PC-9080
User Manual
114 pgs869.8 Kb0

Sharp PC-9080 User Manual

Notice for Users in the USA
FCC Statement
WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules.
•
Reorient or relocate the receiving antenna.
•
Increase the distance between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio / TV technician for help.
A shielded I/F cable is required to insure compliance with FCC regulation for Class B computing equi pment.
* As an Energy Star Partner, SHARP has determined that this product meets the
Energy Star guidelines for energy efficiency.
i
About Modem
This equipment PC-9080 complies with Part 68 of FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.
The modem jack of this equipment complies with Sub-part F of Part 68 of FCC rules.
The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs contact the telephone company to determine the maximum REN for the calling areas.
If the terminal equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a compliant with the FCC if you believe it necessary.
The telephone company may mark changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service.
It trouble is experience with this equipment, please contact Sharp Electronics Corp. for repair and (or) warranty information (Refer to the end of this section). If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved.
The equipment cannot be used on public coin service provided by the telephone company. Connection to Party Line Service is subject to state tariffs. (Contact the state public utility commission, public service commission or corporation commission for information.)
ii
The Telephone Consumer Protection Act of 1991 marks it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.) To program this information, refer to the manual of the communication software.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer's instructions.
Copyright
It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.
Product Information and Customer Assistance
For Product Information and Customer Assistance:
Call: 1-800-BE-SHARP (237-4277) Sharp Electonics Corp.
Sharp Plaza Mahwah, NJ 07430
iii
Notice for Users in Canada
About Modem
The Load Number of your modem is 6.
The Industry Canada label identifies certified equipment. This certification means that the equipment meet certain telecommunications network protective, operational and safety requirements. The department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilites of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company's inside writing associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.
CAUTION Users should not attempt to make such connections themselves, but should contact the approprlate electric inspection authrity, or electrician, as appropriate.
iv
“The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device. To prevent overloading, the termination on a loop may consist of any combination of devise subject only to the requirement that the total of the Load Numbers of all the devices does not exceed 100.”
This digital apparatus does not exceed the Class A Limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulation of the Canadian Depa rtment to Communications.
v
Notice for Users in Australia
Service Inquiries
Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1-800-807820 (free call) for referral to your nearest Sharp authorised Service Centre. Details can be found on the warranty card inserted with the documentation.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Do not dispose of large quantities of used Lithium batteries at the same time.
Copyright
Copyright may exist in material you wish to record. Copying or broadcasting such material without permission of the relevant licensees or owners of the copyright is prohibited by law. SHARP is not in a position to authorise the copying or broadcasting of copyright materials and nothing in this OPERATION MANUAL should be implied as giving that authority.
vi
Notice for Users in the UK
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
BLUE: Neutral BROWN: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows. The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. This apparatus must be protected by a 3A fuse in the mains plug or distribution board.
“WARNING: THIS APPARATUS MUST BE EARTHED”
This apparatus is approved under approval number NS/G 1234/J/100003 for indirect connection to the public telecommunication system in the United Kingdom.
Copyright
Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.
vii
Notice for Users in Europe
This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC.
Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.
Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/EEG.
Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/EEC.
Quest' apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/EEC.
Η εγκατασταση αυτη ανταποκρινεται στιζ απαιτησειζ των οδηγιων τηζ
´
Ευρωπαïκηζ Ενωσηζ αυτοι συµπληρωθηκαν απó την οδηγια
´
´
89/336/EOK
´´
´´´
73/23/EOK, ó
κατ
´
93/68/EOK.
πωζ οι κανονισµοι
´
Este equipamento obedece às exigências das directivas 89/336/CEE e 73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de la 93/68/CEE.
Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/EEC så som komplette ras av 93/68/EEC.
Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og 73/23/EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.
viii
CAUTION:
TO PREVENT ELECTRICAL SHOCK, DISCONNECT THE AC CORD AND THE BATTERY BEFORE SERVICING.
CAUTION:
FOR A COMPLETE ELECTRICAL DISCONNECTION, PULL OUT THE MAIN PLUG AND THE BATTERY.
VORSICHT:
UM DIE STROMZUFUHR VOLLSTÄNDIG ZU UNTERBRECHEN, DEN NETZSTECKER HERAUSZIEHEN UND DIE BATTERIE ÈNTFERNEN.
ATTENTION:
POUR UN ARRET TOTAL DU SYSTEME, DECONNECTEZ LE FIL DE LA BATTERIE.
VARNING:
FÖR TOTAL ELEKTRISK URKOPPLING, KOPPLA UR KONTAKTEN OCH TA UR BATTERIET.
PRECAUCION:
PARA UNA COMPLETA DESCONEXION ELECTRICA DESENCHUFE LA CLAVIJA DE LA RED Y LA BATERIA.
ix
Safety Precautions
•
Follow all cautions and instructions which may be marked on the notebook.
•
Except as described elsewhere in this manual, refer all servicing to qualified personnel. Immediately shut off the notebook and refer for servicing under the following conditions:
when the power cord or plug is damaged or frayed
•
if liquid has been spilled on the notebook
•
if the notebook has been dropped or the cabinet has been damaged
•
•
Never push any objects of any kind into cabinet openings. They may touch dangerous voltage points or short parts that could result in fire or electrical shock.
•
Turn off the notebook before installing or removing a peripheral device.
•
Turn off the notebook and disconnect the AC cord before cleaning.
•
Do not expose the notebook to direct sunlight.
•
Keep the notebook away from any magnetic devices and TVs.
•
Do not drop the notebook.
•
Since this product is not waterproof, do not use it or store it where fluids, for example water, can splash onto it. Raindrops, water spray, juice, coffee, steam, perspiration, etc. will also cause malfunction.
x
About This Manual
Notice
Information in this manual is subject to change without notice and does not represent a commitment on the part of Sharp Corporation.
Sharp Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
Sharp strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, Sharp assumes no responsibility for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other causes.
Sharp assumes no responsibility directly or indirectly, for financial losses or claims from third persons resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss of or alteration of stored data, etc.
Edition
1st Edition, July 1996.
Copyright
© 1996 Sharp Corporation This document contains or refers to proprietary information which is protected by cop yright. All rights are reserved. Copying or other reproducti on of this document is p rohibited without the prior written permission of Sharp Corporation.
Trademarks
Pentium is a registered trademark of Intel Corporation. IBM and PS/2 are trademark s of International Business Machines Corporation. IntelliLink is a registered trademark of IntelliLink Corporation. Microsoft, MS-DOS, Windows, and the Windows Logo are regis tered trademarks of Microsoft Corporation. GlidePoint is a registered trademark of Cirque Corporation. Sound Blaster is a trademark of Creative Technology Ltd. TranXit is a trademark of Puma Technology. Netscape Navigator is a trademark of Netscape Communications Corporation. SuperVoice is a trademark of Pacific Image Communications, Incorporated. PC-cillin ‘95 Virus Scanner is a registered trademark of Trend Micro Devices, Incorporated. Video Work is a registered tra dema rk, and ProImage P lus is a tra dema rk, of Prolab Technology Co., Ltd. All other brand and product names are trademarks or registered trademarks of their respective holders.
xi
Recording the Information
For future reference, please record the following information in the spaces provided below.
Model Number:
Serial Number:
BIOS Version
Number:
Date of purchase:
Dealer’s Name:
Place of purchase:
Password:
The serial number is printed on a sticker located on the bottom of the notebook. You will see the BIOS Version number on the middle line of the LCD screen when you turn on the notebook.
xii
How to Use this Manual
This manual describes your new notebook and contains all the information you need to set up and use the notebook. Whether you are a new or an experienced user, you will benefit more from this manual if you are familiar with its organization.
The manual is divided into four chapters, plus appendixes.
Chapter 1 Quick Setup provides step-by-step instructions to help you setup and begin using the notebook as quickly as possible. You should read this chapter first before you do any operations.
Chapter 2 Customizing Your Notebook provides an introduction to the notebook’s Setup Utility, detailed descriptions of many configuration and power management options it affords.
Chapter 3 Using Your Notebook provides important information on the daily use of the notebook, covering topics such as power sources, keyboard, floppy disks,CD­ROM and hard disk drives, and use of the GlidePoint, video, PC Cards and other features of the notebook.
Chapter 4 Connecting Peripherals provides detailed instructions on expanding the capabilities of the notebook. Topics covered include connecting a printer, attaching a serial device, and replacing the hard disk drive.
Appendixes provide advice on the routine care and maintenance of the notebook, a guide to troubleshooting problems that may arise in the use of the notebook, detailed specifications on your notebook and the built-in ports. For your convenience, an index is provided at the end of this manual.
In addition to this manual, you may want to consult the Windows 95 manual, and the manuals for your software applications. The Sharp Online Manual accessible from the Windows 95 Help button will also help your computing.
xiii
Manual Conventions
Throughout thi s manua l we have used a set of style conventions. These c onventions are described below.
Keyboard Keys
Key labels, when referred to in the instructions, are shown in boldface as below:
Press Enter to continue.
When more than one key are pressed simultaneously, the key labels are separated by a plus (+) sign, a s shown below:
Restart your notebook by pressing Ctrl+Alt+Delete.
This means hold down the Ctrl and Alt keys, and press Delete simultaneously. Important key combi nations are highlighted throughout this manual by enlarged and iconic representations of the keys you must press to perform an operation, e.g.,
Fn
F5
Notes and Cautions
Icons and italicized text are used for notes and cautions, to make important information stand out.
An information icon alerts you to a special technique or information that may help you perform a task or better understand a process.
A caution icon alerts you to something that may cause problems or damage to hardware, software or data.
xiv
Words/Texts on Screen
Words and texts displayed on the screen, such as window titles or possible paramenters, are italicized in this manual. For example,
Double-check this icon to display the Power Properties window. Set the item to Enabled.
Sample Entries/Screens
In the following case, press the Enter key after you type the command.
C:\>FORMAT A: Enter
Note that the screens reproduced in this manual may differ slightly from the screens you see on your notebook.
File Names
References to commands, utilities, device drivers, directory and file names in this manual are printed in upper case, as shown below:
Type in the PHDISK command.
Section Titles
Section titles in other parts of the manual are italicized, as shown below:
Refer to Video Subsystem section in Chapter 3.
xv
Table of Contents
Notice for Users in the USA................................................................. i
Notice for Users in CANADA............................................................ iv
Notice for Users in Australia..............................................................vi
Notice for Users in the UK................................................................vii
Notice for Users in Europe ...............................................................viii
Safety Precautions................................................................................ x
About This Manual............................................................................. xi
Recording the Information................................................................. xii
How to Use this Manual....................................................................xiii
Manual Conventions......................................................................... xiv
Table of Contents.............................................................................. xvi
Appearance of the Notebook..........................................................xviii
Chapter 1 Quick Setup
Getting Started.................................................................................. 1-1
Unpacking the Notebook..................................................................1-2
Installing the Battery Pack................................................................1-3
Connecting to AC Power ..................................................................1-5
Opening the Notebook......................................................................1-7
Turning on the Power........................................................................1-8
Adjusting Screen Brightness.............................................................1-9
Setting up Windows 95................................................................... 1-10
Setting Initial Condition..................................................................1-11
Shutting Down the System.............................................................. 1-12
Chapter 2 Customizing Your Notebook
Running the Setup Utility..................................................................2-1
Power Management...........................................................................2-9
Changing Power Configuration Settings......................................... 2-13
xvi
Chapter 3 Using Your Notebook
Status Indicator LEDs.......................................................................3-1
Power Sources...................................................................................3-3
CD-ROM Drive.................................................................................3-7
Floppy Disk.....................................................................................3-11
Hard Disk Drive..............................................................................3-13
Keyboard.........................................................................................3-14
GlidePoint....................................................................................... 3-16
Video Subsystem.............................................................................3-19
PC Cards and Devices.....................................................................3-21
Infrared Communications................................................................3-23
Modem............................................................................................3-24
Audio System..................................................................................3-25
Chapter 4 Connecting Peripherals
Handling Precautions........................................................................4-1
Installing a Memory Module.............................................................4-2
Changing the Hard Disk Drive..........................................................4-5
Changing the Battery.........................................................................4-7
Connecting a Printer..........................................................................4-8
Connecting an External Monitor.....................................................4-10
Connecting a Serial Device.............................................................4-11
Connecting a Keyboard or Mouse...................................................4-12
Connecting Audio/TV/Video Equipment........................................4-13
Port Replicator................................................................................4-16
Appendixes
Care and Maintenance......................................................................A-1
Recreating the Suspend-to-Disk Partition ........................................ B-1
Troubleshooting............................................................................... C-1
System Mapping...............................................................................D-1
Port Pin Assignments....................................................................... E-1
Technical Specifications...................................................................F-1
Index
xvii
Appearance of the Notebook
Front
Color LCD Screen (See page 3-19)
Keyboard (See page 3-14)
GlidePoint (See page 3-16)
Right Side
PC Card Slot Eject Button (See page 3-21)
PC Card Slot (See page 3-21)
Figure 1. The Front of the Notebook
Audio Volume Audio Connectors (See page 3-26)
Telephone Jack
Modem Jack (See page 3-
Floppy Disk Drive (See page 3-11)
Stereo Speakers (See page 3-25)
S-Input Connector (See page 4-14)
Video Input Jack (See page 4-14)
xviii
Figure 2. The Right Side of the Notebook
Left Side
AC Adapter Jack (See page 1-5)
Rear
PS/2 Keyboard/Mouse Connector (See page 4-12)
CRT Connector (See page 4-10)
Bottom
Floppy Disk Drive or Battery Pack (See page 1-3)
Hard Disk Drive (See page 3-13)
Cooling Fan
Power Switch (See page 1-8)
CD-ROM Drive (See page 3-7)
Figure 3. The Left Side of the Notebook
Video Output Jack (See page 4-13)
Expansion Bus Connector (See page 4-16)
Parallel Port (See page 4-8)
RS-232C Serial Port (See page 4-11)
Figure 4. The Rear of the Notebook
Reset Switch (See page 1-11)
Stand
CD-ROM Drive or Battery Pack (See page 1-3)
Figure 5. The bottom of the Notebook
xix
C H A P T E R 1
Quick Setup
Your notebook is designed and pre-configured for easy setup and use. This chapter describes the steps you should follow to get the notebook up and running as quickly as possible. You should read this chapter first.
Getting Started
This chapter explains the whole procedure to get your notebook up and running in the following sequence.
1. Unpacking the Notebook
2. Installing the Battery Pack
3. Connecting to AC Power
4. Opening the Notebook
5. Turning on the Power
6. Adjusting Screen Brightness
7. Setting up Windows 95
8. Setting Initial Condition
9. Shutting Down the System
1
Quick Setup 1-1
Unpacking the Notebook
Your notebook comes securely packaged in a sturdy cardboard shipping carton. Upon receiving your notebook, open the carton and carefully remove the contents. In addition to this Operation Manual, the shipping carton should contain the following items:
•
Notebook computer
•
AC power cord
•
Lithium-ion battery pack
1
•
Audio connection cable
•
TV connection cable
•
S terminal video cable
•
Blank battery filler cover
•
Windows 95 CD-ROM
•
Backup CD-ROM
•
CD-ROM Setup Boot Disk
•
Windows 95 manual and license
•
Reinstallation Instructions
•
TranXit Quick Reference Guide
•
IntelliLink Import/Export User’s Guide
•
PC-cillin ’95 Virus Scanner User’s Guide
•
Phoenix PowerPanel User’s Guide
•
Modem cable (US only)
•
Super Voice User’s Guide (US only)
•
AT Command Reference M anual (US only)
Carefully inspect each component to make sure nothing is missing or damaged. If any of these items is missing or damaged, notify your dealer immediately. Be sure to save the shipping materials and carton in case you need to ship or store the notebook in the future.
1-2 Unpacking the Notebook
Installing the Battery Pack
The notebook has been shipped with the battery separate to preserve battery life. You can install up to two battery packs, one into the CD-ROM drive slot and the other into the 3.5-inch floppy disk drive slot.
The following steps describe how to install the battery pack into either the CD-ROM drive slot or the floppy disk drive slot:
1. Make sure the notebook is not connected to AC power.
2. Place the notebook on a flat surface, then lift the notebook by the left side and turn it upside down.
3. Slide the retaining levers inward on the desired slot, then gently slide out the drive.
1
Figure 1-1. Removing the CD-ROM Drive
You can remove the floppy disk drive similarly.
Quick Setup 1-3
1
4. If you have selected the CD-ROM slot, slide the supplied blank battery filler cover into place as shown. This cover is not needed for the floppy disk drive.
Figure 1-2. Installing Blank Battery Filler Cover
5. With the bottom of the battery pack facing up, insert the connector into the notebook. When the battery pack clicks into place, slide the retaining levers outward.
When using the battery pack for the first time, connect the notebook to an AC power source and charge the battery pack fully.
1-4 Installing the Battery Pack
Connecting to AC Power
The notebook can be powered by either the rechargeable battery pack or the built-in AC adapter. You will find detailed instructions on using both power sources in Chapter 3, but to get the notebook up and running for the first time, follow the steps below to prepare the battery pack and attach the AC cord.
Before using the notebook for the first time, charge the battery pack by attaching the AC cord, as follows.
1. Connect the female end of the AC cord to the AC jack on the left side of the notebook.
2. Connect the male end of the AC cord to a wall outlet.
1
Figure 1-3. AC Cord Connections
Quick Setup 1-5
1
When you connect the AC cord to the notebook and to a wall outlet, the outlet supplies power to the notebook and recharges the battery. Whenever possi ble, keep the AC cord plugged into t he notebook and a wall outlet to recharge the battery. Although not necessary, it is also a good idea to protect the display panel by always lowering it when the notebook is powered off.
It is important for the notebook to be located near the electrical outlet while connected, and for the AC plug to be easily removable.
Always hold the plug (not the cord) when pulling out the AC cord from the outlet.
1-6 Connecting to AC Power
Opening the Notebook
At the front of the notebook you will find a retaining button on the display panel which locks the display in the closed position when the notebook is not in use. To raise the display follow these steps:
1. Press the display lock latch until the display panel releases, and then raise the LCD screen.
2. Tilt the display to a comfortable viewing position.
➁
➀
1
Figure 1-4. Raising the Display Panel
Quick Setup 1-7
Turning on the Power
You can find the power switch near the center of the left side of the notebook. Press the switch firmly to turn it on.
The power switch does not operate with only a light touch.
After a few seconds, the notebook begins to execute the Power-On-Self-Test (or POST) which is automatically run whenever the notebook is turned on. It checks the
1
memory, keyboard, system board and other components of your notebook before the notebook begins normal operation.
The notebook may alert you with a message that the configuration is invalid. Press the F2 key to enter the Setup Utility. To load the default configuration, press the F9 key. Then press the Esc key, select “Save Change & Exit,” and press the Enter key twice.
1-8 Turning on the Power
Adjusting Screen Brightness
F6
F7
If you have trouble reading the scree n, you can adjust the display through the use of special key combinations. The display control key combinations are as follows:
Fn
Fn
This key combination decreases LCD s creen brigh tness increm entally .
This key combination increas es LC D screen brigh tnes s increm entally .
1
Quick Setup 1-9
Loading...
+ 84 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
