Sharp PC-A290 User Manual

Notice for Users in the USA

FCC Statement

WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reason able protection ag ainst h arm fu l interferen ce in a residential installation. This equipm ent g enerates, u ses an d can radiate radio frequ ency energy and, if not ins talled and u sed in accordan ce w ith th e instru ctions, m ay cau se harmful interferen ce to radio com m un ications. However, there is no guaran tee that interference will not occur in a particular installation . If this equipm ent does cause harmful interf erence to radio or televis ion reception , w hich can be determ in ed by turnin g the equipment off and on , the us er is encou raged to try to correct the in terferen ce by one or more of the follow ing m easures : Reorient or relocate the receiving antenna. Increase the distance between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

A shielded I/F cable and included cables with ferrite cores are required to insure compliance with FCC regulation for Class B computing equipment.

*As an

Declaration of Conformity

SHARP PERSONAL COMPUTER, PC-A200 Series This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:(1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Responsible Party: SHARP ELECTRONICS CORPORATION

NERGY STAR® Partner, SHARP has determined that this product meets

NERGY STAR® guidelines for energy efficiency.

the

Sharp Plaza, Mahwah, New Jersey 07430-2135 TEL: 1-800-BE-SHARP

About the Modem

This equipment complies with Part 68 of FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.

The modem jack of this equipment complies with Sub-part F of Part 68 of FCC rules.

The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs contact the telephone company to determine the maximum REN for the calling areas.

If the terminal equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it necessary.

The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service.

If trouble is experienced with this equipment, please contact Sharp Electronics Corp. for repair and (or) warranty information (Refer to the end of this section). If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved.

The equipment cannot be used on public coin service provided by the telephone company. Connection to Party Line Service is subject to state tariffs. (Contact the state public utility commission, public service commission or corporation commission for information.)

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.) To program this information, refer to the manual of the communication software.

CAUTION: DISCONNECT TELEPHONE LINES BEFORE ACCESSING THE MODEM CARD.

It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.

Product Information and Customer Assistance

For Product Information and Customer Assistance:

Call: 1-800-BE-SHARP (237-4277) Sharp Electronics Corp.

Sharp Plaza, Mahwah, NJ 07430-2135 Home Page: http://www.sharp-usa.com E-mail address: pcsupport@sharpsec.com CompuServe: Go Sharp

iii

Notice for Users in Canada

About Modem

The Industry Canada label identifies certified equipment. This certification means that the equipment meet certain telecommunications network protective, operational and safety requirements. The department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company's inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

CAUTION Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

“The Ringer Equivalence Number (REN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device. To prevent overloading, the termination on a loop may consist of any combination of devices subject only to the requirement that the total of Ringer Equivalence Number of all the devices does not exceed 5.”

CAUTION:

DISCONNECT TELEPHONE LINES BEFORE ACCESSING THE MODEM CARD.

ATTENTION:

DEBRANCHER LES LIGNES TELEPHONIQUES AVANT D’ENLEVER CE COUVRICLE

Product Information and Customer Assistance

For Product Information and Customer Assistance:

Call: 1-905-890-2100 (Toronto Area)

1-800-56-SHARP (Outside Toronto)

Sharp Electronics of Canada Ltd.

335 Britannia Road East, Mississauga, Ontario, L4Z 1W9 Canada

Notice for Users in Australia

Service Inquiries

Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1-800-807820 (free call) for referral to your nearest Sharp authorised Service Centre. Details can be found on the warranty card inserted with the documentation.

Copyright may exist in material you wish to record. Copying or broadcasting such material without permission of the relevant licensees or owners of the copyright is prohibited by law. SHARP is not in a position to authorise the copying or broadcasting of copyright materials and nothing in this OPERATION MANUAL should be implied as giving that authority.

Notice for Users in the UK

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code:

BLUE: Neutral BROWN: Live

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows. The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. This apparatus must be protected by a 3A fuse in the mains plug or distribution board.

Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.

vii

Notice for Users in Europe

About the Modem

Your Sharp PC-A200 series with integral modem has been designed to work with the analogue PSTN’s in the following countries:

United Kingdom Ireland Italy Germany Switzerland

If you wish to connect the equipment to the PSTN in a country not listed above, you should contact your equipment supplier for further details.

The modem is not designed for use on a shared service line or a line equipped with a call waiting facility. If you attempt to use the modem on a telephone line with call waiting, you may experience communication errors.

The equipment has been approved in accordance with Council Decision 98/482/EC(CTR21) for pan-European single terminal connection to the public switched telephone network(PSTN). However, due to differences between the individual PSTN’s provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operatio n on every PSTN ne twork termination poi nt .

In the event of problems, you should contact your equipment supplier in the first instance.

To maintain CTR21 network compatibility when used in the above listed countries the following settings should b e observed:

• Pulse dial may not be available in some countries.

• MODEM Name:WMPJX02.

• CE Marking :CE0197X.

viii

This equipment complies with the requirements of Directives 98/13/EC and

89/336/EEC, 73/23/EEC both amended by 93/68/EEC.

Dieses Gerät entspricht de n Anforderungen der EG-Richtlinien 98/13/EC und 89/336/EWG, 73/23/EWG mit Änderung 93/68/EWG.

Ce matériel répond aux exigences contenues dans les directives 98/13/EC et 89/336/CEE, 73/23/CEE modifiées par la directive 93/68/CEE.

Dit apparaat voldoet aan de eisen van de richtlijnen 98/13/EC en 89/336/EEG, 73/23/EEG, gewijzigd door 93/68/EEG.

Dette udstyr overholder kravene i direktiv nr. 98/13/EC og 89/336/EEC, 73/23/EEC med tillæg nr. 93/68/EEC.

Quest' apparecchio è conforme ai requisiti delle direttive 98/13/EC e 89/336/EEC, 73/23/EEC, come emendata dalla direttiva 93/68/EEC.

Η εγκατασταση αυτη ανταποκρινεται στιζ απαιτησειζ των οδηγιων τηζ Ευρωπαïκηζ Ενωσηζ κανονισµοι αυτοι συµπληρωθηκαν απó την οδηγια

98/13/EC

89/336/EOK, 73/23/EOK, ó

κατ

93/68/EOK.

πωζ οι

Este equipamento obedece às exigências das directivas 98/13/EC e 89/336/CEE, 73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.

Este aparato satisface las exigencias de las Directivas 98/13/EC y 89/336/CEE, 73/23/CEE, modificadas por medio de la 93/68/CEE.

Denna utrustning uppfyller kraven enligt riktlinjerna 98/13/EC och 89/336/EEC, 73/23/EEC så som komplette ras av 93/68/EEC.

Dette produktet oppfyller betingelsene i direktivene 98/13/EC og 89/336/EEC, 73/23/EEC i endringen 93/68/EEC.

Tämä laite täyttää direktiivien 98/13/EC ja 89/336/EEC, 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.

CAUTION:

TO PREVENT ELECTRICAL SHOCK, DISCONNECT THE AC CORD AND THE EXTERNAL BATTERY BEFORE SERVICING.

CAUTION:

FOR A COMPLETE ELECTRICAL DISCONNECTION, PULL OUT THE MAIN PLUG AND THE EXTERNAL BATTERY.

VORSICHT:

UM DIE STROMZUFUHR VOLLSTÄNDIG ZU UNTERBRECHEN, DEN NETZSTECKER HERAUSZIEHEN UND DIE EXTERNE BATTERIE ÈNTFERNEN.

ATTENTION:

POUR UN ARRET TOTAL DU SYSTEME, DECONNECTEZ LA PRISE DE COURANT SECTEUR ET LA BATTERIE EXTÉRIEUR.

VARNING:

FÖR TOTAL ELEKTRISK URKOPPLING, KOPPLA UR KONTAKTEN OCH TA UR BATTERIET.

PRECAUCION:

PARA UNA COMPLETA DESCONEXION ELECTRICA DESENCHUFE LA CLAVIJA DE LA RED Y LA BATERIA EXTERNO.

Safety Precautions

General

•

Follow all cautions and instructions which may be marked on the computer.

•

Except as described elsewhere in this manual, refer all servicing to qualified personnel. Immediately shut off the computer and seek servicing under the following conditions:

•

when the power cord or plug is damaged or frayed

•

if liquid has been spilled on the computer

•

if the computer has been dropped or the cabinet has been damaged

Location

•

Do not expose the computer to direct sunlight.

•

Try to avoid dusty environments.

•

Keep the computer away from any magnetic devices and TVs.

•

Keep the computer away from excessive humidity or fluids such as rain, snow, water spray, juice, coffee, steam, etc.

•

Do not move the computer from an extremely cold place to an extremely warm place. A temperature difference of more than 10°C (18°F) will cause condensation inside the unit, which may cause damage.

•

Do not block or cover slots or openings on the cabinet. These protect the computer from overheating.

•

Care should be exercised when using on heat sensitive surfaces or your lap as the base of this computer will get hot.

•

Do not smoke near your computer.

Usage

•

Never push any objects of any kind into cabinet openings. They may touch dangerous voltage points or short parts that could result in fire or electrical shock.

•

Turn off the computer before installing or removing a peripheral device(except when connecting USB devices and PC cards).

•

Check the AC power cord and power connectors periodically for damage. Replace the power cord immediately if damage is found.

•

Never subject your computer to sudden shocks or extreme vibration.

•

Do not drop the computer nor hit it with other equipment.

•

Do not scratch the surface of the LCD screen.

•

Turn off the computer and disconnect the AC power cord before cleaning.

Battery Pack Precautions

Handling

•

Never put the battery pack in a fire, as it could explode and cause injury.

•

Do not attempt to open or alter the battery pack.

•

Do not place the battery where it might get hotter than 60°C (140°F).

•

Do not allow metal objects such as jewelry to short across the battery terminals, as it could heat up and explode.

•

Do not allow liquids to come in contact with the battery pack.

•

Avoid dropping the pack or other violent shock.

•

Do not solder anything to the battery terminals.

Charging

•

Charge the battery pack only with the AC adapter included with your computer or an optional one.

Discharging

•

Do not use the battery pack for any purpose other than powering the computer.

Storage

•

Store the battery pack in a cool and dry place. Never allow the temperature to exceed 60°C (140°F) during storage.

•

Recharge the battery pack after storage, before use.

xii

Modem Precautions

•

Never install te lephone wiring during a l ightning storm.

•

Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

•

Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.

•

Use caution when installing or modifying telephone lines.

•

Avoid using the telephone during a lightning storm. There may be a remote risk of electric shock from lightning.

•

Do not use the telephone to report a gas leak while in the vicinity of the leak.

xiii

About This Manual

Notice

Information in this manual is subject to change without notice and does not represent a commitment on the part of SHARP Corporation.

SHARP Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

SHARP strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, SHARP assumes no responsibility for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other causes.

SHARP assumes no responsibility directly or indirectly, for financial losses or claims from third persons resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss of or alteration of stored data, etc.

Edition

1st Edition, January 2000.

© 2000 SHARP Corporation This document contains or refers t o proprietary information which is protected by copyright. All rights are reserved. Copying or other reproduction of this document is prohibited wit hout the prior written permission of SHARP Corporation.

Trademarks

Pentium is a registered trademark, and Celeron is a trade mark, of Intel Corporation. IBM and PS/2 are trademarks of Internati onal Business M achines Corpor ation. Microsoft, MS-DOS, Windows, and the Windows Logo are registered trademarks of Microsoft Corporation. Sound Blaster is a trademark of Creative Technology Ltd. All other brand and product names are trademarks or registered trademarks of their respective holders.

xiv

Recording Important Information

For future reference, please record the following information in the spaces provided below.

Model Number:

Serial Number:

Date of purchase:

Dealer’s Name:

Place of purchase:

Password:

The serial number is printed on a sticker located on the bottom of the computer.

Manual Conventions

This manual uses a set of st yle c onventions described below.

Notes and Cautions are italicized with icons:

A note icon informs you of a special technique or information that may help you perform a task or better understand a process.

A caution icon alerts you to something that may cause problems or damage to hardware, software or data.

Key Labels on the Keyboard, when referred to in the instructions, are shown in boldface:

Press Enter to continue.

When more than one key are pressed simultaneously, the key labels are separated by a plus (+) sign:

Restart your computer by pressing Ctrl+Alt+Delete.

When necessary, important key combinations are shown in graphics:

Sample Entries are shown in upper cases of different typeface. In the following case, press the Enter key after you type the command:

C:\>DIR A: Enter

Words/Texts on Screen, such as window titles or possible parameters, are italicized:

Double-click this icon to display the Power Properties window. Set the item to Enabled.

Screens reproduced in this manual may differ slightly from the screens you see on your computer.

Section Titles in other parts of this manual are italicized:

xvi

Table of Contents

Notice for Users in the USA.......................................................................................i

Notice for Users in Canada...................................................................................... iv

Notice for Users in Australia.................................................................................... vi

Notice for Users in the UK...................................................................................... vii

Notice for Users in Europe..................................................................................... viii

Safety Precautions.................................................................................................... xi

About This Manual................................................................................................. xiv

Recording Important Information.............................................................................xv

Manual Conventions...............................................................................................xvi

Table of Contents.................................................................................................. xvii

Overview of Computer........................................................................................... xix

Quick Setup

Turning Power On.................................................................................................. 1-1

Setting up Windows 98.......................................................................................... 1-3

Shutting Down the System.....................................................................................1-4

Basic Operations

Choosing Power Source ......................................................................................... 2-1

Resetting the System..............................................................................................2-3

Using Glide Pad.....................................................................................................2-4

Using Keyboard ..................................................................................................... 2-6

Using External Floppy Disk Drive Unit.................................................................2-7

Battery and Power Management

Standard Battery Pack............................................................................................ 3-1

Optional Batteries...................................................................................................3-5

Power Management................................................................................................3-8

Peripherals

Using Peripherals...................................................................................................4-1

PC Card.................................................................................................................. 4-3

Keyboard / Mouse..................................................................................................4-6

Display...................................................................................................................4-7

Audio System.........................................................................................................4-9

xvii

USB Device............................................................................................................4-9

Printer...................................................................................................................4-10

RS-232C Device...................................................................................................4-10

Communication Functions

Infrared Communication.........................................................................................5-1

Built-in Modem.......................................................................................................5-3

LAN Unit................................................................................................................5-5

Security Features

Passwords...............................................................................................................6-1

Preventing Infection of Computer Viruses..............................................................6-4

Security Slot............................................................................................................6-4

Setup Utility

Running the Setup Utility........................................................................................7-1

Main menu..............................................................................................................7-3

Advanced menu......................................................................................................7-4

Security menu.........................................................................................................7-5

Power menu............................................................................................................7-6

Exit menu................................................................................................................7-7

Appendixes

Maintenance and Care ...........................................................................................A-1

Specifications.........................................................................................................A-3

Troubleshooting

Troubleshooting..................................................................................................... T-1

Index

Index................................................................................................................Index-1

xviii

CHAPTER 1

Quick Setup

Your computer is designed and pre-configured for easy setup and use. This chapter describes the steps to get your comput er up and running as qui ckly as possible. Rea d this chapter first.

Turning Power On

Your computer is powered with either the rechargeable battery or AC power. See the next chapter for more information on power sources. Before using the computer for the first time:

1. Remove the battery protection sheet on the bottom of the computer.

If you do not remove the sheet, you cannot turn on the computer.

Battery Protection Sheet

2. Plug the AC adapter cable in the plug on the left side of the computer.

3. Plug the AC power cord into the AC adapter.

• Always use the AC adapter included with the computer or the optional

one(may not be available in some countries). Using other AC adapters may damage the computer.

• Always hold the AC power cord by its plug when removing it from the

wall outlet. Never pull on the cord.

• When using the computer for the first time, be sure to connect it to AC

power. If using the battery instead, you may not be able to complete the Windows 98 setup if the battery does not have enough power.

1-1

4. Plug the AC power cord into a wall outlet.

T o W all Outlet

5. Slide the display lock latch until the screen cover releases, and raise the cover.

6. Tilt the cover to a comfortable viewing position.

7. Press the power switch located just above the computer.

When you turn on the computer, the power indicator ( ) turns green, the computer goes through a self test to detect any problems, and Windows 98 starts. When using the computer for the first time, a dialog box called

Setup Wizard

page.

appears to gui de you through the Windows 98 setup. See the next

Esc

and F1 keys on the top of the

the Windows 98

1-2

Setting up Windows 98

The first steps in the setup process are as follows:

•

Entering your name

•

Registering your comput er

•

Accepting license agreement

•

Completing configur ation

To set up Windows 98, follow the instructions on the screen. See also the Windows 98 manual. It takes approximately 5-10 minutes to complete the entire setup process.

Do not turn off the computer until completing Windows 98 setup. If you turn off, you cannot set up Windows 98 later.

Properties Dialog Box in Windows

In the instructions in this manual, you will often see the expression “XXX Properties dialog box.” A dialog box is a window containing text boxes, check boxes, buttons, etc., with which you can send commands to Windows 98 or other application programs. To open the properties dialog boxes, click the

Control Panel

use often are:

•

Display

•

Modems

•

Mouse

•

PC Card

•

Power Management

•

System

and double-click the XXX icon. Some of the dialog boxes you will

Start

button, select

Settings

1-3

Shutting Down the System

To turn off the computer:

1. From the

2. Select

Or you can turn off the computer with the power switch. Before turning off the computer with the power switch, follow the steps below:

1. From the

2. Double-click

3. In

4. Select

5. Click OK.

Start

menu, select

Shut down

Start

Power Management Properties

Shutdown

If you have not saved a file, a dialog box will appear asking whether you want to save it.

• Do not turn off or reset the computer while the hard disk indicator, or

the indicator on the external floppy disk drive unit, or optional external CD-ROM drive are lit. Doing so may damage or even wipe ou t the data.

• To protect the screen, always close the screen cover while the computer

is off.

• Before turning it back on, wait at least 5 seconds after turning off the

computer. Turning the power off and on in rapid succession can damage the computer’s electrical circuitry.

and click OK. The computer turns off automatically.

menu, select

Power Management

When I press the power button on my computer

Shut Down

Settings – Control Panel

icon.

dialog box, select

Advanced

tab.

1-4

CHAPTER 2

Basic Operations

This chapter describes the basic operations of your computer.

Choosing Power Source

You can use the computer with one of the following power sources:

•

AC power from a wall outlet Use AC power whenever possible; rely on the battery only when AC power is not available.

•

Rechargeable battery There is an internal standard battery in the computer. You can use an optional external battery adding to the standard battery. See Chapter 3 for battery information.

About the Power Indicators

The following indicators show the power status of your computer.

Indicator Light Meaning

Battery Power On (green) Fully charged

On (orange) Being charged Blinking (ora nge) In abnormal state

On (red) Almost discharged

The warning beep sounds

Blinking(red) Almost completely discharged

Power On (green) Operating

Blinking (green) Off

Standby Hibernation

or powered off

2-1

For more information on

Using the AC Adapter

When connected to a wall outlet, the AC adapter provides power for operation and charges the battery. The AC input voltage can range from 100 to 240 volts so that you can use the computer with the appropriate plug adapter.

The AC power cord included with the computer is appropriate for the voltage used in the area in which you purchased your computer. If you attempt to connect the computer to a wall outlet other than in this area, check the voltage of the outlet and use an AC power cord appropriate for the outlet. Consult local service staff if you a re unsure.

Standby

and

Hibernation

, see Chapter 3.

2-2

Resetting the System

You may need to reset the system after adding hardware or software so that your computer will recognize the newly installed devices or software. When the message appears after the installation, click OK, You can also restart Windows 98 from the

Restart.

Warm Boot (Software Reset)

If the system is locked up because of a software problem, you can reset or reboot the system by pressing the keys again to restart the computer.

Resetting may cause data loss. Use the software reset only if the normal Windows 98 Shut Down does not work because of software malfunction. Although resetting will not damage the system, you may lose the data you are processing.

Ctrl+Alt+Del

Power Sw itch

You can turn off the computer with the power switch if you encounter hardware or software problems which lock up the system. In this case, press the switch for more than six seconds.

Yes

, etc. to restart Windows 98.

Start

menu. Select

keys simultaneously. Press the

Shut down

; then,

Ctrl+Alt+Del

Reset Switch

If you cannot turn off the computer by pressing the power switch, you can use the reset switch on the bottom of your computer. To reset the system, insert a narrow object into the small hole to slide the switch as shown.

Reset Switch

RESET

Reset Switch

Do not use metallic materials to slide the reset switch. It may cause malfunction.

RESET

Push

2-3

Using The Glide Pad

Your computer is equipped with an integrated pointing device called a glide pad. Using the glide pad, you can move the pointer, select an item from a menu, and perform other tasks in the same way you would with a mouse.

Do not hit or scratch the surface of the glide pad with pointed objects

Using the Glide Pad

Take a moment to become familiar with how the glide pad works.

•

(such as a ballpoint pen). Do not operate the glide pad with a moist finger. This may cause the

•

glide pad to operate incorrectly. You cannot use the glide pad when a mouse is connected

•

Place Your Fingertip

Place your left or right hand next to the glide pad, resting your wrist naturally in a relaxed manner. Place your thumb or finger on the glide pad.

Move Your Fingertip

The rectangul ar pad of the glide pad acts li ke a miniature duplicate of the displa y. As you slide your fingertip across the pad, the pointer on the screen moves in the same direction across the screen. The glide pad is very sensitive, so you do not have

2-4

to exert much pressure on the pad. The glide pad will respond to a light touch from your fingertip.

Click, Double-click, and Right-click

To click or double-click, you can use the left button just like that of a mouse. Instead of clicking the left button, you can also just tap gently anywhere on the rectangular pad. For right-clicking, you must use the right button.

Drag and Drop

You can move icons or windows by using “drag and drop” below:

1. Position the pointer over the object.

2. Press the left button; do not release it.

3. Holding down the button, move the pointer. The object moves together with the pointer.

4. Release the button when the object reaches its destination.

Scroll

You can scrol l through information in a list or in a d ocument by using the glide p ad. To view information vertically, place your finger on the most right part of the glide pad and slide your finger up and down. To view horizontally, place your finger on the bottom part of the glide pad and slide your finger left or right. This procedure works only in limited applications.

Changing the Configuration

Mouse Properties

In the pad, such as swapping left and right buttons, changing the pointer size, etc.

If you swap the left and right buttons, "tapping" on the glide pad as an

•

alternative method of pressing the left button will no longer function. If you prefer to use a mouse and turn off the glide pad, you can disable

•

the glide pad in the Setup Utility. See also Chapter 4.

dialog box, you can change the configuration of the glide

2-5

Using The Keyboard

Your computer, equipped with the Windows Enhanced Keyboard, provides all the functionality of a full-sized desktop keyboard.

Windows Logo Keys

System Function Keys

When pressed together with the Fn key, function keys set speci fic system parameters. This combination is sometimes referred to as “hot keys”.

Opens the Windows Start menu.

Opens an application-specific short-cut menu equivalent to rightclicking.

Switches the display output between the LCD screen and external monitor (if connected). See the Chapter 4 for details.

Decreases the LCD screen brightness.

Display

section in

2-6

Increases the LCD screen brightness.

Turns the screen backlight on and off.

Puts the computer in

Hibernation

Chapter 3.

, according to the setup selection). See also

System standby

(to

Standby

or to

Using External Floppy Disk Drive Unit

You can use double-density (2DD) 720KB or high-density (2HD) 1.44MB floppy disks with the external floppy disk drive unit.

The keyboard/mouse port, RS-232C serial port and parallel port are available on the rear side of the floppy disk drive unit. You can connect peripherals to the floppy disk drive unit. For more information about peripherals, refer to Chapter 4.

Connecting External Floppy Disk Drive Unit

Turn off the computer before connecting the external floppy disk drive unit; otherwise the floppy disk drive unit may not be recognized.

Do not place the floppy disk drive unit on its side or upside down.

•

Do not press on the floppy disk drive unit. It may damage the drive or

•

cause malfunction. Do not place the AC adapter on the floppy disk drive. It may cause the

•

drive to malfunction.

1. Turn off the computer.

2. Open the cover of the external floppy disk drive port on the right side of the computer.

3. Connect the connector of the floppy disk drive unit to the floppy disk drive port.

Removing External Floppy Disk Drive Unit

2-7

1. Remove the floppy disk from the floppy disk drive.

2. Turn off the computer.

3. Disconnect the floppy disk drive unit by simultaneously pressing the buttons on each side of the connector and pulling it out.

4. Close the cover of the floppy disk drive port on the computer.

Handling Floppy Disks

•

Do not open the shutter and touch the disk inside; otherwise, you will not be able to read or write data to the disk.

•

Do not place floppy disks near magnets or heat source, in direct sunlight or in a dusty place, etc.

•

Never subject a disk to sudden shocks or extreme vibration. Do not drop, bend, or place heavy objects on a disk.

•

Do not spill liquid onto a disk.

Inserting and Removing a Floppy Disk

Inserting

Hold the floppy disk with the arrow facing up and towards the drive. Slide the disk into the drive until it locks into place.

2-8

Removing

Always insert a floppy disk straight into the floppy disk drive.

•

When inserting the disk, make sure it is not upside down.

•

Do not use excessive force when inserting the floppy disk. If you have

•

difficulty inserting or removing disks, seek the a ssistance of an authorized service technician.

Before removing the floppy disk, make sure the indicator of the floppy disk drive unit is not lit.

Press the eject button firmly. The disk will pop out slightly. Remove it and store it properly.

Formatting a Floppy Disk

1. Make sure the floppy disk is not write-protected, and insert it into the floppy disk drive.

2. Double-click

3. Click

4. From the capacity drop-down list, select 1.44MB or 720KB.

5. Click

3 ½ Floppy [A:]

Start

When you format a floppy disk, all data previously stored on the disk is lost.

My Computer

to start formatting.

on the desktop.

. From the

File

menu, select

Format

Backing Up Data

We recommend that you regularly backup the data on your ha rd disk drive. Windows 98 has a backup function you can use to back up your d ata. See Windows 98 Help for details.

2-9

CHAPTER 3

Battery and Power Management

This chapter explains how to manage the computer’s power effectively and use the standard battery or an optional battery pack.

Standard Battery Pack

When not connected to an external power source, your computer operates with the rechargeable internal standard battery pack. The duration of the battery life may be longer if the computer’s Power Management is active. See the next section for power management.

To keep the battery life long:

•

Initialize the battery pack if the actual remaining power in your battery is less than what the battery indicator lights suggest as per the procedure on page 3 -3.

•

Turn off your computer when you are not using it.

The duration a battery charge will last will depend on the computer

•

usage. Applications which hea v ily use the peripherals will experience shorter power duration. When the battery is not charged, your computer may not operate

•

properly. Connect the AC power to charge the battery. If you see an error message during booting, press F2 to open the Setup

•

Utility. Following the instructions in Chapter 7, adjust the Setup Utility and restart the system. When using the computer for several hours with battery packs, enable

•

power management and set

Management

section in this chapter.

System standby

. Refer to the

Power

3-1

Checking the Battery Level

Battery Indicator

You can check the battery level in the

Control Panel

the

or double-clicking the battery or AC plug icon on the taskbar.

You can also check with the battery indicator on the front side of the computer.

Power Management Properties

dialog box in

Press the button on the right of the battery indicator to show the battery power remaining. Refer to the table below.

Battery Indicator Status

All on 76% -100% Three on 51% - 75% Two on 26% - 50% One on One blinking All off

Capacity Remaining

1% - 25%

Nearly 0%(Empty)

0%(Empty)

This battery indicator turns on automatically while the battery is being charged (when connected to AC power). When the battery is fully charged, the battery indicator turns off.

The battery power remaining is an approximate figure. The remaining operating time expected may be different fro m the actual remaining time, depending on the use of the computer. If the actual remaining power in your battery is less than what the battery indicator lights suggest, you should initialize the battery pack as per the procedure on page 3-3.

3-2

Low Battery Indication

When the battery power becomes significantly low, the battery power indicator turns red and the warning beep sounds. Then the indicator starts blinking and the computer will be shut down soon and the data may be lost. Save your data and turn off the computer, or connect the computer to AC power immediately. Otherwise, the computer will be shutdown If you set the battery alarm in Windows 98, the computer will be turned off or enter

Power Management

See

The remaining operating time dep ends on the power you are consuming. If you are using the audio system, PC card slot, hard disk, floppy disk or CD-ROM, your computer may consume more battery life.

See also the section on power management in this chapter.

System standby

section of this chapter.

in case of significantly low battery power.

Charging the Battery Pack

1. Connect the AC adapter to the computer. While the battery is being charged, the battery power indicator is orange and the battery indicator turns on.

2. When the battery is fully charged, the battery power indicator turns green and the battery indicator turns off. Charging time may vary according to the status of the computer.

(

)

When the battery is hot (for example, after long use), it may take longer to fully charge the battery.

Initializing the Standard Battery Pack

You need to initialize the battery pack when the actual remaining power in your battery is less than what the ba t tery indicator lights suggest.

1. Make sure the computer is turned off. Connect the computer to AC power and wait until the battery is fully charged. The battery power indicator turns green and the battery indicator turns off. It will take about 2 hours and 30 minutes if the battery was previously completed discharged.

2. Turn on the computer.

3-3

3. When the message the Setup Utility.

4. Disable the power management and set

Power

the

5. Press

6. When the message the Setup Utility. Leave the computer in the Setup Utility.

7. Disconnect the AC adapter, and leave the computer on until the battery is completely discharged and the system shuts down automatically. It will take about 3 hours.

8. Connect the computer to AC power and let the battery fully charge.

menu of the Setup Utility. See

Esc

Do not connect the computer to wall outlet while discharging the

•

battery. The initialization will be can celled. You can initialize the standard battery alone if the optional external

•

battery pack is disconnected. When the external battery pack is connected, both the standard and the external battery will be initialized together.

; then

Enter

Changing the Battery Pack

The capacity of a battery pack gradually decreases when used repeatedly (the deterioration rate depends on the operating temperature and environment). If the battery life becomes extremely short even after the initialization, you should change the standard battery pack. Bring your computer to a local dealer for replacement of the standard battery pack.

Press <F2> to enter Setup Utility

Critical Battery Suspend

Power menu

twice. The system restarts.

Press <F2> to enter Setup Utility

appears, press F2 to open

Disabled

in Chapter 7.

appears, press F2 to open

3-4

Never replace the standard battery pack yourself.

Optional Batteries

To power your computer for extended periods of time, there are two available optional batteries, the external battery pack(CE-BL03) or the flat panel battery(CEBP01). For more details about using the flat panel battery, refer to the operation manual provided with it.

Use only the appropriate optional battery (CE-BL03 or CE-BP01), and

•

attach it correctly. You cannot use the external battery pack(CE-BL03) and the flat panel

•

battery(CE-BP01) at the same time. Only one external battery may be connected at any given time.

Connecting External Battery Pack

1. Slide open the cover of the external battery port on the rear of the computer.

2. Connect the external battery pack by matching the projections on either side of the battery to the recessed parts of the computer. Make sure that the battery connector lines up with the external battery port of the computer. If you hear a clicking sound, the external battery pack should be correctly connected.

While the external battery pack is connected, do not carry the computer

•

by holding the battery pack only. Firmly hold both the computer and the external battery pack. You cannot connect an external monitor nor a LAN cable when the

•

external battery pack(CE-BL03) is connected.

3-5

Removing External Battery Pack

Before removing the external battery pack, turn off the computer or confirm that the standard battery pack has power remaining. If the standard battery pack has no power remaining, connect the computer to AC power; otherwise the computer will be shut down and data may be lost.

Remove the external battery pack by pressing the buttons on each end of the battery and sliding the battery off the computer.

Close the cover of the external battery port after the external battery pack is removed.

Checking the Battery Level

You can check the battery level of the external battery pack (in the same way as the standard battery pack) with the battery indicator. Press the button on the right of the indicator. The status of the indicator is the same as that of the standard battery. See page 3-2.

3-6

Charging External Battery Pack

You can charge the external battery pack by connecting AC power to the computer with the external battery connected. To charge most effectively, the standard and external battery pack will be charged as follows:

1. Charge standard battery pack to about 80%.

2. Charge external battery pack to about 80%.

3. Charge standard battery pack remaining 20%.

4. Charge external battery pack remaining 20%.

When the computer is turned off or in minutes to charge both the standard and external battery packs from completely discharged to full. When the computer is turned on, it will take about 7 hours and 30 minutes. (The charging time also depends on the power you ar e consuming.)

Hibernation

, it will take about 5 hours and 30

Initializing External Battery Pack

The procedure for initializing an external battery pack is the same as that of the standard battery. But, you cannot initialize the external battery pack only. If you begin the initializing process, both standard and external battery packs will be initialized.

3-7

Power Management

Power management saves electricity and extends battery life by controlling power supply to built-in devices. You can set the following power management properties in Windows 98.

•

Stopping power supply to the hard disk

•

Stopping power supply to the display

•

Using System standby

Note that the power management may not seem to function under the following conditions:

When you are using an application program that accesses the hard disk

•

periodically When Windows CD Auto Play is functioning

•

Stopping Power Supply to the Hard Disk

1. In the

2. Set

Turn off hard disks

Power Management Properties

to an appropriate value, and click OK.

dialog box, select

Power Schemes

Stopping Power Supply to the Display

This procedure is also effective for an attached external monitor complying with power management.

1. In the

2. Set

Turn off monitor

Power Management Properties

to an appropriate value, and click OK.

dialog box, select

Power Schemes

Using System Standby

System standby

computer has entered standby mode, you can restart your computer within much reduced time compared to when you turn on the computer again after shutting it

3-8

is a very useful power management tool. For example, after your

tab.

down normally. When your computer resumes from restores the exact last state of the computer. There are two types of

Standby

system enters under what conditions.

•

Standby

supply to all but a few essential components. Your system enters and resumes from indicator blinks green.

•

Hibernation

disk and turns off the computer. Your system enters and resumes from

Hibernation

indicator turns off.

You can select

Standby Mode

Selecting System Standby Mode

Hibernation

and

stores the current condition of the computer in RAM and stops power

Standby

per the conditions mentioned below. In

saves the current condition of the computer in an area of the hard

per the conditions mentioned below. In

Standby

below.

If your battery becomes completely discharged during

•

will lose unsaved data and will need to reboot your computer. Therefore, if you are planning to leave your computer powered by battery for long periods of time, we recommend

. In Windows 98, you can define which

Hibernation

in Windows 98. See

System standby

Standby

Hibernation

, the Power

Selecting System

Hibernation

, the system

System standby

, the Power

Standby

;

the

, you

1. From the

2. Double-click

3. In the

4. Check

if you want to support

5. Click

6. Click OK.

Entering System Standby

Start

menu, select

Power Management

Power Management Properties

Enable hibernate support

Standby

Apply

Finish communications, printing, and playing music or video before

•

entering Do not operate the keyboard, glide pad or mouse while the system is

•

entering When the system enters

•

display. This is not a malfunction. Save your data before your computer enters

•

the computer is stopped, the RAM contents will be lost.

System standby

Settings – Control Panel

icon.

dialog box, select

if you want to support

Hibernation

, you may see some flicker on the

Hibernate

Hibernation

Standby

tab.

. Uncheck

. If the power supply to

3-9

Your computer enters

System standby

in each of the following cases.

•

You select

•

The specified time in

Management Properties

In the above two, your computer enters selection in

•

The screen cover is closed

The above functions if you perform the followings:

1. In the

2. Select

3. Click

4. Click OK.

•

You press the power switch.

The above functions if you perform the followings:

1. In the

2. Select

computer:

3. Click

4. Click OK.

•

You press Fn +

The above functions if you perform the followings:

1. In the

2. Select

3. Click

4. Click OK.

Stand by

Selecting System Standby Mode

Power Management Properties

Hibernate

Apply

Power Management Properties

Hibernate

Apply

Power Management Properties

Hibernate

Apply

F12

Shut Down Windows

in the

System standby

dialog box has passed without any operation.

Standby

When I close the lid of my portable computer:

When I press the power button on my

When I press the sleep button on my computer:

Power Schemes

of this chapter.

dialog box, select

dialog box.

tab of

Hibernation

Power

depending o n your

Advanced

tab.

•

The battery level is low.

The above functions if you set the alarm in Windows 98. See section.

3-10

Battery Alarm

in this

Resuming from Standby

Do not operate the keyboard, glide pad or mouse while the system is

•

resuming from

Standby

Your computer resumes from

•

You press any key.

•

The screen cover is opened.

•

The built-in modem receives a call while a communication software is running (the built-in modem may not be available in some countries).

Resuming from Hibernation

Do not operate the keyboard, glide pad or mouse while the system is

•

resuming from If sufficient battery power does not remain, your computer will not resume

•

from

Hibernation

When the system resumes from

•

the display. This is not a malfunction.

Your computer resumes from

Standby

Hibernation

. To resume it, connect the computer to AC power.

Hibernation

in each of the following cases:

Hibernation

if you press the power switch.

, you may see some flicker on

Disabling Power Management

1. In the

2. Set

System standby, Turn off monitor

click OK.

Power Management Properties

dialog box, select

Turn off hard disks

and

Power Schemes

Never

tab.

, and

When you are using communication software or if sound or voice pauses or skips while played back, disable power management.

Battery Alarm

In Windows 98, the alarm will tell you when the battery drops to the specified level by sounding an alarm or displaying a message, and l et your computer go o n

standby

or be shut down automatically.

System

3-11

1. From the

2. Double-click

3. Select

4. Set the battery level at which the alarms are activated and the Alarm Action desired.

5. Click OK twice.

Start

menu, select

Power Management

Alarms

tab.

Settings – Control Panel

icon.

3-12

CHAPTER 4

Peripherals

This chapter describes how to use peripheral devices with your computer. You can connect a printer, external monitor, external keyboard, mouse, or other device to the parallel, RS-232C serial, USB or keyboard/mouse ports. To ensure proper use, be sure to read the instructions for each peripheral device before connecting it to your computer.

Using Peripherals

You can use the peripheral devices shown on the next page. For the details, refer to the section explaining each device, and contact your dealer.

• Be sure to turn off the computer and the peripheral device before

connecting them (except when connecting USB devices and PC cards).

• Some devices have to be turned on after the computer is turned on.

• Some devices require that you install drivers before use.

Connecting Peripheral Device

1. Turn off the computer and the peripheral device (except when connecting USB devices and PC cards).

2. Connect the peripheral device to the computer. If the connector has screws, tighten them.

3. Turn on the peripheral device; then, turn on the computer.

Peripheral Connection Overview

4-1

Computer

USB Device

PC Card

Audio Equipment

USB Device

Microphone

CRT Monitor

Floppy Disk Drive

4-2

Mouse/Keyboard

RS-232C Device

Printer

PC Card

Your computer is equipped with a PC card (PCMCIA) slot, which can accommodate one Type II card. Before inserting a PC card into your computer, refer to its manual.

When using a PC card which needs an IRQ, disable one of the following ports: Serial, IR, LPT, or LAN. Otherwise a PC card or the computer may malfunction.

Never disable the USB port. Disabling the USB port in the Setup Utility may cause some PC cards to malfunction.

Inserting PC Card

1. Raise the PC card eject button and push it in. The protection card pops out.

2. Remove the protection card from the PC card slot.

3. Insert the card into the slot with the label face up until it locks into place. (You

do not have to power down the computer to insert/remove PC cards when using Windows 98). The PC card eject button pops out. When the PC card is fully inserted, fold down the PC card eject button.

4-3

Ejecting PC Card

Raise the PC card eject button only when you need to push it. The eject button may get knocked off the computer if it is not pushed down. In this case, replace the button while the inserted PC card is held in.

When a new card is correctly inserted, the appropriate driver is automatically installed. If the driver is no t installed correctly, you will hear a warning beep. In this ca se, install the PC card driver by following the instructions on the screen.

• Some PC cards may become hot after long use

• Be sure to use the procedure below when ejecting a PC card.

Otherwise, the system may not work properly

1. In the

2. Click

3. When the message prompts you to eject the card, click OK.

4. Gently push in the PC card eject button. The PC card will be pushed out

5. Remove the card, and re-insert the protection card.

6. Fold down the eject button.

PC Card Properties

want to eject.

Stop

slightly.

dialog box, click on the icon of the PC card you

4-4

Connecting Optional External CD- ROM Drive

You can connect the optional external CD-ROM drive using the PC card slot.

Optional CD-ROM Drive

4-5

Keyboard / Mouse

You can use a full size desktop keyboard or external mouse with your computer. A keyboard/mouse port and a RS-232C serial port are available when the external floppy disk drive is connected.

The ways of connecting a PS/2 mouse and a serial mouse are slightly different.

Never connect or disconnect the devices to the keyboard/mouse port when the computer is powered on. This may cause the computer to operate improperly.

Using a PS/2 Mouse

You have only to connect the mouse to the keyboard/mouse port of the external floppy disk drive unit.

You cannot use the glide pad when a PS/2 mouse is connected.

Using a Serial Mouse

Connect the serial mouse to the RS-232C serial port of the external floppy disk drive unit. When starting the system, enter the Setup Utility and set the item

Auto

Enabled

and

Internal Pointing Device

Disabled

in the

Serial Port:

Advanced

menu.

4-6

You cannot use a mouse and the glide pad simultaneously

Display

You can use an external monitor with your computer. To display images on both displays simultaneously, use the 1024x768 resolution.

• Some monitors, which are not compatible with your computer, may not

display correctly.

• In this section, you often see the expression “

box.” To open the dialog box, double-click

Panel - Display

Displaying the Screen on an External Monitor

You can display the screen on an external monitor.

You cannot connect the optional external battery (CE-BL03) when an external monitor is connected.

Display Properties

My Computer - Control

dialog

1. In the

2. Select

3. Click

4. Select

5. Select

6. Select the manufacturer and the model, and click

7. Close the dialog box, following the instructions on the screen.

Display Properties

Monitor Next. Display a list of all the drivers in a specific loca tion, so you can select the

driver you want

Show all hardware

tab and click

; then, click

dialog box, select

Change….

Settings

; then,

Switching the Display

1. In the

2. Select

3. Select the display and click

4. Click OK.

Display Properties

Display Device

• Although you can switch the display with Fn+F5, use the above

procedure in normal use.

• While playing video or animation, you may not be able to switch the

display.

• While using multiple displays, you cannot switch the display.

dialog box, select

tab.

Apply

Settings

; then,

Advanced….

twice.

Advanced …

4-7

Changing Resolution and Number of Colors

When shipped, your computer is set to the default resolution and color. The default resolution is 1024 x 768 at 64k color. To change the resolution and the number of colors, perform the following:

1. In the

Display Properties

dialog box, select

2. Select the number of the colors in the

Screen area

. Refer to the table below.

3. Click OK twice.

Resolutions and Colors you can choose

Settings

Colors

, and select the resolution in

Resolution

640 x 480

800 x 600

1024 x 768 256

(1)

You cannot use screen expansion if you choose 16M colors

(2)

The number of colors in this mode is made using a Dithering algorithm(on the

(1)

Number of Colors

256 64K

(2)

16M 256 64K

(2)

16M

64K

(2)

16M

internal LCD only).

• You cannot switch to a displ ay res olution and num ber of color s t hat are not

available.

• In the Color Palette, High C olor ( 16 bit) means 65,536 (64K ) col ors, and

True Color (24 bit or 32 bit) means about 16,770,000 ( 16M) colors .

• Select 32 bit if you display video or animation in the True Color.

Otherwise the speed of displaying may be decreased.

• If you select True Color(24 bit) in the Color Palette,

* The drawing speed of screen is decreased. * You cannot use multiple monitors.

• Note that the above resolutions are ones t hat you can choose w hen you

connect a monitor with appropri ate re soluti on.

Using Multiple Displays

You can use multiple displays when an external display is connected. See Windows Help for more information.

4-8

Audio System

You can output sound to speakers or headphones using an ordinary audio cable.

Connecting audio equipment

1. Turn off the computer.

2. Use the following audio cable for the connection:

To output the computer’s audio signal to audio equipment:

3. Turn on the computer.

• You can adjust the volume in Windows 98 by clicking the speaker icon

in the taskbar or with the volume control dial on the right side of your computer.

• When using the audio output jack, you cannot use the built-in

speakers.

Connecting Microphone

You can input sound using an external microphone connected to the microphone jack. When using an external microphone, you cannot use the built-in microphone.

USB Device

Your computer has a interface called Universal Serial Bus (USB). With a USB connection, you can connect/disconnect peripherals without turning off the computer. Remove the cover of the USB port before using. To use a USB device, set the item the manuals of peripheral devices supporting USB.

USB Port:

Disabling the USB port may cause some PC cards to malfunction.

Enabled

in the

Advanced

menu of the Setup Utility. See also

4-9

Printer

You can connect a printer to a parallel port of the external floppy disk drive unit.

Before using a printer, read the printer manual.

Setting the Setup Utility

Advanced

In the Also set the

menu of the Setup Utility, set the

Mode:

, referring t o your printer manua l.

Installing a Printer Driver

To use a printer, you need to install a printer driver.

1. From the

2. Double-click

3. Click

4. Confirm

5. Select the manufacturer and the printer, and click model name of your printer, you have to install the printer driver included with your printer. See your printer manual for details.

6. Select

7. Make sure the printer name is correct, and click

8. Decide whether to print a test page, and click page, make sure the printer is ready.

RS-232C Device

Start

Add Printer

Local printer

LPT1

and click

menu, select

. The

is selected and click

Settings

Printers

Add Printer Wizard

LPT Port:

Finish

Auto

appears.

. If you cannot find the

. Before printing a test

Enabled

You can use RS-232C devices, such as a modem or a terminal adapter with your computer. RS-232C port is available on the external floppy disk drive unit. To use an RS-232C device, set the item menu of the Setup Utility. See the manual before using the device.

Serial Port

: to

Auto

Enabled

in the

Advanced

4-10

CHAPTER 5

Communication Functions

This chapter explains how to use infrared communications, the built-in modem and the LAN unit.

Infrared Communication

Using the IR (infrared) port located on the right side of your computer, you can communicate wirelessly with infrared-equipped devices such as electronic organizers, computers or printers. To establish infrared communication, follow the instructions below. See the manual or online help of each application for details.

Positioning and Preparing the Computer and the Target Device

1. Put your computer on a flat surface.

2. Place the target device so that its IR port is in line with that of your computer.

3. Adjust the distance between the IR ports to be less than 20 inches (50 cm).

When using a Sharp electronic organizer, make sure the two IR ports are within 12 inches (30.5cm).

Setting for Infrared Communication

1. In the

2. In the

3. In the

Advanced

IrDA.

Power

dialog box, disable power management. Refer to in Chapter 3.

Infrared Monitor

enable infrared communication.

menu of the Setup Utility, make sure the

menu of the Setup Utility and the

dialog box in the

Mode

Power Management Properties

Disabling Power Management

Control Panel

, select

Options

IR Port

and

5-1

During infrared communication:

• Do not move the computer and the other IR device

• Do not enter

• Do not use a cellular phone or another IR device near the computer.

• Avoid strong light such as sunlight or fluorescent light.

• Disable the screen saver.

IR Mode

Your computer supports two available IR modes: IrDA (Infrared Data Association) and ASK (Amplitude Shift Keying). Each application automatically selects the appropriate IR mode.

Logical Port

For some software, you may have to c hange the assignment of the logic al port:

1. In the

2. Change the settings, and click OK.

3. When the message

Turning off the IR communication

For IrDA communication, your computer is continuously emitting infrared rays to search for other IR devices. If necessary, you can temporally disable this emission.

1. From the

2. Double-click the

3. Turn off the infrared communication, and click OK.

SHARP IR

appears, click OK.

Start menu

System standby

dialog box, select

You have changed the infrared communication port

, select

SHARP IR

Settings

icon.

Ports

Control Panel

Communicating with Windows 98 Personal Computer

To communicate with a personal computer installed with Windows 98:

1. Right-click the file you want to send.

2. Select

The file you send will be saved in personal computer. If you cannot send the file, confirm your computer and the target computer are located correctly. Double-click whether the name of the target computer appears in

range

Send To - Infrared Recipient

My computer - Infrared Recipient

. If not, relocate your computer and the target computer.

My Received Files

in C: drive of the target

Available infrared devices within

, and check

5-2

Built-in Modem (may not be available in some countries)

Core

Modem Jack

You can use the built-in modem for data transfer and fax communication.

• The built-in modem on your comp uter is designed only for regular

analog telephone lines. The modem may be damaged when connected to a digital ISDN terminal or a digital PBX.

• If an unusual device is attached to the line you are connecting to, the

modem may not function properly. Remove the device or contact the dealer of the device.

• Before connecting to a PBX, consult the PBX maintenance staff or its

service company. If the electric characteristics of your PBX are different from those of a regular analog line, the modem will not function properly. If you connect the modem to a digital PBX, both the modem and the PBX may be damaged.

Connecting the Modem to a Telephone Line

1. Turn off your c omputer.

2. Remove the cover of the modem jack on the right side of your computer and connect the end nearest the core on the included modem cable to the modem jack.

3. Connect the other end of the cable to the telephone line.

4. Turn on the computer.

Connect the modem to the telephone line directly. Do not use a distributor or allotter.

5-3

Disabling Power Management

To use communication software, you may have to disable power management. See

Disabling Power Management

in Chapter 3.

Setting Communication Information

1. In the

2. Set each item, following the instructions on the screen.

Modems Properties

dialog box, select

Dialing Properties

Setting Communications Software

1. Within the communications software you are using, set the COM port of the built-in modem to COM3 if you have not changed the settings in the menu of the Setup Utility.

2. Set parameters such as modem speed (baud rate) and line type (pulse dialing or tone dialing).

Advanced

• See also the manual or online help of the software you are using

• Do not enter

• The communication speed may vary depending on the traffic, local

telecommunications infrastructure, and ISP (Internet Service Provider) infrastructure.

• Before commencing with fax communication, it is recommended that

you exit other application programs.

• You cannot use the built-in modem when the computer is in MS-DOS

mode.

System standby

while using communication software.

5-4

LAN unit

LAN Jack

To Network

Your computer is equipped with a 100 Base-TX/10 Base-T LAN interface. To activate the LAN adapter, perform the following steps.

1. Turn off the computer.

2. Connect one end of the LAN cable into the LAN jack on the rear side of the computer.

3. Connect the other end of the LAN cable into the network hub.

4. Turn on the notebook.

5. When

6. In the Advanced menu, enable

7. Press

8. In the

If you cannot access the network,

1. From the

2. Double-click the

3. In the

4. Click

5. Click

6. Click

Press <F2> to enter SETUP

Esc

Network

your network administrator.

• You cannot use the LAN unit when your notebook is in MS-DOS mode.

• You cannot use the LAN unit when you connect an optional external

battery(CE-BL03).

Network Realtek RTL8139 xxxxxx Advanced

an appropriate value in

Enter

; then

Start

twice and restart your computer.

twice. The system restarts.

dialog box, set fields according to your network status. Refer to

menu, select

Network

dialog box, select

tab, and select

Settings – Control Panel

icon.

Value:

appears, press F2.

LAN

Configuration

Properties

; then

Link Speed/Duplex Mode

tab.

Property:

and enter

5-5

CHAPTER 6

Security Features

This chapter describes how to protect your computer against unauthorized use, computer viruses and theft.

Passwords

Setting a password will help protect against unauthorized access to your computer. When a password is set and the computer is turned on or resumes from the suspendto-disk mode, the system will require a password.

If you lose your password, you will be unable to access the computer or change the configuration. Make sure you select a password you will never forget, and write it down and save it in a secure place. Otherwise, you will have to contact your de aler for assistance.

If you enter a wrong password three times, the message appears. Press the power switch to turn off the computer, turn it on again, and enter the correct password.

Supervisor Password and User Password

Two types of passwords limit the access at different levels. To set the user password, you always have to set the supervisor password. When you set the two passwords, a person who knows only the user password has the limitations on the next page:

System Disabled

6-1

When setting items in the Setup Utility

The person who does not know the supervisor password cannot set:

Security Menu

Exit Menu

and cannot get default value with F9 key.

When the system starts or resumes from Hibernation

If you have enabled system requires a password when you turn on the computer. If you have enabled

Power Management Security

resumes from

Password on boot

Hibernation

•

Set Supervisor Password

•

Password on boot

•

Power Management Sec urity

•

Diskette access

•

Fixed disk boot sector

•

Load Setup Defaults

•

Discard Changes

Security

in the

, the system requires a password when the system

menu of the Setup Utility, the

The person who does not know the supervisor password cannot read/write a floppy disk when the item of

Supervisor

Setting the Password

1. In the

2. Type your password (up to eight characters), and press

3. Type the same password again, and press

4. When the confirmation message appears, press

5. Press

6. Press

If you use the computer personally

We recommend that you set the supervisor password. You can prevent other people from using your computer by enabling Setup Utility.

6-2

Security

User Password

Esc Enter

Enter

Security

is defined as

menu of the

Diskette access

in the

Security

menu of the Setup Utility, select

and press

and select

twice. The system restarts and asks the password you have set.

Exit Saving Changes

menu of the Setup Utility.

Enter

Password on boot

Set Supervisor Password

Enter

in the

Set

If you share the computer with others

We recommend that a person who administers the computer sets both supervisor and user passwords and lets the other people know only the user password.

Changing the Password

1. In the

2. Type your current password, and press

3. Type your new password, and press

4. Type your new password again, and press

5. When the confirmation message appears, press

6. Press

7. Press

Security

change and press

Esc

Enter

menu of the Setup Utility, select the password item you want to

and select

twice. The system restarts.

Enter

Exit Saving Changes

Enter

Deleting the Password

1. In the

2. Type your current password, and press

3. Without typing any characters, press

4. Press

5. When the confirmation message appears, press

6. Press

7. Press

Security

delete and press

Enter

again.

Esc

and select

Enter

twice. The system restarts.

menu of the Setup Utility, select the password item you want to

Enter

Exit Saving Changes

6-3

Preventing Infection of Computer Viruses

You can protect against some viruses by limiting writing to the hard disk. To limit writing to the hard disk, set the item

Security

menu of the Setup Utility.

You cannot prevent infection of all types of viruses with the above

•

operation. Even if a warning message appears, the system may not be infected in

•

some cases.

Fixed disk boot sector

Write Protect

Security Slot

You can prevent theft by using a security cable and the security slot on the right side of your computer.

in the

6-4

CHAPTER 7

Setup Utility

This chapter describes how to run the Setup Utility to change settings on your computer.

Running the Setup Utility

With the Setup Utility, you can customize the system configuration information, such as time and date, port assignments, passwords, or power management settings. The information you have specified is saved in a special area called CMOS RAM, which the system reads every time you turn on the computer.

Contents of the Setup Utility

The Setup Utility consists of five menu pages, as follows:

•

Main: Basic system configuration

•

Advanced: Device interface configuration (I/O ports, etc.)

•

Security: Password settings

•

Power: Power management (batte ry saving settings)

•

Exit: Exit the Setup Utility or return to the default values

Entering and Exiting the Setup Utility

1. Turn on the computer.

2. When

3. Change the desired settings.

4. Press

Press <F2> to enter SETUP

Esc

to select the

Exit

menu.

appears, press F2.

7-1

5. Select one of the exit methods, and press

6. When the message restarts.

To turn off the computer when the Setup Utility is open, press the power switch.

Setup Confirmation

Enter

appears, press

Enter

Using the Setup Utility

To navigate through the differ ent menus, you can use the foll owing keys:

Moves the cursor from one menu to another.

Moves the cursor from one item to another in a menu.

Increases the numeric value or changes an item to the next

Space bar

value.

Decreases the numeric value or changes an item to the previous value.

again. The system

7-2

F10

Enters the Exit menu. When a sub-menu is open, this key closes the sub-menu.

Replaces the settings on the current menu with their default values (date and time are not changed).

Saves the settings you have changed and exits the Setup Utility.

Displays online help for the Setup Utility.

Displays sub-menu. Items with marks contain sub-menus.

Main menu

System Time

hour format). The change numerals.

System Date

bar and the "-" key change numerals.

Diskette A

1.44MB,3½

Hard Disk Type

BootSequence

system files.

Internal Numlock

legends on the built-in keyboard when you connect an external keyboard and lock its numeral keys.

Memory Cache

access speed to data previously accessed.

QuickBoot Mode

enabled, the system skips certain tests while booting.

Defines the system time, using the format

Tab

key moves the cursor, and the space bar and the "-" key

Defines the system date. The

Defines whether to use the floppy disk. To use it, set this item to

Specifies the hard disk type. Set to

Specifies the sequence in which the boot program looks for operating

Defines whether you can inp ut numerals through keys with blue

Enables or disables the memory cache function that accelerates the

Enables or disables the quick boot function. When this item is

Tab

key moves the cursor, and the space

hour:minute:second

Auto

during normal use.

(24-

Quiet Boot

the system shows SHARP logo screen while booting.

BIOS version

EC version

System Memory

Extended Memory

Enables or disables the quiet boot function. When this item is enabled,

Shows BIOS version of your notebook.

Shows the version of power source firmware.

shows the size of conventional memory for starting MS-DOS.

Shows the size of extended memory with 1MB or larger.

7-3

Advanced menu

Serial Port

means that you can select the item yourself. automatically assigned.

IR Port

and the DMA channel. means that all the items except the mode are automatically assigned. that you cannot use the port. Set to

Mode LPT Port

Enabled

address is automatically assigned.

Mode

Parallel Port mode) or

Internal Pointing Device Resolution Expansion

is 640x480 or 600x800.

USB Port

some PC ca rds may malfunction.

Sets the RS-232C serial port, selecting the base I/O address.

Auto

means that the item is

Disabled

Sets the infrared port, selecting the mode, the I/O channel, the IRQ channel,

Enabled

Specifies the IR mode: IrDA or ASK. Set to

Sets the printer port, selecting the mode and the base I/O address.

means that you can select the items yourself.

Specifies the LPT port mode:

ECP

Defines whether the screen is expanded when the resolution

Enabled

Enables or disables the USB port. Always set to

means that you cannot use the port.

means that you can select the items yourself.

Auto

during normal use.

IrDA

Auto

Disabled

(Extended Capabilities Port mode).

Enables or disables the glide pad.

means that the screen is expanded.

means that you cannot use the port.

Bi-directional, Output Only, EPP

Enabled

Disabled

during normal use.

means that the base I/O

(Enhanced

Enabled

; otherwise,

Auto

means

LAN

Enables or disables the LAN port.

Plug & Play O/S

function. Set to

Large Disk Access Mode

use. If you use another operating system such as UNIX, select

PCI Configuration

during normal use. Never set them to

Defines whether the operating system supports the plug & play

Yes

during normal use.

Selects the operating system. Set to

Defines IRQs for some internal devices. Leave them as default

Disabled

7-4

DOS

during normal

Other

Security menu

See the previous chapter about setting passwords.

•

In some password settings, you cannot select some items.

•

Set Supervisor Password

Set User Password

set the user password unless you have set the supervisor password.

If you lose your password, you will be unable to access the computer or change the configuration. Make sure to select a password you will never forget, or write it down and protect it in a secure place. Otherwise, you will have to contact your dealer fo r assistance.

Password on boot

process.

Power Management Security

when it resumes from the suspend-to-disk mode. input a password to continue.

Diskette access

Fixed disk boot sector

protected. When formatting the hard disk or when reinstalling software, set it to

Normal

Enabled

Defines whether the system requires passwords during the boot

means that you need to input a password to continue.

Specifies who can access the floppy disk drive.

Defines the supervisor password (up to eight characters).

Defines the user password (up to eight characters). You cannot

Defines whether the system requires a password

Enabled

Defines whether the boot sector of the hard disk is write-

means that you need to

7-5

Power menu

All items you set except for

•

Windows 98. See Chapter 3 about power management and the battery.

•

Power Switch Function

On/Off

, the switch works only to turn on/off the computer. If you

Suspend/Resume Mode

when you press the power switch. To resume the system, press the power

switch again.

Cover Close

Power Management Function

Power Down after, Video Power Down after

Hard Disk Power Down after

after which the power supply for the hard disk stops automatically.

Video Power Down after

which the power supply for the screen stops automatically.

Suspend Mode

suspended.

, the system enters the mode that is specified in the item

Specifies the mode the system enters when the screen cover is closed.

Defines which mode the system enters when the system is

Defines the function of the power switch. If you sele ct

Enables or disables the items below:

Defines the duration of non-access to the hard disk

Defines the duration of non-access to the screen after

Auto Backlight Cont rol

Auto Suspend

, and

do not work in

select

Suspend

Hard Disk

Auto Suspend

operate the computer for the specified length of time. This item does not function under Windows 98.

Critical Battery Suspend

mode when the battery power becomes low.

Auto Backlight Control

backlight. When this item is enabled, for example, backlight brightness is reduced when the system operates on battery power.

Defines whether the system enters a suspend mode when you do not

Defines whether the system enters the suspend-to-disk

Enables or disables the self-adjustment of the display

7-6

Resume On Modem Ring

the modem receives a call. (may not be available in some countries)

The built-in modem may not be available in some countries.

Defines whether the system resumes from

Standby

when

Battery Level

standard battery;

Shows the amount of battery power remaining.

Battery 2

Exit menu

Exit Saving Changes

Utility.

Exit Discarding Changes

have changed.

Load Setup Defaults

of the above items.

Discard Changes

Save Changes

Saves the settings you have cha nged.

Battery 1

refers to the optional external battery pack.

Saves the settings you have changed and exits the Setup

Exits the Setup Utility without saving the settings you

Returns the values of all items to default. To exit, select one

Returns the values of all items to the values you last saved.

refers to the

7-7

Appendixes

The appendixes contain additional information on the use and care of your computer.

Maintenance and Care

This appendix provides you with information on how to maintain the computer in excellent working condition.

Cleaning the Computer

Cabinet

Apply a small amount of mild cleaning solution to a dry, lint-free cloth and wipe the cabinet with the cloth.

• Do not use alcohol, benzene, thinner or other strong chemical agents

that may damage the cabinet.

• Never clean the computer while it is powered on.

Screen

The surface of the screen may become smeared and accumulate dust during use. Avoid touching the sc reen with your fingers when using the system. Gently wipe the surface of the screen with a soft cloth that has been dipped in a mild detergent solution and squeezed dry.

IR Port

Dust on the IR port will interfere with data transfer. Wipe the port clean with a soft, dry cloth.

Glide Pad

Wipe the glide pad with a soft, dry cloth.

Traveling with the Computer

A-1

This computer is designed for portability. For safety and convenience when traveling, please follow these guidelines.

•

Before traveling, back up your data on floppy disks or other external media.

•

Bring an extra copy of your backup data.

•

Do not travel with an external floppy disk drive unit or optional CD-ROM drive connected.

•

Do not travel with the computer powered on. This may result in loss of data and/or damage to the hard disk drive.

•

Disconnect the AC adapter from the computer.

•

Fully charge the standard battery pack and bring the AC adapter and the AC power cord.

•

Avoid sudden shocks or extreme vibration.

A-2

Specifications

Parts Specifications

CPU Mobile Pentium II Processor (frequency differs by configuration) Secondary cache 256KB(Integrated with CPU) ROM Including system BIOS and VGA BIOS RAM System SDRAM 64MB (expandable to 128MB)

Video 2.5MB

Display Panel Active Matrix (TFT) color LCD

Video controller Trident Cyber Keyboard IBM compatible keyboard Pointing device Glide pad (touch-sensitive control pad with 2 buttons ) Drive Hard disk IDE interface

Floppy disk(external) 3.5", 1.44MB/720KB PC card slot Type II × 1 (PCMCIA 2.1 compliant) CardBus compliant Audio system Monaural micropho ne, mo naural spe ake r, so und sy ste m co mpl iant

I/O ports Audio Audio output jack, e xte r nal micr opho ne jack

Video External monitor port

Others Two USB ports, modem jack, LAN jack

Others(on external

floppy disk drive) Infrare d IR p ort (I r DA : 115K bps/4Mbps , SHA RP ASK : 9600bps) Modem (may not be available in some countries) Power AC adapter 100-240V, 50-60 Hz

Battery Rechargea ble lithium ion battery

Battery life Approximately 2 hours (standard internal battery only)

Battery charging time

(both standard and

optional external

batteries) Dimensions Computer 10.4'" wide x 8.3" deep x 0.91"(min.)/1.22"(max.) high

Floppy disk drive

unit Operating Temperature 50°F to 95°F (10°C to 35°C) environment Humidity 20% to 80% (non-condensation)

with Sound Blaste r Pr o

Parallel port, RS-232C serial port, keyboard/mouse port

Data: 56Kbps(receive), 33.6Kbps(send), Fax: 14.4Kbps,

Approximate ly 4 hours (w ith fl at panel batte ry ( CE-BP 01) co nnecte d) Approximate ly 6 hours (with e xte rnal batte ry pack(CE-BL 03) connected) *battery life varies depending on usage Turned off/suspended to disk: about 5.5 hours Turned on: about 7.5 hours *charging time varies depending on usage

(263mm x 212mm x 23mm(min.)/31mm(max.))

4.65" wide x 6.81" deep x 0.94" high(118mm x 173mm x 24mm)

Options(may not be available in some countries)

External Battery Pack Flat Panel Battery External CD-ROM Drive Optional AC Ada pt er

CE-BL03 CE-BP01 CE-CD01 CE-J02V

A-3

Memory Module (64MB)

CE-ME64A (Ask your local service dealer for installat i on)

A-4

Troubleshooting

This chapter describes how to troubleshoot computer problems.

Common Problems

Problems with your computer can be caused by something as minor as an unplugge d power cord or as major as a damaged hard disk drive. The information in this troubleshooting section is designed to help you find and solve minor problems. If you still have a problem after trying all the suggested remedies in this chapter, contact your dealer.

The problems that you might encounter can be divided into two basic categories: hardware and software. Hardware problems can be further divided into being of an electrical or a mechanical nature. You will know you have a hardware problem if, for example, the screen is blank, or the computer cannot recognize the disk drives.

Software problems can occur at several levels. Both your operating system and your software application programs are capable of generating errors and error messages. If you encounter a software error, try to determine if the error message is from your operating system or from an application program, and refer to the appropriate manual for possible remedies.

You can also refer to the Windows 98 manual or Windows Help program to solve the problem. To access the Help program, select Help from the Start menu. It also gives you Troubl eshooting tips and an Index.

Successful troubleshooting is the result of careful observation, deductive reasoning, and an organized approach to solving the problem. If you encounter a problem, begin by performing a careful visual inspection. Check the exterior of the computer first. If no lights are displayed, check the battery charge or power outlet, the plug and power cord, and any power switches that may affect your computer. If the computer has been connected to any peripheral devices, look for loose or disconnected cables. You may also need to check the fuses and breakers in your electric box. A few common problems and suggested solutions are presented in the examples which follow.

Troubleshooting T-1

Troubleshooting

Trouble when Starting

Question: Why doesn't the power switch function?

•

Make sure the AC power cable is correctly connected to a live wall outlet.

•

If the computer is operating with batteries, batteries may be discharged. Connect the computer to a wall outlet.

Question: Why doesn't Windows start?

•

Check whether the external floppy disk drive unit contains a non-system disk. Remove the floppy disk from the drive, and press any key.

•

If you are attempting to boot from the external floppy disk drive, check to make sure the disk is fully inserted and seated into the drive.

•

If you attempt to boot from the external floppy disk drive, check whether the Diskette Drive is set to the first in BootSequence in the Main menu of the Setup Utility.

Question: Why do I get a non-system disk or disk error message?

•

You may have inserted a non-bootable disk in the external floppy disk drive unit (either a defective disk or one without an installed operating system). Remove the disk.

•

If this message is issued when you attempt to boot from your hard disk drive, insert a bootable disk into the external floppy disk drive unit and check the status of your hard disk drive.

•

Check whether the items Diskette A: and Hard Disk Type: are correctly set in the Main menu of the Setup Utility.

Troubleshooting

Question: Why do I get the message Operating system not found?

•

If you get this message when starting from the hard disk, insert the boot up disk into the external floppy disk drive unit; then check the condition of the hard disk.

•

Enter the Setup Utility and check the status of the hard disk. Check the size of the hard disk and make sure the item Hard Disk Type of Main menu is set to Auto.

T-2 Troubleshooting

Trouble with Displa y

See also the Display section in Chapter 4.

Question: Why is the screen blank?

•

Press any key to see if any power management feature has turned off the screen to save power.

•

See the power indicator to check whether the computer is powered.

•

If you are using a standard battery pack, make sure it has a charge remaining. If you are using an external battery pack, make sure it is connected correctly and has a charge remaining.

•

Make sure the LCD screen is selected as the display by pressing

•

Check the brightness c ontrols for your display by pressing

•

Check whether the back light is on by pressing

•

If you still have the problem after trying the above, press the power switch for more than six seconds to turn off the system. Five seconds later, turn the computer on.

•

If you cannot power off the system with above procedure, slide the reset switch on the bottom of your computer and turn off the system (refer to page 2-3). Wait five seconds and turn the computer back on.

Fn+F11

Fn+F7

Fn+F5

Question: Why does the external monitor display nothing?

•

Confirm the monitor is turned on.

•

Confirm the monitor is connected correctly.

•

Make sure an external monitor is selected as the display by pressing

Question: Why is the image on an external monitor display distorted?

•

Confirm the monitor is connected correctly.

•

Make sure the CRT is not near any electric devices having strong magnetic fiel ds such as a TV set or radio.

•

Do not share an outlet with a TV set or radio.

•

Make sure the value of the Screen area in the Display Properties is lower than the resolution of the CRT monitor.

Troubleshooting T-3

Fn+F5

Troubleshooting

Trouble with Hard Disk

Question: Why can't I read or write data to/from the hard disk?

•

Confirm the drive and file names are correct.

•

Confirm the hard disk has sufficient free space.

•

The hard disk in your computer is formatted with FAT32. You cannot read or write data formatted in other operating systems, which are not FAT 32 compatible. Applications that are not compliant with FAT32 may not work properly.

•

If you cannot re-install Windows 98 correctly, check whether the item Fixed disk boot sector: in the Security menu of the Setup Utility is Normal.

Trouble with Floppy Disks

Question: Why can't I use a floppy disk?

•

Confirm the external floppy disk drive unit is correctly connected.

•

Confirm the floppy disk is inserted correctly.

•

The floppy disk may not be formatted or could be corrupted.

•

If you cannot write to a floppy disk, the disk may be write-protected. Eject the disk and ensure that the write-protect tab covers the detection hole.

•

If you cannot write to a floppy disk, the disk may be full. Use another disk.

•

Confirm the item Diskette A: is 1.44MB, 3 ½ in the Main menu of the Setup Utility.

•

Check whether the supervisor has set a password prohibiting access to the floppy

Troubleshooting

disk drive in the Security menu of the Setup Utility.

Trouble with Keyboard/Glide Pad

Question: Why doesn't the keyboard or the glide pad function?

•

Perform a software reset b y pr essing

•

If you cannot perform a software reset, press the power switch for more than six seconds to turn off the system. Five seconds later, turn the computer on.

T-4 Troubleshooting

Ctrl+Alt+Delete

•

If you still cannot turn off the system with the power switch, slide the reset switch on the bottom of your computer to turn off the system(refer to page 2-3). Five seconds later, turn on the computer by pressing the power switch.

Question: Why doesn't the glide pad function correctly?

•

Confirm the surface of the glide pad is completely dry and free from dirt and grease.

•

Confirm the item Internal Pointing Device in the Advanced menu of the Setup Utility is enabled.

Trouble with Peripherals

Question: Why don't expansion or peripheral devices function?

•

Confirm they are correctly connected to your computer or the external floppy disk drive.

•

Confirm the external floppy disk drive is connected correctly to the computer if peripheral devices are connected to the external floppy disk drive.

•

Confirm drivers necessary for operating ports on the devices are installed.

•

There may not be a free IRQ (Interrupt). Free up an IRQ from a built-in device.

Question: Why can't I print?

•

Make sure the printer is turned on.

•

Check whether the external floppy disk drive and the printer are connected correctly.

•

Check whether the print er has enough paper.

•

Check whether the printer driver is installed.

•

Make sure LPT Port in the Advanced menu of the Setup Utility is set correctly.

•

From the Start menu, select Settings - Printers to confirm your printer is installed here. If not, click Add Printer to install your printer.

•

Sharp PC-A290 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
