1. Application
This specification applies to color TFT-LCD module, LQ121S1LG45
These specification sheets are the proprietary product of SHARP CORPORATION(”SHARP) and
include materials
protected under copyright of SHARP. Do not reproduce or cause any third party to reproduce them
in any form or by
any means, electronic or mechanical, for any purpose, in whole or in part, without the express
written permission of
SHARP.
The device listed in these specification sheets was designed and manufactured for use in general
electronic equipment.
In case of using the device for applications such as control and safety equipment for transportation
(aircraft, trains,
automobiles, etc.), rescue and security equipment and various safety related equipment which
require higher
reliability and safety, take into consideration that appropriate measures such as fail-safe functions
and redundant
system design should be taken.
Do not use the device for equipment that requires an extreme level of reliability, such as aerospace
applications,
telecommunication equipment (trunk lines), nuclear power control equipment and medical or other
equipment for life
support.
SHARP assumes no responsibility for any damage resulting from the use of the device which does
not comply with
the instructions and the precautions specified in these specification sheets.
Contact and consult with a SHARP sales representative for any questions about this device.
