Sharp LC-42SV49U User Manual

LC-42SV49U

LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL

TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO

OPERATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN

ENGLISHESPAÑOL FRANÇAIS

IMPORTANT : Please read this operation manual before starting operating the equipment.
IMPORTANT : Veuillez lire ce mode d’emploi avant de commencer à utilliser l’appareil.
IMPORTANTE: Lea este manual de operación antes de comenzar a operar el equipo.

LC-42SV49U

1

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

ENGLISH

IMPORTANT:
To aid reporting in case of loss or theft, please
record the TV's model and serial numbers in the
space provided. The numbers are located at the
rear of the TV.

Model No.:

Serial No.:

IMPORTANT INFORMATION

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning flash with arrow-head

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

symbol,within an equilateral triangle,is
intended to alert the user to the presence

of uninsulated“dangerous voltage“within
the product’s enclosure that may be of

sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a triangle
presence of important operating and
maintenance(servicing)instruction in the
literature accompanying the product .

IMPORTANT INFORMATION

2

CAUTION: TO PREVENT ELECTRIC SHOCK,MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.

WARNING: FCC Regulations state that any unauthorized changes or modifications to this
equipment not expressly approved by the manufacturer could void the user’s authority to operate
this equipment.

CAUTION:

This product satisfies FCC regulations when shielded cables and connectors are used to connect
the unit to other equipment. To prevent electromagnetic interference with electric appliances such
as radios and televisions, use shielded cables and connectors for connections.

This product utilizes fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental consider ations.
For disposal or recycling information,please contact your local authorities, the
Electronic Industries Alliance:www.eiae.org,the lamp recycling organization:

www.lamprecycle.org or Sharp at 1-800-BE-SHARP (For U.S.A only)

DECLARATION OF CONFORMITY:

SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-42SV49U
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:

For Business Customers: URL http://www.sharpusa.com

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

— Consult the dealer or an experienced radio/TV technician for help.

Note to CATV system installer: This reminder is provided to call the CATV system installer’s
attention to Article 820 of the National Electrical Code that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.

This product qualifies for ENERGY STAR when “Home” is selected for “Location”.

Setting “Location” to “Home” allows the TV to achieve an energy-saving status for household

use.

SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
TEL: 1-800-BE-SHARP

TRADEMARKS

HDMI,the HDMI logo,and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.

Manufactured under license from Dolby Laboratories.Dolby and the double-D
symbol are trademarks of Dolby Laboratories.

Products that have earned the ENERGY STAR are designed to protect the
enviroment through superior energy efficiency.

DEAR SHARP CUSTOMER

3

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure
safety and many years of trouble-free operation of your product, please read the
Important Safety Instructions carefully before using this product.

IMPORTANT SAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and
property damage if improperly handled. This product has been engineered and manufactured
with the highest priority on safety. However, improper use can result in electric shock and/or fire.
In order to prevent potential danger, please observe the following instructions when installing,
operating and cleaning the product. To ensure your safety and prolong the service life of your
Liquid Crystal Television, please read the following precautions carefully before using the product.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions..

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.

9) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

10) Only use attachments/accessories specified by the manufacturer.

11) Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.

12) Unplug this apparatus during lightning storms or when unused for long periods of

time.

13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

Additional Safety Information

14) Power Sources—This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your home, consult your
product dealer or local power company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.

15) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles
as this can result in a risk of fire or electric shock.

16) Object and Liquid Entry—Never push objects of any kind into this product through openings as
they may touch dangerous voltage points or short-out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the product.

IMPORTANT SAFETY INSTRUCTIONS

17) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.

Adjust only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the product to its normal operation,

e) If the product has been dropped or damaged in any way, and
f ) When the product exhibits a distinct change in performance - this indicates a need for service.

18) Replacement Parts—When replacement parts are required, be sure the service technician has

used replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

19) Safety Check—Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operating
condition.

20) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.

CAUTION

These servicing instructions are for use by qualified service personnel only. To reduce the

risk of electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.

Outdoor Antenna Grounding — If an outside

antenna is connected to the television
equipment, be sure the antenna system is
grounded so as to provide some protection

EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA
LEAD IN WIRE

against voltage surges and built-up static
charges.
Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with
regard to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna discharge unit,
size of grounding conductors, location
of antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode.

ELECTRIC
SERVICE
EQUIPMENT

GROUND
CLAMP

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING
CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)

NEC — NATIONAL ELECTRICAL CODE

Warning statement indicating that Class I apparatus shall be connected to a mains socket

outlet with a protective earthing connection.

Statement indicating that when the mains plug or appliance coupler shall remain readily

operable.

Where the MAINS plug or an appliance coupler is used as the disconnect device, the

disconnect device shall remain readily operable.

Where an all-pole MAINS SWITCH is used as the disconnect device, the location on the

apparatus and the function of the switch shall be described, and the switch shall remain readily
operable.

4

IMPORTANT SAFETY INSTRUCTIONS

Water and Moisture — Do not use this product near water - for example, near a bath tub, wash •

bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the •

product on an unstable base can cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product
on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware

recommended by the manufacturer.
Selecting the location — Select a place with no direct sunlight and good ventilation.•
Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not •

cover or block these vents and openings since insufficient ventilation can cause overheating

and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other

similar surface, since they can block ventilation openings. This product is not designed for

built-in installation; do not place the product in an enclosed place such as a bookcase or rack,

unless proper ventilation is provided or the manufacturer’s instructions are followed.

The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the •

product is dropped or applied with impact. Be careful not to be injured by broken glass pieces

in case the panel breaks.
Heat — The product should be situated away from heat sources such as radiators, heat •

registers, stoves, or other products (including amplifiers) that produce heat.
The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, •

giving you fine picture details.

Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green

or red. Please note that this does not affect the performance of your product.
Lightning — For added protection for this television equipment during a lightning storm, or •

when it is left unattended and unused for long periods of time, unplug it from the wall outlet and

disconnect the antenna. This will prevent damage to the equipment due to lightning and power-

line surges.
Power Lines — An outside antenna system should not be located in the vicinity of overhead •

power lines or other electric light or power circuits, or where it can fall into such power lines or

circuits. When installing an outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be fatal.
To prevent fire, never place any type of candle or flames on the top or near the TV set. •
To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy •

items.
Do not display a still picture for a long time, as this could cause an afterimage to remain.•
To prevent fire or shock hazard, do not expose this product to dripping or •

splashing.

No objects filled with liquids, such as vases, should be placed on the

product.
Do not insert foreign objects into the product. Inserting objects in the air •

vents or other openings may result in fire or electric shock. Exercise special

caution when using the product around children.

Precautions when transporting the TV

When transporting the TV, never carry it by holding or otherwise putting pressure onto the •

display. Be sure to always carry the TV by two people holding it with two hands — one hand on

each side of the TV.

5

IMPORTANT SAFETY INSTRUCTIONS

6

Caring for the Cabinet

Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.•
Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main •

unit cabinet or cause cracking.
Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.•
If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral •

detergent diluted with water and thoroughly wrung out, and then wipe with a soft dry cloth.
The cabinet is primarily made of plastic. Avoid using benzene, thinner, and other solvents, as •

these may deform the cabinet and cause the paint to peel off.
Do not apply insecticides or other volatile liquids. •

Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long

period of time. Plasticizers inside the plastic may cause the cabinet to deform and cause the

paint to peel off.

Caring for the Liquid Crystal panel

Turn off the main power and unplug the AC cord from the wall outlet before handling.•
Gently wipe the surface of the display panel with a soft cloth (cotton, flannel, etc.). •

To protect the display panel, do not use a dirty cloth, liquid cleaners,

or a chemical cloth (wet/ dry sheet type cloth, etc.). This may damage

the surface of the display panel.
Wiping with a hard cloth or using strong force may scratch the surface •

of the display panel.
Use a soft damp cloth to gently wipe the display panel when it is really •

dirty. (It may scratch the surface of the display panel when wiped

strongly.)
If the display panel is dusty, use an anti-static brush, which is commercially available, to clean it.•
To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved •

cleaning cloths are available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-

CLOTH-3) packs.

Call 1-800-BE-SHARP for ordering, or VISIT http://www.sharpusa.com/SharpDirect.

IMPORTANT SAFETY INSTRUCTIONS

CHILD SAFETY

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips
in mind:

THE ISSUE

The home theater entertainment experience is a growing trend and larger •
flat panel displays are popular purchases. However, flat panel displays are
not always supported on the proper stands or installed according to the

manufacturer’s recommendations.

Flat panel displays that are inappropriately situated on dressers, bookcases, •
shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

The consumer electronics industry is committed to making home •
entertainment enjoyable and safe.

TUNE INTO SAFETY

One size does NOT fit all. Follow the manufacturer’s recommendations for •

the safe installation and use of your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this •

product.

Don’t allow children to climb on or play with furniture and television sets.•
Don’t place flat panel displays on furniture that can easily be used as steps, •

such as a chest of drawers.
Remember that children can become excited while watching a program, •

especially on a “larger than life” flat panel display. Care should be taken

to place or install the display where it cannot be pushed, pulled over, or
knocked down.

Care should be taken to route all cords and cables connected to the flat•
panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY,
ALWAYS:

Use a mount that has been recommended by the display manufacturer and/or listed by an •
independent laboratory (such as UL, CSA, ETL).

Follow all instructions supplied by the display and wall mount manufacturers.•
If you have any doubts about your ability to safely install your flat panel display, contact your retailer •

about professional installation.
Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not •

designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure,
contact a professional installer.

A minimum of two people are required for installation. Flat panel displays can be heavy.•

Note: CEA is the preeminent trade association promoting growth in
the $161 billion U.S. consumer electronics industry. More than 2,200
companies enjoy the benefits of CEA membership, including legislative
advocacy, market research, technical training and education, industry
promotion and the fostering of business and strategic relationships.

7

8

QUICK REFERENCE

Supplied Accessories

Make sure the following accessories are provided with the product.

Remote control unit

(

X1)

Page 11

x4

Stand (

with Screws

X1)

Page 8

Always use the AC cord supplied with the TV.•
The illustrations above are for explanation purposes and may vary slightly from the •

actual accessories.

Attaching/Detaching the Stand

Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT •
terminal.

Before performing work spread cushioning over the base area to lay the TV on. This will •
prevent it from being damaged.

CAUTION

Attach the stand in the correct direction.•
Be sure to follow the instructions. Incorrect installation of the stand may result •

in the TV falling over.

Put the TV face down on a safe surface that is covered by a soft and smooth cloth.1.
Adjust the TV stand to the bottom of the TV.2.
Fasten the screws by using a cross-head screwdriver (Not supplied).3.

“AAA” size battery

(

X2)

Page 13

Operation manual

(

X1)

AC cord

(

X1)

Page 10

CAUTION

Do not push too hard or put excessive pressure •
to the stand neck to avoid the damages when
you turn the TV for the most comfortable
viewing angle.

To detach the stand, perform the steps in reverse •
order.

2

3

QUICK REFERENCE

9

Detaching the stand neck for wall mounting

CAUTION

Please use care when disassembling cabinet, stand, and pillar for wall •
mounting.

Detach the stand neck in the correct direction.•
Do not remove the stand neck from the TV unless using an optional wall mount •

bracket to mount it.

Loosen the 4 screws that secure the stand neck by using a cross-head screwdriver. 1.
Remove stand cover from the TV set.

Stand Cover

To attach the stand neck, perform the steps in reverse order.•
Do not force or overtighten and do not install without stand covers.•

QUICK REFERENCE

10

Quick Installation Tips

Attach your antenna to the back of the

1

television. (See page 12.)
Connect the AC plug for the television

2

into the AC outlet.

Place the TV close to the AC outlet, and •
keep the power plug within reach.

This product must only be connected to •
a 120V, 60Hz AC outlet.
Connecting it to any other kind of outlet
will damage the product and invalidate
the warranty.

AC outlet

How to turn on the television for the first

3

time.
A) Press POWER on the television.
B) The POWER indicator on the front

of the television lights off.

CH

+

VOL

MENU

INPUT

POWER

POWER

Speakers cannot be detached from the •
TV.

POWER indicator

TO PREVENT RISK OF ELECTRIC •
SHOCK, DO NOT TOUCH UN­INSULATED PARTS OF ANY
CABLES WITH THE AC CORD
CONNECTED.

Insert the batteries into the remote control

4

unit.(See page 13.)

QUICK REFERENCE

11

Using the Remote Control Unit

Use the remote control unit by pointing it towards the remote control sensor on the TV.
Objects between the remote control unit and the remote control sensor may prevent
proper operation.

Cautions regarding the remote

■

control unit

Do not expose the remote control unit •
to shock. In addition, do not expose the
remote control unit to liquids, and do
not place in an area with high humidity.

Do not install or place the remote control•
unit under direct sunlight. The heat may
cause deformation of the remote control
unit.

The remote control unit may not work •
properly if the remote control sensor on
the TV is under direct sunlight or strong
lighting. In such cases, change the angle
of the lighting or the TV, or operate the
remote control unit closer to the remote
control sensor.

T
U
P
N
I

6

2

9

5

K

T

C

N

A

E

B
H
S

8

A
L
F

4

O
I
D

0

U
A

7

E
Z
E
E

H

R

E

F

T

C

U

Y

M
A
L

U

P

D

N
S
I

N

E

D

U

M

O

R
R
U
S

C
P

+

L

B

O

S

V

U

V
T

D

E
D
O

H

M

C

V

E

A

T

E

I

C

D

R

O

O

M

V

W

A
F

E
I
V

B

C
C

A

P
E
E
L
S

V
T

1

D

2

C

2
L
J
G

I
N
P

4

U

2

T

7

5

D

8

I
S

6

P
L

A
Y
F

R

0

E

9

E
Z
E

A
U

E

D

+

I

N

O

T

M

F

V

L

U

A

T

O

S

E

H

L

B
A

C

K
S
U
R

T

R

V

O
U
N

D
U
S
B

C

H

P
C

M

E
N
U

A

S

F
A

L
E

V

E

O

P

R
I

B

T
E

C

C

H

C

C

V
I
E
W

M
O
D
E

D

A
V
M

O
D
E

L

C
D
T

G

V
J
2
2
1

4

7

2

D

I

I

N

S

P

5

P

U

LA

T

Y

8

F
R
E

+

E

0

Z

6

V

E

O

A

L

9

U

M

D

U

I

T

O

T

E

V

E

N

S

F

T

U

L

R

A

R

S
H

O

U

B

U

A

S

N

C

B

D

K

P

C

C

H

M
E
N

U

A

S
L
E
E

F

P

A
V

B

O
R

C

I
T

C

E
C
H

V

C

I
E

W
M
O
D
E
A

D

V
M
O
D
E

L
C
D
G
T
J
V
2
2
1

POWER

indicator

0º

45º (4m)
Horizontal only

30º (5m)
Horizontal & Vertical

INPUT

2

Remote Control
sensor

(8 m)

IMPORTANT:

If the POWER indicator light on the television still does not turn off, press POWER on the remote control
to turn the power on.

IMPORTANT:

IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND
REPEAT THE INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.

Preparation

12

Antennas

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of
the types of connections that are used for a coaxial cable. If your outdoor antenna uses
a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the
rear of the TV set.

A 75-ohm system is generally a round 1.
cable with F-type connector that can
easily be attached to a terminal without
tools (Commercially available).

A 300-ohm system is a flat “twin-lead” 2.

cable that can be attached to a 75-ohm
terminal through a 300/75-ohm adapter
(Commercially available).

When connecting the RF cable to the TV set,
do not tighten F-type connector with tools.
If tools are used, it may cause damage to
your TV set. (The breaking of internal circuit,
etc.)

Connecting Antenna

Connect the antenna cable to the TV using one of the methods in the illustration as •
shown ( , , or ).

1 2 3 4

Cable without a CATV converter1

Cable TV lead-In

VHF/UHF antenna2

75-ohm coaxial cable (round)

Combination VHF/UHF antenna3

Home Antenna
terminal (75-ohm)

Coaxial cable
(commercially available)

Home Antenna
terminal (75-ohm)

Coaxial cable
(commercially available)

F-type connector

75-ohm coaxial cable
(round)

300-ohm twin-lead cable (flat)

F-type connector

75-ohm coaxial cable

75-ohm coaxial cable (round)

300-ohm twin-lead cable (flat)

Separate VHF/UHF antenna4

VHF

UHF

ANTENNA

ANTENNA

or

300-ohm
twin-lead cable

300-ohm twin-lead cable

75-ohm coaxial cable

or

300/75-ohm adapter

(commercially available)

IN OUT

Combiner
(commercially available)

To TV antenna terminal

Preparation

13

Installing Batteries in the Remote Control Unit

If the remote control fails to operate TV functions, replace the batteries in the remote
control unit.

1 Open the battery cover.

2 Insert two “AAA” size batteries (supplied

with the product).

Place the batteries with their terminals •
corresponding to the ( ) and ( )
indications in the battery compartment.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow
the instructions below.

Do not mix batteries of different types. Different types of batteries have different •
characteristics.

Do not mix old and new batteries. Mixing old and new batteries can shorten the life of •
new batteries or cause chemical leakage in old batteries.

Remove batteries as soon as they are worn out. Chemicals that leak from batteries •
come in contact with skin can cause a rash. If you find any chemical leakage, wipe
thoroughly with a cloth.

The batteries supplied with this product may have a shorter life expectancy due to •
storage conditions.

If you will not be using the remote control unit for an extended period of time, remove •
batteries from it.

The batteries (batteries installed) shall not be exposed to excessive heat such as •
sunshine, fire or the like.

3 Close the battery cover.

Contents

14

IMPORTANT INFORMATION ...................................................................................... 1

TRADEMARKS............................................................................................................. 2

IMPORTANT SAFETY INSTRUCTIONS...................................................................... 3

QUICK REFERENCE.................................................................................................... 8

Supplied Accessories .............................................................................................. 8

Attaching/Detaching the Stand ................................................................................ 8

Detaching the stand neck for wall mounting............................................................. 9

Quick Installation Tips ............................................................................................ 10

Using the Remote Control Unit .............................................................................. 11

Antennas ............................................................................................................... 12

Connecting Antenna Cable .................................................................................... 12

Installing Batteries in the Remote Control Unit........................................................ 13

Contents..................................................................................................................... 14

Part Names ................................................................................................................ 15

TV (Front)............................................................................................................... 15

TV (Side/Rear) ........................................................................................................ 15

Remote Control Unit .............................................................................................. 16

Introduction to Connectionst ................................................................................... 17

Watching TV............................................................................................................... 23

Turning On/Off the Power...................................................................................... 23

Initial Setup............................................................................................................ 23

Direct Button Operation ............................................................................................ 25

On-Screen Display Menu.......................................................................................... 29

Menu Items ............................................................................................................ 29

On-Screen Display Menu Operation....................................................................... 30

Menu Operation Button ......................................................................................... 31

Video Menu ........................................................................................................... 31

Audio Menu ........................................................................................................... 33

TV Menu................................................................................................................ 34

Setup Menu........................................................................................................... 35

Parental Menu ....................................................................................................... 37

USB ...................................................................................................................... 41

Appendix .................................................................................................................... 44

Troubleshooting..................................................................................................... 44

Specifications ........................................................................................................ 45

PC Compatibility Chart .......................................................................................... 46

RS232 Port Specifications ..................................................................................... 47

Information on the Software License for This Product ............................................ 48

Legal notices ......................................................................................................... 49

Calling for Service ..................................................................................................... 50

LIMITED WARRANTY................................................................................................ 50

Dimensional Drawings

The dimensional drawings for the LCD TV set are shown on the inside back cover.•

Part Names

15

TV (Front)

TV (Side/Rear)

POWER indicator

Remote control sensor

Light sensor

*2

Channel

CH

VOL

MENU

INPUT

POWER

buttons
(CH/)

Volume

+

buttons

_

)

(VOL+/

MENU

button

INPUT

button

POWER

button

AC IN

Y

Y PB

PB PR

*3

L- AUDIO -R

PR L- AUDIO -R

*1: See pages 19, 20, 21 and 22 for external equipment connection.
*2: See page 18 ,23,25 and 31 for button operations.
*3: See page 10 for connecting the AC cord.

VIDEO

RS-232C
IOIOI

HEAD
PHONE

INPUT 1

INPUT 2

USB

L- AUDIO -R

HEAD PHONE
INPUT 1

terminal (HDMI)
INPUT 2
terminal (HDMI)

USB

DIGITAL AUDIO

*1

*1

The illustrations in this operation manual are for explanation purposes and may vary slightly from •
the actual operations.

Part Names

16

Remote Control Unit

POWER

16

1

4

7

17

DISP LAY FRE EZE

18
19

+

VOL CH

20
21

TV USBPCMENU

22
23

24

A B C D

SLE EP C C VIEWMODEAV MODE

25
26

When using the remote control unit, •
point it at the TV.

1

INPUT: Select a TV input source.

(See page 25.)

2 0–9: Set the channel.

ENT: Jumps to a channel after selecting

3

with the 0–9 buttons.

4

FLASHBACK: Press to switch to the

previously tuned channel or external input
mode. Press again to switch back to the
currently tuned channel or external input
mode.

5

AUDIO: Display the MTS/SAP setting

menu. (See page 26-27.)

2

5

8

0

MUTE

SURR OUND

ENTER

FAVO RITE C H

LCDTV

GJ221

INPUT

1

3

6

2

9

ENT

3

FLASHBACK

AUDIO

4
5
6
7

8
9

10

NRUTERTIXE

11

12
13

14
15

MUTE: Mute the sound. (See page 25.)

6
7

CH / : Select the channel.

(See page 25.)

8

MENU: Display the menu screen.
PC: Direct switch PC source.

9
10

/ /

/

, ENTER: Select a desired item

on the screen. (See page 31.)

11

RETURN: Return to the previous menu

screen.

12

FAVORITE CH:

A, B, C, D: Select 4 preset favorite channels
in 4 different categories. (See page 34 for
details.) While watching, you can toggle the
selected channels by pressing A, B, C and D.

AV MODE: Select an adjusted picture

13

settings. (Standard, Movie, Power Saver
User, Dynamic) (See page 26.)

VIEW MODE: Select the Picture Mode.

14

(See page 28.)

15

POWER: Switch the power on or enters

16

:Only for USB .

standby mode. (See page 19.)

• (DOT): (See page 25.)

17

DISPLAY: Display the current channel

18

(or input source) information on the screen.

19

FREEZE: Set the still image. Press again to

return to normal screen.

20

VOL / : Set the volume. (See page 25.)

21

SURROUND: Display the surround setting

menu. (See page 26.)

TV: Direct switch TV source.

22

USB: Direct switch USB source.

23
24

EXIT: Turn off the menu screen.

SLEEP: Allows you to set a time when the 25

TV automatically switches to standby. This
display will disappear after a few seconds,
and the sleep timer automatically starts
counting down. (See page 25.)

26

CC: Display captions during closed-caption

source.(See page 27.)

Introduction to Connections

17

Experiencing HD Images

An HDTV without an HD source is just an ordinary TV.
To enjoy HD images on the TV, you should get HD programming from the following:

Over-the-air broadcasting via HD quality antenna

•
HD cable/satellite subscription

•
HD compatible external equipment

•

For information on updating to HD programming, ask your cable/satellite service provider.

•

Types of Connection

Image quality differs depending on the terminal used. To enjoy clearer images, check the
output terminals of your external equipment and use its appropriate terminals for higher

quality images.

For connecting the TV to external equipment, use commercially available cables.

•

The illustrations of the terminals are for explanation purposes and may vary slightly from the actual
products.


Quality

HD

Quality

Standard

Quality

Terminal on external

equipment

AUDIO

DVI OUT

Cable

HDMI-certified cable

Ø 3.5 mm stereo minijack cable

DVI-HDMI conversion cable

Component video cable(commercially
available)

Audio cable(commercially available)

AV cable (commercially available)

Terminal

on the TV

INPUT 1, 2, 3, 4

INPUT 1, 2, 3, 4

INPUT 5, 6

(COMPONENT)

Y

PB PR

Y PB

INPUT 7

VIDEO

L- AUDIO -R

PR L- AUDIO -R

L- AUDIO -R

Page

Page

Page

Page

9

1

19

20

20

18

Connecting to External Equipment

Displaying an External Equipment Image Display

To view external source images, select the input source by pressing INPUT on the
remote control unit or on the TV.

ExampleExample

<

CH

<

+

VOL

-

MENU

INPUT

POWER

Press INPUT.

1

•

The CH List screen displays.

Press / to select the input source.

2

•

You can also select the input source by pressing INPUT. Each time INPUT is

INPUT

POWER

1

2

4

5

7

8

0

AUDIO

DISP LAY FREE ZE

MUTE

+

SURRO UND

VOL CH

TV U SBPCMENU

ENTER

INPUT

3

6

9

ENT

FLASHBACK

NRUTERTIXE

pressed, the input source toggles.

INPUT1 INPUT2 INPUT3

INPUT7TV

•

An image from the selected source automatically displays.

TV

INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
PC IN
USB

Input

HDMI1
HDMI2
HDMI3
HDMI4
COMP1
COMP2
AV

19

Connecting to External Equipment

You can connect many types of external equipment to your TV. To view external source
images, select the input source from INPUT on the remote control unit or on the TV.
(See pages 18 and 25.)For connecting the TV to external equipment, use commercially
available cables.

CAUTION

• To protect equipment, always turn off the TV before connecting any external equipment.

• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making

connections.

Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box

When using HDMI cable (INPUT 1, 2, 3 or 4):

The HDMI (High Definition Multimedia Interface) terminal is an audio-video interface that enables a
connection for audio and video signals using a single cable. The HDMI terminal supports high-resolution
video input.

• Blu-ray disc player • DVD player

• HD cable/satellite set-top box

HDMI-certified cable

HDMI OUT

Back and side panel
inputs

INPUT 1

INPUT 1

INPUT 2

terminal (HDMI)
INPUT 2
terminal (HDMI)

USB

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certified cable

or a component cable and set the equipment to 1080p output.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

When using DVI-HDMI conversion cable (INPUT 1,2,3,4):

Blu-ray disc player •DVD player

•

• HD cable/satellite set-top box

Back panel
vertical inputs

Ø 3.5 mm stereo minijack cable

DVI-HDMI conversion cable

AUDIO DVI OUT

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this

case, in addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3,4 (HDMI) terminal,
connect a Ø 3.5 mm stereo minijack cable to the AUDIO PC/HDMI terminal

.

.

20

Connecting to External Equipment

When using Component cable (INPUT 5,6):

Blu-ray disc player •DVD player

•

• HD cable/satellite set-top box

Audio cable

Audio cable

Component video cable

Component video cable

(Red)

(Red)

P

P

R

R

P

P

(Blue)

(Blue)

B

B

Y (Green)

Y (Green)

AUDIO-L (White)
AUDIO-R (Red)

COMPONENT OUT

COMPONENT OUT

Y

Y PB

Back panel

Back panel
horizontal inputs

horizontal inputs

PB PR

L- AUDIO -R

PR L- AUDIO -R

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certifi ed cable or a
component cable and set the equipment to 1080p output.

• See page 19 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the

HDMI terminal.

Connecting a Game Console, VCR, Camcorder or Cable/Satellite Set-top Box

When using Composite cable (INPUT 7):

Game console

•

Camcorder

•

VCR

•

• Cable/Satellite set-top box

Back panel

Back panel
vertical inputs

vertical inputs

VIDEO

VIDEO

L- AUDIO -R

L- AUDIO -R

21

Connecting to External Equipment

Connecting an Audio Amplifier

When using coaxial cable:

It is possible to output audio through the DIGITAL AUDIO terminal. PCM audio outputs
from the terminal.

Back panel

vertical inputs

Optical fiber cable

OPTICAL

DIGITAL AUDIO INPUT

• Digital Audio output is not available when using an HDMI input.

Connecting an AV Amplifier

HD Cable/Satellite set-top box

HDMI-certified cable

HDMI OUT

HDMIINHDMI

OUT

VIDEO

L- AUDIO -R

Back panel

vertical inputs

OIDUALATIGG ID

INPUT 1

INPUT 2

USB

• If the image is not in sync with the audio, check the settings of the connected
surround system.

• Letting the TV output the audio to an AV amplifier:

22

Connecting to External Equipment

Connecting a PC

Refer to page 46 for a list of PC signals compatible with the TV.

When using HDMI cable (INPUT 1, 2, 3 or 4):

HDMI-certified cable

HDMI OUT

The HDMI terminals only support digital signal.

•

When using DVI-HDMI conversion cable (INPUT 1,2,3,4):

Ø 3.5 mm stereo minijack cable

AUDIO

DVI OUT

DVI-HDMI conversion cable

Side panel
vertical inputs

Back panel
vertical inputs

INPUT 1

INPUT 2

USB

INPUT 1
terminal (HDMI)
INPUT 2
terminal (HDMI)

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case,
in addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3,4 (HDMI) terminal, connect

Ø 3.5 mm stereo minijack cable

to the AUDIO PC/HDMI terminal.

When using analog RGB cable (PC IN):

Back panel
vertical inputs

Analog RGB cable

(D-sub 15-pin cable or VGA cable)

Ø 3.5 mm stereo minijack cable

AUDIORGB

• When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of PC IN.

a

Watching TV

23

Turning On/Off the Power

Press POWER on the TV, or POWER on the remote
control unit to turn the power on.

<

CH

<

+

VOL

-

MENU

INPUT

POWER

POWER

INPUT

1

3

2

POWER

Initial Setup

When you turn on the TV for the first time,
the Initial Setup will guide you through
the setup process. Perform the following
steps before you press POWER on the
remote control unit.

Insert the batteries into the remote 1.
control unit. (See page 13.)

Connect the antenna cable to the TV. 2.
(See page 12.)

Plug in the AC cord to the AC outlet. 3

.

(See page 10.)

POWER indicator : Power on,nothing;Power off,red. •

Press POWER on the TV, or POWER on the remote
control unit again to turn the power off.

The TV enters standby and the image on the screen •
disappears.

• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.

• Small amount of electric power is still consumed even when
the TV is turned off.

• Ifthere is no signal input for 5 minutes, the power will turn to
standby mode automatically.

Initial Setup1.

The Initial Setup screen display at •
the first use. Press ENTER to start
the initial setup.

Initial Setup

Thank you for your purchase of our
SHARP Liquid Crystal Television.

Please press [ENTER] to start the
wizard.

Welcome

TV USB

ENTER

PC

ME NU

Language setting2.

Select the OSD menu language •
from English, Spanish, or French.

Press ▲ / ▼ to select the desired •
language listed on the screen, and

NRUTERTIXE

then press the ► button to the
next step.

English

Españpl
Français

Language

Return Exit

Initial Setup

Please select your Language:

< Back Select >Next

Watching TV

24

3. Location setting

Press ▲ / ▼ to select “Home” or •
“Store” and press ► to the next
step.

Initial Setup

Select where the TV will be placed.
The picture will be optimized for
that location. This product
qualifies for ENERGY STAR in
Home mode default setting.

< Back Select >Next

4. Time Zone setting

Press ▲ / ▼ to select your current •
location for time zone.

Initial Setup

Please select your time zone:

< Back Select >Next

5. Tuner setting

Make sure what kind of connection •
is made with your TV when
selecting “Air” or “Cable”.

Press ▲ / ▼ to select “Air” or •
“Cable” and press ► to the next
step.

Initial Setup

Please select your tuner mode:

Location

Home

Store

Return

Time Zone

Eastem Time

Indiana

Central Time

Mountain Time

Arizona

Pacific Time

Alaska

Hawaii

Return

Air

Cable

Tuner

7. Start channel searching

Wait until the channel scan to •
complete.

If you press • RETURN, the process
will return to the previous step.

If you skip this step, the channel •
search can be performed in the TV
Menu. (See page 34.)

Initial Setup

The channel scan may take a while to

Exit

complete.

Status: Scanning...
Analog Channels: 0
Digital Channels: 0

12%

Channel Scan

Return

Cancel

8. Initial setup completed

Press• ENTER to exit the setup
wizard.

Initial Setup

Exit

Congratulations!!

Completed Initial Setup.

Please press [ENTER] to exit the
wizard.

< Back

Complete

< Back Select >Next

6. Channel scan setting

Press ▲ / ▼ to select “Scan” or •
“Skip Scan” and press ► to continue.

Initial Setup

First,please connect cable and/or
antenna.

Start channel scan now?

If you skip this step,the channel
scan could be performed in Menu.

< Back Select >Next

Skip Scan

0%

Return

Channel Scan

Scan

Return

Exit

Auto programming may take 20+ •
minutes to complete. Please wait
until you see the Auto programming
complete message. The TV will then
switch automatically to the first channel

Exit

found.

Direct Button Operation

25

POWER

DISP LAY FREE ZE

1

2

4

5

7

8

0

FLASHBACK

AUDIO

MUTE

+

SURRO UND

VOL CH

TV U SBPCMENU

INPUT

3

6

9

ENT

ENTER

FAVORI TE CH

A B C D

SLEE P CC VIEWMODEAV MODE

LCDTV

GJ221

NRUTERTIXE

Changing Channels

You can change channels by pressing

CH / or 0-9, or • (DOT).

Examples:
To select a 1 or 2-digit channel number

(e. g., Channel 5):
Press 5 ENT.

To select a 3-digit channel number

(e. g., Channel 115):
Press 1 1 5 ENT.

To select a 4-digit channel number

(e. g., Channel 22.1):
Press 2 2 • (DOT) 1
ENT.

When selecting a 1-digit channel •
number, it is not necessary to press 0
before the number.

Changing Volume

You can change the volume by pressing
VOL / on the TV or on the remote
control unit.

To increase the volume, press •
VOL .

To decrease the volume, press •

VOL .

INPUT

To view external source images, select the
input

source using INPUT on the remote

control unit or INPUT on the TV.

Press

A list of selectable sources •
appears.

Press
source.

INPUT.

INPUT

again to select the input 2.

1.

An image from the selected source •
automatically displays.

Each time • INPUT is pressed, the
input source toggles.

If you press ▲ / ▼ to select the •
input source, press ENTER to
confirm your selection.

• See page 19-22 for external equipment
connection.

MUTE

Mutes the current sound output.
Press MUTE.

Mute can be canceled by using the •
method below.

- Mute will be canceled if you press

VOL + / - or MUTE.

SLEEP

Allows you to set a time when the TV
automatically switches to standby.

Press SLEEP.

The remaining time displays when •
the sleep timer has been set.

Each time you press • SLEEP, the
remaining time switches as shown
below.
Off, 10, 20, 30, 40, 50, 60, 90, 120

When set, the time automatically •
starts counting down.

If you want to adjust the sleep •
timer, you can press SLEEP twice
then change the time setting.

Select "Off" by pressing SLEEP to •
cancel the sleep timer.

The TV will enter standby mode (power •
indicator lights red) when the remaining
time reaches zero.

Direct Button Operation

26

FLASHBACK

Press FLASHBACK to switch to the
previously tuned channel or input.

Press• FLASHBACK again to
switch back to the currently tuned
channel or input.

SURROUND

The surround function produces Surround
effect from the speakers. Each time you
press SURROUND, the mode changes
between On and Off.

• On: Makes it possible to enjoy

natural, realistic surround sound.

• Off: Outputs the normal sound.

You can have the same settings by •

choosing “Surround” on the menu

items. (See page 33.)

FREEZE

Allows you to capture and freeze a moving
image that you are watching.

Press FREEZE.

A moving image is captured.•
Press• FREEZE again to cancel the

function

AV MODE

AV MODE gives you several viewing
options to choose from to best match
the surrounding environment of the TV,
which can vary due to factors like room
brightness, type of program watched
or the type of image input from external
equipment.

Press AV MODE. Current AV MODE
displays.

Press• AV MODE again before the
mode displayed on the screen
disappears.

AUDIO

MTS/SAP stereo mode

■

The TV has a feature that allows reception
of sound other than the main audio for
the program. This feature is called Multi­channel Television Sound (MTS). The TV
with MTS can receive mono sound, stereo
sound and Secondary Audio Programs
(SAP). The SAP feature allows a TV
station to broadcast other information,
which could be audio in another language
or something completely different like
weather information.

You can enjoy Hi-Fi stereo sound or SAP
broadcasts when available.

Stereo broadcasts: View programs •

like live sporting events, shows and
concerts in dynamic stereo sound.

SAP broadcasts: Receive TV •
broadcasts in either MAIN or SAP
sound.

MAIN sound: The normal program
soundtrack (either in mono or stereo).
SAP sound: Listen to a second language,
supplementary commentary or other
information. (SAP is mono sound.)

If stereo sound is difficult to hear.

Obtain a clearer sound by manually •
switching to fixed mono-sound mode.

You can change MTS as shown below to
match the television broadcast signal.

Press AUDIO to toggle between audio
modes.

Examples: when receiving MTS and SAP

MAIN + SAP mode: MAIN SAP
MONO mode: MONO

Direct Button Operation

27

Digital broadcasting audio mode

■

The types of audio transmitted in a digital
broadcast include SURROUND as well as
MONO and STEREO. In addition, it is possible
for multiple audio tracks to accompany a single
video track.

Press MTS/SAP to toggle between audio
modes.

Example: when receiving Digital
broadcasting

STEREO (Audio1) STEREO (Audio2)
SURROUND (Audio3)

MTS only operates while in TV mode.

Closed Captions (CC)

Your TV is equipped with an internal
Closed Caption decoder. It allows you
to view conversations, narration and
sound effects as subtitles on your TV.
Closed Captions are available on some TV
programs and on some VHS home video
tapes at the discretion of the program
provider.

Digital Closed Caption service is a new
caption service available only on digital
TV programs (also at the discretion of

the service provider). It is a more flexible

system than the original Closed Caption
system, because it allows for a variety of
caption sizes and font styles. When the
Digital Closed Caption service is in use, it
will be indicated by the appearance of a
3-letter abbreviation that also indicates the
language of the Digital Closed Captions:
ENG (English), SPA (Spanish), FRA
(French) or other language codes.

In the Closed Caption system, there
can be more than one caption service

provided. Each is identified by its own
number. The “CC1” to “CC4” services

display subtitles of TV programs
superimposed over the program's picture.

In the Closed Caption system, the “TEXT1”

to “TEXT4” services display text that is

unrelated to the program being viewed
(e.g., weather or news). These services
are also superimposed over the program
currently being viewed.

Press 1. CC.

This will display the current Closed

Caption information. Press CC to
turn the Closed Caption on or off.

Caption Display will not work when

viewing a 480i, 480p, 720p, 1080i or
1080p input via the COMPONENT:

Y-PbPr or HDMI inputs.
Closed Captions availability and content

depends on the broadcaster. Closed
Caption are available when the Closed
Caption icon is displayed on screen.

Closed Captions and Digital Captions
availability and content depends on
the broadcaster. Closed Caption are
available when the Closed Caption icon
is displayed on screen

Not all programs and VHS videotapes
offer closed captions.

28

Direct Button Operation

VIEW MODE

You can select the screen size.

1 Press VIEW MODE.

• The View Mode menu displays.

• The menu lists the View Mode options selectable for the type of video signal currently being
received.

2 Press VIEW MODE or / while the View Mode menu is displayed to select a desired item on

the menu.

• You can sequentially select a View Mode that has its own aspect ratio.

For 4:3 programs

Example: Screen size images

Normal

StretchZoomS.Stretch (Smart stretch)

Suitable for viewing
conventional 4:3 programs in
their normal format.

Suitable for stretching 4:3
programs to fi ll the screen.

Suitable for viewing wide­screen 2.35:1 anamorphic
DVDs in full screen.

This mode is useful for 1.78:1
DVDs. When viewing 1.85:1
DVDs, stretch mode will still show
very thin black bands at the top
and bottom of the screen.

For HD programs

Stretch: Suitable for viewing wide-screen 1.78:1 aspect ratio program, stretch mode will still show

very thin black bands at the top and bottom of the screen.
Dot by Dot (1080i/p only): Detects the resolution of the signal and displays an image with the
same number of pixels on the screen.

Full Screen(720p only): You can select “Full Screen” only when receiving a 720p signal.
S.Stretch (Smart stretch): Suitable for stretching 4:3 programs to fi ll the screen.
Zoom: Suitable for viewing wide-screen 2.35:1 aspect-ratio programs in full screen.

• When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer
portions of the screen, Please change view mode to correct this.

For PC input mode

• Connect the PC before making adjustments.

• Selectable screen size may vary with input signal type.

Example: Screen size images

Input signal Normal Cinema

4:3

Input signal

Keeps the original
aspect ratio in a full
screen display.

Normal

For viewing
widescreen
programs. The top
and bottom of the
image is cropped.

Dot by Dot

Full Screen Dot by Dot

An image fully fi lls the
screen.

Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.

16:9 An image fully fi lls the

screen.

Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
