INSTRUCTION MANUAL

’11.●

SH-13C

’11.7

Introduction

Thank you for purchasing “AQUOS PHONE f SH-13C”. Make sure to read this manual before and during use to ensure proper operation.

Using the FOMA terminal

SH-13C supports W-CDMA, GSM/GPRS and

Wireless LAN System.

Because the FOMA terminal relies on radio signals,

it cannot be used in places with no signal (such as tunnels, underground or in buildings), in places with a weak signal or outside the FOMA service area. You may not use the FOMA terminal in the upper floors of a building even with no obstructions in sight. There may also be times when the signal is strong and you are not moving but the call is interrupted.

Because the FOMA terminal uses electrical signals,

it is possible for a third party to listen in on a conversation. However, since the W-CDMA and GSM/GPRS systems automatically apply privacy to every call, a third party that tries to listen in only hears static.

The FOMA terminal converts conversations into a

digital signal and sends it to the other party over the radio. If the signal cannot be reconverted properly by such as moving to an area with a weak signal, the voice may not be heard correctly.

Keep a separate memo and note information (e.g.

phonebook, calendar, notepad, voice memo, answering memo) stored in the FOMA terminal. DOCOMO shall not be liable for any loss of content due to a failure, repair, upgrade or other handling of the FOMA terminal.

As with PCs, some user-installed applications etc.

may disrupt the stability of your FOMA terminal performance or unexpectedly transmit information via the Internet causing improper use of your location information and personal information stored in the FOMA terminal. Therefore, verify the supplier and operating conditions of the applications to be used before using them.

It is recommended to save the important data to the

microSD Card.

The FOMA terminal supports the FOMA Plus-Area

and the FOMA HIGH-SPEED area.

Unlocking SIM card

The FOMA terminal can unlock the SIM card. Unlock the SIM card to use non-DOCOMO SIM cards.

SIM card can be unlocked at a docomo Shop. Commission is incurred separately for unlocking SIM

card.

When using non-DOCOMO SIM card, some

services and functions are unavailable. DOCOMO shall not be liable for guaranteeing operation of the FOMA terminal.

For details on unlocking SIM card, refer to

DOCOMO website.

Download the latest information on this manual from the DOCOMO website.

“User’s Manual (in PDF format)” Download

http://www.nttdocomo.co.jp/english/support/ trouble/manual/download/index.html

ɦ The URL and contents of this manual are

subject to change without prior notice.

Main optional parts

SH-13C terminal (includes warranty and Back Cover SH55)

microSD Card (2 GB) (sample) (includes user’s guide)

microSD Card is inserted to the FOMA terminal by default.

Wireless Charger SH01 (includes warranty)

Battery Pack SH29

microUSB cable for PC (sample) (includes user’s guide)

Quick Start Guide (in Japanese only)

Basic package and main optional parts

Basic package

FOMA AC Adapter 01/02 (includes warranty and user’s guide)

For details on other optional parts nP. 127

The screens and illustrations in this manual

are shown as examples. The actual screens and illustrations may differ.

The explanations in this manual are based on

default settings. The actual screens may differ depending on settings changed after purchase.

Note that “SH-13C” is referred to as “FOMA

terminal” in this manual.

This manual refers to microSD Card as

“microSD Card” or “microSD”.

Reproduction of this manual in part or in whole

is prohibited.

The contents of this manual are subject to

change without prior notice.

Checking operation method on the FOMA terminal

Select [R]/[Instruction Manual] in the home screen. Main contents described in the manual can be referred (in Japanese only). Also, you can find a description of the function you want to use using table of contents, index and searching. The latest information on the manual is

described.

FOMA charger micro USB adapter SH01 (includes warranty and user’s guide)

Contents

Basic package and main optional parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Notes on using SH-13C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Precautions (ALWAYS FOLLOW THESE DIRECTIONS) . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Handling precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Waterproof/Dust-proof function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Part names and functions, miniUIM, microSD Card, Battery

Before Using the Handset P. 28

pack, Charging, Power ON/OFF, Basic operation, Changing screen display to English, Initial setting, Screen display/icon, Home screen, Application screen, Market, docomo market, Character entry

Call/Network Services P. 64

Various Settings P. 75

Mail/Internet P. 87

Phone, Outgoing call history/Incoming call history, Phonebook, Available network services

Setting menu, Profile, Energy saving settings, Wireless & networks, Call settings, Sound settings, Display settings, USB connection, Location & security, Applications, Accounts & synchronization, Privacy, microSD & phone storage, Language & keyboard, Voice input & output, Accessibility, Pedometer setting, Date & time, About phone, Security codes

Mail, Early warning “Area Mail”, Browser

Contents/Precautions

Multimedia P. 92

Camera, Camera reader, Gallery, Picture, Music player

File Management P. 102

Applications P. 112

Overseas Use P. 123

Appendix/Index P. 127

Contents manager, Infrared communication, iC communication,

Bluetooth with Blu-ray Disc recorder, Home network settings

GPS/Navigation, Compass, Osaifu-Keitai, Calendar, Clock, Notepad, Voice recorder, Calculator, microSD backup,

Dictionary, Pedometer, iD୭೰ͺίς (iD setting appli)

Outline of international roaming (WORLD WING), Available services overseas, Before use overseas, Setting to use overseas, Make/Receive a call in your country of stay

Introduction of options and related devices, Troubleshooting (FAQ), Warranty and After-Sales Service, Software update, OS version upgrade, Main specifications, Specific Absorption Rate (SAR) of mobile phone, Export Administration Regulations, Intellectual Property Right, Index

function, External connector device, Cooperation

Contents/Precautions

Notes on using SH-13C

This FOMA terminal does not support i-mode

functions (connection to i-mode site (broadcast), i-appli, etc.).

Google applications and its service contents

are subject to change without prior notice.

This FOMA terminal automatically performs

communication for some functions, for example, to synchronize data, check the latest software version or maintain connection with the server. Also, making a communication with large-volume data such as downloading applications or watching videos will lead to higher packet communication charges. Subscription to flat-rate packet communication services is highly recommended.

Subscription to sp-mode is required to use

Wi-Fi tethering.

Packet communication charges when using

Wi-Fi tethering are same as when connecting a PC or PDA, etc. Note that making a communication with large-volume data will lead to higher communication charges.

Packet communication charges when using

Wi-Fi tethering differ according to your payment plans. Subscription to flat-rate packet communication services is highly recommended.

If you subscribe to flat-rate packet

communication services, all of the packet communications (including Browser, Mail, etc.) when using Wi-Fi tethering will be regarded as ones with external devices such as PC connected even if external devices are not connected. Make sure that Wi-Fi tethering is disabled as soon as communications using external devices are finished.

For details on usage fees to use, refer to

http://www.nttdocomo.co.jp/ (in Japanese only).

This FOMA terminal does not support Public

mode (Drive mode).

Setting this FOMA terminal to manner mode

does not mute sounds (camera shutter sound, etc.) other than the ring tone, operation sound, and various notification sounds.

Software in this FOMA terminal can be

updated to up-to-date status (nP. 134).

For details on software version of your FOMA

terminal nP. 84

For details on checking your phone number

(own number) nP. 76

New functions may be added to this FOMA

terminal, the operation method may change, etc. by upgrading the OS version. Check the DOCOMO website for the latest information of additions and changes.

Contents/Precautions

If the OS is upgraded, some applications that

used in the previous OS version may not be available or some unintended bugs may occur.

Capacity of microSD Card or the FOMA

terminal is nearly full, applications in use may not work properly. In that case, delete saved data.

Secure the security of the FOMA terminal by

setting Screen lock in case you lose it (nP. 80).

Read the terms of use of Google Inc. for

details on Google services. Also, read each terms of use for details on other web services.

If your FOMA terminal is lost, change your

each account password using a PC to prevent other persons from using Twitter, mixi, and Google services such as Google Talk, Gmail, Android Market.

The FOMA terminal does not support

providers other than mopera U, Business mopera Internet (URL restriction) and sp-mode.

The FOMA terminal is available without

microSD Card. However, some data such as images shot with camera or voices recorded with voice recorder can be saved only to microSD Card. Also, data cannot be sent and received using infrared communication or Bluetooth connection without microSD Card. It is recommended that microSD Card be inserted to use the FOMA terminal.

Precautions (ALWAYS FOLLOW THESE DIRECTIONS)

Before use, read these “Precautions” carefully

and use your FOMA terminal properly. Keep this manual in a safe place for future reference.

These precautions contain information intended

to prevent bodily injury to the user and to surrounding people, as well as damage to property, and must be observed at all times.

The following symbols indicate the different degrees of injury or damage that may occur if information provided is not observed and the FOMA terminal is used improperly.

This symbol indicates that “death or serious bodily

Danger

Warning

Caution

injury may directly and immediately result from improper use”.

This symbol indicates that “death or serious bodily injury may result from improper use”.

This symbol indicates that “minor injury and/or property damage may result from improper use”.

Contents/Precautions

The following symbols indicate specific

Danger

directions.

Indicates a prohibited action.

Indicates not to disassemble the device.

Indicates not to handle the device with wet hands.

“Precautions” is explained in the following six sections.

Handling the FOMA terminal, battery pack,

adapters (including charger micro USB adapter), wireless charger and miniUIM (general)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 6

Handling the FOMA terminal. . . . . . . . . . . . . P. 8

Handling battery pack . . . . . . . . . . . . . . . . . P. 11

Handling adapters (including charger micro USB

adapter) and wireless charger . . . . . . . . . . P. 12

Handling miniUIM . . . . . . . . . . . . . . . . . . . . P. 14

Handling near electronic medical equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14

Handling the FOMA terminal,

Indicates not to use the device near water or get it wet.

Indicates that instructions specified are compulsory (must be followed).

Indicates that the power cord must be unplugged from the outlet.

battery pack, adapters (including charger micro USB adapter), wireless charger and miniUIM (general)

Do not use, store or leave the equipment in locations subject to high temperatures, such as near a fire, in direct sunlight or inside a car on a hot day.

May cause fires, burns or bodily injury.

Do not place the equipment inside cooking appliances such as microwave ovens or pressure cookers.

May cause fires, burns, bodily injury or electric shock.

Contents/Precautions

Do not attempt to disassemble

Warning

Caution

or modify the equipment.

May cause fires, burns, bodily injury or electric shock.

Do not cover or wrap the equipment with bedding, etc. when using or charging.

May cause fires or burns.

Do not get the equipment wet with water, drinking water, pet urine, etc.

May cause fires, burns, bodily injury or electric shock. Refer to the following for details on waterproofness.

“Waterproof/Dust-proof function” on P. 22

Use only the battery packs and adapters (including charger micro USB adapter) specified by NTT DOCOMO for use with the FOMA terminal.

May cause fires, burns, bodily injury or electric shock.

Do not subject the equipment to strong impacts or throw it.

May cause fires, burns, bodily injury or electric shock.

Do not allow conductive materials (such as metal objects and pencil lead) to come into contact with the charger terminal, external device terminal or earphone/microphone terminal. In addition, do not insert such objects.

May cause fires, burns, bodily injury or electric shock.

Make sure to turn off the FOMA terminal and not to charge the battery in locations such as gas stations where flammable gas is generated.

May cause a gas explosion or fire. To use Osaifu-Keitai in locations such as gas stations, make sure to turn off the power in advance (If the Osaifu-Keitai lock setting is activated, disable the lock before turning off the power).

If you notice anything unusual, such as an unusual odor, overheating, discoloration or deformation during use, charging or storage, immediately follow the instructions below.

Unplug the power cord from the outlet or cigarette lighter socket. Turn off the FOMA terminal. Remove the battery pack from the FOMA terminal.

May cause fires, burns, bodily injury or electric shock.

Do not leave the equipment on unstable surfaces, such as on a wobbling table or sloped surface.

May fall and cause injury.

Contents/Precautions

Do not store the equipment in

Warning

locations that are subject to humidity, dust or high temperatures.

May cause fires, burns or electric shock.

Handling the FOMA terminal

If being used by a child, have a guardian teach him/her the proper handling procedures. In addition, check that the child is using the equipment as directed.

May result in bodily injury.

Keep the equipment out of the reach of young children.

A young child may swallow the equipment or suffer other bodily injury.

Be very careful when using the FOMA terminal connected to adapters (including charger micro USB adapter) repeatedly or for long periods of time.

The FOMA terminal, battery pack or adapters (including charger micro USB adapter) may become warm if games etc. are used for a long time while charging. Touching high temperature areas for a prolonged period of time may cause skin irritations, itchiness or low-temperature burn in some people.

Do not aim the infrared port towards the eyes.

May cause eye injury.

Do not aim the infrared port towards home electric appliances with an infrared device during infrared communication.

May interfere with the operation of infrared devices and cause an accident.

Do not point the illuminated light directly at someone’s eyes. Especially when you shoot still pictures or moving pictures of young children, keep 1 m or more distance from them.

Do not use Mobile light near people’s faces. Eyesight may be temporarily affected leading to accidents. Precautions: The Mobile light source used for this product may emit the light over the safety level for eyes when operations such as undirected adjustments are intentionally made. Therefore, do not disassemble the terminal.

Contents/Precautions

EN60825-1:1994 A1:2002 & A2:2001

Mobile light

CLASS1 LED Product

CAUTION:

Use of controls, adjustments or performance of procedure other than those specified herein may result in hazardous radiation exposure. As the emission level from Mobile light LED used in this product is harmful to the eyes, do not attempt to disassemble the cabinet. Servicing is limited to qualified servicing station only.

Do not allow water or other liquids, metal, flammable material or other foreign objects to enter the miniUIM or microSD Card slot on the FOMA terminal.

May cause fires, burns, bodily injury or electric shock.

Do not shine the light at anyone driving a car or other vehicles.

May prevent a driver from driving safely and cause a traffic accident.

Turn off the FOMA terminal in areas where the use of mobile phones is prohibited, such as in aircraft or hospitals.

May interfere with the operation of electronic devices and electronic medical equipment. Follow the instructions given by the respective medical facilities regarding the use of mobile phones on their premises. Actions such as using a mobile phone aboard aircraft are prohibited and punishable by law. However, follow the instructions on use of the mobile phone given by the airline if the mobile phone can be used aboard aircraft by setting the mobile phone such as setting it not to emit radio wave.

Keep the FOMA terminal away from the ears during a call in which hands-free is set or while the ring tone is ringing. When you attach the earphone/ microphone, etc. to the FOMA terminal to play games or music, do not make the volume too loud.

Excessive high volume may damage your hearing. Also, it may prevent you from hearing the ambient sounds and cause an accident.

Earphone Signal Level

The maximum output voltage for the music player function, measured in accordance with EN 50332-2, is

24.0 mV.

If you have a weak heart, take extra precautions when setting functions such as the vibrator and ring tone volume for incoming calls.

May have harmful effects on your heart.

Contents/Precautions

If you are using electronic

Caution

medical equipment, contact the respective manufacturer or vendor to check whether the operation of the equipment is affected by signals.

May interfere with the operation of electronic medical equipment, etc.

Turn the FOMA terminal off near high-precision electronic devices or devices that use weak electronic signals.

May interfere with the operation of electronic devices.

Take particular care with the following devices

Hearing aids, implanted cardiac pacemakers, implanted cardioverter-defibrillators or other electronic medical equipment. Fire alarms, automatic doors, and other equipment controlled by electronic signals. If you use an implanted cardiac pacemaker, implanted cardioverter-defibrillator or other electronic medical equipment, contact the respective manufacturer or vendor to check whether the operation of the equipment is affected by signals.

In case that the display part or camera lens is damaged, make sure to pay attention to a broken glass and the exposed inside of the FOMA terminal.

The surface of the display part is covered by a protective film while the surface of camera lens is covered by a plastic panel so as to minimize the possibility of glass scattering. However, touching the broken or exposed parts may cause injury.

Do not swing the FOMA terminal by its strap etc.

May hit you or others around you, resulting in bodily injury.

Do not use the damaged FOMA terminal.

May cause fires, burns, bodily injury or electric shock.

If the display is broken and the liquid crystal then leaks, do not get the liquid on your skin (face, hands, etc.).

May result in loss of eyesight and harm to your skin. If the liquid comes into contact with your eyes or mouth, immediately rinse your eyes or mouth with clean water and see a doctor. If the liquid comes into contact with your skin or clothes, immediately wipe it off with alcohol, and wash with water and soap.

The surface of the display part is covered by a protective film for ensuring the security against damages caused by dropping, giving strong impacts on the equipment, etc. Do not remove the film forcibly or damage it.

Using the equipment with the film removed may damage the display and cause bodily injury.

Contents/Precautions

If you use the FOMA terminal in

Danger

an automobile, contact the automobile manufacturer or vendor to check whether the operation of the electronic equipment is affected by signals.

May interfere with the operation of electronic equipment in some vehicle models. In such cases, stop using the FOMA terminal.

Do not touch terminals with metallic objects such as wires. In addition, do not carry or store the battery pack with metallic necklaces, etc.

The battery pack may catch fire, explode, overheat or leak.

Use of the FOMA terminal may cause skin irritations such as itchiness, rashes or eczema in some people. If this occurs, immediately stop using the FOMA terminal and seek medical treatment.

For details on materials of each part n“Material list” on P. 15

Look at the display in a well-lit place, keeping a certain distance from the screen.

Otherwise, eyesight may be decreased.

Handling battery pack

Check the type of battery using the information printed on the battery pack label.

Label Battery type

Li-ion00 Lithium-ion

Check that the battery pack is facing the correct direction before you attach it to the FOMA terminal. If you are having difficulty fitting the battery pack to the FOMA terminal, do not use excessive pressure to force the battery into place.

The battery pack may catch fire, explode, overheat or leak.

Do not throw the battery pack into a fire.

The battery pack may catch fire, explode, overheat or leak.

Do not puncture, hit with a hammer or step on the battery pack.

The battery pack may catch fire, explode, overheat or leak.

If the battery fluid, etc. comes into contact with your eyes, do not rub your eyes but immediately rinse your eyes with clean water. Then seek prompt medical treatment.

May result in loss of eyesight.

Contents/Precautions

If any trouble such as a

Warning

Caution

Warning

deformation or scratches caused by a drop is found, never use it.

The battery pack may catch fire, explode, overheat or leak.

If the battery pack leaks or emits an unusual odor, immediately stop use and move it away from any flame or fire.

The battery fluid is flammable and could ignite, causing a fire or explosion.

Prevent your pet from biting the battery pack.

The battery pack may catch fire, explode, overheat or leak.

Do not dispose of used battery packs in ordinary garbage.

May catch fire or cause damage to the environment. Place tape over the terminals to insulate unnecessary battery packs, and take them to a docomo Shop, retailer or institution that handles used batteries in your area.

Do not use or charge a wet battery pack.

If the battery fluid, etc. leaks, do not get the liquid on your skin (face, hands, etc.).

May result in loss of eyesight and harm to your skin. If the liquid comes into contact with your eyes, mouth, skin or clothes, immediately rinse them with clean water. If the liquid, etc. comes into contact with your eyes or mouth, see a doctor immediately after rinsing your eyes or mouth.

Handling adapters (including charger micro USB adapter) and wireless charger

Do not use if the cord of the adapter (including charger microUSB adapter) or of the wireless charger is damaged.

May cause fires, burns or electric shock.

Never use the AC adapter or the wireless charger in humid locations such as a bathroom.

May cause fires, burns or electric shock.

The DC adapter should only be used in negative grounded vehicles. Never use it in positive grounded vehicles.

May cause fires, burns or electric shock.

The battery pack may catch fire, explode, overheat or leak.

Contents/Precautions

Do not touch adapters (including charger micro USB adapter) or the wireless charger if you hear thunder.

May cause electric shock.

Do not connect the voltage converter for overseas travel (Travel converter) to the wireless charger.

May cause overheat or electric shock or catch fire.

Take care not to short-circuit the charging terminal when connected to an outlet or cigarette lighter socket. Also, take care not to allow any part of your body (hands, fingers, etc.) to come into contact with the charging terminal.

May cause fires, burns or electric shock.

Do not place heavy objects on the cord of the adapter (including charger microUSB adapter) or of the wireless charger.

May cause fires, burns or electric shock.

When plugging/unplugging the AC adapter or power plug into/ from the outlet, do not allow metallic straps or other metallic objects to come into contact with the terminal.

May cause fires, burns or electric shock.

Do not handle the cord of the adapters (including charger microUSB adapter), the wireless charger or the outlet with wet hands.

May cause fires, burns or electric shock.

Do not charge any parts wet with water with the wireless charger.

May cause fires, burns, bodily injury or electric shock.

Always use the specified power supply and voltage. When using overseas, use the AC adapter that is available overseas.

Using the incorrect voltage may cause fire, burns or electric shock. AC adapter: 100V AC DC adapter: 12/24V DC (for negative grounded vehicles only) AC adapter available overseas: 100 to 240V AC (Connect only with household AC outlet)

Do not place foreign objects between the wireless charger and the FOMA terminal.

May cause overheat or burns or catch fire.

Do not paste stickers such as aluminium or metallic objects on the wireless charger.

May cause overheat or burns or catch fire.

If the fuse in the DC adapter blows, always replace it with a fuse of the specified type.

May cause fires, burns or electric shock. Refer to the respective manuals for information on the correct fuse specifications.

Contents/Precautions

Wipe off any dust on the power

Caution

plug.

May cause fires, burns or electric shock.

Fully plug the AC adapter or power plug into the outlet.

May cause fires, burns or electric shock.

Always grasp the adapters when unplugging the power plug from the outlet or cigarette lighter socket. Do not forcibly pull by the cord of the adapter (including charger micro USB adapter) or of the wireless charger.

May cause fires, burns or electric shock.

If you have an implanted cardiac pacemaker or an implanted cardioverter-defibrillator, consult a doctor about the use of the wireless charger.

Electromagnetic signals may have harmful effects on the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Always unplug the power plug from the outlet or cigarette lighter socket before cleaning the equipment.

May cause fires, burns or electric shock.

Handling miniUIM

Be careful with the cutting surface when detaching the miniUIM.

May cause bodily injury.

Handling near electronic medical equipment

The precautions detailed here conform to the guidelines drawn up by the Electromagnetic Compatibility Conference Japan, regarding the protection of electronic medical equipment from signals emitted by mobile phones.

Unplug the power cord from the outlet or cigarette lighter socket when not using for a long time.

May cause fires, burns or electric shock.

Should water or other liquids enter the equipment, remove the power plug from the outlet or cigarette lighter socket immediately.

May cause fires, burns or electric shock.

Contents/Precautions

Observe the following in

Warning

hospitals or other medical facilities.

Do not take your FOMA terminal into operating rooms, ICUs (Intensive Care Units) or CCUs (Coronary Care Units). Turn off your FOMA terminal inside hospital wards. Turn off your FOMA terminal even when you are in an area outside hospital wards, such as a hospital lobby, since electronic medical equipment may be in use nearby. Where a medical facility has specific instructions prohibiting the carrying and use of mobile phones, observe those instructions strictly.

Patients receiving medical treatment away from a hospital or medical facility (e.g. home treatment) who are using electronic medical equipment other than implanted cardiac pacemakers or implanted cardioverter-defibrillators should consult the respective manufacturers for information regarding the effects of signals on the equipment.

Electromagnetic signals may have harmful effects on the operation of electronic medical equipment.

Material list

Turn off your FOMA terminal in crowded places such as rush-hour trains in case somebody nearby is using an implanted cardiac pacemaker or implanted cardioverter-defibrillator.

Electromagnetic signals may have harmful effects on the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

If you have an implanted cardiac pacemaker or an implanted cardioverter-defibrillator, always carry or use your FOMA terminal at least 22 cm away from your implant.

Electromagnetic signals may have harmful effects on the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Part

Display side

Surrounding section of display side

Surrounding section of earpiece

Sides

Back cover

Gasket of back cover Silicone rubber

Operation key

Material/Surface

treatment

Reinforced glass/ Shatterproof sheet of surface

PA resin/UV coating

PMMA resin/Hard coating for surface

PA resin/UV coating for surface, Discontinuous deposition

PC resin/Surface coating

PC resin/UV coating for surface

Contents/Precautions

Part

Side key

Earphone/Microphone terminal

External connector terminal

External connector terminal cover

Camera/infrared port panel

Mobile light ABS resin Inside back cover PA resin Speaker section PE Surrounding section of

speaker section Sheet PET resin miniUIM slot miniUIM lever microSD Card slot SUS Battery terminal

connector

Battery terminal

Battery storage side PET/Glass epoxy board

Screw

Battery pack PC resin/Spark erosion

Battery pack terminal section

Material/Surface

treatment

PC resin/UV coating for surface

Copper alloy/Gold plating

SUS/Ni plating

PC resin/UV coating for surface

PC resin/Hard coating for surface

PE foam

SUS Nylon 46

LCP

Free-cutting brass/Ni base, Gold plating

Steel/Ni plating, Trivalent chromate

Copper alloy/Full surface Ni with plating base, Gold plating

Handling precautions

General notes

SH-13C is waterproof/dust-proof, however, do not allow water to seep or dust to get in the FOMA terminal and do not allow accessories or optional parts to get wet or do not allow dust to adhere.

The battery pack, adapter (including charger micro USB adapter), wireless charger and miniUIM are not waterproof/dust-proof. Do not use in humid or steamy areas such as bathrooms and avoid exposing to rain and other forms of moisture. If the FOMA terminal is carried close to skin, perspiration may cause internal components to corrode and result in malfunction. Note that if problem is found to be due to moisture, handset and parts are not covered by warranty and in some cases may be irreparable. Even where repairs are possible, repair charges will be incurred, since damage is not covered by warranty.

Clean only with a soft and dry cloth (such as the type used for eyeglasses).

Forceful rubbing of LCD with a dry cloth may scratch LCD surface.

Note also that LCD coating may stain if moisture or soiling is left on the surface for a long period.

Never use chemicals such as alcohol, thinners, benzene or detergents, as these agents may erase the printing on the handset or cause discoloration.

Occasionally clean terminals with a dry cotton swab, etc.

Unclean terminals may result in poor connections and loss of power. Keep terminal clean with a dry cotton swab, etc. Take care of the terminal while cleaning it.

Contents/Precautions

Do not place the handset near an air conditioning vent.

Condensation formed due to rapid changes in temperature may cause internal corrosion and lead to malfunction.

Do not apply excessive force to the FOMA terminal and battery pack when using them.

Carrying the handset in a tightly packed bag or sitting on the handset in your pocket may cause a damage to display, other internal components or battery pack or result in malfunction. Keeping an external connector device plugged into the external connector terminal or earphone/ microphone terminal may cause a damage to the connector or result in malfunction.

Do not rub or scratch the display with metal, etc.

May scratch the handset and cause malfunction or damage.

Read the respective manuals or user’s guides supplied with the battery pack and adapters (including charger micro USB adapter) carefully.

Notes about the FOMA terminal

Do not forcefully press a surface of the touch panel or operate with a pointed object such as a fingernail, ballpoint pen, pin, etc.

May damage the touch panel.

Avoid using the handset in extremely high or low temperatures.

Use the FOMA terminal within the range of a temperature between 5°C and 40°C (for temperatures of 36°C or higher, such as in a room with a bath, limit usage to a short period of time) and a humidity between 45% and 85%.

Using the handset close to landline phones, TVs or radios may have harmful effects on the operation of such equipment. Move as far away as possible from such items before use.

Keep a separate memo and note information stored in the FOMA terminal.

DOCOMO shall not be liable for any loss of content.

Do not drop or otherwise subject the FOMA terminal to severe impact.

May damage the handset and cause malfunction.

When connecting an external connector device to the external connector terminal or earphone/microphone terminal, do not put it in obliquely or do not pull it while it is plugged in.

May damage the handset and cause malfunction.

The FOMA terminal becomes warm during using or charging but this is not a malfunction.

Do not leave the camera in direct sunlight.

May cause discoloration or burn-in.

Use the FOMA terminal with the external connector terminal cover closed.

Dust, water and others enter inside and cause a malfunction.

Contents/Precautions

Do not use the FOMA terminal without the back cover.

May detach the battery pack or cause malfunction or damage.

While using a microSD Card, do not remove the card or turn off the FOMA terminal.

May cause data loss or malfunction.

Never place a magnetic card near the FOMA terminal.

The stored magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

Never place magnetized items near the FOMA terminal.

Putting highly magnetized items closer may cause an error.

Do not decorate the FOMA terminal with stickers etc.

Charging with the wireless charger may become unavailable.

Notes about battery pack

Battery pack is a consumable product.

Though usage time varies with use, change battery if battery level is extremely low even after fully charged. Purchase a specified new battery pack.

Charge battery in areas where ambient temperature is between 5°C and 35°C.

The usage time for a battery pack depends on the usage and deterioration of battery pack.

Depending on usage, the battery pack may swell as it approaches the end of its service life, but this will not cause problems.

Note the following when the battery pack is stored.



The storage with the battery pack fully charged (immediately after charging is completed)



The storage with no battery level (cannot turn the

main body on) May lower the performance or shorten the life of the battery pack. Approximately 40% is recommended as the battery level for storage.

Notes about adapters (including charger micro USB adapter) and wireless charger

Charge battery in areas where ambient temperature is between 5°C and 35°C.

Do not charge battery pack in the following locations.



Areas with high humidity or dust or in areas

exposed to strong vibrations



Close to landline phones, TVs, radios, etc.

Adapters (including charger micro USB adapter) or the wireless charger may become warm during charging but this is not a malfunction.

Do not use DC adapter to charge battery when the car engine is not running.

May cause car battery to run down.

Contents/Precautions

When using an outlet with a feature to prevent the plug from being removed accidentally, follow instructions in the outlet user’s guide.

Do not subject to strong force or impacts. Also, do not disfigure the charger terminals.

May cause a malfunction.

Do not use the wireless charger with a blanket etc. covering it.

The wireless charger becomes warm during using but this is not a malfunction.

Connect only the specified devices and exclusive AC adapter to the wireless charger.

Do not charge with metallic straps or other metallic objects inserted between the FOMA terminal and the wireless charger.

Do not place the FOMA terminal on the wireless charger with the adapters (including charger micro USB adapter) or microUSB cable for PC connected to the FOMA terminal.

Never place a magnetic card etc. near the wireless charger.

The stored magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

Never place magnetized items near the FOMA terminal.

Putting highly magnetized items closer may cause an error.

Notes about miniUIM

Do not apply unnecessary force when inserting/removing the miniUIM.

Customer is responsible for malfunctions arising from inserting miniUIM into a different IC card reader/writer.

Always keep IC area clean. Clean only with a soft and dry cloth (such

as the type used for eyeglasses). Keep a separate memo and note

information stored in the miniUIM.

DOCOMO shall not be liable for any loss of content.

To protect the environment, please take any unnecessary miniUIMs to a docomo Shop or retailer.

Do not damage, touch haphazardly or short-circuit the IC.

May cause data loss or malfunction.

Do not drop or otherwise subject the miniUIM to severe impact.

May cause a malfunction.

Never bend the miniUIM or place heavy objects on it.

May cause a malfunction.

Do not insert the miniUIM to the FOMA terminal with a label or sticker attached on the card.

May cause a malfunction.

Notes on using Bluetooth function

The FOMA terminal supports the security function that meets the Bluetooth specification for the security during communication using Bluetooth function. However, the security may not be sufficient depending on the configuration. Take care of the security while making communication using Bluetooth function.

Contents/Precautions

Even if any leak of data or information

ӱġ Ӳġ

ӳġ

Ӵġ

occurs while making communication using Bluetooth function, DOCOMO shall not be liable for any loss of content.

With the FOMA terminal, use headset, hands-free, audio, keyboard, object push, serial port and phone book access. Also, the audio/video remote-control may be available depending on the audio (only with compatible Bluetooth devices).

Radio frequencies The radio frequencies the Bluetooth

function of the FOMA terminal uses are as follows.

2.4: This radio equipment uses the 2.4 GHz band.

FH: The modulation system is the FH-SS system.

1: The estimated coverage distance is 10 m or less.

2400 MHz and 2483.5 MHz are used and the frequencies for mobile object identifiers shall not be avoided.

: All radio frequencies between

Cautions on using Bluetooth devices Bluetooth operates at radio frequencies assigned to the in-house radio stations for a mobile object identifier that have to be licensed and is used in production lines of a factory, specific unlicensed low power radio stations, and amateur radio stations (hereafter, referred to “another radio station”) in addition to industrial, scientific, medical devices or home electric appliances such as microwave ovens.

1. Before using this product, make sure that “another radio station” is not operating nearby.

2. If radio interference between this product and “another radio station” occurs, avoid interference by moving immediately to another place or “turning off the power”.

3. Contact the number listed in “General Inquiries” on the back of this manual for further details.

Notes about wireless LAN (WLAN)

Wireless LAN (WLAN) uses radio waves to communicate information. Therefore, it has an advantage of freely connecting to the LAN within the service area. On the other hand, if security setting is not set, it is possible for a malicious third party to intercept the communication contents or hack. It is recommended to set security setting at your own risk and judgement.

Contents/Precautions

Wireless LAN

Do not use wireless LAN near magnetic devices such as electric appliances or AV/OA devices or in radio waves.

Magnetism or radio waves may increase noises or disable communications (especially when using a microwave oven).

When used near TV, radio, etc., reception interference may occur or channels on the TV screen may be disturbed.

If there are multiple wireless LAN access points nearby and the same channel is used, search may not work correctly.

Radio frequencies The radio frequencies the WLAN-installed

devices use are indicated on the battery storage section of the main body of the terminal. The following are the descriptions:

2.4: This radio equipment uses the 2400 MHz band.

DS: The modulation system is the DS-SS system.

4: The estimated coverage distance is 40 m or less.

OF: The modulation system is the OFDM system.

between 2400 MHz and 2483.5 MHz are used and the frequencies for mobile object identifiers shall not be avoided.

: All radio frequencies

Available channels for SH-13C’s wireless LAN are between 1 to 13. Note that other channel access points cannot be connected. Available channels vary depending on the country. For use in an aircraft, contact the airline beforehand. There are restrictions on the use of wireless LAN in some countries or regions such as France. If you intend to use wireless LAN overseas, check the local laws and regulations beforehand.

Cautions on using 2.4 GHz devices

WLAN-installed devices operate at radio frequencies assigned to the in-house radio stations for a mobile object identifier (radio stations requiring a license) used in production lines of a factory, specific unlicensed low power radio stations (radio stations requiring no license), and amateur radio stations (radio stations requiring a license) in addition to industrial, scientific, medical devices or home electric appliances such as microwave ovens.

1. Before using this device, make sure that the in-house radio stations for a mobile object identifier, specific unlicensed low power radio stations and amateur radio stations are not operating nearby.

2. If the device causes harmful radio interference to the in-house radio stations for a mobile object identifier, immediately change the radio frequency or stop use, and contact the number listed in “General Inquiries” on the back of this manual for crosstalk avoidance, etc. (e.g. partition setup).

Contents/Precautions

3. If the device causes radio interference to specific unlicensed low power radio stations for a mobile object identifier or amateur radio stations, contact the number listed in “General Inquiries” on the back of this manual for further details.

FeliCa reader/writer

The FeliCa reader/writer function in the FOMA terminal uses weak electric waves in the handling of which does not require a license of radio station.

The frequency in use is the 13.56 MHz band. When another reader/writer is being used nearby, keep enough distance from it. Make sure that there is no radio station using the same frequency band in the nearby area.

Be careful when using the FOMA terminal while driving a motor vehicle.

Using a mobile phone in hand while driving is regarded as a punishable act. However, the punishment has no application in some cases such as when rescuing sick and injured people or maintaining public safety.

Use the FeliCa reader/writer function only in Japan.

The FeliCa reader/writer function in the FOMA terminal conforms to the domestic radio wave standards. Using the function overseas may result in punishment.

Be careful not to connect the FOMA terminal to PC using the microUSB cable for PC (sample) in areas where the use of mobile phones is prohibited.

Power may turn on automatically.

Waterproof/Dust-proof

Caution

Never use the FOMA terminal that is modified. Using a modified device violates the Radio Law.

The FOMA terminal has acquired the certification of conformity with technical regulations for the specified radio station based on the Radio Law, and the “Technical Conformity Mark ” is printed on the model nameplate of the FOMA terminal as a proof. If the screws of FOMA terminal are removed and a modification is given to the inside, the certification of conformity with technical regulations will become invalid. Never use the FOMA terminal without the valid certification. Doing so violates the Radio Law.

Contents/Precautions

function

SH-13C is waterproof to IPX5*1 and IPX7*2

standards, and dust-proof to IP5X the external connector terminal cover is securely closed as well as the back cover is attached.

*1 IPX5 means that phone keeps functioning after

being subjected to a jet flow (approximately

12.5 liters/min) discharged from a nozzle (inner diameter: 6.3 mm), from all directions (approximately 3 m from the handset) for 3 minutes or more.

*2 IPX7 means that SH-13C phone keeps

functioning after it is slowly submerged to depth of 1 m in static tap water at room temperature, left there for approximately 30 minutes and then taken out.

standards if

*3 IP5X means the level of protection. Phone

keeps functioning in safety after it is left in the device containing dust (diameter: 75 Ђm or smaller) for 8 hours, agitated and then taken out.

What you can do with waterproof/dust-proof function of SH-13C

You can call without using an umbrella in the rain

(for rainfall of approximately 20 mm per hour).

You can rinse off dirt from the FOMA terminal.

Wash the FOMA terminal with low-pressure water flow (6 liters/min or lower and tap water at room temperature (between 5°C and 35°C)), holding it approximately 10 cm below faucet or shower head. Wash by using only your hands, not a brush or sponge, with the back cover attached, and the external connector terminal cover held in position. Drain the handset before use (nP. 26).

You can use the FOMA terminal at a poolside.

Do not throw water in a swimming pool on the FOMA terminal, soak the FOMA terminal in the water of a swimming pool, etc.

You can use the FOMA terminal in a bathroom.

Do not soak the FOMA terminal in the bathtub.

Make sure that the external connector terminal

cover and the back cover are completely closed without floating.

To maintain waterproof/dust-proof performance,

the FOMA terminal has the external connector terminal cover and the back cover that allow you to close securely. May cause injuries to your nails or fingers if you try to open them forcibly.

If dusts get into the earphone/microphone

terminal, clear them before use.

Opening external connector terminal cover

Hook a finger on the slot to open.

Slot

Closing external connector terminal cover

Push and close securely in the direction of the arrow so that gaps are not left between the FOMA terminal and the external connector terminal cover.

Things to keep in mind

To maintain waterproof/dust-proof performance, check the followings.

Securely close the external connector terminal

cover and the back cover. Be careful not to apply excessive force on the rubber gasket when opening and closing them.

Contents/Precautions

Removing back cover

Concave portion

Securely hold the surrounding

section of camera, put fingers on the center of the back cover and hook the tip of a finger on the concave portion of the back cover to remove

: Apply force while turning around your finger

put on the concave portion towards the direction of the arrow.

Securely close the back cover. If not closed

securely, the back cover may come off and the battery pack may fall out due to vibration. May damage the waterproof/dust-proof performance and allow water to seep or dust to get in.

The back cover may be damaged if it is inserted

or removed forcibly. Be careful not to apply excessive force on it.

Attaching back cover

Confirm the direction of the back

cover, adjust it to the direction of the FOMA terminal and press the surrounding section (shaded section) of the back cover securely to attach

: Make sure there is no space between the

back cover and the FOMA terminal.

Contents/Precautions

To maintain waterproof/dust-proof

performance, replacement of parts is required every 2 years regardless of whether the FOMA terminal appears normal or abnormal. DOCOMO replaces the parts as a chargeable service. Bring the FOMA terminal to a repair center that DOCOMO specifies.

Precautions

When your hands or the FOMA terminal are wet,

do not attach/remove the back cover or open/ close the external connector terminal cover.

Close the external connector terminal cover and

the back cover securely. Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between contact surfaces may allow water to seep or dust to get in.

If the FOMA terminal gets wet with water or other

liquids with the external connector terminal cover or the back cover opened, the liquid may get inside the terminal causing electric shocks or malfunction. Stop using the FOMA terminal, turn off the power, remove the battery pack and contact a repair center that DOCOMO specifies.

The rubber gasket of the external connector

terminal cover and the back cover play an important role in maintaining waterproof/ dust-proof performance. Do not remove or scratch them. Also, prevent dust from adhering to them. If the rubber gasket of the external connector terminal cover or the back cover is damaged or deformed, replace it at a repair center that DOCOMO specifies.

Do not insert sharp objects through external

connector terminal cover and back cover gaps. It causes damage to the rubber gasket and allow water to seep or dust to get in.

If the back cover is damaged, replace it. Water

may seep inside from a damaged section causing troubles such as electric shocks or corrosion of the battery.

Do not use the FOMA terminal underwater

(including key operations). May cause malfunction.

Do not apply water flow stronger than allowed

(nP. 22) (over 6 liters/min). May cause malfunction though SH-13C provides waterproof performance of IPX5.

Do not let the FOMA terminal get wet with liquids

other than water at room temperature (between 5°C and 35°C).

Do not wash the FOMA terminal in a washing

machine, etc.

To prevent condensation, do not bring the FOMA

terminal from a cold place to a bathroom, etc. without letting the FOMA terminal cool to room temperature.

Do not expose the FOMA terminal to extreme

humidity for long periods. Avoid prolonged use in bathrooms.

Never soak the FOMA terminal in hot spring

water or water containing soap, detergent or bath powder.

Do not soak the FOMA terminal in hot water, use

it in a sauna or apply hot air (from a hair dryer, etc.) to it.

Do not soak the FOMA terminal in seawater. Do not put the FOMA terminal directly on sand/

dirt.

Do not leave the FOMA terminal wet. In cold

places, water may freeze and cause malfunction.

The FOMA terminal does not float on water. Do not let the FOMA terminal fall. It may become

scratched and cause the waterproof/dust-proof performance to degrade.

Do not leave water on the mouthpiece, earpiece,

speaker or earphone/microphone terminal. Such water may interfere with talking.

Do not insert an earphone to the FOMA terminal

while the FOMA terminal is wet. May cause malfunction.

Contents/Precautions

Accessories and optional parts are not

Soap/Detergent/ Bath powder

Seawater Swimming pool

Hot spring Sand/Dirt

waterproof/dust-proof. When the FOMA terminal is placed on the accompanying Wireless Charger SH01, do not use it in rooms where water is regularly in use such as bathroom, shower room, kitchen, lavatory, etc. even if the exclusive AC adapter is not connected to it.

Draining water when the FOMA terminal gets wet

When the FOMA terminal is wet, water may flow out after wiping it off. Drain the water following the steps below.

Wipe the FOMA terminal surface

with dry and clean cloth, etc.

: If a strap is attached, dry the strap well.

DOCOMO does not guarantee actual

operations under all states. Malfunctions deemed to be caused by inappropriate operation by the customer are not covered by the warranty.

Contents/Precautions

Shake the FOMA terminal

approximately 20 times, securely holding it, until there is no more water splattering

To drain water off the speaker, shake the FOMA terminal with the speaker turned up

Softly press dry and clean cloth,

etc. against the FOMA terminal to wipe off water remaining in the mouthpiece, earpiece, speaker, keys or earphone/microphone terminal

: Pat the opening with cloth to remove water

because there may be any water remaining in the grooves of each part.

Charging

Accessories and optional parts are not waterproof/dust-proof. Check the followings before and after charging.

Make sure that the FOMA terminal is not wet. If

the FOMA terminal is wet or after the FOMA terminal is wet, adequately drain it and wipe off water with dry and clean cloth, etc. before placing on the Wireless Charger SH01 or opening the external connector terminal cover.

When the external connector terminal cover is

opened for charging, close the cover securely after charging. It is recommended that the Wireless Charger SH01 be used for charging to prevent water from seeping inside and dust from getting in from the external connector terminal cover.

Never try to charge the battery pack when the

FOMA terminal is wet.

Do not touch accessories or optional parts with

your wet hands. May cause electric shock.

Do not use accessories or optional parts in a

place subject to water. Do not use accessories or optional parts in rooms which water is regularly in use such as bathroom, shower room, kitchen, lavatory, etc. May cause fire or electric shock.

Wipe off water drained from the

FOMA terminal with dry and clean cloth, etc.

: Water, if any, remaining in the main body

may ooze up after wiping off.

Contents/Precautions

Before Using the Handset

Part names and functions

Before Using the Handset

1 Incoming/Charging lamp

Lamp to be illuminated/flashed differs

according to the function being used and situation.

2 External connector terminal 3 Display/Touch panel

The display for the FOMA terminal is

manufactured using high-precision technology, but it may occasionally contain dots that fail to light or that remain permanently lit. This is not a malfunction.

4 Mouthpiece/Microphone 5 Earpiece 6 Proximity sensor/Brightness sensor

Proximity sensor detects the distance to face

and prevents a false operation of touch panel during a call.

Brightness sensor detects brightness of the

surrounding area and adjusts the brightness of backlight. Do not cover the sensor area with your hand, paste a sticker on the sensor area, etc. The sensor may not work properly.

7 z: Menu key

Displays available functions (menus) in a

screen.

8 |: Home key

Displays the main page of the home screen.

9 {: Back key

Returns to the previous screen.

a Speaker

Ring tone, music, etc. can be heard from

here.

Voice of the other party can be heard from

here during a hands-free call.

b a mark

IC card is contained (It cannot be removed).

c H: Power key

Use to set/disable the sleep mode, turn the

power on/off, etc.

d x/y: Volume UP/DOWN key

Adjusts the volume in each function.

e }: Search key

Displays the quick search box.

f FOMA antenna g Earphone/Microphone terminal

Refer to http://k-tai.sharp.co.jp/peripherals/

earphone_support_sh-13c.html (in Japanese only) for details on the corresponding earphone/microphone.

h Camera i Mobile light j microSD Card slot k Strap hole

When attaching a strap, remove the back

cover, put the strap through the strap hole, put it on the hook inside and attach the back cover.

l GPS antenna m Back cover n Infrared port

* The antenna is built in the main body. Covering

the antenna area with your hand may influence the quality.

Menu key, Home key, Back key

When you press keys, press the parts marked by red rectangles in the following illustration. If you press edges of the keys, you may not be able to operate.

Before Using the Handset

miniUIM

Notch

IC (gold)

Notch

A miniUIM is an IC card that records personal information, such as phone numbers.

You cannot make a call and use functions such

as packet communication etc. on the FOMA terminal without inserting a miniUIM.

You cannot use miniUIM on the terminal that

does not support it, and part of sites, data, etc. in use may become unavailable when you replace the miniUIM with it.

In Japan, you cannot call to the emergency

number (110, 119 or 118) without inserting a miniUIM.

The FOMA terminal does not support the UIM.

Change the UIM at a docomo Shop.

Before inserting or removing the miniUIM, turn

off the power, position the back facing upwards and remove the battery pack. Hold the FOMA terminal securely with your both hands.

Attach the back cover (nP. 24)

Removing miniUIM

Pull the lever until miniUIM comes

out (1) and pull miniUIM straight out (2) while pressing it from above

: Do not allow the miniUIM to fall when

removing it.

Inserting miniUIM

Remove the back cover (nP. 24)

Set miniUIM into miniUIM slot with

the IC (gold) side turned down (1)

: Insert miniUIM securely (2).

Before Using the Handset

Lever

Note that the lever may be damaged if it is

pulled forcibly, an excessive force is applied on it, etc.

Note that inserting, removing the miniUIM

forcibly, etc. may damage the miniUIM.

Refer to the miniUIM user’s guide for more

information on the miniUIM.

Do not misplace the miniUIM once it is taken

out.

microSD Card

You can save data in the FOMA terminal to microSD Card, import data in microSD Card to the FOMA terminal, etc.

The SH-13C is compatible with microSD Card of up to 2 GB and microSDHC Card of up to 32 GB (as of July 2011). Refer to http://k-tai.sharp.co .jp/peripherals/microsd_support_sh-13c.html (in Japanese only) for the latest information such as the manufacturer, available capacity, etc. of the microSD Card. In addition, some microSD Cards that are not provided in the sites may not operate. Note that the provided information is the information checked for operation. DOCOMO shall not be liable for all operations.

The size of a file that can be used is up to 2 GB. Do not turn off the FOMA terminal immediately

after inserting the microSD Card in the terminal (while writing information needed for FOMA terminal operation) or while editing data on the microSD Card. Data may be damaged or operation may not work properly.

Format unformatted microSD Cards on the

FOMA terminal before use (nP. 82). microSD Cards formatted by PCs or other devices may not be used properly by the FOMA terminal.

Data saved on the microSD Cards from other

devices may not be displayed or played on the FOMA terminal. Some data saved to the microSD Card from the FOMA terminal may not be displayed or played on other devices.

Back up the data saved in a microSD Card and

store in another place. DOCOMO shall not be liable for any loss or change of the saved data.

Before inserting or removing (including after

unmounting) the microSD Card, turn off the power and position the back facing upwards. Hold the FOMA terminal securely with your both hands. Data may be damaged or operation may not work properly.

Inserting microSD Card

Insert the microSD Card slowly with

the metal terminal side turned down

: Do not force the microSD Card in at an angle

or with the wrong side up. The microSD Card slot may be damaged.

: Insert the microSD Card slowly with your

fingers until a click is heard.

Before Using the Handset

Attaching battery pack

With recycle mark side up

Connector terminal

Attach the battery pack

: With the recycle mark side turned up, place

the connector terminal of the FOMA terminal to that of the battery pack and attach the battery pack.

Removing microSD Card

Gently push the microSD Card

towards inside (1)

: Push the microSD Card until it clicks.

Otherwise it will eject towards you. Pulling it forcibly may damage the FOMA terminal or the microSD Card.

Remove the microSD Card (2)

: Remove the microSD Card by slowly pulling

it straight out.

Removing battery pack

Remove the battery pack

: The battery pack has a tab that makes it

easy to remove. Hook a finger on the tab to prevent excessive force on it and remove the battery pack upward.

Ta b

Battery pack

Use the Battery Pack SH29 exclusive to the

For attaching or removing the battery pack, turn

Before Using the Handset

FOMA terminal.

off the power, position the back facing upwards, and hold the FOMA terminal securely with your both hands.

Using unnecessary force when attaching or

removing the battery pack may damage the connector terminal for the battery pack (charger terminal) on the FOMA terminal.

Charging

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery before use.

It is recommended that the accompanying

Wireless Charger SH01 be used for charging to prevent water from seeping or dust from getting in caused by forgetting to close the external connector terminal cover (nP. 35).

Cautions while charging

Do not charge for a long time with the power left

on. If the FOMA terminal is left on after charging is complete, the battery pack charge decreases. In that case, the AC or DC adapter (sold separately) or the wireless charger charges the battery again. However, depending on the time when the FOMA terminal is disconnected from the AC or DC adapter or the wireless charger, the battery charge level may be low or the battery may only be usable for a short time.

If the FOMA terminal is left for a long time even

after the charging is completed, the battery level may decrease.

When the battery is empty and terminal is

recharging, charging lamp may not illuminate immediately.

If the battery empty alert is displayed and the

power cannot be turned on, charge the battery for a while.

While charging, terminal may not turn on even

when charging lamp is illuminated in red. Charge longer and try turning power on again.

Frequently recharging the battery when its power

is still remaining enough may shorten the life of the battery pack. It is recommended to use the battery to a certain level before recharging.

Estimated charge time and lamp display

The following figures are estimated times for charging an empty battery pack with the FOMA terminal turned off.

FOMA AC Adapter 01/02 Approx. 220 min FOMA DC Adapter 01/02 Approx. 220 min

Charging lamp illuminates in red while charging,

and it turns off when charging is completed.

If the power of the FOMA terminal is off during

the use of the wireless charger, charging lamp flashes red on starting or finishing charging.

Check that the battery pack has been properly

attached when charging lamp flashes red during the use of the AC or DC adapter. The lamp also flashes red when the battery pack has reached the end of its service life.

If the charging information flashes blue (with

approximately 0.25 second intervals) during the use of the wireless charger, remove and place the FOMA terminal on it again properly after confirming that there is no foreign object between the wireless charger and the FOMA terminal, remove and insert the power plug into the outlet again, etc.

The battery pack can also be charged with the

FOMA terminal turned on (While charging, the battery icon appears with [w] superimposed).

Before Using the Handset

When the battery becomes warm, charging may

automatically stop even if the battery has not been fully charged. In that case, the charging information flashes in blue slowly (illuminates for approximately two seconds b turns off for approximately one second). Charging resumes after the temperature lowers to an appropriate temperature.

Estimated time of use when fully charged

Continuous talk time

Continuous stand-by time

For details on time of use nP. 142

FOMA/3G

Approx. 280 min

GSM

Approx. 310 min

FOMA/3G

When mobile: Approx. 420 hr (Network Mode: 3G) When mobile: Approx. 330 hr (Network Mode: 3G/ GSM(Auto)) At rest: Approx. 500 hr (Network Mode: 3G/ GSM(Auto))

GSM

At rest: Approx. 400 hr (Network Mode: 3G/ GSM(Auto))

Battery pack service life

Battery pack is a consumable product. Service

time per charge is gradually reduced every time the battery is charged.

When service time per charge is reduced to

about half of the default time, this means that the battery pack is approaching the end of its service life. In such a case, it is recommended to replace the battery pack as soon as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life, but this will not cause problems.

If games etc. are used while charging for a long

time, the service life of the battery pack may become shorter than estimated.

To prevent damage to the environment, bring

used battery packs to a docomo service counter, a docomo agent or a recycle center.

AC adapter and DC adapter

Refer to user’s guide of FOMA AC Adapter 01/02

(sold separately), FOMA AC Adapter 01 for Global use (sold separately) or FOMA DC Adapter 01/02 (sold separately).

FOMA AC Adapter 01 covers only 100V AC.

FOMA AC Adapter 02/FOMA AC Adapter 01 for Global use covers from 100 to 240V AC.

The shape of the plug for the AC adapter is for

100V AC (for domestic use). To use the AC adapter of 100 to 240V AC overseas, a conversion plug adapter that is compatible with the voltage of your country of stay is required. Do not use a transformer for use overseas to charge the battery.

Before Using the Handset

Charging with wireless charger

Exclusive AC adapter

Charging information

Charging lamp

100V AC outlet

Compatible devices provided by docomo with b

mark can be charged with the wireless charger. Read the instruction manuals of the compatible devices that you are going to use.

Products with b mark conform with wireless

power standard of Wireless Power Consortium (WPC).

Part names are as followings.

Charging assist button

Charging area

Charging information

Insert the connector of the

exclusive AC adapter into the wireless charger (1)

: Insert the connector securely. : Insert only the exclusive AC adapter.

: There may be some cases in which the

charging information slowly flashes (with approximately one second intervals) before illuminating.

Insert the power plug of the

exclusive AC adapter into an outlet (2)

When you place the FOMA terminal

on the wireless charger, charging lamp and charging information illuminate and charging starts

: Place the FOMA terminal slowly with the b

mark side turned down so that b mark of the wireless charger faces the battery pack.

When charging lamp and charging

information turn off, charging is complete

: Remove the FOMA terminal from the the

wireless charger.

Before Using the Handset

Charging battery pack

You can charge the battery pack by placing only the battery pack on the wireless charger. Place the battery pack on the wireless charger

with the b mark side turned down.

Charging information

Place the wireless charger on a stable and

horizontal surface to charge.

Pull the exclusive AC adapter out of the outlet if

it is not used for a long time.

When the power plug is inserted into an outlet

or the FOMA terminal/battery pack is placed on the wireless charger or removed, there may be some cases in which sounds are emitted from the wireless charger. This is not a malfunction.

Multiple FOMA terminals/battery packs cannot

be charged at the same time.

If charging does not start, remove and place the

FOMA terminal/battery pack on the center of the charging area again, and then press the charging assist button.

If the FOMA terminal is equipped with a cover

etc., it may not be charged depending on material, thickness, etc. of the cover etc. Remove the FOMA terminal out of the cover etc. to securely charge it.

When noises interfere on a TV, radio set, etc.

during its use, use the wireless charger after distancing it as far away from a TV, radio set, etc. as possible.

If electronic devices are used near the wireless

charger, the FOMA terminal may not be charged. When you use electronic devices, keep them at least 30 cm away from the wireless charger to use them.

Do not move the wireless charger and the

FOMA terminal/battery pack while charging.

Do not let the vibrator activated while charging

the FOMA terminal. It may move or fall due to vibrations.

If you charge the FOMA terminal with a

commercially available product with b mark, the handset may not receive calls during charging. Charge with the accompanying Wireless Charger SH01.

Charging with AC adapter/DC adapter

[Read the user’s guides of FOMA AC Adapter 01/02 (sold separately) and FOMA DC Adapter 01/02 (sold separately)]

Insert the AC or DC adapter

connector horizontally into the external connector terminal of the FOMA charger micro USB adapter SH01 (1)

: Check the direction (front or rear) of the

connector, keep it parallel with the FOMA charger micro USB adapter SH01 and securely push all the way in until it clicks.

Before Using the Handset

Open the external connector

Connector (with the arrow side down)

microUSB plug (with the character side down)

External connector terminal (with the character side up)

External connector terminal

Charging lamp

100V AC outlet

For AC adapter

Cigarette lighter socket

For DC adapter

terminal cover of the FOMA terminal and insert the microUSB plug of the FOMA charger micro USB adapter SH01 horizontally into the external connector terminal (2)

: Insert the microUSB plug horizontally with

the character side turned down.

When charging lamp turns off,

charging is complete

: When charging is complete, remove the

microUSB plug horizontally from the FOMA terminal (1).

: When removing the connector from the

FOMA charger micro USB adapter SH01, always hold the release buttons on both sides (2) and unplug it horizontally (3).

When inserting the AC adapter

power plug into an outlet or inserting the DC adapter power plug into a car cigarette lighter socket, charging lamp illuminates and charging starts

Release buttons

Do not forcibly insert or remove. May cause

damage to the external connector terminal, the microUSB plug and the connector.

Pull the adapter out of the outlet or cigarette

lighter socket if it will not be used for a long time.

Before Using the Handset

Do not forcibly pull the external connector

terminal cover. May damage the cover.

Do not place objects near the FOMA terminal

when charging. May damage the FOMA terminal.

When using a DC adapter

The DC adapter should only be used in

negative grounded vehicles (12 and 24V DC).

Do not use with the car engine shut off. May

drain the car battery.

The DC adapter fuse (2A) is a consumable. For

replacement, purchase a new fuse at a local automobile supply shop.

Refer to the user’s guide of FOMA DC Adapter

01/02 for details.

Charging with microUSB cable

Turning power OFF

H (for at least 1 second)/[Power

off]/[OK]

Sleep mode

The screen is off and the sleep mode is activated when H is pressed or the FOMA terminal is not in use for a set length of time. Press H in the sleep mode to deactivate the sleep mode.

Touch panel lock

When the power is turned on or the sleep mode is deactivated, the touch panel is locked. Keep touching [J] and slide it up into [K] to unlock.

for PC

When the FOMA terminal is turned on, you can charge the FOMA terminal by connecting the FOMA terminal to a PC with the microUSB cable for PC (sample).

Install the USB driver to the PC in advance. And

also enable USB battery charge (nP. 79). Ʀ Refer to “Manual for USB Driver Installation” in

PDF format in http://k-tai.sharp.co.jp/support/d/ sh-13c/download/usb/index.html (in Japanese only) for details on installing USB driver.

For details on connecting to a PC nP. 108

Turning power ON/OFF

Turning power ON

H (for at least 2 seconds)

Before Using the Handset

Key operation in touch panel unlock screen

To set/disable manner mode: y (for at least

1 second)

To turn off power: H (for at least 2 seconds)

If there is an unchecked missed call etc., an

icon is displayed on the unlock screen. If you touch the icon before unlocking the touch panel, the corresponding screen is displayed.

Basic operation

Operation of touch panel

You can operate by touching the touch panel (display) directly with your finger.

Operations differ depending on the function and

screen in use.

Cautions when using the touch panel

The touch panel is designed to be lightly

touched with your finger. Do not forcefully press with your finger, press with a pointed object (fingernail, ballpoint pen, pin, etc.), etc.

In the following cases, the touch panel may

not work even if you touch it. May cause a malfunction.

 Operation with a gloved finger  Operation with a fingernail  Operation with foreign objects placed on

the operation pad

 Operation on the touch panel on which a

protective sheet or a sticker is put

 Operation while the touch panel is wet  Operation with fingers wet with sweat or

water

Touch for a while

When you touch the screen for a while, a menu may appear depending on the function and screen in use.

Keep your finger on the touch panel

Slide

Slide up/down while a menu is displayed etc. to scroll the screen. When you touch a menu or item by mistake, slide away from the menu or item to cancel the selection.

Keep your finger on the touch panel

and slide it

Touch

Touch a key or an item displayed on the screen to select or set it.

Put your finger on the touch panel

and put it off

Quickly slide

Quickly slide to the left/right in the home screen etc. to switch pages.

Quickly slide your finger and put it

off

Before Using the Handset

Put a distance between two fingers

Set item list

apart/closer

Put a distance between two fingers apart/closer while displaying an image etc. to zoom in/out.

Put two fingers on the touch panel

and slide them with putting a distance between two fingers apart/ closer

Operation while using function

Switching the settings

When a check box is displayed beside the setting item, you can set it enabled/disabled or [ON]/[OFF] by touching it.

Example: Energy saving settings screen,

Alarm setting contents screen

[0]: Enabled, [1]: Disabled

Retrieving menu

When you press z or touch the screen for a while, functions (menus) available in that screen appear.

Example: Notepad screen

TapFlow UI

TapFlow UI is a menu to be displayed by touching [T] when using phonebook, camera and picture. The kinds, position and size of the displayed menu differ depending on the frequency of using menu.

Before Using the Handset

Example: Phonebook list screen

Vertical/Horizontal display

The screen display is switched when you tilt the FOMA terminal. Vertical/Horizontal display is not switched if the

FOMA terminal is turned in the place parallel to the ground.

The screen display may not be switched

depending on the application being used.

The screen display may not be switched properly

when a sound or a vibration is activated.

Vertical/Horizontal display may not appear

properly right after the screen or power is turned on.

You can set the display not to automatically

switch (nP. 79).

Screens may be displayed in the full screen

depending on the application when switching the vertical display to the horizontal display.

Multi Assistant (Multitask)

If you cancel the use of function by pressing | etc., the function does not end and remains activated in background. Display running functions as a list and switch functions to use by using Multi Assistant (Multitask).

| (for at least 1 second)

Select a function to be used

: To terminate a function: [Y] : To terminate all functions: [Quit all]/[Yes]

The functions being activated in background

may end depending on the memory usage or application. Also, the display of running function on the Multi Assistant (Multitask) screen may change depending on the memory usage.

Shooting screenshot

Press Hȼ| to save the screen being displayed to the microSD Card.

Data cannot be saved while using home

network or displaying e-books. In addition, image part cannot be saved while playing video such as YouTube.

Data may not be saved completely or partially

depending on the application.

Searching information in the FOMA terminal and sites

In the home screen, }

: Alternatively, [R]/[Google Search] in the

home screen.

: Quick search box appears.

Enter the keyword

: Search applications and data that start with

the entered character and display a list of them.

Select the search result

: When a search result is an application, the

corresponding application is activated.

Before Using the Handset

Searching sites by voice

୭೰

࡞ࢊ΅ȜδȜΡ

࡞ࢊ

஖఼

In the quick search box, [!]

: Alternatively, } (for at least 1 second) in the

home screen.

: Or, [R]/[Voice Search] in the home screen.

Enter the keyword by voice

Select the keyword

Changing screen display to English

In the home screen, [R]/[

(Settings)/[ (Language & keyboard)/[ (Language)

language)/[English]

] (Select

]

Setting access point

The access point (sp-mode and mopera U) for Internet connection is registered by default. You can add or change it if necessary. At the time of purchase, an access point of sp-mode is set for usual connection.

Checking access point in use

In the home screen, [R]/

[Settings]/[Wireless & networks]/[Mobile networks]/ [Access Point Names]

Setting access point additionally

Never set the MCC to other than 440 and the

MNC to other than 10. They do not appear on the screen.

In the home screen, [R]/

[Settings]/[Wireless &

Initial setting

In the home screen, [R]/

[Settings]/[Default settings] Set the date and time (nP. 84)/

[Next]

Set the location information

(nP. 80)/[Next]

Set each item

 Wi-Fi settings: For details nP. 43  Google account: For details nP. 45  Profile settings: For details nP. 76

[Done]

Before Using the Handset

networks]/[Mobile networks]/ [Access Point Names]/z/ [New APN]

[Name]/enter the name of the

network profile to create/[OK] [APN]/enter the access point

name/[OK]

Enter other items required by

telecommunications carriers/ z/[Save]

ΑζȜΠέ΁ϋ೰ڣ

୭೰

If the settings of MCC and MNC are changed

and they do not appear on the screen, reset the settings or set the access point manually.

Setting mopera U

In the home screen, [R]/

[Settings]/[Wireless &

Resetting access point

Reset an access point to default setting.

In the home screen, [R]/

[Settings]/[Wireless & networks]/[Mobile networks]/ [Access Point Names]/z/ [Reset to default]

When sp-mode is not subscribed or if you failed

to perform automatic setting of access point due to signal status such as outside the service area etc., you are required to set the access point again manually.

sp-mode

sp-mode is an ISP owned by NTT DOCOMO for the Smartphone. In addition to the Internet connection, mail service with the same address you use on i-mode (@docomo.ne.jp) is available. sp-mode is a paid service that requires subscription. For details on sp-mode, refer to DOCOMO website.

mopera U

networks]/[Mobile networks]/ [Access Point Names]/[mopera

)] (mopera

U(Smartphone flat-rate))/[mopera U

mopera U ୭೰ (mopera U settings) is an

access point for mopera U settings. When you use the access point for setting mopera U, packet communication charges are not incurred. Note that you can connect to only the initial setting screen or the change setting screen. For details on mopera U settings, refer to the mopera U website.

To use mopera U(ΑζȜΠέ΁ϋ೰ڣ)

(mopera U(Smartphone flat-rate)), subscription to flat-rate packet communication services is required. For details on mopera U (Smartphone flat-rate), refer to DOCOMO website.

] (mopera U settings)

Wi-Fi settings

If you use Wi-Fi function of the FOMA terminal, you can use mail or internet by connecting to your home, corporate network or access points of public wireless LAN service.

mopera U is an ISP owned by NTT DOCOMO. If you subscribe to mopera U, you can use Internet with easy setting. mopera U is a paid service that requires subscription.

Before Using the Handset

The radio interference with Bluetooth devices

Wireless LANs (IEEE 802.11b/g/n) use the

same frequency band (2.4 GHz) as the Bluetooth device. Therefore, using the wireless LAN device near a Bluetooth device may cause the radio interference, lowering of communication speed, noise or connection fail. In this case, turn off the Bluetooth device or keep the FOMA terminal and the wireless LAN device at least approximately 10 m away from the Bluetooth device.

Packet communication is also available while

Wi-Fi function is enabled. Wi-Fi connection is prioritized while Wi-Fi connection is set, but the connection will be automatically switched to that of 3G/GPRS network once Wi-Fi connection is terminated. Note that packet communication charges will be incurred in such case.

Refer to the manual of your wireless LAN base

unit when using the access point at home.

Operate access point registration near the

access point.

Enable Wi-Fi function in advance (nP. 76).

In the home screen, [R]/

[Settings]/[Wireless & networks]/[Wi-Fi settings]

Select an item

 Wi-Fi: Enable Wi-Fi function.  Network notification: You get notified by the

notification icon when open Wi-Fi network is detected.

 Wi-Fi sleep policy: Set the timing to switch

Wi-Fi sleep.

 Easy Wi-Fi registration: Register AOSS/

WPS-compatible access point with each method.

 Auto login settings: You can set the handset

to log in DOCOMO Public Wireless LAN Service automatically when you come within its service area.

 Add Wi-Fi network: Register access points

which are not compatible with AOSS/WPS manually.

: Available access points are displayed as

items in “Wi-Fi networks”. To connect, select an access point to be used/[Connect]. Ʀ If you select an access point protected by

security, enter the password (security key).

[Easy Wi-Fi registration]

The registration process takes a few minutes.

After completion of the registration of the access point, check that the proper connection to the access point is acquired.

[Auto login settings]

Separate subscription is required to use

DOCOMO Public Wireless LAN Service.

In some service areas, automatic login function

may be unavailable. If you set the automatic login to [ON], the

handset logs in automatically when coming within the service area. Note that high charges may be incurred if your subscription is Mzone daily plan and you set the automatic login to [ON].

This function may become unavailable

according to change of the log-in page contents of DOCOMO Public Wireless LAN Service. In this case, log in via the browser.

[Add Wi-Fi network]

This function supports WEP, WPA/WPA2 PSK,

802.1xEAP as for the security setting.

Before Using the Handset

Disconnecting

In the home screen, [R]/

[Settings]/[Wireless & networks]/[Wi-Fi settings]

Select the connected access

point/[Forget]

: Disconnect retaining the password.

When you terminated the connection with Wi-Fi

function disabled, enable Wi-Fi function to connect automatically if the previously connected access point is available.

Setting up mail account

In the home screen, [R]/[Email]

: Only when an account is not set, the account

setting screen appears.

Enter mail address and password/

[Next]

: Provider information is preset for some mail

accounts, and a receiving mail server and a sending mail server are automatically set.

When you use an account whose provider information is not preset, it is necessary to set a receiving mail server and a sending mail server manually. For details on those settings, contact the Internet service provider you use.

Enter an account name and your

name/[Done]

The account which is registered first is

automatically given priority to normal use. To change the priority, enable Default account of the account to be given priority.

When you delete an account, all mails delivered

to that account are deleted. When there is any protected mail, the account cannot be deleted.

When the account type is Exchange, entering “¥UsernameDomain” in the “Domain¥Username” area is required to set a receiving mail server manually depending on the provider to use. Contact the administrator of the server for details.

Setting up Google account, etc.

In the home screen, [R]/

[Settings]/[Accounts & sync]/ [Add account]

Select the account type

Set up an account

When activating the application that requires an

account without setting the account, the account setup screen appears.

Keep a separate memo of the set account and

password.

Retrieving your Google account password

If you forget your Google account password, retrieve it.

In the home screen, [R]/

[Browser]

Enter “http://www.google.com/” in

the URL entry field/[I]/[Sign in]/[Can’t access your account?]/follow the instructions on the screen

Before Using the Handset

Screen display/icons

Status bar

Status icon

Notification icon

Icon Description

Missed call

Viewing icons

Icons displayed on the status bar at the top of the screen give you various kinds of information, such as the status of the FOMA terminal or the presence of missed calls. You can check the detailed information by displaying the status panel.

Two kinds of icons are displayed.

Notification icon

Status icon Displayed at the right side of the

Displayed at the left side of the status bar, notifying you of missed calls or new mails, etc.

status bar, notifying you of the status of the FOMA terminal such as current time or the battery level.

? # $

& *

,(green) B(blue)

New SMS

New mail

New Gmail

New instant message

Error Appears when some error

happened.

End the Alarm Appears when the alarm is

terminated without End Alarm operation.

Schedule notification of the calendar

Playing music

USB debug connecting

Calling

,(green): During dialing/ incoming call/calling B(blue): During a call using Bluetooth device

-: Putting a call on hold

Main notification icon list

When the same type of notifications exist, the

number of them is displayed on the notification icon.

Before Using the Handset

Answering memo

Voice mail message

microSD Card

3: Scanning 2: Unmount

Few space available in the FOMA terminal

Icon Description

Bluetooth

#: Receiving registration/ Connection request from

#:68

%45

789

EFG

= A

Bluetooth device

:: Receiving data request 6: Bluetooth sending 8: Bluetooth receiving 7: Sent history 9: Received history

USB connection

%: USB connection (in Card reader mode connecting)

4: Card reader mode 5: Fast transfer mode

Data upload/download

7: Uploading 8: Finished uploading 9: Downloading H: Finished downloading

Finished installing application

Wi-Fi

E: Open network F: Wi-Fi information notification G: Wi-Fi connection notification

Wi-Fi tethering enabled

VPN

;: Connecting <: Unconnected

Application update available

OS version upgrade available

Software update

a: Software update available b: Software update finished

Icon Description

Notification icon (not appeared)

Main status icon list

Icon Description

8 to =

!# $%

)

012

PQR

Alarm set

Battery level

8 to =: Approx. 100 to 5% >: Approx. 0% ?: Unknown battery level

While charging, the battery icon

appears with [w] superimposed.

Signal strength

!: Level 4 #: Level 3 $: Level 2 %: Level 1 &: Level 0 (: Out of service area

While international roaming, [R]

appears on the upper left of the signal icon.

Offline mode set

3G data communication status

0: 3G available 1: Receiving 3G data 2: Sending 3G data 3: Sending and receiving 3G

data

GSM data communication status

P: GSM available Q: Receiving GSM data R: Sending GSM data S: Sending and receiving GSM

data

miniUIM not inserted

Before Using the Handset

Icon Description

!"# $%&

()

A B

()*

Osaifu-Keitai is locked

Character entry

!: Hiragana-Kanji ": Full-width Katakana #: Half-width Katakana $: Full-width alphabet %: Half-width alphabet &: Full-width numeric (: Half-width numeric ): Character code

Manner mode status

+: Standard manner ,: Drive manner

-: Silent manner

During a call using speaker

Microphone OFF is set

Wi-Fi signal strength

(: Level 4 ): Level 3 *: Level 2 +: Level 1 ,: Level 0

Bluetooth

#: Connection stand-by $: Connecting

Icon Description

Answering memo

P: No Answering memo when Answering memo is set

Q: Answering memo is one to

PQR

.(green)

-(blue)

nine entries when Answering memo is set R: Answering memo is ten entries when Answering memo is set

Home network

/: Suspending .(green): Preparing

-(blue): Running

Using status panel

Touch the status bar

: Alternatively, keep touching the status bar

and slide down.

Before Using the Handset

GPS positioning

Data synchronizing

1 Setting panel

Set Wi-Fi, Bluetooth, GPS, auto-sync, and

brightness of the screen.

2 Details of notification icon

When there is a corresponding application,

touch the detailed information to activate the application.

3 Details of status icon

When there is a corresponding application,

touch the detailed information to activate the application.

4 Close bar

Touch or keep touching and slide up to close

the status panel.

5 Manner mode

Set manner mode.

6 VeilView

Set VeilView.

7 Auto-rotate screen

Set whether to switch the screen to horizontal/

vertical display when rotating the FOMA terminal 90° to the left/right.

8 microSD Settings

You can check the available space in the

microSD Card and manage back up.

9 Running application

Display functions being activated as a list.

Home screen

Viewing home screen

The home screen appears when the FOMA terminal power is turned on. You can paste widget, activate applications by selecting shortcuts or quick menu, etc.

You can paste shortcuts, widgets, etc. to each

page of the home screen.

1 Indicator

Indicates the displayed page.

2 Folder

Paste a folder to display a data in the folder

quickly and to store shortcuts into the folder.

3 Display application screen

Touch to display an application screen.

4 Widget

Paste widget to use easy functions such as

calendar or compass.

Paste a web page widget to quickly access to

a frequently used site.

The FOMA terminal supports Android

standard widget.

5 Shortcut

Paste a shortcut to quickly activate a

frequently used application.

6 Quick menu

Paste a shortcut to quickly activate an

application.

You can display the home screen list by putting

distance between two fingers apart/closer on the home screen.

Before Using the Handset

Managing pages

Adding pages

You can add a maximum of 12 pages.

Keep touching quick menu and

slide it to the destination

Delete quick menu

In the home screen, z/[Home

screen list]/[+]

Sorting pages

In the home screen, z/[Home

screen list]/touch a thumbnail for a while

Keep touching the thumbnail and

slide it to the destination

Deleting pages

In the home screen, z/[Home

screen list]/touch a thumbnail for a while

[Delete]

: Alternatively, keep touching thumbnail and

slide it to [X].

Managing quick menu

Creating quick menu

You can create up to three quick menus.

In the home screen, touch a

shortcut for a while

Keep touching the shortcut and

slide it to the quick menu

Move quick menu

Touch quick menu for a while

[Delete]

: Alternatively, keep touching quick menu and

slide it to [X].

Managing home screen

In the home screen, z/[Add]

Select an item to add

 Shortcut: Paste a shortcut to an application.  Widget: Paste a widget.  Folder: Paste a folder.  Wallpaper: Set an image on the home

screen.

 Group: Paste a shortcut to a group.  Web page: Paste a web page widget.

Moving shortcut etc.

In the home screen, touch shortcut

etc. for a while

Keep touching shortcut etc. and

slide it to the destination

: If you slide it to the end of the page and stop,

the previous/next page is displayed and you can move to the previous/next page.

Deleting shortcut etc.

In the home screen, touch shortcut

etc. for a while

[Delete]

Before Using the Handset

: Alternatively, keep touching shortcut etc. and

slide it to [X].

Renaming folder

In the home screen, touch a folder

for a while

Touch a group to display/hide an application icon

in the group. Also, you can display/hide all the application icons in a group collectively by putting distance between two fingers apart/closer on the application screen.

[Edit name]

Enter a folder name/[OK]

Application screen

Application screen layout

Loaded applications are displayed as icons in the application screen by group. Select an icon to activate an application.

If you install a new application, an icon is added

to the application screen.

If you uninstall an application, an icon is deleted.

1 Group name 2 Application icon 3 Number of applications

Application list

Applications are classified into groups by their function or type.

docomo service

Icon Application Description

docomo market

iΙλΥσ (i-Channel)

melodycall

Access to docomo market where you can search both applications and movies (nP. 60).

Distribute various

information on weather, news, etc. The latest information received automatically are displayed on the widgets of the stand-by display. i-Channel is a paid service that requires a subscription.

Let the other party who has made a call to you listen to your favorite melody. You can listen to, purchase and set music saved as the melody call. Melody call is a paid service that requires a subscription.

Before Using the Handset

Basic function

Icon Application Description

Phone Use Phone (nP. 64).

Address Book Use Address Book

(nP. 67).

Phonebook backup

PhoneBookCopy*1The phonebook data can

Phonebook backup is a service to backup phonebook data automatically to the backup center on regular basis and restore it when you lost the FOMA terminal, deleted data, etc. For details on

Phonebook backup, refer to “၌ဥ΄ͼΡ

ήΛ· (spκȜΡ<Α ζȜΠέ΁ϋ>༎)”

(Mobile Phone User’s Guide [sp-mode <Smartphone>]) (in Japanese only).

be copied into another FOMA terminal by using the microSD Card. Also, the phonebook data registered in a Google account can be copied into a docomo account (nP. 69).

Icon Application Description

Koe no Takuhaibin

spκȜΡιȜ σ (sp-mode

*1, 2

mail)

Email Use Email (nP. 87).

Gmail Use Gmail (nP. 88).

Area Mail Receive earthquake early

Messaging Use SMS (nP. 88).

Talk Use Google Talk. Google

Koe no Takuhaibin is a

*1, 2

service for recording messages by voice call and notifying the other party of the recorded messages. This application enables you to record and play voice messages easily.

Send and receive mail using mail address of i-mode (@docomo.ne.jp) (nP. 88).

warning etc. provided from the Japan Meteorological Agency (nP. 89).

Talk is an instant message service provided by Google. You can communicate with other users in real time with FOMA terminal or on the website by using Google Talk.

Before Using the Handset

Icon Application Description

Instruction Manual

*1, 2

Instruction manual for this FOMA terminal. You can also activate the functions that you want to use directly from the explanations on the manual (nP. 1).

Browser Display a website using

packet communication or Wi-Fi (nP. 90).

Google Search

Use quick search box (nP. 41).

Voice Search Search information of sites

by voice (nP. 41).

Download Manage data such as

images downloaded from sites.

Market Use Android Market

(nP. 59).

VirusScan

*1, 2

Anti-virus service for Smartphone.

Entertainment

Icon Application Description

BOOKΑΠͺ 2Dfacto

*1, 2

BOOKΑΠͺ 2Dfacto is an electronic bookstore to

read full e-books in a wide variety of genres such as literary books, popular comics and hot business book.

Icon Application Description

ୠȆ΋ηΛ·

ɚ΀ήςΑΗ

*1, 2

View popular e-books/ comics etc. ranging from original works by professional storywriters or celebrity to the popular posted works by general users. Viewing works of professional storywriters or celebrity will be charged.

GALAPAGOS App for Smartphone

Purchase and read full e-books such as

newspaper, magazine or other publications.

BeeTV

*1, 2

BeeTV is a broadcast station for mobile phone. You can watch all the programs of BeeTV by subscribing to BeeTV as a dues-paying member.

YouTube Use YouTube. YouTube is

a free online video streaming service. You can play, search, and upload videos.

SH m2U Use millmo Media Player

for SH. You can manage/ play music or moving pictures in the FOMA terminal or play movie contents etc. on websites.

Before Using the Handset

Icon Application Description

G΄ͼΡ๔ழ ນ (G-Guide

program guide)

*1, 2

G΄ͼΡ๔ழນ (G-Guide program guide) is an

application to read terrestrial TV or BS digital broadcasting program guide. You can search program by keyword or genre.

Twitter A client application of

Twitter. You can communicate with other people by sharing short messages on sites.

mixiSH

Use mixi. You can use mixi to communicate with your friends through various services such as posting diary, uploading pictures, posting voice.

Twonky

*1, 2

Play still/moving pictures, music in the FOMA terminal or on the internet wirelessly on TVs or audios compatible with home network. If you use the contents on the internet, a hotspot that enables you to access to the internet is required.

Icon Application Description

Smart Familink

Watch or listen to still/ moving pictures, music, etc. in the FOMA terminal on “AQUOS” or display information on incoming calls and new mails on “AQUOS” by connecting the FOMA terminal and the home network function compatible TV “AQUOS” to the Wi-Fi network (nP. 110). Also, you can watch TV programs recorded by “AQUOS Blu-ray” on the FOMA terminal by connecting “AQUOS Blu-ray” compatible with the home network function to the Wi-Fi network. You may not be able to

watch “AQUOS Blu-ray” smoothly depending on its record settings or communication devices.

MusicPlayer Play music (nP. 100).

Recochoku

*1,2

Download music data.

Before Using the Handset

mora touch

music.jp for

*1, 2

Download music data.

Icon Application Description

΂ςɚΑΗ

*1, 2

΂ςɚΑΗ is an application where you can

view ΂ςɚΑΗ.

Picture Sort images and moving

pictures by people, event and location and use them (nP. 99).

Gallery Display images (nP. 99).

UkiUkiView Use UkiUkiView. UkiUki

balloons (comments) and store information are registered to location information. They allow you to see information of the place shot in the camera mode or displayed in the map mode. Also, you can post UkiUki balloon to register information to location information.

What If Camera

Shoot still/moving pictures with various effects applied.

Mobage

*1, 2

Mobage is an application where you can enjoy popular games.

*1, 2

ΨΠΑΞZ

The game where you get rid of monsters by searching them with the AR function.

Convenient tool

Icon Application Description

Camera Shoot still pictures

(nP. 95).

Video Camera Shoot moving pictures

(nP. 95).

౷଎ͺίς

(Map appli)

Maps Use Google Maps. You

Navigation Use Google Maps

Compass Check present location and

Places Use Google Places. You

౷଎ͺίς (Map appli) is

*1, 2

an application to support you going out by functions such as map, navigation, transfer, etc. provided by docomo map navi. You can use it for free during trial period (nP. 114).

can measure your present location, and use the navigation function to check how to get to your destination in detail by using it (nP. 113).

Navigation. You can search for a route from the present location to the destination by using it (nP. 113).

azimuth (nP. 114).

can search for facilities near your present location according to genre by using it.

Before Using the Handset

Icon Application Description

Latitude Use Google Latitude. You

can check where a friend is on the map and share status messages by using it.

Evernote

Calculator Use a calculator

*1, 2

Evernote is a service to save various information such as contents of web site, pictures you shot or note of ideas in the sever and to retrieve/view them when you need. You can save and view the information not only from the FOMA terminal but from a PC or other devices. To use this application,

you need to create an Evernote account.

(nP. 120).

Icon Application Description

Camera Reader

Calendar Manage the schedule

Notepad Save a note (nP. 119).

Send and Receive by Infrared

Pedometer Use a pedometer

Dictionary Use a dictionary

Use Barcode reader (nP. 96), Business card reader (nP. 97), Kanji/ English Grabber (nP. 97), Text reader (nP. 98) and Information reader (nP. 98).

(nP. 117).

Send and receive data by infrared communication (nP. 103).

(nP. 121).

Household account Photo money

Clock Use World clock

Before Using the Handset

An application for keeping household accounts. Easily enter the contents written on the receipt such as date, store’s name, price and item just by shooting the receipt with a camera.

(nP. 118), Alarm (nP. 118), Stopwatch (nP. 118) and Timer (nP. 119).

News & Weather

Voice Recorder

Use news and weather. You can check the weather of present location and news by each category. When setting location

information manually, enter the name of Japanese city in romaji. When entering a postal code, enter a space and “jp” or “Japan” after the postal code.

Use voice recorder (nP. 119).

Icon Application Description

Documents To Go

Display files such as Microsoft Word, Microsoft Excel, Microsoft PowerPoint.

Adobe

Display PDF files.

Reader

Contents Manager

ιȜ΃Ȝͺί ς (Maker

appli)

Manage data stored to the microSD Card (nP. 102).

Connect to SHARP website.

Osaifu-Keitai/Shopping

Icon Application Description

Osaifu-Keitai*1Osaifu-Keitai can be used

(nP. 115).

iD୭೰ͺίς (iD setting

appli)

ToruCa

*1, 2

ڢഛ΂Ȝ· Ώοϋ

*1, 2

ڢഛ gateway

iD is the electronic money that enables you to pay by simply holding the FOMA terminal over the scanning device at stores. You can use iD after carrying out simple settings (nP. 122).

Display, search or update ToruCa such as store information or a coupon (nP. 116).

Search popular fashion items etc. that are listed on Rakuten Auction easily.

Use various services such as Rakuten Ichiba.

Icon Application Description

ͼΥΑΏȜ· τΛΠ

ͼΥΑΏȜ·τΛΠ is an application directed by Ines

Ligron for letting the exterior and interior beauty of women shine. It supports “beauty” with the lessen videos, workbooks, diet diary and body weight management function.

ζ·Ρ΢σΡ

Launcher (McDonald Launcher)

*1, 2

ζ·Ρ΢σΡ

Launcher

(McDonald) is an application to allow you to use coupons for McDonald’s members and store locator.

Amazon JP

Access to the Amazon site and purchase various goods such as books and home electric appliances.

Setting

Icon Application Description

Settings Set each item of the FOMA

terminal. The same operation can

be performed as z/ [Setting] in the home screen.

Ρ΋κ٬ٸ၌ ဥ (DOCOMO

Roaming Utility)

*1, 2

HomeSwitcher

Support the use of packet communication overseas or the setting/checking of the flat-rate packet communication service overseas.

Switch the home application to use.

Before Using the Handset

*1 This is provided in Japanese.

*2 When you use this application for the first time,

you need to download it. Packet communication charge is incurred separately for downloading applications.

Pasting group

In the home screen, [R]/touch a

group for a while

[Add to home]

Managing groups

Adding groups

You can add a maximum of 50 groups in the

application screen.

In the home screen, [R]/z/

[Add group] Enter a group name/[OK]

Sorting groups

In the home screen, [R]/touch a

group for a while

Keep touching the group and slide

it to the destination

Editing title of groups

In the home screen, [R]/touch a

group for a while [Edit name]/enter a group name/

[OK]

Changing group color

In the home screen, [R]/touch a

group for a while

Deleting group

In the home screen, [R]/touch a

group for a while [Delete]/[OK]

Managing application icons

Moving application icons

In the home screen, [R]/touch an

application icon for a while [Move]/Select a group

: Alternatively, keep touching an application

icon and slide it to the destination.

Pasting shortcut

In the home screen, [R]/touch an

application icon for a while

[Add to home]

Uninstalling application

In the home screen, [R]/touch an

application icon for a while [Uninstall]/[OK]

[Change color]/select a color

Before Using the Handset

Switching display of application screen

In the home screen, [R]/z/

[List view]/[Tile view]

Once you accept the installation of application,

you are responsible for the results of using the application. Be very cautious about installation of applications that have access to many functions or a significant amount of data.

Purchasing application

Market

By using Android Market, you can access to useful applications or fun games directly, that can be downloaded and installed to the FOMA terminal.

Enable Background data (nP. 81) in advance.

In the home screen, [R]/[Market]

Be sure to check the security of application,

then install it at your own risk. The FOMA terminal may be infected with a virus or data may be damaged.

Note that DOCOMO shall not be liable for

malfunctions caused by the application you installed.

Note that DOCOMO shall not be liable for any

disadvantage brought to you or any third party due to the application you installed.

Installing application

In the Android Market screen,

select an application to download/

When downloading a charged application, you

need to create a Google Checkout account to purchase the application.

In the Android Market screen,

select an application to purchase/ touch the price/[OK]

: If you make a purchase for the first time, sign

in Google Checkout payment and billing service.

You pay for the application only once.

Re-downloading applications which you previously uninstalled after first downloading it is not charged.

If you have multiple Android devices that use

the same Google account, you can download the purchased application to all of them at no additional cost.

DOCOMO holds no responsibility for

responding to purchase applications and get refund from the Android Market.

[FREE]/[OK]

Before Using the Handset

Uninstalling applications

You can ask for a refund within a specified time after of the purchase of application. The application is deleted and you are not charged. In addition, note that a refund request is available for each application only once. If you requested a refund for the purchased application in the past and purchase the same application again, a second refund request is not available.

In the Android Market screen,

[My apps]

: In the Android Market screen, z/

[Help]/[Android Apps]/each item of [Buying apps] for details on the payment method when purchasing an application, the terms on the refund request, etc.

Select an application to uninstall/

[Uninstall]/[OK] Answer the survey form/[OK]

docomo market

In docomo market, you can quickly access DOCOMO recommended sites and useful applications.

ɦdocomo market is provided in Japanese.

In the home screen, [R]/[docomo

market]

Packet communication (3G/GPRS) or Internet

connection via Wi-Fi is required to use docomo market.

Packet communication charge is incurred

separately for connecting to docomo market and downloading applications introduced on docomo market. Some downloaded applications automatically perform packet communication.

Applications introduced on docomo market

include charged ones.

DOCOMO shall not be liable for any

disadvantage caused by sites introduced on docomo market or the information acquired from the sites.

DOCOMO shall not be liable for contents,

adequateness to purpose of use, reliability, etc. of applications introduced on docomo market.

Some applications that you perform installation

may give your FOMA terminal instability of the operation or may send your location information or personal information registered in the FOMA terminal to outside via the Internet and the information may be used improperly. Please thoroughly check a provider and operation condition of the application, etc. before using it.

The copyrights of materials (documents,

photographs, illustrations, animations, sounds, software, etc.) on this site are owned by DOCOMO or other third parties and are protected by the Copyright Act as well as other laws and agreements. Excluding the extent of quotation and reproduction for private use that is approved in the Copyright Act, the reproduction, adapting or public transmission of copyrighted material is prohibited without the consent of the party owing the copyright.

Before Using the Handset

Character entry

QWERTY keyboard

12 keyboard

Switching keyboards

You can use the following two types of the

keyboards.

QWERTY keyboard

12 keyboard Several characters are assigned

In the character entry screen, [T]/

You can enter a displayed character by touching the character entry key. Use romaji for entry.

to one character entry key. Characters are switched every time the key is pressed. You can enter characters

quickly by keeping touching a character entry key and slide up/down or to the left/right.

[Change keyboard(Portrait)]/ [Change keyboard(Landscape)]

Keyboard layouts

1 Character entry keys

Use to enter characters or numbers. The display of character entry keys changes

according to the input mode or the setting of upper/lower case.

2 Alphabet/Shift key

Touch to enter half-width alphabet in

Hiragana-Kanji entry mode.

Touch to switch between upper/lower case

letters. Symbols that can be entered changes when you switch the upper/lower case letters.

3 Character key

Touch to change input modes.

4 Delete key

Use to delete a character on the left side of

the cursor. When the cursor is on the beginning, delete a character on the right side of the cursor. When the cursor is on a character, delete the character.

5 Enter key

Use to confirm the entered characters or

insert a line break.

6 Symbol key

Use to display the pictogram/symbol/emoticon

list.

7 Setting/Conversion key

Display setting menu. Convert input characters.

8 Cursor keys

Use to move the cursor or to change the

range of characters to be converted.

Before Using the Handset

9 Riverse toggle/Undo key

໲ল



་۟

໲ল

ͺ΢;ϋΑ



ͺ΢;ϋΑ

Conversion candidates field

Use to display characters assigned to the

same key in the inverse order.

Use to undo previous operation.

Entering characters

Example: When entering “

In the character entry screen, enter

“

: To enter a displayed conversion candidate:

: To confirm characters in hiragana: [OK]

[

: To broaden/restore the conversion

”

Touch the conversion candidate

] (conversion)

candidates field: [P]/[Q]

”

Example: When entering “

In the character entry screen, enter

“ [S]/[S]/[S]

: Each time you touch [S], [ī] is entered and

In the conversion candidates field,

select “

Switching input modes

Switch input modes according to types of characters to enter.

In the character entry screen, touch

”

the predictive conversion candidates appear according to the number of characters.

”

character key for a while

: Touch character key to switch input modes in

the order of Hiragana-Kanji b Half-width alphabet b Half-width numeric.

Select input mode

Entering pictograms/symbols/ emoticons

Unavailable characters cannot be entered

depending on applications.

Select “

Wildcard Prediction

Conversion candidates are predicted by the number of the entered characters and appear. Enable Wildcard Prediction of iWnn IME - SH

edition in advance (nP. 82).

This function is available in the Hiragana-Kanji

entry mode and the Half-width alphabet entry mode.

Before Using the Handset

”

In the character entry screen,

symbol key

Select a pictogram/symbol/

emoticon

Inputting kuten codes

You can use four-digit kuten codes assigned to each character for entering kanji, hiragana, katakana, symbol or alphanumeric characters.

In the character entry screen, touch

character key for a while/ [Character Code]

Input a kuten code

: After the fourth digit is entered, the

corresponding character appears.

: After the fourth digit is entered, the entry

mode is switched to the previous entry mode.

Inputting with voice

You can enter characters with voice. Enable voice input of iWnn IME - SH edition in

advance (nP. 82).

In the character entry screen, [T]/

[Voice Input]/[OK]

Entering by handwriting

You can enter characters by handwriting.

In the character entry screen, [T]/

[Handwriting Input]

Enter characters or symbols in the

character entry area by handwriting

: To enter a displayed conversion candidate:

You can cut, copy or paste the entered characters.

Touch the conversion candidate

When entering characters by handwriting, enter

slowly and legibly.

Convenient functions in character entry

Touch the character entry field for a

while

Select a function to be used

Speak to the mouthpiece

In the following cases, Voice input may not

work properly.

 When the voice is too loud  When the surrounding noise is big  When the phonation is not clear  When the phonation is not natural  When the pronunciation is too fast  When any key is pressed, the mouthpiece is

touched, etc.

Before Using the Handset

Call/Network Services

Phone

Making a call

Emergency call

Emergency calls Phone number

Emergency call to police 110 Emergency call to fire

station/medical assistance Emergency call at sea 118

119

In the home screen, [R]/[Phone]

Enter a phone number

: Always dial the area code, even when the

number is of the same area.

: You can set to notify/not to notify the other

party of your phone number for each call by adding “186”/“184” to the head of the phone number.

[Call]

[End call] to end the call

This FOMA terminal supports “Location

notification of emergency call”. When dialing an emergency number such as 110, 119, and 118, the information of your location (location information) is automatically notified to the agency that received the emergency call (e.g. the police station). Depending on your location and the reception status of the signal, the agency that received the emergency call may not be able to confirm the exact location. If you are not sending your caller ID by calling with “184” added or other means, your location information and phone number are not notified. However, if the agency that received the emergency call considers your location information and phone number necessary for important purposes, such as life saving, the agency can retrieve them regardless of your settings. In addition, the area/timing to introduce “Location notification of emergency call” depends on the state of preparation in each agency that receives emergency calls.

In Japan, you cannot call to the emergency

number (110, 119 or 118) from the PIN code entry screen and PUK (PIN Unlock Key) entry screen, with a miniUIM locked.

Call/Network Services

When calling 110, 119, and 118 from your

FOMA terminal, the police or fire stations may return your call for verification purposes. State that you are calling from a mobile phone, and give your phone number and exact location. Remain stationary to ensure that you are not disconnected while making an emergency call, and keep handset turned on to receive calls for approximately 10 minutes afterwards.

Depending on the region, calls to the police or

fire station may not be connected.

International call (WORLD CALL)

WORLD CALL is an international calling service available from DOCOMO FOMA terminal in Japan. WORLD CALL is registered when FOMA services are registered (excluding users who did not apply for WORLD CALL).

You can call to about 240 countries and regions

worldwide. Calling to a fixed-phone and mobile phone overseas is available.

For information on available countries and

telecommunications carriers, refer to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International Services website.

WORLD CALL charges are billed with the

monthly FOMA service charges.

Commission and monthly usage fees are free. Contact “General Inquiries” on the back of this

manual for details on WORLD CALL.

To make an international call through a company

other than DOCOMO, contact the representative companies for instructions.

The caller ID may not be notified or displayed

correctly depending on some overseas telecommunications carriers. In this case, making a call with incoming call history is not available.

[Calling Method]

When calling to a fixed-line phone: 010/

country code/area code (city code)/the other party’s phone number/[Call]

When calling to a mobile phone: 010/country

code/the other party’s phone number/[Call]

Ʀ For the other parties’ phone numbers and area

codes (city codes) that begin with “0”, omit the “0” when entering (except some countries or regions such as Italy).

Ʀ Alternatively, enter “009130-010” as usual or “+”

instead of “010”.

Receiving a call

When a call is received, the ring

tone sounds and the incoming lamp flashes

Keep touching [2] and slide to the

right

: When call is received while the backlight is

illuminated (except while the touch panel unlock screen is displayed), touch [Answer].

: To place a call on hold: Keep touching [4]

and slide to the left

[End call] to end the call

Call/Network Services

Rejecting calls

Outgoing history list Incoming history list

Adjusting the in-call volume

When call is received, the ring tone

sounds and the incoming LED flashes

z/[Reject]

Operation during a call

You can carry out operations such as using a hands-free call and adjusting the in-call volume depending on the using condition during a call.

1 Mute/Disable mute

Enables or disables mute setting on a current

call.

2 Activate memo 3 Activate voice memo 4 Call by number key 5 Display phonebook 6 Speaker/Speaker off

You can talk with hands-free.

x/y during a call

Outgoing call history/ Incoming call history

The FOMA terminal keeps a record of the 100 most recent phone numbers to which calls were made.

In the home screen, [R]/

[Phone]/[Outgoing History]/ [Incoming History]

: To register an entry to the phonebook: Touch

a history for a while/[Add to Address Book]/register it to the phonebook

: To delete all entries in the outgoing call

history/incoming call history: z/[Delete All]/ Enter the Lock No./[OK]/[OK] Ʀ You can also delete the outgoing call

history/incoming call history in the phonebook by enabling [With Address Book’s call history].

: To delete one entry in the outgoing call

history/incoming call history: Touch a history for a while/[Delete]/[OK]

Note the following when using hands-free.

Ʀ Speak approximately 20 to 40 cm away from

the mouthpiece. When the surroundings are noisy, the sound may break up and the call may not be satisfactory.

Ʀ When calling outdoors, in a location where

surroundings are noisy and where the sound echoes loudly, use the earphone.

Ʀ If the sound breaks up during a hands-free

call, lower the in-call volume.

Call/Network Services

1 Image

Appears when the other party’s image is

added to phonebook.

2 Called/Received date and time 3 The other party’s name/phone number 4 Outgoing call icon

Touch to make a call.

5 Group icon

Touch to display Collected histories. The

histories will be collected as the same group even when “186” or “184” is added to the phone numbers.

6 Incoming call status icon

(green)

E(red)

7 Talk time/Incoming call ring time

Select a history

Calls that were answered

Calls that were not answered within 3 seconds ring time

Incoming calls that were rejected

Calls that were not answered, calls that were forwarded or calls with an Answering memo left

Phonebook

Set each item/[Save]/[Yes]

 Image (face), Image (full body): Save an

image to display when making and receiving a call or confirming the phonebook.

 Family name, Given name: Enter a name.

You can edit a reading.

 Phone number: Save phone numbers.  Mail: Save mail addresses.  mixi: Register my mixi information.  Twitter: Register information of following

person on twitter.

 Chat: Save chat addresses.  Group setting: Save a group.  Other: Save other information. Information

which can be saved differs depending on the account type.

: Select [#] to specify a phone number/mail

address that is usually displayed.

Adding entries to phonebook

In the home screen, [R]/[Address

Book]/z/[Add new entry]

: When a confirmation screen for linking mixi

and Twitter appears, follow the instructions on the screen and operate.

Select the account to register

Checking phonebook

You can retrieve phone numbers from the phonebook to make calls and send mail.

Call/Network Services

In the home screen, [R]/[Address

Phonebook list screen

Phonebook detail screen

Book]

: To switch account: z/[Setting]/[Switch

account]/select an account

: To delete a phonebook: Touch a phonebook

for a while/[Delete]/[Yes]

1 Account

Display the account of retrieved

phonebook.

2 Icon for searching

Enter characters one by one to display

the closest entries each time.

3 Tab

The tabs of Japanese syllabary row,

alphabet and the others are displayed.

4 Integrated icon

The integrated multiple phonebook is

displayed.

5 Image (face)

6 Speech bubble

Speech bubble icon appears when the

call, message of mixi/Twitter, etc. is received within 24 hours. Touch it to display the details of the notice in the speech bubble. Touch the speech bubble to check communications.

7 TapFlow UI activation

Display TapFlow UI (nP. 40).

Select a name

1 Image (full body) 2 Picture field

The data classified by people category

from Picture is displayed.

3 Registered contents

Check or use all the registered contents.

4 Speech bubble

Displays messages such as incoming call

and mixi/Twitter. Touch to check communications.

5 Priority icon

Displayed in a phone number/mail

address that is usually displayed.

6 Action icons

Use to make a call or compose a mail.

Call/Network Services

7 TapFlow activation

·ΑεȜΠ

ٳই

ϋεȜΠ

ષ



೏ح

ͺ΃;ϋΠ΋άȜ

ષ

೏ح

Displays TapFlow UI (nP. 40).

Integrated icon

When the same name, mail address, etc. as the

contact to import are saved in the phonebook, they may be automatically integrated.

Speech bubble

The outgoing call history/incoming call history

can be deleted in the “Phone” application (nP. 66).

Using PhoneBookCopy

You can copy phonebook data to/from other FOMA terminals using microSD Card. Also, you can copy phonebook data stored in Google account to docomo account.

In the home screen, [R]/

[PhoneBookCopy]

: When you use this for the first time, you must

agree with “license agreement”.

Exporting phonebook to microSD Card

Insert microSD Card in advance.

In the PhoneBookCopy screen, [

] (Export)/[

(Start)/[OK]

: Phonebook data stored in docomo account

are saved to microSD Card.

Importing phonebook from microSD Card

Insert microSD Card with phonebook data in

advance.

In the PhoneBookCopy screen, [

] (Import)

]

Select a phonebook to import/[

] (Overwrite)/[

: Imported phonebook data are saved in

docomo account.

Copying contact information stored in Google account to docomo account

In the PhoneBookCopy screen,

[docomo to docomo account)

Select a Google account to copy/

[ [OK]

: Copied phonebook data are saved in

docomo account.

: You can copy phonebook data stored in the

main body to docomo account in the same way as Google account.

When phonebook item names (phone number

etc.) stored in other FOMA terminals are different from those of this FOMA terminal, the item names may be changed or deleted. Also, the characters that can be registered in contact information are different in each FOMA terminal, so they may be deleted in copy destination.

When you export phonebook to microSD Card,

you cannot copy phonebook data without name.

When you import phonebook from microSD

Card, you cannot read file which backed up collectively.

] (Overwrite)/[

] (Add)/[OK]

] (Add)/

] (Copy

Call/Network Services

Available network services

You can use the following DOCOMO network

services on the FOMA terminal.

Service name

Voice Mail Service

Call Waiting Service

Call Forwarding Service

Nuisance Call Blocking Service

Caller ID Notification Service

Public mode (Power off)

“Deactivate” does not mean that the Voice Mail

Service, Call Forwarding Service or other subscriptions are canceled.

Network services are not available outside the

service area or in a place with no signal.

This manual explains the outline of each network

service based on the operation using the FOMA terminal menu. Refer to “Mobile Phone User’s Guide [Network Services]” for details.

For subscription and inquiries, contact “General

Inquiries” on the back of this manual.

Subscription

Necessary Fees apply

Necessary Free

Not

necessary

Not

necessary

Not

necessary

Monthly fee

Free

Voice Mail Service

Voice Mail Service is a service for answering calls with a reply message and recording callers’ messages when the handset is outside the service area or turned off or when you cannot answer calls.

This FOMA terminal does not support Voice Mail

Service of videophone call. Call “1412” to disable it.

To prioritize Voice Mail Service when Answering

Memo (nP. 77) is also set, set the ringing time for Voice Mail Service shorter than the answering duration for Answering Memo.

If a call is not answered when Voice Mail Service

is set to “Activate”, the call is saved as “Missed Call” in “Incoming History” and the notification icon [+] appears.

Basic flow

STEP 1 Activate Voice Mail Service. STEP 2 Call is received. STEP 3 Call is connected to Voice Mail Service

center if not answered.

STEP 4 Caller records a message.

To record a message immediately

without hearing a reply message when you are in a hurry, press “#” when a reply message is played.

STEP 5 Play message.

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Voice mail service]

Select the service

 Activate: Start Voice Mail Service.

Call/Network Services

 Ring time: Set time to connect to Voice Mail

Service.

 Deactivate: Stop Voice Mail Service.  Check setting: Check current settings.  Play messages: Play new message.  Setting: Set Voice Mail Service.  Check messages: Check new message.  Notification setting: Set to notify when a

message is stored.

 Missed call notification: If a call is received

while the handset is outside the service area or turned off, SMS notifies the missed calls received after the handset is turned on again or returns to the service area.

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Call waiting]

Select the service

 Activate: Start Call Waiting Service.  Deactivate: Stop Call Waiting Service.  Check setting: Check current settings.

Charges are incurred by a caller even when the

call is on hold.

Placing the current call on hold and making a

call to another party are possible even when Call Waiting Service is deactivated.

You can record up to 20 messages with the

recording time per message up to approximately 3 minutes. Messages are saved for up to approximately 72 hours.

When Call Forwarding Service is set to

“Activate”, Voice Mail Service is stopped automatically.

Ring time

If you set Ring time to “0 sec.”, an incoming call

is directly connected to Voice Mail Service center without being registered in the incoming call history.

Call Waiting Service

Call Waiting Service is a service for placing the current call on hold and answering a new incoming call when the handset beeps during a call to notify you of another call. In addition, place the current call on hold and make a new call.

When receiving another call during a call, a

beeping is heard.

Placing the current voice call on hold and answering an incoming call

When a beeping tone is heard

during a call, keep touching [2] and slide to the right

: Alternatively, z/[Hold current call &

answer].

: The original call is automatically placed on

hold and an incoming call is connected.

: To switch between callers: [Swap calls]

Disconnecting the current voice call to answer an incoming call

When a beeping tone is heard

during a call, keep touching [4] and slide to the left/[Answer]

: Alternatively, z/[End current call &

answer].

: The voice call to the first person is

disconnected, and you can answer the new incoming call.

Call/Network Services

Placing the current voice call on hold

and making a separate call

During a call, z/[Add Call]/

enter a phone number/[Call]

: The original call is automatically placed on

hold.

: To switch between callers: [Swap calls]

Rejecting an incoming call during a call

When a beeping tone is heard

during a call, z/[Reject]

Call Forwarding Service

Call Forwarding Service is a service for forwarding calls when the handset is outside the service area or turned off or when calls are not answered within set ringing time.

To prioritize Call Forwarding Service when

Answering Memo (nP. 77) is also set, set the ringing time for Call Forwarding Service shorter than the answering duration for Answering Memo.

If a call is not answered when Call Forwarding

Service is set to “Activate”, the call is saved as “Missed Call” in “Incoming History” and the notification icon [+] appears.

Basic flow

STEP 1 Register forwarding destination. STEP 2 Activate Call Forwarding Service. STEP 3 Call is received. STEP 4 Call is automatically forwarded to the

registered destination if not answered.

Call Forwarding Service fees

Caller

Charged to caller.

Call Forwarding Service

subscriber

Charged to Call Forwarding Service subscriber.

Forwarding destination

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Call Forwarding]

Select the service

 Activate: Start Call Forwarding Service. Also,

the ringing time can be set and a phone number to forward to can be entered.

 Deactivate: Stop Call Forwarding Service.  Register number: Change phone number to

forward to.

 Forwarding number busy: Set whether to

connect to Voice Mail Service center when the forwarding destination is busy.

 Check setting: Check current settings.

When Voice Mail Service is set to “Activate”,

Call Forwarding Service is stopped automatically.

Setting Call Forwarding guidance

In the home screen, [R]/

[Phone]/enter “1429”/[Call]

: Set according to the voice guidance.

Call/Network Services

Nuisance Call Blocking Service Caller ID Notification Service

You can register phone numbers for “nuisance calls” such as prank calls. When numbers are registered for the Nuisance Call Blocking Service, calls are automatically rejected and a guidance answers them.

A ring tone does not sound when calls are

received from registered numbers. In addition, the calls are not saved in the incoming call history.

You can reject callers with no caller ID. International calls may not be rejected.

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Nuisance call blocking service]

Select the service

 Register nuisance caller: Register the last

caller.

 Register selected No.: Register specified

caller.

 Delete all entries: Delete all registered

numbers.

 Delete last entry: Delete the last registered

number.

 Check the number of entries: Check the

number of registered entries.

You can display your number (caller ID) on the other party’s phone (display) when you make a call.

Caller ID is important personal information. Be

very careful about your caller ID setting.

The caller ID notification function is available

only on compatible phone devices.

If you hear a message asking you to notify caller

ID, enable the caller ID notification function or add “186” and call again.

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Caller ID notification]

Select the service

 Check setting: Check current settings.  Setting: Activate/Deactivate Caller ID

Notification Service.

Additional service

Save and use new DOCOMO network services when they are added.

You can save command of new services to the

FOMA terminal. When there is a command, it is saved as a “USSD” to the FOMA terminal.

Enter the “special number” or “service code”

notified from DOCOMO to use the service. “Spacial number” is a number to connect to the service center. “Service code” (USSD) is a code number to notify the service center.

Call/Network Services

In the home screen, [R]/

[Settings]/[Call settings]/ [NWService]/[Additional service]

Select the service

 USSD: Register additional services.

Ʀ You can register up to ten new network

services.

 Reply message: Register reply message.

Ʀ You can register up to ten reply messages.

Public mode (Power off)

Public mode (Power off) is an automatic answering service used to ensure the proper manners in public places. Set Public mode (Power off) to play a message for the caller stating that the power is off and you are unable to answer because you are in a place that does not allow the use of mobile phone (in a hospital, on the airplane, near the priority seats on the train, etc.), and the call is disconnected automatically.

When Public mode and network services are set

simultaneously, Voice Mail Service

Forwarding Service Request Service Public mode (Power off). *1 For calls whose ringing time is other than 0

seconds, the service is activated after the Public mode (Power off) guidance.

*2 Public mode (Power off) is activated when

the caller notifies the ID.

For calls from callers rejected by Nuisance Call

Blocking Service, Public mode (Power off) is not activated.

and Caller ID Display

are activated in priority to

, Call

When a “User unset” call is received while Caller

ID Display Request Service is set to “Activate”, Caller ID Display Request message is played (Public mode (Power off) message is not played).

In the home screen, [R]/[Phone]

Enter “b25251”/[Call]

: Public mode (Power off) is set (Nothing

changes in the home screen).

Disabling Public mode (Power off)

: In the home screen, [R]/[Phone]/enter

“b25250”/[Call]

Checking Public mode (Power off) setting

: In the home screen, [R]/[Phone]/enter

“b25259”/[Call]

When Public mode (Power off) is set

Public mode (Power off) remains set until disabled. The setting is not canceled just by turning on the power. When a call is received, a message stating that you are in a place that does not allow the use of mobile phone is played and the call is disconnected automatically. Public mode (Power off) message is played when the handset is outside the service area or in a place with no signal.

Call/Network Services

Various Settings

Setting menu

In the home screen, [R]/[Settings] to display the menu and set various settings of the FOMA terminal.

Setting Description

Profile You can display the phone

number registered in the miniUIM and register a name, mail address, etc.

Energy saving settings

Wireless & networks

Call settings Set call such as voice mail,

Sound settings Set manner mode, ring tone,

Display settings Set screen display etc. USB connection Change the setting in

Location & security

Applications Manage applications.

Set to conserve the battery power.

Set communication such as Wi-Fi, Bluetooth function and Wi-Fi tethering.

reject calls, etc.

etc.

connecting the FOMA terminal to PC using the microUSB cable for PC (sample).

Set the security lock or the way to retrieve information of the present location.

Setting Description

Accounts & sync

Privacy Delete all of the data in the

microSD & phone storage

Language & keyboard

Voice input & output

Accessibility Set accessibility option. Pedometer

setting Date & time Set the date and time and the

About phone Check the information about

Default settings Change the initial setting.

You can synchronize data between the FOMA terminal and online services. You can access personal information stored in online services from the FOMA terminal and PC, and you can use and update data by synchronizing them.

FOMA terminal. You can check the available

space in the microSD Card and manage back up.

Set the language displayed in the screen or character entry.

Set Voice input & output and text-to-speech.

Set pedometer setting such as User Information.

date format.

phone.

Various Settings

Profile

Wireless & networks

You can display the phone number registered in the miniUIM and register a name, mail address, etc.

In the home screen, [R]/

[Settings]/[Profile] z/[Edit]/set each item/

z/[Save]/[Yes]

: For details on each item which can be set

nP. 67

Energy saving settings

Set to conserve the battery power.

In the home screen, [R]/

[Settings]/[Energy saving settings]

Select an item

 Quick energy saving: Set all the items

displayed in Energy saving settings to conserve the battery power.

 Energy saving rest mode: Set time and level

to conserve the battery power.

 Wi-Fi, Bluetooth: For details nP. 76  Audible touch tones, Audible selection,

Screen lock sounds, Pulse notification light:

For details nP. 78

 Auto-rotate screen, Brightness, Screen

timeout: For details nP. 79

 Use GPS satellites: For details nP. 80  Background data: For details nP. 81

Set communication such as Wi-Fi, Bluetooth function and Wi-Fi tethering.

In the home screen, [R]/

[Settings]/[Wireless & networks]

Select an item

 Offline mode: Restrict the use of all functions

using communication such as call/mail function.

 Wi-Fi: Enable Wi-Fi function.  Wi-Fi settings: For details nP. 43  Home network settings: For details

nP. 110

 Bluetooth: Activate Bluetooth function.  Bluetooth settings: For details nP. 107  Portable hotspot: For details nP. 77  VPN settings: Set and manage VPN.  Mobile networks: For details nP. 125

[Offline mode]

When the SIM card lock setting is enabled, you

cannot call to the emergency number (110, 119 or 118). When the SIM card lock setting is disabled, you can call to the emergency number (110, 119 or 118) in Offline mode. If you call to the emergency number, Offline mode is disabled and the call is made.

[VPN settings]

VPN (Virtual Private Network) is a connection

method to prepare for and connect safely to a virtual dedicated line on the network at home or in the office from outside the home, office, etc. Ʀ PPTP is not available when ISP is set to

sp-mode.

Various Settings

Wi-Fi tethering

Tethering function that connects Wi-Fi compatible devices to the Internet via networks of this FOMA terminal by using the FOMA terminal as a Wi-Fi access point is available.

You can connect to up to five Wi-Fi compatible

devices simultaneously.

This function is available inside the FOMA

service area. However, this function may be interrupted depending on the conditions on communications or on network congestion.

This function is not available when miniUIM is not

inserted or in cases in which the FOMA service is canceled or stopped.

In the home screen, [R]/

[Settings]/[Wireless & networks]/[Portable hotspot]

Select an item

 Portable Wi-Fi hotspot: Enable the Wi-Fi

tethering.

 Portable Wi-Fi hotspot settings: Set the Wi-Fi

tethering settings such as network SSID and security. Ʀ [Configure Wi-Fi hotspot]/set each item/

[Save] to set Wi-Fi hotspot. Set security setting if necessary. The security setting supports WPA2 PSK.

 Help: Display Help information.

Call settings

Set call such as voice mail, reject calls, etc.

In the home screen, [R]/

[Settings]/[Call settings]

Select an item

 Any key answer settings: Set an action when

you press | on receiving a call.

 Auto answer: Set to answer a call

automatically when an earphone is connected.

 Calling display setting: Set the display in the

screen during a call.

 Call/Ans Memo: Play or set Call/Answer

Memo. If you set Answering Memo, the FOMA terminal answers a call and records the caller’s message when you cannot answer.

 Int’l call settings: Check country codes.  Call blocking: Set Call blocking.

Ʀ [Specified numbers]/z/[Edit] to save

the specified phone number.

 NWService: For details nP. 70  Accounts: Set an account of Internet call.  Use Internet calling: Set whether to use

Internet call.

[Any key answer settings]

Following items can be set.

 Answer: Press | on receiving a call to

answer it.

 Quick silent: Press | on receiving a call to

temporarily stop the ring tone or vibration.

 OFF: Operation is not available by pressing

| on receiving a call.

Various Settings

Sound settings

Set manner mode, ring tone, etc.

In the home screen, [R]/

[Settings]/[Sound settings]

Select an item

 Manner mode: Set to avoid disturbing others

when in public.

 Phone vibe: Set whether to enable the

vibrator for receiving a call.

 Volume: Set the volume of ring tone, media

play sound, etc. Ʀ Alternatively, press x/y to change the

volume.

 Earphone type: Set the type of earphone

connected.

 Melody: Set the ring tone.  Vibrator Pattern: Set the vibrator pattern.  Incoming lamp: Set the pattern of lamp when

receiving a call.

 Notification sound: Set the sound for

receiving notification.

 Ring duration: Set the ring duration.  Pulse notification light: Set whether to flash a

lamp for receiving a notification.

 Audible touch tones: Set whether to enable

dial sound.

 Audible selection: Set whether to enable

operation sound for selecting items.

 Screen lock sounds: Set whether to enable

operation sound for locking or unlocking screen.

 Haptic feedback: Set whether to enable the

vibrator for specific key operation.

Note that if the vibrator is set to be enabled and

the FOMA terminal is left on a table, it may fall due to vibration.

[Manner mode]

The following is not silenced even while Manner

mode is set.

 Shutter sound of camera  Record start/end sound of video camera  Record start/end sound of voice recorder

The following manner mode can be set.

 Standard manner mode: The ring tone and

operation sound are silenced, and the

vibrator is activated when receiving a call or

others. When Answering Memo setting is set

to [Mannermode], Answering Memo is

enabled and operated according to its

setting.

 Drive manner mode: The ring tone and

operation sound are silenced, and the

vibrator is not activated even when receiving

a call or others. Answering Memo is enabled

and operated with the Answering message

setting of [Drive].

 Silent manner mode: The ring tone and

operation sound are silenced, and the

vibrator is not activated even when receiving

a call or others. When Answering Memo

setting is set to [Mannermode], Answering

Memo is enabled and operated according to

its setting.

While manner mode is set, incoming call

volume cannot be changed by pressing x/y.

[Pulse notification light]

If no operations are performed for

approximately 24 hours after notification lamp starts flashing, notification lamp will be turned off.

Various Settings

Display settings

USB connection

Set screen display etc.

In the home screen, [R]/

[Settings]/[Display settings]

Select an item

 Brightness: Set the brightness of backlight.  Auto-rotate screen: Set whether to switch the

screen to horizontal/vertical display when rotating the FOMA terminal 90° to the left/ right.

 Animation: Express screen switch with

animation.

 Screen timeout: Set the light duration of

backlight.

 VeilView: Prevent others from seeing

display.

 Text font: Set the text font.  Wallpaper: Set an image of home screen.

[Brightness], [Screen timeout]

Note that increasing the brightness level or the

light duration shortens the continuous stand-by time.

[VeilView]

The effect of preventing others from seeing

differs depending on the selected patterns.

The intensity is more effective to prevent others

from seeing the display in order of [Dark],ȁ [Medium], and [Light].

VeilView is disabled if the power is turned off.

[Text font]

Font may not appear correctly when activating

an application downloaded from Android Market etc. depending on the selected font.

Change the setting in connecting the FOMA terminal to PC using the microUSB cable for PC (sample).

In the home screen, [R]/

[Settings]/[USB connection]

Select an item

 USB battery charge: Charge the FOMA

terminal while it is connected to a PC via the microUSB cable for PC.

 USB connection mode: Change the mode

set when connecting the FOMA terminal to a PC. Ʀ Connect the FOMA terminal to a PC via the

microUSB cable for PC in advance.

[USB battery charge]

USB battery charge setting is enabled when a

USB is connected next time or the USB connection mode is changed.

[USB connection mode]

The following modes can be set.

 Card reader mode: Mode for using microSD

Card inserted to the FOMA terminal as an

external memory for a PC.

 Fast transfer mode: Mode for upgrading OS

version.

 MTP mode: Mode for transferring music/

video/still picture data to microSD Card using

Windows Media

While transferring data, Offline mode may be

enabled.

Player 11/12.

Various Settings

Location & security

 Clear storage: Delete all credentials and

reset the credential storage password.

Set the security lock or the way to retrieve information of the present location.

In the home screen, [R]/

[Settings]/[Location & security]

Select an item

 Use wireless networks: Position location

information using wireless network.

 Use GPS satellites: Position location

information with higher accuracy.

 Lock Setting: Set the various locks.



Unlock method: Change the unlock method.

finger list, Lock No. or password can be used.

 Change unlock pattern: Change the finger

list pattern, Lock No. or password set for unlock method.

 Use visible pattern: Display track for entering

finger list pattern with line.

 Use tactile feedback: Activate vibration on

entering Lock No., finger list pattern and password.

 Set up SIM card lock: Set for the PIN code.  Visible passwords: When you enter the PIN

code etc., you can display the entered characters before displaying [Ȇ].

 Select device administrators: Set the device

administrators when the device administrators is certificated.

 Use secure credentials: Allow to access

secure certificates and other credentials. Ʀ Set the credential storage password in

advance.

 Install from microSD: Install encrypted

certificates from microSD.

 Set password: Set the credential storage

password.

It is necessary to enable location information

services ([Use wireless networks] or [Use GPS satellites]) to measure the present location.

[Use GPS satellites]

Power consumption of the FOMA terminal

increases.

[Lock Setting]

If you failed to enter finger list pattern five times

when disabling Screen lock, you cannot enter it for 30 seconds. Disable the lock by signing in with your Google account and enter new finger list pattern.

You can call to the emergency number (110,

119 or 118) even when you set Restrict calls.

To use a function while it is restricted, enter the

Lock No. to temporarily disable the restriction.

[Set up SIM card lock]

In Japan, you cannot call to the emergency

number (110, 119 or 118) from the PIN code entry screen and PUK (PIN Unlock Key) entry screen, with a miniUIM locked.

The setting is saved in the miniUIM.

Various Settings

Applications

Manage applications.

If you delete the applications or widgets installed

by default, you can download them from the manufacture’s site (http://galapagossquare.com/) (in Japanese only).

In the home screen, [R]/

[Settings]/[Applications]

[Unknown sources]

Applications you download from the sites may

be of unknown origin. To protect your FOMA terminal and personal data, download applications only from trusted sources such as Android Market.

[Development]

Refer to http://developer.android.com/ for

details on development function.

Select an item

 Unknown sources: Allow installation of

application received via mail or site other than Android Market.

 Preferred install location: Set the preferred

location for installed applications.

 File transfer mail software: Set a mail

software to be activated by attaching to mail from another application.

 Home applications: Switch the home

application to use.

 Manage applications: Check application

names, their versions, the memory usage, etc.

 Running services: Display and control the

running services.

 Storage use: Check storage usage per

application.

 Battery use: Check battery usage per

application.

 Development: Use application development

functions.

Accounts & synchronization

In the home screen, [R]/

[Settings]/[Accounts & sync]

Select an item

 Background data: Allow all applications to

automatically perform data communication.

 Auto-sync: Allow all applications to

automatically perform data synchronization.

: Accounts to be synchronized are displayed

as items in “Manage accounts”.

: For details on adding an account nP. 45

synchronize phonebook of your FOMA terminal with contacts on the online services even if you synchronize with other than Google account.

Various Settings

Privacy

Delete all data in the FOMA terminal.

In the home screen, [R]/

[Settings]/[Privacy]/[Reset all]/

[Erase microSD]

Note that all the data on the microSD Card will

be deleted when formatted.

Language & keyboard

[Reset phone] Enter the Lock No./[OK]/[Erase

everything]

microSD & phone storage

You can check the available space in the microSD Card, manage the backup, etc.

In the home screen, [R]/

[Settings]/[microSD & phone storage]

Select an item

 Total space: Check the microSD Card space.  Available space: Check the available space

in the microSD Card.

 microSD backup: For details nP. 120  Mount microSD/Unmount microSD: Mount/

Unmount microSD Card.

 Erase microSD: Format the microSD Card.

Ʀ Unmount the microSD Card in advance.

 Available space: Check the available space

in the FOMA terminal.

Set the language displayed in the screen or character entry.

In the home screen, [R]/

[Settings]/[Language & keyboard]

Select an item

 Select language: Select Japanese/English.  User dictionary: Register any words in the

dictionary and display them as conversion candidates when you enter the characters with the Android keyboard.

 iWnn IME - SH edition: Set iWnn IME - SH

edition.

 Android keyboard: Set the Android keyboard.

[Mount microSD]/[Unmount microSD]

Turn off the power before mounting or

unmounting the microSD Card.

Various Settings

Voice input & output

Pedometer setting

Set Voice input & output and text-to-speech.

In the home screen, [R]/

[Settings]/[Voice input & output]

Select an item

 Voice recognizer settings: Set the voice input

method.

 Text-to-speech settings: Set the voice for

text-to-speech.

[Text-to-speech settings]

Text-to-speech settings is available only when

the screen of the FOMA terminal is set to the English display (nP. 82).

Accessibility

Set accessibility option.

In the home screen, [R]/

[Settings]/[Accessibility]

Select an item

 Accessibility: Set accessibility option which

responds to user’s operation with sound and vibration is available.

 Power key ends call: Set whether to end the

call by pressing H.

Set pedometer setting such as User Information.

In the home screen, [R]/

[Settings]/[Pedometer setting]

Select an item

 Pedometer On: Enable the pedometer.  User Information: Register height, weight

and stride.

 Pedometer Reset Time: Set time to reset the

pedometer.

 Walking Sensitivity: Set the sensitivity of the

pedometer.

Pedometer On cannot be enabled without

inputting User Information.

When Pedometer On is enabled, the number of

steps is always counted while the power is turned on.

The display of the pedometer is reset once a

day on the time set in the Pedometer Reset Time.

[Accessibility]

By default, accessibility option is not registered.

Settings will be available by downloading accessibility options such as “SoundBack”, “KickBack” and “TalkBack” from Android Market.

Various Settings

Date & time

About phone

Set the date and time and the date format.

In the home screen, [R]/

[Settings]/[Date & time]

Select an item

 Automatic: Set whether to adjust the date

and time automatically.

 Set date: Set the date manually.  Select time zone: Set the time zone

manually.

 Set time: Set the time manually.  Use 24-hour format: Switch 12-hour format/

24-hour format.

 Select date format: Set the date format to

display.

When [Automatic] is enabled

If the FOMA terminal does not adjust the time

for a while after the power is turned on, turn off the power and restart it.

Time may not be adjusted depending on the

signal status.

Time may be off by a few seconds.

Check the information about phone.

In the home screen, [R]/

[Settings]/[About phone]

Select an item

 Status: You can check the battery level,

network in use, etc.

 Battery use: You can check the battery

usage per application.

 Adjust sensitivity of sensor: Adjust accuracy

of motion sensor and geomagnetic sensor.

 Software Update: For details nP. 134  Major Update: Upgrade OS version of the

FOMA terminal by connecting the FOMA terminal to your PC. Ʀ For details on upgrade nP. 141

 Legal information: You can check copyright

notice, terms of service, etc.

 Technical Regulations Conformity

Certification: You can check the certification

of conformity with technical regulations.

 Model number: You can check the model

number.

 Android version: You can check the Android

version.

 Baseband version: You can check the

baseband version.

 Kernel version: You can check the kernel

version.

 Build number: You can check the build

number.

Various Settings

[Adjust sensitivity of sensor]

Perform the adjustment approximately 10

seconds after the adjustment screen appears.

Adjustment may be failed depending on

surroundings or other simultaneously running applications. Change the place where you make adjustment, end running applications, etc.

Security codes

Security codes used on the FOMA terminal

Some functions for convenient use of the FOMA terminal require security codes. In addition to the Lock No. used for various handset operations, use security codes such as the network security code when using network services. Use security codes with various functions to fully utilize the FOMA terminal.

Entered Lock No. (security code for each

function) and PIN code are marked with [Ȇ].

Precautions for various security codes

Do not use easily estimated numbers for

security codes to be set such as “birthday”, “part of a phone number”, “address or room number”, “1111” or “1234”. Keep a separate memo of security codes.

Keep security codes private. If the security

codes are found and improperly used by others, DOCOMO shall not be liable for any loss of the users.

If you forget your security codes, you are

required to bring your identification (a driver’s license etc.), your FOMA terminal and your miniUIM to a docomo Shop. For details, contact “General Inquiries” on the back of this manual.

PUK (PIN Unlock Key) is described in the

agreement form (customer copy) you received at the time of subscription at a docomo Shop. If you made a subscription outside a docomo Shop, bring your identification (a driver’s license etc.) and your miniUIM to a docomo Shop or contact “General Inquiries” on the back of this manual.

Lock No. (for various functions)

Lock No. is set to [0000] by default but you can change the number (nP. 80). If you enter the wrong Lock No. five times

continuously, you cannot enter it for 30 seconds.

Various Settings

Network security code

Network security code is a four-digit code required for confirming the subscriber’s identity when an order is received at a docomo Shop or docomo Information center or used for accessing various network services. You set arbitrary code at the time of subscription but you can change the code. For those with “docomo ID/password” of the general support site “My docomo” designed for PC (in Japanese only), the registration procedure for a new network security code is available from PC. Refer to the inside back cover of this manual for

details on “My docomo”.

PIN code

A miniUIM has a security code called PIN code. This security code is set to [0000] by default but you can change the code (nP. 80). The PIN code is a four- to eight-digit security code that is entered when a miniUIM is inserted or when the FOMA terminal is turned on to prevent unauthorized use by a third party. Making/ Receiving a call and the terminal operation are enabled by entering PIN code. Use the previously set PIN code when inserting a

miniUIM that has been used in another FOMA terminal. It is [0000] if the setting has not been changed.

If you enter the wrong PIN code three times

continuously, it is locked. In this case, unlock with “PUK” (PIN Unlock Key).

PUK (PIN Unlock Key)

PUK (PIN Unlock Key) is an eight-digit number used to disable the PIN code lock. You cannot change the code. If you enter the wrong code ten times

continuously, the miniUIM is completely locked. In this case, contact a docomo Shop.

Disabling PIN lock

In the PIN locking screen, enter

PUK (PIN Unlock Key)/[OK] Enter the new PIN code/[OK]

Enter the new PIN code again/

[OK]

Various Settings

Mail/Internet

Mail

You can send and receive mail by setting a mail account provided by service provider such as mopera U.

Set the account in advance (nP. 45).

In the home screen, [R]/[Email]

: The Inbox screen appears when an account

is registered. Ʀ To display the mail main screen: z/

[Accounts]

Ʀ To display the mailbox screen: z/

[Folders]

: The mail main screen appears when multiple

accounts are registered.

z/[Compose]

Enter a destination, a subject, and a

message/[Send]

: To attach a file: z/[Add attachment]/

select a file

Some receiving models may not be able to

receive the subject completely.

Mail sent from a Gmail account are treated as

one from a PC. When receiving models set PC-mail rejection, mails cannot be sent.

Mail that could not be sent by some reason is

saved as unsent mail.

Text for recipient may not appear correctly

depending on signal status.

Attaching file

You can attach up to 5 MB by each file. There

are no limits for number of attaching data.

Depending on the receiving side terminal, files

may not be received, correctly displayed/played etc. Also, the quality of videos may deteriorate, videos may be converted to continuous still pictures, etc.

Displaying mail

In the home screen, [R]/[Email]

: To update Inbox: In the Inbox screen, z/

[Refresh] Ʀ Incoming new mails are received and

displayed in the Inbox screen.

Select a mail

Replying mail

In the home screen, [R]/[Email]

Select a mail

[Reply]/[Reply all]/compose and

send the mail

Forwarding mail

In the home screen, [R]/[Email]

Select a mail

z/[Forward]/enter the

destination and send

Deleting mail

In the home screen, [R]/[Email]

Select a mail

: In the mail list screen, touch check boxes

and [Delete] to delete multiple mails.

Mail/Internet

[Delete]

κȜΡ

ιȜσ

sp-mode mail

You can send and receive mail using i-mode mail address (@docomo.ne.jp). Pictograms and Deco-mail are available. Automatic reception is also supported.

For details on sp-mode mail, refer to “၌ဥ΄ͼ

ΡήΛ· (spκȜΡ<ΑζȜΠέ΁ϋ>༎)”

(Mobile Phone User’s Guide [sp-mode <Smartphone>]) (in Japanese only).

In the home screen, [R]/[sp

] (sp-mode mail)

Replying mail

In the home screen, [R]/[Gmail]

Select a mail

[$]/compose and send the mail

: To reply to all: In the mail composition

screen, [%]/[Reply All]/compose and send the mail

Forwarding mail

In the home screen, [R]/[Gmail]

Select a mail

[$]/[%]/[Forward]/enter the

destination and send

Gmail

Gmail is a mail service provided by Google.

Refer to Gmail website for details on Gmail.

In the home screen, [R]/[Gmail]

z/[Compose]

Enter a destination, a subject, and a

message/[#]

Displaying mail

In the home screen, [R]/[Gmail]

: To update Inbox: z/[Refresh]

Ʀ Incoming new mails are received and

displayed in the Inbox screen.

Select a mail

Deleting mail

In the home screen, [R]/[Gmail]

Select a mail

: In the mail list screen, touch check boxes

and [Delete] to delete multiple mails.

[Delete]

SMS

You can send and receive text messages that include up to 70 double-byte characters (160 characters for single-byte characters only) to/ from other terminal using phone numbers.

You can also exchange messages with users of

non-DOCOMO overseas telecommunications carriers. Refer to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International Services website for information on available countries and overseas telecommunications carriers.

Mail/Internet

In the home screen, [R]/

[Messaging]

: The thread list screen appears.

[New message]/enter a

destination and a message/[Send]

For destinations of non-DOCOMO overseas

telecommunications carriers, enter “+”, the country code, and the recipient’s mobile phone number. If the phone number begins with “0”, omit the “0”. Alternatively, enter “010”, the country code and the phone number. Add “010” to reply to SMS received from abroad.

Single-byte katakana and special symbols in

SMS text may not appear correctly for recipient.

SMS cannot be sent when “186” or “184” is

added.

Displaying message

In the home screen, [R]/

[Messaging]

Select a thread

Deleting message

In the home screen, [R]/

[Messaging]

Select a thread

Touch a message for a while/

[Delete message]/[Delete]

Deleting thread

In the home screen, [R]/

[Messaging]

Touch a thread for a while/[Delete

thread]/[Delete]

Early warning “Area Mail”

Area Mail is a service to receive the earthquake early warning, etc. provided from the Japan Meteorological Agency.

When an area mail is sent to you, it is

automatically received and the contents of it is displayed whether or not sleep mode is set or whether or not screen lock is set.

Area Mail may not be received or displayed

automatically depending on the condition of the FOMA terminal. Ʀ In the following cases, you cannot receive Area

Mail.

 While power is off  While out of service area  During international roaming  In Offline mode

Ʀ In the following cases, you may not receive

Area Mail.

 During packet communication (data

communication)

 During Wi-Fi tethering  During software update  During OS version upgrade

Ʀ In the following cases, you can receive Area

Mail but it may not be displayed automatically.

 During a call  During packet communication (playing data by

streaming, data communication)

 During software update  During OS version upgrade

Area Mail is a free service that does not require a

subscription.

Mail/Internet

Receive Area Mail automatically

When Area Mail is received, the

Area Mail dedicated ring tone

 Manner mode setting: Set the operations

activated during manner mode.

 Check display image and beep tone: Set the

incoming screen and ring tones.

sounds and the incoming lamp flashes

Checking received Area Mail later

Touch the status bar/select

received Area Mail

: Alternatively, [R]/[Area Mail] in the home

screen.

You can receive Area Mail without subscription

to mopera U, Business mopera Internet (URL restriction) and sp-mode.

You cannot receive the Area Mail that failed to

be received again.

You can save up to 50 Area Mails. If the number of Area Mails saved in the FOMA

terminal exceeds the maximum number to be saved, Area Mail is deleted from the oldest one.

Setting of early warning “Area

Settings of the earthquake early warning alarm,

ring tone sounds dedicated to disaster and evacuation information, ring tone volume, vibrator cannot be changed.

Browser

Displaying sites

This FOMA terminal can display sites over packet communication or Wi-Fi connection.

In the home screen, [R]/

[Browser]

Some sites may not appear properly.

Searching sites

In the browser screen, touch a

search box

Mail”

Whether to receive Area Mail, operations on receiving Area Mail, etc. is set.

In the home screen, [R]/[Area

Mail] z/[Early warning “Area Mail”

setting]/select an item

 Receive setting: Set whether to receive Area

Mail.

 Beep time: Set the ring duration.

Mail/Internet

Enter the URL/keyword

: Display a list of URLs that start with the

entered characters or sites that include the entered characters.

Select the search result

: Alternatively, [I] after entering whole URL/

keyword.

Opening new window

In the browser screen, z/[New

window]

: When multiple windows are opened: z/

[Windows]/[Open new window]

Switching windows

In the browser screen, z/

[Windows]

Select a window

Searching characters in the page

In the browser screen, z/[Find

on page]

Enter the keyword

[a]/[b]

: To end searching: [c]

Copying characters

In the browser screen, z/

[More]/[Copy text]

Keep touching the start position

and slide it to the end position

: To change the copy range: Keep touching

[d]/[e] and slide it

Touch the copy range

Convenient functions

You can display a link with a new window, download data such as images, etc.

In the browser screen, touch a link/

an image for a while

Select a function to use

Setting website

In the browser screen, z/

[More]/[Settings]/[Home page setting]

Enter the URL

: To enter the URL of displaying site: [Use

current page]

[OK]

Using bookmark and history

Saving bookmarks

In the browser screen, z/

[Bookmarks] [Add]/[OK]

: When display is set to List view: [Bookmark

current page]/[OK]

Displaying sites from bookmarks

In the browser screen, z/

[Bookmarks]

Select a bookmark

Displaying sites from frequently used sites/histories

In the browser screen, z/

[Bookmarks]/[Most visited]/ [History]

Select a frequently used site/history

Mail/Internet

Multimedia

Camera

Before using camera

Fingerprints or oil on the lens may cause the

image to be out of focus. In addition, images may blur, rays of light may appear in images when shot near a strong light source, etc. Wipe the lens with a soft cloth before shooting images.

You cannot shoot when battery level is

insufficient. Images may appear dark, distorted, etc. when shot with insufficient battery power even while the handset is charging. Do not shoot images while charging.

Although the cameras are made with

high-precision technology, some pixels or lines look constantly dark or bright. Further, white lines and other noise may appear in images especially when shooting images in dimly lit surroundings.

The quality of images may deteriorate when shot

or saved after the FOMA terminal has been left in a warm location for a long time.

If the camera lens is exposed to direct sunlight

for a long time, the internal color filter may discolor, creating a discoloration of shot images.

Images shot in shooting conditions which include

strong light source such as the sun or a lamp may appear dark, distorted, etc.

Shooting the sun directly may damage the

performance of the CMOS.

In the following cases, the FOMA terminal may

become warm and the camera may end. This is not a malfunction.

 When shooting still pictures continuously  When shooting long moving pictures  When activating the camera for a long time

Use the camera again after a while.

When Focus settings is switched, sounds may

be heard from the camera lens. This is not a malfunction.

Images are blurred when the FOMA terminal

moves while shooting images. Hold securely to prevent blurring. Use Steady cam function when shooting still pictures.

The color and brightness of the subject in images

shot with the camera may differ from the actual color and brightness.

Make sure that your fingers, hair and handset

strap do not obscure the camera lens when shooting images.

Because a larger picture size requires more

data, movement in the image on the FOMA terminal display may appear slow.

Indoor fluorescent lighting may create flickering,

streaky shading on the screen, etc. This flickering or shading may be reduced by changing the lighting conditions, brightness, adjusting the camera brightness and white balance, etc.

Shot still pictures are saved in DCF1.0

(ExifVer.2.3, JPEG) format.

Multimedia

“DCF” (Design rule for Camera File system) is a standard created mainly by JEITA (Japan Electronics and Information Technology Industries Association) for images from digital cameras and other devices to be shared with related devices. However, DCF standard does not guarantee the entire compatibility of all devices.

Ʀ “Exif” is a file format established by JEITA

(Japan Electronics and Information Technology Industries Association) for adding supplementary information to the still picture.

Copyrights and rights of portrait

Images and audio recorded with the FOMA terminal are for personal use and may not be used for any other purposes without the consent of the rightful person in accordance with copyright laws. Please note that acts such as the use or defacement of the likeness or name of other individuals without their consent may infringe on an individual’s rights of portrait. Please be aware of copyrights and rights of portrait when posting images and audio recorded with the handset on the Internet or similar media. The recording of images or audio may be restricted at concerts, performances and exhibits even when recorded for personal use. Do not use this handset to send copyrighted images for uses other than those permitted under copyright laws. If you cause the public any trouble using the FOMA terminal, you may be punished under law or regulations (for example, nuisance prevention ordinance).

Please be considerate of the privacy of individuals around you when shooting and sending pictures using a camera-enabled mobile phones.

Performance while using camera

Shooting lamp flashes in each camera mode. In each camera mode, if no operations are

performed for approximately 3 minutes, the camera mode automatically ends. Unsaved data is saved and the scanned result is deleted. However, if you shoot still pictures and there is unsaved data, the camera mode does not end. In each camera mode, Mobile light cannot be on after lighting on for 3 minutes in total. End each camera mode and reactivate it to put Mobile light on.

The shutter sound volume cannot be changed.

Picture size and magnification of camera

Vertical display

The following picture size and magnification are

available.

Shoot still picture


size

QVGA: 240×320

VGA: 480×640

QHD: 540×960

2M: 1200×1600

FullHD: 1080×1920

3M: 1536×2048

5M: 1944×2592

8M: 2448×3264

Maximum magnification

(zoom step)

Approx. 1.9× (7 steps)

Approx. 1.5× (5 steps)

Approx. 1.9× (7 steps)

Approx. 1.7× (6 steps)

Approx. 1.5× (5 steps)

Approx. 1.2× (3 steps)

Approx. 1.9× (7 steps)

Multimedia

* If you use zoom, the suitable picture size is

automatically selected.

Horizontal display

The following picture size and magnification are

available.

Shooting screen layout

Still picture shooting screen


size

Shoot still picture

Shoot moving picture

* If you use zoom, the suitable picture size is

automatically selected.

QVGA: 240×320

VGA: 480×640

QHD: 540×960

2M: 1200×1600

FullHD: 1080×1920

3M: 1536×2048

5M: 1944×2592

8M: 2448×3264

HD: 1280×720

QHD: 960×544

VGA: 640×480

QVGA: 320×240

Maximum magnification

(zoom step)

Approx. 1.9× (7 steps)

Approx. 1.5× (5 steps)

Approx. 1.9× (7 steps)

Approx. 1.7× (6 steps)

Approx. 1.5× (5 steps)

Approx. 1.2× (3 steps)

Approx. 1.9× (7 steps)

Actual size (–)

Approx. 1.5× (5 steps)

Approx. 5.1× (14 steps)

Approx. 6.4× (15 steps)

Moving picture shooting screen

1 Remaining number of pictures/time which

can be shot

Even after shooting a still picture, remaining

number of pictures/time which can be shot may not be changed.

2 Focus settings 3 Blog mode

An application is activated by touching it when

the upload destination setting of the blog mode setting is set to [Twitter] or [mixiSH].

4 TapFlow activation

Displays TapFlow UI (nP. 40).

5 ISO sensitivity

Multimedia

6 Thumbnail

Shoot when Auto Save is set to [ON].

Thumbnail appears. Touch to display the shot still picture/moving picture.

7 White balance 8 Picture size 9 Save settings a Scene settings b Image quality c Camera mode d Fix camera shake e Self-timer f Shutter g Mobile light

Switch ON/OFF of Mobile light.

h Auto save settings

Touch icon display area to switch display

range.

Camera

Shoot a still picture.

In the home screen, [R]/[Camera]

: To adjust the brightness: Slide up/down : Zoom: Slide to the left/right : Focus lock: Touch the subject

Ʀ Touch anywhere other than focus frame to

cancel the focus lock.

: To display All Menu: z

 Switch camera: Switch camera mode.  Blog mode Settings: Set the blog mode.  Detect Personal: Set personal detection.  Self-timer: Set the use of self-timer.  Picture Size: Set the picture size.  Focus settings: Set the type of focus.  Shutter settings: Set the shutter.  ISO Sensitivity: Set ISO sensitivity.

 Settings: Set each item of settings for

shooting.

 Picture: Activate Picture.  D-Range: Set whether to use dynamic

range adjustment.

 Save settings: Set saving method.  Scene: Set shooting mode.  Mobile light: Set the use of Mobile light.  Help: Display Help.  Reset usage history: Reset the TapFlow

UI history.

[!]

: The shutter sounds. : If Auto Save of Save settings is set to [ON],

this operation is completed.

[Save]

Video camera

Shoot a moving picture.

In the home screen, [R]/[Video

Camera]

: To adjust the brightness: Slide up/down : Zoom: Slide to the left/right : To display All Menu: z

 Switch camera: Switch camera mode.  Self-timer: Set the use of self-timer.  Picture Size: Set the picture size.  Focus settings: Set the type of focus.  Settings: Set each item of settings for

shooting.

 Picture: Activate Picture.  Auto Save: For details nP. 96  Scene: Set shooting mode.  Mobile light: Set the use of Mobile light.  Help: Display Help.

Multimedia

 Reset usage history: Reset the TapFlow

UI history.

[(]

: Shooting starts after the shooting start sound

is heard.

[)] to end shooting

: After the shooting end sound, the shooting

stops.

: When Auto Save is set to [ON], this

operation is completed.

[Save]

The remaining time indicator is an

approximation. Shooting may continue longer than the remaining time indicated before the start of shooting or may automatically stop even when there is remaining time.

The remaining time indicator changes

according to the available space in the microSD Card and battery level.

Auto save settings

Set whether you save a shot still picture or a shot moving picture automatically.

Camera reader

Barcode reader

You can use the camera to scan bar codes (JAN/QR codes), and perform various operations according to the contents of scanned item.

JAN code

JAN code is a type of bar code using vertical

bars of varying width to express numbers.

The following code is read as [4942857119022].

JAN8 and JAN13 can be read.

QR code

QR code is a type of two-dimensional code

expressing data vertically and horizontally.

The following code is read as [ڼ৆ٛ২NTTΡ΋

κ].

In the still picture shooting screen, z/[Save settings]/[Auto Save]

: When the video camera is on: In the moving

picture shooting screen, z/[Auto Save].

Select the setting

Multimedia

In the home screen, [R]/[Camera

Reader]/[Switch reader]/ [Barcode]

: To adjust the brightness: Slide up/down

Scan the bar code

: The Barcode reader screen appears and

scanning starts. Display bar code to be scanned in the center of the screen.

: Position the camera approximately 10 cm

right away from the bar code. Keep aligned and do not move the FOMA terminal or code while scanning.

: When scanning is complete, an end tone

sounds and the scan result screen appears.

Split data

: Some QR codes are consisted of single data

by scanning split multiple data (up to 16). If split data is scanned, a message appears. Select [Yes] to proceed to the next QR code scanning screen. When the next QR code is displayed in the center of the screen, scanning starts automatically. Repeat until all split data is scanned and the scan results appear.

Use the scan result

Some bar codes cannot be scanned depending

on types or sizes.

Bar codes may not be scanned due to

scratches, dirt, damage, poor print quality, lighting conditions or QR code version.

Business card reader

Display a business card in the

center of the screen/[Read]

: The shutter sounds. : Hold the FOMA terminal securely to fit the

entire business card with the frame displayed on the screen. Make sure that no other objects, especially text-written objects, are displayed on the screen.

: Keep the camera approximately 10 cm away

from the business card.

: For scanning, the direction of the business

card can be either vertical or horizontal on the screen. Do not place the card obliquely.

[Recognition]

[Register]

: The shot card images are automatically

saved.

Select an account to register

Specify the register range of the

image/[Save]

: The specified range of the image is added to

the phonebook as an image.

Add to the phonebook

: Scanned items are entered in the phonebook

editing screen.

You can scan information such as name or phone number from a business card (Japanese/ English) with the camera and save it to the phonebook.

In the home screen, [R]/[Camera

Reader]/[Switch reader]/[Card]

: To adjust the brightness: Slide up/down

Some business cards cannot be scanned or

recognized properly.

Kanji/English Grabber

You can scan kanji and English words with camera and display readings or meanings. You can also search the scanned characters in dictionaries.

Multimedia

The readings or meanings displayed in Kanji/

MINAMIDE Kosei & Taishukan, 2009.

In the home screen, [R]/[Camera

Reader]/[Switch reader]/[Kanji/ English]

Display the characters to scan in

the loupe frame of the screen

: The scanned results and readings or

meanings appear in a speech bubble. Ʀ Up to two readings or meanings appear.

[ఈetc] appears when three or more.

: To search the scanned characters in

dictionaries: While displaying the scanned results, [Select]/[Search]/search in dictionaries

Point the cursor to the line to scan

with [#]/[$]/[Read]

: When letters written in vertical direction are

recognized: [%]/[&]

: The line to which the cursor is pointed is

displayed in light blue frame.

[OK]

: To change scanning mode: z/select a

mode

Use the scan result

: To register to notepad: [Register to

Notepad]/[Register]

: Touch the scan result to use after scanning

phone numbers, URLs and mail addresses.

: To display menu: z

Text may not be scanned correctly due to

scratches, dirt, damage, poor print quality, lighting conditions or text size.

The scanned results are not saved. The characters may not be scanned correctly

due to scratches, dirt, lighting conditions or text size.

Text reader

You can scan an article of newspaper, magazines, etc. by using the camera, and compose mail, notepad, etc.

In the home screen, [R]/[Camera

Reader]/[Switch reader]/[Text]

: To adjust the brightness: Slide up/down

Display the text to scan in the

screen/[Shoot]

: The shutter sounds.

Multimedia

Information reader

You can scan information such as store name or phone number from a magazine, etc. by using the camera, and save it to the phonebook.

In the home screen, [R]/[Camera

Reader]/[Switch reader]/[Info.]

: To adjust the brightness: Slide up/down

Display information in the center of

the screen/[Read]

: The shutter sounds. : Hold the FOMA terminal securely to fit

necessary information in the screen. However, if the text gets too small, display a phone number or address largely enough to be scanned.

Sharp HRO00153 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
