Sharp HRO00185 User Manual
General Inquiries
FCCID:APYHRO00185
<docomo Information Center>
(Business hours: 24 hours (open all year round))(Business hours: 9:00 a.m. to 8:00 p.m.)
0120-005-250 (toll free)
ɦ Service available in: English, Portuguese, Chinese, Spanish, Korean.
Unavailable from part of IP phones.
ɦ
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year round))
ɡ
From DOCOMO mobile phones
(In Japanese only)
(No prefix) 151 (toll free)
ɦ Unavailable from land-line phones, etc.
ɜ Please confirm the phone number before you dial.
ɜ For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo Shop etc. near you on
the NTT DOCOMO website or the i-mode site.
NTT DOCOMO websiteȁhttp://www.nttdocomo.co.jp/english/
ɡFrom land-line phones
(In Japanese only)
0120-800-000
Unavailable from part of IP phones.
ɦ
(toll free)
Loss or theft of FOMA terminal or
payment of cumulative cost overseas
<docomo Information Center>
From DOCOMO mobile phones
International call access code
for the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
If you use SH-05D, you should dial the number +81-3-6832-6600
ɦ
(to enter “+”, press and hold the “0” key for at least one second).
-81-3-6832-6600
*
(toll free)
From land-line phones
<Universal number>
Universal number
international prefix
* You might be charged a domestic call fee according to the call rate for the
country you stay.
ɦ
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
ɜġIf you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the
FOMA terminal.
ġ
ɜ
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO
after returning to Japan.
-8000120-0151
*
ɡFrom DOCOMO mobile phones
(In Japanese only)
(No prefix) 113 (toll free)
ɦ
Unavailable from land-line phones, etc.
i-mode siteȁiMenuȁݖအεȜΠ (user support)ȁΡκΏοΛίġ
(docomo Shop) ɦIn Japanese only
Failures encountered overseas
<Network Support and Operation Center>
(available 24 hours a day)(available 24 hours a day)
From DOCOMO mobile phones
International call access code
for the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
If you use SH-05D, you should dial the number +81-3-6718-1414
ɦ
(to enter “+”, press and hold the “0” key for at least one second).
From land-line phones
<Universal number>
Universal number
international prefix
You might be charged a domestic call fee according to the call rate for the
*
country you stay.
ɦ
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
Repairs
ɡFrom land-line phones
(In Japanese only)
0120-800-000
ɦ Unavailable from part of IP phones.
-81-3-6718-1414
-8005931-8600
(toll free)
*
(toll free)
*
Don’t forget your mobile phone… or your manners!
When using your mobile phone in a public place, don’t forget to show common courtesy and consideration for
others around you.
Sales:
Manufacturer: SHARP Corporation
To prevent damage to the environment,
bring used battery packs to a docomo
service counter, a docomo agent or a
recycle center.
’12.1 (1st Edition)
12A MS117
㸭㸭∧
SH-05D
INSTRUCTION MANUAL
1
’12.1
n Strap hole
o FOMA antenna*
p Camera
Use to shoot still pictures or moving pictures.
q Infrared port (nP. 80)
r Back cover (nP. 23)
s @ mark
When charging, place the FOMA terminal
slowly so that @ mark of the wireless charger
faces that of the FOMA terminal.
t Bluetooth/Wi-Fi antenna*
u Back cover lever (nP. 23)
* The antenna is built in the terminal. Covering the
antenna area with your hand may influence the
quality.
Precautions (Always follow
these directions)
Before use, read these “Precautions” carefully and
use your FOMA terminal properly.
Keep this manual in a safe place for future
reference.
These precautions contain information intended to
prevent bodily injury to the user and to surrounding
people, as well as damage to property, and must be
observed at all times.
The following symbols indicate the different
degrees of injury or damage that may occur if
information provided is not observed and the
FOMA terminal is used improperly.
The 1Seg antenna is built in the terminal. The
whole FOMA terminal works as the antenna.
Danger
Warning
Caution
This symbol indicates
that “death or serious
bodily injury may
directly and
immediately result
from improper use”.
This symbol indicates
that “death or serious
bodily injury may
result from improper
use”.
This symbol indicates
that “minor injury and/
or property damage
may result from
improper use”.
Introduction
6
The following symbols indicate specific
Danger
directions.
Handling the FOMA terminal, battery
pack, adapters, wireless charger, and
Indicates a prohibited action.
Indicates not to disassemble the
device.
Indicates not to handle the device with
wet hands.
Indicates not to use the device near
water or get it wet.
Indicates that instructions
specified are compulsory (must
be followed).
Indicates that the power cord must be
unplugged from the outlet.
“Precautions” is explained in the following six
sections.
Handling the FOMA terminal, battery pack,
adapters, wireless charger, and docomo mini UIM
card (general) . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 7
Handling the FOMA terminal . . . . . . . . . . . . . . . P. 9
Handling battery pack. . . . . . . . . . . . . . . . . . . . P. 11
Handling adapters and wireless charger . . . . . P. 12
Handling docomo mini UIM card. . . . . . . . . . . . P. 13
Handling near electronic medical equipment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14
docomo mini UIM card (general)
Do not use, store or leave the
equipment in locations subject to
high temperatures (near a fire or
heating unit, in a kotatsu, under
direct sunlight, inside a vehicle on a
hot day, etc.).
May cause fires, burns or bodily injury.
Do not place the equipment inside
cooking appliances such as
microwave ovens or pressure
cookers.
May cause fires, burns, bodily injury or electric shock.
Do not attempt to disassemble or
modify the equipment.
May cause fires, burns, bodily injury or electric shock.
Do not get the equipment wet with
water, drinking water, pet urine, etc.
May cause fires, burns, bodily injury or electric shock.
Refer to the following for details on waterproofness.
n“Waterproof/Dust-proof function” on P. 22
Use only the battery packs and
adapters specified by NTT DOCOMO
for use with the FOMA terminal.
May cause fires, burns, bodily injury or electric shock.
Introduction
7
Do not subject the equipment to
Warning
Caution
strong force or impacts or throw it.
May cause fires, burns, bodily injury or electric shock.
Do not allow conductive materials
(such as metal objects and pencil lead)
to come into contact with the charger
terminal or external connector terminal.
In addition, do not insert such objects.
May cause fires, burns, bodily injury or electric shock.
Do not cover or wrap the equipment
with bedding, etc. when using or
charging.
May cause fires or burns.
Do not use the FOMA terminal near
high-precision electronic devices or
devices that use weak electronic
signals.
May interfere with the operation of electronic devices.
Take particular care with the following devices
Hearing aids, implanted cardiac pacemakers, implanted
cardioverter-defibrillators or other electronic medical
equipment. Fire alarms, automatic doors, and other
equipment controlled by electronic signals. If you use
an implanted cardiac pacemaker, implanted
cardioverter-defibrillator or other electronic medical
equipment, contact the respective manufacturer or
vendor to check whether the operation of the equipment
is affected by signals.
Make sure to turn off the FOMA
terminal and not to charge the battery
in locations such as gas stations
where flammable gas is generated.
May cause a gas explosion or fire.
If you notice anything unusual, such
as an unusual odor, overheating,
discoloration or deformation during
use, charging or storage, immediately
follow the instructions below.
Unplug the power cord from the
outlet or cigarette lighter socket.
Turn off the FOMA terminal.
Remove the battery pack from the
FOMA terminal.
May cause fires, burns, bodily injury or electric shock.
Do not leave the equipment on
unstable surfaces, such as on a
wobbling table or sloped surface.
May fall and cause injury.
Do not store the equipment in
locations that are subject to
humidity, dust or high temperatures.
May cause fires, burns or electric shock.
If being used by a child, have a guardian
teach him/her the proper handling
procedures. In addition, check that the
child is using the equipment as directed.
May result in bodily injury.
Keep the equipment out of the reach
of young children.
A young child may swallow the equipment or suffer
other bodily injury.
Introduction
8
Be very careful when using the FOMA
Warning
terminal connected to adapters
repeatedly or for a long time.
The FOMA terminal, battery pack or
adapters may become warm if i-appli, videophone or
1Seg is used for a long time while charging.
Touching high temperature areas for a long time may
cause skin irritations, itchiness or low-temperature burn
in some people.
Handling the FOMA terminal
Do not aim the infrared port towards
the eyes.
Turn off the FOMA terminal in areas
where the use of mobile phones is
prohibited, such as in aircraft or
hospitals.
May interfere with the operation of electronic devices
and electronic medical equipment.
In addition, if auto power on function is set to on,
disable this function before turning off your mobile
phone.
Follow the instructions given by the respective medical
facilities regarding the use of mobile phones on their
premises.
Actions such as using a mobile phone aboard aircraft
are prohibited and punishable by law.
However, follow the instructions on use of the FOMA
terminal given by the airline if the mobile phone can be
used aboard aircraft by setting the mobile phone such
as setting it not to emit radio wave.
May cause eye injury.
Do not aim the infrared port towards
home electric appliances with an
infrared device during Ir
communication.
May interfere with the operation of infrared devices and
cause an accident.
Do not allow water or other liquids,
metal, flammable material or other
foreign objects to enter the docomo
mini UIM card or microSD Card slot
on the FOMA terminal.
May cause fires, burns, bodily injury or electric shock.
Keep the FOMA terminal away from
the ears during a call in which
hands-free is set or while the ring
tone is ringing.
When you attach the earphone/
microphone, etc. to the FOMA
terminal to play games, music, etc.,
do not make the volume too loud.
Excessive high volume may damage your hearing.
Also, it may prevent you from hearing the ambient
sounds and cause an accident.
Earphone Signal Level
The maximum output voltage for the music player
function, measured in accordance with EN 50332-2, is
34.0 mV.
If you have a weak heart, take extra
precautions when setting functions
such as the vibrator and ring tone
volume for incoming calls.
May have harmful effects on your heart.
Introduction
9
If you are using electronic medical
Caution
equipment, contact the respective
manufacturer or vendor to check
whether the operation of the
equipment is affected by signals.
May interfere with the operation of electronic medical
equipment, etc.
In case that the display part or camera
lens is damaged, make sure to pay
attention to a broken glass and the
exposed inside of the FOMA terminal.
The surfaces of the display part and the camera lens are
covered by plastic panels so as to minimize the possibility of
glass scattering. However, touching the broken or exposed
parts may cause injury.
If the display is broken and internal
substances such as liquid crystal
then leaks, do not get the liquid on
your skin (face, hands, etc.).
May result in loss of eyesight and harm to your skin.
If internal substances such as liquid crystal come into
contact with your eyes or mouth, immediately rinse your
eyes or mouth with clean water and see a doctor.
If the liquid comes into contact with your skin or clothes,
immediately wipe it off with alcohol, and wash with
water and soap.
If you use the FOMA terminal in an
automobile, contact the automobile
manufacturer or vendor to check
whether the operation of the electronic
equipment is affected by signals.
May interfere with the operation of electronic equipment
in some vehicle models. In such cases, stop using the
FOMA terminal.
Do not swing the FOMA terminal by
its strap etc.
May hit you or others around you, resulting in bodily injury.
Do not use the damaged FOMA
terminal.
May cause fires, burns, bodily injury or electric shock.
Introduction
10
Use of the FOMA terminal may cause
skin irritations such as itchiness,
rashes or eczema in some people. If
this occurs, immediately stop using
the FOMA terminal and seek medical
treatment.
For details on materials of each part n“Material list”
on P. 14
Do not close the FOMA terminal on
your fingers or objects such as the
strap.
May result in bodily injury.
Look at the display in a well-lit place,
keeping a certain distance from the
screen.
Otherwise, eyesight may be decreased.
Handling battery pack
Danger
Warning
Caution
Check the type of battery using the information
printed on the battery pack label.
Label Battery type
Li-ion00 Lithium-ion
If the battery fluid, etc. comes into
contact with your eyes, do not rub
your eyes but immediately rinse
your eyes with clean water. Then
seek prompt medical treatment.
May result in loss of eyesight.
Do not touch terminals with metallic
objects such as wires. In addition,
do not carry or store the battery
pack with metallic necklaces, etc.
The battery pack may catch fire, explode, overheat or leak.
Check that the battery pack is facing
the correct direction before you
attach it to the FOMA terminal. If you
are having difficulty fitting the
battery pack to the FOMA terminal,
do not use excessive pressure to
force the battery into place.
The battery pack may catch fire, explode, overheat or leak.
Do not throw the battery pack into a
fire.
The battery pack may catch fire, explode, overheat or leak.
Do not puncture, hit with a hammer
or step on the battery pack.
The battery pack may catch fire, explode, overheat or leak.
If any trouble such as a deformation
or scratches caused by a drop is
found, never use it.
The battery pack may catch fire, explode, overheat or leak.
If the battery pack leaks, emits an
unusual odor, etc., immediately stop
use and move it away from any flame
or fire.
The battery fluid is flammable and could ignite, causing
a fire or explosion.
Prevent your pet from biting the
battery pack.
The battery pack may catch fire, explode, overheat or leak.
Do not dispose of used battery
packs in ordinary garbage.
May cause fires or damage to the environment. Place
tape over the terminals to insulate unnecessary battery
packs, and take them to a docomo Shop, retailer or
institution that handles used batteries in your area.
Introduction
11
Do not use or charge a wet battery
Warning
pack.
Do not touch adapters
if you hear thunder.
The battery pack may catch fire, explode, overheat or leak.
If the battery fluid, etc. leaks, do not
get the liquid on your skin (face,
hands, etc.).
May result in loss of eyesight and harm to your skin.
If the liquid, etc. comes into contact with your eyes,
mouth, skin or clothes, immediately rinse them with
clean water.
If the liquid comes into contact with your eyes or mouth,
see a doctor immediately after rinsing your eyes or mouth.
Handling adapters and wireless
charger
Do not use if the cord of the adapter
is damaged.
May cause fires, burns or electric shock.
May cause electric shock.
Take care not to short-circuit the
charging terminal when it is connected
to an outlet or cigarette lighter socket.
Also, take care not to allow any part of
your body (hands, fingers, etc.) to come
into contact with the charging terminal.
May cause fires, burns or electric shock.
Do not place heavy objects on the
cord of the adapter
May cause fires, burns or electric shock.
When plugging/unplugging the AC
adapter into/from the outlet, do not allow
metallic straps or other metallic objects
to come into contact with the terminal.
May cause fires, burns or electric shock.
Do not place foreign objects
between the FOMA terminal.
May cause overheat or burns or catch fire.
Never use the AC adapter
in humid locations
such as a bathroom.
May cause fires, burns or electric shock.
The DC adapter should only be used
in negative grounded vehicles.
Never use this adapter in positive
grounded vehicles.
May cause fires, burns or electric shock.
Introduction
12
Do not paste stickers such as
aluminium or metallic objects on the
wireless charger.
May cause overheat or burns or catch fire.
Do not connect the voltage
converter for overseas travel (Travel
converter) to the wireless charger.
May cause overheat or electric shock or catch fire.
Do not handle the cord of the
Caution
adapters, the wireless charger or the
outlet with wet hands.
May cause fires, burns or electric shock.
Do not charge any parts wet with
water with the wireless charger.
May cause fires, burns, bodily injury or electric shock.
Always use the specified power
supply and voltage.
When using overseas, use the AC
adapter that is available overseas.
Using the incorrect voltage may cause fire, burns or
electric shock.
AC adapter: 100V AC
DC adapter: 12/24V DC (for negative grounded vehicles only)
AC adapter available overseas: 100 to 240V AC (Connect
only with household AC outlet)
If the fuse in the DC adapter blows,
always replace it with a fuse of the
specified type.
May cause fires, burns or electric shock. Refer to the
respective manuals for information on the correct fuse
specifications.
Wipe off any dust on the power plug.
Always grasp the adapters when
unplugging the power plug from the
outlet or cigarette lighter socket. Do
not forcibly pull by the cord of the
adapter or of the wireless charger.
May cause fires, burns or electric shock.
If you have an implanted cardiac
pacemaker or an implanted
cardioverter-defibrillator, consult a
doctor about the use of the wireless
charger.
Electromagnetic signals may have harmful effects on
the operation of implanted cardiac pacemakers and
implanted cardioverter-defibrillators.
Unplug the power plug from the
outlet or cigarette lighter socket
when not using for a long time.
May cause fires, burns or electric shock.
Should water or other liquids enter
the equipment, remove the power
plug from the outlet or cigarette
lighter socket immediately.
May cause fires, burns or electric shock.
Always unplug the power plug from
the outlet or cigarette lighter socket
before cleaning the adapters.
May cause fires, burns or electric shock.
May cause fires, burns or electric shock.
Fully plug the AC adapter or the
power plug into the outlet.
May cause fires, burns or electric shock.
Handling docomo mini UIM card
Be careful with the cutting surface
when detaching the docomo mini
UIM card.
May cause bodily injury.
Introduction
13
Loading...
