Date: Apr. 16, 1993
LASER PRINTER : JX-9600
No. : LPE-145
TROUBLESHOOTING A NOISE FROM THE
COOLING FAN MOTOR
1.Model name: JX-9600 series laser printers.
2.General: To prevent vibration and resonance, the cure is provided in two steps of makeshift and
permanent.
3.Description: 1. Makeshift action
• Employment of 8 O-rings
• Employment of a plastic washer
Mesh sheet
Power supply unit chassis
4.Action: Since December 1992.
O-ring x 8 (new)
Fan motor
Plastic washer (new)
Screw, M3x35
Ozone filter cover
SHARP CORPORATION Printer and Scanner Division
1/3
Orange
C
2. Permanent action
• Discontinued use of 8 O-rings
• Discontinued use of the plastic washer
• Use of a screw with a new length
• Employment of a fan motor sheet
O-ring x 8 (new)
Plastic washer (new)
Screw, M3x35
Power supply unit chassis
Screw lock paint
Power supply chassis
Fan metallic net
Ozone filter cover
Mesh sheet
Fan motor
Screw
Ozone filter cover
Fan motor
Fan motor sheet (new parts)
(PSHEG0093GCZZ)
* When fastening the power supply chassis with the screw, allow it to extend 0 to
0.5mm.
4.Action: Since January 1993.
2/3
Ref.
Model
No.
JX-9600 All
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. C urr e nt t y pe c a n be u s ed i n p la ce of new ty pe .
New ty pe cann ot be us ed i n place of curr ent type .
3. C urre nt ty pe cann ot be used i n place of new ty pe.
New t y pe c a n be u sed in pla c e of c u rr en t ty p e.
Parts m ar ke d wi t h “ ” is i mp ort an t fo r m a inta i ni ng t he sa fe ty of t he s e t. B e su r e to re pl ace these pa r ts wi t h
specified ones for maintaining the safety and performance of the set.
name
Version P/G No.
3 -31
— — PSHEG0093GCZZ AD
!
Current parts New parts
Parts code Parts code
XBPSD30P35000 XBPSD30P32000 AA
Price
rank
5. Interchangeable if replaced with same types of
relate d parts in use .
6. Others.
Parts name
Screw, M3x32
Fan motor sheet
Effective
time
’93/1 3
’93/1 6
Interchangability
Note
3/3
