Sharp MD-E9000H User Manual
MD COMPACT COMPONENT
SYSTEM
MODEL
MD-E9000H
OPERATION MANUAL
If you require any advice or assistance regarding your Sharp product, please visit our website www.sharp.co.uk/support.
Customers without internet access may telephone 08705 274277 during office hours (or (01)
676 0648 if telephoning from Ireland).
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
MD-E9000H MD Compact Component System consisting of MD-E9000H
(main unit) and CP-E9000H (speaker system).
*MD9000H(FRONT/BACK) 2001.4.20, 2:01 AM2
Special Notes
NOTES FOR USERS IN THE U.K. AND IRELAND
The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS
1362 fuse marked
the pin face of the plug must be used.
Always refit the fuse cover after replacing the fuse. Never use the plug without the
fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the
plug supplied, cut-off the mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and the cut-off plug destroyed
immediately and disposed of in a safe manner.
Under no circumstances should the cut-off plug be inserted elsewhere into a 13A
socket outlet as a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this product may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:
● The wire which is coloured blue must be connected to the plug terminal which is
marked N or coloured black.
● The wire which is coloured brown must be connected to the plug terminal which is
marked L or coloured red.
- Special Notes -
Ensure that neither the brown nor the blue wire is connected to the earth terminal in
your three pin plug.
Before replacing the plug cover, make sure that:
● If the new fitted plug contains a fuse, its value is the same as that removed from
the cut-off plug.
● The cord grip is clamped over the sheath of the mains lead and not simply over the
Important Instruction
lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair, please contact the dealer or
supplier from whom it was purchased. Where this is not possible, please visit our
web-site www.sharp.co.uk/support.
Customers without internet access may telephone 08705 274277 during office hours
(or (01) 676 0648 if telephoning from Ireland).
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be obtained from our main parts
distributor.
In the unlikely event of this equipment requiring repair during the guarantee period,
you will need to provide proof of the date of purchase to the repairing company.
Please keep your invoice or receipt, which is supplied at the time of purchase.
or and of the same rating as above, which is also indicated on
WILLOW VALE ELECTRONICS LTD.
0121 766 5414
WARNINGS
● When the ON/STAND-BY button is set at STAND-BY position, mains voltage is
still present inside the unit. When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the timer mode or remote
control.
● This unit contains no user serviceable parts. Never remove covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug
from the socket before any service operation and when not in use for a long
period.
● T o prevent fire or shock hazard, do not expose this appliance to dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION
● Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
● As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
NOTES
● Recording and playback of any material may require consent, which SHARP is
unable to give. Please refer particularly to the provisions of the Copyright Act
1956, the Dramatic and Musical Performers Protection Act 1958, the Performers
Protection Acts 1963 and 1972 and to any subsequent statutory enactments and
orders.
● This equipment complies with the requirements of Directives 89/336/EEC and 73/
23/EEC as amended by 93/68/EEC.
● US and foreign patents licensed from Dolby Laboratories.
2
*MD9000H-E02-03 2001.4.20, 2:01 AM2
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Contents
■ Important Instruction Page
Special Notes ......................................................................................2
■ General Information
Precautions...................................................................................... 4-5
Accessories .........................................................................................5
Controls and Indicators ................................................................. 6-9
■ Preparation for Use
System Connections ........................................................................10
Remote Control .................................................................................11
■ Radio Page
Listening to the Radio ......................................................................22
Listening to a Memorised Station ...................................................23
■ RDS Radio
Using the Radio Data System (RDS)......................................... 24-30
■ MD Recording
Before Recording to a MiniDisc ......................................................31
Recording to a MiniDisc from a CD .......................................... 32-34
Recording to a MiniDisc from the Radio ........................................35
MD-E9000H
1
2
3
4
5
■ Basic Operation
General Control ................................................................................. 1 2
Sound Control ...................................................................................13
Setting the Clock...............................................................................14
■ CD Playback
Listening to a CD ........................................................................ 15-16
■ MD Playback
Listening to a MiniDisc............................................................... 17-18
■ Advanced CD/MD Playback
Programmed Play .............................................................................19
Direct Play..........................................................................................20
Repeat or Random Play ...................................................................20
Switching the Display.......................................................................21
■ MD Editing
Titling a MiniDisc ........................................................................ 36-37
Editing a Recorded MiniDisc ..................................................... 38-40
■ Advanced Features
Timer and Sleep Operation ........................................................ 41-43
Enhancing Your Stereo System ......................................................44
■ References
What is a MiniDisc? ..........................................................................45
MiniDisc System Limitations ...........................................................45
Error Messages .................................................................................46
Troubleshooting Chart ............................................................... 47-48
Maintenance ......................................................................................48
Specifications....................................................................................49
TERMS OF GUARANTEE ................................................. Back cover
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
6
7
- Contents -
8
9
10
Important Instruction
11
12
3
*MD9000H-E02-03 2001.4.20, 2:01 AM3
Precautions
■
General
● Please ensure that the equipment is positioned in a well-ventilated area
and that there is at least 10 cm (4") of free space along the sides and
back.
There must also be a minimum of 20 cm (8") of free space on the top of
the unit.
● Use the unit on a firm, level surface free
from vibration.
● Keep the unit away from direct sunlight,
strong magnetic fields, excessive dust,
- Precautions -
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generates electrical noise.
● Do not place anything on top of the unit.
10 cm (4”) 10 cm (4”)
General Information
● Do not expose the unit to moisture, to temperatures higher than 60°C
(140°F) or to extremely low temperatures.
● If your system does not work properly , unplug it. Plug the AC power lead
back in, and then turn on your system.
● In case of an electrical storm, unplug the
unit for safety.
4
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
20 cm (8”)
● Hold the AC power plug by the head when unplugging the unit, as pulling the lead can damage internal wires.
● Do not remove the outer cover, as this may
result in electric shock. Refer internal service to your local SHARP service facility.
10 cm (4”)
● The ventilation should not be impeded by covering the ventilation openings with items, such
as newspapers, tablecloths, curtains, etc.
● No naked flame sources, such as lighted candles, should be placed on
the apparatus.
● Attention should be drawn to the environmental aspects of battery disposal.
● The apparatus is designed for use in moderate climate.
● This unit should only be used within the range of 5°C - 35°C (41°F -
95°F).
Warnings:
● The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is specified
is dangerous and may result in a fire or other type of accident causing
damage. SHARP will not be held responsible for any damage resulting
from use of this unit with a voltage other than that which is specified.
● CD players use a laser pickup which can damage the eyes if viewed
directly. Do not look at the pickup, and do not touch the pickup directly.
■ Volume control
The sound level at a given volume setting depends on speaker efficiency,
location, and various other factors.
It is advisable to avoid exposure to high volume levels, which occurs whilst
turning the unit on with the volume control setting up high, or whilst continually listening at high volumes.
*MD9000H-E04-09 2001.4.20, 2:51 AM4
Precautions (continued)
Accessories
MD-E9000H
■ Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due to an accumulation of dirt on the disc surface.
Follow the guidelines below for maximum enjoyment from your CD collection and player.
● Do not write on either side of the disc, particularly the non-label side from
which signals are read.
Do not mark this surface.
● Keep your discs away from direct sunlight, heat, and excessive mois-
ture.
● Always hold the CDs by the edges. Fingerprints, dirt, or water on the
CDs can cause noise or mistracking. If a CD is dirty or does not play
properly , clean it with a soft, dry cloth, wiping straight out from the centre,
along the radius.
Please confirm that the following accessories are included.
AC power lead × 1
AM loop aerial × 1
Remote control × 1
FM aerial × 1
1
2
3
4
5
6
7
8
9
- Precautions / Accessories -
General Information
10
*MD9000H-E04-09 2001.4.20, 2:51 AM5
“AAA” size battery
(UM-4, R03, HP-16 or similar) × 2
Note:
Only the above accessories are included.
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Speaker wire × 2
11
12
5
Controls and Indicators
1
2
- Controls and Indicators -
567891011
General Information
15
12 13 14
4
19
20
3
■ Front panel Reference page
01. CD Compartment ......................................................................12, 15
02. Timer Set Indicator .........................................................................41
03. Remote Sensor ...............................................................................11
04. MD Compartment ............................................................................ 1 7
05. On/Stand-by Button........................................................................12
06. MD Eject Button ..............................................................................18
07. Tuner (Band) Button.......................................................................22
08. Auxiliary Button ..............................................................................44
09. Extra Bass Button...........................................................................13
10. Equalizer Button .............................................................................13
11. Memory/Enter Button ........................................................ 14, 19, 23
12. Display (Demo) Button .............................................................12, 21
13. CD Open/Close Button .............................................................12, 15
14. Volume Up and Down Buttons ......................................................13
15. MD Record Mode Selector Buttons (SP/LP2/LP4) ................32, 35
16. CD/MD Normal Speed Record Button ..........................................32
17. CD/MD High Speed Record Button...............................................32
18. MD Record Button ....................................................................33, 35
19. CD Stop Button .........................................................................15, 32
20. CD Play or Pause Button ...............................................................15
21. CD/MD Track Up and Fast Forward, Tuner Preset
Up Button............................................................................ 16, 18, 23
22. CD/MD Track Down and Fast Reverse, Tuner Preset
Down Button ...................................................................... 16, 18, 23
23. MD Stop Button.................................................................. 17, 32, 35
24. MD Play or Pause Button.........................................................17, 18
6
*MD9000H-E04-09 2001.4.20, 2:51 AM6
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
16 17 18 21 22 23 24
Controls and Indicators (continued)
1
2 3 4 5 6 7 8 9 101112131415 16
171819 20 21 22 23 24 25
1
2
34 5
MD-E9000H
1
■ Display
01. Record Indicator24, 41-43
02. Record Pause Indicator
03. High Speed Record Indicator
04. CD/MD Repeat Indicator
05. RDS Indicator
06. Programme Type Indicator
07. Traffic Programme Indicator
08. Traffic Announcement Indicator
09. EON Indicator
10. Traffic Information Indicator
11. FM Stereo Mode Indicator
12. FM Stereo Receiving Indicator
13. TOC Indicator
14. Over Indicator
15. Track Edit Indicator
16. Extra Bass Indicator
17. Timer Play/Record Indicator
18. 2 times Long Recording (stereo) Indicator
19. 4 times Long Recording (stereo) Indicator
20. Sleep Indicator
21. Level Meter/Character Information/Frequency Indicator
- Controls and Indicators -
22. Track Indicator
23. Random Play Indicator
24. Memory Indicator
General Information
25. Disc Indicator
6
■ Rear Panel Reference page
01. AM Loop Aerial Socket...................................................................10
02. FM 75 Ohms Aerial Socket ............................................................10
03. Auxiliary (Audio Signal) Input Sockets ........................................44
04. Headphone Socket .........................................................................44
05. Speaker Terminals............................................................................9
06. AC Power Input Socket ..................................................................10
2
3
4
5
6
7
8
9
10
11
12
*MD9000H-E04-09 2001.4.20, 2:51 AM7
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
7
Controls and Indicators (continued)
- Controls and Indicators -
General Information
■ Remote Control Reference page
01. Remote Control Transmitter.......................................................... 11
02. On/Stand-by Button
03. Extra Bass Button
04. Video/Auxiliary Button
05. Timer Button....................................................................................41
06. Clock Button ...................................................................................14
07. Tuning Up and Down Buttons .......................................................22
08. Clear/Delete Button ........................................................... 19, 23, 37
09. Cursor/MD Recording Level Selector Buttons ............................ 37
10. Volume Up and Down Buttons
11. Equalizer Mode Selector Button
12. Tuner (Band) Button
13. Sleep Button....................................................................................42
14. CD Open/Close Button
15. Memory/Enter Button
16. Character Input/CD, MD Direct Buttons .......................... 19, 20, 36
17. Symbol/Time Button.................................................................21, 36
18. Dimmer Button ................................................................................ 12
19. MD Play or Pause Button
20. CD/MD Fast Reverse, Track Down Button
21. Recording Mode Selector Button
22. MD Stop Button
23. CD Play or Pause Button
24. CD/MD Fast Forward, Track Up Button
25. CD Stop Button
26. MD Record Button
27. RDS EON Button .......................................................................28, 29
28. RDS Programme Type/Traffic Information Search Button ... 27-29
29. CD/MD Play Mode Selector Button ...............................................20
30. Auto Marker Button ........................................................................44
31. RDS ASPM (Auto Station Programme Memory) Button.............26
32. Display/Character Button
33. Name/TOC Button ........................................................................... 3 6
34. Track Edit Button............................................................................34
Buttons with “✰“ mark in the illustration can be operated on the remote control only.
Other buttons can be operated both on the main unit and the remote control.
8
*MD9000H-E04-09 2001.4.20, 2:51 AM8
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Controls and Indicators (continued)
MD-E9000H
1
2
4
3
■ Speaker System
01. Tweeter
02. Woofer
03. Bass Reflex Duct
04. Speaker Terminals
Make sure nothing comes into contact with the speaker diaphragms when you remove the speaker grilles.
Placing the speaker system:
There is no distinction between the right and the left speakers.
Left speaker Right speaker
■ Speaker connection
Connect the black wire to the minus (-) terminal and the red wire to the plus (+)
terminal.
Red
Black
Caution:
● Connect the speaker wires to the speakers first, then to the unit.
● Use speakers with an impedance of 4 ohms or more, as lower impedance speak-
ers can damage the unit.
● Do not mistake the right and the left channels. The right speaker is the one on the
right side when you face the unit.
● Do not let the bare speaker wires touch each other.
1
2
3
4
5
6
7
8
- Controls and Indicators -
General Information
9
10
11
*MD9000H-E04-09 2001.4.20, 2:51 AM9
Incorrect Incorrect
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
12
9
System Connections
External FM aerial
AM loop aerial
Right
speaker
FM aerial
Left speaker
■ Aerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS socket and position it in the direction
where the strongest signal can be received.
Supplied AM loop aerial:
Connect the AM loop aerial wire to the AM LOOP socket. Position the AM loop aerial
for optimum reception. Place the AM loop aerial on a shelf, etc., or attach it to a stand
or a wall with screws (not supplied).
Note:
Placing the aerial on the unit or near the AC power lead may cause noise pickup.
Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
< Assembling > < Attaching to the wall >
- System Connections -
Preparation for Use
10
*MD9000H-E10-11 2001.4.20, 2:02 AM10
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Wall socket
(AC 230 V, 50 Hz)
Wall
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM aerial wire from the
FM 75 OHMS socket.
Screws (not supplied)
■ Connecting the AC power lead
After checking all the connections have been made correctly, connect the AC power
lead to the AC INPUT socket, then into the wall socket.
Notes:
● Unplug the unit if it will not be used for a prolonged period of time.
● Use only the supplied power lead. Otherwise, a malfunction or an accident may occur.
Remote Control
■ Battery installation
1. Remove the battery cover.
2. Insert the batteries according to the direction indicated in the battery compartment.
When inserting or removing the batteries, push them towards the ë terminals.
3. Replace the cover.
■ Test of the remote control
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy the
music.
MD-E9000H
1
2
3
Precautions for battery use:
● Replace all old batteries with new ones at the same time.
● Do not mix old and new batteries.
● Remove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
● Do not use rechargeable batteries (nickel-cadmium battery, etc.).
● Installing the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
● Replace the batteries if the operating distance is reduced or if the operation be-
comes erratic. Purchase 2 “AAA” size batteries (UM-4, R03, HP-16 or similar).
● Periodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
● Exposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
● Keep the remote control away from moisture, heat, shock, and vibrations.
Remote sensor
0.2 m - 6 m
(8" - 20')
4
5
6
7
8
- Remote Control -
9
Preparation for Use
10
11
12
*MD9000H-E10-11 2001.4.20, 2:02 AM11
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
11
General Control
■ Demonstration mode
The first time the unit is plugged in, the unit will enter the demonstration mode. Y ou will
see words scroll.
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the DISPLAY (DEMO) button. The unit will enter the low power consumption mode.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the DISPLAY (DEMO) button
again.
■ To turn the power on
Press the ON/STAND-BY button.
To set the unit to stand-by mode:
Press the ON/STAND-BY button again.
- General Control -
Basic Operation
12
*MD9000H-E12-14 2001.4.20, 2:05 AM12
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
■ To change the display brightness (2 levels)
You can switch the display brightness by pressing the DIMMER button on the remote
control.
Dimmed Brightened
■ Opening and closing the CD compartment
The CD compartment cover is motorised.
When the power is turned on, you can open or close the CD compartment by pressing
the CD 7 (OPEN/CLOSE) button.
Caution:
● Do not open or close the CD compartment cover manually. It may cause mal-
functions to the unit.
● Be careful not to jam your fingers in the CD compartment cover.
Sound Control
■ Adjusting the volume
Press the VOLUME W button to increase the volume and the VOLUME X button for
decreasing.
MD-E9000H
1
2
0 1 239MAXIMUM
■ Bass control
When the power is first turned on, the unit will enter the extra bass mode which
emphasises the bass frequencies, and “BASS” will appear. To cancel the extra bass
mode, press the X-BASS button.
Bass is emphasised. Cancelled.
The “X-BASS” function is only accessible with the equaliser set to “FLAT”.
■ Equaliser
When the EQUALIZER button is pressed, the current mode setting will be displayed.
To change to a different mode, press the EQUALIZER button repeatedly until the
desired sound mode appears.
The sound is not modified. Bass and treble are emphasised.
Treble is reduced. Vocals (midrange-tones) are
emphasised.
3
4
5
6
7
8
- Sound Control -
9
Basic Operation
10
11
*MD9000H-E12-14 2001.4.20, 2:05 AM13
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
12
13
Setting the Clock
This may be operated only with the remote control.
In this example, the clock is set for the 24-hour (0:00) display.
- Setting the Clock -
1 Press the CLOCK button and within 10 seconds, press the
Basic Operation
MEMORY/ENTER button.
5/35/3
5/3
2 Press the
display and then press the MEMORY/ENTER button.
“0:00” → The 24-hour display will appear.
“AM 0:00” → The 12-hour display will appear.
“AM 12:00” → The 12-hour display will appear.
5/35/3
(0:00 - 23:59)
(AM 0:00 - PM 11:59)
(AM 12:00 - PM 11:59)
or
2/42/4
2/4
2/42/4
button to select 24-hour or 12-hour
5/35/3
5/3
3 Press the
press the MEMORY/ENTER button.
● When the 12-hour display is selected, “AM” will change automatically to
“PM”.
4 Press the
then press the MEMORY/ENTER button.
● The hour will not advance even if minutes advance from “59” to “00”.
● The clock starts from “0” second. (Seconds are not displayed.)
To check the time when the power is on:
Press the CLOCK button.
The time display will appear for about 10 seconds.
Note:
The “0:00” or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock by performing “Setting the Clock” from the beginning.
5/35/3
5/35/3
5/3
5/35/3
or
or
2/42/4
2/4
2/42/4
2/42/4
2/4
2/42/4
button to adjust the hour and then
button to adjust the minutes and
14
*MD9000H-E12-14 2001.4.20, 2:05 AM14
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Listening to a CD
1 Press the ON/STAND-BY button to turn the power on.
2 Press the CD ■ button.
● If no disc is loaded, “CD NO DISC” will appear.
77
7
3 Press the CD
ment.
77
(OPEN/CLOSE) button to open the CD compart-
4 Place a CD on the spindle, label side up.
77
7
77
5 Press the CD
ment.
(OPEN/CLOSE) button to close the CD compart-
Total number of tracks Total playing time
MD-E9000H
1
2
3
4
5
6
7
8
- Listening to a CD -
CD Playback
9
*MD9000H-E15-16 2001.4.20, 2:06 AM15
0606
06
0606
06
0606
0606
button.
button to start playback from track 1.
0606
06
0606
button again.
6 Press the CD
When the last track on the disc has finished, the CD player will stop automatically.
To interrupt playback:
Press the CD
To resume playback from the same point, press the CD
To stop playback:
Press the CD ■ button.
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
10
11
12
15
Listening to a CD (continued)
To remove the CD:
Whilst in the stop mode, press the CD 7 (OPEN/CLOSE) button.
Press the CD eject button and remove the CD.
PUSH
Notes:
● After removing the CD, make sure to press the CD
close the CD compartment.
- Listening to a CD -
CD Playback
● When the unit enters the stand-by mode, the opened CD compartment cover will
be closed automatically.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Caution:
● Do not open or close the CD compartment cover manually. It may cause
malfunctions to the unit.
● Be careful not to jam your fingers in the CD compartment cover.
● If the power fails whilst the compartment is open, wait until the power is restored.
● If a disc is damaged, dirty, or loaded upside down, “CD NO DISC” will appear on
the display.
● Keep foreign objects out of the CD compartment.
● Subjecting the unit to shock or vibration may cause mistracking.
● When the unit is not being used, be sure to close the CD compartment. If it is left
open, the lens may be covered with dust and the unit may not operate properly.
● If TV or radio interference occurs during CD operation, move the unit away from
the TV or radio.
CD Eject Button
7
(OPEN/CLOSE) button and
■ To locate the beginning of a track
To move to the beginning of the next track:
Press the 4 button for less than 0.5 seconds during playback.
● You can skip to any track by pressing the
sired track number appears.
4
button repeatedly until the de-
To restart the track being played:
Press the 5 button for less than 0.5 seconds during playback.
● You can skip to any track by pressing the
sired track number appears.
55
5 button repeatedly until the de-
55
■ To locate the desired portion
For audible fast forward:
Press and hold down the
For audible fast reverse:
Press and hold down the
Notes:
● Normal playback will resume when the
● When the end of the last track is reached during fast forward, “END” will appear
on the display and CD operation will be paused. When the beginning of the first
track is reached during fast reverse, playback will start automatically.
● The
tions.
5/3
or
2/4
44
4
44
button during playback.
55
5
55
button during playback.
5
or 4 button is released.
button on the remote control allows you the same opera-
16
*MD9000H-E15-16 2001.4.20, 2:06 AM16
Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
Loading...
