Selecting a function from Submenu

Submenu screen

When [Submenu] appears in the operation guidance, press C to display functions (Submenu) that can be used in the screen. Select the displayed Submenu with w or the Optical TOUCH CRUISER. If there are multiple pages in the Submenu, change pages with w or the Optical TOUCH CRUISER. Alternatively, press the dial key corresponding to the menu item number (U, V, W, etc.) to select a function. However, some Submenus do not have item numbers.

Support Book

Displaying Support Book

Use this function for unsure operations. After the Support Book appears, check the explanation and operation procedures of each function. In addition, directly start functions that were looked up in the Support Book.

Before Using the Handset

■ Target data when operating functions from Subme nu

When operating functions from Submenu of data list screen, some

functions target at selected data only while other functions target at all data in the list screen. When attempting to operate selected data only, select the data to operate in advance.  Function targeting at selected data only

Example: Edit title, Edit file name, Delete one, etc.

 Function targeting at all data in the list screen

Example: Delete all, Copy all in folder, Move all in folder, etc.

In stand-by, press $/[Support Book].

Select a menu or item/t.

: To start functions directly: Select the function to start/t/[Yes].

FOMA card

Using FOMA card

A FOMA card is an IC card that records personal information, such as phone numbers. A FOMA card can store phonebook data and SMS. By switching FOMA cards, multiple FOMA terminals can be used for different purposes as needed.

If a FOMA card is not inserted, transmission functions such as voice/

Videophone calls, i-mode, mail transmission and pa cket transmis sion are not available on the FOMA terminal.

Inserting/Removing FOMA card

Before inserting or removing the FOMA card, turn off the power, position

the back facing upwards and remove the battery pack. Close and hold the FOMA terminal securely with your both hands.

■ Inserting FOMA card

Notch IC (gold)

Tray

Fit the notch of the FOMA card to that of the tray.

Tab

Hook a finger on the tab and pull the tray out (1).

: Pull out the tray straight until it stops.

Before Using the Handset

Hold the FOMA card with the IC

facing up and set on the tray (2).

Push the tray all the way in (3).

■ Removing FOMA card

Hook a finger on the tab, pull the tray out (1) and

remove the FOMA card (2).

: Do not allow the FOMA card to fall when removing it.

Inserting or removing the FOMA card forcibly may damage the card or

deform the tray. Use caution.

Refer to the FOMA card user’s guide for more information on t he FOMA

card.

Do not misplace the FOMA card once it is taken out. When the tray falls off, slide the tray in straight along the guide rail.

Security codes

The FOMA card has a “PIN1 code” and a “PIN2 code”. Both are set to [0000] by default but can be changed to a four- to eight-digit number by the user (nP. 110).

FOMA card security functions

The FOMA terminal has built-in FOMA card security functions (FOMA card restriction functions) as functions for protecting personal data and files. When data or files are retrieved using any of the following methods or

i-appli is running with the FOMA card inserted into the FOMA terminal, FOMA card security functions are automatically set in the retrieved data or files.  When a file such as an image, melody or PDF is downloaded from a

site or Internet web page

 When a site or Internet web page is added in screen memo  When i-mode mail with a file attached is received  When i-appli is running

Data, files or software with FOMA card security functions run only when

in use with the FOMA card inserted at time of acquisition. Display, play, attach to i-mode mail, run software, send data using Ir communication function and iC communication function, and copy to microSD Card can be executed. These operations cannot be performed if a different FOMA card is inserted.

The following indicates the data for which FOMA card security is set.

One’s own FOMA card security functions are set for downloaded data, files attached to received mail and i-appli that have been run, allowing viewing and playback of data.

When another’s FOMA card is inserted, data with one’s own FOMA card security functions set cannot be viewed or played.

One’s own FOMA card

Another’s FOMA card

Different FOMA card

inserted

 Melody   Screen memo  Chaku-uta®/Chaku-uta full  Chara-den  File attached to Message R/F  i-motion  ToruCa (details) image  PDF data  Image inserted to Deco-mail or signature  Kisekae Tool  Videophone picture memo  Machi-chara  i-appli (including i-appli stand-by)  Download dictionary  Download font  Contents transfer compatible data  Image in Message R/F  Music&Video Channel program  Deco-mail template with data which FOMA card security functions are

set

 Decome-Anime Template  e-book/e-dictionary/e-comic saved in the [Comic] folder  File attached to i-mode mail other than the following

• ToruCa • Phonebook • Schedule

• Bookmark • Documents

※ “Chaku-uta” is a registered trademark of the Sony Music

Entertainment (Japan) Inc.

The following indicates the settings saved in the FOMA card.

 Own number  PIN setting  Select language  SSL/TLS certificates  SMS center  SMS expiry  SMS input character

The following explanation refers to the FOMA card inserted at time of

data/files retrieval as “one’s own FOMA card” and other FOMA cards as “another’s FOMA card”.

Image (including animation and Flash movie)

Before Using the Handset

When one’s own FOMA card is replaced with another’s FOMA card, the

data or files for which FOMA card security functions are set cannot be set as stand-by displays or ring tones.

When a FOMA card is replaced with another’s FOMA card, FOMA card

security functions are activated and if data or file retrieved from a site is set as the stand-by display or ring tone, the setting is reset to the default. When one’s own FOMA card is re-inserted, the setting returns.

Example: When setting [Melody A], for which FOMA card

When one’s own FOMA card is taken out or is replaced with another’s FOMA card, ring tone returns to default setting. When one’s own FOMA card is put back, the ring tone returns to [Melody A].

FOMA card security functions cannot be set for data received using Ir

communication or data transmission functions, and still/moving pictures, etc. shot with the FOMA terminal.

It is possible to move or delete data or files for which FOMA card

security functions are set even when another’s FOMA card is inserted.

Running i-appli by selecting highlighted text in i-mode mail details

screen cannot be performed or retrieved when FOMA card security functions are set.

security functions are set, as a ring tone

Continued on next page

If the FOMA card is replaced with another’s FOMA card after i-appli

Face the side with a recycle mark up

Tabs

Battery pack

Battery pack connector terminal side

stand-by is set, the set i-appli cannot be activated in stand-by, and the image set in Stand-by display appears.

Before Using the Handset

FOMA card type

Note the following differences between “FOMA card (blue)” and “FOMA card (green/white)” used on the FOMA terminal.

Function

Number of phone number digits available in the FOMA card phonebook

Client certificate operations for FirstPass

Use of WORLD WING Not available Available P. 428 Service Numbers Not available Available P. 418

About WORLD WING

WORLD WING is a DOCOMO’s FOMA international roaming service that makes it possible to use the mobile phone number registered in Japan to make and receive calls even overseas by the FOMA card (green/white) and supported FOMA terminal. If subscribed to the FOMA service after September 1, 2005,

subscription for “WORLD WING” is not required. However, if subscription for “WORLD WING” is canceled at or after subscription for the FOMA service, subscription for “WORLD WING” is required again.

If subscribed to the FOMA service before August 31, 2005 but not

subscribed to “WORLD WING”, subscription for “WORLD WING” is required.

Some payment plans are not available. When the FOMA card (green/white) is lost or stolen overseas, promptl y

contact DOCOMO and conduct a procedure for canceling the use of service. Refer to General Inquiries on the back of this manual for inquiries. Note that transmission/calling charges after the FOMA card is lost or stolen are incurred to the subscriber.

FOMA card

(blue)

Up to 20 digits Up to 26 digits P. 79

Not available Available P. 183

FOMA card

(green/white)

Page

Attaching/Removing battery pack

Use the Battery Pack SH22 exclusive to the FOMA terminal.

Turn off the power, close the FOMA terminal, and hold it in your both

hands before attaching or removing the battery pack.

■ Attaching battery pack

Push the back cover in the direction of the arrow (1),

slide approximately 2 mm (2) and remove the back cover (3).

Attach the battery pack (4).

: The FOMA terminal has tabs that make it easy to attach. Attach the

battery pack with a recycle mark side faced up.

Attach the back cover (5).

Tab

: Place the back cover as shown in the illustration and then push the

back cover and slide.

■ Removing battery pack

Follow step 1 of “Attaching battery pack” to remove

the back cover. Remove the battery pack.

: The battery pack has a tab that makes it easy to remove. Hook a

finger on the tab to prevent excessive force on it and remove the battery pack upward.

Using unnecessary force when attaching or removing the battery pack

may damage the connector terminal for the battery pack (charger terminal) on the FOMA terminal.

Securely close the back cover. If not closed securely, the back cover

may come off and the battery pack may fall out due to vibration.

Charging

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery using the exclusive AC or DC adapter (sold separately) before use.

■ Cautions while charging

Do not charge for long periods of time with the power left on. If the FOMA

terminal is left on after charging is complete, the battery pack charge decreases. In such cases, the AC or DC adapter charges the battery again. However, depending on when the FOMA terminal is disconnected from the AC or DC adapter, the battery charge level may be low, the battery alert tone may sound, or the battery may only be usable for a short time.

When the battery is empty and terminal is recharging, charging LED may

not illuminate immediately.

If the battery empty alert is displayed, the alert tone sounds and the

power cannot be turned on, charge the battery for a while.

If the battery empty alert is displayed and charging begins within 60

seconds of the alert tone, the status returns to normal.

While charging, terminal may not turn on even when charging LED is

illuminated in red. Charge longer and try turning power on again.

Frequently recharging the battery when its power is still remaining

enough may shorten the life of the battery pack. It is recommended to use the battery to a certain level before recharging.

■ Estimated charge times and LED display

The following figures are estimated times for charging an empty battery pack with the FOMA terminal turned off.

FOMA AC Adapter 01/02 Approx. $$ min FOMA DC Adapter 01/02 Approx. $$ min

Charging LED illuminates in red while charging, and it turns off when

charging is completed.

Before Using the Handset

Continued on next page

Check that the battery pack has been properly attached when charging

LED flashes red. The LED also flashes red when the battery pack has reached the end of its service life.

The battery pack can also be charged with the FOMA terminal turned on

Before Using the Handset

(Battery icon flashes during charging).

When the battery becomes warm, charging may automatically stop even

if the battery has not been fully charged. Charging resumes after the temperature lowers to an appropriate temperature. While charging is stopped, charging LED turns off (Battery icon flashes while stopped).

■ Estimated times of use when fully charge d

Continuous talk time

Continuous stand-by time

1Seg watching time Approx. $$ min

FOMA/3G Voice call: Approx. $$ min

Videophone call: Approx. $$ min

(Substitute image: Approx. $$ min) GSM Voice call: Approx. $$ min FOMA/3G3G/GSM

setting: 3G 3G/GSM

setting: AUTO

GSM 3G/GSM

setting: AUTO

When mobile: Approx. $$ hr

At rest: Approx. $$ hr

Continuous talk time is estimated as the usage time at normal

transmission signal strength, and continuous stand-by time is estimated as the usage time while moving with the FOMA terminal folded at normal signal strength. Using i-mode reduces talk (transmission)/stand-by time. When i-Channel is subscribed, information is automatically received and updated, so talk (transmission)/stand-by time will be redu ced. In addition, when shooting or editing an image, watching 1Seg, composing i-mode mail, activating the downloaded i-appli or the i-appli stand-by, or using MUSIC Player, i-motion player, Bluetooth function or data communication, the talk (transmission)/stand-by time will be reduced even if calls or i-mode transmission are not made. Some i-appli software may continue transmission even after downloading. To avoid this, set not to connect in advance.

The actual usage time is a combination of stand-by time and talk time,

and the longer the talk time, the shorter the stand-by time becomes.

1Seg watching time is estimated as the watching time at normal

transmission signal strength with the Stereo Earphone Set 01 (sold separately) used.

Talk (transmission)/stand-by time may be reduced by about half or 1Seg

watching time may be shortened depending on battery pack status, function used, temperature and other environmental conditions, or signal strength (no signal or weak signal).

■ Battery pack service life

Battery pack is a consumable product. Service time per charge is

gradually reduced every time the battery is charged.

When service time per charge is reduced to about half of the default time,

this means that the battery pack is approaching the end of its service life. In such a case, it is recommended to replace the battery pack as soon as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life but this will not cause problems.

If i-appli, Videophone, or 1Seg is used while charging for a long time, the

service life of the battery pack may become shorter than estimated.

To prevent damage to the environment, bring used battery

packs to a docomo service counter, a docomo agent or a recycle center.

■ About charging batteries

Connector (Face the side with the arrows up)

External connector terminal cover

External connector terminal

Charging LED

100V AC outlet

For AC adapter For DC adapter

Cigarette lighter socket

Release buttons

Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately),

FOMA AC Adapter 01 for Global use (sold separately), or FOMA DC Adapter 01/02 (sold separately).

FOMA AC Adapter 01 covers only 100V AC. FOMA AC Adapter 02/

FOMA AC Adapter 01 for Global use covers from 100 to 240V AC.

The shape of the plug for the AC adapter is for 100V AC (for domestic

use). To use the AC adapter of 100 to 240V AC overseas, a conversion plug adapter that is compatible with the voltage of your country of stay is required. Do not use a transformer for use overseas to charge the battery.

Charging by using AC adapter/DC adapter

[Read “FOMA AC Adapter 01/02 (sold separately) and FOMA DC Adapter 01/02 (sold separately) user’s guide” carefully.]

Battery pack can be charged even with the FOMA terminal opened or in

the Cycloid position.

Open the external connector terminal cover and insert

the AC or DC adapter connector horizontally into the external connector terminal (1).

: Check the direction (See diagram) of

the connector, keep it parallel with the FOMA terminal and securely push all the way in until it clicks.

When inserting the AC adapter power plug into an

outlet or inserting the DC adapter power plug into a car cigarette lighter socket, Charge start sound is heard, charging LED illuminates, and charging starts.

When Charge end sound is heard and charging LED

turns off, charging is complete.

: When removing the connector, always hold the release buttons on

both sides (1) and unplug it horizontally (2).

Continued on next page

Before Using the Handset

Do not forcibly insert or remove. May cause damage to the external

Connector (Face the side with the arrows up)

FOMA AC Adapter 01/02

100V AC outlet

Charging LED

connector terminal and the connector.

Pull the adapter out of the outlet or cigarette lighter socket if it will not be

Before Using the Handset

used for a long time.

Do not forcefully pull the external connector terminal cover. May

damage the cover.

Do not place objects near the FOMA terminal when charging. May

damage the FOMA terminal.

When using a DC adapter

The DC adapter should only be used in negative grounded vehicles (12

and 24V DC).

Do not use with the car engine shut off. May drain the car battery. The DC adapter fuse (2A) is a consumable. For replacement, purchase

a new fuse at a local automobile supply shop.

Refer to the FOMA DC Adapter 01/02 user’s guide for details.

Charging by using desktop holder

Battery pack can be charged even with the FOMA terminal opened or in

the Cycloid position.

Face the side with the arrows of the AC adapter

connector up and insert it into the connector terminal of the desktop holder (1).

: Keeping the connector parallel with the desktop holder, securely

push it all the way in until it clicks.

Insert the AC adapter power plug into an outlet (2).

When placing the FOMA terminal in the desktop

holder, Charge start sound is heard, charging LED illuminates, and charging starts.

: Place the FOMA terminal as the figure shows (3), and push it in the

direction of the arrow (4) until it clicks.

When Charge end sound is heard and charging LED

turns off, charging is complete.

: Hold the desktop holder and lift the FOMA terminal out.

Pull the AC adapter out of the outlet when left unused for a long period

of time.

When Charge start sound is not heard or when charging LED does not

illuminate, check that the FOMA terminal is placed securely in the desktop holder (except when terminal is turned off, Manner mode is set or Charge start sound is Silent).

When placing the FOMA terminal in the desktop holder, be careful that

the strap is not caught in between the handset and the desktop holder.

When the FOMA terminal placed in the desktop holder is set to the

81 to 100%

Battery is sufficiently remaining.

61 to 80% Battery is remaining.

41 to 60% Battery level is low.

21 to 40% Battery level is very low.

1 to 20%

Battery is almost empty. Charge the battery.

Battery is empty (Power will turn off soon).

Cycloid position, operate while holding it so as not to come off from the desktop holder.

Battery level

Checking battery level

If the battery icon is changed to [電池残量$$], battery level is displayed in

percentage. However, [&] appears when battery level is 100% while [(] appears when battery level is 4% or less.

The battery icon and Percentage are rough indications. If the FOMA terminal is left for a long time or the power remains on, the

battery level may reduce even after charging is complete.

■ Changing design of battery icon <Battery icon>

In the Custom menu, select [Settings]/[Battery]/

[Battery icon]/i. Select an image/i.

Checking battery level with sound and dis p lay

In the Custom menu, select [Settings]/[Battery]/

[Battery level].

: Battery level is displayed in percentage and graphic. In addition, it is

notified by the number of the battery level sound according to its remaining amount.

Graphic Number of beep sound

Five times Four times

Three times

Twice

Once

: Wait approximately 5 seconds and the display disappears. : The battery level sound is heard at the volume set in Key sound

(nP. 90).

: If the Manner mode is set, the battery level sound follows the setting

of the Manner mode.

If battery runs out

[Battery empty. Unsaved data will be lost. Ending current operation] appears if battery starts to run out (Press t to clear the message). After a while, an alert tone sounds. The warning screen stating that the battery runs out appears, handset operations are disabled and power turns off after approximately 60 seconds. During a voice/Videophone call, the alert tone sounds and [Battery

empty. Unsaved data will be lost. Ending current operation] appears. The call is disconnected after approximately 20 seconds. At the same time, the screen above appears and after approximately 60 seconds, the power turns off.

Alert tone does not sound when Manner mode or Public mode (Drive

mode) is set (Alert tone sounds during a call).

Before Using the Handset

Power ON/OFF

Stand-by display

Turning power ON/OFF

Before Using the Handset

Turning power ON

Press H (for 2+ seconds).

: It may take some time for the wakeup screen to appear. : The wakeup screen appears followed by the initial settings screen.

Proceed to Initial setting (nP. 48).

: If initial settings have been completed, the

screen shown on the right appears when power is turned on. This screen is called the “stand-by display”.

Welcome mail

: “Welcome-ドコモ動画#”

(Welcome-docomo-doga#) and “緊急速報

「エリアメール」のご案内” (Information of Early

Warning “Area Mail”) are saved by default.

: To check a welcome mail: In stand-by, press

t/select the stock icon [C] (mail message)/t.

• For details on the following operations nP. 138

If initial settings are not yet completed, the setting screen appears every

time the power is turned on.

If the FOMA card is not inserted, [Insert UIM] and a FOMA card error

appear (nP. 31).

When [Enter PIN1 code] appears, enter the PIN1 code (nP. 109). When a FOMA card is replaced with a new card, the terminal security

code (four to eight digits) must be entered after turning on the terminal. If a correct terminal security code is entered, stand-by display appears. When a wrong terminal security code is entered five times, the power is turned off. However, turning on the power again is possible.

When [A] appears, the handset is outside the service area or in a

place with no signal. Move to a place where the icon disappears.

Turning power OFF

Press H (for 2+ seconds).

: It may take some time for the power to be turned off (The end screen

appears on the display until the power is turned off).

Select language

Changing screen display to English

In the Custom menu, select [設定]/[一般設定]/

[Bilingual]/[English].

: To switch the display language from English to Japanese: In the

Custom menu, select [Settings]/[General settings]/[Select language]/[日本語].

If a FOMA card is inserted, settings are saved to the FOMA card as

well. When the setting of the FOMA terminal handset and the setting of the inserted FOMA card are different, the setting in the FOMA card is prioritized.

Initial setting

Making initial setting

The initial settings screen appears automatically when the power is turned on for the first time. Each setting item can also be set from Menu (When the initial settings are complete, the stand-by display appears).

 Date and time settings  Change terminal security code  Key sound  Location request menu  Set all font size When items that have not been set remain, the setting screen appears

every time the power is turned on.

Alternatively, select [Settings]/[Initial setting] in the Custom menu to

display the setting screen.

Set the date and time (nP. 49).

Set the Key sound (nP. 90).

Set GPS Location provision ON/OFF (nP. 304).

Set the font size collectively (nP. 105).

: When the initial settings are complete, the software update function

confirmation screen appears. Read the description and select [Agree] (When the initial settings are made from the menu or the software update is set to other than [auto-update], the confirmation screen does not appear).

Press H to cancel the initial settings.

Date settings

Setting date and time

Set the date and time on the FOMA terminal.

In the Custom menu, select

[Settings]/[General settings]/[Date settings].

Select the [Auto time correction] field/t/select the

setting.

; Select [ON]/i. ; Select [OFF]/select the [Date] field/t/enter the date/t/

select the [Time] field/t/enter the time (24-hour format)/ t/i.

• When entering month, day and time, add 0 before numbers one through nine (example: 01, 02, 03, etc.).

• Set the date and time from 00:00 January 1, 2001 to 23:59 December 31, 2050.

When Limit settings is set to [Enable], the terminal security code must

be entered in the Date settings.

The date and time that are set are saved even if the battery pack is

removed, but if the battery pack remains removed for approximately 30 seconds or more, the settings are reset. Also, if the battery remains empty, the settings may be reset. When this happens, set again after charging the battery.

If the date and time are not set correctly, the following functions cannot

be used properly.

 Redial, Received calls  Auto power ON/OFF  Alarm  Schedule  SSL/TLS (authentication)  i-appli Auto start  Starting i-appliDX  Reception, Recording  Machi-chara  Software update  Pattern definitions update  Record message (voice), Record message (Videophone calls)  Camera image titles/shooting date  Playback of i-motion or music data with expiration date/period for

replay

 View of e-books/e-dictionaries/e-comics with expiration date/period

for browse

When [Auto time correction] is set to [ON]

When the power is turned on, the FOMA terminal adjusts the time by

connecting to the network’s time information.

If the FOMA terminal does not adjust the time even when the power is

turned on, turn off the power and restart.

Time may not be adjusted depending on the signal status. Time may be off by a few seconds. When time difference is adjusted overseas, the local time and date and

[!] appear in Redial, Received calls, Received/Sent messages history (SMS only), received/sent mails list and location history list. The received/sent mails are not displayed in order of the displayed time and date but the mail reception/send.

[!] does not appear in the Unsent messages for mail messages. If the

date order display is set for the Unsent messages, unsent mails are displayed in the order of the displayed time and date.

Time correction may not be performed depending on the overseas

telecommunications carriers. Change the time zone manually.

Before Using the Handset

Continued on next page

During overseas use, Japan time and local time (or time set in City)

appear in the dual display except for the following cases.  When Auto time correction is set to [ON] and time correction

Before Using the Handset

information is not being received from an overseas network

 When Auto time correction is set to [OFF] and City is set to the city in

the same time zone as Japan

■ Changing time zone manually <City>

In the Date settings screen, select the [Auto time

correction] field/t/[OFF]/C. Select a time zone/t.

Select a city/t/i.

Notify caller ID

Notifying the other party of your phone number

Display your number (caller ID) on the other party’s phone (display) when making a voice/Videophone call.

Handset number (caller ID) is important personal information. Be very

careful about your caller ID setting.

The Notify caller ID function is available only on compatible phone

devices.

Setting Notify caller ID/No caller ID in advance

In the Custom menu, select [Settings]/[NW

Services]/[Notify caller ID]. Select [Activate/Deactivate].

: To check the setting: Select [Check setting].

Select the setting.

: To notify caller ID: Select [Yes]. : To not notify caller ID: Select [No].

Notify caller ID setting cannot be set from outside the service area.

Own number

Checking your own phone number

When checking your own phone number during a call nP. 54

In the Custom menu, press 0.

: Alternatively, select [Phone]/[Own number] (or [Settings]/

[General settings]/[Check status]/[Own number]).

: To switch between Number A and Number B (when 2in1 [Dual mode]

is used): Press i.

When changing the Number B of 2in1, use any of the following methods

to obtain the correct Number B.  Set 2in1 function OFF and then perform 2in1 setting again to set

2in1 function ON

 Check the 2in1 subscription

When a FOMA card exchange (2in1 subscriber b 2in1 nonsubscriber)

is performed, set 2in1 function OFF.

When a FOMA card exchange (2in1 subscriber b 2in1 subscriber) is

performed, check the 2in1 subscription.

For details on Owner information nP. 384

+ 28 hidden pages
