Use to select or execute the menus that appear in the operation guidance.
The following shows the keys assigned to select or execute the menu items
that appear in the guidance.
■ Operation guidance menu
In the operation guidance, menus appear according to the function being
used and situation.
The following table describes examples of the main operation guidance
menus that appear.
OKSets the selected item
SubmenuDisplays the Submenu
AgreeChecks selected image, music, etc.
BackReturns to the previous screen
Play/StopPlays/Stops i-motion, music, etc.
FullDisplays selected images, etc. in full screen
Show allDisplays sorted files, etc. as a list
1/1 or ZoomeDisplays selected images, etc. in actual/reduced size
MailDisplays the compose message screen
SendSends a mail
CancelCancels the operation such as receiving a mail
SelAll/ClrAllSelects/Disables all selectable items
Page ▲/Page ▼
CloseCloses the Submenu, etc.
(Up to 50 items can be selected/disabled depending
on the function)
Scrolls the display by page
Viewing display
Icons are shown in the order of main display and sub display.
Main display
Before Using the Handset
Continued on next page
31
Sub display
1st hi82 b 2
k l
c
z2<
y 2
The following shows a screen when Sub Clock display (nP. 94) is set to
[Stdby clock(H・L)].
Before Using the Handset
1Signal status
Indication of the signal strength
]/a
When [A] appears, the handset is outside the service area or in a
place with no signal. Signal icon can be changed (nP. 99).
2Battery level (nP. 47)
"/b
Flashes during charging.This icon can be changed (nP. 47, P. 99).
3i-mode/Full Browser (nP. 159, P. 162)
7 = IJA
A B N O
4SSL/TLS (nP. 159, P. 162)
When this icon appears while Multi Assistant is used, function such as
i-mode, Full Browser, i-appli or Software update is being used with
Multi Assistant.
32
]nop
StrongWeak
Indicates battery level
Indicates i-mode/Full Browser status
SSL/TLS pages are viewed
o
5i-appli (nP. 257)
i-appli is being activated
G
i-appli stand-by is being activated
i-appli stand-by is set
N
i-appliDX is being activated
I
i-appliDX stand-by is being activated
i-appliDX stand-by is set
Q
*i-appli is set as the stand-by display, but cannot be used.
Does not appear in the i-Widget screen.
6GPS (nP. 295, P. 298)
Location request menu is set to [Loc. provision:ON]/
A (blue)
A (gray)
7Ir communication/External device
t (green)
t (red)
8i-mode mail/SMS/Area Mail received (nP. 132)
* Appears when Area Mail is received.
[Reject No. unset]
Location request menu is set to [Permission sched.] and
Location provision is permitted
Location request menu is set to [Permission sched.] and
Location provision is rejected
GPS positioning
B
Data is communicated with another device using the Ir
communication function (nP. 346)
J
Data is sent using the Ir remote control (nP. 349)
Connected to an external device and transmitting
packets
Connected to an external device and sending/receiving
packet data
Connected to an external device and transmitting 64K
u
data
Indicates the status of the i-mode mail/SMS/Area
UhH
v[/x
Mail reception
*
Indicates the status of the memory to store
received mail
*
*
9Message R/F received (nP. 150)
ABJ
aStorage status of i-mode center (nP. 132, P. 150)
WGIX
STKL
May not appear even if messages are held at the i-mode center.
bmicroSD Card (nP. 329)
^ (gray)/m
^ (pink)/l
cClock display (nP. 49)
Small clock icon can be changed (nP. 99).
d1Seg being recorded (nP. 230)
eRecord message (nP. 68)
When there are messages, [D] to [P] appears, indicating the total
number of both types of messages. When there are three Record
messages (voice calls) and two Record messages (Videophone), [k]
appears.
fSilent (nP. 87)
gVibrator (nP. 89)
hManner mode (nP. 91)
Z/f
Indicates the reception status of the Message R/F
Indicates the status of the memory to store Message R/F
Indicates the storage status of the mail and
Message R/F
microSD Card is inserted
microSD Card is being used
a/r
a
]
[
b
Appears when microSD Card is not recognized
1Seg is being recorded
Record message is set
The phone ring volume [Silent] is set
Vibration mode is set
Manner mode is set
iPublic mode (Drive mode) (nP. 66)
_/d
ji-appli call (nP. 273)
a
kIC card lock (nP. 284)
H/c
lRestriction (nP. 108, P. 114)
K (red)/e
K (blue)/e
mHands-free (nP. 53)
; (red)
; (green)
nAlarm (nP. 232, P. 362, P. 367)
* Appears only when an Alarm is set for that day.
Public mode (Drive mode) is set
New i-appli call
IC card is locked
R/i
S
T
U/e
V/e
W/e
X/e
\
Secret mode is set
Secret data is being edited
Keypad dial lock
All lock is set
Function lock is set
Keypad dial lock and Function lock are set
Secret mode, Function lock and Keypad dial lock
are set
Side key lock, Secret mode, Function lock and
Keypad dial lock are set
Side key lock is set
Hands-free in progress
USB hands-free in progress
Alarm is set
Schedule alarm is set
Reception reserve alarm is set
Recording reserve alarm is set
Wakeup TV is set
*
*
Continued on next page
Before Using the Handset
*
*
33
oMusic&Video Channel program reservation (nP. 241)
Appears 12 hours before Music&Video Channel program
0
distribution
pi-mode mail send reservation (nP. 132)
Before Using the Handset
Mail with send reservation
=
Mail failed to be automatically sent
;
qEarphone/microphone connection (nP. 378)
While Auto answer setting is set to [ON] with an
s
earphone/microphone (sold separately) connected
rUSB mode (nP. 340)
FOMA USB Cable with Charge Function 02 (sold
x
separately) is connected in the Communication mode
sFOMA card error
R/j
B/h
tSelf mode (nP. 110)
g/g
uVeilView (nP. 103)
Does not appear while displaying d or v.
v3G
Appears when FOMA card is malfunctioning or not
inserted
Appears when a card other than the FOMA card is
inserted
Self mode is set
VeilView is set
P
3G network (Packet transmission is available)
S
3G network (Packet transmission is available/Call is not
Q
available)
3G network (Packet transmission is not available)
R
wStatus of Comics setting (nP. 355)
Frame display is set
I
Page display is set
H
Does not appear while displaying m or y.
xToruCa (nP. 286)
Unread ToruCa
Q
Does not appear while displaying m, w or y.
yReceiving information (nP. 192)
C/z
Does not appear while displaying m.
zMultitask (nP. 360)
Indicates functions that are running.
While two or more functions are running, the Multitask icon also
appears on the sub display.
g
*
h
t
#
i
C
j
l
New information
Four or more applications
are running
Videophone
Voice call
Phonebook
Modem transmission
(appears during data
transmission)
Software update
Map/GPS
Receive via Ir/iC/USB
communication
i-appli
Shoot still picture
2
Shoot moving picture
3
Character reader (OCR)
4
Bar code reader
5
Card reader
]
Information reader
,
Motiondeco
[
Shotdeco
)
Voice recorder
v
Schedule
w
Text memo, Stand-by memo
y
Calculator
z
Manga&BookReader
6
34
i-mode, i-Channel, Full
Message
Number of entries
Stock icon
Browser, Internet movie
m
player
i-concier
/
Receive information
X
Mail, SMS, Message R/F,
p
Check new messages
Mail/Decome-Anime/SMS
q
being composed
Received calls
|
Received messages history
;
Own number
"
Redial
!
Sent messages history
:
<Operation in progress
A screen other than stand-by appears in the main display
w
Does not appear while displaying z.
microSD Card is referred to as [microSD] or [SD] on the FOMA terminal
(nP. 329).
Some of the screen shots in this manual have been modified or
abbreviated.
The display for the FOMA terminal is manufactured using
high-precision technology, but it may occasionally contain dots that fail
to light or that remain permanently lit. This is not a malfunction.
The display time of sub display follows the light duration setting.The icon of sub display cannot be changed.
Quick search
=
ToruCa
>
Alarm
{
Timer
8
microSD
}
General settings
9
Voice memo/Record message
0
1Seg
f
Reception reserve/
Recording reserve alarm
^
sounds
Data Security Service
*
Data box
u
MUSIC
s
Checking notices with stock icon
Display stock icons in stand-by when a call is missed or new mail is
received. In stand-by, select stock icons to check notice details.
*1 When the 2in1 mode is set to [Dual mode], the number of [A mode] and
[B mode] appears each.
*2 The displayed message differs depending on the menu screen.
In stand-by, a stock icon appears/t.
1
: When both the stock icon and the popup messa ge appear, s witch the
Select the stock icon/t.
2
: After the details are checked, the stock icon and message disappear.
Stock icons do not appear while the i-motion set as stand-by is played
or the i-appli stand-by is being activated.
Send loc - FailedP. 300
New i-appli callP. 273
Custom menu/Basic menu
selection between the stock icon and the popup message with u.
*2
Displaying and operating i-Widget
In the i-Widget screen, multiple Widget Appli can be activated
simultaneously and viewed as a list.
For details on operation of i-Widget nP. 278
P. 38
Activating i-concier with popup message
Display popup messages in the stand-by display
when information is received. Activate i-concier with
the popup messages to check information details.
36
In stand-by, a popup message appears/t.
1
Select the popup message/t.
2
: The popup message disappears after activating i-concier.
Calendar or Stand-by memo does not appear while a popup message
appears.
Setting and selecting menu
ta
Stand-by displayCustom menuBasic menu
Set, change or save functions from the menu screens.
Menus are classified by function (nP. 422).
The explanations in this manual are based on how to retrieve a function
from the Custom menu.
Setting start menu <Menu priority>
Set the start menu that displayed when t is pressed in stand-by.
Start menuCharacteristics
Custom menu The preset Kisekae Tool (nP. 97) can be selected and
Basic menuSelect the icon displayed on the menu to retrieve the
In stand-by, press t/[Settings]/[Disp/LED/Power
1
saver]/[Menu priority].
Select the start menu/t/[Yes].
2
set. Each Kisekae Tool consists of different functions and
designs. Kisekae Tools can be do wnloaded from site s and
used.
Preset Kisekae Tools
White Black Pink
Blue Green 拡大メニュー (Large)
シンプル (Simple) ダイレクトメニュー
※ Preset Kisekae Tools differ depending on the FOMA
terminal handset color.
function. Also, input the function number, which is
assigned to setting menu, to quickly retrieve the function
to be used.
Switching set start menu temporarily
Switch the start menu temporarily. When the stand-by display reappears,
the start menu returns to the one set in Menu priority.
Before Using the Handset
■ Submenu operations for the Custom menu screen
[Assign function]nP. 98
[Rst func asgnment]nP. 98
[Reset menu screen]nP. 98
[Reset menu history]nP. 98
[Menu priority]nP. 37
[Operation guide]/select an item/t
37
■ Submenu operations for the Basic men u screen
wt
Custom menuWhen [Camera]
appears
When the camera
(shooting still
pictures) is activated
ut
Basic menuWhen [Camera func]
appears
When the camera
(shooting still
pictures) is activated
wtut
[Icon settings]
/[Icon image]nP. 100
Before Using the Handset
/[Dsp icon name]nP. 100
[Set background]nP. 100
[Reset menu screen]nP. 100
[Menu priority]nP. 37
[Operation guide]/select an item/t
Retrieving a function from each menu
For details on operating shortcut menu nP. 370
For details on the available functions nP. 422
Use w in either menu.
Press the dial key corresponding to the menu item number (U, V, W,
etc.) to select a function. However, in the Custom menu, a function may
not be selected by using the menu item numbers.
The method for selecting functions may differ depending on the Kisekae
Tool set for the Custom menu.
Press c to re-select a function, and the previous screen reappears.
Press H to return to stand-by.
When a stock icon (nP. 35) appears in stand-by, select [G] to show
the each menu.
The way of activating camera (shooting still pictures) with Multi guide key
is explained as an example below.
38
■ Retrieving from the Custom menu
■ Retrieving from the Basic menu
In the Basic menu, input the function number, which is assigned to
setting menu, to quickly retrieve the function to be used (nP. 422).
When the Custom menu screen is changed by Kisekae Tool, the
operation may differ from the description in this manual. In this case,
switch the menu screen to the Basic menu (nP. 37) or perform the
Reset menu screen (nP. 98).
Retrieving a function from the Simple menu
Simple menuWhen [Camera func]
appears
When the camera
(shooting still
pictures) is activated
wtwt
Submenu screen
Refer to the menu list for details on [シンプル(Simple)] (nP. 442).
Selecting a function from Submenu
When [Submenu] appears in the operation guidance,
press C to display functions (Submenu) that can be
used in the screen. Select the displayed Submenu
with w.
If there are multiple pages in the Submenu, change
pages with w.
Alternatively, press the dial key corresponding to the
menu item number (U, V, W, etc.) to select a
function. However, some Submenus do not have item
numbers.
■ Target data when operating functions from Submenu
When operating functions from Submenu of data list screen, some
functions target at selected data only while other functions target at all
data in the list screen. When attempting to operate selected data only,
select the data to operate in advance.
Function targeting at selected data only
Example: Edit title, Edit file name, Delete one, etc.
Function targeting at all data in the list screen
Example: Delete all, Copy all in folder, Move all in folder, etc.
Support Book
Displaying Support Book
Use this function for unsure operations. After
the Support Book appears, check the
explanation and operation procedures of each
function. In addition, directly start functions
that were looked up in the Support Book.
In stand-by, press $/[Support Book].
1
Select a menu or item/t.
2
: To start functions directly: Select the function to start/t/[Yes].
Before Using the Handset
39
FOMA card
Notch
IC (gold)
2
Tray
3
Fit the notch of the FOMA card to
that of the tray.
1
Tab
1
2
Using FOMA card
A FOMA card is an IC card that records personal information,
Before Using the Handset
such as phone numbers. A FOMA card can store phonebook data
and SMS. By switching FOMA cards, multiple FOMA terminals
can be used for different purposes as needed.
If a FOMA card is not inserted, transmission functions such as voice/
Videophone calls, i-mode, mail transmission and packet transm ission are
not available on the FOMA terminal.
■ Removing FOMA card
Hook a finger on the tab, pull the tray out (1) and
1
remove the FOMA card (2).
: Do not allow the FOMA card to fall when removing it.
Inserting/Removing FOMA card
Before inserting or removing the FOMA card, turn off the power, position
the back facing upwards and remove the battery pack. Close and hold
the FOMA terminal securely with your both hands.
■ Inserting FOMA card
Hook a finger on the tab and pull the tray out (1).
1
: Pull out the tray straight until it stops.
Hold the FOMA card with the IC
2
facing up and set on the tray (2).
Push the tray all the way in (3).
3
40
Inserting or removing the FOMA card forcibly may damage the card or
deform the tray. Use caution.
Refer to the FOMA card user’s guide for more inf ormation on the FOMA
card.
Do not misplace the FOMA card once it is taken out.When the tray falls off, slide the tray in straight along the guide rail.
Security codes
The FOMA card has a “PIN1 code” and a “PIN2 code”.
Both are set to [0000] by default but can be changed to a four- to eight-digit
number by the user (nP. 108).
FOMA card security functions
One’s own FOMA
card security functions
are set for
downloaded data, files
attached to received
mail and i-appli that
have been run,
allowing viewing and
playback of data.
When another’s
FOMA card is
inserted, data with
one’s own FOMA
card security
functions set cannot
be viewed or played.
One’s own
FOMA card
Another’s
FOMA card
Different FOMA card
inserted
<FOMA card security functions>
The FOMA terminal has built-in FOMA card security functions (FOMA card
restriction functions) as functions for protecting personal data and files.
When data or files are retrieved using any of the following methods or
i-appli is running with the FOMA card inserted into the FOMA terminal,
FOMA card security functions are automatically set in the retrieved data
or files.
When a file such as an image, melody or PDF is downloaded from a
site or Internet web page
When a site or Internet web page is added in screen memo
When i-mode mail with a file attached is received
When i-appli is running
Data, files or software with FOMA card security functions run only when
in use with the FOMA card inserted at time of acquisition. Display, play,
attach to i-mode mail, run software, send data using Ir communication
function and iC communication function, and copy to microSD Card can
be executed. These operations cannot be performed if a different FOMA
card is inserted.
The following indicates the data for which FOMA card security is set.
Melody Image (including animation and Flash movie)
Screen memo Chaku-uta
Chara-den File attached to Message R/F
i-motion ToruCa (details) image
PDF data Image inserted to Deco-mail or signature
Kisekae Tool Videophone picture memo
Machi-chara i-appli (including i-appli stand-by)
Download dictionary
Download font Contents transfer compatible data
Image in Message R/F
Music&Video Channel program
Deco-mail template with data which FOMA card security functions are
set
Decome-Anime Template
e-book/e-dictionary/e-comic saved in the [Comic] folder
®
/Chaku-uta full
File attached to i-mode mail other than the following
• ToruCa• Phonebook• Schedule• Bookmark
※ “Chaku-uta” is a registered trademark of the Sony Music
Entertainment (Japan) Inc.
The following indicates the settings saved in the FOMA card.
Own number PIN setting
Select language SSL/TLS certificates
SMS center SMS expiry
SMS input character
The following explanation refers to the FOMA card inserted at time of
data/files retrieval as “one’s own FOMA card” and other FOMA cards as
“another’s FOMA card”.
®
When one’s own FOMA card is replaced with another’s FOMA card, the
data or files for which FOMA card security functions are set cannot be
set as stand-by displays or ring tones.
Continued on next page
Before Using the Handset
41
When a FOMA card is replaced with another’s FOMA card, FOMA card
security functions are activated and if data or file retrieved from a site is
set as the stand-by display or ring tone, the setting is reset to the
Before Using the Handset
default. When one’s own FOMA card is re-inserted, the setting returns.
Example: When setting [Melody A], for which FOMA card
security functions are set, as a ring tone
When one’s own FOMA card is taken out or is replaced with another’s
FOMA card, ring tone returns to default setting. When one’s own FOMA
card is put back, the ring tone returns to [Melody A].
FOMA card security functions cannot be set for data received using Ir
communication or data transmission functions, and still/moving
pictures, etc. shot with the FOMA terminal.
It is possible to move or delete data or files for which FOMA card
security functions are set even when another’s FOMA card is inserted.
Running i-appli by selecting highlighted text in i-mode mail details
screen cannot be performed or retrieved when FOMA card security
functions are set.
If the FOMA card is replaced with another’s FOMA card after i-appli
stand-by is set, the set i-appli cannot be activated in stand-by, and the
image set in Stand-by display appears.
FOMA card type
Note the following differences between “FOMA card (blue)” and “FOMA
card (green/white)” used on the FOMA terminal.
Function
Number of phone number digits
available in the FOMA card
phonebook
Client certificate operations for
FirstPass
Use of WORLD WINGNot availableAvailableP. 406
Service NumbersNot availableAvailableP. 396
FOMA card
(blue)
Up to 20 digits Up to 26 digits P. 77
Not availableAvailableP. 182
FOMA card
(green/white)
Page
About WORLD WING
WORLD WING is a DOCOMO’s FOMA international roaming service that
makes it possible to use the mobile phone number registered in Japan to
make and receive calls even overseas by the FOMA card (green/white)
and supported FOMA terminal.
Also, SH-05A is available in the DOCOMO’s 3G roaming service area
only. When using this service in the GSM service area, the FOMA card is
inserted into GSM supported terminal.
If subscribed to the FOMA service after September 1, 2005,
subscription for “WORLD WING” is not required. However, if
subscription for “WORLD WING” is canceled at or after subscription for
the FOMA service, subscription for “WORLD WING” is required again.
If subscribed to the FOMA service before August 31, 2005 but not
subscribed to “WORLD WING”, subscription for “WORLD WING” is
required.
Some payment plans are not available.When the FOMA card ( green/whit e) is los t or stole n overseas, promptly
contact DOCOMO and conduct a procedure for canceling the use of
service. Refer to General Inquiries on the back of this manual for
inquiries. Note that transmission/calling charges after the FOMA card
is lost or stolen are incurred to the subscriber.
42
Attaching/Removing battery pack
Face the side with a
recycle mark up
Battery pack connector terminal side
Battery pack
Tabs
Tabs
“PULL” Tag
Use the Battery Pack SH20 exclusive to the FOMA terminal.
Turn off the power, close the FOMA terminal, and hold it in your both
hands before attaching or removing the battery pack.
The battery pack is not waterproof.
■ Attaching battery pack
Remove the back cover (nP. 22).
1
Attach the battery pack.
2
: The battery pack has tabs that make it easy to attach. Attach the
battery pack with a recycle mark side faced up.
■ Removing battery pack
Remove the back cover (nP. 22).
1
Remove the battery pack.
2
: The battery pack has a “PULL” Tag that makes it easy to remove.
Hold the “PULL” Tag between the fingers and lift up it in the direction
of an arrow (45-degree from the FOMA terminal) to remove the
battery pack.
Using unnecessary force when attaching or removing the battery pack
may damage the connector terminal for the battery pack (charger
terminal) on the FOMA terminal.
Securely close the back cover. If not closed securely, the back cover
may come off and the battery pack may fall out due to vibration. May
damage the waterproof performance and allow water to seep.
Before Using the Handset
Attach the back cover (nP. 21).
3
Charging
The battery pack is not fully charged at the time of purchase. Be
sure to charge the battery using the exclusive AC or DC adapter
(sold separately) before use.
It is recommended that the desktop holder be used for charging to
prevent water from seeping caused by forgetting to close the external
connector terminal cover (nP. 45).
The AC adapter and desktop holder are not waterproof. Never try to
charge the battery pack when the FOMA terminal is wet. For precautions
on the waterproof performance when charging nP. 25
43
■ Cautions while charging
Do not charge for long periods of time with the po wer left on. If the FOMA
terminal is left on after charging is complete, the battery pack charge
decreases.
Before Using the Handset
In such cases, the AC or DC adapter charges the battery again.
However, depending on when the FOMA terminal is disconnected from
the AC or DC adapter, the battery charge level may be low, the battery
alert tone may sound, or the battery may only be usable for a short time.
When the battery is empty and terminal is recharging, charging LED may
not illuminate immediately.
If the battery empty alert is displayed, the alert tone sounds and the
power cannot be turned on, charge the battery for a while.
If the battery empty alert is displayed and charging begins within 60
seconds of the alert tone, the status returns to normal.
While charging, terminal may not turn on even when charging LED is
illuminated in red. Charge longer and try turning power on again.
Frequently recharging the battery when its power is still remaining
enough may shorten the life of the battery pack. It is recommended to
use the battery to a certain level before recharging.
■ Estimated charge times and LED display
The following figures are estimated times for charging an empty battery
pack with the FOMA terminal turned off.
FOMA AC Adapter 01/02Approx. 120 min
FOMA DC Adapter 01/02Approx. 120 min
Charging LED illuminates in red while charging, and it turns off when
charging is completed.
Check that the battery pack has been properly attached when charging
LED flashes red. The LED also flashes red when the battery pack has
reached the end of its service life.
The battery pack can also be charged with the FOMA terminal turned on
(Battery icon flashes during charging).
When the battery becomes warm, charging may automatically stop even
if the battery has not been fully charged. Charging resumes after the
temperature lowers to an appropriate temperature. While charging is
stopped, charging LED turns off (Battery icon flashes while stopped).
44
■ Estimated times of use when fully charged
Continuous talk timeFOMA/3G Voice call: Approx. 220 min
Continuous stand-by time FOMA/3G When mobile: Approx. 370 hr
1Seg watching timeApprox. 230 min
Continuous talk time is estimated as the usage time at normal transmission
signal strength, and continuous stand-by time is estimated as the usage
time while moving with the FOMA terminal folded at normal signal strength.
Using i-mode reduces talk (transmission)/stand-by time. When i-Channel is
subscribed, information is automatically received and updated, so talk
(transmission)/stand-by time will be reduced. In addition, when shooting or
editing an image, watching 1Seg, composing i-mode mail, activating the
downloaded iplayer or data communication, the talk (transmission)/stand-by time will be
reduced even if calls or i-mode transmission are not made. Some isoftware may continue transmission even after downloading. To avoid this,
set not to connect in advance.
The actual usage time is a combination of stand-by time and talk time,
and the longer the talk time, the shorter the stand-by time becomes.
1Seg watching time is estimated as the watching time at normal
transmission signal strength with the Stereo Earphone Set 01 (sold
separately) used.
Talk (transmission)/stand-by time may be reduced by about half or 1Seg
watching time may be shortened depending on battery pack status,
function used, temperature and other environmental conditions, or signal
strength (no signal or weak signal).
a
ppli or the i-appli stand-by, or using MUSIC Player, i-motion
Videophone call: Approx. 110 min
At rest: Approx. 570 hr
a
ppli
■ Battery pack service life
Battery pack is a consumable product. Service time per charge is
gradually reduced every time the battery is charged.
When service time per charge is reduced to a bout half of the defaul t time,
this means that the battery pack is approaching the end of its service life.
In such a case, it is recommended to replace the battery pack as soon as
possible. Depending on usage, the battery pack may swell as it
approaches the end of its service life but this will not cause problems.
If i-appli, Videophone, or 1Seg is used while charging for a long time, the
Connector
(Face the side
with the arrows
up)
FOMA AC
Adapter 01/02
100V AC
outlet
3
1
2
Charging LED
4
service life of the battery pack may become shorter than estimated.
To prevent damage to the environment, bring used battery
packs to a docomo service counter, a docomo agent or a
recycle center.
■ About charging batteries
Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately),
FOMA AC Adapter 01 for Global use (sold separately), or FOMA DC
Adapter 01/02 (sold separately).
FOMA AC Adapter 01 covers only 100V AC. FOMA AC Adapter 02/
FOMA AC Adapter 01 for Global use covers from 100 to 240V AC.
The shape of the plug for the AC adapter is for 100V AC (for domestic
use). To use the AC adapter of 100 to 240V AC overseas, a conversion
plug adapter that is compatible with the voltage of your country of stay is
required. Do not use a transformer for use overseas to charge the
battery.
Battery pack cannot be charged with the FOMA terminal opened.
Face the side with the arrows of the AC adapter
1
connector up and insert it into the connector terminal
of the desktop holder (1).
: Keeping the connector parallel with the desktop holder, securely
push it all the way in until it clicks.
Insert the AC adapter power plug into an outlet (2).
2
When placing the FOMA terminal in the desktop
3
holder, Charge start sound is heard, charging LED
illuminates, and charging starts.
: Place the FOMA terminal as the figure shows (3) and push it in the
direction of the arrow (4) until it clicks.
: Do not open the FOMA terminal while it is placed in the desktop
holder.
When Charge end sound is heard and charging LED
4
turns off, charging is complete.
: Hold the desktop holder and lift the FOMA terminal out.
Pull the AC adapter out of the outlet when left unused for a long period
of time.
Before Using the Handset
Continued on next page
45
When Charge start sound is not heard or when charging LED does not
Connector (Face the side with the arrows up)
1
External connector terminal cover
External connector
terminal
Charging LED
100V AC
outlet
For AC adapter
For DC adapter
Cigarette
lighter socket
1
2
1
Release buttons
illuminate, check that the FOMA terminal is placed securely in the
desktop holder (except when terminal is turned off, Manner mode is set
Before Using the Handset
or Charge start sound is Silent).
When placing the FOMA terminal in the desktop holder, be careful that
the strap is not caught in between the handset and the desktop holder.
Charging by using AC adapter/DC adapter
[Read “FOMA AC Adapter 01/02 (sold separately) and FOMA DC
Adapter 01/02 (sold separately) user’s guide” carefully.]
Battery pack can be charged even with the FOMA terminal opened.
Open the external connector terminal cover and insert
1
the AC or DC adapter connector horizontally into the
external connector terminal (1).
When Charge end sound is heard and charging LED
3
turns off, charging is complete.
: When removing the connector, always hold the release buttons on
both sides (1) and unplug it horizontally (2).
: Check the direction (See diagram) of
the connector, keep it parallel with
the FOMA terminal and securely
push all the way in until it clicks.
When inserting the AC adapter power plug into an
2
outlet or inserting the DC adapter power plug into a
car cigarette lighter socket, Charge start sound is
heard, charging LED illuminates, and charging starts.
46
Do not forcibly insert or remove. May cause damage to the external
connector terminal and the connector.
Pull the adapter out of the o utlet or cigar ette lighter s ocket if it w ill not be
used for a long time.
Do not forcefully pull the external connector terminal cover. May
damage the cover.
Do not place objects near the FOMA terminal when charging. May
damage the FOMA terminal.
When using a DC adapter
"
81 to 100%
Battery is sufficiently
remaining.
0
61 to 80% Battery is remaining.
!
41 to 60% Battery level is low.
#
21 to 40% Battery level is very low.
$
1 to 20%
Battery is almost empty.
Charge the battery.
%
0%
Battery is empty (Power will
turn off soon).
The DC adapter should only be used in negative grounded vehicles (12
and 24V DC).
Do not use with the car engine shut off. May drain the car battery.The DC adapter fuse (2A) is a consumable. For replacement, purchase
a new fuse at a local automobile supply shop.
Refer to the FOMA DC Adapter 01/02 user’s guide for details.
Battery level
Checking battery level
If the battery icon is changed to [電池マーク%表示], battery level is
displayed in percentage. However, [&] appears when battery level is
100% while [(] appears when battery level is 4% or less.
The battery icon and Percentage are rough indications.The battery level may change a lot depending on the conditions of use.If the FOMA terminal is left for a long period or without turning off the
power, the battery level may decrease even after the charging is
completed.
■ Changing design of battery icon <Battery icon>
In the Custom menu, select [Settings]/[Battery]/
1
[Battery icon]/i.
Select an image/i.
2
■ Displaying battery icon in percentage temporarily
<Icon% temp display>
When the battery icon is set to other than [電池マーク%表示], if the display
is shown again with the display off, the battery icon in percentage is
displayed for approximately 3 seconds.
In the Custom menu, select [Settings]/[Battery]/
1
[Icon% temp display]/[ON].
Checking battery level with sound and display
In the Custom menu, select [Settings]/[Battery]/
1
[Battery level].
: Battery level is displayed in percentage and graphic. In addition, it is
notified by the number of the battery level sound according to its
remaining amount.
GraphicNumber of beep sound
Five times
Four times
Three times
Twice
Once
: Wait approximately 5 seconds and the display disappears.
:
The battery level sound is heard at the volume set in Key sound (nP. 88).
: If the Manner mode is set, the battery level sound follows the setting
of the Manner mode.
If battery runs out
[Battery empty. Unsaved data will be lost. Ending current
operation] appears if battery starts to run out (Press t to
clear the message). After a while, an alert tone sounds.
The warning screen stating that the battery runs out
appears, handset operations are disabled and power turns off after
approximately 60 seconds.
Continued on next page
Before Using the Handset
47
During a voice/Videophone call, the alert tone sounds and [Battery
Stand-by display
empty. Unsaved data will be lost. Ending current operation] appears. The
call is disconnected after approximately 20 seconds. At the same time,
the screen above appears and after approximately 60 seconds, the
power turns off.
Before Using the Handset
Alert tone does not sound when Manner mode or Public mode (Drive
mode) is set (Alert tone sounds during a call).
Power ON/OFF
Turning power ON/OFF
Turning power ON
Press H (for 2+ seconds).
1
: It may take some time for the wakeup screen to appear.
: The wakeup screen appears followed by the initial settings screen.
Proceed to Initial setting (nP. 48).
: If initial settings have been completed, the
screen shown on the right appears when
power is turned on. This screen is called the
“stand-by display”.
Welcome mail
: “Welcome-ドコモ動画#”
(Welcome-docomo-doga#) and “緊急速報
「エリアメール」のご案内” (Information of Early
Warning “Area Mail”) are saved by default.
: To check a welcome mail: In stand-by, press
t/select the stock icon [C] (mail
message)/t.
• For details on the following operations
nP. 136
If initial settings ar e not yet comp leted, the set ting scr een appears ev ery
time the power is turned on.
If the FOMA card is not inserted, [Insert UIM] and a FOMA card error
appear (nP. 34).
When [Enter PIN1 code] appears, enter the PIN1 code (nP. 107).
When a FOMA card is replaced with a new card, the terminal security
code (four to eight digits) must be entered after turning on the terminal.
If a correct terminal security code is entered, stand-by display appears.
When a wrong terminal security code is entered five times, the power is
turned off. However, turning on the power again is possible.
When [A] appears, the handset is outside the service area or in a
place with no signal. Move to a place where the icon disappears.
Turning power OFF
Press H (for 2+ seconds).
1
: It may take some time for the power to be turned off (The end screen
appears on the display until the power is turned off).
Select language
Changing screen display to English
In the Custom menu, select [Settings]/[一般設定]/
1
[Bilingual]/[English].
: To switch the display language from English to Japanese: In the
If a FOMA card is inserted, settings are saved to the FOMA card as
well. When the setting of the FOMA terminal handset and the setting of
the inserted FOMA card are different, the setting in the FOMA card is
prioritized.
Initial setting
Making initial setting
The initial settings screen appears automatically when the power
is turned on for the first time. Each setting item can also be set
from Menu (When the initial settings are complete, the stand-by
display appears).
Date and time settings Change terminal security code
48
Key sound Location request menu
Set all font size
When items that have not been set remain, the setting screen appears
every time the power is turned on.
Alternatively, select [Settings]/[Initial setting] in the Custom menu to
display the setting screen.
Set the date and time (nP. 49).
1
Register a terminal security code (nP. 107).
2
Set the Key sound (nP. 88).
3
Set GPS Location provision ON/OFF (nP. 298).
4
Set the font size collectively (nP. 103).
5
: When the initial settings are complete, the software update function
confirmation screen appears. Read the description and select
[Agree] (When the initial settings are made from the menu or the
software update is set to other than [auto-update], the confirmation
screen does not appear).
Press H to cancel the initial settings.
Date settings
Setting date and time
Set the date and time on the FOMA terminal.
In the Custom menu, select
1
[Settings]/[General settings]/[Date
settings].
Select the [Auto time correction] field/t/select the
2
setting.
; Select [ON]/i.
; Select [OFF]/select the [Date] field/t/enter the date/t/
select the [Time] field/t/enter the time (24-hour format)/t/i.
• When entering month, day and time, add 0 before numbers one
through nine (example: 01, 02, 03, etc.).
• Set the date and time from 00:00 January 1, 2001 to 23:59
December 31, 2050.
When Limit settings is set to [Enable], the terminal security code must
be entered in the Date settings.
The date and time that are set are saved even if the battery pack is
removed, but if the battery pack remains removed for approximately 30
seconds or more, the settings are reset. Also, if the battery remains
empty, the settings may be reset. When this happens, set again after
charging the battery.
If the date and time are not set correctly, the following functions cannot
be used properly.
Redial, Received calls Auto power ON/OFF
Alarm Schedule
SSL/TLS (authentication) i-appli Auto start
Starting i-appliDX Reception, Recording
Machi-chara Software update
Pattern definitions update
Record message (voice), Record message (Videophone calls)
Camera image titles/shooting date
Playback of i-motion or music data with expiration date/period for
replay
View of e-books/e-dictionaries/e-comics with expiration date/period
for browse
When [Auto time correction] is set to [ON]
When the power is turned on, the FOMA terminal adjusts the time by
connecting to the network’s time information.
If the FOMA terminal does not adjust the time even when the power is
turned on, turn off the power and restart.
Time may not be adjusted depending on the signal status.Time may be off by a few seconds.
Before Using the Handset
Continued on next page
49
When time difference is adjusted overseas, the local time and date and
[!] appear in Redial, Received calls, Received/Sent messages history
(SMS only), received/sent mails list and location history list. The
Before Using the Handset
received/sent mails are not displayed in order of the displayed time and
date but the mail reception/send.
[!] does not appear in the Unsent messages for mail messages. If the
date order display is set for the Unsent messages, unsent mails are
displayed in the order of the displayed time and date.
Time correction may not be performed depending on the overseas
telecommunications carriers’ network. Change the time zone manually.
During overseas use, Japan time and local time (or time set in City)
appear in the dual display except for the following cases.
When Auto time correction is set to [ON] and time correction
information is not being received from an overseas
telecommunications carriers’ network
When Auto time correction is set t o [OFF] and City is set to the city in
the same time zone as Japan
■ Changing time zone manually <City>
In the Date settings screen, select the [Auto time
1
correction] field/t/[OFF]/C.
Select a time zone/t.
2
Select a city/t/i.
3
Notify caller ID
Notifying the other party of your phone
number
Display your number (caller ID) on the other party’s phone
(display) when making a voice/Videophone call.
Handset number (caller ID) is important personal information. Be very
careful about your caller ID setting.
The Notify caller ID function is available only on compatible phone
: To switch between Number A and Number B (when 2in1 [Dual mode]
is used): Press i.
When changing the Number B of 2in1, us e any of the fo llowing method s
to obtain the correct Number B.
Set 2in1 function OFF and then perform 2in1 setting again to set
2in1 function ON
Check the 2in1 subscription
When a FOMA card exchange (2in1 subscriber b 2in1 nonsubscriber)
is performed, set 2in1 function OFF.
When a FOMA card exchange (2in1 subscriber b 2in1 subscriber) is
performed, check the 2in1 subscription.
For details on Owner information nP. 372
50
15°
b mark
15°
Approx. 4 m
Data Management
Actual operational methods will differ with each i-appli software
application.
Control devices from a distance of up to approximately 4 m (Distance will
vary depending on the device, the ambient brightness and other factors).
When in the Self mode, the Ir remote control function cannot be used.Depending on the device, operation may not run properly.Remote control operation may not run properly directly under
fluorescent lights, near other equipment using infrared signals, or in
areas of direct sunlight.
Infrared port
For an image, i-motion, Melody, PDF, or Decome-Anime Template in the
Data box, Sending and receiving all data items is not available. For other
than those above, data that can be sent and received or operations when
various lock functions are set are same as for Ir communication
(nP. 346).
For details on starting iC communication from i-appli nP. 277
Precautions for using iC communication function
iC communication
Use iC communication to send and receive da ta to and from o ther
FOMA terminals which also support iC communication function.
During iC communication, the FOMA terminal status is the same as
when outside the service area, such that making/receiving calls, i-mode,
and data communications are not possible.
iC communication is not available while a call is in progress or the IC
card is locked.
350
Use while placing the b mark of receiver’s FOMA terminal on that of
sender’s FOMA terminal as shown.
Do not move the FOMA terminal until all data are sent and received.Sending and receiving data may be difficult depending on the other
party’s FOMA terminal. In such case, make the clearance between the
b mark closer or farther, or move them up/down/left/right alternately.
During iC communication, FOMA terminal called LED flashes
(nP. 100).
Data communication via iC communication is not available while
charging.
Sending and receiving data
Voice recorder
screen
Terminal security code and authentication password entry are required
for sending or receiving all data items. The authentication password is a
password exclusively for iC communication. Before sta rting dat a transfer,
the sender and receiver must enter the same user-specified four-digit
password.
Using network services during roaming . . . . . . . . . . . . .<Int’l services>413
405
Outline of international roaming
(WORLD WING)
International roaming (WORLD WING) is a service that enables
you, using overseas telecommunications carrier’s networks, to
make calls and use i-mode.
Use this FOMA terminal for voice/Videophone calls, i-mode and
SMS with the phone number and mail address used in Japan.
Network services such as Voice Mail and Call Forwarding
Services can also be used.
This service is available in the 3G network service area. In addition, this
service is available in countries and regions supporting 3G850MHz. This
FOMA terminal cannot be used in the GSM/GPRS network service area.
By default, the FOMA terminal is set to automatically switch networks
(nP. 411).
Refer to the following before using the FOMA terminal overseas.
“Mobile Phone User’s Guide [International Services]”
“Mobile Phone User’s Guide [Network Services]”
PDF file “海外ご利用ガイド” pre-installed in [My Documents] of Data
box
DOCOMO “International Services website”
Overseas Use
Country codes of major countries
The following shows “Country code” used when making international calls
(nP. 60) or setting International dial assist (nP. 61).
For other country codes and details, refer to “Mobile Phone User’s Guide
[International Services]” or the DOCOMO “International Services
website”.
The available communication services overseas are as follows.
Communication
service
*1, 2
Voice call
Videophone
i-mode mailSend or receive i-mode mail overseas with
*3
i-mode
*3, 4
i-Channel
*5
i-concier
*6
i-Widget
SMSSend or receive SMS overseas with the same
GPS position
*7
location
Packet transmission
by connecting a PC,
*8
etc.
*1 When the 2in1 is used, calling from Number B is not available overseas.
*2 When Multi Number is used, calling from Additional Number is not
available overseas.
*3 Overseas use settings for i-mode is required (nP. 408).
*4 i-Channel setting is required. Packet transmission charges are incurred
for each i-Channel reception (including Basic channel).
Make or receive calls in your country of stay
or make international calls to Japan or to
other countries with the same phone number
as used in Japan while abroad.
*1, 2
Make international Videophone calls to users
of the specified 3G telecommunications
carriers overseas and FOMA users in Japan.
the same address as used in Japan.
Use i-mode overseas.A
Use i-Channel overseas.A
Use i-concier overseas.A
Use i-Widget overseas.A
phone number as used in Japan.
Use the GPS function to check the present
location overseas.
Use packet transmission overseas.
Explanation3G
A
A
A
A
A
A
*5 Overseas use settings for i-concier is required. Packet transmission
charges are incurred for each information reception.
Overseas use settings for i-concier can be changed in the following
way.
In the Custom menu, select [i-concier]/i/[設定]/[その他共通設定]/[海外利用設定].
*6 Setting for i-Widget roaming is required (nP. 279). Multiple Widget
Appli may attempt transmission when i-Widget screen appears. In such
case, packet transmission charges are incurred for each transmission.
*7 Set the correct date and time in advance. Transmission charges are not
incurred when the present location is positioned. However, packet
transmission charges are incurred when a map is displayed based on
the location information.
*8 Unable to use 64K data communication by connecting a PC, etc.
Some services are not available depending on the telecommunications
carrier or network. Refer to “Mobile Phone User’s Guide [International
Services]” or the DOCOMO “International Services website” for
information on available countries and regions, and
telecommunications carriers.
Overseas packet transmission charges differ from those in Japan.日英版しゃべって翻訳 for SH (J-E Speech Translation for SH) is
available overseas (nP. 262).
Before use overseas
The following items must be checked before departure, at your
country of stay, and after homecoming.
Preparation before departure
Prepare below in Japan before using the FOMA terminal overseas.
■ About contract
If subscribed to the FOMA service after September 1, 2005, a
subscription for “WORLD WING” is not required. However, if a
subscription for “WORLD WING” is canceled at or after a subscription for
the FOMA service, a subscription for “WORLD WING” is required again.
Continued on next page
Overseas Use
407
If subscribed to the FOMA service before August 31, 2005 but not
subscribed to “WORLD WING”, a subscription for “WORLD WING” is
required. Some payment plans are not available.
Insert the WORLD WING compatible FOMA card (green/white) to the
FOMA terminal (nP. 42).
■ About charging batteries
Precautions for handling the AC adapter nP. 16Methods for charging the AC adapter nP. 43
■ About browsing i-mode sites
To browse i-mode site overseas, the settings for overseas use must be
made from iMenu in advance.
i-mode site: Select [iMenu]/[English]/[Options]/[International
Settings]/[i-mode services Settings].
iMenu cannot be displayed by pressing i in the stand-by display
overseas. If Set i-mode button is set to [iMenu/Search], the message
stating that i-mode menu is displayed appears when i is pressed for
the first time overseas. i-mode menu appears from the next time.
■ About setting network service
If subscribed to network services, Voice Mail Service, Call Forwarding
Service or other services can be used overseas.
Some network services may not be set or checked depending on
overseas telecommunications carrier. In addition, some network services
Overseas Use
are available only in Japan.
To use network services overseas, set Remote Control (nP. 397,
P. 414) to “Activate” in advance.
■ About inquiries overseas
For lost, stolen, and cost settlement, or malfunction of the FOMA terminal
overseas, refer to “Loss or theft FOMA terminal or payment of cumulative
cost overseas” or “Failures encountered overseas” on the back of this
manual. Note that any call or transmission charges incurred after the FOMA
terminal is lost or stolen are charged to the subscriber.
Add the “International call access codes for major countries (table 1)” or
“International prefix numbers for the universal number (table 2)” that is
assigned to your country of stay, to the head of your phone number for
inquiries.
408
International call access codes for major countries (table 1)
The following shows the International call access codes for major countries.
Communication charges to Japan will apply.
International prefix numbers for the universal number (table 2)
The following shows the International prefix number for the universal
number of each country.
Communication charges or other charges to your country of stay will
apply.
Communication charges to your country of stay will apply when calling
Some codes may not be used.Note that the universal number may not be used for calls from a mobile
phone, payphone or hotel.
The universal number can be used only for countries listed on table 2.Calling from a hotel may cost you extra call charges requested by the
hotel (You are responsible for the call charges). Confirm with the hotel
before making calls.
Using at your country of stay
The service is available in the 3G network service area.
The FOMA terminal automatically searches for the network when the power
is turned on, and connects to the available telecommunications carrier in
your country of stay.
When Auto time correction (nP. 49) is set to [ON], if information with
time and time differences is received from overseas telecommunications
carrier which is being connected, time and time differences on the FOMA
terminal clock are corrected. The correction timing differs depending on
the telecommunications carrier.
Auto time correction may not be available overseas. In such case,
correct the time manually (nP. 49).
If the connected telecommunications carrier is changed when Auto time
correction is set to [ON], a screen notifying that time difference is
adjusted may appear.
When Operator name display (nP. 412) is set to [Display on], the
telecommunications carrier connected appears in stand-by.
When Clock display (nP. 93) is set to [ON(Large)], the local time and
Japan time appear (excluding regions keeping the same standard time
as Japan time). If selecting Down for Set display position, Japan time
appears above the local time. If selecting Up for Set display position,
Japan time appears under the local time. The local time appears on the
sub display.
Talk time or stand-by time may be reduced to half the normal time
depending on the network condition of your country of stay.
Setting after homecoming
By default, the FOMA terminal is set to automatically search for the network
and to be connected to the FOMA network when the power is turned on
after homecoming.
If the Network search mode is set to [Manual], switch to the FOMA
network (DOCOMO) manually or change to [Auto].
Overseas Use
409
Making a call at your country of stay
Make a call from overseas using the international roaming
service.
Even when Notify caller ID of the network service (nP. 50) is set to
“Send ID”, [Unavailable] or [User unset] appears depending on the
telecommunications carrier, and the caller ID may not be displayed
correctly.
Making a call outside your country of stay
(including Japan)
Make a call from your country of stay to Japan or other countries.
In stand-by, enter + (press 0 for 1+ seconds),
1
country code, area code (city code) and other party’s
phone number.
: When the area code (city code) begins with 0, omit the 0 when
dialing (Include 0 when making a call to some countries or regions
such as Italy).
Press s (Phone)/i (V.phone).
2
Overseas Use
■ Making an international call outside your country of stay
using Country code conversion
Set Country code conversion (nP. 61) to [ON] and set the country code
frequently called to easily make an international call.
0 at the beginning of a phone number is automatically converted to the
country code set in Country code conversion.
Example: Make a call from phonebook
In stand-by, press a/select the other party.
1
Press s (Phone)/i (V.phone).
2
Select [Call].
3
: To dial a phone number as stored in the phonebook: Select [Original
number].
■ Making a call to the phone in country saved in Set country
code
Save a country code using Set country code (nP. 62) to select a country
code before making an international call.
The following operation is available overseas only.
In stand-by, enter a phone number/C/[Add prefix
1
setting]/[International Call].
Select the country code/t.
2
Press s (Phone)/i (V.phone).
3
Making a call in your country of stay
Make a domestic call at your country of stay in the same way as you do in
Japan.
In stand-by, enter a phone number.
1
Press s (Phone)/i (V.phone).
2
: Always dial the area code (city code), even w hen the n umber is in the
same area.
: When making a domestic call at your country of stay using the
phonebook, select [Original number] in step 3 of “Making an
international call outside your country of stay using Country code
conversion” on P. 410.
Making a call to a WORLD WING subscriber
overseas
When making a call to a “WORLD WING” subscriber overseas, make an
international call to Japan regardless of your country of stay.
In stand-by, enter + (press 0 for 1+ seconds),
1
country code 81 (Japan), the other party’s mobile
phone number excluding 0.
Press s (Phone)/i (V.phone).
2
410
Receiving a call overseas
Receive a call overseas in the same way as you do in Japan.
Press s to receive an incoming call.
1
: Speak to the caller.
Even when a caller tried to notify of caller ID, it might not be notified
depending on the used telecommunications carrier.
When a call is received during international roaming, the call is
forwarded from Japan. Call charges to Japan are incurred by the caller
and receiving charges by the receiver.
Having calls to your FOMA termina l
■ Having calls made to your FOMA terminal from Japan
To receive an international call from Japan, have your phone number dialed
just as a domestic call in Japan.
090 (or 080)-XXXX-XXXX
Calling from Received calls may not be available since the phone
number may not be displayed correctly.
■ Having calls made to your FOMA terminal from countries
other than Japan
Have the international call access code and 81 (Japan) added to the
beginning of your phone number, and 0 excluded as an international call to
Japan regardless of your country of stay.
International call access code of the country of the caller-81-90 (or
80)-XXXX-XXXX
Network search mode
Setting a search method of
telecommunications carrier
Set to manually select a telecommunications carrier.Re-search a network to set another telecommunications carrier.Check that the Network search mode is set to [Auto] when [A] appears
even after homecoming.
If telecommunications carrier is selected with [Manual] set overseas,
manually set to the FOMA network (DOCOMO) again or change to [Auto]
after homecoming.
; Select [Manual]/select a telecommunications carrier/t.
• The telecommunications carrier is changed.
; Select [Network re-search].
• The host network is changed automatically if the Network search
mode is set to [Auto]. If set to [Manual], select a
telecommunications carrier and press t.
Checking available communication services
<In-area status>
Check the status whether making a call, data transmission or packet
transmission is available.
; Select [Activate]/[Yes]/select the barring method/t/enter
the network security code/t.
; Select [Deactivate]/[Yes]/enter the network security code/
t.
; Select [Check setting].
Missed Call Notice
Using Missed Call Notice function
during roaming
When the FOMA terminal is outside the service area, turned off,
or a received call cannot be answered during international
roaming, the information of the call (received date and time or
caller ID) is notified with SMS.
For details on setting at your country of stay nP. 414
Sharp Data Communication Support Center
TEL: 03-5396-2351
Hours: 10:00 A.M. to 12:00 noon, 1:00 P.M. to 5:00 P.M.,
Monday through Friday
(Closed on weekends, national holidays, and company
holidays)
devices
Combine the FOMA terminal with various optional accessories
(sold separately) for expanded personal and business use.
Some products may not be available in certain areas. Contact a
docomo Shop or retailer for details.
Refer to the user’s guide of each product for more details.
FOMA AC Adapter 01*1/02
Battery Pack SH20Back Cover SH30Desktop Holder SH25Earphone Terminal P001Flat-plug Stereo Earphone Set
*3
P01
Flat-plug Earphone/Microphone
with Switch P01
Stereo Earphone Set P001
Appendix/Troubleshooting
Earphone/Microphone with Switch
*2
P001
Earphone/Microphone 01Stereo Earphone Set 01Earphone Plug Adapter P001Earphone Plug Adapter for
External connector terminal 01
Earphone Plug Adapter 01FOMA USB Cable
*1 Refer to P. 43 for details on charging with an AC adapter.
*2 Connect Earphone Plug Adapter for External connector terminal 01 and
450
Earphone Plug Adapter to use these options and related devices.
*3 Connect Earphone Plug Adapter for External connector terminal 01 to
use these options and related devices.
*4 The use of USB HUB may not work correctly.
*5 For use only in Japan.
*6 FOMA In-Car Hands-Free Cable 01 is required to use/charge SH-05A.
/P002
*3
*2
*7 Activate Side key lock to use the In-Car Holder 01.
Interfacing to external devices
Play moving pictures saved on microSD Cards on the FOMA
terminal by using supported external devices.
microSD Cards are sold separately. Purchase microSD Cards at
home electronics shops (nP. 329).
For details on compatible devices, refer to http://k-tai.sharp.co.jp/support/d/sh-05a/. Or, contact the number below.
Play i-motion created on external devices (including music data in AAC
format) on the FOMA terminal (nP. 247).
* Some moving pictures cannot be played depending on the file format or
*5
*6
the type of external device.
Check the phone number carefully before dialing.
About moving picture player software
QuickTime™ Player (Free) ver. 6.4 or later (or ver. 6.3+3GPP) provided by
Apple Computer, Inc. is required to play moving pictures on a PC.
QuickTime™ Player can be downloaded from the following web page.
http://www.apple.com/jp/quicktime/download/
To download, a PC connected to the Internet is required. Additional
transmission fees are charged for downloading.
Refer to the Apple Computer, Inc. web page for details on the operating
environment, downloading, and usage instructions.
*
Specific Absorption Rate (SAR) of
mobile phone
This model phone SH-05A meets the MIC’s* technical regulation
for exposure to radio waves.
The technical regulation established permitted levels of radio frequency
energy, based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies.
The regulation employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)
averaged over ten grams of tissue. The limit includes a substantial safety
margin designed to assure the safety of all persons, regardless of age and
health. The value of the limit is equal to the international guidelines
recommended by ICNIRP
All phone models should be confirmed to comply with the regulation, before
they are available for sale to the public. The highest SAR value for this
model phone is 0.680 W/kg. It was taken by the Telecom Engineering
Center (TELEC), a Registered Certification Agency on the Radio Law. The
test for SAR was conducted in accordance with the MIC testing procedure
using standard operating positions with the phone transmitting at its highest
permitted power level in all tested frequency bands. While there may be
differences between the SAR levels of various phones and at various
positions, they all meet the MIC’s technical regulation. Although the SAR is
determined at the highest certified power level, the actual SAR of the phone
during operation can be well below the maximum value.
For further information about SAR, please see the following websites:
* Ministry of Internal Affairs and Communications
** The technical regulation is provided in Article 14-2 of the Ministry
Ordinance Regulating Radio Equipment.
***International Commission on Non-Ionizing Radiation Protection
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by
international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety margins
designed to assure the protection of all persons, regardless of age and
health.
The guidelines use a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest
SAR value for this device when tested at the ear was 0.670 W/kg
As SAR is measured utilizing the devices highest transmitting power the
actual SAR of this device while operating is typically below that indicated
above. This is due to automatic changes to the power level of the device to
ensure it only uses the minimum level required to reach the network.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions for the
use of mobile devices. They note that if you want to reduce your exposure
then you can do so by limiting the length of calls or using a hands-free
device to keep the mobile phone away from the head.
* The tests are carried out in accordance with international guidelines for
testing.
*
.
Continued on next page
Appendix/Troubleshooting
483
FCC Notice
Hereby, Sharp Telecommunications of Europe Ltd, declares
that this SH-05A is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original declaration of conformity can be
found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Declaration of Conformity
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the
Appendix/Troubleshooting
equipment.
Information to User
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation; if this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
484
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The guidelines are based on standards that were devel oped by ind ependent
scientific organisations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg.
The tests are performed in positions and locations (e.g., at the ear and worn
on the body) as required by the FCC for each model. The highest SAR
value for this model handset when tested for use at the ear is 0.663 W/kg
and when worn on the body, as described in this user guide, is 0.735 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the back of the handset kept 1.5 cm from the body. To
maintain compliance with FCC RF exposure requirements, use accessories
that maintain a 1.5 cm separation distance between the user’s body and the
back of the handset. The use of beltclips, holsters and similar accessories
should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization for this model handset
with all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model handset is on file with
the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID APYHRO00094.
Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications & Internet Association (CTIA) Website at
http://www.phonefacts.net.
Export Administration RegulationsIntellectual property rights
The Japan Export Administration Regulations (“Foreign
Exchange and International Trade Law” and its related laws) will
be applied to this product and its accessories under certain
conditions. The Export Administration Regulations are also
applied. To export or reexport this terminal and its accessories,
conduct all legally required procedures at your own risk and
expense. For details on the procedures, contact the Ministry of
Economy, Trade and Industry or the US Department of
Commerce.
Copyrights and rights of portrait
Data with third party copyrights such as text, images, music and software
that is downloaded or acquired via Internet web pages, shot by the
FOMA terminal, or acquired from TV or other video cannot be duplicated,
altered or publicly transmitted without rightful party’s consent. Only
duplicating, quoting, etc. for personal use is permitted under copyright
laws.
Even if for personal use, filming and recording may be prohibited for
demonstrations, performances and exhibitions.
Also, shooting another’s image or posting another’s image on Internet
web pages without their consent may constitute a violation of one’s right
to their image.
ACCESS, NetFront and Media: are trademarks or registered trademarks
of ACCESS Co., Ltd. in the United States, Japan and other countries.
Appendix/Troubleshooting
Microsoft
®
, Windows®, Windows Vista® and Windows Media® are
trademarks or registered trademarks of Microsoft Corporation in the
U.S.A. and other countries.
Java and all Java-based trademarks and logos are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S.A. and other
countries.
QuickTime is a registered trademark of Apple Inc., in the US and other
countries.
QR code is a registered trademark of Denso Wave Inc.microSDHC Logo is a trademark.
Powered by JBlend™ Copyright 2002-2009 Aplix Corporation.
All rights reserved.
JBlend and JBlend related trademarks are registered
trademarks or trademarks of Aplix Corporation in Japan and
other countries.
486
“AXIS Font” is a trademark of AXIS Inc., and the “AXIS” font is a font
developed by Type Project Inc.
This handset features LCFONT, developed by Sharp Corporation, to
make the LCD easier to view and read. LCフォント/LCFONT and
are registered trademarks of Sharp Corporation.
DynaFont is a registered trademark of DynaComware Taiwan Inc.McAfee
®
is registered trademarks or trademarks of McAfee, Inc. and/or
its affiliates in the U.S.A. and other countries.
Gガイド, G-GUIDE, Gガイドモバイル, G-GUIDE
MOBILE and the G-GUIDE related logos are registered
trademarks of Gemstar-TV Guide International, Inc. and/
or its affiliates in Japan.
Google and Google Map for Mobile are trademarks of Google Inc.IrSimple™, IrSS™ or IrSimpleShot™ are trademarks of Infrared Data
Association
FeliCa, which uses non-contact IC card technology, was created
by Sony Corporation.
FeliCa is a registered trademark of Sony Corporation.b is a registered trademark of FeliCa Networks, Inc.
®
.
Napster is a registered trademark of Napster, LLC. and/or its affiliates in
the US and/or other countries.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
®
FlashFX
Pro™ is a trademark or registered trademark of the Datalight,
Inc. in the US.
(U.S.Patent Office 5,860,082/6,260,156)
PhotoSolid
®
, FaceSolid®, FrameSolid®, PhotoScouter™, ImageSurf™,
and TrackSolid™ are the trademarks or the registered trademarks of
Morpho, Inc.
「Chizu Talk」 is a trademark of ZENRIN DataCom CO.,LTD.“AQUOS”, “VeilView”, “Egao focus shutter”, “Furimuki shutter”, “Chase
focus”, “Motiondeco”, “Shotdeco”, “Wakeup TV”, and “Quick Stand-by
Display Setting” are trademarks or registered trademarks of Sharp
Corporation.
All other company names and product names are trademarks or
registered trademarks of the respective companies.
Others
Under the MPEG-4 Visual Patent Portfolio License, customers have
licensed permission for the following use of this product to engage in
non-profit personal use. Other uses are not permitted.
Encoding MPEG-4 standard video (henceforth referred to as MPEG-4
video).
Decoding an MPEG-4 video that a customer not engaged in personal
commercial activities has encoded.
Decoding an MPEG-4 video obtained from a licensed provider.
For details on other intended uses, contact MPEG LA, LLC.
This product is licensed under the MPEG-4 Systems Patent Portfolio
License for encoding in compliance with the MPEG-4 Systems Standard.
An additional license and payment of royalties are necessary in the
following cases.
Data stored or replicated in physical media which is paid for on a title
by title basis.
Data which is paid for on a title by title basis and is transmitted to an
end user for permanent storage and/or use.
Such additional license may be obtained from MPEG LA, LLC. Contact
MPEG LA, LLC for additional details.
This product is licensed under the AVC patent portfolio license for the
personal and noncommercial use of a consumer to (i) encode video in
compliance with the AVC standard (henceforth referred to as AVC video)
and/or (ii) decode AVC video that was encoded by a consumer engaged
in a personal and noncommercial activity and/or was obtained from a
video provider licensed to provide AVC video. No license is granted or
shall be implied for any other use. Additional information may be
obtained from MPEG LA, L.L.C.
See HTTP://WWW.MPEGLA.COM
This product is licensed under the VC-1 Patent Portfolio License for the
personal and noncommercial use of a consumer to (i) encode video in
compliance with the VC-1 standard (henceforth referred to as VC-1
video) and/or (ii) decode VC-1 video that was encoded by a consumer
engaged in a personal and noncommercial activity and/or was obtained
from a video provider licensed to provide VC-1 video. No license is
granted or shall be implied for any other use. Additional information may
be obtained from MPEG LA, L.L.C.
See HTTP://WWW.MPEGLA.COM
Content owners use Windows Media digital rights management
(WMDRM) technology to protect their intellectual property, including
copyrights. This device uses WMDRM software to access
WMDRM-protected contents. If the WMDRM software fails to protect the
content, content owners may ask Microsoft to revoke the software’s
ability to use WMDRM to play or copy protected content. Revocation
does not affect unprotected content. When you download licenses for
protected content, you agree that Microsoft may include a revocation list
with the licenses. Content owners may require you to upgrade WMDRM
to access their content. If you decline an upgrade, you will not be able to
access content that requires the upgrade.
CP8 PATENT
®
Flash® Lite™ and Adobe Reader®
Appendix/Troubleshooting
Continued on next page
487
This manual refers to each OS (Japanese version) as follows.
Windows Vista is an abbreviation of Windows Vista
Home Premium, Business, Enterprise, Ultimate).
Windows XP is an abbreviation of Microsoft
Professional operating system or Microsoft
Edition operating system.
Windows 2000 is an abbreviation of Microsoft
Professional operating system.
Internet dictionary embedded in this product uses the BSD license.
• Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions
are met:
• Redistributions of source code must retain the above copyright
notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the
documentation and/or other materials provided with the distribution.
• Neither the name of the <ORGANIZATION> nor the names of its
Appendix/Troubleshooting
contributors may be used to endorse or promote products derived
from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS
AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY
OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
®
Windows® XP
®
Windows® XP Home
®
®
(Home Basic,
Windows® 2000
488
Quick Manual
Cut along the perforations.
This manual is produced using recyclable material. Please recycle when no longer needed.
How to use Quick Manual
Remove the Quick Manual attached to the end of this manual by cutting along the perforations and fold it as shown below.
Carry the Quick Manual “Overseas Use” when the mobile phone is used with the International Roaming (WORLD WING) overseas.
■ Folding Quick Manual
Be careful of injuries when cutting out the Quick Manual.
<Cut here>
Index/Quick Manual
(Completed)
502
SH-05
A
Quick Manual
General Inquiries <docomo Information Center>
s
※ Service available in: English, Portuguese, Chinese, Spanish, Korean.
※ Available from mobile phones and PHSs.
From DOCOMO mobile phones
(In Japanese only)
r
※ Unavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
s
※ Available from mobile phones and PHSs.
Please confirm the phone number before you dial.
<Cut here>
Registration/Contacts
0120-005-250 (toll free)
(No prefix) 151 (toll free)
0120-800-000 (toll free)
If you have problems with your FOMA
From DOCOMO mobile phones
(In Japanese only)
(No prefix) 113 (toll free)
r
※ Unavailable from land-line phones, etc.
From land-line phones
(In Japanese only)
0120-800-000 (toll free)
s
※ Available from mobile phones and PHSs.
Please confirm the phone number before you dial.
Adding entries to phonebook
(FOMA terminal handset)
1 In stand-by, press a (for 1+ seconds)/[Phone].
2 Enter a name/t/[9]/enter a phone
number/t/select a phone type icon/t/
[S]/enter a mail address/t/select a mail
address type icon/t/i/t.
–1––2–
■ Other save items
Q : Group; : Secret
a : Company/schoolF : Secret code
J : Company/school (Reading) < : Select ring tone
q : DepartmentV : Mail ring tone
r : Titleq : Called LED color
N : Postal code- : Called LED pattern
O : Postal address: : Mail/Message LED colorj : Location info+ : Mail LED pattern
P : Birthday8 : Picture call set
G : Memo1 : Substitute image
Adding entries to phonebook from
Redials/Received calls
1 In stand-by, press r (I)/q (M)/select a
phone number/C/[Add to phonebook]/
[Save new to phone]/add to the phonebook.
Editing phonebook entries
1 In stand-by, press a/select a name/C/
[Edit data]/[Edit]/select an item/t/edit.
Text input
In the text input screen, press a/select the
1
input mode.
Changing input mode
Switching upper/lower case
1 Enter a character/*.
1 Move the cursor to the text and press c.
: To delete all text: At the en d of the message, press c
(for 1+ seconds).
1 In the text input screen, press a (for 1+
seconds)/select a phrase/t/confirm the
phrase/t.
Deleting text
Using phrases
Entering pictograms/symbols
1 In the text input screen, press i.
: To switch between pictogram and Deco-mail
pictogram: Press i.
: To switch between single- and double-byte symbols:
Press C.
2 Select a pictogram/symbol/t.
Entering emoticons
1 In the text input screen, press m (for 1+
seconds)/select an emoticon/t.
Cutting/Copying/Pasting text
1 In the text input screen, move the cursor to the
start position/C/[Copy]/[Cut(HoldS)]/t.
2 Move the cursor to the end position/t.
3 Move the cursor to the paste position/* (for
1+ seconds).
–4––3––5–
Ex.) 今日のテニス3時t
Text input example
1 In the text input screen,
press 2 (twice)/p/[今
日].
: As each hiragana character is
entered, conversion
candidates appear and they
can be selected.
2 Press p/[の].
3 Press 453/o/[テニス].
: Use o for One-touch conversion.
4 Press a (five times)/3.
: Press a (five times) for single-byte numeric mode.
5 Press a (twice)/3 (twice)/*/p/[時].
: Use * for dakuten mark.
6 Press i/[t].
1 In the Custom menu, select [Settings]/[Disp/
1 In the Custom menu, select [Settings]/[Disp/
Changing font (font style)
LED/Power saver]/[Font style]/[Font style
setting]/select the font/t.
Changing font size
LED/Power saver]/[Font style]/[Font size
setting]/[Individual setting]/select the [Input]
field/t/select the font size/t/[Yes].
: To change collectively: In stand-by, pr ess 5 (for 1+
seconds).
Camera
1 In stand-by, press C/t/t.
Shooting still pictures
1 In the Custom menu, select [Camera]/[Shoot
1 In the Custom menu, select [Data box]/[My
1 In the Custom menu, select [Data box]/
Shooting moving pictures
movie]/t/t/[Save].
Displaying still pictures
picture]/select a still picture/t.
Playing moving pictures
[i-motion/Movie]/select a moving picture/t.
–6––8–
Watching 1Seg
Performing Automatic channel setting
1 In the Custom menu, select [1Seg]/[Channel
setting].
2 Select the number to save/C/[Auto channel
set]/[Yes].
3 Select an area/t/select a prefecture/
district/t/t/[Yes]/[Yes].
1 In the Custom menu, select [1Seg]/[Channel
setting]/select a channel list/t.
1 In stand-by, press C (for 1+ seconds).
: To record a video of 1Seg programs: While watching
: To record 1Seg programs as a still picture: While
Selecting a channel list
Watching 1Seg
1Seg, press i (for 1+ seconds)/(record)/i.
watching 1Seg, press i.
–7–
Watching videos
1 In the Custom menu, select [Data box]/[1Seg].
2 Select the [Video] folder/select a video/t.
Music playback
1 In the Custom menu, select [Data box]/
[MUSIC]/select music data/t.
To pause/playt
To stopm
To adjust the volumeu
To play previous song/return to
the beginning of song
To play next songr
To end MUSIC PlayerH/[Yes]
Using MUSIC Player
Key operations for MUSIC Player
q
–10–
Mail
Composing and sending i-mode mail
1 In stand-by, press m (for
1+ seconds)/select the
[To] field/t/select the
input method.
; Select [Search
phonebook]/select a
recipient/t.
; Select [Sent messages]/
select a recipient/t.
; Select [Rcvd messages]/select a recipient/t.
; Select [Mail members]/select a mail member/
t.
; Select [Blog/SNS]/select a posting site/i.
; Select [Direct input]/enter an address/t.
2 Select the [Sub] field/t/enter a subject/
t/[Msg]/enter the message/t/i.
–11––9–
<Cut here>
1 In the text input screen, press C/[Decorate
mail]/select a decoration type/t/specify
decoration/t/input text/t/i.
Attaching a file
1 In the compose message screen, select the
attachment field (No attachment)/t/select
the file to attach.
; Select [Image]/select an image/i.
; Select [Melody]/select a melody/i.
; Select [i-motion]/select i-motion/i.
; Select [ToruCa]/select a ToruCa/i.
; Select [PDF]/select a PDF/i.
; Select [Phonebook]/select a save destination/
t/select a name/t.
Sending Deco-mail
; Select [Schedule]/select a save destination/t
(/select a day/i)
* No operation is needed if [microSD] is selected as the
unknown, User unset, Reject
payphone, Reject not support
Show rcvd calls, Show redial
Show sent messages,
Show rcvd messages
Function lock, Multi lock set,
IC card lock, Multi lock auto-set
–24–
UIncoming
settings
VInformation display
UBattery level
VBattery icon
WIcon% temp display
TOwn number
RInitial setting
\i-concier settings
Select volume, Select sound, Vibrator,
Ring time setting, LED setting
]Battery
Other settings
Manner mode enable/disable# (for 1+ seconds)
Public mode (Drive mode)
activate/deactivate
Display the Lock selectiont (for 1+ seconds)
Show i-Channel listc (J)
Show iMenui
Show i-appli software list screen i (,) (for 1+
Activate Quick search$
Activate Multi Assistant
(Multitask)
Display Shortcut menup
Display i-Widget screeno
Display Received messages
history
Display Sent massages history r (for 1+ seconds)
VeilView ON/OFF$ (for 1+ seconds)
Position locationy (for 1+ seconds)
–25––26–
Other functions
* (for 1+ seconds)
seconds)
$ while using a
function
q (for 1+ seconds)
※ When the confirmation screen appears, select [Yes].
Network services
Voice Mail Service is a paid option (monthly fees apply) that
requires subscription.
1 In the Custom menu, select [Settings]/[NW
Services]/[Voice Mail].
2 Select [Activate VoiceMail]/[Activate
VoiceMail].
: To deactivate: Select [Deactivate VoiceMail].
: To play messages: Select [Play Messages]/
[Play(voice call)]/[Play(videophone)].
: To check messages: Select [Check messages].
Voice Mail Service
Call Waiting is a paid option (monthly fees apply) that requires
subscription.
1 In the Custom menu, select [Settings]/[NW
Services]/[Call waiting].
2 Select [Activate].
: To deactivate: Select [Deactivate].
: To check settings: Select [Check setting].
Call Forwarding Service
Call Waiting
Call Forwarding Service is a free option (no monthly fees) that
requires subscription.
1 In the Custom menu, select [Settings]/[NW
Services]/[Call Forwarding].
2 Select [Activate]/[Activate].
: To deactivate: Select [Deactivate].
: To check settings: Select [Check setting].
–28––27––29–
Subscription is not required (no monthly fees).
Caller ID Request Service
1 In the Custom menu, select [Settings]/[NW
Services]/[Caller ID request].
2 Select [Activate].
: To deactivate: Select [Deactivate ].
: To check settings: Select [Check setting].
Icons are shown in the order of main display and sub display.
2345 7b c
pmlkjihgnq orfe
s
zyx
d
uv
6a98
w
t
1
1shi82 b 2
kl< 2z
c
ty 2
Icon list
Main display
Sub display
1 ]/aSignal status
2 "/b
3 7=IJAABNO
4 oSSL/TLS
5 GNIQ
6 AB
7 JtuIr communication/External device
8
UhHv[/x
9 ABJ
a WGIX
STKL
b ^ (gray)/m
^ (pink)/l
a/r
Clock display
c
d a
Battery level
i-mode/Full Browser
i-appli
GPS
i-mode mail/SMS/Area Mail
received
Message R/F received
Storage status of i-mode center
microSD Card is inserted
microSD Card is being used
microSD Card cannot be
recognized
1Seg being recorded
–30––32–
e ]
D to Pk
f [Silent
g b
h Z/fManner mode
i _/dPublic mode (Drive mode)
j a
k H/cIC card lock
l RSTUVW
KX/ie
m ;
n \Alarm
o
0
p =;
q sEarphone/Microphone connection
r xUSB mode
Record message
Vibrator
i-appli call
Restriction
Hands-free in progress
Music&Video Channel program
reservation
i-mode mail send reservation
–31–
s
R/j
B/hNon-FOMA card is inserted
t g/g
u PVeilView
v SQR3G
wIH
x QToruCa
y C/zReceiving information
Multitask
z
< wOperation in progress
※ Refer to P. 31 to P. 35 of the manual for detailed explanations
of displayed icons.
FOMA card is malfunctioning or
not inserted
Self mode
Status of Comics setting
–34–
<Emergency contacts in case of
loss or other accidents>
Omakase Lock
※Omakase Lock is a paid service. However, if Omakase
Lock is subscribed while or at the same time as when
the use of FOMA terminal is suspended, or if the user is
a member of docomo Premier Club, the usage fee of
Omakase Lock is not charged. Additionally, if Keitai
Anshin Pack (Mobile Phone Security Package) is
subscribed, Omakase Lock is available for a flat-rate.
Enable/Disable Omakase Lock
0120-524-360 Office hours: 24hours
s
Other contacts
<Contacts:>
<Contacts:>
<Contacts:>
※Please confirm the phone number before you dial.
–35––33–
<Cut here>
SH-05
A
Quick Manual “Overseas Use”
Loss or theft FOMA terminal or payment of cumulative
cost overseas <docomo Information Center>
From DOCOMO mobile phones
International call access code
for the country you stay (table 1)
*
※
If you use SH-05A, you should dial the number +81-3-5366-3114
(to enter “+”, press the “0” key for 1+ seconds).
From land-line phones
<Universal number>
International prefix number for
the universal number (table 2)
* You might be charged a domestic call fee according to the call rate
※ See P.19 to P.22 for international call access codes for major
countries (table 1) and international prefix numbers for the
universal number (table 2).
<Cut here>
(available 24 hours a day)
-81-3-5366-3114* (toll free)
You are charged a call fee to Japan when calling from a land-line phone, etc.
-800-0120-0151*
for the country you stay.
Failures encountered overseas
<Network Technical Operation Center>
From DOCOMO mobile phones
※
If you use SH-05A, you should dial the number +81-3-6718-1414
(to enter “+”, press the “0” key for 1+ seconds ).
From land-line phones
<Universal number>
※ See P.19 to P.22 for international call access codes for major
countries (table 1) and international prefix numbers for the
universal number (table 2).
(available 24 hours a day)
International call access code
for the country you stay (table 1)
*
You are charged a call fee to Japan when calling from a land-line phon e, etc.
International prefix number for
the universal number (table 2)
* You might be charged a domestic call fee according to the call rate
for the country you stay.
-81-3-6718-1414* (toll free)
-800-5931-8600*
–1––2–
Preparing for overseas use
Refer to the following before using the FOMA terminal overseas.
“ M obi le Phon e User’s Gu ide [International Services]”
“Mobile Phone User’s Guide [Network Services]”
PDF file “海外ご利用ガイド” (Guide for overseas use)
pre-installed in [My Documents] of Data box
DOCOMO “International Services website”
■ Setting in Japan
1 In the Custom menu, select [i-mode]/[iMenu/
Search]/[English]/[Options]/[International
Settings]/[i-mode services Settings]/[Yes]/
select the [Enter i-mode Password] field/t/
enter the i-mode password/t/[OK].
Setting i-mode
■ Setting in overseas
1 In the Custom menu, select [i-mode]/[iMenu/
Search]/[English]/[International Settings]/
[i-mode services Settings]/[Yes]/select the
[Enter i-mode Password] field/t/enter the
i-mode password/t/[OK].
Setting remote access
■ Setting in Japan
1 In the Custom menu, select [Settings]/[Other
NW Services]/[Remote Control]/[Activate]/
[Yes].
■ Setting in overseas
1 In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Remote access (Int.)]/[Yes]/operate
according to the voice guidance.
Correcting date and time automatically
1 In the Custom menu, select [Settings]/[General
settings]/[Date settings]/select the [Aut o time
correction] field/t/[ON]/i.
Setting time zone manually
1 In the Custom menu, select [Settings]/[General
settings]/[Date settings]/select the [Aut o time
correction] field/t/[OFF]/C.
2 Select a time zone/t/select a city/t/i.
–4––3––5–
Available network
3G networkAvailable
GSM networkNot available
GPRS networkNot available
Available services overseas
Telecommunications
carrier name
Communication service3G
Voice call
Videophone
i-mode mail
i-mode
i-Channel
i-concier
i-Widget
SMS
GPS position location
Packet transmission by connecting a PC, etc.
Unable to use 64K data communication by connecting a PC,
etc. overseas.
A
A
A
A
A
A
A
A
A
A
Setting a search method of
telecommunications ca rrier
Network search mode
Default setting: Auto (Automatically switches telecommunications
carriers)
Select [Manual]/select a telecommunications
carrier/t.
: To re-search for the host network: Select [Network
re-search].
Setting a telecommunications carrier to
preferentially connect to
1 In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Network search mode]/[PLMN
setting]/select the number of the priority
order/C.
2 Select [PLMN manual select]/enter a country
code (MCC)/t/enter a network code (MNC)/t/[Yes].
: To save from a telecommunications carrier list: Select
[UPLMN by list]/select a telecommunications
carrier/t/[Yes].
: To save the telecommunications carrier curren tly
connected to: Select [Set VPLMN to PLMN]/[Yes].
: To change the priority: Select [Change priori ty]/
select a destination/t/[Yes].
–6––8–
Displaying a telecommunications carrier
In the Custom menu, select [Settings]/[Phone
1
settings]/[Other settings]/[International
Roam.]/[Operator name disp]/[Display on]/
[Yes].
name in stand-by
Setting after homecoming
If Network search mode is set to [Auto], reset Network search
mode to the FOMA network (DOCOMO) automatically when the
power is turned on after homecoming.
the country code, area code ( city cod e) and othe r
party’s phone number/s (Phone)/i
(V.phone).
: When the area code (city code) begins wi th 0, omit the
0 when dialing (Include 0 when making a call to some
countries or regions such as Italy).
(including Japan)
–10–
■ Making a call outside your country of stay using
country code conversion
0 at the beginning of a phone number is automatically converted to
the country code set in Country code conversion.
Example: Make a call from the phonebook
1 In stand-by, press a/select the other party/
s (Phone)/i (V.phone)/[Call].
■ Making an international call
Save a country number using Set country code to select a country
code before making an international call.
The following operation is available overseas only.
1 In stand-by, enter a phone number/C/[Add
prefix setting]/[International Call]/select the
country code/t/s (Phone)/i (V.phone).
–11––9–
<Cut here>
Making a call in your country of stay
1 In stand-by, enter a phone number/s (Phone)/
i (V.phone).
■ Making a call to the phone in your country of
stay using phonebook
1 In stand-by, press a/select the other party/
s (Phone)/i (V.phone)/[Original number].
■ Making a call to a WORLD WING subscriber
overseas
Even when making a call to the phone in your country of stay,
make an international call to Japan if the call recipient is a
“WORLD WING” subscriber overseas.
1 In stand-by, press 0 (for 1+ seconds)/81/
enter the other party’s mobile phone number
excluding the first 0/s (Phone)/i (V.phone).
Receiving calls
1 Press s to answer an incoming call.
<Cut here>
–12–
■ Having calls made to your FOMA terminal from
Japan
Enter the phone number in the same way as it is entered in Japan
and make a call.
■ Having calls made to your FOMA terminal from
countries other than Japan
Enter international call access code of the country of the
caller-81-user’s phone number excluding the first 0 and make a
call.
Setting roaming guidance
Make this setting while still in Japan.
※ When the confirmation screen appears, select [Yes].
1 In the Custom menu, select [Settings]/[Other
NW Services]/[Roaming guidance].
2 Select [Activate].
: To deactivate: Select [Deactivate].
: To check settings: Select [Check setting].
–13––14–
Depending on the overseas telecommunications carrier, the
Singapore001Switzerland00
South Africa09Taiwan00
South Korea001Thailand001
Spain00U.K.00
Sweden00U.S.A.011
–22–
About inquiries overseas
For lost, stolen, and cost settlement, or
malfunction of the FOMA terminal overseas,
refer to “Loss or theft FOMA terminal or
payment of cumulative cost overseas” on the
cover of Quick Manual “Overseas Use” or
“Failures encountered overseas” on P.1. Note
that transmission/calling charges after the
FOMA terminal is lost or stolen are incurred to
the subscriber.
When the FOMA terminal is lost or st olen overseas,
promptly contact DOCOMO and conduct a
procedure for canceling th e use of service.
Add the “International call access codes for major
countries (table 1)” or “International prefix numbers
for the universal number (table 2)” that is assigned
to your country of stay, to the head of your phone
number for inquiries.
–23––21–
Check/Change the subscription, apply for various services, and request various information materials online.
From i-mode
Packet communication charges free
From a PC
iMenu/お客様サポート
(user support)/お申込・お手続き
(Applications/Procedures)/各種お申込・お手続き
(Various Applications/Procedures)
※ You will need your “Network Security Code” to access the site from i-mode.
※ No packet communication charges are incurred when accessing the site from i-mode. Accessing from overseas will incur charges.
※ You will need your “docomo ID/Password” to access the site from PC.
※ If you do not have or you have forgotten your “Network Security Co de” or “docomo ID/Password”, contact the number listed in General Inquiries on the back of this manual.
※ The site may not be available depending upon the content of your subscription.
※ You may not be able to access some site services due to system maintenance, etc.
My docomo (http://www.mydocomo.com/)/各種お申込・お手続き (Various Applications/Procedures)
Please follow proper etiquette
When using your FOMA terminal, please be considerate of those
around you.
Turn off your FOMA terminal in the following places
■ When in an area where use is prohibited
There are places where the use of mobi le phon es is pr ohibi ted. B e sure to turn
off your FOMA terminal in the following places.
★On an aircraft ★In a hospital
※ There are people outside hospital wards who also use electric medical
equipment. Please make sure that your FOMA terminal is turned off in the
lobby and waiting room.
■ While driving
Using a mobile phone in hand while driving is regarded as a punishable act.
※ If there is no choice but to receive a call, use hands-free and tell the caller
that you will “call back”, and then pull over to a safe place to make a call.
■ When in crowded places such as rush-hour trains in case
somebody nearby is using an implanted cardiac pacemaker or
implanted cardioverter-defibrillator
Your FOMA terminal may affect the operation of such equipment.
■ When in public places such as theaters, movie theaters, or
museums
Use of your FOMA terminal in quiet public places will annoy others.
Be careful of where you use your FOMA terminal and the
volume of your voice and the ring tone
■ When using your FOMA terminal in a restaurant or a hotel
lobby, lower your voice.
In crowded places, be careful not to obstruct other pedestrians.
■
Be considerate of the privacy of the individuals around you
Please be considerate of the privacy of individuals around
you when taking and sending images using a
t
camera-enabled mobile phones.
The following functions will help you to keep your
manners in public
There are useful functions you can use to set your FOMA
terminal not to answer incom ing ca lls, and to s ilen ce a ll sou nds.
● Manner mode (nP. 91)/Original manner mode (nP. 92)
Silences the Key sound and all the sounds from the FOMA terminal, and
Record message is set (Manner mode). When in the Manner mod e,
automatically set functions (Record message, Vibrator, Mic sensitivity up,
Ring tone, Mail ring tone, alarm tone, Key sound and Low battery alarm)
can be set to ON (enable)/OFF (disable) (Original manner mode).
● Public mode (Drive mode/Power OFF) (nP. 66, P. 67)
The caller hears a guidance message stating that the r eceive r is dri ving, or
in the place where the receiver should refrain from using the mobile phone
or turn off the power. The call is disconnected.
● Vibration mode (nP. 89)
Notifies incoming calls by vibration.
● Record message (nP. 68)
When you are unable to answer a call, the Record message function
records the caller’s message.
※ You can also use optional services such as Voice Mail Service
(nP. 390) and Call Forwarding Service (nP.392).
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
