

Space (20H)

UETOMTI

SPC 0 0 1

Carriage return code

H

, 0AH)

(0D

■ If the current parameter is read out using “?” for the parameter (for numerical values etc.)

• Response when no ID number has been set

Example:

VOLM????
10

• Response when an ID number has been set (In the example below: ID=001)

Example:

VOLM????
10_001

<Communication interval>

• If the next command is sent in the interval before OK or ERR is returned, it will basically be ignored.

(Exception: Forced end using ASNC command)

• Leave an interval of 100 ms between command response and transmission of the next command.

VOLM0020
OK

VLMP0031
OK

E

46

Leave an interval of 100 ms

RS-232C command table

<How to read the command table>

Command: Command field (See page 40.)
Direction: W When the “Parameter” is set in the parameter field (see page 40), the

command functions as described under “Control/Response Contents”.

R The returned value indicated under “Reply” can be obtained by setting

“????”, “___?” or “???+” (repeater control) in the parameter field (see page

40).
Parameter: Parameter field (See page 40.)
Reply: Response (Returned value)

*A circle indicates commands which can be used in power standby mode.

Power control/Input selection, etc.

*can be used in standby mode

Control item Command Direction Parameter Reply Control/Response contents

ENGLISH

*

Power Setting

Input Selection

POWR

INPS

W

R

W

R

0
1

0
1
2
3
4

Switches to standby.
Returns from standby.
Standby mode

0

Normal mode

1

Waiting mode

2

Toggle change
INPUT1 : DVI
INPUT2 : RGB
INPUT3 : Component
INPUT4 : S-Video/Video
INPUT1 : DVI

1

INPUT2 : RGB

2

INPUT3 : Component

3

INPUT4 : S-Video/Video

4

Ye s

Ye s

47

E

PC Operation (Continued)

Picture Adjustment (INPUT1)

Control item Command Direction Parameter Reply Control/Response contents

THRU
COOL

•
STD

WHITE
BALANCE

RESOLUTION CHECK

ENLARGE

WIDE MODE

•
WARM
USER
R-CONTRAST
G-CONTRAST
B-CONTRAST

ENLARGE
SETTING

POSITION
(2 x 2)

POSITION
(3 x 3)

CTMP

CRTR
CRTG
CRTB
PXCK

EMAG

EPOS

EPOS

WIDE

WR
WR
WR
WR
WR
WR
WR
WR
WR
WR

R

WR

WR

WR

WR

0
1
2
3
4
5

6
0-max value
0-max value
0-max value

0

1

2

0

1

2

3

0

1

2

3

4

5

6

7

8

1

2

3

4

5

0
1
2
3
4
5

6
0-max value
0-max value
0-max value

—

0

1

2

0

1

2

3

0

1

2

3

4

5

6

7

8

1

2

3

4

5

*can be used in standby mode

Returns current resolution in the form of xxx, xxx.
ENLARGE OFF
2 x 2
3 x 3
SETTING: 2 x 2) UPPER LEFT
SETTING: 2 x 2) UPPER RIGHT
SETTING: 2 x 2) LOWER LEFT
SETTING: 2 x 2) LOWER RIGHT
SETTING: 3 x 3) UPPER LEFT
SETTING: 3 x 3) UPPER MIDDLE
SETTING: 3 x 3) UPPER RIGHT
SETTING: 3 x 3) MIDDLE LEFT
SETTING: 3 x 3) CENTER
SETTING: 3 x 3) UPPER RIGHT
SETTING: 3 x 3) LOWER LEFT
SETTING: 3 x 3) UPPER MIDDLE
SETTING: 3 x 3) LOWER RIGHT
WIDE
NORMAL
Dot by Dot
ZOOM1
ZOOM2

*

Ye s

No

No

Ye s

E

48

Picture Adjustment (INPUT2)

ENGLISH

*can be used in standby mode

Control item Reply

Auto Sync.

Sync.
Adjustment

Auto Gain

adjustment

WHITE
BALANCE

RESOLUTION CHECK

768 LINES

480 LINES

ENLARGE

WIDE MODE

AUTO ADJUSTMENT
Clock
Phase
H-Position
V-Position
AUTO ADJUSTMENT
Black level
Contrast
COOL

•
STD

•
WARM
USER
R-CONTRAST
G-CONTRAST
B-CONTRAST

DOTS
SETTING

DOTS
SETTING

ENLARGE
SETTING

POSITION
(2 x 2)

POSITION
(3 x 3)

Command Direction Parameter

ASNC
CLCK
PHSE

HPOS

VPOS

AGIN

BLVL

CONT

CTMP

CRTR

CRTG

CRTB
PXCK

PXSL

PXSL

EMAG

EPOS

EPOS

WIDE

W
WR
WR
WR
WR

W
WR
WR
WR
WR
WR
WR
WR
WR
WR
WR
WR

R

WR

WR

WR

WR

WR

WR

1
0-max value
0-max value
0-max value
0-max value

1
0-max value
0-max value

1

2

3

4

5

6
0-max value
0-max value
0-max value

0

1

2

3

4

5

6

0

1

2

0

1

2

3

0

1

2

3

4

5

6

7

8

1

2

3

4

5

0-max value
0-max value
0-max value
0-max value

0-max value
0-max value

1
2
3
4
5

6
0-max value
0-max value
0-max value

—

0

1

2

3

4

5

6

0

1

2

0

1

2

3

0

1

2

3

4

5

6

7

8

1

2

3

4

5

Control/Response contents

Returns Error in case of DVI or Video input mode.

Returns Error in case of DVI or Video input mode.

Returns current resolution in the form of xxx, xxx.
V=768 / 1366 x 768
V=768 / 1360 x 768
V=768 / 1280 x 768
V=768 / 1024 x 768
V=480 / 852 x 480
V=480 / 848 x 480
V=480 / 640 x 480
ENLARGE OFF
2 x 2
3 x 3
SETTING: 2 x 2) UPPER LEFT
SETTING: 2 x 2) UPPER RIGHT
SETTING: 2 x 2) LOWER LEFT
SETTING: 2 x 2) LOWER RIGHT
SETTING: 3 x 3) UPPER LEFT
SETTING: 3 x 3) UPPER MIDDLE
SETTING: 3 x 3) UPPER RIGHT
SETTING: 3 x 3) MIDDLE LEFT
SETTING: 3 x 3) CENTER
SETTING: 3 x 3) UPPER RIGHT
SETTING: 3 x 3) LOWER LEFT
SETTING: 3 x 3) UPPER MIDDLE
SETTING: 3 x 3) LOWER RIGHT
WIDE
NORMAL
Dot by Dot
ZOOM1
ZOOM2

*

No

No

No

Ye s

Ye s

No

No

Ye s

49

E

PC Operation (Continued)

Picture Adjustment (INPUT3/INPUT4)

Control item Command Direction Parameter Reply Control/Response contents

WR
WR
WR
WR
WR
WR
WR
WR
WR
WR

WR

0-max value
0-max value
0-max value
0-max value
0-max value

1
2
3
4
5
1
2
3
4
5

0-max value
0-max value
0-max value
0-max value
0-max value

1

2

3

4

5

1

2

3

4

5

WHITE
BALANCE

WIDE MODE

CONTRAST
BLACK LEVEL
COLOR
TINT
SHARPNESS
COOL

•
STD

•
WARM

CONT

BLVL

COLR

TINT

SHRP

CTMP

WIDE

WIDE
ZOOM1
ZOOM2
NORMAL
Dot by Dot

*can be used in standby mode

*

Ye s

Ye s

E

50

Special Control

ENGLISH

*can be used in standby mode

Control item

OFF TIMER

ID NO.
SETTING

ID NO.
SETTING
(ONCE)

ID NUMBER

Information

Display mode

Brightness
Volume

Mute

ALL RESET

ADJUSTMENT

OSD DISPLAY

LED OFF

CAUSE OF LAST STANBY

Status check

ID NO.
SETTING
(SUBSEQUENT)

ID CHECK

MODEL
SERIAL NO.

Temperature

Fan

Command Direction Parameter

0

1-23

0-255

1-255

0

1-255

0

0

0
1

2
0-max value
0-max value

0

1

0

0

1

0

1

0

1

0

OFTM

IDST

IDSL

IDLK

IDCK

INF1

SRNO

BMOD

VLMP
VOLM

MUTE

RSET

ALCK

LOSD

OFLD

STCA

ERRT

ERRF

W

R

W

R

W

W

W

R
R

WR

WR
WR

WR

W

WR

WR

WR

W

R

R

R

Reply

0

1-23

0-255

Value
Value

0
1

2
0-max value
0-max value

0

1

0

1

0

1

0

1

0

1

2

3

4

5

6

Value

0

1

Control/Response contents

TIMER OFF
OFF TIMER
TIMER OFF
Remaining time
Sets the monitor’s ID number.
Returns the monitor’s ID number.

Sets a monitor ID number. This ID number is only
effective for the command immediately after this
command.

Clears the ID number if one has been designated.
Sets a monitor ID number. This ID number is

effective for the next and all subsequent commands
after this command.

Clears the ID number if one has been designated.
Displays selected ID number and the monitor’s own

ID number on the screen.

STANDARD
OFFICE MODE
VIVID MODE
BRIGHTNESS

OFF
ON
ALL RESET
OSD DISPLAY ON
OSD DISPLAY OFF
ADJUSTMENT UNLOCKED
ADJUSTMENT LOCKED
LED ON
LED OFF
Initialization
No detectable error has occurred
Standby by remote control
Standby by power switch
Standby by RS-232C
Waiting by No Signal/Out of Timing (Incl: VESA DPMS/DMPM)
Standby by FAN error
Standby by abnormal temperature
Temperature
No error
FAN error

*

No

Ye s

Ye s

Ye s

Ye s

Ye s

Ye s

Ye s
Ye s

No

No

Ye s

Ye s

Ye s

Ye s

No

51

E

Troubleshooting

Problem Check item Page

There is no picture
or sound.

There is no picture.

Remote control does not work.

Sound from left and
right speakers is
reversed.
Sound is heard from
only one side.

There is a picture
but no sound.

Faint color or bad hue.

• Is the AC cord disconnected?

• Is the main power switch turned off or is the
monitor in standby mode?

• Make sure external equipment is connected
properly.

• Make sure correct INPUT is selected.

• Make sure the connected external equipment is
operating (playing back).

• The signal may be incompatible.

• Is the monitor in waiting mode?

• Are the batteries inserted with polarity ( , )
aligned?

• Are the batteries worn out?

•Point the remote control unit toward the monitor’s
remote control sensor.

• Is the menu display locked?

• Are audio cables connected properly?

• Make sure audio cables for external speakers are
connected properly: left and right cables may be
reversed or one of the two cables may not be
connected.

• Make sure the volume is not set to minimum.

• Video, S-video, component and RGB terminals
are for video only. Make sure audio cables are
also connected.

• Is the audio corresponding to the selected image
being input?

• Check “Color” and “Tint” adjustments.

• Make sure the connection sequence is correct.

19
24

13 to 17

25

–

–

24

12

29

13 to 17

18

25

13 to 17

13 to 17

31 to 32
13 to 17

Picture disappears.

Before calling for repair services, make sure following checks for possible remedies to the encountered
symptoms.

E

52

■ Warning when temperature rises

Nature of warning:

• The power LED lights up red and the monitor enters standby mode.

Solution:

• If the monitor enters standby mode due to a rise in temperature, you can turn off the main power
switch and turn it back on again. However the monitor will enter standby mode again if the cause of
the temperature rise is not eliminated.

• Check whether the monitor is placed at a location where a quick rise in temperature is likely. Internal
temperature rises quickly if the vents on the back are blocked.

• Internal temperature rises quickly if dust accumulates inside the monitor or around the vents.
Remove dust if possible. Ask your dealer about removing internal dust.

• If the power LED blinks red, there might be a problem with the fan.

Cracking sound

ENGLISH

The monitor sometimes makes a cracking sound.

•You may hear cracking sound from the monitor. This happens
when the cabinet slightly expands and contracts according to
change in temperature. This does not affect the monitor’s
performance.

53

E

Specifications

■ Product Specifications

Model PN-455
LCD element 45" wide (113.1 cm diagonal) ASV low-reflection black TFT LCD
Max. resolution (pixels) 1920 x 1080
Max. colors 16.77 M colors (8 bits/color)
Viewing angle 170° right/left/up/down (contrast ratio ≥10)

7

Screen active area inch (mm) 38­Computer input signal Digital DVI 1.0 standard-compliant, analog RGB (0.7Vp-p) [75Ω]

Sync signal Horizontal/vertical separate (TTL: positive/negative), Sync-on-green,

Video signal system NTSC (3.58MHz)
Plug and play VESA DDC2B
Power management VESA DPMS, DVI DMPM
Input terminals Computer signal Digital DVI-D 24 pin

Output terminals Computer signal Analog

Power requirement AC120 V, 60 Hz
Operating temperature 0°C to 40°C
Operating humidity 20% to 80% (no condensation)
Power consumption 312 W, 18 W in waiting mode, 2.9 W in standby mode
Dimensions inch (mm) Approx. 42­Weight lbs. (kg) Approx. 59.5 (27)

*1 S-video input will have priority over composite video when connected.
*2 Through output for the analog computer input signal. Does not support plug and play.

/8 x 21-7/8 (985.9 X 554.6)

Composite sync (TTL: positive/negative)

Analog Mini D-sub 15 pin, 3 rows
Computer audio 3.5 mm mini stereo jack
Serial RS-232C
Composite video BNC
S-video 1 line
Component BNC (Y, Pb/Cb, Pr/Cr)
Audio RCA pin (L/R)

Serial RS-232C
Audio RCA pin (L/R)
Speaker 10 W + 10 W [6Ω]

7

/8 x 3-3/4 x 25-3/8 (1,089 x 96 x 645) (excluding protrusions)

*1

*1

*2

Mini D-sub 15 pin, 3 rows

• As a part of our policy of continuous improvement, SHARP reserves the right to make design and
specification changes for product improvement without prior notice.
The performance specification figures indicates are normal values of production units: There may be
some deviation from these values in individual units.

E

54

■ Power management

This monitor conforms to VESA DPMS and DVI DMPM. Both your video card and computer must support
the same standard in order for the monitor’s power management function to work.
DPMS: Display Power Management Signaling

Power

consumption

312 W

18 W

Ye s

No

Ye s

No

Ye s
Ye s

No
No

ON STATE
STANDBY

SUSPEND

OFF STATE

ScreenDPMS Hsync Vsync

Display

No

display

DMPM: Digital Monitor Power Management

ENGLISH

DMPM

Monitor ON

Active OFF

Screen

Display

No display

Power

consumption

312 W

18 W

■ DDC (plug and play)

The monitor supports the VESA DDC (Display Data Channel) standard.
DDC is a signal standard for plug and play between monitors and computers. Information about resolu­tion and other parameters is exchanged between the two. This function can be used if the computer
supports DDC and it has been configured to detect plug-and-play monitors.
There are several types of DDC, depending on the communication method used. This monitor supports
DDC2B.

55

E

PC Digital/Analog Signal Input Compatibility Chart

• Video Analog RGB (0.7 Vp-p) [75 Ω]
Conforms to DVI (digital visual interface) standard 1.0

• Sync H/V separate (TTL: Positive/negative), Sync-on-green,
Composite sync (TTL: Positive/negative)

• Supported frequencies See the Screen resluton chart shown below.

■ Screen resolution chart

Screen resolution Hsync Vsync Dot frequency Analog signal Digital signal

VESA

• IBM AT compatible

Wide

US TEXT

640 x 480

800 x 600

1024 x 768

1280 x 1024

848 x 480

852 x 480
1280 x 720
1280 x 768

1360 x 768
1366 x 768

1920 x 1080

720 x 400

31.5 kHz

37.9 kHz

37.5 kHz

35.1 kHz

37.9 kHz

48.1 kHz

46.9 kHz

48.4 kHz

56.5 kHz

60.0 kHz

63.3 kHz

31.1 kHz

31.7 kHz

44.7 kHz

47.986 kHz

60.15 kHz

47.7 kHz

48.3 kHz

67.5 kHz

31.5 kHz

60.0 Hz

72.0 Hz

75.0 Hz

56.0 Hz

60.0 Hz

72.0 Hz

75.0 Hz

60.0 Hz

70.0 Hz

75.0 Hz

60.0 Hz

60.0 Hz

60.0 Hz

60.0 Hz

60.0 Hz

75.0 Hz

60.0 Hz

60.0 Hz

60.0 Hz

70.0 Hz

25.175 MHz

31.5 MHz

31.5 MHz

36.0 MHz

40.0 MHz

50.0 MHz

49.5 MHz

65.0 MHz

75.0 MHz

78.75 MHz

108.2 MHz

33.3 MHz

35.0 MHz

74.4 MHz

81.0 MHz

102.977 MHz

84.7 MHz

81.9 MHz

148.5 MHz

28.3 MHz

* All are compliant only with non-interlaced.
* If the monitor is receiving timing signals that are not compatible, [OUT OF TIMING] will appear. In this case,

please change the setting so that the timing signals will be compatible with the monitor, according to your PC
manual.

* If the monitor is not receiving any signal (sync signal), [NO SIGNAL] will appear.

E

56

Connector Compatibility Charts

■ PC digital RGB input terminal pins

(DVI-D 24 pin)

No.

TMDS data 2–

1

TMDS data 2+

2
3

TMDS data 2/4 shield

4

N.C.

5

N.C.

6

DDC clock

7

DDC data

8

N.C.

9

TMDS data 1–

10

TMDS data 1+

11

TMDS data 1/3 shield

12

N.C.

13

N.C.

14

+5 V

15

GND

Function

No.

16
17
18
19
20
21
22
23
24
C1
C2
C3
C4
C5

Function

Hot-plug detection
TMDS data 0–
TMDS data 0+
TMDS data 0/5 shield
N.C.
N.C.
TMDS clock shield
TMDS clock +
TMDS clock –
N.C.
N.C.
N.C.
N.C.
GND

■ PC analog RGB input terminal pins

(Mini D-sub 15 pin)

No.

1
2
3
4
5
6
7
8

Function

Red video signal input
Green video signal input
Blue video signal input
N.C.
GND
GND for red video signal
GND for green video signal
GND for blue video signal

No.

9
10
11
12
13
14
15

Function

+5 V
GND
N.C.
DDC data
Hsync signal input
Vsync signal input
DDC clock

ENGLISH

■ RS-232C input terminal pins

(D-sub 9 pin)

No.

1
2
3
4
5

Function

N.C.
Tr ansmitted data
Received data
Data terminal ready
GND

No.

6

Data set ready

7

Request to send

8

Clear to send

9

N.C.

■ RS-232C output terminal pins

(D-sub 9 pin)

Function

■ PC analog RGB output terminal pins

(Mini D-sub 15 pin)

No.

1
2
3
4
5
6
7
8

Function

Red video signal input
Green video signal input
Blue video signal input
N.C.
GND
GND for red video signal
GND for green video signal
GND for blue video signal

No.

9
10
11
12
13
14
15

Function

+5 V
GND
N.C.
N.C.
Hsync signal output
Vsync signal output
N.C.

No.

Carrier detect

1

Received data

2

Tr ansmitted data

3

Data terminal ready

4
5

GND

Function

No.

6
7
8
9

Function

Data set ready
Request to send
Clear to send
Ring indicator (open)

57

E

Dimensional Drawings

42-7/8 [1089]

[7]

[96]

4

/

3

3-

4

/

1

Opening width (39 [991])

30-3/4 [780]

Unit: inch [mm]

[645]

8

/

1

3

25-

[614]

8

/

24-

15-3/4 [400]

[557])

8

/

7

(21-

Opening height

[119]

8

/

5

4-

[200]

7

/

8

7-

E

58

Menu Option Reference Chart

■ INPUT1

ENGLISH

WHITE BALANCE

MODE SELECT1

MODE SELECT 2

THRU
COOL

•
STD

•
WARM
USER

ENLARGE
ENLARGE POS
MULTI ZOOM

OFF TIMER
OSD H-POSITION
OSD V-POSITION
LANGUAGE
ID NO SET

R-CONTRAST
G-CONTRAST
B-CONTRAST

OFF, 2 x 2, 3 x 3
2 x 2: 0 to 3, 3 x 3: 0 to 8

IMAGE ZOOM
H-POS
V-POS

0 to 23

0 to 255

0 to 255
0 to 255
0 to 255

■ INPUT2

ADJUSTMENT

GAIN CONTROL

WHITE BALANCE

MODE SELECT1

MANUAL
AUTO

MANUAL
AUTO

COOL

•
STD

•
WARM
USER

480 LINES
768 LINES
ENLARGE
ENLARGE POS
MULTI ZOOM

CLOCK
PHASE
H-POS
V-POS

BLACK LEVEL
CONTRAST

R-CONTRAST
G-CONTRAST
B-CONTRAST

852, 848 , 640
1366, 1360, 1280, 1024
OFF, 2 x 2, 3 x 3
2 x 2: 0 to 3, 3 x 3: 0 to 8

IMAGE ZOOM
H-POS
V-POS

0 to 255
0 to 255
0 to 255
0 to 255

0 to 31
0 to 31

0 to 255
0 to 255
0 to 255

59

E

Menu Option Reference Chart (Continued)

MODE SELECT 2

■ INPUT3/4

WHITE BALANCE

MODE SELECT 2

OFF TIMER
OSD H-POSITION
OSD V-POSITION
LANGUAGE
ID NO SET

CONTRAST
BLACK LEVEL
TINT
COLORS
SHARPNESS
WHITE BALANCE

OFF TIMER
OSD H-POSITION
OSD V-POSITION
LANGUAGE
ID NO SET

0 to 23

0 to 255

0 to 31
0 to 31
0 to 31
0 to 31
0 to 31
COOL, •, STD, •, WARM

0 to 23

0 to 255

E

60
