Sharp LC-26D5U, LC-32D5U, LC-37D5U Operating Manual

Download

LC-37D5U LC-32D5U LC-26D5U

LIQUID CRYSTAL TELEVISION

ENGLISH

FRANÇAIS

TÉLÉVISEUR ACL TELEVISOR CON PANTALLA DE CRISTAL LIQUIDO

OPERATION MANUAL MODE D’EMPLOI MANUAL DE OPERACIÓN

ESPAÑOL

LC-37D5U LC-32D5U LC-26D5U

LIQUID CRYSTAL TELEVISION

OPERATION MANUAL

• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual operations.

• Menu items that are not selectable are grayed out.

• The examples used throughout this manual are based on the LC-32D5U model.

IMPORTANT: To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the space provided. The numbers are located at the rear of the TV.

ENGLISH

Model No.:

Serial No.:

IMPORTANT INFORMATION

WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning flash with arrow-head

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT INFORMATION

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO

WIDE SLOT, FULLY INSERT.

CAUTION:

DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD, BRACKET, OR TABLE. THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS DAMAGE TO THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE RECOMMENDED BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE MANUFACTURER’S INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING ACCESSORIES RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART COMBINATION SHOULD BE MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND UNEVEN SURFACES MAY CAUSE THE PRODUCT AND CART COMBINATION TO OVERTURN.

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

CAUTION:

This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

DECLARATION OF CONFORMITY

SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-37D5U SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-32D5U SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-26D5U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RESPONSIBLE PARTY:

For Business Customers: URL

SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 TEL: 1-800-BE-SHARP

http://www. sharpusa. com

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eia.org

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product.

IMPORTANT SAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Power Sources — This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

16) Overloading — Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

17) Object and Liquid Entry — Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18) Damage Requiring Service — Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions.

Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to

restore the product to its normal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance – this indicates a need for service.

19) Replacement Parts — When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

20) Safety Check — Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

21) Wall or ceiling mounting — When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer.

IMPORTANT SAFETY INSTRUCTIONS

• Water and Moisture — Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.

• Selecting the location — Select a place with no direct sunlight and good ventilation.

• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.

• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.

• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

• The Liquid Crystal panel is a very high technology product with 3,147,264 thin film transistors, giving you fine picture details. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.

Precautions when transporting the TV

When transporting the TV, never carry it by holding onto the speaker. Be sure to always carry the TV by two people holding it with two hands—one hand on each side of the Display.

• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

IMPORTANT SAFETY INSTRUCTIONS

• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA

ELECTRIC SERVICE EQUIPMENT

NEC —NATIONAL ELECTRICAL CODE

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

• To prevent fire, never place any type of candle or flames on the top or near the TV set.

• To prevent fire or shock hazard, do not expose this product to dripping or splashing. No objects filled with liquids, such as vases, should be placed on the product.

• To prevent fire or shock hazard, do not place the AC power cord under the TV set or other heavy items.

• Turn off the main power and unplug the AC cord from the wall outlet before handling.

• Use a soft cloth and gently wipe the surface of the TV panel. Using a hard cloth may scratch the panel surface.

• Use a soft damp cloth to gently wipe the panel when it is really dirty. (It may scratch the panel surface when wiped strongly.)

• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.

• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it, such materials may damage the panel surface.

• Do not display a still picture for a long time, as this could cause an afterimage to remain.

QUICK REFERENCE

STOP! To safely remove the AQUOS television from the box

It's best to use 2 people to remove the AQUOS television for stability.

1. Use the cardboard holders on either side of the AQUOS television to remove it from the box.

2. Remove the cardboard; however, keep the wrapping on the AQUOS television to protect it while moving.

3. Lift onto installation location as the diagram illustrates.

Ventilation & Cleaning Tips

Keep your AQUOS television in a well ventilated area and make sure not to place it by a heat source or use near water. The AQUOS television is designed for AC use only and should be used with supplied AC cord.

Clean the screen by spraying a soft lint free cloth with water to lightly moisten. Gently wipe and avoid pressing on the screen. To clean the outer cabinet, use the same method. Do not use liquid or aerosol cleaners.

The screen is glass and can be scratched or broken when dropped or impacted.

QUICK INSTALLATION TIPS

1. Facing the back of the AQUOS television, remove the terminal cover.

4. Bundle the cords properly with a cable clamp and cable tie, and close the terminal cover.

Press down the upper hooks to remove the cover toward you.

2. Attach your antenna to the back of the TV. (See page 16.)

3. Connect the AC plug for the AQUOS television into the wall outlet.

CAUTION

• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT

TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC CORD CONNECTED.

5. How to turn on the AQUOS television for the first time. A) Press POWER on AQUOS television.

POWER

B) POWER indicator on the front of the AQUOS

television lights blue.

POWER indicator

NOTE

• Speaker cannot be detached from the TV.

• TV angle cannot be adjusted.

QUICK REFERENCE

If the remote control fails to operate TV functions, replace the batteries in the remote control unit.

1 Open the battery cover. 2 Insert two “AAA” size batteries

(supplied with the product).

• Place the batteries with their terminals

corresponding to the (e) and (f) indications in the battery compartment.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage in old batteries.

• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a rash. If you find any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove batteries from it.

3 Close the battery cover.

IMPORTANT:

The POWER indicator on the AQUOS television should light blue indicating you have power to the AQUOS television.

If the POWER indicator on the AQUOS television still does not light up, press TV POWER on the remote control to turn the power on.

IMPORTANT:

IF THE UNIT DOES NOT POWER ON - UNPLUG THE AQUOS TELEVISION FROM THE OUTLET AND REPEAT THE INSTALLATION STEPS.

IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.

Please refer to the BASIC ADJUSTMENT SETTINGS SECTION for EZ setup and basic channel setup functions and USING EXTERNAL EQUIPMENT SECTION for other device connections (DVD, VCR, AUDIO, etc) in your AQUOS operation manual.

QUICK REFERENCE

TV GUIDE ON SCREEN™ QUICK SETUP SHEET

Once you set up the TV according to this operation manual, you are ready to set up TV Guide On Screen!

Note: TV Guide On Screen™ interactive program guide supports cable-ready, cable box and digital cable services as well as over-the-air broadcast. It does not provide listings for satellite services.

After completing the TV’s initial setup, you see the TV Guide On Screen Setup Welcome Screen. Note: If TV Guide On Screen is not set up, pressing TV

GUIDE while watching TV will display the Welcome Screen.

Follow the on-screen instructions

If you previously skipped TV Guide On Screen setup, you see the Reminder Screen.

Note: If you press ENTER and the screen does not change, make sure that the batteries in the remote control are properly installed. If you need to control a cable box and/or a VCR, complete steps 1 through 3. If not, go to step 4.

Find and Connect the included G-LINK cable into the G-LINK terminal.

G-LINK cable with Double-Sided Tape

Find the VCR and Cable Box IR Sensors.

To control recording, find the VCR's IR sensor.

1 Turn the VCR off. 2 Hold the VCR remote so that it touches the

front of the VCR (Figure 1).

3 Move the remote across the front while

pressing POWER (Figure 2). (You must press and release the power button each time you move the remote; holding down the button will not work).

4 When the VCR powers on, you have found

the sensor.

5 Remember the location of the sensor, and go

to step 3.

If you have a cable box, repeat this procedure using the cable box and its remote, and then go to step 3.

Figure 1

Correct Incorrect

Place the G-LINK cable(s)

Figure 2

To control a VCR, place one of the G-LINK cables underneath the VCR approximately 1 inch in front of the sensor you found in step 2. If you have a cable box, place the other GLINK cable approximately 1 inch in front of the sensor you found in step 2. Use the double-sided tape to secure each G-LINK cable.

This end is connected to the TV as shown in step 1.

G-LINK

cable

VCR

Cable Box

1 inch

G-LINK cable

Use the TV remote for On-Screen Setup

1 Press a/b/c/d and ENTER to highlight an

item in a Setup screen.

2 Press ENTER to select that item.

G-LINK wand

a/b/c/d

ENTER

QUICK REFERENCE

On-Screen Setup

• TV Guide uses setup information to provide TV listings and lineups.

The first two screens ask you about your

location.

Follow the on-screen instructions.

Press c/d to move the highlight. Press 0-9 or a/b to enter a ZIP Code or Postal Code.

This screen asks you about a VCR.

If the answer is “YES”, you are directed through additional screens, which include selecting and verifying the VCR brand. When successfully completed, you next see the screen in step 10 which asks about confirming all of your settings.

If the answer is “NO”, you next see the screen in step 10 which asks about confirming all of your settings.

This screen asks you to confirm that the settings are correct.

If the answer is “YES”, you

These screens ask you about cable.

If the answer is “YES”, you next see a screen about a cable box. If the answer is “NO”, you next see the screen in step 7 which asks about an antenna connection.

If the answer is “YES”, you are directed through additional screens, which include selecting the input used on the TV for the cable box and verifying the cable box and verifying the cable box brand. When successfully completed, you next see the screen in step 7 which asks about an antenna connection.

• Please refer to the note on step 4 in page 21 for

details.

If the answer is “NO”, you next see the screen in step 7 which asks about an antenna connection.

next see the screen in step

11.

If the answer is “NO”, you are returned to step 5 from where you can change any incorrect information by repeating the Setup process.

This screen indicates you have successfully completed setup for TV Guide On Screen.

Important: Power off your recorder overnight and if you have a cable box, leave it on.

Within 24 hours, you will begin to receive TV program listings.

Note: If you have a cable box, it is normal for the TV to switch channels on the cable box while the unit is setting up. DO NOT interfere with the process. If you want to resume TV

This screen asks you about an antenna connection.

If the answer is “YES”, you may see an additional screen to select the input. Then you next see the screen in step 8 about confirming your basic settings.

If the answer is “NO”, you next see the screen in step 8 about confirming your basic settings.

viewing and stop the TV from changing channels, you need to power on the TV.

This screen gives helpful information about TV Guide On Screen.

Congratulations, you are done!

Important: If you selected that you do not have cable service connected to this TV in the previous screens, you must select “YES” in this screen to receive a channel lineup and listings.

In the United States, TV GUIDE and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates. In Canada, TV GUIDE is a registered mark of Transcontinental Inc.,

This screen asks you if the settings are correct, so far.

If the answer is “YES”, you next see an information screen and then the screen in step 9 which asks about a VCR.

If the answer is “NO”, you are returned to step 5, from where you can change any incorrect information by repeating the Setup process.

and is used under license by Gemstar-TV Guide International, Inc.

Contents

IMPORTANT INFORMATION ………………………1 DEAR SHARP CUSTOMER …………………………3 IMPORTANT SAFETY INSTRUCTIONS ……………3 QUICK REFERENCE ………………………………… 6 Contents …………………………………………… 10 Trademarks ………………………………………… 11 COPYRIGHT AND LICENSE NOTICE ………… 11 PATENT NOTICE…………………………………… 11 Supplied accessories …………………………… 12 Part names ………………………………………… 13

TV (Front) ……………………………………… 13 TV (Rear) ……………………………………… 14 Remote control unit …………………………… 15

Preparation ………………………………………… 16

Using the remote control unit ………………… 16

Cautions regarding remote control unit … 16

Antennas ……………………………………… 16

Watching TV ……………………………………… 17

Turning on the power ………………………… 17 Turning off the power ………………………… 17 Initial setup ……………………………………… 18 Using the TV Guide On Screen™

(Interactive Program Guide) ……………… 19 TV Guide On Screen Initial setup …………… 20 Using TV Guide On Screen …………………… 24 Program recording using

LISTINGS function ………………………… 27 Using Reminder function ……………………… 27 Using SCHEDULE function …………………… 28 Changing system settings …………………… 31 Changing channel display …………………… 31 Changing default options …………………… 32 Changing channels-Air/Cable ……………… 34 Changing volume/sound ……………………… 35 Setting MTS/SAP stereo mode ……………… 36 Setting Digital broadcasting audio mode …… 36 Connecting Digital Cable Module …………… 37

Basic adjustment settings ……………………… 38

AV input mode menu items …………………… 38 PC input mode menu items …………………… 39 EZ setup ………………………………………… 39 Channel Setup ………………………………… 40 Antenna Setup – DIGITAL – Air ……………… 42 Standby Mode ………………………………… 42 Favorite channel setting ……………………… 43 Language setting ……………………………… 43 Picture adjustments …………………………… 44

OPC setting ………………………………… 45

C.M.S. (Color Management System) …… 45

Color temperature ………………………… 46

Black ……………………………………… 46

3D-Y/C ……………………………………… 46

Monochrome ……………………………… 47

Film Mode (3:2 pull-down) ……………… 47

I/P Setting ………………………………… 47 Sound adjustment ……………………………… 48 Dolby Virtual …………………………………… 48 Power Control ………………………………… 49

Power control for AV source ……………… 49

Power control for PC source……………… 49 Digital Setup …………………………………… 50

Video Setup ………………………………… 50

Audio Setup ……………………………… 51

Using external equipment ……………………… 52

Displaying an external equipment image …… 52 Connecting a DVD player …………………… 53 Connecting a VCR …………………………… 54 Connecting a game console

or camcorder ……………………………… 54 Connecting a Digital TV STB (Air or Cable) … 55 Connecting HDMI equipment ………………… 56 Displaying an image from HDMI

equipment ………………………………… 56 Connecting a PC ……………………………… 57 Connecting D-VHS decks/AV-HDD recorder/

Blu-ray Disc recorder (i.LINK connection)

About i.LINK ……………………………… 58

i.LINK connection ………………………… 58

Connecting two or more i.LINK devices … 58

Setting the Recording Mode (i.LINK) …… 59

Setting the Standby Mode (i.LINK) ……… 59

Selecting an i.LINK device ……………… 60

Disabling the TV’s operation of

an i.LINK device ……………………… 60 Deleting registered i.LINK devices ……… 60 Controlling an i.LINK device……………… 61 Automatic input switching to i.LINK …… 62 Recording digital programs

with a D-VHS deck (i.LINK)…………… 62 Recording digital programs with AV-HDD

recorder/Blu-ray Disc recorder ……… 63 Playing back using REC LIST (i.LINK) … 63

Useful adjustment settings ……………………… 64

Image position (AV input mode only) ……… 64 Moving the picture on the screen …………… 64 Auto Sync. adjustment (PC input mode only) … 65 Fine Sync. adjustment (PC input mode only) … 65 Input Select …………………………………… 66 Input Label ……………………………………… 67 Picture Flip ……………………………………… 67 AV MODE ……………………………………… 68 View mode for 4:3 Programs ………………… 68 View mode for HD Programs ………………… 68 View mode (for PC input mode) ……………… 69 Input signal (for PC input mode) …………… 70 Digital Noise Reduction ……………………… 70 Audio Only ……………………………………… 70 Output Select …………………………………… 71 Quick Shoot …………………………………… 71 Sleep Timer …………………………………… 71 Program Title Display ………………………… 72 Closed Captions and Digital Closed

Captions …………………………………… 73 Caption Size ……………………………… 74 Font Style …………………………………… 74 Foreground Color ………………………… 75 Foreground Opacity ……………………… 75 Background Color ………………………… 75 Background Opacity ……………………… 76 Character Edge …………………………… 76

Secret number setting for parental control

(AV input mode only) ……………………… 77

Parental control (setting V-CHIP level) ……… 79 How to temporarily release

the V-CHIP BLOCK ……………………… 83

Reactivating the temporarily released

V-CHIP BLOCK …………………………… 83

Contents

Other viewing options …………………………… 84

Viewing information of the program ………… 84 Picture and still image ………………………… 84 Presetting remote control function …………… 85

Appendix ………………………………………… 90

Removing the stand …………………………… 90 Setting the TV on the wall …………………… 90 Troubleshooting ………………………………… 91 Troubleshooting-TV Guide On Screen ……… 92 Troubleshooting-Digital broadcasting ……… 93 PC compatibility chart ………………………… 93 RS-232C port specifications ………………… 94 Specifications ………………………………… 96 Optional accessories ………………………… 96

Dimensional drawings …………………………… 97

Trademarks

• Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

• Manufactured under license from BBE Sound, Inc.

Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC.”

• CableCARD™ is a trademark of Cable Television Laboratories, Inc.

• In the United States, TV GUIDE and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates. In Canada, TV GUIDE is a registered mark of Transcontinental Inc., and is used under license by Gemstar-TV Guide International, Inc.

• It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.

• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. U. S. Patent Nos. 4,631,603; 4,577,216; 4,819,098; 4,907,093; 5,315,448; 6,381,747; and 6,516,132.

• This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as videoon-demand, a cable operator's enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

• The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide International, Inc. and/or one of its affiliates.

PATENT NOTICE

The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121.

Supplied accessories

Make sure the following accessories are provided with the product.

Remote control unit (g1)

Page 7

Cable clamp (g1)

“AAA” size battery (g2)

Page 7

Cable tie (g1)

AC cord (g1)

Page 6

G-LINK cable (g1)

Page 6

Operation manual (g1)

NOTE

• Always use the AC cord supplied with the LCD-TV.

Page 6

Page 8

Part names

TV (Front)

Volume buttons (VOLl/k )

Channel buttons** (CHs/r)

INPUT button*

POWER button

* INPUT button works as ENTER in TV Guide On Screen

** Channel buttons work as a/b in TV Guide On Screen

NOTE

• See page 17 for status indicator.

POWER indicatorOPC sensor

Remote control sensor

OPC/DL indicator

*OPC: Optical Picture Control

(See page 45.)

*DL: DownLoad

Part names

TV (Rear)

G-LINK terminal

INPUT 3

terminals

INPUT 1

terminals

MONITOR OUT/ REC OUT terminals

INPUT 2 terminals

i.LINK terminals

CableCARD™ slot

AC INPUT terminal

DIGITAL AUDIO

OUTPUT terminal

DIGITAL CABLE

IN terminal

SYSTEM RESET**

RESET*

ANALOG IN terminal

DIGITAL AIR IN terminal

INPUT 5 terminals

RS-232C terminal

INPUT 4 terminal

* Press RESET if the TV cannot return to its original state after performing various operations.

• AV MODE resets to DYNAMIC (Fixed)

• TV channel returns to initial channel (Air:2ch, Cable:1 or 2ch)

• Audio setting initializes

• Dolby Virtual resets to off

• Image position initializes

** Press SYSTEM RESET if the TV does not operate after starting up.

NOTE

• Pressing RESET will not work if the TV is in standby mode.

• Pressing RESET will not delete channel preset or secret number. See page 78 for clearing the secret number when you know it. See page 98 for initializing to the factory preset values when you forget your secret number.

Part names

Remote control unit

117

2 318

6 7

8 9

10 11

21 22

23 24

25 26

14 15 16

1 TV POWER: Switches the Liquid Crystal Television

power on or enters Standby mode. (See page 17.)

2 DISPLAY: Displays the channel information. 3 SOURCE POWER: Turns the power of the external

equipment on and off.

4 External equipment operational buttons: Operates

the external equipment.

50 – 9/• (DOT): Sets the channel.

30 31 32

6 AIR: Receives air signal. 7 CABLE: Receives cable signal.

8VOL 9

page 35.)

10 INFO: Displays the program information screen. (See

page 84.)

11 RECORD: Records the program to equipment (capable

of recording). (See page 27.) In TV Guide On Screen, initiates the recording process.

12 EXIT: Turns off the menu screen and TV Guide On

Screen.

13 FAVORITE CH

A, B, C, D: Selects four preset favorite channels in four

different categories. (See page 43 for details.) While watching, you can toggle the selected channels by pressing A, B, C and D. DAY l/DAY k:In TV Guide On Screen, moves forward or backward in 24 hour increments in the listing grid.

14 AUDIO: Selects the MTS/SAP or the audio mode during

multi-channel audio broadcasts. (See page 36.)

15 SLEEP: Sets the sleep timer. (See page 71.) 16 i.LINK: Displays the i.LINK panel. (See page 60.) 17 FUNCTION: Switches the remote control for TV, CBL/

SAT, VCR, DVD and AUDIO operation. Indicator lights up for the current mode. (See pages 85 to 88 for details.) * To enter the code registration mode, you need to press

will light. The lighting will turn off if no operations are performed within about 5 seconds. This button is used for performing operations in low-light situations.

19 VIEW MODE: Selects the screen size. (See pages 68

and 69.)

20 ENT: Enters a channel selection when choosing with

the 0-9 buttons.

21 FLASHBACK: Returns to the previous channel or

external input mode. (See page 34.)

22 INPUT: Selects a Liquid Crystal Television input source.

(TV, CableBox, INPUT 1, INPUT 2, INPUT 3, INPUT 4, INPUT 5, i.LINK) (See pages 52 and 66.) If the CableBox is set up in the TV Guide On Screen setting menu, the CableBox option appears.

23 CH

Screen, moves one page up or one page down in the LISTINGS grid.

24 MUTE: Mutes the sound. (See page 35.) 25 TV GUIDE: Displays TV Guide On Screen. 26 MENU: Displays the menu screen. 27 a/b/c/d/ENTER: Selects a desired item on the

screen.

28 RETURN: Returns to the previous menu screen. 29 FREEZE: Sets the still image. Press again to return to

normal screen. (See page 84.)

30 CC: Displays captions when receiving closed-caption

signals. (See page 73.)

31 EDIT: Registers favorite channel. 32 AV MODE: Selects an audio or video setting. (See

page 68.) (AV mode: STANDARD, MOVIE, GAME, USER, DYNAMIC (Fixed), DYNAMIC. PC mode: STANDARD, USER.)

l: Sets the volume. (See page 35.)

Virtual: Selects Virtual Dolby Surround settings. (See

FUNCTION and DISPLAY at the same time.

: When pressed all buttons on the remote control unit

s: Selects the channel. In the TV Guide On

Preparation

Using the remote control unit

Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the remote control unit and the remote control sensor may prevent proper operation.

Cautions regarding remote control unit

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.

• Do not install or place the remote control unit under direct sunlight. The heat may cause deformation of the remote control unit.

• The remote control unit may not work properly if the remote control sensor on the TV is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the TV, or operate the remote control unit closer to the remote control sensor.

Antennas

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set.

1. A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a terminal without tools (Commercially available).

2. A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm adapter (Commercially available).

NOTICE

F-type connector

F-type connector should be finger-tightened only.

When connecting the RF cable to the TV set, do not tighten F-type connector with tools. If tools are used, it may cause damage to your TV set.

75-ohm coaxial cable

(The breaking of internal circuit, etc.)

Connecting Antenna Cable

Cable without a CATV

Cable TV lead-In

converter

Combination

VHF/UHF antenna

75-ohm coaxial cable (round)

300/75-ohm adapter (commercially available)

300-ohm twin-lead

Combiner (commercially available)

IN OUT

Separate VHF/UHF

antenna

300-ohm twin-lead (flat)

VHF ANTENNA

75-ohm coaxial cable

UHF ANTENNA

300-ohm twin-lead

Home Antenna

terminal (75-ohm)

Coaxial cable

(commercially

available)

F-type connector

75-ohm coaxial cable (round)

300-ohm twin-lead cable (flat)

signal splitter (commercially available)

Depending on your reception environment, either CABLE IN or AIR IN may be used, or both CABLE IN and AIR IN may be used.

Watching TV

Simple operations for watching a TV program

Turning on the power

POWER indicator

OPC/DL indicator

TV POWER

POWER

Press POWER on the TV or press TV POWER on the remote control.

• POWER indicator (Blue): The TV is on. (After a few seconds, a window appears with sound.)

NOTE

• The initial setup starts when the TV powers on for the first time. If the TV has been turned on before, the EZ setup will not be invoked. See page 39 for performing EZ setup from the Setup menu.

Turning off the power

Press POWER on the TV or press TV POWER on the remote control.

• The TV enters standby mode and the image on the screen disappears.

• The POWER indicator on the TV gradually turns off.

NOTE

• If you are not going to use this TV for a long period of time, be sure to remove the AC cord from the power outlet.

CAUTION

• Please do not unplug the AC cord when the OPC/DL indicator is red.

TV status indicator (POWER)

OFF/Standby

Lighting (Blue)

Lights off

TV status indicator (OPC/DL)

“Off” is selected in OPC setting

“On” or “On:Display” is selected in OPC setting

CableCARD is downloading data

TV Guide On Screen system is downloading data

Timer recording (in TV Guide On Screen system) is in progress

TV Guide On Screen system is preparing to start timer recording or display reminder screen

*OPC: Optical Picture Control *DL: DownLoad

Lights off

Lighting (Green)

Lighting (Red)

Watching TV

Initial setup

When you turn on the TV for the first time, it will automatically memorize the broadcasting channels where you live. Perform the following steps before you press TV POWER on the remote control unit.

1. Insert the batteries into the remote control unit. (See page 7.)

2. Connect the antenna cable to the TV. (See page 16.)

3. Plug in the AC cord to the AC outlet. (See page 6.)

Language setting

Select from among 3 languages: English, French and Spanish. Press a/b to select the desired language listed on the screen, and then press ENTER.

Standby Mode setting

Select the standby setting. (See page 42.)

Language

Standby Mode

TV Guide On Screen

Air/Cable

CH Search

Mode 1: Starting TV is quick from standby. Mode 2: Power consumption is small at the standby.

NOTE

• When the CableCARD is inserted, power consumption will be higher.

Mode 1

Mode 2

Channel search

Channel auto search makes the TV look for all channels viewable in the set area.

Press c/d to select “Yes” for ANALOG, then press b to move down. Press c/d to select “Yes” for DIGITAL (Air), then press b to move down. Press c/d to select “Yes” for DIGITAL (Cable), and press b to move down. Select “Search Start”, and then press ENTER.

• This operation makes the TV search for both ANALOG , DIGITAL (Air) and DIGITAL (Cable) channels.

Language

Standby Mode

TV Guide On Screen

Air/Cable

CH Search

ANALOG Yes

DIGITAL (Air)NoYes No

DIGITAL (Cable) Yes No

Search Start

Example

CH Search

ANALOG [ ]25 [ ]20

FoundAir

TV Guide On Screen setting

Press ENTER to continue the setting. (See page

20.)

Antenna setting

Make sure what kind of connection is made with your TV.

Press c/d to select “Air”, “Cable” for ANALOG, then press b to move down. Press c/d to select “Standard”, “HRC” or “IRC” for DIGITAL (Cable). Press ENTER to enter the setting.

• There are 3 kinds of CATV system, including Standard, HRC and IRC. Select the one that matches to your TV.

NOTE

• Some items are not selectable because the antenna setting is linked to the TV Guide On Screen setting.

• DIGITAL(Cable) setting cannot be selected when a proper CableCARD is inserted.

CH Search

DIGITAL [ ]25 [ ]20

FoundAir

CH Search

DIGITAL [ ]25 [ ]25

Air ANALOG

FoundCable

Audio : MONO

NOTE

• Make sure what kind of connection is made with your TV.

• If no channel is found, make sure what kind of connection is made with your TV and try EZ setup again. (See page

39.)

Watching TV (TV Guide On Screen)

Using the TV Guide On Screen™ (Interactive Program Guide)

The TV Guide On Screen system is a free, on-screen interactive television program guide (“IPG”) built into your LCD-TV. The TV Guide On Screen system was developed to help today’s TV viewers, overwhelmed by myriad viewing choices, find what they want to watch quickly and easily, directly from their TV screen. The TV Guide On Screen System displays all the major TV channels and programs available in the viewer’s household.

NOTE

• Over-the-air or cable access to stations carrying TV Guide On Screen data is required for the TV Guide On Screen system to operate. The data provider may elect to discontinue the service or it may cease to be available in your area. In either of these cases, the TV Guide On Screen feature will not function. Also, since the program information provided by TV Guide On Screen system is based on your location, you will need to run SETUP again if you move to a different ZIP or postal code.

About the Key features of TV Guide On Screen

LISTINGS Service

●

1. Displays eight days of viewers’ local program listings

and descriptions for broadcast and cable.

2. Viewers can tune to any program, schedule a

program to record, or set a reminder.

3. The Video Window lets viewers monitor the last

channel tuned while viewing program listings, or preview channels as they page through listings.

4. Color-coded program genres help viewers quickly

identify movies, sports, and children’s programming.

SEARCH Feature

●

1. Viewers can search for programs by categories such

as HDTV, movies, sports or children’s shows. Within categories, viewers can sort by show type, such as baseball or football.

2. Viewers can sort alphabetically, or by a keyword

such as a show title or a starring actor.

One-touch Recording

●

1. To record, viewers simply highlight a program title

and then press a button on the remote control. TV Guide On Screen will automatically record the program.

2. Programs may be set to record one time or every

time they air.

Reminder Feature

●

1. Viewers may set reminders to ensure they never miss their favorite programs.

2. Reminders can even be set to automatically turn on the TV when a program begins.

Important!

The TV Guide On Screen system automatically comes up when you turn on the LCD-TV. You can turn off this feature by changing default options. (See page 32 for details.)

Screen Components

●

Video Window Service Bar

Logo

Video Windows - displays the last TV program or the preview of the next TV program

Service Bar - provides access to the 4 main Guide Services(LISTINGS/SEARCH/SETUP/SCHEDULE)

Tile - displays program title Info Box - provides information for a highlighted item Channel Logo - identifies network Panel Ad - displays promotional information

The screening times of the selected programs

TilePanelAdChannel

Names and categories of the selected programs

Info Box

NOTE

• A VCR or a supported i LINK recording device is required for one-touch recordings. If you connect a VCR, it is recommended that you connect it according to the instructions on pages 8 and 54.

Information on the selected programs

Watching TV (TV Guide On Screen)

Info Box

●

Info Box contains information about a show, service, ad, or provides general help. A Show Listing Info Box can have up to three sizes: Small, Large, and “No”. The default size of the Info Box is Small. Press INFO to cycle among the sizes.

Info Button

●

The Info button appears on the button bar, if the Info box size can change and/or if there are additional Info screens.

• Press INFO on the remote control cycles between Info box sizes, as available.

• In some instances, the Info key is used to page forward, if there are additional pages of information, such as a Panel Ad, Channel Ad, or help text.

Icons

●

The following icons indicate the current program information and the current and future actions & status.

IMPORTANT: When using TV Guide On Screen or if program information does not download, please follow the instructions below.

The TV must be off to download information. Leave your TV off overnight to receive the initial download in your area. (Refer to Troubleshooting-TV Guide On Screen on page 92 for details.)

TV Guide On Screen Initial setup

The Guide uses Setup information to provide you with show listings and lineups in your area - which are updated several times a day. Once you setup the LCDTV according to this operation manual, you are ready to set up TV Guide On Screen.

Press TV GUIDE to start setup.

Name

INFO button

Progress bar

HDTV

New

Stereo

TV Rating

Record once

Record off/

Record suspend

Remind once

Remind off

Remind suspend

Icon

Description

• Display the additional information.

• Elapsed time in current program. This appears in LISTINGS, SEARCH and when INFO is pressed while watching TV.

• The program is presented in HighDefinition TV, if available.

• The program is new (not a repeat program).

• The program is available in Stereo.

• Closed Caption is available for the program.

• TV rating for the program.

• The program is set to record once.

• Other frequencies are Daily (manual recording only), Regularly, and Weekly.

• The program is set to Record but is currently off. (The program remains in schedule.)

• The program is suspended due to a schedule conflict. (The program remains in Schedule.)

• Recording resumes when the conflict no longer exists.

• The program is set to remind once. Other frequencies are Daily (manual recording only), Regularly, and Weekly.

• The program is set to remind but is currently off. (The program remains in Schedule.)

• The program is suspended due to a schedule conflict. (The program remains in Schedule.)

• Remind resumes when the conflict no longer exists.

Press ENTER. Basic initial setup will start.

Reminder screen

If you previously skipped Guide setup you will see the Reminder Screen when you power on your LCD-TV.

• If you decide not to set up the Guide now, this reminder screen will appear each time you power on the LCD-TV (except if you selected “Don’t remind me again”).

Press a/b to select an option.

• “Set up TV Guide On Screen now”: Basic initial setup will start.

• “Remind me to set it up later”: Returns to watching TV.

• “Don’t remind me again”: Returns to watching TV and stops the reminder screen from appearing upon powering on.

NOTE

Watching TV (TV Guide On Screen)

Basic initial setup

Which country is your LCD-TV located in ?

Press a/b to select the country.

Enter the ZIP code (or postal code) for your location using the number buttons or a/b.

• To receive TV program listings in the TV Guide On Screen system, please ensure to connect your cable box to the input marked “VIDEO” if you connect your cable box to your LCD-TV using INPUT 1 or INPUT 2. Do not connect the cable box to the “COMPONENT” video of INPUT 1 or INPUT 2, as you will not receive any TV program listings through this input.

Is a cable box connected to this TV?

Press a/b to select “Yes” or “No”, and then press ENTER.

• If your answer is “No” skip to step 12 on page

22.

NOTE

Do you have cable service connected to this TV?

Press a/b to select “Yes” or “No”, and then press ENTER.

Please indicate which input the cable box is plugged into.

Press a/b to select the input you connected, and then press ENTER.

• To receive TV program listings in the TV Guide On Screen system, if you select “Input 1” or “Input 2”, please ensure your cable box is connected to the input marked “VIDEO” and proceed to step 7. Do not connect your cable box to the “COMPONENT” video of INPUT 1 or INPUT 2, as you will not receive any TV program listings. If you select “Analog” input, proceed to step 6.

What is your TV tuned to when using the cable box?

Press a/b to select from “Ch 2”, “Ch 3” and “Ch 4”, and then press ENTER.

• If your answer is “No”, skip to step 11 on page

22.

• Please consult your cable provider if you are unsure.

The diagram on the screen shows the correct way to connect the G-LINK cable from the back of the TV to the cable box. Make sure the G-LINK cable is properly connected, and then press ENTER.

Watching TV (TV Guide On Screen)

Selecting the cable box brand name.

Press a/b to select the cable box brand, and then press ENTER.

• Press a/b to view more cable box brands.

Tune your cable box to channel 02. Make sure to leave your cable box turned on, and then press ENTER.

The TV Guide On Screen system will conduct a series of tests and when the testing is completed the next screen will be displayed automatically. Do not press any buttons while testing is in progress.

Do you have an antenna connected to your TV?

Press a/b to select “Yes” or “No”, and then press ENTER.

• If you select “Yes”, go to the next step.

• If you selected “No” in step 3, you must connect an antenna to your TV and select “Yes” to receive a channel lineup and listings.

Are the settings correct?

Confirm the settings displayed on the screen and press a/b to select “Yes, end setup” or “No, repeat setup process”, and then press ENTER.

Is your cable box now tuned to channel 09?

Press a/b to select “Yes”, “No” or “Test this code again”, and then press ENTER.

• If you select “Yes”, go to the next step.

• If you select “No”, a different code is tested in the previous screen.

• If you select “Test this code again”, the same code is tested again in the previous screen.

Press ENTER to continue.

NOTE

• Please do not use the CableCARD while using cable box.

Watching TV (TV Guide On Screen)

VCR setting

Connect a VCR to your TV and use the TV Guide On Screen system’s program listings to easily schedule recordings using the one-touch recording feature.

Did your VCR stop playing?

Press a/b to select “Yes”, “No” or “Test this code again”, and then press ENTER.

Use TV Guide On Screen to control VCR?

Press a/b to select “Yes, setup VCR control” or “No, end setup”, and then press ENTER.

• If you select “Yes”, go to the next step.

• If you select “No”, setup will end.

This screen shows the correct way to connect the G-LINK cable from the back of the TV to the recording device. Make sure the G-LINK cable is properly connected, and then press

ENTER.

Selecting the VCR brand name.

Press a/b to select the VCR brand, and then press ENTER.

Turn on your VCR and insert a tape, and then play the media on the VCR. Then press ENTER on the remote control of your TV.

• If you select “Yes”, go to the next step.

• If you select “No”, a different code is tested in the previous screen.

• If you select “Test this code again”, the same code is tested again in the previous screen.

•

Up-to-date listings will begin loading over the next 24 hours when your LCD-TV is powered off.(Do not unplug the AC cord.)

• It may take more than one day for all eight days of listings to update. The guide will automatically receive updates during the period when your LCD-TV is turned off.

• To receive your channel lineup and program listings, leave your cable box on. Your VCR and LCD-TV should be turned off overnight.(Do not unplug the AC cord.)

• To record a TV program, make sure your cable box is on. Put a tape in your VCR, tune the device to the Line input, then turn the VCR off. (Do not unplug the AC cord.)

• You must redo the TV Guide On Screen system setup if you:

- Move your LCD-TV to a new ZIP or postal code

- Cancel cable service or change cable boxes

- Change your VCR brand or model

Are the settings correct?

Confirm the settings displayed on the screen and press a/b to select “Yes, end setup” or “No, repeat setup process”, and then press ENTER.

Press ENTER to complete the SETUP.

NOTE

The TV Guide On Screen system will conduct a series of tests and when the testing is completed the next screen will be displayed automatically. Do not press any buttons while testing is in progress.

Press ENTER twice to watch TV.

Watching TV (TV Guide On Screen)

Using TV Guide On Screen

Basic buttons on the remote control

Button

TV GUIDE

INFO

a/b/c/d

ENTER

DAY l/k c/d

MENU PAGE r/s

(CH r/s)

How to go to Service Bar

●

• When watching TV, enters the Guide and highlights a program listing.

• When in the Guide, exit the Guide without changing channels.

• The Info Box contains information about a program, service, ad, or provides general help. The size of the Info Box can be set to “Small” or “Large”, or not to be displayed by selecting “No”. The default size of the Info Box is “Small”. Press INFO to cycle among “Small”, “Large” and “No”.

• Provides directional control.

• When watching TV, press a/b to scroll through the channel list.

• Makes a selection or executes an action.

• With a currently airing program listing highlighted, returns to normal TV viewing and tunes to the program channel.

• With a future airing program listing highlighted, displays a Panel menu with viewing options.

• Shows the program listing for a different day.

• Selects the time on the changed listing.

• Display the Options for the Guide.

• Moves one page up or one page down in the LISTINGS grid.

The service provided by TV Guide On Screen is composed of four services: SETUP, LISTINGS, SEARCH and SCHEDULE. To make detailed settings for each service, it is necessary to select the service bar and change the selected service.

Description

Video Window

Clock

Lock/Unlock Icon

Video Window

When you enter the Guide, the TV program for the current show appears in the Video Window. The Video Window also includes a clock display and a lock/ unlock icon to indicate the status of the Video Window. You can set the Video Window to remain on a single channel (locked) or change channels (unlocked) as you navigate through Listings.

How to set the Video Window

• The TV Guide On Screen menus shown in this manual are for illustration purposes only. The channels, programs, and TV Guide On Screen information illustrated in this manual may not be available in your area. The options and features illustrated in this manual are subject to change when updates are downloaded from the TV Guide On Screen service to your TV.

• The TV Guide On Screen system does not display program listings for satellite TV systems.

Press c/d to highlight the desired Channel Logo.

Press MENU to display the Listings Options.

Press a/b to select “video” and then press c/d to select “locked” or “unlocked”.

NOTE

Choosing a program to watch - Using the LISTINGS

Press TV GUIDE.

Press MENU to display “Service Options”.

Press a/b to select “go to Service Bar”.

Press ENTER.

Press a/b/c/d to select the program to watch, and then press ENTER.

NOTE

• The current position of the cursor is highlighted in yellow.

• To cancel the Guide screen, press TV GUIDE.

Changes the day from within LISTINGS

• Press DAYl or DAYk to select the day you want to check the TV program table.

Watching TV (TV Guide On Screen)

Searching programs

You can search for programs alphabetically, by category - HDTV, MOVIES, SPORTS, CHILDREN, EDUCATIONAL, NEWS, VARIETY, SERIES - or by keyword, and the result is displayed in a list.

Search by category

●

You can search for programs by specifying category in the “Confirmation” screen.

When the LISTINGS screen is displayed, press MENU. Press a/b to select “go to Service Bar” from the “Episode Options” menu, and press ENTER.

Press c/d to select “SEARCH” and then press ENTER or b.

NOTE

• Repeat the same steps for the other categories.

• When you want to record a program found during a search, press MENU and after “Episode options” displays, carry out “Set recording”. (See page 27.)

Search by keyword

●

Keyword Search lets you enter a word to look for, a particular program by category or for every program title that matches.

Repeat steps 1 to 2 in Search by category.

Press c/d to select “KEYWORD”, and then press ENTER to display the “Keyword Search” menu.

Press a/b to select “new search”, and then press ENTER to display the “Search Options” menu.

Example: Searching for a program in the category “MOVIES”.

Press c/d buttons to select “MOVIES” (=Search type) and press b to display the movies genre.

Press a/b/c/d to select a genre within “MOVIES”. (e.g.: select “ALL” and press

ENTER)

• BKSP: Backspace

• DEL: Delete

• CLR: Clear

Press a to select “category” to search, and then press c/d to select the desired category.

Press b to select “enter keyword”, and then press ENTER. Press a/b/c/d to select a character, and press ENTER to display it. When complete, press a/b/c/d to select “DONE” and press ENTER.

NOTE

Press a/b to select a program you want to watch, and then press ENTER.

A list of all matching programs is displayed. Press b to highlight the program you want to watch, and press ENTER.

Watching TV (TV Guide On Screen)

Edit keyword

This Guide stores all the keywords you created.

When the LISTINGS screen is displayed, press MENU. Press a/b to select “go to Service Bar” from the “Episode Options” menu, and press ENTER.

Press c/d to select “SEARCH” and then press ENTER or b.

Press c/d to select “KEYWORD”.

• The keyword list is displayed.

Press a/b to select the keyword you want to edit.

Press MENU to display the “Search Options” menu.

ALPHABETICAL search

●

Repeat steps 1 to 2 in Edit Keyword.

Press c/d to select “ALPHABETICAL”.

Press a/b/c/d to select the initial letter of the program.

Press ENTER and then the search result displays.

Press MENU to display “Episode Options”.

Delete keyword

Keywords may be deleted from the keyword list.

Press b to select “edit search”, and press ENTER.

Repeat steps 1 to 2 in Edit Keyword.

Press c/d to select “KEYWORD”.

Press a/b to select the keyword you want to delete.

Press MENU to display “Search Options” menu.

• On the “Episode Options”, if you want to set timer recording, select “set recording”.(See page 27.)

• If you want to set the reminder function for this program, select “edit reminder”.(See page 29.)

Press a/b to select “tune to channel”. You can watch the program on the LCD-TV.

NOTE

Press b to select “delete search”, and press ENTER.

Press a/b to select “Yes” to delete the keyword, or “No” to close the “Search Options” menu.

Watching TV (TV Guide On Screen)

Program recording using LISTINGS function

You can set any programs to record on a G-LINK connected recording device (VCR) directly from the LISTINGS for the appropriate day.

Set recording

●

Press a/b/c/d to select the program you want to record in the LISTINGS.

Press MENU to display “Episode Options”. Press a/b to select “set recording”, and then press ENTER to display “Record Options”.

Press a/b/c/d to set the following items.

Using RECORD button on the remote control

• Each time you press RECORD, you can change the record frequency.

Press a/b/c/d to select the program you want to record on the LISTINGS.

By pressing RECORD, the program you want to record is set to record on time. “on time” is the default setting and can be changed.

NOTE

Using Reminder function

You can set this function to remind you of the screening times for programs from LISTINGS and of programs you have set to record.

Using Episode Options

Press MENU to display “Episode Options”. Press a/b to select “set reminder”, and then press ENTER to display “Remind Options”.

Press a/b/c/d to set the following items.

Setup items

frequency

start

end

recorder

once/regularly/weekly/ off

on time/120 min early ... 120 min late

VCR/i.LINK

Press ENTER to highlight “schedule

DescriptionSelectable items

Set the recording cycle

Set the start timing of recording

Set the end timing of recording

Set the external recording device

recording”.

• Device must be selected beforehand when using i.LINK as a recording device.

Press ENTER again to exit.

NOTE

Setup items

frequency

power on TV

auto tune TV

when

Press ENTER to highlight “schedule reminder”.

Press ENTER again to exit.

Selectable items

once/regularly/weekly/ off

yes/no

on time/30 sec - 15 min early ... 30 sec 15 min late

Description

Set the reminder cycle

When this is set to “yes”, the TV will automatically switch on at the time the reminder was set for.

When this is set to “yes”, the channel will be automatically changed before the reminder screen is displayed.

Set the timing to perform above two functions

Watching TV (TV Guide On Screen)

Using SCHEDULE function

The SCHEDULE is a list of programs created whenever you set a recording, or a reminder to watch a program. You can use this list to edit or delete the reminders and recordings you have set.

Sort programs

Press MENU to display “Episode Options”. Press a/b to select “go to Service Bar”, and then press ENTER.

You can sort Record and Remind programs in SCHEDULE list.

Press c/d to select “SCHEDULE”.

The program listings in SCHEDULE display a range of icons and show information about the settings for each program.

Function

Record (Using “Record Options”)

Once

Daily

Regularly

Weekly

Off

Suspend

Icon

Records the program one time.

Indicates the program is set to record daily (manual record setting only).

Records the program every time the program airs on the same channel and starts at the same time.

Records the program each time the program airs on the same day of the week, on the same channel and starts at the same time.

Keeps the program in the list but will not record this program until the frequency is changed.

• The program is suspended due

• Recording resumes when the

Description

to a schedule conflict. (The program remains in Schedule.)

conflict no longer exists.

Press MENU to display “Schedule Options”.

Press c/ d to select how to sort the SCHEDULE.

Selected item

date

title

event

Press a/b to select “done”.

Description

Both Record and Remind programs are intermixed and sorted by scheduled date, with the next scheduled program at the top.

Both Record and Remind programs are intermixed and sorted by program title into alphabetical order.

Sorts first Record programs and then Remind programs, by date.

Remind (Using “Remind Options”)

Once

Daily

Regularly

Weekly

Off

Suspend

Set a program reminder one time.

Indicates the program is set to remind daily (manual remind setting only).

Set a program reminder every time the program airs on the same channel and starts at the same time.

Set a program reminder each time the program airs on the same channel and starts at the same time.

Keeps the program in the list but will not remind this program until the frequency is changed.

• The program is suspended due to a schedule conflict. (The program remains in Schedule.)

• Remind resumes when the conflict no longer exists.

Watching TV (TV Guide On Screen)

Delete recording

Edit recording

Repeat steps 1 and 2 in Using SCHEDULE function.

Press a/b to select the program you want to delete.

Press MENU to display “Schedule Options”.

Press a/b to select “delete recording”, and then press ENTER.

• Confirmation screen displays.

Press a/b to select “yes” or “no”.

Repeat steps 1 to 2 in Using SCHEDULE function.

Press a/b to select the program you want to edit.

Edit reminder

Repeat steps 1 to 2 in Using SCHEDULE function.

Press a/b to select the program for which you want to set the reminder.

Press MENU to display “Schedule Options”.

Press a/b to select “edit reminder”, and then press ENTER to display “Remind Options”.

• You can change the setting items again.

Press ENTER to highlight “schedule reminder”.

Press ENTER again to exit.

Press MENU to display “Schedule Options”.

Press a/b to select “edit recording”, and then press ENTER to display “Record Options”.

• You can change the setting items again.

Press ENTER to highlight “schedule recording”.

Press ENTER again to exit.

Watching TV (TV Guide On Screen)

New manual recording

Aside from setting recordings using the program LISTINGS menus, you can also define the schedule of recordings manually by following the steps below.

Setup items

date

start

end

channel

input

recorder

frequency

Press a/b to select the program you want to record.

Press MENU to display “Record Options”.

Press a/b to select “new manual recording” and then press ENTER.

• “Record Options” screen displays.

DescriptionSelectable items

—

analog/digital air/ digital cable/input 1/ input 2/input 3/

VCR/i.LINK

once/weekly/daily/off

Set a date to record

Set a start time to record

Set an end time to record

Set a channel to record using 0–9

Set the external recording device or antenna source

Select a recorder you connected

Set the recording cycle

Press ENTER to highlight “schedule recording”.

Press ENTER again to exit.

New manual reminder

Instead of setting a reminder from the program LISTINGS, you can set a reminder manually for a program that you want to watch or a recording you have set.

Setup items

date

start

end

channel

input

power on TV

auto tune TV

frequency

Press a/b to select the program you want to set reminder.

Press MENU to display “Remind Options”.

Press a/b to select “new manual reminder” and then press ENTER.

• “Remind Options” screen displays.

DescriptionSelectable items

—

analog/digital air/ digital cable/input 1/ input 2/input 3/

yes/no

once/weekly/daily/off

Set a date to remind

Set a start time to remind

Set an end time to remind

Set a channel to remind using 0–9

Set the external device or antenna source

When this is set to “yes”, the TV will automatically switch on at the time the reminder was set for.

When this is set to “yes”, the channel will be automatically changed before the reminder screen is displayed.

Set the reminder cycle

NOTE

• The program set to be manually recorded is listed by channel number in the SCHEDULE.

Press ENTER to highlight “schedule reminder”.

• The program set to be manually reminded is listed by channel number in the SCHEDULE.

Press ENTER again to exit.

NOTE

Watching TV (TV Guide On Screen)

Changing system settings

After you initially complete Guide Setup, you can make changes to System settings in the “SETUP” screen.

Press TV GUIDE and then press MENU.

Press a/b to select “go to Service Bar” in “Episode Options”, and then press ENTER.

Press c/d to select “SETUP” .

Press b to select “Change system settings”.

Changing channel display

This setting lets you edit channel information that appears in LISTINGS.

You can set each function as follows:

1. Re-order the position the channel appears in

LISTINGS

2. Change the channel number

3. Switch a channel

• On - the channel is always displayed

• Off - the channel is never displayed

• Auto-Hide - the channel is only displayed when

program information is available

Repeat steps 1 to 3 in Changing system settings.

Press a/b to select “Change channel display”, and then press ENTER.

Press ENTER to display the “Confirming Your Settings” screen.

Selected item

channel

• If you want to change System settings, select “No, repeat setup process” and then press ENTER.

• If the setting details displayed on the screen is correct, select “Yes, everything is correct”, and then press ENTER.

• If the channel lineup is incorrect, select “Yes, but my channel lineup is incorrect”, and then press ENTER.

service tune channel position

• Depending on the channel currently being received you may be able to select “service”.

Press ENTER to display the “Grid Options” screen.

Press a/b/c/d to set the following items.

Description

off/on/auto-hide

Air/Cable/Cablebox

Set the channel number you want to display

Set the channel display position.

Press a/b to select “done”, and then press

ENTER to exit.

Watching TV (TV Guide On Screen)

Changing default options

This setting lets you change the default settings as follows.

General default options

Press TV GUIDE and then press MENU.

Press a/b to select “go to Service Bar” in “Episode Options”, and then press ENTER.

Press c/d to select “SETUP” .

Press b to select “General default options”, and press ENTER.

Record default options

Press TV GUIDE and then press MENU.

Press a/b to select “go to Service Bar” in “Episode Options”, and then press ENTER.

Press b to select “Record defaults”, and press ENTER.

Press ENTER to display “Record Defaults”.

Setup items

Info box size

box cycle

auto guide

Press MENU to display “General Defaults”.

Press a/b/c/d to set the following items.

last used/no/small/ large

all/no only/small only/ large only/no & small/ no & large/small & large

on/off

DescriptionSelectable items

Set the initial info box size when you enter the TV Guide On Screen

Set the info box rotation when you press INFO

When this is set to “on”, automatic entry into the TV Guide On Screen when you turn on the TV

Setup items

start

end

recorder

Press a/b/c/d to set the following items.

DescriptionSelectable items

on time/120 min early ... 120 min late

VCR

Set the start timing of recording

Set the end timing of recording

Set the external recording device

When you have finished, press a/b to select “done”, and then press ENTER again to exit.

Watching TV (TV Guide On Screen)

Remind Default Options

Press TV GUIDE and then press MENU.

Press a/b to select “go to Service Bar” in “Episode Options”, and then press ENTER.

Press b to select “Remind defaults”, and then press ENTER.

Press ENTER to display “Remind Defaults”.

Setup items

power on TV

auto tune TV

when

Press a/b/c/d to set the following items.

When you have finished, press a/b to select “done”, and then press ENTER again to exit.

yes/no

on time/30 sec - 15 min early ... 30 sec 15 min late

DescriptionSelectable items

When this is set to “yes”, the TV will automatically switch on at the time the reminder was set for.

When this is set to “yes”, the channel will be automatically changed before the reminder screen is displayed.

Set the timing to perform above two functions

Watching TV

Changing channels-Air/Cable

You can change channels in several ways by pressing AIR or CABLE to select the antenna and then following one of the methods below .

Method 1

Using CHr/s on the remote control unit or on the TV.

Method 2

1. Press FLASHBACK to switch to the previously tuned

channel.

2. Press FLASHBACK again to switch back to the

currently tuned channel.

NOTE

• FLASHBACK will not work if no channel has been

changed after TV is turned on.

Method 4

1. Press INPUT.

2. Press a/b to select CableBox [TV], and then press

ENTER.

INPUT SOURCE

CableBox [TV]

INPUT1 INPUT2 INPUT3 INPUT4

INPUT5INPUT5

i.LINK

3. Press CHr/s to change the channel of the cable

box.

Method 3

Using remote control buttons (0–9, • (DOT) to select

channels for VHF/UHF/CATV/DIGITAL.

To select a 1 or 2-digit channel number (e. g., Channel 5):

NOTE

s ENT

Air

Air ANALOG

Press 5

• When selecting a 1-digit channel number, it is not

necessary to press 0 before the number.

• When you enter 0–9 only, channel selection will be made

if there is no operation for a few seconds.

To select a 3-digit channel number (e. g., Channel 115):

Press 1

s1s5

Cable

Cable ANALOG

115

To select a 4-digit channel number (e. g., Channel 22.1):

Press 2

s2s• (DOT) s1s ENT

Air

Air Air DIGITAL

22.

Air

22.1

NOTE

• When you enter 0–9 only, channel selection will be made

if there is no operation for a few seconds.

• If you push “0” by itself, nothing will happen.

• Complete the above steps within a few seconds.

• When you enter 0–9 and • (DOT), channel selection will

be made if there is no operation for a few seconds.

Watching TV

Changing volume/sound

■ Changing the volume

You can change the volume on the TV or on the remote control unit.

■ Using VOL

• To increase the volume, press VOL

• To decrease the volume, press VOL

NOTE

• VOL l/kon the TV operates the same as VOL k/l on

the remote control unit.

Volume adjustment

■ Using MUTE on the remote control unit

Mutes the current sound output.

Press MUTE.

•“M” will be displayed on the screen for 30

minutes, and the sound is silenced.

Mute

NOTE

• Within 30 minutes of pressing MUTE, mute can be canceled by using one of the methods below.

• Mute will cancel if you press VOL l/k or MUTE.

• Mute will be canceled after 30 minutes have passed. However, the TV will not suddenly output a loud sound as the volume level is set to 0 automatically.

Audio status

specified

Output Select

VariableFixed

Mute

Variable sound

Output device

Speaker

MONITOR OUT

* When “Output Select” is set to “Variable”, the indicator on

the screen changes as shown below.

Variable sound

Constant as

NOTE

• See page 71 for details on the output select function.

■ Using Virtual on the remote control unit

Virtual produces Dolby Virtual effect from the

speakers. Each time you press changes between On and Off.

Dolby Virtual sound options

• On: Makes it possible to enjoy natural, realistic

surround sound.

• Off: Outputs the normal sound.

Dolby Virtual : Off

NOTE

• You can have the same settings by choosing “Dolby Virtual” on the menu items. (See page 48.)

Virtual, the mode

Dolby Virtual : On

Watching TV

Setting MTS/SAP stereo mode

The TV has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The TV with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.

• Stereo broadcasts

View programs like live sporting events, shows and concerts in dynamic stereo sound.

• SAP broadcasts

Receive TV broadcasts in either MAIN or SAP sound. MAIN sound: The normal program soundtrack (either in mono or stereo). SAP sound: Listen to second language, supplementary commentary and other information. (SAP is mono sound.)

If stereo sound is difficult to hear.

• Obtain a clearer sound by manually switching to fixed mono-sound mode.

NOTE

• MTS only operates while in TV mode.

You can change MTS as shown below to match the television broadcast signal.

Setting Digital broadcasting audio mode

The types of audio transmitted in a digital broadcast include SURROUND as well as MONO and STEREO. In addition, it is possible for multiple audio tracks to accompany a single video track.

Press AUDIO to toggle between audio modes.

Examples: when receiving Digital broadcasting

Air DIGITAL

2.2

Audio1 : STEREO

Air DIGITAL

2.2

Audio2 : STEREO

Air DIGITAL

2.2

Audio3 :

SURROUND

Examples: when receiving MTS and SAP

STEREO mode MAINkSAP mode

Air ANALOG

Audio : STEREO

Air ANALOG

Audio : MONO

Air ANALOG

Audio : MAIN

Air ANALOG

Audio : SAP

STEREOkSAP mode MONO mode

Air ANALOG

Audio : ST(SAP)

Air ANALOG

Audio : MONO

Audio : SAP(ST)

Air ANALOG

Audio : MONO

Watching TV

Connecting Digital Cable Module

Digital Cable Module is called CableCARD™. By attaching the CableCARD, you can receive various digital services provided by your Cable Company. To obtain and use a CableCARD you need to first submit an application. Please contact your cable company to discuss receiving an application.

NOTE

• If your cable company does not have CableCARD available, you must connect to the cable-TV set-top box via component video or DVI in order to receive HDTV programs. (See page 55.)

■ When you change your address (See page 89.)

■ About EAS (Emergency Alert System) (See page

89.)

Turn on the power of the TV.

Press c/d to select “Digital Setup”, a/b to

select “CableCARD Menu”, a/b to select “Pairing Information”, and then press

ENTER.

Connect the antenna cable to DIGITAL CABLE IN.

Insert the CableCARD (upper side facing

right) into the CableCARD slot.

• A message will appear on the screen. (It might take a couple of minutes before the message appears.) Call the number on the screen and tell the operator the CableCARD ID and Host ID numbers displayed on the screen.

CableCARD(tm) Pairing Status

In order to start cable service for this device, please contact your cable provider 1-888-555-2222

CableCARD™ ID: 7-561-034-449-009 Host ID: 0-100-331-784-018

NOTE

• Do not insert any PCMCIA card other than CableCARD into the CableCARD slot.

• Please do not pull the AC cord out while the CableCARD is inserted.

• After inserting the CableCARD, it may take several minutes before video output from the selected channel appears on screen.

■ If the above procedure does not work,

please follow the following steps instead.

Press MENU and the MENU screen displays.

Conditional Access

Pairing Information

Diagnostic Screen

ECM

• The words “Pairing Information” may be replaced by a different expression depending on the manufacturer of the CableCARD.

A message will appear on the screen. Call

the number on the screen and tell the operator the CableCARD ID and Host ID numbers displayed on the screen.

CableCARD Dialog CableCARD(tm) Pairing Status

In order to start cable service for this device, please contact your cable provider 1-888-555-2222

CableCARD(tm) ID: 7-561-034-449-009 Host ID: 0-100-331-784-018

• If there is a white triangle at the right side of the screen, the screen is not showing the entire message. Press a/b on your remote control to display the rest of the message.

• When there is a “LINK” button on the screen, there is a link to the next page. Press ENTER to go to the next page.

CableCARD(tm) Diagnostic Information

Power: ON In band: O.K. Out of band: O.K. Video: O.K. Audio: O.K.

LINK

Removing CableCARD

1 Turn on the power of the TV. 2 Check that the CableCARD upgrade screen is not

displayed. If it is displayed, wait until it disappears.

3 Remove the CableCARD.

Disconnecting the cable antenna

1 Turn on the power of the TV. 2 Check that the CableCARD upgrade screen is not

displayed. If it is displayed, wait until it disappears.

3 Disconnect the cable antenna.

Basic adjustment settings

AV input mode menu items

List of AV menu items to help you with operations


OPC ................................................ Page 45

Backlight ........................................ Page 44

Contrast ......................................... Page 44

Brightness ..................................... Page 44

Color ............................................... Page 44

Tint ................................................. Page 44

Sharpness...................................... Page 44

Advanced

C.M.S. ................................... Page 45

Color Temp. ......................... Page 46

Black .................................... Page 46

3D-Y/C .................................. Page 46

Monochrome ....................... Page 47

Film Mode ............................ Page 47

I/P Setting ............................ Page 47

Audio

Treble.............................................. Page 48

Bass ............................................... Page 48

Balance .......................................... Page 48

Dolby Virtual .................................. Page 48

Option

Audio Only ..................................... Page 70

Digital Noise Reduction ............... Page 70

HDMI Setup .................................... Page 56

Input Select.................................... Page 66

Output Select................................. Page 71

Quick Shoot ................................... Page 71

Caption Setup......................... Pages 73-76

Program Title Display ................... Page 72

Digital Setup

CableCARD Menu ......................... Page 37

Video Setup ................................... Page 50

Audio Setup ................................... Page 51

i.LINK Setup............................ Pages 58-63

Power Control

No Signal Off ................................. Page 49

No Operation Off ........................... Page 49

Setup

EZ Setup ................................ Pages 39, 40

CH Setup ................................ Pages 40, 41

Antenna Setup-DIGITAL ............... Page 42

Input Label ..................................... Page 67

Parental CTRL ........................Pages 79-83

Position .......................................... Page 64

Picture Flip .................................... Page 67

Standby Mode ............................... Page 42

Language ....................................... Page 43

Basic adjustment settings

*PC input mode menu items

List of PC menu items to help you with operations

*When INPUT5 is set to PC.


OPC ................................................ Page 45

Backlight ........................................ Page 44

Contrast ......................................... Page 44

Brightness ..................................... Page 44

Red ................................................. Page 44

Green .............................................. Page 44

Blue ................................................ Page 44

Advanced

C.M.S. ................................... Page 45

Audio

Treble.............................................. Page 48

Bass ............................................... Page 48

Balance .......................................... Page 48

Dolby Virtual .................................. Page 48

Power Control

Power Management ...................... Page 49

EZ Setup

You can run EZ Setup again, even after setting up the preset channels.

Language setting

Select from among 3 languages: English, French and Spanish.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “EZ Setup”, and then press ENTER.

• If you already set the Secret No., go to step 4. If not, skip to step 5.

Input the 4-digit secret number by using 0 – 9.

...

[

Setup

Setup Option

Secret No.

EZ Setup

]

––––

Setup

Input Signal ................................... Page 70

Auto Sync. ..................................... Page 65

Input Label ..................................... Page 67

Fine Sync. ...................................... Page 65

Picture Flip .................................... Page 67

Standby Mode ............................... Page 42

Language ....................................... Page 43

Option

Audio Only ..................................... Page 70

Input Select.................................... Page 66

Output Select................................. Page 71

Quick Shoot ................................... Page 71

Digital Setup

i.LINK Setup............................ Pages 58-63

Press a/b to select the desired language listed on the screen, and then press ENTER.

Language

Air/Cable

CH Search

English

Français

Español

Basic adjustment settings

Antenna setting

Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for ANALOG and DIGITAL (Cable).

Press c/d to select “Air”, “Cable”, for ANALOG, then press b to move down. Press c/d to select “Standard”, “HRC”, “IRC” for DIGITAL (Cable). Press ENTER to enter the setting.

• There are 3 kinds of CATV system, including Standard, HRC and IRC. Select the one matches to your TV.

• If cable or antenna connection was selected for the ANALOG IN terminal at the time when you set up TV Guide On Screen, the analog settings cannot be changed afterward. If you need to change the analog settings, you will have to change the TV Guide On Screen settings first.

Channel search

Channel auto search makes the TV look for all channels viewable in the set area.

• This operation makes the TV search for both ANALOG, DIGITAL (Air) and DIGITAL (Cable) channels.

Language

Air/Cable

CH Search

ANALOG

DIGITAL (Air)

DIGITAL (Cable) Yes No

Search Start

Yes

Yes No

Channel Setup

If initial setup does not memorize all the channels in your region, follow the instructions below to manually memorize the channels.

Antenna setting

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “CH Setup”, and then press ENTER.

• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.

Air/Cable

CH Search

CH Memory

ANALOG

DIGITAL (Cable)

Air

Standard

Press a/b to select “Air/Cable”, and then press ENTER.

Searching TV channels

Example

...

[

Setup

[

Setup

[

Setup

EZ Setup

...

EZ Setup

...

EZ Setup

ANALOG [ ]25 [ ]20FoundAir

DIGITAL [ ]25 [ ]20FoundAir

DIGITAL [ ]25 [ ]25

NOTE

• If no channel is found, make sure what kind of connection is made with your TV and try EZ Setup again.

• Make sure what kind of connection is made with your TV.

...

CH Search

...

CH Search

...

CH Search

]

FoundCable

Press c/d to select “Air”, “Cable”, for ANALOG, then press b to move down. Press c/d to select, “Standard”, “HRC”, “IRC” for DIGITAL (Cable). Press ENTER to enter the setting.

Example

Air/Cable

CH Search

CH Memory

NOTE

• Make sure what kind of connection is made with your TV.

• There are 3 kinds of CATV system, including Standard, HRC and IRC. Select the one matches to your TV.

ANALOG

DIGITAL (Cable)

Air

Standard

Basic adjustment settings

Channel search

Channel auto search makes the TV look for all channels viewable in the set area.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “CH Setup”, and then press ENTER.

• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.

Press a/b to select “CH Search”, and then press ENTER.

Air/Cable

CH Search

CH Memory

ANALOG Yes

DIGITAL (Air)

DIGITAL (Cable) Yes No

Search Start

Yes No

Example: CH Search

...

[

Setup

ANALOG [ ]25 [ ]20

CH Setup

...

CH Search

]

FoundAir

Channel memory setting

• On: Skips channels. (Channel selection disabled using

• Off: Does not skip channels. (Channel selection enabled

using CH

• Make sure what kind of connection is made with your TV.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “CH Setup”, and then press ENTER.

• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.

Press a/b to select “CH Memory”, and then press ENTER.

Press a/b to select ANALOG, DIGITAL (Air), DIGITAL (Cable) and CableCARD, and then press ENTER.

Perform the following steps after confirming the type of antenna connection made with your TV, and the channel type selected in Step 5.

When viewing ANALOG broadcasts:

1 Press a/b, and then press c/d to select

the channel to skip or not.

2 Press a/b to select “Skip”, and then press

c/d to select “On” or “Off”.

When viewing DIGITAL broadcasts:

1 Press a/b to select the channel to skip or

not, and then press c/d to select “On” or “Off”.

s.)

NOTE

...

[

Setup

[

Setup

CH Setup

...

CH Setup

DIGITAL [ ]25 [ ]20

DIGITAL [ ]25 [ ]25

...

CH Search

...

CH Search

]

FoundAir

]

FoundCable

NOTE

• Make sure what kind of connection is made with your TV.

Basic adjustment settings

Antenna Setup – DIGITAL – Air

In order to receive digital air broadcasts, you need a digital broadcast antenna. You can confirm the antenna configuration through the “Antenna Setup - DIGITAL” screen.

If necessary, adjust the direction of the antenna to obtain the maximum signal strength.

Signal Strength

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Antenna Setup DIGITAL”, and then press ENTER.

• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.

Press a/b to select “Signal Strength”.

• The signal strength of the DIGITAL (Air) antenna is displayed. The signal information is based on the current channel.

Signal Strength

Channel Strength

Standby Mode

Standby Mode may be set to either start the TV quickly from standby or conserve energy while on standby.

Selected item Description

Mode1

Mode2

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Standby Mode”, and then press ENTER.

Press a/b to select “Mode1” or “Mode2”, and then press ENTER.

Starting TV is quick from standby.

Power consumption is small at the standby.

Signal Strength

Current Max00

Channel Strength

• The channel signal strength can also be checked separately.

Repeat steps 1 to 3 in Signal Strength in Antenna Setup - DIGITAL - Air.

Press a/b to select “Channel Strength”, and then press ENTER.

Input the 2-digit channel number to check the signal strength of the selected channel.

• Make sure the appropriate signal strength of each channel received is obtained.

Signal Strength

Channel Strength

Signal Strength

Current

Max0

NOTE

• This function is available for DIGITAL (Air) only.

Basic adjustment settings

Favorite channel setting

This function allows you to program 4 favorite channels, in 4 different categories. By setting the favorite channels in advance, you can select your favorite channels easily.

Select the channel you want to register as a favorite channel.

Press EDIT.

Press a/b to select “Register”, and then press ENTER.

1 Data Clear

All Data Clear

Press a/b/c/d to select the channel you want to delete, and then press ENTER.

ABCD

ANALOG3ANALOG

ANALOG

Press c/d to select “Yes”, and then press

ANALOG

125

10.1

D-Air

ANALOG

ENTER.

Yes No

ABCD

ANALOG

125

D-Air

10.1

ANALOG

NOTE

• You can delete all the favorite channels by selecting “All Data Clear” in step 2 in Deleting favorite channel.

Language setting

You can also select a language from the Setup menu. Select from among 3 languages: English, French and Spanish.

Press a/b/c/d to select the position in the area, and then press ENTER to register.

ABCD

ANALOG

Deleting favorite channel

Press EDIT and the favorite channel screen displays.

Press a/b to select “1 Data Clear”, and then press ENTER.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Language”, and then press ENTER.

Press a/b to select the desired language listed on the screen, and then press ENTER.

English

Français

Español

Basic adjustment settings

Picture adjustments

Adjusts the picture to your preference with the following picture settings.

Adjustments for AV source

[

]


Picture Audio

OPC

Backlight [ +8] –8

Contrast

Brightness

Color

Tint

Sharpness

Advanced

Reset

[+30]

[ 0]

Off On

–30

–10

On : Display

+40

+30

+10

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select a specific adjustment item.

Press c/d to adjust the item to your desired position.

NOTE

• For resetting all adjustment items to factory preset values, press a/b to select “Reset”, press ENTER, press c/d to select “Yes”, and then press ENTER.

Adjustments for PC source

[

]


Picture Audio

OPC

Backlight [ +8] –8

Contrast

Brightness

Red

Green

Blue

Advanced

Reset

Off On

[+30]

[ 0]0–30

[ 0]

–30

[ 0]

–30

[ 0]

–30

On : Display

+40

+30

Selected item

Backlight

Contrast

Brightness

Color

Tint

Sharpness

cbutton

The screen dims

For less contrast

For less brightness

For less color intensity

Skin tones become purplish

For less sharpness

dbutton

The screen brightens

For more contrast

For more brightness

For more color intensity

Skin tones become greenish

For more sharpness

NOTE

• Select “Advanced” and then press ENTER to set “C.M.S-

Hue”, “C.M.S-Saturation”, “C.M.S-Value”, “Color Temp.”, “Black”, “3D-Y/C”, “Monochrome”, “Film Mode” or “I/P Setting”. See pages 45 to 47.

Selected item

Backlight

Contrast

Brightness

Red

Green

Blue

cbutton

The screen dims

For less contrast

For less brightness

For weaker red

For weaker green

For weaker blue

dbutton

The screen brightens

For more contrast

For more brightness

For stronger red

For stronger green

For stronger blue

NOTE

• Select “Advanced” and then press ENTER to set “C.M.S-

Hue”, “C.M.S-Saturation” and “C.M.S-Value”.

Basic adjustment settings

OPC setting

Automatically adjusts the brightness of the screen.

Selected item

Off

On On: Display

• When set to “On”, the OPC senses the surrounding light and automatically adjusts the backlight brightness. Make sure no object obstructs the OPC sensor, which could affect its ability to sense surrounding light.

• When set to “On: Display”, OPC effect displays on the screen while OPC is adjusting the screen brightness.

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “OPC”.

Press c/d to select “On” or “On: Display”.

OPC

Backlight [ +8] –8

Contrast

Brightness

Color

Tint

Sharpness

Advanced

Reset

NOTE

Off On On : Display

[+30]

–30

[ 0]

–30

[ 0]

–30

–10

[ 0]

Description

The brightness is fixed at the value set in “Backlight” (see page 44).

Automatically adjusts

Displays the OPC effect on the screen while adjusting the brightness of the screen.

+40

+30

+10

C.M.S. (Color Management System)

Color tone is managed using the six-color adjustment setting.

Selected item

C.M.S-Hue

C.M.SSaturation

C.M.SValue

• For resetting all adjustment items to the factory preset

values, press a/b to select “Reset”, and then press ENTER.

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “Advanced”, and then press ENTER.

Press a/b to select “C.M.S-Hue”, and then press ENTER.

• You can select “C.M.S-Saturation” or “C.M.SValue” here instead of selecting “C.M.S-Hue”.

Press a/b to select a specific adjustment item. Press c/d to adjust the item to your desired position.

C. M. S.-Hue

NOTE

C. M. S.-Saturation

C. M. S.-Value

Changing reds

closer to

magenta or yellow.

This is a standard to adjust the color either more reddish or more bluish in tone.

Increases or decreases the saturation of a selected color.

A higher value makes the image brighter. A lower value makes the image darker.

[ 0]

[ 0] –30

Reset

Description

–30

+30

Basic adjustment settings

Color temperature

For a better white balance, use color temperature correction.

Selected item

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “Advanced”, and then press ENTER.

Press a/b to select “Color Temp.”, and then press ENTER.

C. M. S-Hue

C. M. S-Saturation

C. M. S-Value

Color Temp.

Black

3D-Y/C

Monochrome

Film Mode

I/P Setting

High

Mid-High

Middle

Mid-Low

Low

Press a/b to select the desired level, and then press ENTER.

Description

Black

For easier viewing, change the viewing depth by selecting a level for automatically adjusting the dark portion of an image.

Repeat steps 1 to 3 in Color temperature.

Press a/b to select “Black”, and then press

ENTER.

Press c/d to select “On”, and then press

ENTER.

Selected item

Off On

No adjustment

For high detail in black portions

Description

3D-Y/C

Provides high quality images with minimal dot crawl and cross color noise.

Repeat steps 1 to 3 in Color temperature.

Press a/b to select “3D-Y/C”, and then press ENTER.

High Mid-High Middle Mid-Low Low

White with Bluish tone

White with Reddish tone

Press a/b to select the desired level, and then press ENTER.

Selected item

Standard Fast Slow

NOTE

• 3D-Y/C is available for input signal from Composite Video and ANALOG IN.

Normal adjustment

For movie image

For still image

Description

Basic adjustment settings

Monochrome

For viewing a video in monochrome.

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “Advanced”, and then press ENTER.

Press a/b to select “Monochrome”, and then press ENTER.

C. M. S-Hue

C. M. S-Saturation

C. M. S-Value

Color Temp.

Black

3D-Y/C

Monochrome

Film Mode

I/P Setting

On Off

I/P Setting

Converts input signals from interlace to progressive.

• I/P Setting is set to Slow when Film Mode is “On”.

• “I/P Setting” is not selectable when channel display shows an input resolution of 480P or 720P.

Repeat steps 1 to 3 in Monochrome.

Press a/b to select “I/P Setting”, and then press ENTER.

Press c/d to select “Fast” or “Slow”, and then press ENTER.

NOTE

Press c/d to select “On”, and then press

ENTER.

Selected item

Off On

Normal color

For viewing in monochrome

Description

Film Mode (3:2 pull-down)

Automatically detects a film-based source (originally encoded at 24 frames/second), analyzes it then recreates each still film frame for high-definition picture quality.

Selected item

Off On

Repeat steps 1 to 3 in Monochrome.

Press a/b to select “Film Mode”, and then press ENTER.

Press c/d to select “On”, and then press

ENTER.

Description

Normal viewing mode

Detects, analyzes, converts film source

Basic adjustment settings

Sound adjustment

You can adjust the sound quality to your preference with the following settings.

Selected item

Treble

Bass

Balance

Press MENU and the MENU screen displays.

Press c/d to select “Audio”.

[

]

Audio

Audio Power Control

Treble

Bass

Balance

Dolby Virtual

Reset

[ 0]

–15

+15

[Off]

Press a/b to select a specific adjustment item.

Press c/d to adjust the item to your desired position.

cbutton

For weaker treble

For weaker bass

Decrease audio from the right speaker

dbutton

For stronger treble

For stronger bass

Decrease audio from the left speaker

Dolby Virtual

You can enjoy the SURROUND 2ch stereo with Dolby Pro Logic II technology.

VIRTUAL DOLBY DIGITAL is a technology certified by Dolby Laboratories that creates a virtualized surround sound experience from two speakers using Dolby Pro Logic or Dolby Pro Logic II.

VIRTUAL DOLBY DIGITAL retains all the original multichannel audio information and provides the listener with the sensation of being surrounded by additional speakers.

Press MENU and the MENU screen displays.

Press c/d to select “Audio”.

Press a/b to select “Dolby Virtual”, and then press ENTER.

...

[

Audio

[ 0]

Dolby Virtual

–15

Audio Power Control

Treble

Bass

Balance

Dolby Virtual

Reset

]

+15

[Off]

Press c/d to select “On”, and then press

ENTER.

NOTE

• Audio menu is grayed out when Output Select is set to “Variable”.

• “Balance”, “Treble” and “Bass” are grayed out when Dolby Virtual is set to “On”.

• For resetting all adjustment items to factory preset values, press a/b to select “Reset”, press ENTER, press c/d to select “Yes”, and then press ENTER.

NOTE

• You can choose Dolby Virtual by pressing Virtual on

the remote control unit.

• Audio menu is grayed out when Output Select is set to “Variable”.

• “Balance”, “Treble” and “Bass” are grayed out when Dolby Virtual is set to “On”.

• For some discs, setup may be required on your DVD. In this case, please refer to the operation manual of your DVD player.

Basic adjustment settings

Power Control

Power control setting allows you to save energy.

Power control for AV source

No signal off

When set to “Enable”, the power will automatically shut down if no signal inputs for 15 minutes.

• “Disable” is factory preset value.

• When a TV program finishes, this function may not operate.

No operation off

When set to “Enable”, the power will automatically shut down if there is no operation for 3 hours.

Press MENU and the MENU screen displays.

Press c/d to select “Power Control”.

Press a/b to select “No Signal Off”, and then press ENTER.

Press c/d to select “Enable”, and then press ENTER.

DisableEnable

• Five minutes before the power shuts down, remaining time displays every minute.

NOTE

Power control for PC source

Power control setting allows you to save energy.

Power management

When set, the power will automatically shut down.

Selected item

Off

Mode1

Mode2

Repeat steps 1 and 2 in No signal off.

Press a/b to select “Power Management”, and then press ENTER.

Press a/b to select “Mode1” or “Mode2”, and then press ENTER.

Off

Mode1

Mode2

Description

• No power management

• Factory preset value.

• If no signal inputs for 8 minutes, the power shuts down.

• Even if you start using the PC and the signal inputs again, the TV stays off.

• The TV turns on again by pressing TV POWER on the remote control unit. (See page 17).

• Pressing POWER on the TV will have the same result.

• If no signal inputs for 8 seconds, the TV enters standby mode.

• When you start using the PC and the signal inputs again, the TV turns on.

Repeat steps 1 and 2 in No signal off.

Press a/b to select “No Operation Off”, and then press ENTER.

• “Disable” is factory preset value.

Press c/d to select “Enable”, and then press ENTER.

• Five minutes before the power shuts down, remaining time displays every minute.

NOTE

• When using a digital PC and setting “Mode2” in Power management, the power may not turn back on automatically even if the signal inputs again.

• If you turn off the power by disconnecting AC cord when setting “Mode2” in power management, the TV may not function properly after turning the power on again. In such case, press TV POWER on the remote control unit.

• Pressing POWER on the TV will have the same result.

Basic adjustment settings (DIGITAL)

Digital Setup

This setting allows you to set the image of Digital broadcasting.

Video Setup

You can adjust the settings for Digital image.

Screen Size

Set the format of image of Digital broadcasting.

Press MENU and the MENU screen displays.

Press c/d to select “Digital Setup”.

Press a/b to select “Video Setup”, and then press ENTER.

Press a/b to select “Screen Size”, and then press ENTER.

Screen Size

REC Picture Size

Select the screen size to record on 16:9 video.

Press MENU and the MENU screen displays.

Press c/d to select “Digital Setup”.

Press a/b to select “Video Setup”, and then press ENTER.

Press a/b to select “REC Picture Size”, and then press ENTER.

Screen Size

REC Picture Size

4 : 3 TV 16 : 9 TV

Press c/d to select the desired picture size, and then press ENTER.

Manual Auto

Selected item Description

Manual

Auto

• “Manual” is factory preset value.

Press c/d to select “Manual” or “Auto”.

With 480i/480p/720p broadcasts you can change the screen size to the size of your choice.

All broadcasts will be converted and displayed in the 1080i format.

NOTE

Selected item Description

4:3 TV

16:9 TV

Bars may appear on the top and bottom with some programs

Displays in full screen

Basic adjustment settings (DIGITAL)

Audio Setup

You can output digital audio to an AV amplifier or similar device whose DIGITAL AUDIO INPUT terminal is connected to the DIGITAL AUDIO OUTPUT terminal on the TV. Please select an audio output format compatible with the audio format of the program you are watching and the equipment connected.

Selected item Description

PCM

Press MENU and the MENU screen displays.

Press c/d to select “Digital Setup”.

Press a/b to select “Audio Setup”, and then press ENTER.

Press a/b to select “PCM” or “Dolby Digital”, and then press ENTER.

PCM

Dolby Digital

The optical output terminal outputs audio signal by PCM form. If your digital audio system does not support Dolby Digital, select “PCM”.

Dolby Digital

The optical output terminal outputs audio signal by Dolby Digital form. It reproduces sound from surround program of digital.

Using external equipment

CAUTION

You can connect many types of external equipment to your TV, like a DVD player, VCR, Digital TV tuner, PC, HDMI equipment, game console and camcorder. To view external source images, select the input source from

INPUT on the remote control unit or on the TV.

Displaying an external equipment image

Explanation here is for the setting when connecting DVD to INPUT1 terminal.

To watch a DVD image, select “INPUT1” from “INPUT SOURCE” menu using INPUT on the remote control unit or on the TV. (See page 66.)

INPUT SOURCE

TV CableBox [TV]

INPUT1

INPUT2 INPUT3 INPUT4

INPUT5INPUT5

i.LINK

NOTE

• If the image does not come in clearly, you may need to change the input signal type setting on the “Input Select” menu.

Selecting the INPUT signal

The setting is stored and can be selected on the “INPUT SOURCE” menu.

• To protect all equipment, always turn off the TV before connecting to a DVD player, VCR, Digital TV tuner, PC, HDMI equipment, game console, camcorder or other external equipment.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Input Select”, and then press ENTER.

...

[

Audio Only

Digital Noise Reduction

Input Select

Output Select

Quick Shoot

Option

Caption Setup

Program Title Display

Input Select

]

[Low]

[Auto]

[Fixed]

[Off]

[No]

Select the desired signal type.

For INPUT1 signal

...

COMPONENT

[

Option

Auto

VIDEO

Input Select

]

NOTE

• See pages 53 to 58 for external equipment connection.

• Please refer to the relevant operation manual (DVD player, PC, etc.) carefully before making connections.

• Each time INPUT is pressed, the input source toggles.

• Refer to your external equipment operation manual for the signal type.

Using external equipment

Connecting a DVD player

You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting to a DVD player and other audiovisual equipment.

When using component cable.

Component video cable

(commercially

available)

DVD player

When using composite cable.

Audio cable (commercially available)

AV cable (commercially

available)

DVD player

When using DVI cable. (INPUT 5)

ø 3.5 mm stereo minijack cable

(commercially available)

DVI cable (Commercially available)

DVD player

NOTE

• See page 56 for connecting a DVD player with HDMI terminal.

Using external equipment

Connecting a VCR

You can use the INPUT 3 terminal when connecting a VCR and other audiovisual equipment.

NOTE

• The S-video terminal has priority over the video terminals.

• The G-LINK cable connection is necessary if you want to use the recording features of the TV Guide On Screen system with your VCR.

G-LINK cable

This end is connected

S-video cable

(commercially

available)

AV cable (commercially available)

G-LINK

cable

to the TV.

VCR

1 inch

G-LINK wand

VCR

This connection is necessary when using TV Guide On Screen’s recording function.

(INPUT)(OUTPUT)

(commercially available)

Connecting a game console or camcorder

A game console, camcorder and some other audiovisual equipment are conveniently connected using the INPUT 3 terminals.

NOTE

• The S-video terminal has priority over the video terminals.

S-video cable (commercially

available)

AV cable (commercially available)

Game console/Camcorder

Using external equipment

Connecting a Digital TV STB (Air or Cable)

You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting a Digital TV STB (Air or Cable) and other audiovisual equipment.

NOTE

• If your cable-TV company has CableCARD available, you can also use the CableCARD to receive HDTV programs. (See page 37.)

When using component cable.

When using DVI cable. (INPUT 5)

Component video

(commercially

cable

available)

Digital TV STB

Audio cable (commercially available)

ø 3.5 mm stereo

NOTE

• See page 56 for connecting a Digital TV STB to HDMI terminal.

When using composite cable.

Cable box connection (for TV Guide On Screen)

minijack cable

(commercially

available)

DVI cable (Commercially available)

Digital TV STB

G-LINK cable

(commercially available)

AV cable

This end is connected to the TV.

Digital TV STB

G-LINK

cable

1 inch

NOTE

• To receive TV program listings in the TV Guide On Screen system, please connect your cable box using this input, marked “VIDEO”. Do not connect the cable box to the “COMPONENT” video as you will not receive any TV program listings.

Cable Box

G-LINK wand

Using external equipment

Connecting HDMI equipment

Please use the INPUT 4 terminal when connecting HDMI equipment.

HDMI cable (Commercially available)

HDMI equipment

Displaying an image from HDMI equipment

To watch an HDMI equipment image, select

“INPUT4” from “INPUT SOURCE” menu

Press a/b to select the desired item and press ENTER.

using INPUT on the remote control unit or on the TV. (See page 66.)

INPUT SOURCE

TV CableBox [TV] INPUT1 INPUT2 INPUT3

INPUT4 INPUT5INPUT5

i.LINK

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “HDMI Setup”, and then press ENTER.

...

[

Option

Audio Only

Digital Noise Reduction

HDMI Setup

]

[Low]

Press a/b/c/d to select the desired setting and press ENTER.

HDMI Setup items

Signal Type

Color Matrix

Dynamic Range

Auto View

NOTE

• Refer to your external equipment operation manual for the signal type.

Selectable items

Auto/RGB/YCbCr 4:4:4/YCbCr 4:2:2

Auto/ITU601/ ITU709

Standard/ Out of Standard

Enable/Disable

Description

Select the signal type from an HDMI terminal. Unless the image quality looks obviously poor, select Auto.

Select the internal color space conversion method when an RGB signal is input. Normally, select Auto.

Select the signal amplitude range. Normally, select Standard.

Set whether or not to use VIEW MODE based on signal recognition, including an HDMI signal.

Using external equipment

Connecting a PC

Use the INPUT 5 terminal to connect a PC.

NOTE

• Refer to page 93 for a list of PC signals compatible with the TV.

ø 3.5 mm stereo minijack cable

(commercially available)

PC with DVI terminal

DVI cable (Commercially available)

ø 3.5 mm stereo minijack cable (commercially available)

PC with analog RGB terminal

RGB/DVI conversion cable (Commercially available)

Using external equipment

Connecting D-VHS decks/AV-HDD recorder/Blu-ray Disc recorder (i.LINK connection)

About i.LINK

i.LINK is an interface connection using a serial transfer system and is able to transfer multimedia data, such as digital images and digital sound, between devices that have i.LINK terminals. i.LINK is a term defined in the IEEE1394 (Institute of Electrical and Electronics Engineers) standard. Currently, the transfer speeds are at 100 Mbps, 200 Mbps and 400 Mbps, each of them expressed as S100, S200 and S400 respectively. On this TV, the maximum speed is 400 Mbps.

i. LINK devices that can be connected to this TV.

Only D-VHS decks, AV-HDD recorders and Blu-ray Disc recorders can be connected to this TV via i.LINK. Other devices such as DVD recorders, digital video cameras, computers or computer peripheral devices do not meet the specifications for this TV and therefore cannot be connected via i.LINK. Even for the types of i.LINK device mentioned above, device recognition, control, recording and playback operations may not be possible on some devices.

Materials that can be recorded with the i.LINK

Only digital programs can be recorded by i.LINK devices connected to this TV using the i.LINK. i.LINK recording is not compatible with analog broadcasts or external input signals (INPUT terminals 1 through

5).

Connecting two or more i.LINK devices

Up to 16 i.LINK devices can be connected using a daisy-chain connection with i.LINK cables.

When 3 or more i.LINK devices are connected, branch connection can be used. With branch connections, up to 62 i.LINK devices can be connected.

Cautions regarding i.LINK connection

• Please use S400 type i.LINK cables.

• Some i.LINK devices may not relay data if their power is off. In this case the device should be connected at the end of any series of connections.

• This TV can relay data during power off, by selecting “Active” in the “Standby Mode” option in “i.LINK Setup”. (See Page 59.)

• Please do NOT use a loop connection as shown in the diagram.

i.LINK connection

NOTE

• Please make sure the shapes of the terminal and the plug match, and insert the plug into the terminal straight, not on an angle.

• Use either one of the terminals. These two terminals do not differ in quality or function.

i.LINK device

Only an i.LINK cable is needed to connect the TV to i.LINK devices. (VIDEO, S-VIDEO, and AUDIO terminals need not be connected.)

• When using the i.LINK, do not turn off the power of, or pull the cable from i.LINK devices, even if that i.LINK devices is not in use. This may affect the picture and the sound from an i.LINK device in use.

• If devices such as a DVD recorders, digital video cameras, computers and computer peripheral devices which are not compatible with this TV, are connected to the TV using i.LINK, other i.LINK connections may be disrupted.

• When device recognition, control, recording or play back, on an i.LINK connected device does not function correctly, correct operation may be restored by disconnecting and reconnecting the i.LINK cable.

• When connecting multiple i.LINK devices, depending on the specifications and the interoperability of the connected devices, their operation may not be stable. In that case, disconnecting all devices not in use and changing the method of connection may result in stable operation.

Using external equipment

Setting the Recording Mode (i.LINK)

• The function for automatically adjusting the recording mode of connected i.LINK devices can be turned on or off.

• Since most of the currently available i.LINK devices automatically recognize the transfer rates of the pictures and sound being recorded and control the recording mode accordingly, you should always

set this Mode to “Pass through” in normal circumstances.

• Depending on the i.LINK devices used and the type of broadcast being recorded, this TV may not adjust the recording mode properly. In this case, please set the “Recording Mode” to “Pass through”.

Press MENU and the MENU screen displays.

Press c/d to select “Digital Setup”.

Press a/b to select “i.LINK Setup”, and then press ENTER.

Press a/b to select “Recording Mode”, and then press ENTER.

Press c/d to select “Auto” or “Pass through”, and then press ENTER.

• Normally, this should be set to “Pass through”.

Setting the Standby Mode (i.LINK)

• Power consumption during standby mode can be minimized by changing the setting of the “Standby Mode” in “i.LINK Setup”.

• When i.LINK is not in use, select “Inactive” in “Standby Mode”.

“Active”: Power continues to pass through the i.LINK circuit so data can be relayed. “Inactive”: Power consumption is minimized during stand-by mode. Data cannot be relayed at this setting.

• When the main power of the TV is in standby mode (POWER indicator lights off), i.LINK control commands cannot be received from an i.LINK device. This does not change even if the “Standby Mode” is set to “Active”. To control the TV from an i.LINK device, turn the TV power on (POWER indicator lights up in blue).

• Data cannot be relayed between i.LINK devices when all the following conditions are met: 1) More than one i.LINK device is connected to the TV with i.LINK cables, 2) “Standby Mode” is set to “Inactive”, and 3) The power of the TV is in standby mode (POWER indicator lights off). When the TV is connected between two i.LINK devices in series, select “Active” in “Standby Mode” or connect the TV at an end of the series as shown in the diagram.

Press MENU and the MENU screen displays.

Press c/d to select “Digital Setup”.

Press a/b to select “i.LINK Setup”, and then press ENTER.

Press a/b to select “Standby Mode”, and then press ENTER.

Press c/d to select “Active” or “Inactive”, and then press ENTER.

NOTE

Using external equipment

Selecting an i.LINK device

• In order to control an i.LINK device from the TV, you must first choose the i.LINK device to be controlled.

• One i.LINK device can be chosen from up to 16 i.LINK connected decks.

• All i.LINK devices connected with i.LINK cables should automatically appear in the selection screen.

• When there is no i.LINK device connected, the message “No i.LINK model is available” appears. In this case, please connect an i.LINK device. (See page 58.)

• When there is no i.LINK device selected, the selection screen appears. In this case, please go to step 3.

Press i.LINK to display the i.LINK control panel.

STOP

00:01:32

PWR

STOP

Model

Input

Press a/b/c/d to select “Model”, and press ENTER.

• Selection screen appears.

i.LINK 1/1 [Thu] 1:33AM

Type

Which model do you use? Manufacturer

Cancel Connection

Model

Disabling the TV’s operation of an i.LINK device

•

By disabling the TV’s operation of an i.LINK device, the device can be operated from another i.LINK device.

• When there is no i.LINK device connected, “No i.LINK model is available” appears. Please connect an i.LINK device. (See page 58.)

• When there is no i.LINK device selected, the selection screen appears. Please go to step 3.

Press i.LINK to display the i.LINK control panel.

STOP

00:01:32

STOP

PWR

Model

Input

Press a/b/c/d to select “Model”, and then press ENTER.

• Selection screen appears.

Press b to select “Cancel Connection” and then press ENTER.

• Operation of the i.LINK device from the TV is disabled.

i.LINK 1/1 [Thu] 1:33AM

Type

Which model do you use? Manufacturer

Cancel Connection

Model

Press a/b to select a device, and then press ENTER.

• The control panel for the i.LINK device appears.

NOTE

• Devices that cannot be used with this TV will not appear in the selection screen.

• Depending on the i.LINK devices connected, the manufacturer’s name and model name of some devices may not display correctly.

• In the case where the manufacturer’s and model names are not correctly displayed, disconnect the i.LINK cable. Follow the procedure for “Deleting registered i.LINK devices” and cancel all i.LINK devices you have registered before reconnecting the i.LINK cable.

• When an item in the selection screen is grayed out, the item is not recognized by the TV and cannot be selected. (The item may not be connected properly.)

• The i.LINK device selected above will be automatically set as a recording device in the TV Guide On Screen system and may be used to record digital broadcasts.

Deleting registered i.LINK devices

• Registered i.LINK devices can be deleted from a list.

• If an i.LINK device is connected, it cannot be deleted from the list.

Press i.LINK to display the i.LINK control panel.

Press a/b/c/d to select “Model”, and then press ENTER.

STOP

00:01:32

STOP

PWR

Model

Input

Press a/b to select a device to be deleted, and then press ENTER.

i.LINK 1/1 [Thu] 1:33AM

Type

Which model do you use? Manufacturer

Cancel Connection

Model

Press c to select “Delete”, and then press ENTER.

• The selected i.LINK device is deleted from the list.

• Select “Cancel” if you do not want to delete any device.

Using external equipment

Controlling an i.LINK device

• An i.LINK compatible device can be controlled from the TV using the i.LINK control panel on the screen.

• The steps in “i.LINK Setup” on page 59 need to be completed beforehand.

• Please also refer to the operation manual of the i.LINK device to be used with this TV.

Basic operation

1 Press i.LINK to display the i.LINK control panel.

• The i.LINK button is also used to exit the i.LINK control panel.

2 Press a/b/c/d to select a function, and then press ENTER.

i.LINK control panel (D-VHS decks)

Cassette inserted

Current operation

Type of i.LINK

Manufacturer

Model

device

STOP

00:01:32

Tape Counter

Type of videotape

PWR

STOP

Function selected with the cursor

PWR

Power On/Off

STOP

PLAY

PAUSE

REC START

i.LINK control panel (AV-HDD recorder/Blu-ray Disc recorder)

Current operation

Current counter

position/Time*

Disk inserted

STOP

00:01:10 00:01:12/

Free 61%

Type of i.LINK device

PWR

STOP

Manufacturer

Model

REC Oper.REC LIST

Model

Input

Model

Inputk30secl30sec

Go to Model Selection screen Select input

SKIP BACK

REWIND

FAST FORWARD

SKIP FORWARD

Go to REC operation screen Go to Model Selection screen Select input

Repeat status

Remaining space

NOTE

Function selected with the cursor

PWR

REC LIST

Power On/Off

STOP

PLAY

PAUSE

GO TO REC LIST

SKIP BACK

REWIND

FAST FORWARD

SKIP FORWARD

REPEAT PLAYBACK

EJECT

l30sec

30 SEC SKIP BACK

k30sec

30 SEC SKIP FORWARD

• The input selection button is used to select either i.LINK input or others.

• The EJECT button is displayed for Blu-ray Disc recorder only. * Time: If you commence playback before Time is displayed, Time will not be displayed during the playback.

Using external equipment

NOTE

• IEEE1394 is the IEEE’s international standard.

• i.LINK and the i.LINK logo are registered trademarks of Sony Electronic, Inc.

• A copy protection technology is used on i.LINK devices that incorporate copyright protection. This technology has received the approval of the Digital Transmission Licensing Administrator (DTLA), an organization that administers copyright protection technologies. Some picture and sound data have restrictions on duplication. Such data cannot be digitally copied using the i.LINK. Some picture and sound data may not be able to be sent back and forth between an i.LINK device that has DTLA copyright protection technology and one that does not.

Notes on i.LINK connection of D-VHS deck/AV-HDD recorder/Blu-ray Disc recorder

• Even when a connected i.LINK device is playing, input signal can be switched to input mode other than i.LINK by shifting the cursor to the input selection button and pressing ENTER.

• This TV may not be able to operate some i.LINK devices using the control panel, or to display picture and/or sound input from some i.LINK devices.

• When the TV’s control panel is used to record a program, what is recorded with the i.LINK device are the pictures and sound of the digital program that the TV is receiving.

• The i.LINK control panel cannot be used during timer recording.

• There may be some programs which i.LINK devices cannot record.

• With some i.LINK devices, the quality of the picture may be distorted during fast forwarding or rewinding.

Notes specifically on i.LINK connection of D-VHS deck

• Depending on the D-VHS deck, this TV’s i.LINK may not allow viewing of VHS and S-VHS tape or analog recorded D-VHS tape. In this case, connect the D-VHS deck’s analog output with the TV’s analog input, and switch the TV’s input mode to external input.

• If a D-VHS deck is operated with the TV’s control panel during timer recording, the recording may fail. Do not use the TV’s control panel to operate the D-VHS deck during timer recording.

• To record the picture and sound of a digital program which the TV is receiving, use D-VHS tape. VHS or S-VHS tape will not record.

Notes specifically on i.LINK connection of AV-HDD recorder/Blu-ray Disc recorder

• Depending on the AV-HDD recorder and/or Blu-ray Disc recorder, some functions, such as playback during recording, display of the recording list screen during recording, and so on, may not be able to be operated.

• Depending on the AV-HDD recorder and/or Blu-ray Disc recorder, playback may stop automatically when switching to another i.LINK device.

• If an AV-HDD recorder/Blu-ray Disc recorder is operated with the TV’s control panel during timer recording, the recording may fail. Do not use the TV’s control panel to operate the AV-HDD recorder/Blu-ray Disc recorder during timer recording.

Notes specifically on i.LINK connection of AV-HDD recorder

• Depending on the AV-HDD recorder, it may be possible to change the recorder’s operations mode (D-VHS mode, HDD recorder mode). When the operations mode is DVHS mode, the HDD recorder is recognized as a D-VHS Deck.

Automatic input switching to i.LINK

• Input mode can be set to automatically switch to i.LINK when an i.LINK device connected to the TV is played.

Press MENU to display the MENU screen.

Press c/d to select “Digital Setup”, and then press ENTER.

Press a/b to select “i.LINK Setup”, and then press ENTER.

Press a/b select “i.LINK Autoswitch”, and then press ENTER.

Press c/d to select “Yes”, and then press ENTER.

i.LINK Autoswitch

Recording Mode

Standby Mode

Yes No

Recording digital programs with a D-VHS deck (i.LINK)

• Before commencing this procedure, the steps in “i.LINK Setup” on page 59 need to be completed beforehand.

• Please also refer to the operation manual of the DVHS deck to be used with this TV.

• Input mode cannot be switched to i.LINK during recording.

• When a D-VHS deck connected to the TV is under timer recording, the deck cannot be operated using the TV’s control panel.

Select a digital program to be recorded.

Press i.LINK to display the i.LINK control panel.

STOP

00:01:32

STOP

PWR

Press a/b/c/d to select E, and then press ENTER.

• Recording starts.

• Select H and press ENTER to stop recording.

NOTE

Model

Input

Using external equipment

Recording digital programs with AV-HDD recorder/Blu-ray Disc recorder

• Before commencing this procedure, the steps in “i.LINK Setup” on page 59 need to be completed beforehand.

• Please also refer to the operation manual of the AVHDD recorder/Blu-ray Disc recorder to be used with this TV.

• Input mode cannot be switched to i.LINK during recording.

• When the input mode is i.LINK, you cannot operate recording.

• When an AV-HDD recorder/Blu-ray Disc recorder connected to the TV is under timer recording, the recorder cannot be operated using the TV’s control panel.

Select a digital program to be recorded.

Press i.LINK to display the i.LINK control panel.

Press a/b/c/d to select “REC Oper.”, and then press ENTER.

Press a/b/c/d to select E, and then press ENTER.

• Recording starts.

• Select “REC STOP” and press ENTER to stop

recording.

NOTE

STOP

– – : – –: – –

Free 61%

PWR

PLAY OPE-

RATION

REC STOP

REC PAUSE

Play Ope.

Model

Input

Playing back using REC LIST (i.LINK)

• You can display a list of the programs you have recorded on AV-HDD recorder and Blu-ray Disc.

Selected item

From top

From current position

Press i.LINK to display the i.LINK control panel.

Press a/b/c/d to select “REC LIST”, and then press ENTER to display the REC LIST.

Press a/b to select the desired program, and then press ENTER.

Capacity: Free 61%

PLAY DELETE LOCK/UNLOCK

Press c/d to select “PLAY”, and then press ENTER.

Press c/d to select “From Top” or “From current position”, and then press ENTER.

Description

Playback will start from the beginning of the selected program.

Playback will start from the point playback stopped last time.

NOTE

• A program in the REC LIST may be deleted by performing: Select the program s Press ENTER s Select “DELETE” on REC LIST s Press ENTER s Select “Delete” s Press

ENTER

• A program in the REC LIST may be locked or unlocked by performing: Select the program s Press ENTER s Select “LOCK/ UNLOCK” s Press ENTER

• Depending on the device connected, the audio and images of the program selected with the cursor may not be displayed in the small play screen.

• Depending on the device connected, when the recording list is displayed during recording, the recording may stop.

• The program information displayed in the title (Program name, date and time, etc.) will be taken from the program information for the program broadcast at the time recording commenced.

• When recording several programs in succession, the program information displayed will be that of the first program recorded at the time recording originally commenced.

• When playing back content recorded on other devices, the program information in the title may not be displayed correctly in some cases.

Useful adjustment settings

Image position (AV input mode only)

For adjusting a picture’s horizontal and vertical position.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Position”, and then press ENTER.

Press a/b to select “H-Pos.” or “V-Pos.”.

H-Pos. –10 +10

[ 0]

V-Pos. –20

[ 0]

Reset

+20

Press c/d to adjust the item to your desired position.

Moving the picture on the screen

You can move the picture around on the screen.

Press a/b/c/d to move an image on the screen to the desired position. Press ENTER to return to the initial image position.

NOTE

• While pressing a/ b / c/d, an on-screen image, “Adjusting Position” displays to the desired position.

• This setting cannot be stored. Once the TV shuts down or enters standby mode, the setting is erased. To move the picture around the screen again, you must perform the above procedure again.

• The image position setting using the steps on this page can be stored. Select either according to your objectives.

• “TV”, “INPUT1”, “INPUT2”, “INPUT3” and “INPUT4” can each adjust the image position setting on this page. The same for view modes.

• An on-screen image from PC cannot be moved around.

• Even when the image fills the screen, its position can be adjusted with this function.

• Press ENTER to reset the image to original positions.

NOTE

• For resetting all adjustment items to the factory preset

values, press a/b to select “Reset”, and then press ENTER.

• Adjustments are stored separately according to input

source.

• You can easily move the image position as shown on this page, but when the power is switched off the image will return to the previously memorized position.

Selected item

H-Pos.

V-Pos.

Centers the image by moving it to the left or right.

Centers the image by moving it up or down.

Description

Useful adjustment settings

Auto Sync. adjustment (PC input mode only)

For automatically adjusting the PC image.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Auto Sync.”, and then press ENTER.

Press c/d to select “Yes”, and then press ENTER.

• Auto Sync. starts and “Now adjusting the image” displays.

...

[

Setup

Auto Sync.

]

NoYes

Fine Sync. adjustment (PC input mode only)

Ordinarily you can easily adjust the picture as necessary to change image position using Auto Sync. In some cases, however, manual adjustment is needed to optimize the image.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Fine Sync.”, and then press ENTER.

Press a/b to select the specific adjustment item.

H-Pos. [ 90] – +

V-Pos.

Clock

Phase

Reset

[ 39]

[ 90]

[ 20]

–

30%

NOTE

• When Auto Sync. is successful, “Completed” displays. If not, Auto Sync. failed.

• Auto Sync. may fail even if “Completed” displays.

• Auto Sync. may fail if the computer image has low resolution, has unclear (black) edges, or is moved while executing Auto Sync.

• Be sure to connect the PC to the TV and switch it on before starting Auto Sync.

Press c/d to adjust the item to your desired position.

NOTE

• For resetting all adjustment items to the factory preset

values, press a/b to select “Reset”, and then press

ENTER.

Selected item

H-Pos.

V-Pos.

Clock

Phase

Centers the image by moving it to the left or right.

Centers the image by moving it up or down.

Adjust when the image flickers with vertical stripes.

Adjust when characters have low contrast or when the image flickers.

Description

Useful adjustment settings

Input Select

Selecting input source

Use this menu to select the input source.

Selecting input signal type

For setting the signal type of external equipment connected to INPUT 1 and INPUT 2 terminals.

Press INPUT.

• A list of selectable sources appears.

Press INPUT again to select the input source.

• An image from the selected source automatically displays.

• You can also select the input source by pressing a/b.

• If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.

• When the CableBox is selected in TV Guide On Screen setting, CableBox will be displayed in the INPUT SOURCE screen. If you select CableBox in the INPUT SOURCE screen you can change the channels of the CableBox.

Press MENU and the MENU screen displays.

DVI input signal setting

Press INPUT to select INPUT5.

INPUT SOURCE

TV CableBox [TV] INPUT1 INPUT2 INPUT3 INPUT4

INPUT5INPUT5

i.LINK

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Input Select”, and then press ENTER.

...

[

Option

Audio Only

Input Select

Output Select

Quick Shoot

Input Select

[ANALOG PC]

]

[Fixed]

[Off]

Press c/d to select “Option”.

Press a/b to select “Input Select”, and then press ENTER.

Press a/b to select a signal type you want to set, and then press ENTER.

• If the selected signal type is incorrect, images are not displayed or displayed without any color.

NOTE

• If you set INPUT1 and INPUT2 to Auto, the TV will automatically select the input signal.

• Check the operation manual of the external equipment for the signal type.

• Setting INPUT 1 and INPUT 2 signal selection to “Auto” when other equipment is connected will result in the following connectivity priority.

INPUT 1 and INPUT 2

1. COMPONENT VIDEO

2. VIDEO

Press a / b to select the equipment connected to INPUT 5 terminal, and then press ENTER.

...

[

Option

DIGITAL PC

ANALOG PC

DIGITAL AV

ANALOG AV

Input Select

]

Useful adjustment settings

Input Label

Lets you set the input terminal displayed using the INPUT SOURCE menu or channel display.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Input Label”, and then press ENTER.

Picture Flip

You can set the orientation of the picture.

Repeat steps 1 and 2 in Input Label.

Press a/b to select “Picture Flip”, and then press ENTER.

Press a/b to select the desired mode, and then press ENTER.

[Standard]: normal image.

ABC

[Mirror]: mirror image.

• You cannot change labels if the INPUT SOURCE is TV, or i.LINK.

Press a/b/c/d to select the new name for the channel, and then press ENTER.

INPUT SOURCE

TV CableBox [TV]

DVD

INPUT2 INPUT3 INPUT4 INPUT5INPUT5 i.LINK

(Example)

NOTE

ABC

[Upside Down]: upside down image.

ABC

[Rotate]: rotated image.

ABC

Useful adjustment settings

AV MODE

AV MODE gives you six viewing options to choose from to best match environment of the TV, which can vary due to factors like room brightness, type of program watched or the type of image input from external equipment.

Mode selection for TV, INPUT 1 to 5 and i.LINK mode

AV MODE: STANDARD

AV MODE: DYNAMIC

Press AV MODE.

• Present AV MODE displays.

Press AV MODE again before the mode displayed on the screen disappears.

• The mode changes as shown below.

(Example)

AV MODE: MOVIE

AV MODE: GAME

View mode for 4:3 Programs

Press VIEW MODE.

• The View mode menu displays.

• The menu lists the view mode options selectable for the type of video signal currently received.

Press VIEW MODE or a/b while the View mode menu is still on the screen.

• You can sequentially select a view mode that has its own aspect ratio.

View Mode

Side Bar

S. Stretch Zoom Stretch

Side Bar: Suitable for viewing

S.Stretch: Suitable for stretching 4:3 (Smart stretch)

conventional 4:3 programs in their normal format.

programs to fill the screen.

AV MODE: DYNAMIC (Fixed)

AV MODE: USER

Mode selection for the PC terminal

(Example)

AV MODE: STANDARD

Selected item

STANDARD

MOVIE GAME

USER

DYNAMIC (Fixed)

DYNAMIC

For a highly defined image in a normally bright room

For a movie

Lowers image brightness for easier viewing

Allows the user to customize settings as desired. You can set the mode for each input source.

Changing image and sound settings to factory preset values. No adjustments are allowed.

For a clear-cut image emphasizing high contrast for sports viewing

AV MODE: USER [PC]

Description

NOTE

• You can select a different AV MODE item for each input mode. (For example, select STANDARD for TV input and DYNAMIC for VIDEO input.)

Zoom: Suitable for viewing wide-

Stretch: This mode is useful for

screen 2.35:1 anamorphic DVDs in full screen.

1.78:1 DVDs. When viewing 1.85:1 DVDs, stretch mode will still show very thin black bands at the top and bottom of the screen.

View mode for HD Programs

The following modes are available for HD programs.

S.Stretch: (Smart stretch)

Zoom:

Stretch:

Dot by Dot:

NOTE

• When using Dot by Dot, it is possible to see noise or bars around different outer portions of the screen. Please change view mode to correct this.

Suitable for stretching 4:3 programs to fill the screen.

Suitable for viewing wide-screen 2.35:1 aspectratio programs in full screen.

Suitable for viewing wide-screen 1.78:1 aspectratio programs. When viewing 1.85:1 programs, stretch mode will still show very thin black bands at the top and bottom of the screen.

Detects the resolution of the signal and displays an image with the same number of pixels on the screen.

Useful adjustment settings

Screen size images.

Input signal

View Mode

Normal

Zoom Stretch

View mode (for PC input mode)

You can select the screen size.

NOTE

• Connect the PC before making adjustments. (See page

57.)

• Selectable screen size may vary with input signal type.

Dot by Dot

Normal Zoom Stretch Dot by Dot

Press VIEW MODE.

• The View mode menu displays.

Press VIEW MODE or a/b to select a desired item on the menu.

Keeps the original aspect ratio in a full screen display.

Keeps the original aspect ratio in a full screen display. The top and bottom of the image is slightly cropped.

An image fully fills the screen.

Detects the resolution of the signal and displays an image with the same number of pixels on the screen.

Useful adjustment settings

Input signal (for PC input mode)

• Some input signals may have to be registered manually to display properly.

• The pairs of input signals (resolutions) in the list below are not distinguishable when received. In such case, you have to set the correct signal manually. After setting once, it will display when the same signal (resolution) is input again.

640g400 640g480

1024g768

NOTE

• You can only select the “Input Signal” on the Setup menu when receiving one of the 6 input signals listed above.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Input Signal” and then press ENTER.

Press a/b to select the desired input signal on the display.

720g400 848g480

1280g768

Example

Digital Noise Reduction

Produces a clearer video image.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Digital Noise Reduction”, and then press ENTER.

Press a/b to select the desired level, and then press ENTER.

Off

High

Low

Audio Only

When listening to music from a music program, you can set the Liquid Crystal display off and enjoy audio only.

Repeat steps 1 and 2 in Digital Noise Reduction.

Press a/b to select “Audio Only”, and then press ENTER.

Press c/d to select “On”, and then press

ENTER.

640 x 480

848 x 480

Selected item

Off

Description

Audio is output without screen image.

Both screen images and audio are output.

Useful adjustment settings

Output Select

Allows you to select what controls the audio output.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Output Select”, and then press ENTER.

Press c/d to select “Fixed” or “Variable”, and then press ENTER.

Selected item

Fixed

Variable

• Sound via speaker is adjusted with VOL

k/l on the remote control unit or VOL l/ k on the TV.

• Sound via the MONITOR OUT terminal is not adjustable and constantly outputs.

• Sound via the MONITOR OUT terminal is adjusted with VOL k/l on the remote control unit or VOL l/k on the TV.

• Sound via speaker is muted.

Description

Quick Shoot

Use Quick Shoot to view fast-action video more clearly.

Sleep Timer

Allows you to set a time when the TV automatically switches to standby.

Press SLEEP.

• Remaining time displays when sleep timer has been set.

Sleep Timer: Remaining

Each time you press SLEEP, the remaining time switches as shown below.

• When set, the time automatically starts counting down.

• If you want to adjust the sleep timer, you can press SLEEP twice then change the time setting.

• Five minutes before time expires, the remaining time displays each minute.

Sleep Timer: Off

• If video noise occurs, turn the function “Off”.

Repeat steps 1 and 2 in Output Select.

Press a/b to select “Quick Shoot”, and then press ENTER.

Press c/d to select “On”, and then press

ENTER.

NOTE

Sleep Timer:

NOTE

• Select “Off” by pressing SLEEP to cancel the sleep timer.

• The TV will enter the standby mode when the remaining time reaches zero.

120

Useful adjustment settings

Program Title Display

Select the CH display when changing channels for digital broadcasting.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Selected item Description

Yes

Press a/b to select “Program Title Display”, and then press ENTER.

Press c/d to select “Yes” or “No”, and then press ENTER.

“Program Info.” displays

“Program Info.” does not display

Useful adjustment settings

1/3 ENG 2/3 CC1 3/3 Text1 OFF

Closed Captions and Digital Closed Captions

• Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. Closed Captions are available on some TV programs, and on some VHS home video tapes, at the election of the program provider.

• Digital Closed Caption service is a new caption service available only on digital TV programs (also at the election of the service provider). It is a more flexible system than the original Closed Caption system, because it allows a variety of caption sizes and font styles. When the Digital Closed Caption service is in use, it will be indicated by appearance of a 3-letter abbreviation that also indicates the language of the Digital Closed Captions: ENG (English) or SPA (Spanish) or FRA (French), or other language codes.

• Not all programs and VHS videotapes offer closed caption. Please look for the “N” symbol to ensure that captions will be shown.

• In the Closed Caption system, there can be more than one caption service provided. Each is identified by its own number. The “CC1” and “CC2” services display subtitles of TV programs superimposed over the program’s picture.

• In the Closed Caption system, the “Text1” or “Text2” services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

Press CC.

• This will present the Closed Caption information display.

Press CC while the Closed Caption information is still on the screen.

• Press repeatedly until you select a closed caption service which you prefer.

Air ANALOG

Audio : MONO

CC : 1/2 CC1

• Depending on the number of caption services in the signal being received, you will see information such as 1/2 or 1/4 displayed. 1/2 means “the first of two services”. Example: If a program has three services (Digital CC(ENG), CC1 and Text1), the closed caption display will toggle in this sequence:

• The CC button keeps a record of the last service selected in its memory. If the last closed caption mode (e.g. 1/3ENG) you selected is not available for the next program, or on another channel, the closed caption service that is available is automatically selected, and this service appears in parentheses, e.g.1/3(CC1). Closed caption services that appear in parentheses will not be recorded in the CC button’s memory as your last selected service. Only services that you have selected with the CC button are recorded.

Examples:

In a case where there are two closed caption services provided, for instance, Digital CC(ENG) and CC1), and Digital CC(ENG) is displayed as your current selection, if Digital CC(ENG) is not broadcast for the next program, the other closed caption service, CC1, will be displayed in parentheses. A closed caption service appears in parentheses because the service you selected is not available and a different service is displayed on your screen. “1/1(CC1)” is displayed instead of “1/2/ ENG”.

Closed Caption information

NOTE

• See page 74 to 76 for detailed closed caption settings.

• When using Freeze functions, closed captions will not be displayed on the right-most screen (still image).

• When the program contains no closed caption, “--” displays in the closed caption information.

• If the language code, e.g. “ENG”, is not found on Digital TV programs, “--” will be shown.

• Four kinds of closed caption service (CC1, CC2, Text1, Text2) are potentially available, but a broadcast may contain none, or only some of these services, at the election of the program provider.

Useful adjustment settings

Caption Size

Select a caption size.

• Default: The caption size specified by broadcasting station or default size.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Caption Setup”, and then press ENTER.

Press a/b to select “Caption Size”.

Caption Size Default

Font Style

Foreground Color

ABC 123

Foreground Opacity

Background Color

Background Opacity

Character Edge

Reset

Press c/d to select the desired size.

NOTE

Default

Font Style

Select a font style.

Selected item

Default

Type 0 Type 1 Type 2 Type 3 Type 4 Type 5 Type 6 Type 7

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Caption Setup”, and then press ENTER.

Press a/b to select “Font Style”.

Press c/d to select the desired style.

Description

The font specified by broadcasting station or default font.

Proportional font used in the MENU screen.

Monospaced with serifs.

Proportionally spaced with serifs.

Monospaced without serifs.

Proportionally spaced without serifs.

Casual font type.

Cursive font type.

Small capitals.

NOTE

• For resetting all adjustment items to the factory preset

values, press a/b to select “Reset”, and then press

ENTER.

Useful adjustment settings

Foreground Color

Select a character foreground color.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Caption Setup”, and then press ENTER.

Press a/b to select “Foreground Color”.

Caption Size Default

Font Style

Foreground Color

ABC 123

Foreground Opacity

Background Color

Background Opacity

Character Edge

Reset

Press c/d to select the desired color.

Default

Foreground Opacity

Select a foreground opacity value.

• Default: The foreground opacity value specified by broadcasting station or default opacity value.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Repeat steps 1 to 3 in Foreground Color.

Press a/b to select “Foreground Opacity”.

Press c/d to select the desired value.

NOTE

Background Color

Select a character background color.

Repeat steps 1 to 3 in Foreground Color.

NOTE

• Default: The foreground color specified by broadcasting station or default color.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press

ENTER.

• Default: The background color specified by broadcasting station or default color.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Press a/b to select “Background Color”.

Press c/d to select the desired color.

NOTE

Useful adjustment settings

Background Opacity

Select a background opacity value.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Caption Setup”, and then press ENTER.

• Default: The background opacity value specified by broadcasting station or default opacity value.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Press a/b to select “Background Opacity”.

Caption Size Default

Font Style

Foreground Color

ABC 123

Foreground Opacity

Background Color

Background Opacity

Character Edge

Reset

Press c/d to select the desired value.

NOTE

Default

Character Edge

Select a character edge.

• Default: The character edge specified by broadcasting station or default edge.

• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Caption Setup”, and then press ENTER.

Press a/b to select “Character Edge”.

Press c/d to select the desired setting.

NOTE

Useful adjustment settings

Secret number setting for parental control (AV input mode only)

Allows you to use a secret number to protect certain settings from being accidentally changed.

IMPORTANT:

Three conditions must be met to enable V-Chip (see pages 77 to 83):

1 Secret No. is registered. 2 V-Chip settings have been made. 3 “Status” is set to “On”.

Select “New Secret No.”, and then press ENTER. Input the new 4-digit secret number by using 0 – 9.

New Secret No.

Secret No. Clear

Input Secret No.

New Secret No.

Reconfirm

––––

Input the same 4-digit number on the “Reconfirm” screen as in step 5 to confirm.

New Secret No.

Secret No. Clear

Input Secret No.

New Secret No.

Reconfirm

––––

****

––––

Press RETURN to start configuring V-Chip settings. (See pages 80 and 82 for details.)

Setting a secret number

Press MENU and MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Parental CTRL”, and then press ENTER.

Press a/b to select “Secret No.”, and then press ENTER.

...

[

Setup

Parental CTRL

V-Chip

Secret No.

Status

...

Secret No.

Setting parental control status

Used to enable or disable the parental control function.

]

• You can skip step 1 and 2 above while in Parental CTRL screen.

Repeat steps 1 to 3 in Setting a secret number.

• Secret number setting menu displays.

Input the 4-digit secret number by using 0 –

Press a/b to select “Status”, and then press ENTER.

Press c/d to select “On” or “Off”, and then press ENTER.

• Select “On” to enable and “Off” to disable Parental CTRL.

V-Chip

Secret No.

Status

On Off

NOTE

Useful adjustment settings

Clearing the secret number

Allows you to clear your secret number.

Changing the secret number

Allows you to change your current secret number.

Repeat steps 1 to 3 in Setting a secret number.

• Secret number setting menu displays.

Input the 4-digit secret number by using 0 –

Press a/b to select “Secret No.”, and then press ENTER.

Press a/b to select “New Secret No.”, and then press ENTER.

Input the old 4-digit number you have set using 0 – 9.

[

Setup

New Secret No.

Secret No. Clear

...

Parental CTRL

...

Secret No.

Input Secret No.

New Secret No.

Reconfirm

]

––––

Input the new 4-digit number using 0 – 9.

New Secret No.

Secret No. Clear

Input Secret No.

New Secret No.

Reconfirm

––––

Repeat steps 1 to 3 in Setting a secret number.

• Secret number setting menu displays.

Input the 4-digit secret number by using 0 –

Press a/b to select “Secret No.”, and then press ENTER.

Press a/b to select “Secret No. Clear”, and then press ENTER.

Press c/d to select “Yes”, and then press ENTER.

• Your secret number is cleared.

New Secret No.

Secret No. Clear

Yes No

NOTE

• See page 77 for re-registering with a new secret number after being cleared.

• As a precautionary measure, make a note of your

secret number and keep it in a familiar place. If you lose or forget your secret number, initialize the Liquid Crystal Television to return all settings except for the TV channel settings to factory preset values. (See page 98.)

• If the secret number is cleared the Status setting automatically sets to “Off”. “V-Chip” and “Status” will not be selectable from the menu.

Input the same 4-digit number on the “Reconfirm” screen as in step 6 to confirm.

New Secret No.

Secret No. Clear

Input Secret No.

New Secret No.

Reconfirm

––––

****

––––

Useful adjustment settings

Parental control (setting V-CHIP level)

V-CHIP is an electronic filtering device built into your TV. This tool gives parents a great degree of control over broadcasts accessed by their children. It allows parents to select programs judged suitable for child viewing while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature in your Liquid Crystal Television.

“V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret number. (See page 77 for Secret number setting for parental control.)

• The U.S. has two rating systems for viewing content: TV Parental Guidelines and movie ratings.

• The TV Parental Guidelines work in conjunction with the V-CHIP to help parents screen out inappropriate television shows from their children.

• Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as watched on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies.

Voluntary movie rating system (MPAA)

Rating

PG-13

Age

NC-17

[

Setup

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

...

Parental CTRL

...

V-Chip

]

TV Parental Guidelines

Rating

Description

General audiences. All ages admitted.

Parental guidance suggested. Some material may not be suitable for children.

Parents strongly cautioned. Some material may be inappropriate for children under 13.

Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some jurisdictions).

No one 17 and under admitted.

X is an older rating that is unified with NC-17 but may be encoded in the data of older movies.

• If you select “PG-13”, this will automatically block the higher ratings “R”, “NC-17” and “X”.

PG-13

NC-17

NONE

NOTE

• Voluntary movie rating system only uses an age-based rating.

Content

(Fantasy

violence)

(Violence)S(Sexual

situation)

(Adult

language)

(Sexually

suggestive

dialog)

TV-Y (All children)

TV-Y7 (Directed to older children)

Suggested age

TV-G (General audience)

TV-PG (Parental Guidance suggested)

TV-14 (Parents strongly cautioned)

TV-MA (Mature audience only)

X: Content rating can be set.

Useful adjustment settings

TV Parental Guidelines (TV Guidelines)

Voluntary movie rating system (MPAA)

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Parental CTRL”, and then press ENTER.

• Secret number setting menu displays only when “Secret No.” is set. (See page 77.)

• “V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret number. (See page 77.)

Input the 4-digit secret number by using 0 –

Press a/b to select “V-Chip”, and then press ENTER.

V-Chip

Secret No.

Status

[

Setup

...

Parental CTRL

...

V-Chip

]

Press a/b to select “MPAA”, and then press

ENTER.

Repeat steps 1 to 5 in Voluntary movie rating system (MPAA).

Press a/b to select “TV Guidelines”, and then press ENTER.

Press a/b to adjust the item to your desired position. “ ” indicates the item is blocked.

• The setting automatically enters “Block” for any ratings below your selection.

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

NONE

When setting an individual content-based rating item, do as follows: 1 Press d to access block content items from

the currently selected age-based rating item.

2 Press a/b to select an individual item, and

then press ENTER to unblock (“

” is removed). Repeat the same steps for other items.

3 Press c or RETURN to register after all

individual content rating items are set.

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

• If Status is not set to “On” the configuration settings will not work. (See page 77.)

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

NONE

Press a/b to adjust the item to your desired position. “

” indicates the item is blocked.

Press RETURN.

• The setting automatically enters “Block” for any ratings below your selection.

• If Status is not set to “On” the configuration settings will not work. (See page 77.)

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

PG-13

NC-17

NONE

Useful adjustment settings

Canadian Rating Systems

• The TV rating systems in Canada are based on the Canadian Radio-Television and Telecommunications Commission (CRTC) policy on violence in television programming.

• While violence is the most important content element to be rated, the structure developed takes into consideration other program content like language, nudity, sexuality and mature themes.

• When setting the V-CHIP on the Canadian system you can choose either the Canadian English ratings or the Canadian French ratings.

Canadian English ratings

Rating

Exempt: Includes news, sports, documentaries and other information programming; talk shows, music videos, and variety programming.

Children: Intended for younger children under the age of 8 years. Pays careful attention to themes that could threaten their sense of security and well-being.

Children over 8 years old: Contains no portrayal of violence as the preferred, acceptable, or only way to resolve conflict; nor encourage children to imitate dangerous acts which they may see on the screen.

General: Considered acceptable for all age groups. Appropriate viewing for the entire family, contains very little violence, physical, verbal or emotional.

Parental Guidance: Intended for a general audience, but may not be suitable for younger children (under the age of 8) because it could contain controversial themes or issues.

Over 14 Years: Could contain themes where violence is one of the dominant elements of the storyline, but it must be integral to the development of plot or character. Language usage could be profane and nudity present within the context of the theme.

Adults: Intended for viewers 18 years and older and might contain depictions of violence, which while related to the development of plot, character or themes, are intended for adult viewing. Could contain graphic language and portrayals of sex and nudity.

Age

C8e

14e

18e

Canadian French ratings

Rating

Description

Age

8anse

13anse

16anse

18anse

Exempt programming.

General: All ages and children, contains minimal direct violence, but may be integrated into the plot in a humorous or unrealistic manner.

General but inadvisable for young children: May be viewed by a wide public audience, but could contain scenes disturbing to children under 8 who cannot distinguish between imaginary and real situations. Recommended for viewing with parent.

Over 13 years: Could contain frequent violent scenes and therefore recommended for viewing with parent.

Over 16 years: Could contain frequent violent scenes and intense violence.

Over 18 years: Only for adult viewing. Could contain frequent violent scenes and extreme violence.

Useful adjustment settings

Canadian English ratings

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Parental CTRL”, and then press ENTER.

• Secret number setting menu displays only when “Secret No.” is set. (See page 77.)

• “V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret number. (See page 77.)

Input the 4-digit secret number by using 0 –

...

[

Setup

Parental CTRL

Setup Option

Secret No.

Press a/b to select “V-Chip”, and then press ENTER.

V-Chip

Secret No.

Status

Press a/b to adjust the item to your desired position. “

” indicates the item is blocked.

• The setting automatically enters “Block” for any ratings below your selection.

• If Status is not set to “On” the configuration settings will not work. (See page 77.)

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

E C C8+ G PG 14+ 18+ NONE

Canadian French ratings

]

––––

Repeat steps 1 to 5 in Canadian English ratings.

Press a/b to select “Can. French Ratings”, and then press ENTER.

Press a/b to adjust the item to your desired position. “

• The setting automatically enters “Block” for any ratings below your selection.

• If Status is not set to “On” the configuration settings will not work. (See page 77.)

” indicates the item is blocked.

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

8ans+

13ans+

16ans+

18ans+

NONE

Press a/b to select “Can. English Ratings”, and then press ENTER.

Useful adjustment settings

How to temporarily release the VCHIP BLOCK

• The V-CHIP BLOCK is working and censors a broadcast, “V-CHIP HAS BEEN ACTIVATED.” displays.

Press ENTER while the V-CHIP is working and then the secret number setting menu displays.

Enter your 4-digit secret number with 0 – 9. At this time V-CHIP BLOCK temporarily releases.

Reactivating the temporarily released V-CHIP BLOCK

• You can reactivate the temporarily released V-CHIP BLOCK as shown below.

Method 1:

Select “Status” setting from the Parental CTRL menu to reactivate BLOCK. (See page 77.)

Method 2:

Select “V-Chip” setting (“MPAA”, “TV Guidelines”, “Can. English Ratings” or “Can. French Ratings”) from the Parental CTRL to reactivate BLOCK. (See pages 80 and 82.)

Method 3:

Switch off the TV power.

NOTE

• Performing any of the three above will activate the V-CHIP BLOCK.

Other viewing options

Viewing information of the program

You can view information about a program you are currently watching.

Press INFO while watching a broadcast.

• Information of the current program will be displayed.

WGBH-HD 2.1

20:00 21:00

American Family – – – Journey of DreamsPBS

Sample program information

• If the program you are receiving is copyprotected, an icon will be displayed in the program information. Recording digital programs via i.LINK, or recording digital audio via digital audio output terminals, is restricted.

Picture and still image

You can display two same-sized pictures – one moving and one still.

Press FREEZE.

• A moving image displays on the left screen and a still image displays on the right screen. The still image is one frame captured from a moving image at the moment you press FREEZE.

Icon Description

Digital copying prohibited

One digital copy only

NOTE

• Sometimes the name of the program is not broadcast. In that case, the program name will not be displayed.

FREEZE

• This function does not work in INPUT 4 (HDMI) and INPUT 5 (DVI-I).

• When this function is not available, “No displaying still image available” will display.

• The still image is automatically erased after 30 minutes.

• If you are using freeze function and a broadcast activates the V-CHIP BLOCK, freeze function will be cancelled and a V-CHIP BLOCK message will appear.

Update the still image by pressing ENTER.

• Each time you press ENTER, the image on the

right screen updates.

Press FREEZE to exit still image.

NOTE

Other viewing options

Presetting remote control function

You can operate the connected AV products (AV Receiver, Cable Box, SAT tuner, DTV, VCR, DVD, LD) using the presetting manufacturer function for your remote control unit.

Presetting manufacturer codes

Press FUNCTION until the LED for your device lights up.

After the LED for your device lights up, if you press FUNCTION and DISPLAY and enter the code registration mode, the LED will blink.

Press 0 – 9 to enter the manufacturer code. (See page 86.)

• Preset mode is finished once the LED no longer lights up.

After registering the code, the LED will stop blinking then turn off after one second. (If you perform an incorrect operation, the LED will blink quickly then turn off.)

Other viewing options

Manufacturer codes

VCR BRAND

Akai Audio Broksonic Canon Capehart Craig Curtis Mathis Daewoo DBX Dynatech Emerson Fisher Funai G.E. Goldstar Hitachi Instant Replay JC Penney JVC Kenwood Lloyds Magnavox Magnin Marantz Memorex Minolta Mitsubishi Montgomery Ward Multitech NEC Panasonic Pentax Philco Philips RCA Realistic Samsung Sanyo Scott Sears Sharp Shintom Sony Sound Design Sylvania Symphonic Tatung Teac Teknika Thomas TMK Toshiba Video Concepts Yamaha Zenith

REMOTE CONTROL

CODE NUMBER

25, 26, 37 15, 22, 30 32 04 34 10, 31 04 34 15, 22, 30 29 21, 32, 35 09, 10, 11 28, 29 04 24 06, 47 04 04, 06, 24, 30 15, 41, 42, 53 14, 15 29 04, 05, 08 31 30 04, 10, 24, 29 06 17, 18, 39, 40 02, 43 29 15, 22, 30 44, 45 05, 06 05 05, 08 06, 07, 33, 51 01, 02, 10, 24 23, 31 10, 14, 52 20 06, 11, 24 01, 02, 03 36 12, 13, 38 29 05, 08 29 15 15, 29 27, 29 29 21 19, 20 30 15, 29, 30 16

DVD/LD BRAND

Denon JVC Kenwood Magnavox Marantz Mitsubishi Panasonic Philips Pioneer Proscan RCA Samsung Sharp Sony Toshiba Yamaha Zenith

CATV/SAT BRAND

Anvision Cable Star Eagle General Instrument

REMOTE CONTROL

CODE NUMBER

02 09, 13 21 04 04 06 02, 22 04, 23 08, 11, 20 03 03, 24 07, 12 01, 10 05, 25 04 02 04

REMOTE CONTROL

CODE NUMBER

04, 05 04, 05 05 02, 03, 07, 12, 13, 14, 19, 22

Jerrold

02, 03, 07, 12, 13, 14, 19, 22, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40

Magnavox

04, 05, 09, 14, 17, 18,

20, 21, 24, 25 Oak Sigma Panasonic Philips

16, 23

04, 05, 09, 15, 17, 18,

20, 21, 24, 25 Pioneer Randtek RCA Scientific Atlanta Sony Viewstar

08, 10, 29, 30, 43*, 46

04, 05

16, 27, 44*, 45*

01, 26

04, 05, 09, 15, 17, 18,

20, 21, 24, 25 Zenith

NOTE

• Numbers marked with * are SAT codes, all others are CATV codes.

AUDIO BRAND

Sharp

06, 14

REMOTE CONTROL

CODE NUMBER

Other viewing options

Cable control buttons

When the FUNCTION is set to CBL/SAT the cable converter connected to the TV can operate using 1 to

1 SOURCE POWER

Turns the cable converter power on and off.

20 – 9

Press a button (or buttons) that corresponds to the channel that you wish to watch.

3 FLASHBACK *

Press to switch between the current channel and the channel you were watching immediately before.

4 CH r/s

Press CH r or CH s to tune in a higher or lower channel.

* Some manufacturers do not preset FLASHBACK.

NOTE

• CABLE and SAT cannot be selected at the same time.

SAT control buttons

1 SOURCE POWER

Turns the Satellite broadcast tuner power on and off.

20 – 9,

3 ENTER, a/b/c/d

• CABLE and SAT cannot be selected at the same time.

• (DOT)

Press a button (or buttons) that corresponds to the channel that you wish to watch.

ENTER: Press to activate the selected function. a/b/c/d: Press the button to select items on the SAT

GUIDE screen or SAT MENU screen.

NOTE

Other viewing options

2 4

7 3

VCR control buttons

The remote control unit button will function as follows when the FUNCTION of the remote control unit is set to VCR.

• When the input selector button having the same number as the input terminal connecting the VCR is pressed, the VCR can operate using 1 to 8.

1 CH r/s

Press to select the channel of the TV tuner on the VCR.

2 SOURCE POWER

Turns the power of the VCR on and off.

3 F

Sets pauses and still pictures.

4 G

Rewinds the tape and allows picture search.

5 H

Stops the tape transport.

6 REC

Starts recording.

7 J

Rapidly advances the tape and allows picture search.

8 I

Starts playback.

DVD control buttons

The remote control unit button will function as follows when the FUNCTION of the remote control unit is set to DVD.

• When the input selector button having the same number as the input terminal connecting a DVD

103

5 6

4 2 1

7 8

player is pressed, these players can operate using

1 to 10.

1 U

Pressing quickly once takes you to the start of the next chapter. Each time you press it, you move ahead to the start of the next chapter.

2 T

Pressing quickly once takes you to the start of the chapter currently playing. Each time you press it, you move back to the start of the previous chapter.

3 SOURCE POWER

Turns the power of the DVD player on and off.

4 F

Sets pauses and still pictures.

5 G

Continue pressing to go backward.

6 H

Playback stops when pressing once. With some DVD players, pressing the button twice may open the disc tray.

7 MENU

When this button is pressed, the DVD menu will display.

8 ENTER, a/b/c/d

ENTER: Press to activate the selected function. a/b/c/d: Press the button to select items on the DVD

MENU screen.

9 J

Continue pressing for fast forward.

10 I

Starts playback.

Other viewing options

Notice

■ When you change your address

• If you change your address, please return the

CableCARD to your Cable Provider Company.

• You will need to request a new CableCARD from the

cable provider at your new location.

■ About EAS (Emergency Alert System)

• In the case of a national emergency, natural disaster,

or other emergency situation, Cable MSO will broadcast an Emergency Alert Message (EAS message). When this unit receives an EAS message, if the level of emergency is comparatively low, an alert text message will be displayed on screen. If the level of emergency is high, the receiver will be force tuned to a details channel.

• Alert text messages will be displayed, and force

tuning will occur, even during paid programming. Even when force tuning is active, the user can still change the channel.

• If the unit is force tuned to a channel that has been

blocked by Parental Control, the Parental Control setting will be given priority.

NOTE

• If you have a digital cable antenna connected, you can

receive EAS messages whether CableCARD is inserted or not.

• EAS messages may be broadcast not only via digital

cable, but also via Analog Cable or over-the-air Analog transmission.

• When force tuning occurs, Video output from the

MONITOR OUT terminal will also be switched to the details channel.

• An alert text message does not output from MONITOR

OUT terminal.

• While TV Guide On Screen is on display, force tuning

and alert text messages are NOT available and the details channel will not be displayed on the full screen.

Appendix

Removing the stand

Before detaching (or attaching) stand, unplug the AC cord from the AC input terminal.

CAUTION

• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.

Before attaching/detaching stand

• Before performing work make sure to turn off the TV.

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being

damaged.

Unfasten the screw used to secure the bracket in place.

CAUTION

• Do not remove the stand from the TV unless using an optional bracket to mount it.

NOTE

• To attach the stand, perform the above steps in reverse order.

Unfasten the four screws used to secure the stand in place.

(LC-37/32D5U)

Detach the stand from the TV. (Hold the stand so it will not drop from the edge of the base area.)

(LC-26D5U)

Detach the stand from the TV. (Hold the stand so it will not drop from the edge of the base area.)

Setting the TV on the wall

CAUTION

• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service

personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting that results in accident or injury.

Using an optional bracket to mount the TV

• You can ask a qualified service professional about using an optional AN-37AG2 bracket to mount the TV to

the wall. The AN-37AG2 is compatible with the LC-37D5U and LC-32D5U only.

• Carefully read the instructions that come with the bracket before beginning work.

Hanging on the wall

AN-37AG2 wall mount bracket. (See the bracket instructions for details.)

Vertical mounting Angular mounting

About setting the TV angle

Angle of TV

LC-37D5U 5˚

LC-32D5U 10˚

Appendix

Troubleshooting

Problem Possible Solution

• No power

• Check if you pressed TV POWER on the remote control unit. (See page 17.) If the indicator on the TV is off, press POWER on the TV.

• Is the AC cord disconnected? (See page 6.)

• Unit cannot be operated.

• Remote control unit does not operate.

• Picture is cut off/with sidebar screen.

• Strange color, light color, or color misalignment

• Power is suddenly turned off.

• No picture

• External influences such as lightning, static electricity, may cause improper operation. In this case, operate the unit after first turning on the power of the TV or unplugging the AC cord and replugging it in after 1 or 2 minutes.

• Is the FUNCTION set correctly? Set it to the TV setting position.

• Are batteries inserted with polarity (e, f) aligned? (See page 7.)

• Are batteries worn out? (Replace with new batteries.)

• Are you using it under strong or fluorescent lighting?

• Is a fluorescent light illuminated near the remote control sensor?

• Is the image position correct? (See page 64.)

• Are screen mode adjustments such as picture size made correctly? (See pages 68 and 69)

• Adjust the picture tone. (See pages 44 to 47.)

• Is the room too bright? The picture may look dark in a room that is too bright.

• Check the input signal setting. (See page 66.)

• Is the sleep timer set? (See page 71.)

• Check the power control settings. (See page 49.)

• The unit’s internal temperature has increased. Remove any objects blocking vent or clean the vent.

• Is connection to other components correct? (See pages 53 to 58.)

• Is correct input signal source selected after connection? (See page 66.)

• Is the correct input selected? (See page 66.)

• Is a non-compatible signal being input? (See page 93.)

• Is picture adjustment correct? (See pages 44 to 47.)

• Is “On” selected in “Audio Only”? (See page 70.)

• If, after inserting the CableCARD, you are unable to receive broadcast service, remove the CableCARD and reinsert.

• No sound

• Upgrade is displayed continuously.

• Is the volume too low? (See page 35.)

• Is “Variable” selected in “Output Select”? (See page 71.)

• Verify your antenna cable is connected property.

• Reinsert the CableCARD. If the trouble still exists after reinserting the CableCARD and verifying the antenna cable, please contact your Cable Provider Company.

Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction. Storage temperature: –4°F to +140°F (–20°C to +60°C)

Appendix

Troubleshooting-TV Guide On Screen

Problem Possible Solution

• LISTINGS disappeared after a power failure.

• You should begin to receive listings again within 24 hours.

• Some channel numbers in the TV Guide On Screen are incorrect.

• You have not received any local program listings.

• A program you set to record did not record.

• The TV did not tune to a program you scheduled with the reminder feature.

• You set a program to "auto tune TV" and it did not.

• You set a program with the "power on TV" option and it did not.

• You can correct them using "Changing channel display" under SETUP.

Listings usually appear within 24 hours after a successful Setup.

• Check the connections between the TV, cable, antenna, and the G-LINK cable if using a cable box.

• Verify Setup information under "Changing system settings".

• Make sure the cable box is on, if applicable.

• Review step 4 and step 5 of "Basic Initial Setup" on page 21.

• Make sure your recorder is turned off before the recording begins.

• Make sure there is free space available for recording on the tape or recording device.

• Check the SCHEDULE menu and verify that the program is listed, before recording begins.

• Check the placement of the G-LINK cable in front of your recorder.

• Check the SCHEDULE menu and verify that the program is listed.

• If you have a cable box, check the G-LINK cable.

• Check the SCHEDULE menu and verify that the program is listed as a Reminder.

• Highlight the program under LISTINGS and do the following:

- Press MENU on the remote control.

- Use b to highlight "edit reminder", and press ENTER.

- Verify the "auto tune TV" option reads "yes".

• The TV must be on at the scheduled time for "auto tune TV".

• Check the SCHEDULE menu and verify that the program is listed as a Reminder.

• Highlight the program under LISTINGS and do the following:

- Press MENU on the remote control.

- Use b to highlight "edit reminder", and press ENTER.

- Verify that the "power on TV" option reads "yes".

• The TV must be off at the scheduled time for "power on TV".

Appendix

Troubleshooting-Digital broadcasting

■ The error message about reception of broadcast

The example of an error message displayed on a screen

• Failed to receive broadcast.

• No broadcast now.

Error code Possible Solution

E202 E203

■ The cautions about i.LINK

Caution sentence

• Record/Playback may fail on the selected model.

• Wrong connection or no i.LINK connection was found. Refer to Operation Manual on connection.

• The selected model is disabled to record/play. Check that no other model is used.

PC compatibility chart

• Check the antenna cable. Check that the antenna is correctly setup.

• Check the broadcast time in the program guide.

Possible Solution

• Displayed when you have selected a device that is not compatible with the TV, or that does not have DTLA copy protection technology installed.

• Displayed when a problem is experienced with a connection using i.LINK cable. Check the connection, and re-connect the cable if necessary.

• Displayed when the device you have selected is already being used by another i.LINK connected device. To operate the selected device from the TV, you will first have to override control from the other device.

PC/MAC Resolution Horizontal Frequency Vertical Frequency VESA Standard

MAC13" MAC16" MAC19"

640 x 400

720 x 400

VGA

640 x 480

WVGA 848 x 480

SVGA 800 x 600

1024 x 768XGA

WXGA

SXGA

VGA

SVGA

XGA

1280 x 720 1280 x 768

1280 x 1024

640 x 480 832 x 624

1024 x 768

31.5 kHz

37.9 kHz

31.5 kHz

37.9 kHz

31.5 kHz

37.9 kHz

37.5 kHz

43.3 kHz

31.5 kHz

35.1 kHz

37.9 kHz

48.1 kHz

46.9 kHz

53.7 kHz

48.4 kHz

56.5 kHz

60.0 kHz

68.7 kHz

45.0 kHz

48.1 kHz

64.0 kHz

34.9 kHz

49.7 kHz

60.2 kHz

60 Hz 85 Hz 60 Hz 85 Hz 60 Hz 72 Hz 75 Hz 85 Hz 60 Hz 56 Hz 60 Hz 72 Hz 75 Hz 85 Hz 60 Hz 70 Hz 75 Hz 85 Hz 60 Hz 60 Hz 60 Hz 67 Hz 75 Hz 75 Hz

O O O O O

O O O O O O O O O

Apple and Macintosh are registered trademarks of Apple Computer, Inc. DDC is a registered trademark of Video Electronics Standards Association. Power Management is a registered trademark of Sun Microsystems, Inc. VGA and XGA are registered trademarks of International Business Machines Co., Inc.

Appendix

RS-232C port specifications

PC Control of the TV

• When a program is set, the TV can be controlled from the PC using the RS-232C terminal. The input signal (PC/AV) can be selected, the volume can be adjusted and various other adjustments and settings can be made, enabling automatic programmed playing.

• Attach an RS-232C cable cross-type (commercially available) to the supplied Din/D-Sub RS-232C for the

connections.

NOTE

• This operation system should be used by a person who is accustomed to using computers.

Communication conditions

Set the RS-232C communications settings on the PC to match the TV’s communications conditions. The TV’s communications settings are as follows:

Baud rate: Data length: Parity bit:

Stop bit:

Flow control:

9,600 bps

8 bits None 1 bit None

Communication procedure

Send the control commands from the PC via the RS-232C connector. The TV operates according to the received command and sends a response message to the PC. Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the next command.

Command format

Eight ASCII codes e CR

C1 C2 C3 C4 P1 P2 P3 P4

Parameter

Input the parameter values, aligning left, and fill with blank(s) for the remainder. (Be sure that 4 values are input for the parameter.) When the input parameter is not within an adjustable range, “ERR” returns. (Refer to “Response code format”.) Any numerical value can replace the “x” on the table.

Command 4-digits:Command. The text of four characters. Parameter 4-digits:Parameter 0 – 9, x, blank, ?

Return codeCommand 4-digits Parameter 4-digits

0009

⫺ 30

100

0055

When “?” is input for some commands, the present setting value responds.

????

Appendix

Response code format

Normal response

Return code (0DH)

Problem response (communication error or incorrect command)

ERR

Return code (0DH)

Command table

• Commands not indicated here are not guaranteed to operate.

CONTROL ITEM COMMAND

POWER SETTING It shifts to standby. INPUT SELECTION A TOGGLE

INPUT SELECTION B

AV MODE SELECTION

VOLUME

POSITION

VIEWMODE

MUTE

Dolby Virtual

AUDIO SELECTION SLEEP TIMER

CHANNEL

Air/Cable SELECT

TV INPUT1-5 i.LINK INPUT 1

INPUT 2

INPUT 5

H-POSITIONH-POSITION

V-POSITION

CLOCK PHASE

DIRECT CHANNEL (ANALOG) DIRECT CHANNEL (DIGITAL)

CH UP CH DOWN

POWR

ITGD ITVD IAVD

LINKx___

INP1

INP5

AVMD

VOLM HPOS

VPOS

CLCK PHSE

WIDE

MU T E 0

ACDV

ACHAx _ _ _

OFTM

DCCH

DA2 P * * * * DC2 U * * * _

DC2 L * * * _

DC1 0 * * * * DC1 1 * * * *

CHUP CHDW

CLCP

PARAMETER

2 3

5 6

* ***

_ _

1 23_____

_ _

(Toggle) _ _

Input terminal number (1–5)

AUTO

AUTO _

VIDEO _

COMPONENT _

AUTO

AUTOINP2 _

VIDEO _

COMPONENT _

DIGITAL PC _

ANALOG PC _

DIGITAL AV _

ANALOG AV _

(Toggle) _

STANDARD _

MOVIE

GAME

_ _

USER _

DYNAMIC (Fixed) _

DYNAMIC _

Volume (0–60) _

AV mode. (Ⳳ10)

INPUT5: AV mode. (Ⳳ90)***_ _

PC mode. (0–180) _

AV mode. (Ⳳ20)

INPUT5: AV mode. (Ⳳ50)

_ _

PC mode. (0–100) _

Only PC mode. (0–180) _

Only PC mode. (0–40) _

(Toggle) [AV] _

Side Bar [AV] _

S.Stretch [AV] _

Zoom [AV] _

Stretch [AV] _

Normal [PC] _

Zoom [PC] _

Stretch [PC] _

Dot by Dot [PC]

(Toggle)

Off

_ _

(Toggle) _

On _

Off

(Toggle) _

OFF _

OFF TIMER – 30 MIN.

OFF TIMER – 60 MIN.

OFF TIMER – 90 MIN.

OFF TIMER – 120 MIN. 4___ _

The channel number of TV

(1–125)

(0-999)

(0-9999)

(0-6383) _

The channel number of TV Ⳮ1 _

The channel number of TV ⳮ1

AIR1___

CABLE2___ _

(Toggle)

It input-switches by the toggle. (It is the same as an input change key) It input-switches to TV. (A channel remains as it is. (Last memory)) It input-switches to INPUT1~INPUT5. It input-switches to i.LINK. An input change is also included.

Although it can choose now, it is toggle operation in inside.

An input change is included if it is not TV display. In Air, 2–69ch is effective. In Cable, 1–125ch is effective. DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)(0101-9999) DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel) DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel) DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000) DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000) If it is not TV display, it will input-switch to TV. (same function as CHr) If it is not TV display, it will input-switch to TV. (same function as CHs) AIR s CABLE s AIR(Toggle)ACS L 0 _ __

Toggle operation of a closed caption.

CONTROL CONTENTS

NOTE

• If an underbar (_) appears in the parameter column, enter a space.

• If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.

• As long as that from which the parameter (g) in the table is a numerical value, it may write anything.

Appendix

Specifications

Item Model: LC-37D5U

LCD panel 37o Advanced Super

View & BLACK TFT LCD

Model: LC-32D5U Model: LC-26D5U

32o Advanced Super View & BLACK TFT LCD

26o Advanced Super View & BLACK TFT LCD

Number of dots 3,147,264 dots (1366 m 768 m 3 dots) TV

Function

TV-standard (CCIR) Receiving

Channel

VHF/UHF

CATV 1-125ch

Digital Terrestrial Broadcast (8VSB)

Digital cable (64/256 QAM)

American TV Standard ATSC/NTSC System VHF 2-13ch, UHF 14-69ch

2-69ch

1-135ch

Audio multiplex BTSC System

Brightness 450 cd/m

Backlight Life 60,000 hours (at Backlight Standard position) Viewing angles H : 170° V : 170° Audio out 10W m 2 Terminals

Rear

INPUT 1 INPUT 2 INPUT 3 INPUT 4

AV in, COMPONENT in AV in, COMPONENT in S-VIDEO in, AV in

HDMI in (Type-A) with HDCP INPUT 5 Audio in, DVI-I in with HDCP ANALOG ANTENNA DIGITAL ANTENNA MONITOR/REC OUT G-LINK

DIGITAL AUDIO OUTPUT i.LINK CableCARD slot

75 q Unbalance, F Type for VHF/UHF/CATV in m 1

75 q Unbalance, F Type m 2 (for Digital Air m 1/Digital Cable in m 1)

S-VIDEO out, AV out

Ø 3.5mm jack Optical Digital audio output m 1 (PCM/Dolby Digital)

IEEE1394 m 2 with DTCP 68 pin PCMCIA m 1

OSD language English/French/Spanish

Power Requirement Power Consumption

Weight

TV only

Stand

AC 120 V, 60 Hz 195 W

45.4 lbs./20.6 kg

10.8 lbs./4.9 kg

56.2 lbs./25.5 kgTV with stand

155 W 130 W

39 lbs./17.7 kg 29.8 lbs./13.5 kg

8.4 lbs./3.8 kg 7.7 lbs./3.5 kg

47.4 lbs./21.5 kg 37.5 lbs./17 kg

Accessories Operation manual (m1), Remote control unit (m1), AC cord (m1), “AAA” size

battery (m2), Cable clamp (m1), G-LINK cable (m1), Cable tie (m1)

• As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

Optional accessories

The listed optional accessories are available for these AQUOS models. Please purchase it at your nearest shop.

• Additional optional accessories may be available in the near future. When purchasing, please read the newest catalogue for compatibility and check the availability.

Tilting wall-mount bracket for LC32D5U and LC-37D5U

Part name Part number

AN-37AG2

Dimensional drawings

LC-37D5U

647)

(

200)

(

562)3

(

85)

(

104)

(

Unit: inch/(mm)

2613/32(

671)

/2(

1105)

/8(

822.6)

463.8)

(

/8(

200)

367.8)

(

/8(

105) 4

/64(

114)

/64(

306)

LC-32D5U

578)

(

200)

(

493)3

(

85)

(

115)

(

247/8(

632)

/64(

980)

/64(

700.4)

395.1)

(

/8(

200)

333.5)

(

/64(

90) 4

/64(

114)

/8(

289)

Dimensional drawings

LC-26D5U

497)

(

100) 19

(

418)

(

79) 16

(

50) 3

50)1

(

Unit: inch/(mm)

/64(

560)

/8(

848)

/64(

567.9)

320.6)

(

/16(

100)

289)

(

/8(

54)4

/64(

114)

482)

(

/64(

268)

HOW TO SET THE FACTORY PRESETS

Check that the power indicator is not on. Remove the AC cord and switch off the power. Press and hold down RESET at the same time as you re-insert the AC Cord into the outlet and switch on the TV. All setting items (except TV channel) return to the factory presetting.

NOTE

• Running the factory presetting operation also clears the secret number.

You can run the EZ Setup again by using the following steps.

1 Turn on the power of the TV. 2 Press MENU. (Make sure the menu screen displays.) 3 Press c/d to select “Setup”. 4 Press a/b to select “EZ Setup”. 5 Press ENTER.

NOTE

• If the secret number setting screen displays, you need to enter your secret number.

• If you forget your secret number, refer to HOW TO SET THE FACTORY PRESETS above.

The secret number is .

NOTE

• As a precautionary measure, make a note of your secret number above, scissor it from this manual, and keep it in a familiar place.

Calling for Service

For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer assistance, please call 1-800-BE-SHARP.

LIMITED WARRANTY

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Model Specific Section Your Product Model Number & Description:

Warranty Period for this Product: Additional Item(s) Excluded from

Warranty Coverage (if any):

Where to Obtain Service:

What to do to Obtain Service: LC37D5U/LC-32D5U

LC-26D5U

TO OBTAIN PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com

LC-37D5U • LC-32D5U • LC-26D5U LCD Color Television (Be sure to have this information available when you need service for your Product.)

One (1) year parts and labor from the date of purchase.

Non-rechargeable batteries. From a Sharp Authorized Servicer located in the United States.

To find the location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP.

Contact your Sharp Authorized Servicer to obtain in-home service for this Product. The Servicer will come to your home and if it is necessary to remove the Product, the Servicer will reinstall it. Be sure to have Proof of Purchase available.

Ship prepaid or carry in your Product to a Sharp Authorized Servicer. Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and packaged securely.

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

Sharp LC-26D5U, LC-32D5U, LC-37D5U Operating Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
