The FCC has granted an Equipment Authorization for this model
handset with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
handset is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/ea/fccid/ after searching
on FCC ID APYHRO00116.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Website at http://www.ctia.org/.
Powered, Picsel Viewer, Picsel Document
Viewer and the Picsel cube logo are trademarks or registered
trademarks of Picsel Technologies and/or its affiliates.
・ Redistribution and use in source and binary forms, with or
without modification, are permitted provided that the
following conditions are met:
・ Redistributions of source code must retain the above
copyright notice, this list of conditions and the following
disclaimer. Redistributions in binary form must reproduce the
above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other
materials provided with the distribution.
・ Neither the name of the <ORGANIZATION> nor the names
of its contributors may be used to endorse or promote
products derived from this software without specific prior
written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS
AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PART ICULA R PURP OSE ARE DISCLAIMED. IN NO EVENT SHALL
THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR
TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN
ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
そ
の
他
97
Before Use
1
2
3
12 3
FOMA card
lever
Notch
Tabs
External connector
terminal cover
External
connector
terminal
Connector
(Turn the
side with the
arrows up)
Charging
LED
Release buttons
2
1
1
Inserting FOMA card and battery pack
1 Lightly push the catch on the back cover in the
direction of the arrow (1), slide approximately
3 mm (2) and remove the back cover (3)
2 Pull the FOMA card lever down (1). Hold the FOMA card with the IC
(gold) side turned down and push it all the way in (2). Pull the FOMA
card lever up (3)
Charging
1 Open the external
connector terminal
cover and insert the
AC adapter connector
horizontally into the
external connector
terminal
2 Insert the AC adapter power plug into an outlet
Charge start sound is heard, charging LED
illuminates, and charging starts.
3 Turn a recycle mark side up, match tabs and
attach the battery pack
4 Place the back cover to the FOMA te rminal
slot with the back cover open approximately 3
mm, push and slide it to the direction of arrow
to insert
Turn off the power and insert the FOMA card/battery pack while holding the
FOMA terminal with your both hands. Note that excessive force may damage
the FOMA terminal, FOMA card, battery pack and FOMA card lever.
3 Hold the release buttons (1) and
horizontally remove the connector (2)
when charging is complete
Charge end sound is heard and charging
LED turns off when charging is complete.
Note that excessive force may damage the FOMA terminal and AC adapter.
そ
の
他
99
1 Earpiece
2 Main display
3 i (,): i-mode/Operation guidance key
4 m: Mail/Operation guidance key
5 s: Start/Hands-free/Eco key
6 1 to 9, 0, * and #: Dial/Character entry keys
7 $: Multi/Quick search/VeilView key
8 In-camera
9 w&t&: Multi-guide key
a C: Camera/TV/Operation guidance key
b a: Phonebook/Operation guidance key
c c (J): i-Channel/Clear key
d H: Power/End key
e y: In-camera key
f Mouthpiece/Microphone
g microSD Card slot
h &: Light key
i FOMA antenna
j 1Seg antenna
k Called/Charging LED
l Sub microphone
m Sub display
n External connector terminal
o Strap hole
p Speaker
q Main camera
r Infrared port
s Picture Light
t Back cover
u b mark
v Charger terminal
j
h
i
k
m
l
g
d
c
b
2
4
9
3
1
5
a
e
f
6
7
8
q
p
t
s
r
o
n
u
i
v
そ
の
他
Key illustrations are examples and may look different from actual keys.
100
Part Names and Functions
Main icons
Icon display area
Viewing Display/Icon
Signal status
bbbb (Strong b Weak)
When [ ] appears, the handset is outside the service area
or in a place with no signal.
Battery level
bbbbb (High b Low)
i-mode/Full Browser
i-appli
Ir communication
i-mode mail/SMS/Area Mail received
microSD Card
1Seg being recorded
Record message
Silent
Vibrator
Manner mode
Public mode (Drive mode)
IC card lock
Restriction
Hands-free
Alarm
Music&Video Channel program reservation
FOMA card error
Self mode
VeilView
3G
ToruCa
Information received
そ
の
他
101
Basic Operations
Turning power on/off
Turning power on
1 H (for 2+ seconds)
Turning power off
1 H (for 2+ seconds)
Changing screen display to English
1 ][Settings]/[一般設定]/[Bilingual]/[English]
Making initial setting
The initial setting screen automatically appears when the power is turned on for
the first time. Make the initial setting according to instructions on the screen.
※ Terminal security code (four to eight digits) is set to [0000] by default but can
be changed by user.
Checking your own phone number
1 ]0
Character entry
※ Operate in the character entry screen.
Switching entry modes
1 a/select the entry mode with w&/t&
Switching upper/lower case
1 Enter a character/*
Deleting characters
1 Move the cursor to the character and c
そ
の
他
To delete all characters: At the end of the message, c (for 1+ seconds)
Using phrases
1 a (for 1+ seconds)/select a phrase/t&/confirm the phrase/t&
Entering pictograms/symbols
1 i
To switch between pictogram and Deco-mail pictogram: iTo switch between single- and double-byte symbols: C
2 Select a pictogram/symbol/t&
Entering emoticons
1 m (for 1+ seconds)/select an emoticon/t&
Character entry example
Ex.) When entering “電話”
1 a/[あ] with w&
2 4 (four times)/* (once)/0 (three times)/r&/0 (once)
3 p& to move the cursor to the conversion candidates field
4 Select “電話”/t&
Changing ring tone
1 ][Settings]/[Snd/Vibrator/Manner]/[Select sound]
2 Select an item/t&
3 Select a ring tone/i
Lock/Security
Changing terminal security code
1 ][Settings]/[Security]/[Change security code]/enter the current
terminal security code/t&
2 Enter the new terminal security code/t&/enter the new terminal
security code again/t&
Changing network security code
1 ^i/[お客様サポート]/[各種設定 (確 認・変 更・利 用 )]/[ネットワー
ク暗証番号変更]
Changing i-mode password
1 ^i/[English]/[Options]/[Change i-mode Password]
Changing PIN1/PIN2 code
1 ][Settings]/[Security]/[UIM Settings]/enter the terminal
security code/t&
2 Select the PIN1 or PIN2 code/t&
3 Enter the current PIN code/t&
4 Enter the new PIN code/t&/enter the new PIN code again/t&
102
Various lock functions
All lock
1 ][Settings]/[Security]/[Lock settings]/enter the terminal
security code/t&/[All lock]/[Yes]
Keypad dial lock
1 ][Settings]/[Security]/[Lock settings]/enter the terminal
security code/t&/[Keypad dial lock]/select the setting/t&
Function lock
1 ][Settings]/[Security]/[Lock settings]/enter the terminal
security code/t&/[Function lock]/select an item to lock/t&/C
Self mode
1 ][Settings]/[Phone settings]/[Self mode]/select the set ting/
t&/[Yes]
Multi lock
1 ^t& (for 1+ seconds)/[Multi lock]/[Yes]
IC card lock
1 ^t& (for 1+ seconds)/[IC card lock]/[Yes]
Side key lock
1 ^t& (for 1+ seconds)/[Side key lock]
Omakase Lock
Omakase Lock is a service to lock the personal data and IC card functions in case
of loss, etc. by only your request to DOCOMO via phone.
This is a paid service. Refer to “Mobile Phone User’s Guide [i-mode] FOMA
version” for details on Omakase Lock.
Enable/Disable Omakase Lock
s 0120-524-360 Office hours: 24 hours
Incoming call restriction
Rejecting a call with no caller ID
1 ][Settings]/[Security]/[Accept/Reject calls]/enter the terminal
security code/t&
2 Select the reason/t&
3 Select the setting/t&
Rejecting a call from a caller unset in phonebook
1 ][Settings]/[Security]/[Accept/Reject calls]/enter the terminal
security code/t&/[Reject unknown]
2 Select the setting/t&
Voice/Videophone Calls
Making a voice/videophone call
1 ^enter a phone number
2 s (Phone)/i (V.phone)
3 H to end the call
Receiving a voice/videophone call
1 When a call is received, the ring tone sounds and the called LED flashes
2 s
3 H to end the call
Making a call with redials/received calls
1 ^r& (I) (Redial)/q& (M) (Received calls)
2 Select a phone number and dial
Voice call: sVideophone: t&/i
Overseas use
Making a call outside your country of stay (including Japan)
1 ^0 (for 1+ seconds)/enter the country code, area code (city
code) and other party’s phone number/s (Phone)/i (V.phone)
When the area code (city code) begins with “0”, omit the “0” when dialing
(Include “0” when making a call to some countries or regions such as Italy).
Making a call in your country of stay
1 ^enter a phone number
2 s (Phone)/i (V.phone)
Making a call to a WORLD WING subscriber overseas
Even when making a call to the phone in your country of stay, make an
international call to Japan if the call recipient is a WORLD WING subscriber
overseas.
1 ^0 (for 1+ seconds)/81/enter the other party’s mobile
phone number excluding the first “0”/s (Phone)/i (V.phone)
そ
の
他
103
Mail
Composing and sending i-mode mail
1 ^m/[Compose message]/select the [To] field/t&/[Direct
input]*1/enter an address/t&
2 Select the [Sub] field/t&/enter a subject/t&/[Msg]/enter
messages/t&/i
*1 To select a recipient from a phonebook, select [Search phonebook].
*2 To attach a file, select the attachment field (None)/t&/select the file to
attach.
*2
Checking new i-mode mail
1 ^m/[Check new messages]
Replying to i-mode mail
1 In the received mail details screen, C/[Reply/Forward]
2 Select the reply method/t&
3 Compose and send a mail
Forwarding i-mode mail
1 In the received mail details screen, C/[Reply/Forward]/[Forward]
2 Enter an address and send a mail
Displaying a mail in Inbox/Outbox/Unsent messages
1 ^m
2 Select the mailbox/t&
3 Select a mail/t&
※ [ ] appears in the stand-by display when a mail is received.
そ
の
1 ^a/C/[New]/[Phone]
他
2 Enter a name/t&/[]/enter a phone number/t&/select a phone
type icon/t&/[]/enter a mail address/t&/select a mail address
type icon/t&/i/t&
※ Other items can be saved as well.
Adding entries to phonebook
Phonebook
Camera
Shooting still pictures
1 ][Camera]/[Shoot still pic]/t&/t&
Shooting moving pictures
1 ][Camera]/[Shoot movie]/t&/t&/[Save]
Displaying still pictures
1 ][Data box]/[My picture]/select a still picture/t&
Playing moving pictures
1 ][Data box]/[i-motion/Movie]/select a moving picture/t&
Watching 1Seg
Performing automatic channel setting
1 ][1Seg]/[Channel setting]
2 Select the number to save/C/[Auto channel set]/[Yes]
3 Select an area/t&/select a prefecture/district/t&/t&/[Yes]
Selecting a channel list
1 ][1Seg]/[Channel setting]/select a channel list/t&
Watching 1Seg
1 ][1Seg]/[Activate 1Seg]
To record a video of 1Seg programs: While watching 1Seg, i (for 1+
seconds)/(record)/i
To record 1Seg programs as a still picture: While watching 1Seg, i
Watching Videos
1 ][Data box]/[1Seg]
2 [Video] folder/select a video/t&
104
Music Playback
Using Music&Video Channel
1 ][MUSIC]/[Music&Video ch]/select a program/t&
Using MUSIC Player
1 ][Data box]/[MUSIC]/select music data/t&
Network Services
Using Voice Mail Service
Voice Mail Service is a paid option (monthly fees apply) that requires subscription.
Hold the b mark of the FOMA terminal over the scanning device to use as
electronic money or railway tickets, or retrieve ToruCa.
When the FOMA terminal is stolen or lost, immediately contact your provider of
Osaifu-Keitai compatible service for handling methods.
General Notes
Introduction of options and related devices
Battery Pack SH21 FOMA AC Adapter 01 for Global use
FOMA AC Adapter 01/02 Desktop Holder SH23
Main specifications
Size
Weight$$ g (with battery pack attached)
Continuous
talk time
Continuous
stand-by time
Estimated
charge time
* Approximate value
FOMA/3G
FOMA/3G
FOMA AC Adapter 01/02 $$ min
FOMA DC Adapter 01/02 $$ min
$$ (H) × $$ (W) × $$ (D) mm ($$ at
thickest point) (when folded)
Voice call: $$ min
Videophone: $$ min
When mobile: $$ hr
At rest: $$ hr
*
*
*
*
*
*
*
*
そ
の
他
105
Inquiries
General inquiries <docomo Information Center>
s 0120-005-250 (toll free)
※ Service available in: English, Portuguese, Chinese, Spanish, Korean.
※ Available from mobile phones and PHSs.
From DOCOMO mobile phones
(In Japanese only)
r (No prefix) 151 (toll free)
※ Unavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
s 0120-800-000 (toll free)
※ Available from mobile phones and PHSs.
Please confirm the phone number before you dial.
Repairs
From DOCOMO mobile phones
(In Japanese only)
r (No prefix) 113 (toll free)
※ Unavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
s 0120-800-000 (toll free)
Please confirm the phone number before you dial.For Applications or Repairs and After-Sales Service, please contact the
above-mentioned information center or the docomo Shop, etc. near you on the
NTT DOCOMO website or the i-mode site.
NTT DOCOMO website: http://www.nttdocomo.co.jp/english/
そ
の
他
i-mode site: iMenu/お客様サポート (user support)/ドコモショップ
(docomo Shop) (In Japanese only)
Loss or theft FOMA terminal or payment of cumulative
cost overseas <docomo Information Center>
(available 24 hours a day)
From DOCOMO mobile phones
International call access code for the country
you stay
* You are charged a call fee to Japan when calling from a land-line phone,
etc.
※ If you use SH-05B, you should dial the number +81-3-5366-3114
(to enter “+”, press the “0” key for 1+ seconds).
From land-line phones
<Universal number>
International prefix number for the universal
number
* You might be charged a domestic call fee according to the call rate for the
country you stay.
-81-3-5366-3114* (toll free)
-800-0120-0151
*
Failures encountered overseas
<Network Operation Center>
(available 24 hours a day)
From DOCOMO mobile phones
International call access code for the country
you stay
* You are charged a call fee to Japan when calling from a land-line phone,
etc.
※ If you use SH-05B, you should dial the number +81-3-6718-1414
(to enter “+”, press the “0” key for 1+ seconds).
From land-line phones
<Universal number>
International prefix number for the universal
number
* You might be charged a domestic call fee according to the call rate for the
country you stay.
If you lose your FOMA terminal or have it stolen, immediately take the steps
necessary for suspending the use of the FOMA terminal.
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to
a repair counter specified by DOCOMO after returning to Japan.
-81-3-6718-1414* (toll free)
-800-5931-8600
*
108
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
