The following symbols indicate specific directions.

Easy Search/Contents/Precautions

Before use, read these “Precautions” carefully and use your FOMA

These precautions contain information intended to prevent bodily

The following symbols indicate the different degrees of injury or damage that may occur if information provided is not observed and the FOMA terminal is used improperly.

Precautions (ALWAYS FOLLOW THESE DIRECTIONS)

properly. Keep this manual in a safe place for future reference.

injury to the user and to surrounding people, as well as damage to property, and must be observed at all times.

This symbol indicates that “death or serious bodily injury

Danger

Warning

Caution

may directly and immediately result from improper use”.

This symbol indicates that “death or serious bodily injury may result from improper use”.

This symbol indicates that “bodily injury and/or property damage may result from improper use”.

Indicates a prohibited action.

Indicates not to disassemble the device.

Indicates not to handle the device with wet hands.

Indicates not to use the device near water or get it wet.

Indicates that instructions specified are compulsory (must be followed).

Indicates that the power cord must be unplugged from the outlet.

“Precautions” is explained in the following six sections.

Handling the FOMA terminal, battery pack, adapters (chargers),

and FOMA card (general). . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 11

Handling the FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . . P. 12

Handling battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 15

Handling adapters (chargers) . . . . . . . . . . . . . . . . . . . . . . . . . . P. 16

Handling FOMA card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 17

Handling mobile phones near electronic medical equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 17

Handling the FOMA terminal, battery pack, adapters (chargers), and FOMA card (general)

Danger

Do not use, store, or leave the FOMA terminal, battery pack, adapters (chargers) or FOMA card in locations subject to high temperatures, such as near a fire, in direct sunlight, or inside a car on a hot day.

The FOMA terminal may become deformed or malfunction. In addition, the battery pack may leak, overheat, explode, catch fire or suffer performance loss and a reduced service life. Part of the casing may also become hot and cause burns.

Do not attempt to disassemble or modify. In addition, do not attempt to solder.

May cause accidents such as fire, bodily injury, electric shock or malfunction. In addition, the battery pack may leak, overheat, explode or catch fire.

Do not get the FOMA terminal, battery pack, adapters (chargers) or FOMA card wet.

Contact with water, pet urine, and other liquids may cause overheating, electric shock, fire, malfunction or bodily injury. Be attentive to where and how you use the handset.

Use only the battery packs and adapters (chargers) specified by NTT DOCOMO for use with the FOMA terminal.

The use of devices other than those specified may cause the FOMA terminal, battery pack or other devices to leak, overheat, explode, catch fire or malfunction.

Battery Pack SH18 Desktop Holder SH24 FOMA AC Adapter 01/02 FOMA DC Adapter 01/02 FOMA Dry Battery Adapter 01

FOMA USB Cable with Charge Function 02

FOMA Portable Charging Adapter 01 ɦ For information on other compatible

products, contact a docomo Shop or retailer.

Warning

Do not place the battery pack, FOMA terminal, adapters (chargers), or FOMA card inside cooking appliances such as microwave ovens or pressure cookers.

The battery pack may leak, overheat, explode or catch fire, and the FOMA terminal and adapters (chargers) may overheat, emit smoke or catch fire. The internal circuitry may also be damaged.

Do not subject the FOMA terminal to strong impacts or throw it.

The battery pack may leak, overheat, explode or catch fire. Other devices may also be damaged or cause a fire.

Do not allow conductive materials (such as metal objects and pencil lead) to come into contact with the charger terminal or external device terminal. In addition, do not insert such objects.

The battery pack may short-circuit and cause a fire or malfunction.

Make sure to turn off the mobile phone in locations such as gas stations where flammable gas is generated. In addition, do not charge the battery. It may cause a gas explosion or fire.

To use Osaifu-Keitai in locations such as gas stations, make sure to turn off the power in advance (If the IC card lock is set, disable the lock before turning off the power).

Easy Search/Contents/Precautions

Continued on next page

Easy Search/Contents/Precautions

Continued use (charging) may cause overheating, explosion, or fire. In addition, the battery pack may leak.

The FOMA terminal may fall and cause injury or be damaged.

May cause a malfunction.

If you notice anything unusual, such as an unusual odor, overheating, discoloration or deformation during use, charging or storage, immediately follow the instructions below.

1. Unplug the power cord from the outlet or cigarette lighter socket.

2. Turn off the FOMA terminal.

3. Remove the battery pack from the FOMA terminal.

Caution

Do not leave the FOMA terminal on unstable surfaces, such as on a wobbling table or sloped surface.

Do not store the FOMA terminal in locations that are subject to humidity, dust or high temperatures.

If being used by a child, have a guardian teach him/ her the proper handling procedures. In addition, check that the child is using the FOMA terminal as directed.

May result in bodily injury.

Keep the FOMA terminal out of the reach of young children.

A young child may swallow components or suffer other bodily injury.

Be very careful when using the FOMA terminal connected to adapters (chargers) repeatedly or for long periods of time.

The FOMA terminal, battery pack or adapters (chargers) may become warm if i-appli, Videophone, or 1Seg is used for a long time while charging. Touch high temperature areas for a prolonged period of time may cause skin irritations, itchiness, or low-temperature burn in some people.

Handling the FOMA terminal

Warning

Do not aim the Infrared port towards the eyes.

May cause eye injury. In addition, do not aim or direct the Infrared port towards another Ir device as this may cause the device to malfunction.

Do not point the illuminated light directly at someone’s eyes.

May damage eyesight. May also cause momentary sight loss or startle someone and cause an accident.

Do not put the FOMA terminal in the place where it could be affected by an expanded airbag, e.g., on the dashboard.

If the air bag inflates, the FOMA terminal may hit you or others around you, resulting in bodily injury or damage to the FOMA terminal or other property.

If you are using electronic medical equipment, do not put the FOMA terminal in your breast pocket or in the inside pocket of your jacket.

Using the FOMA terminal in close proximity to electronic medical equipment may cause the equipment to malfunction.

Do not allow water or other liquids, metal, flammable material, or other foreign objects to enter the FOMA card or microSD Card port on the FOMA terminal.

May cause a fire, electric shock or other malfunctions.

Do not shine the light at anyone driving a car or other vehicles.

This may prevent a driver from driving safely and cause a traffic accident.

Turn off the FOMA terminal in areas where the use of mobile phones is prohibited, such as in aircraft or hospitals.

The FOMA terminal may interfere with the operation of electronic devices and electronic medical equipment. In addition, if Auto power ON function is set to ON, disable this function before turning off your mobile phone. Follow the instructions given by the respective medical facilities regarding the use of mobile phones on their premises. In addition, actions such as using on a mobile phone aboard aircraft are prohibited and may be punishable by law.

During a call in which Hands-free is set, keep the FOMA terminal away from the ears. When you attach the earphone/microphone to the FOMA terminal to play games or music, do not make the volume too loud.

Excessive high volume may damage your hearing. Also it may prevent you from hearing the ambient sounds and cause an accident.

If you have a weak heart, take extra precautions when setting functions such as the Vibrator and Ring tone volume for incoming calls.

Various settings may have effects on your heart.

If you hear thunder while using the FOMA terminal outdoors, put the antenna back into the FOMA terminal, immediately turn it off and move to a safe location.

There is a risk of being struck by lightning and suffering electric shock.

Turn the FOMA terminal off near high-precision electronic devices or devices that use weak electronic signals.

The FOMA terminal may interfere with the operation of electronic devices.

Take particular care with the following devices:

Hearing aids, implanted cardiac pacemakers, implanted cardioverter-defibrillators, or other electronic medical equipment. Fire alarms, automatic doors, and other equipment controlled by electronic signals. If you use an implanted cardiac pacemaker, implanted cardioverter-defibrillator or other electronic medical equipment, contact the respective manufacturer or vendor to check whether the operation of the equipment is affected by signals.

In case that the display part or camera lens is damaged, make sure to pay attention to a broken glass and the exposed inside of the FOMA terminal.

The surface of the display is covered by a protective film or the surface of camera lens are covered by a plastic panel so as to minimize the possibility of glass scattering. However, touching the broken display or camera lens may cause injury.

Easy Search/Contents/Precautions

Continued on next page

Easy Search/Contents/Precautions

The FOMA terminal may hit you or others around you, resulting in bodily injury or damage to the FOMA terminal or other property.

The antenna may hit others, resulting in an accident such as bodily injury.

Touching the antenna may cause an accident such as burn or other injuries.

Use Motion tracking to operate by tilting and shaking (or swinging) the FOMA terminal. The FOMA terminal may hit people or objects, if shaken (or swung) too much, and cause a serious accident or damage, etc.

Caution

Do not swing the FOMA terminal by its antenna, strap, etc.

Do not use the FOMA terminal in area with many people.

Do not use the FOMA terminal with the damaged antenna.

When using Motion tracking, confirm the safety of surroundings, hold the FOMA terminal securely and do not swing it around more than necessary.

If using Motion tracking with the FOMA terminal to which metallic straps or others are attached, be careful not to hit people or objects with the straps.

May result in bodily injury or damage to the FOMA terminal or other property.

Never place a magnetic card near or in the FOMA terminal.

The stored magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

Never place magnetized items near the FOMA terminal.

Putting highly magnetized items closer may cause a malfunction.

If the display is broken and the liquid crystal then leaks, do not lick or inhale the liquid or get the liquid on your skin. If the liquid comes into contact with your eyes or mouth, immediately rinse your eyes or mouth with clean water and see a doctor. If the liquid comes into contact with your skin or clothes, immediately wipe it off with alcohol, and wash with water and soap.

May result in loss of eyesight and harmful to your skin.

While the ring tone is ringing or a melody is played on the FOMA terminal, do not put the ears closer to the speaker.

This may cause hearing loss.

On the surface of the display, there is a protective film for securing the safety (for preventing the reinforced glass panel from shattering) in case of the damage caused by a drop, impact, etc. Do not forcibly peel off or scratch this film.

Using the FOMA terminal with the film removed may cause a bodily injury when the display is damaged.

Using the FOMA terminal in an automobile may sometimes affect the electronic equipment in some vehicle models.

In such cases, stop using the FOMA terminal, as this could impede safe driving.

Use of the FOMA terminal may cause skin irritations such as itchiness, rashes or eczema in some people. If this occurs, immediately stop using the FOMA terminal and seek medical treatment.

The following parts contain metals.

Do not close the FOMA terminal on your fingers or objects such as the strap.

May result in bodily injury or cause a malfunction.

Watch 1Seg in a well-lit place, keeping a certain distance from the screen.

Otherwise, eyesight may be decreased.

Handling battery pack

Check the type of battery using the information printed on the battery pack label.

Label Battery type

Li-ion 00 Lithium-ion

If you are having difficulty fitting the battery pack to the FOMA terminal, do not use excessive pressure to force the battery into place. Check that the battery pack is facing the correct direction before you attach it.

The battery pack may leak, overheat, explode or catch fire.

Do not throw the battery pack into a fire.

The battery pack may leak, overheat, explode or catch fire.

Easy Search/Contents/Precautions

Part Material

Surface of FOMA terminal (back of display side)

Surface of FOMA terminal (slide hinge section on the back of display side)

Metal section of 1Seg antenna

External connector terminal

Memory Card slot Charger terminal Gold plating

Magnesium

SUS

Brass

SUSInside microSD

Surface

treatment

Coating

Nickel plating

Danger

Do not touch terminals with metallic objects such as wires. In addition, do not carry or store the battery pack with metallic necklaces, etc.

The battery pack may leak, overheat, explode or catch fire.

Do not puncture, hit with a hammer or step on the battery pack.

The battery pack may leak, overheat, explode or catch fire.

If the battery fluid comes into contact with your eyes, do not rub your eyes but immediately rinse your eyes with clean water. Then seek prompt medical treatment.

May result in loss of eyesight.

Continued on next page

Easy Search/Contents/Precautions

The battery pack may leak, overheat, explode or catch fire. Other equipment may also be damaged or catch fire.

The battery pack may leak, overheat, explode or catch fire.

The battery fluid is flammable and could ignite, causing a fire or explosion.

Warning Caution

If any trouble is found on the battery pack due to an external impact such as a deformation or scratches caused by a drop, immediately stop using it.

If the battery pack is not fully charged after the specified time has elapsed, stop charging.

If the battery pack leaks or emits an unusual odor, immediately stop use and move it away from any flame or fire.

Prevent your pet from biting the battery pack.

May cause fires or damage to the environment. Place tape over the terminals to insulate unnecessary battery packs, and take them to a docomo Shop, retailer or institution that handles used batteries in your area.

The battery pack may overheat, catch fire or explode.

Battery fluid is harmful to your skin.

Handling adapters (chargers)

Do not dispose of used battery packs in ordinary garbage.

Do not charge a wet battery pack.

If the battery fluid comes into contact with your skin or clothing, stop using the FOMA terminal immediately and rinse it off thoroughly with clean water.

Warning

Never use the AC adapter or desktop holder in humid locations such as a bathroom.

May result in electric shock.

The DC adapter should only be used in negative grounded vehicles. Never use these adapters in positive grounded vehicles.

May cause a fire.

Do not touch the FOMA terminal or adapters (chargers) if you hear thunder.

There is a risk of being struck by lightning and suffering electric shock.

Take care not to short-circuit the charging terminal when connected to an outlet or cigarette lighter socket. Also, take care not to allow any part of your body (hands, fingers, etc.) to come into contact with the charging terminal.

May result in a fire, equipment malfunction, electric shock or bodily injury.

The battery pack may leak, overheat, explode or catch fire. Other equipment may also be damaged or catch fire.

Do not use if the adapter’s (charger’s) cord or power cord is damaged.

May cause electric shock, overheating or fire.

Place the charger and desktop holder on stable surfaces when charging. In addition, do not cover or wrap the charger or desktop holder with clothing or bedding.

The FOMA terminal may detach, overheat, or cause a fire or malfunction.

Do not place heavy objects on the adapter’s (charger’s) cord or power cord.

May cause an electric shock or fire.

Do not handle the cord and plug of the adapters (chargers) with wet hands.

May result in electric shock.

Always use the specified power supply and voltage.

Using the incorrect voltage may cause a fire or malfunction. When using overseas, use the AC adapter that is available overseas. AC adapter: 100V AC DC adapter: 12/24V DC (for negative grounded vehicles only) AC adapter available overseas: 100 to 240V AC (Connect only with household AC outlet)

If the fuse in the DC adapter blows, always replace it with a fuse of the specified type.

Using the fuse other than the specified one may cause a fire or malfunction. Refer to the respective manuals for information on the correct fuse specifications.

Wipe off any dust on the power plug.

May cause a fire.

When plugging the AC adapter into the outlet, make sure that no metallic straps or other metallic objects are caught between the plug and the socket.

May cause electric shock, short-circuiting or fire.

Always grasp the power plug when unplugging the adapters (chargers) from the outlet or cigarette lighter socket. Do not forcibly pull by the adapter’s (charger’s) cord or power cord.

Pulling on the cord may damage the cord and cause an electric shock or fire.

Unplug the power cord from the outlet when not using for a long time.

May cause an electric shock, fire, or malfunction.

Should water or other liquids enter the adapters (chargers), remove the power plug from the outlet or cigarette lighter socket immediately.

May cause an electric shock, smoke emission or fire.

Always unplug the power plug from the outlet or cigarette lighter socket before cleaning the adapters (chargers).

May result in electric shock.

Handling FOMA card

Caution

Be careful with the cutting surface when detaching the FOMA card (IC).

May cause injuries to your hand or fingers.

Handling mobile phones near electronic medical equipment

The precautions detailed here conform to the guidelines drawn up by the Electromagnetic Compatibility Conference Japan, regarding the protection of electronic medical equipment from signals emitted by mobile phones.

Easy Search/Contents/Precautions

Continued on next page

Easy Search/Contents/Precautions

Do not take your FOMA terminal into

Turn off your FOMA terminal inside

Turn off your FOMA terminal even when

Where a medical facility has specific

If Auto power ON function is set to ON,

Electromagnetic signals may affect the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Warning

Observe the following in hospitals or other medical facilities.

operating rooms, ICUs (Intensive Care Units) or CCUs (Coronary Care Units).

hospital wards.

you are in an area outside hospital wards, such as a hospital lobby, since electronic medical equipment may be in use nearby.

instructions prohibiting the carrying and use of mobile phones, observe those instructions strictly.

disable this function before turning off your mobile phone.

Turn off your FOMA terminal in crowded places such as rush-hour trains in case somebody nearby is using an implanted cardiac pacemaker or implanted cardioverter-defibrillator.

If you have an implanted cardiac pacemaker or an implanted cardioverter-defibrillator, always carry or use your FOMA terminal at least 22 cm away from your implant.

Electromagnetic signals may affect the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Patients receiving medical treatment away from a hospital or medical facility (e.g. home treatment) who are using electronic medical equipment other than implanted cardiac pacemakers or implanted cardioverter-defibrillators should consult the respective manufacturers for information regarding the effects of signals on the equipment.

Electromagnetic signals may affect the operation of electronic medical equipment.

Handling precautions

General notes

Do not expose to water.

FOMA terminal, battery pack, adapters (chargers) and FOMA card are not waterproof. Do not use in humid or steamy areas such as bathrooms and avoid exposing to rain and other forms of moisture. If FOMA terminal is carried close to skin, perspiration may cause internal components to corrode and result in malfunction. Note that if problem is found to be due to moisture, handset and parts are not covered by warranty and in some cases may be irreparable. Even where repairs are possible, repair charges will be incurred since damage is not covered by warranty.

Clean only with a soft and dry cloth

(such as the type used for eyeglasses).

The surface of the handset’s LCD has a special coating to improve the visibility of the color display. Forceful rubbing of LCD with a dry cloth may scratch LCD surface. Handle the handset carefully and clean using a soft and dry cloth (such as the type used for eyeglasses). Note also that LCD coating may peel off or stain if moisture or soiling is left on the surface for a long period. Never use chemicals such as alcohol, thinners, benzene or detergents, as these agents may erase the printing on the handset or cause discoloration.

Occasionally clean terminals with a

dry cotton swab.

Unclean terminals may result in poor connections and loss of power. Additionally, keep terminal clean with a dry cloth or cotton swab to prevent charge performance loss.

Do not place the handset near an air

conditioning vent.

Condensation formed due to rapid changes in temperature may cause internal corrosion and lead to malfunction.

Do not apply excessive force to the

FOMA terminal and battery pack when using them.

Carrying the handset in a tightly packed bag, or sitting on the handset in your pocket may cause a damage to display, other internal components or battery pack, or result in malfunction. Keeping an external connector device plugged into the external connector terminal (earphone/microphone terminal) may cause a damage to the connector or result in malfunction.

Read the manuals supplied with the

FOMA terminal, adapters (chargers), and desktop holder carefully.

Do not rub or scratch the display

with metal, etc.

May scratch the handset and cause malfunction or damage.

Notes about the FOMA terminal

Do not forcefully press a surface of

the touch panel, or operate with a pointed object such as a fingernail, ballpoint pen, pin, etc.

May damage the touch panel.

Avoid using the handset in

extremely high or low temperatures.

Use the FOMA terminal within the range of a temperature between 5Ɏ and 35Ɏ and

a humidity between 45% and 85%.

Using the handset close to landline

phones, TVs or radios may affect the operation of such equipment. Move as far away as possible from such items before use.

Keep a separate memo and note information stored in the FOMA terminal.

DOCOMO shall not be liable for any loss of content.

Do not drop or otherwise subject the

FOMA terminal to severe impact.

May cause a malfunction.

When connecting an external connector device to the external connector terminal (earphone/microphone terminal), do not put it in obliquely or do not pull it while it is plugged in.

May damage the handset and cause malfunction.

Do not close the FOMA terminal on

strap, etc.

May damage the handset and cause malfunction.

FOMA terminal may become warm

during using or charging but this is not a malfunction.

Do not leave the camera in direct sunlight.

May cause discoloration or burn-in.

Use the FOMA terminal with the external connector terminal cover on.

Dust, water and others enter inside and cause a malfunction.

Do not use the FOMA terminal

without the back cover.

May detach the battery pack or cause malfunction or damage.

Do not paste a label or sticker on the

back of the FOMA terminal display.

The FOMA terminal is caught by the label or sticker when opened or closed, and it may cause malfunction or damage.

While using a microSD Card, do not

remove the card or turn off the FOMA terminal.

May cause data loss or malfunction.

Notes about battery pack

Battery pack is a consumable product.

Though usage time varies with use, change battery if battery level is extremely low even after fully charged. Purchase a specified new battery pack.

Charge battery in areas where ambient temperature is between 5°C and 35°C.

Always charge the battery before the

first use or after not using battery for a long time.

Easy Search/Contents/Precautions

Continued on next page

The usage time for a battery

Easy Search/Contents/Precautions

Depending on usage, the battery

Do not store or leave the battery

Note the followings when the battery

Do not charge battery pack in the

Adapters (chargers) may become

depends on the usage and deterioration of battery pack.

may swell as it approaches the end of its service life but this will not cause problems.

pack with no battery left.

May lower the performance or shorten the life of the battery pack.

pack is stored for a long term.

 The storage with the battery pack fully

charged (immediately after charging is completed)

 The storage with no battery level

(cannot turn the FOMA terminal on) May lower the performance or shorten the life of the battery pack. The second level of the battery pack icon is recommended as the battery level for long-term storage.

Notes about adapters (chargers)

Charge battery in areas where ambient temperature is between 5°C and 35°C.

following locations:

 Areas with high humidity or dust, or in

areas exposed to strong vibrations

Close to landline phones, TVs, radios, etc.



warm during charging but this is not a malfunction.

Do not use DC adapter to charge battery when the car engine is not running.

May cause car battery to run down.

When using an outlet with a feature to prevent the plug from being removed accidentally, follow instructions in the outlet user’s guide.

Do not subject to strong force or

impacts. Also, do not disfigure the charger terminals.

May cause a malfunction.

When putting back the stand of the desktop holder, do not catch a finger or the cord of the adapters (chargers).

May result in bodily injury or cause a malfunction.

Notes about FOMA card

Do not apply unnecessary force when inserting/removing the FOMA card.

FOMA card may become warm during using but this is not a malfunction.

Customer is responsible for

malfunctions arising from inserting FOMA card into a different IC card reader/writer.

Always keep IC area clean.

Clean only with a soft and dry cloth (such as the type used for eyeglasses).

Keep a separate memo and note

information stored in the FOMA card.

DOCOMO shall not be liable for any loss of content.

To protect the environment, please take any unnecessary FOMA cards to your local docomo Shop or retailer.

Avoid using in extremely high or low

temperatures.

Do not damage, touch haphazardly

or short-circuit the IC.

May cause data loss or malfunction.

Do not drop or otherwise subject the

FOMA card to severe impact.

May cause a malfunction.

Never bend or place heavy objects

on the FOMA card.

May cause a malfunction.

Do not insert the FOMA card to the

FOMA terminal with a label or sticker attached on the card.

May cause a malfunction.

Notes on using Bluetooth function

FOMA terminal supports the security function that merity may not be sufficient depending on the configuration. Take care of the security while making communication using Bluetooth function.

Even if any leak of data or

information occurs while making communication using Bluetooth function, DOCOMO shall not be liable for any loss of content.

Before Using the Handset

Component names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Viewing display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Operations with touch panel . . . . . . . . . . . . . . . . . . . . . . .<Touch panel>33

Setting and selecting menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Displaying Support Book. . . . . . . . . . . . . . . . . . . . . . . . . <Support Book>40

Using FOMA card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <FOMA card>40

Attaching/Removing battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Checking battery level. . . . . . . . . . . . . . . . . . . . . . . . . . . . <Battery level>49

Turning power ON/OFF . . . . . . . . . . . . . . . . . . . . . . . <Power ON/OFF>50

Changing screen display to English . . . . . . . . . . . . . .<Select language>50

Making initial setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Initial setting>50

Setting date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . <Date settings>51

Notifying the other party of your phone number . . . . . . <Notify caller ID>52

Checking your own phone number . . . . . . . . . . . . . . . . . <Own number>52

Before Using the Handset

Component names and functions

Using earphone

Connect an earphone compatible with external connector terminal (sold separately). When using an earphone which does not support external connector

terminal, connect with an earphone plug adapter for external connector terminal (sold separately).

Connection example for flat-plug earphone/ microphone with switch (sold separately)

Connector

Flat-plug earphone terminal

Flat-plug connector of flat-plug earphone/microphone with switch (sold separately)

ɦ Key illustrations are examples and may look different from actual keys.

1 Earpiece

Listen to the other party’s voice. Listen to Record message/Voice memo.

2 1Seg antenna (nP. 227)

Use to receive 1Seg.

3 Keybord (nP. 26, P. 404) 4 microSD Card slot (nP. 334) 5 Charger terminal (nP. 48)

Terminal for charging with the desktop holder.

6 Strap ring 7 Brightness sensor (nP. 103)

The sensor detects the light of the surrounding area and automatically

adjusts the display brightness and turns on/off the keypad backlight. Do not cover the sensor area with your hand or a sticker. May

interfere with the sensor.

8 Display (nP. 28) 9 Called/Charging LED

Flashes while receiving a call, etc. (nP. 107). Illuminates while charging (nP. 45).

a Front clear key z

Press to return to the previous screen. Use to delete text or phone numbers. Press to disable the lock of touch panel, side key and front clear key.

Press for 1+ seconds to lock again (nP. 120).

b Mouthpiece/Microphone

Sends out your own voice.

c Speakers

Emits ring tones, music, etc. Emits the other party’s voice during hands-free operation.

d Picture light

Illuminates while activating the camera (nP. 202). Illuminates/Flashes during shooting (nP. 207, P. 209).

e Infrared port

Use for the Ir communication (nP. 351). Use for the Ir remote control (nP. 356).

f Camera

Use to shoot still pictures or movies (nP. 202).

Use to send a camera image shot during a Videophone call to the

othe

r party (nP.

54).

g Back cover (nP. 44)

A radio frequency-preventing sticker is attached on the back of the

back cover. Do not peel off this sticker.

h b mark

The IC card is included (The IC card cannot be removed). Use

Osaifu-Keitai holding the b mark up to the scanning device (nP. 287).

Use to send and receive data via the iC communication (nP. 356).

i Shutter/PushTalk key & (q)

Press to use the PushTalk phonebook (nP. 78). Press while using a camera to shoot (nP.000). Press for 1+ seconds to enable/disable the VeilView (nP. 110).

j Start/Hands-free key s

Press in the close position to display the Dial input screen (nP. 35). Press to make or receive a voice call. Press to use Hands-free (nP. 55, P. 76). Press for 1+ seconds in the close position to turn on/off the picture

light.

Press for 1+ seconds while using a function to use Multi Assistant

(nP. 370).

k Power/End key H

Press for 2+ seconds to turn the power on/off (nP. 50). Use to end the function being used and return to stand-by display.

l FOMA antenna

An antenna is built in. To speak in better conditions, do not cover the

antenna area by hand.

m External connector terminal

Integrated terminal used while charging, connecting the earphone,

etc.

Connect to an external device such as AC adapter/DC adapter,

FOMA USB Cable with Charge Function 02 (sold separately) (nP. 47, P. 345).

Before Using the Handset

Keyboard

The following mainly explains operations in the stand-by display. For

details on inputting text nP. 404

143

7 6

1 Numeric key 0 to 9

Enter a phone number or number. Press 1, 2, or 3 for 1+ seconds to use assigned functions

(nP. 380).

Press 4 for 1+ seconds to check your present location (nP. 296). Press 5 for 1+ seconds to set font size collectively (nP. 110). Press 6 for 1+ seconds to turn on/off the Bluetooth power

(nP. 393). Press 7 for 1+ seconds to record Voice memos or play Voice

memos/Recorded messages (nP. 70, P. 384). Press 8 for 1+ seconds to start to use 2in1 or switch modes

(nP. 423, P. 424). Press 9 for 1+ seconds to reset Kisekae Tool settings or Font style

setting (nP. 105, P. 109).

2 Keys for operation guidance U to P

Press to execute the functions of the operation guidance (nP. 27).

3 Quick search key $

Press to use Quick search (nP. 381).

4 Clear key c

Press to display the i-Channel list (nP. 182). Press to return to the previous screen. Use to delete texts and phone numbers. Press with holding > to work in the same way as H.

5 Multi-guide key wt

Move the cursor to select an item and execute or set ( Press to displa

i-Widget screen and Shortcut menu.

Press t for 1+ seconds to use Lock selection (nP. 119). Press r for 1+ seconds to display the Sent messages history

(nP. 150)

Press q for 1+ seconds to display the Received messages history

(nP. 150).

Press u for 1+ seconds to adjust the earpiece volume (nP. 96).

6 Guidance key |

Press to display the operation guidance (nP. 27).

7 X/MULTI key X

Press to use Multi Assistant (nP.000).

8 S/b key S

Enter Press for 1+ seconds in stand-by/while receiving a call to enable/

9 D/# key D

Enter #. Press for 1+ seconds in stand-by/while receiving a call to enable/

disable the Public mode (Drive mode) (nP. 67).

disable the Manner mode (nP. 99).

y Menu, Redial list screen, Received calls list screen,

. 27).

Opening the FOMA terminal

To open the FOMA terminal, push its display side up as shown.

Close position Open position

When making a Videophone call in the open position, use the

earphone/microphone (sold separately) or use hands-free.

ɡ Changing vertical/horizontal view

The display is automatically changed between the vertical view and the horizontal view just by tilting the FOMA terminal as shown. Use the FOMA terminal with closed and turned sideways or longways. In the open position, the screen is displayed in the horizontal view regardless of direction of the FOMA terminal. The screen may not be changed depending on the function and screen in

use.

The vertical/horizontal view may not work properly immediately after the

screen/power is turned on.

Rotate 90° to

the left

Rotate 90° to

the right

Sideways

ɡ Open position

Press the keys allotted as follows to select or execute the menus items in the guidance. If the operation guidance is not displayed, press | to display. Press |

again to hide.

For inputting texts, press with holding > (nP.000).

UI PO

The operation guidance for i-appli can also be operated by pressing its

allotted keys U to P. Presence or absence of the operation guidance, or position for the guidance may differ depending on software.

ɡ Operation guidance menu

In the operation guidance, menus appear according to the used function and situation. The following table describes examples of the main operation guidance menus that appear.

Before Using the Handset

Longways

The display may not be changed depending on the function.

Operation guidance

The operation guidance appears at the lower part of the display.

ɡ Close position

Directly touch the keys for operation guidance to select or execute the menus items in the guidance.

OK Sets the selected item Submenu Displays the Submenu Full Displays selected images, etc. in full screen Show all Displays sorted files, etc. as a list IrSS Sends via Ir communication Mail Displays the compose message screen Send Sends a message Cancel Cancels the operation such as receiving a message SelAll/ClrAll Selects/Disables all selectable items

(Up to 50 items can be selected/disabled depending on the function)

Page F/Page G Scrolls the display by page I page /H page Switches pages

3 i-mode/Full Browser (nP. 164, P. 190)

Before Using the Handset

Viewing display

12345 7

pmlkjihgn

q or f e d

1 Signal status

]

When A appears, the handset is outside the service area or in a

place with no signal. Signal icon can be changed (nP. 106).

2 Battery level/Charging (nP. 49)

Indication of the signal strength

] no p

Strong Weak

6 a8 9

<z wx

b c

7=A A

Indicates i-mode/Full Browser status

BNO

4 SSL (nP. 166, P. 190)

SSL compatible sites are viewed

When o appears while Multi Assistant is used, function such as

i-mode, Full Browser, i-appli or Software update is being used with Multi Assistant.

5 i-appli (nP. 261)

*i-appli is set as the stand-by display, but cannot be used. The i-appli icons do not appear in the i-Widget screen.

6 GPS (nP. 296, P. 304)

A (blue)

A (gray)

SSL compatible Internet web pages are viewed SSL/TLS pages are viewed

i-appli is being activated i-appli stand-by is being activated

i-appli stand-by is set

i-appliDX is being activated i-appliDX stand-by is being activated

i-appliDX stand-by is set

Location request menu is set to [Loc. provision:ON]/ [Reject No. unset] Location request menu is set to [Permission sched.] and Location provision is permitted

Location request menu is set to [Permission sched.] and Location provision is rejected

{

Battery icon can be changed (nP. 106).

Battery level

Charging

GPS positioning

7 Ir communication/Bluetooth communication/External device

e Record message (nP. 69)

Data is communicated with another device using the Ir

t (green)

t (red)

8 i-mode mail/SMS/Area Mail received (nP. 138)

UhH

9 Message R/F received (nP. 155)

ABJ

a Storage status of i-mode center (nP. 138, P. 155)

communication function (nP. 351) Data is sent using the Ir remote control (nP. 356)

Data is communicated with another device using the Bluetooth function (nP. 395)

Connected to commercially available Bluetooth compatible keyboard (nP. 394)

Connected to an external device and transmitting packets

Connected to an external device and sending/receiving packet data

Connected to an external device and transmitting 64K data

Indicates the status of the i-mode mail/SMS/Area Mail reception Indicates the status of the memory to store received mail

Indicates the reception status of the Message R/F Indicates the status of the memory to store Message R/F

]

When there are messages, D to P appears, indicating the total

number of both types of messages. When there are three Record messages (voice calls) and two Record messages (Videophone), k appears.

f Silent (nP. 95)

[

g Vibrator (nP. 97)

h Manner mode (nP. 99)

i Public mode (Drive mode) (nP. 67)

j i-appli call (nP. 276)

k IC card lock (nP. 288)

Record message is set

The phone ring volume [Silent] is set

Vibration mode is set

Manner mode is set

Public mode (Drive mode) is set

New i-appli call

Before Using the Handset

WGIX

STKL

The status may not always be indicated even if messages are held at

the i-mode center.

b microSD Card (nP. 334)

^ (gray) ^ (pink)

c Clock display (nP. 51)

Small clock icon can be changed (nP. 106).

d 1Seg being recorded (nP. 235)

microSD Card is inserted

microSD Card is being used

1Seg is being recorded

Indicates the storage status of the mail and Message R/F

l Restriction indicator (nP. 115, P. 121)

T U V W

K (red)

IC card is locked

Secret mode is set

Secret data is being edited

Keypad dial lock

All lock is set

Function lock is set

Keypad dial lock and Function lock are set

Secret mode, Function lock and Keypad dial lock are set

Continued on next page

Before Using the Handset

K (blue)

m Hands-free (nP. 55, P. 76, P. 393)

; (red)

; (green)

n Alarm (nP. 236, P. 372, P. 377)

Touch panel/Side key lock, Secret mode, Function lock and Keypad dial lock are set

Touch panel/Side key lock is set

Hands-free in progress

USB hands-free in progress

Mute in progress (only when in the open position)

Bluetooth hands-free in progress

r USB mode (nP. 345)

s FOMA card error

t Self mode (nP. 117)

u PushTalk (nP. 76)

FOMA USB Cable with Charge Function 02 (sold separately) is connected in the Communication mode

Appears when FOMA card is malfunctioning or not inserted

Appears when a card other than the FOMA card is inserted

Self mode is set

Alarm is set Schedule alarm is set

* Appears only when an Alarm is set for that day.

o Music&Video Channel program reservation (nP. 245)

p i-mode mail send reservation (nP. 138)

= ;

q Earphone/microphone connection (nP. 388)

Appears when Auto answer for PushTalk is set even if an earphone/

microphone is not connected.

Reception reserve alarm is set Recording reserve alarm is set Wakeup TV is set

Appears 12 hours before Music&Video Channel program distribution

Mail with send reservation

Mail failed to be automatically sent

When voice/Videophone call in Auto answer setting is set to [ON] and while an earphone/microphone (sold separately) is connected When PushTalk in Auto answer setting is set to [ON]

* *

v Bluetooth (nP. 391)

L (blue)

L (gray)

The Bluetooth icon does not appear during SSL page display.

w VeilView (nP. 110)

The VeilView icon does not appear during International roaming or

while 1Seg is recorded.

x 3G/GSM

4 (green) 4 (red)

K J

During PushTalk transmission

Stand-by for Bluetooth registration Stand-by for Bluetooth connection Connected to Bluetooth

During power saver mode for Bluetooth (Appears when data is not transmitted from the FOMA terminal for a set length of time)

VeilView is set

3G network (Packet transmission is available)

3G network (Packet transmission is not available)

GSM/GPRS network (Packet transmission is available)

GSM/GPRS network (Packet transmission is not available)

y Status of Comics setting (nP. 363)

I H

Status of Comics setting icon does not appear during hands-free

operation or receiving information display.

z ToruCa (nP. 290)

The ToruCa icon does not appear during hands-free operation,

receiving information display or e-comic display.

< Receiving information (nP. 185)

Receiving information icon does not appear during hands-free

operation.

> Multitask (nP. 370)

Indicates functions that are running.

Four or more applications

are running

Videophone

Voice call

Phonebook

PushTalk/

PushTalk phonebook

Modem transmission (appears during data

transmission)

Frame display is set

Page display is set

Unread ToruCa

New information

Shoot still picture

Shoot movie

Character reader (OCR)

Bar code reader

Card reader

]

Information reader

Shotdeco

)

Voice recorder

Schedule

Quick search

Receive via Ir/iC/USB/

Bluetooth communication

i-appli

i-mode, i-Channel, WEB Mail

Full Browser, Internet movie

player

i-concier

Receive information

Mail, SMS, Message R/F,

Check new messages

Mail/Decome-Anime/SMS

being composed

Received calls

Received messages

;

Redial

Sent messages

microSD Card is referred to as [microSD] or [SD] on the FOMA terminal

(nP. 334).

Some of the screen shots in this manual have been modified or

abbreviated.

The display for the FOMA terminal is manufactured using

high-precision technology, but it may occasionally contain dots that fail to light or that remains permanently lit. This is not a malfunction.

ToruCa

Alarm

{

Timer

microSD

}

General settings

Voice memo/Record

message

Document Viewer

1Seg

Reception reserve/ Recording reserve alarm

sounds

Data Security Service

Data box

MUSIC

Own number

Before Using the Handset

Software update

Map/GPS

Bluetooth function

(

Text memo, Stand-by memo

Calculator

Manga&BookReader

Before Using the Handset

Checking notices with stock icon

Display stock icons in stand-by when a call is missed or new mail is received. In stand-by, select stock icons to check notice details.

Number of entries Message

Stock icon

Stock icon type

Icon Message Page

xx missed call

Recorded messages Fxx message/Axx message

xx voice mail

xx mail message P. 139, P. 160

P. 68

P. 70

P. 415

Icon Message Page

Send loc - No resp P. 306

*1 When the 2in1 mode is set to [Dual mode], the number of [A mode] and

[B mode] appears each.

*2 The message that appears differs depending on the menu screen or

position of the FOMA terminal.

In stand-by, a stock icon appears.

Select the stock icon.

: Touch the stock icon to point the cursor and touch again. : After the details are checked, the stock icon and message disappear.

Stock icons do not appear while the i-motion set as stand-by is played

or the i-appli stand-by is being activated.

Send loc - Resp P. 306 Send loc - Failed P. 306

New i-appli call P. 276

Custom menu/Basic menu/Menu

P. 38

L Q

t g

xx New Message R P. 156

xx New Message F P. 156

xx new ToruCa P. 290

New auto send result P. 138

Update complete P. 497 Check update P. 497 Update required P. 495 Check for update P. 495

USB mode setting P. 345

Download successful (Music&Video Channel)

Download failed (Music&Video Channel) P. 245

Charge limit exceeded P. 385

P. 245

Displaying and operating i-Widget

In the i-Widget screen, multiple i-Widget can be activated simultaneously and viewed as a list. For details on operation of i-Widget nP. 282

1 Area where Widget appli is pasted

Slid

2 Setting status icons for Widget appli

For details on the setting status icons

nP. 261

3 Operation guidance

Available menus appear.

Touch panel

Operations with touch panel

Operate by putting the finger on the touch panel (screen).

In this manual, operations with touch panel are mainly explained.

Before Using the Handset

i-Widget screen

Activating i-concier with popup message

Display popup messages in the stand-by display when information is received. Activate i-concier with the popup messages to check information details.

In stand-by, a popup message appears.

Select the popup message.

: Touch the popup message to point the cursor and touch again. : The popup message disappears after activating i-concier.

Touch panel

The operations differ depending on the

function and screen in use. The message stating that the operation is not available appears when the touch panel cannot be used.

Operate the touch panel inside the

operating range of touch panel in the figure. However, the area where the operation guidance appears cannot be touched in the open position.

The notation of operation described in this

manual and its meaning are shown as follows.

ouc

Put the finger on the touch panel and put it off.

Keep the finger on the touch panel and slide it.

Operating range of touch panel

Calendar or Stand-by memo does not appear while a popup message

appears.

Continued on next page

Before Using the Handset

Quick slide

Quickly slide the finger and put it off.

When putting the finger on the touch panel, the tone sounds and the

vibrator is activated. However, they may not be activated in some cases, such as activating a camera, playing music, etc.

• The volume can be changed (nP. 96). The tone cannot be changed.

• The vibrator can be set to ON/OFF (nP. 97).

Putting the distance between two fingers apart/closer

Put two fingers on the touch panel and slide them with putting the distance between two fingers apart/closer.

When using the touch panel

The touch panel does not work when operated with a gloved finger or

with foreign objects placed on the operation pad.

Note that operating with a wet finger or putting a sticker to the touch

panel (display) may cause a malfunction.

Using menus or functions

Select each menu or keys by touching.

ɡ Operations in stand-by

Activate various functions such as activating the Stand-by Display Touch Launcher, moving the position of clock, changing the stand-by display, etc. by the touch operation in the stand-by display.

ɡ Selecting menu or item

Select a menu such as the Custom menu or a menu in the Stand-by Display Touch Launcher, etc. by touching the menu icon. For a menu in list format, touch the object to point the cursor and touch again to select.

Example: 1Seg setting menu

ɡ Switching pages

When a menu contains multiple pages, quickly slide to the left/right to switch pages.

Example: Mail setting

Slide to the

left

Slide to the

right

1/3 page 2/3 page

ɡ Control key

While using the function, touch the screen to display control keys.

Example: MUSIC Player

Before Using the Handset

• Touch the area other than the control keys to hide the control keys (excluding 1Seg).

Slide to the right

Slide to the left

ɡ Submenu (nP. 40)

Slide to

the right

3/3 page

Slide to the left

Touch [

The control keys always appear while camera is activated or music data

is played (excluding while displaying images/lyrics).

F] to display next keys.

ɡ Slide operation

The slide operation is available for adjusting the volume or scrolling the

screen.

Be careful not to touch a key displayed on the screen.

ɡ Number entry

When numbers such as the phone number, terminal security code, or Pin code are required to be entered, the numeric panel appears in the close position. Touch the numeric part. If an input field appears for time setting, etc., touch the field to move the cursor there and enter numbers in the position.

ɡ Character entry (nP.000)

Before Using the Handset

Locking touch panel

The touch panel is automatically locked while making a voice/Videophone/ PushTalk call, receiving a call, or calling (including while playing a reply message, recording sounds, and recording Voice memo (during call)) to prevent from errors. To temporarily disable the lock: Press z.

• Press z for 1+ seconds to lock again.

Touch panel lock is temporarily disabled when the

FOMA terminal is opened. It is locked again when the FOMA terminal is closed.

This function is not linked with Touch panel/Side

key lock (nP. 120).

e.g.) During a ca

Locking screen

Setting and selecting menu

Start menu Characteristics

Custom menu The preset Kisekae Tool (nP. 104) can be selected and

set. Each Kisekae Tool consists of different functions and designs. Kisekae Tools can be downloaded from sites and used.

Preset Kisekae Tools

 Black  ڐఱιΣνȜ(Large)  Ώϋίσ(Simple)  Θͼτ·ΠιΣνȜ

Basic menu Select the icon displayed on the menu to retrieve the

function.

In the Stand-by Display Touch Launcher, select [$]/

[Settings]/[Disp/LED/Power saver]/[Menu priority].

: In the Custom menu/Basic menu: Select [Submenu]/[Menu

priority].

Select the start menu/[Yes].

Set, change or save functions from the menu screens.

The explanations in this manual are based on how to retrieve a function from the Custom menu. As for functions retrieved from the Stand-by Display Touch Launcher and the Quick Settings, how to retrieve from those menus is individually explained.

Setting start menu <Menu priority>

Set the start menu that displayed when [$] is selected in the Stand-by Display Touch Launcher. When Stand-by touch launcher display is set to [OFF], touch the wall

paper on the stand-by display (excluding an area where the clock or i-Channel ticker is displayed, and the Pict area) to display the start menu.

ɡ Switching set start menu temporarily

Switch the start menu temporarily. When the stand-by display reappears, the start menu returns to the one set in Menu priority. Use the Horizontal display menu.

[Custom]

Touch the stand-by

display (wall paper)

[$]

[Basic]

Before Using the Handset

Stand-by (vertical)

Turn sideways/ Set to open position

Stand-by Display Touch Launcher

(horizontal)

Turn longways

Touch the

stand-by display

(wall paper)

Turn sideways/ Set to open position

Stand-by Display Touch

Launcher (vertical)

Turn longways

Stand-by (horizontal)

t (in the open position)

*1 When Stdby toch lnch disp is set to [OFF], the Start menu/Horizontal display menu appears. *2 Turning is not available in the open position.

[$]

Turn sideways/ Set to open position

Horizontal display menu

Basic menuCustom menu

Turn longways

Before Using the Handset

Retrieving a function from each menu

For details on operating shortcut menu nP. 380 For details on the available functions nP. 446 All menus can be operated by the touch operation, or with w. Touch a menu item to select from the Custom menu or Basic menu. For

menus in list format, such as 1Seg setting, touch a menu item to point the cursor and touch again. When a menu contains multiple pages, quickly slide to the left/right to change pages. Alternatively, scroll or change pages with w.

The method for selecting functions may differ depending on the Kisekae

Tool set for the Custom menu.

Press z or c to re-select a function, and the previous screen

reappears. Press H to return to stand-by.

When a stock icon (nP. 32) appears in stand-by, select G to show the each menu.

ɡ Retrieving from the Basic menu

[Acti-

vate

[1Seg]

Basic menu When [1Seg]

appears

1Seg]

ɡ Retrieving from the Horizontal display menu

When 1Seg is

activated

Touch operation or the way of activating 1Seg with the Multi-guide key is explained as an example below.

ɡ Retrieving from the Custom menu

[Acti-

vate

Custom menu

[1Seg]

When [1Seg]

appears

1Seg]

When 1Seg is

activated

[1Seg]

Horizontal display menu When [1Seg] appears

[Acti-

vate

1Seg]

When 1Seg is activated

When the Custom menu image is changed by Kisekae Tool, the

operation may differ from the description in this manual. In this case, switch the menu screen to the Basic menu (nP. 36) or perform the Reset menu screen (nP. 105).

Press the key corresponding to the menu item number when

connecting the Bluetooth compatible keyboard to select a function. However, in the Custom menu/Horizontal display menu, a function may not be selected by using the menu item numbers.

Retrieving a function from Quick Settings

Touch the Pict area in the stand-by display to display the Quick Settings. Touch each key to point the cursor and touch again to activate related setting menus. Press z or touch the area other than the Quick Settings to return to

the stand-by display.

For details on the avialable functions nP.000

Pict area

Touch the

Pict area

Retrieving a function from Stand-by Display Touch Launcher

Touch the wall paper on the stand-by display (excluding an area where the clock or i-Channel ticker is displayed, and the Pict area) to display the Stand-by Display Touch Launcher. Touch each key in the Stand-by Display Touch Launcher to activate the corresponding function. For details on the avialable functions nP.000

Touch the

wall paper

Wall paper

Before Using the Handset

Stand-by Quick Settings

Stand-by Stand-by Display

Touch Launcher

If no operations are performed for approximately 5 seconds, z, c, or

H is pressed, or the area other than the Stand-by Display Touch

Launcher is touched, the stand-by display reappears.

ɡ Setting whether to display Stand-by Display Touch

Launcher

In the Custom menu, select [Settings]/[Disp/LED/

Power saver]/[Set screen]/[Stdby toch lnch disp].

Select the setting.

Selecting a function from Submenu

Support Book

Before Using the Handset

While using the function, slide from the upper right to the lower left (or from the upper left to the lower right) to display the Submenu.

Submenu screen

To display the Submenu, touch [

the operation guidance or [ press I.

When the Submenu contains multiple pages, slide up/down to scroll the

screen and display items.

To hide the Submenu, touch the area other than the Submenu. Press

z or c to return to the previous screen (menu).

Submenu may not appear depending on the function.

C] of the control key, [Submenu] in

D] on the upper part of the screen, or

Displaying Support Book

Use this function for unsure operations. After the Support Book appears, check the explanation and operation procedures of each function. In addition, directly start functions that were looked up in the Support Book.

In the Stand-by Display Touch Launcher, select [9]/

[Support Book].

Select a menu or item.

: To start functions directly: Select the function to start/[Yes].

FOMA card

Using FOMA card

A FOMA card is an IC card that records personal information, such as phone numbers. A FOMA card can store phonebook data and SMS. By switching FOMA cards, multiple FOMA terminals can be used for different purposes as needed.

If a FOMA card is not inserted, transmission functions such as voice/

Videophone/PushTalk calls, i-mode, mail transmission and packet transmission are not available on the FOMA terminal.

Inserting/Removing FOMA card

Before inserting or removing the FOMA card, turn off the power, position

the back facing upwards and remove the battery pack. Close and hold the FOMA terminal firmly with your both hands.

ɡ Inserting FOMA card

Hook a finger on the tab and pull the tray out (1).

: Pull out the tray straight until it stops.

Hold the FOMA card with the IC

facing down and set on the tray (2).

Notch

IC (gold)

Inserting or removing the FOMA card forcibly may damage the card or

deform the tray. Use caution.

Refer to the FOMA card user’s guide for more information on the FOMA

card.

Do not misplace the FOMA card once it is taken out. When the tray falls off, slide the tray in straight along the guide rail.

Security codes

The FOMA card has a “PIN1 code” and a “PIN2 code”. Both are set to [0000] by default but can be changed to a four- to eight-digit number by the user (nP. 114).

Before Using the Handset

Push the tray all the way in (3).

Tab

Tray

Fit the notch of the FOMA card to that of the tray.

ɡ Removing FOMA card

Hook a finger on the tab, pull the tray out (1) and

remove the FOMA card (2).

: Do not allow the FOMA card to fall when removing it.

FOMA card security functions

The FOMA terminal has built-in FOMA card security functions (FOMA card restriction functions) as functions for protecting personal data and files. When data or files are retrieved using any of the following methods or

i-appli is running with the FOMA card inserted into the FOMA terminal, FOMA card security functions are automatically set in the retrieved data or files.  When a file such as an image, melody or PDF is downloaded from a

site or Internet web page

 When a site or Internet web page is saved as a screen memo  When i-mode mail with a file attached is received  When i-appli is running

Data, files or software with FOMA card security functions run only when

in use with the FOMA card inserted at time of acquisition. Display, play, attach to i-mode mail, run software, send data using Ir communication function and iC communication function, and copy to microSD Card can be executed. These operations cannot be performed if a different FOMA card is inserted.

The following indicates the data for which FOMA card security is set.

 Melody   Screen memo  Chaku-uta®/Chaku-uta full  Chara-den  File attached to Message R/F

Image (including animation and Flash movie)

Continued on next page

Before Using the Handset

 i-motion  ToruCa (details) image  PDF data  Image inserted to Deco-mail or signature  Kisekae Tool  Videophone picture memo  Machi-chara  i-appli (including i-appli stand-by)  Download dictionary  Download font  Contents transfer compatible data  Image in Message R/F  Music&Video Channel program  Deco-mail template with data which FOMA card security functions are

set

 Decome-Anime Template  e-book/e-dictionary/e-comic saved in the [Comic] folder  File attached to i-mode mail other than the following

• ToruCa Ȇ Phonebook Ȇ Schedule

• Bookmark Ȇ Documents

ɦ “Chaku-uta” is a registered trademark of the Sony Music

Entertainment (Japan) Inc.

The following indicates the settings saved in the FOMA card.

 Own number  PIN setting  Select language  SSL certificates  SMS center  SMS expiry  SMS input character

The following explanation refers to the FOMA card inserted at time of

data/files retrieval as “one’s own FOMA card” and other FOMA cards as “another’s FOMA card”.

One’s own FOMA card

One’s own FOMA card security functions are set for downloaded data, files attached to received mail and i-appli that have been run, allowing viewing and playback of data.

When one’s own FOMA card is replaced with another’s FOMA card, the

data or files for which FOMA card security functions are set cannot be set as stand-by displays or ring tones.

When a FOMA card is replaced with another’s FOMA card, FOMA card

security functions are activated and if data or file retrieved from a site is set as the stand-by display or ring tone, the setting is reset to the default. When one’s own FOMA card is re-inserted, the setting returns.

Different FOMA card

Another’s FOMA card

inserted

When another’s FOMA card is inserted, data with one’s own FOMA card security functions set cannot be viewed or played back.

Example: When setting [Melody A], for which FOMA card

security functions are set, as a ring tone

When one’s own FOMA card is taken out or is replaced with another’s FOMA card, ring tone returns to default setting. When one’s own FOMA card is put back, the ring tone returns to [Melody A].

FOMA card security functions cannot be set for data received using Ir

communication or data transmission functions, and still pictures/movies, etc. shot with the FOMA terminal.

It is possible to move or delete data or files for which FOMA card

security functions are set even when another’s FOMA card is inserted.

Running i-appli by selecting highlighted text in i-mode mail details

screen cannot be performed or retrieved when FOMA card security functions are set.

If the FOMA card is replaced with another’s FOMA card after i-appli

stand-by is set, the set i-appli cannot be activated in stand-by, and the image set in Stand-by display appears.

FOMA card type

Note the following differences between “FOMA card (blue)” and “FOMA card (green/white)” used on the FOMA terminal.

Function

Number of phone number digits available in the FOMA card phonebook

Client certificate operations for FirstPass

Use of WORLD WING Not available Available P. 430 Service Numbers Not available Available P. 421

FOMA card

(blue)

Up to 20 digits Up to 26 digits P. 86

Not available Available P. 179

FOMA card

(green/white)

Page

About WORLD WING

WORLD WING is a DOCOMO’s FOMA international roaming service that makes it possible to use the mobile phone number registered in Japan to make and receive calls even overseas by the FOMA card (green/white) and supported FOMA terminal. If subscribed to the FOMA service after September 1, 2005,

subscription for “WORLD WING” is not required. However, if subscription for “WORLD WING” is canceled at or after subscription for the FOMA service, subscription for “WORLD WING” is required again.

If subscribed to the FOMA service before August 31, 2005 but not

subscribed to “WORLD WING”, subscription for “WORLD WING” is required.

Some payment plans are not available. When the FOMA card (green/white) is lost or stolen overseas, promptly

contact DOCOMO and conduct a procedure for canceling the use of service. Refer to General Inquiries on the back of this manual for inquiries. Note that transmission/calling charges after the FOMA card is lost or stolen are incurred to the subscriber.

Before Using the Handset

Attaching/Removing battery pack

Use the Battery Pack SH18 exclusive to the FOMA terminal.

Turn off the power, close the FOMA terminal, and hold it in your both

hands before attaching or removing the battery pack.

ɡ Attaching battery pack

Push the catch on the back cover in the direction of

the arrow (1), slide approximately 2 mm (2) and

Attach the back cover (5).

: Attach the back cover as shown in the illustration and then push the

back cover and slide into place.

remove the back cover (3).

Attach the battery pack (4).

: The FOMA terminal has tabs that make it easy to attach. Attach the

battery pack with a recycle mark side faced up.

Face the side with a recycle mark up

Tabs

Battery pack connector terminal side

Battery pack

ɡ Removing battery pack

Follow step 1 of “Attaching battery pack” to remove

the back cover.

Remove the battery pack.

: The battery pack has a tab that makes it easy to remove. Hook a

finger on the tab to prevent excessive force on it and remove the battery pack upward.

Tabs

Using unnecessary force when attaching or removing the battery pack

may damage the connector terminal for the battery pack (charger terminal) on the FOMA terminal.

Firmly close the back cover. If not closed firmly, the back cover may

come off and the battery pack may fall out due to vibration.

Charging

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery using the exclusive AC or DC adapter (sold separately) before use.

ɡ Cautions while charging

Do not charge for long periods of time with the power left on. If the FOMA

terminal is left on after charging is complete, the battery pack charge decreases. In such cases, the AC or DC adapter charges the battery again. However, depending on when the FOMA terminal is disconnected from the AC or DC adapter, the battery charge level may be low, the battery alert tone may sound, or the battery may only be usable for a short time.

When the battery is empty and terminal is recharging, charging LED may

not illuminate immediately.

If the battery empty alert is displayed, the alert tone sounds and the

power cannot be turned on, charge the battery for a while.

If the battery empty alert is displayed and charging begins within 60

seconds of the alert tone, the status returns to normal.

While charging, terminal may not turn on even when charging LED is

illuminated in red. Charge longer and try turning power on again.

Frequently recharging the battery when its power is still remaining

enough may shorten the life of the battery pack. It is recommended to use the battery to a certain level before recharging.

The battery pack cannot be charged by itself.

Check that the battery pack has been properly attached when charging

LED flashes red. The LED also flashes red when the battery pack has reached the end of its service life.

The battery pack can also be charged with the FOMA terminal turned on

({ on the display flashes during charging). When charging is completed, charging LED turns off, and { on the display changes to ".

When the battery becomes warm, charging may automatically stop even

if the battery has not been fully charged. Charging resumes after the temperature lowers to an appropriate temperature. While charging is stopped, charging LED turns off ({ on the display flashes while stopped).

ɡ Estimated times of use when fully charged

Continuous talk time

Continuous stand-by time

1Seg watching time Approx. $$ min

FOMA/3G Voice call: Approx. $$ min

Videophone call: Approx. $$ min GSM Voice call: Approx. $$ min FOMA/3G3G/GSM

setting: 3G

3G/GSM setting: AUTO

GSM 3G/GSM

setting: AUTO

When mobile: Approx. $$ hr

At rest: Approx. $$ hr

Before Using the Handset

ɡ Estimated charge times and LED display

The following figures are estimated times for charging an empty battery pack with the FOMA terminal turned off.

FOMA AC Adapter 01/02 Approx. $$ min FOMA DC Adapter 01/02 Approx. $$ min

Charging LED illuminates in red while charging, and it turns off when

charging is completed.

Continued on next page

Before Using the Handset

Continuous talk time is estimated as the usage time at normal

transmission signal strength, and continuous stand-by time is estimated as the usage time while moving with the FOMA terminal closed at normal signal strength. Using i-mode reduces talk (transmission)/stand-by time. When i-Channel is subscribed, information is automatically received and updated, so talk (transmission)/stand-by time will be reduced. In addition, when shooting or editing an image, watching 1Seg, composing i-mode mail, activating the downloaded i-appli or the i-appli stand-by, or using MUSIC Player, i-motion player, Bluetooth function or data communication, the talk (transmission)/stand-by time will be reduced even if calls or i-mode transmission are not made. Some i-appli software may continue transmission even after downloading. To avoid this, set not to connect in advance.

The actual usage time is a combination of stand-by time and talk time,

and the longer the talk time, the shorter the stand-by time becomes.

1Seg watching time is estimated as the watching time at normal

transmission signal strength with the Flat-plug Stereo Earphone set P01 (sold separately) used.

Talk (transmission)/stand-by time may be reduced by about half or 1Seg

watching time may be shortened depending on battery pack status, function used, temperature and other environmental conditions, or signal strength (no signal or weak signal).

ɡ Battery pack service life

Battery pack is a consumable product. Service time per charge is

gradually reduced every time the battery is charged.

When service time per charge is reduced to about half of the default time,

this means that the battery pack is approaching the end of its service life. In such a case, it is recommended to replace the battery pack as soon as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life but this will not cause problems.

If i-appli, Videophone, or 1Seg is used while charging for a long time, the

service life of the battery pack may become shorter than estimated.

To protect the environment, return used batteries to NTT

DOCOMO, any DOCOMO retailer, or a recycling agency.

ɡ About charging batteries

Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately),

FOMA AC Adapter 01 for Global use (sold separately), or FOMA DC Adapter 01/02 (sold separately).

FOMA AC Adapter 01 covers only 100V AC. FOMA AC Adapter 02/

FOMA AC Adapter 01 for Global use covers from 100 to 240V AC.

The shape of the plug for the AC adapter is for 100V AC (for domestic

use). To use the AC adapter of 100 to 240V AC overseas, a conversion plug adapter that is compatible with the voltage of your country of stay is required. Do not use a transformer for use overseas to charge the battery.

Charging by using AC adapter/DC adapter

[Read “FOMA AC Adapter 01/02 (sold separately) and FOMA DC Adapter 01/02 (sold separately) user’s guide” carefully.]

Battery pack can be charged even in the open position.

Open the external connector terminal cover (1) and

insert the AC or DC adapter connector horizontally into the external connector terminal (2).

Charging LED

External connector terminal

Release buttons

When inserting the AC adapter power plug into an

outlet or inserting the DC adapter power plug into a car cigarette lighter socket, Charge start sound is heard, charging LED illuminates, and charging starts.

100V AC outlet

Cigarette lighter socket

Before Using the Handset

External connector terminal cover

Connector (Face the side with the arrows up)

: Check the direction (See diagram) of

the connector, keep it parallel with the FOMA terminal and firmly push all the way in until it clicks.

For AC adapter For DC adapter

When Charge end sound is heard and charging LED

turns off, charging is complete.

: When removing the connector, always hold the release buttons on

both sides (1) and unplug it by pulling out horizontally (2).

Continued on next page

Before Using the Handset

Do not forcibly insert or remove. May cause damage to the external

connector terminal and the connector.

Pull the adapter out of the outlet or cigarette lighter socket if it will not be

used for a long time.

Do not forcefully pull the external connector terminal cover. May

damage the cover.

Do not place objects near the FOMA terminal when charging. May

damage the FOMA terminal.

When using a DC adapter

The DC adapter should only be used in negative grounded vehicles (12

and 24V DC).

Do not use with the car engine shut off. May drain the car battery. The DC adapter fuse (2A) is a consumable. For replacement, purchase

a new fuse at a local automobile supply shop.

Refer to the FOMA DC Adapter 01/02 user’s guide for details.

Charging LED

Connector (Face the side with the arrows up)

Charging by using desktop holder

[Read “Desktop Holder SH24 (sold separately) user’s guide” carefully.]

Face the side with the arrows of the AC adapter

connector up and insert it into the connector terminal of the desktop holder (1).

: Keeping the connector parallel with the desktop holder, firmly push it

all the way in until it clicks.

Insert the AC adapter power plug into an outlet (2).

When placing the FOMA terminal in the desktop

holder, Charge start sound is heard, charging LED illuminates, and charging starts.

: Place the FOMA terminal in the direction of the arrow until it clicks as

the figure shows (3).

100V AC outlet

When Charge end sound is heard and charging LED

FOMA AC Adapter 01/02

turns off, charging is complete.

: Hold the desktop holder and lift the FOMA terminal out.

Charging with the desktop holder stood up

Charging becomes available with the desktop holder stood up by using the stand behind the desktop holder.

Do not force to make the stand behind stand up.

Pull the AC adapter out of the outlet when left unused for a long period

of time.

When Charge start sound is not heard or when charging LED does not

illuminate, check that the FOMA terminal is placed securely in the desktop holder (except when terminal is turned off, Manner mode is set or Charge start sound is Silent).

When placing the FOMA terminal in the desktop holder, be careful that

the strap is not caught in between the handset and the desktop holder.

Battery level

Checking battery level

" #

Battery level is still sufficient.

Battery level is low.

Checking battery level with sound and display

In the Custom menu, select [Settings]/[General

settings]/[Check status]/[Battery level].

Graphic

Sound Three beeps Two beeps One beep

Battery is

Status

: Wait approximately 2 seconds and the display disappears. : The battery level sound is heard at the volume set in Key/Touch

sound (nP. 96).

sufficiently full.

Battery is running low.

Battery is almost empty. Charge the battery.

Before Using the Handset

$ %

{

Battery is almost empty. Charge the battery.

Battery is empty (Power will turn off soon).

Battery pack is being charged.

If battery runs out

[Battery empty. Unsaved data will be lost. Ending current operation] appears if battery starts to run out (Select [Agree] to clear the message). After a while, an alert tone sounds. The warning screen stating that the battery runs out appears, handset operations are disabled and power turns off after approximately 60 seconds. During a voice/Videophone call, the alert tone sounds and [Battery

empty. Unsaved data will be lost. Ending current operation] appears. The call is disconnected after approximately 20 seconds. At the same time, the screen above appears and after approximately 60 seconds, the power turns off.

Alert tone does not sound when Manner mode or Public mode (Drive

mode) is set (Alert tone sounds during a call).

Power ON/OFF

Turning power OFF

Before Using the Handset

Turning power ON/OFF

Turning power ON

Press H (for 2+ seconds).

: It may take some time for the wakeup screen to appear. : The wakeup screen appears followed by the initial settings screen.

Proceed to Initial setting (nP. 50).

: If initial settings have been completed, the

screen shown on the right appears when power is turned on. This screen is called the “stand-by display”.

Welcome mail

: “Welcome$Ο΋ιͺΣι%&”

(Welcome$Decome-Anime%&) and “޽ݢ௸ ༭ȶ΀ςͺιȜσȷմඤ” (Information of

Early Warning “Area Mail”) are saved by default.

: To check a welcome mail: In stand-by, select

the stock icon C (mail message).

• For details on the following operations

nP. 143

If initial settings are not yet completed, the setting screen appears every

time the power is turned on.

If the FOMA card is not inserted, [Insert UIM] and a FOMA card error

appear (nP. 30).

When [Enter PIN1 code] appears, enter the PIN1 code (nP. 114). When a FOMA card is replaced with a new card, the terminal security

code (four to eight digits) must be entered after turning on the terminal. If a correct terminal security code is entered, stand-by display appears. When a wrong terminal security code is entered five times, the power is turned off. However, turning on the power again is possible.

When A appears, the handset is outside the service area or in a place

with no signal. Move to a place where the icon disappears.

Stand-by display

Press H (for 2+ seconds).

: It may take some time for the power to be turned off (The end screen

appears on the display until the power is turned off).

Select language

Changing screen display to English

In the Custom menu, select [୭೰]/[๊֚୭೰]/

[Bilingual]/[English].

: To switch the display language from English to Japanese: In the

Custom menu, select [Settings]/[General settings]/[Select language]/[඾ུࢊ].

If a FOMA card is inserted, settings are saved to the FOMA card as

well. When the setting of the FOMA terminal handset and the setting of the inserted FOMA card are different, the setting in the FOMA card is prioritized.

Initial setting

Making initial setting

The initial settings screen appears automatically when the power is turned on for the first time. Each setting item can also be set from Menu (When the initial settings are complete, the stand-by display appears).

 Date and time settings  Change terminal security code  Key/Touch sound  Location request menu  Font size settings

When items that have not been set remain, the setting screen appears

every time the power is turned on.

Set the date and time (nP. 51).

Set the Key/Touch sound (nP. 96).

Set GPS Location provision ON/OFF (nP. 304).

Set the font size (nP. 109).

: When the initial settings are complete, the software update function

confirmation screen appears. Read the description and select [Agree] (When the initial settings are made from the menu or the software update is set to other than [auto-update], the confirmation screen does not appear).

Press H to cancel the initial settings.

Date settings

Setting date and time

Set the date and time on the FOMA terminal.

In the Custom menu, select

[Settings]/[General settings]/[Date settings].

Select the [Auto time correction] field/select the

setting.

; Select [ON]/[Complete]. ; Select [OFF]/select the [Date] field/enter the date/[OK]/

select the [Time] field/enter the time (24-hour format)/[OK]/ [Complete].

• When entering month, day and time, add 0 before numbers one through nine (example: 01, 02, 03, etc.).

• Set the date and time from 00:00 January 1, 2001 to 23:59 December 31, 2050.

When Limit settings is set to [Enable], the terminal security code must

be entered in the Date settings.

The date and time that are set are saved even if the battery pack is

removed, but if the battery pack remains removed for approximately 30 seconds or more, the settings are reset. Also, if the battery remains empty, the settings may be reset. When this happens, set again after charging the battery.

If the date and time are not set correctly, the following functions cannot

be used properly.

 Redial, Received calls  Auto power ON/OFF  Alarm  Schedule  SSL (authentication)  i-appli Auto start  Starting i-appliDX  Reception, Recording  Machi-chara  Software update  Pattern definitions update  Record message (voice), Record message (Videophone calls)  Camera image titles/shooting date  Playback of i-motion or music data with expiration date/period for

replay

 View of e-books/e-dictionaries/e-comics with expiration date/period

for browse

When Auto time correction is set to [ON]

When the power is turned on, the FOMA terminal adjusts the time by

connecting to the network’s time information.

If the FOMA terminal does not adjust the time even when the power is

turned on, turn off the power and restart.

Time may not be adjusted depending on the signal status. Time may be off by a few seconds. When time difference is adjusted overseas, the local time and date and

! appear in Redial, Received calls, Received/Sent messages history (SMS only), and Received/Sent messages list. The received/sent messages are not displayed in order of the displayed time and date but the mail reception/send.

! does not appear in the Unsent messages for mail messages. If the

date order display is set for the Unsent messages, unsent messages are displayed in the order of the displayed time and date.

Time correction may not be performed depending on the overseas

network.

Before Using the Handset

Continued on next page

Before Using the Handset

During overseas use, Japan time and local time (or time set in City)

appear in the dual display except for the following cases.  When Auto time correction is set to [ON] and time correction

information is not being received from an overseas network

 When Auto time correction is set to [OFF] and City is set to the city in

the same time zone as Japan

ɡ Changing time zone manually <City>

In the Date settings screen, select the [Auto time

correction] field/[OFF]/[City].

Own number

Checking your own phone number

When checking your own phone number during a call nP. 55

In the Custom menu, select [Phone]/[Owner

Information].

: Alternatively, press 0 in the Horizontal display menu. : To switch between Number A and Number B (when 2in1 [Dual mode]

is used): Select [Number A]/[Number B].

Select a time zone/select a city/[Complete].

Notify caller ID

Notifying the other party of your phone number

Display your number (caller ID) on the other party’s phone (display) when making a voice/Videophone/PushTalk call.

Handset number (caller ID) is important personal information. Be very

careful about your caller ID setting.

The Notify caller ID function is available only on compatible phone

devices.

Setting Notify caller ID/No caller ID in advance

In the Custom menu, select [Settings]/[NW

Services]/[Notify caller ID].

Select [Activate/Deactivate].

: To check the setting: Select [Check setting].

Select the setting.

: To notify caller ID: Select [Yes]. : To not notify caller ID: Select [No].

When changing the Number B of 2in1, use any of the following methods

to obtain the correct Number B.  Set 2in1 function OFF and then perform 2in1 setting again to set

2in1 function ON

 Check the 2in1 subscription

When a FOMA card exchange (2in1 subscriber b 2in1 nonsubscriber)

is performed, set 2in1 function OFF.

When a FOMA card exchange (2in1 subscriber b 2in1 subscriber) is

performed, check the 2in1 subscription.

For details on Owner information nP. 382

Notify caller ID setting cannot be set from outside the service area.

Overseas Use

Outline of international roaming (WORLD WING) . . . . . . . . . . . . . . . . .430

Available services overseas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .431

Before use overseas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .431

Making a call at your country of stay. . . . . . . . . . . . . . . . . . . . . . . . . . . . 434

Receiving a call overseas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .435

Setting network communication system . . . . . . . . . . <3G/GSM setting>435

Setting a search method of telecommunications carrier

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Network search mode>436

Setting a telecommunications carrier to preferentially connect to

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <PLMN setting>436

Displaying a telecommunications carrier during roaming

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Operator name disp>437

Activating roaming guidance. . . . . . . . . . . . . . . . .<Roaming guidance>437

Setting incoming call to reject during roaming . . . . . . . . <Call barring>437

Using Missed Call Notice function during roaming

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Missed Call Notice>438

Using network services during roaming . . . . . . . . . . . . .<Int’l services>438

429

Overseas Use

Outline of international roaming (WORLD WING)

International roaming (WORLD WING) is a service that enables you, using overseas telecommunications carrier’s networks, to make calls and use i-mode. Use this FOMA terminal for voice/Videophone calls, i-mode and SMS with the phone number and mail address used in Japan. Network services such as Voice Mail and Call Forwarding Services can also be used.

This service is available in the 3G network and GSM/GPRS network

service areas. Refer to the DOCOMO “International Services website” for details on the area.

By default, the FOMA terminal is set to automatically switch networks

(nP. 436).

Refer to the following before using the FOMA terminal overseas.

 “Mobile Phone User’s Guide [International Services]”  “Mobile Phone User’s Guide [Network Services]”

 PDF file “٬ٸ၌ဥ΄ͼΡ” pre-installed in [My Documents] of Data

box

Country codes of major countries

The following shows “Country code” used when making international calls (nP. 61) or setting International dial assist (nP. 62). For other country codes and details, refer to the DOCOMO “International

Services website”.

Country/Region Code Country/Region Code

Australia 61 Maldives 960 Austria 43 Netherlands 31 Belgium 32 New Caledonia 687 Brazil 55 New Zealand 64 Canada 1 Norway 47 China 86 Peru 51 Czech 420 Philippines 63 Egypt 20 Russia 7 Fiji 679 Singapore 65 Finland 358 South Korea 82 France 33 Spain 34 Germany 49 Sweden 46 Greece 30 Switzerland 41 Hong Kong 852 Tahiti Hungary 36 India 91 Taiwan 886 Indonesia 62 Thailand 66 Italy 39 Turkey 90 Japan 81 U.K. 44 Macau 853 U.S.A. 1 Malaysia 60 Vietnam 84

(French Polynesia)

689

430

Available services overseas

The available communication services overseas are as follows.

Communication

service

Voice call

Videophone

i-mode mail Send or receive i-mode mail

i-mode i-Channel i-concier i-Widget SMS Send or receive SMS overseas

Packet transmission by connecting a PC, etc.

*1 When the 2in1 is used, calling from Number B is not available overseas. *2 When Multi Number is used, calling from Additional Number is not

*3 Overseas use settings for i-mode is required.

*1, 2

*3, 4

available overseas.

Make or receive calls in your country of stay or make international calls to Japan or to other countries with the same phone number as used in Japan while abroad.

*1, 2

Make international Videophone calls to users of the specified 3G telecommunications carriers overseas and FOMA users in Japan.

overseas with the same address as used in Japan.

Use i-mode overseas. ABA Use i-Channel overseas. ABA Use i-concier overseas. ABA Use i-Widget overseas. ABA

with the same phone number as used in Japan.

Use packet transmission overseas.

Explanation 3G GSM GPRS

AAA

ABB

ABA

AAA

ABA

*4 i-Channel setting is required. Packet transmission charges are incurred

for each i-Channel reception (including Basic channel).

*5 Overseas use settings for i-concier is required. Packet transmission

charges are incurred for each information reception.

*6 Setting for i-Widget roaming is required. Multiple Widget appli may

attempt transmission when i-Widget screen appears. In such case, packet transmission charges are incurred for each transmission.

*7 Unable to use 64K data communication by connecting a PC, etc.

Some services are not available depending on the telecommunications

carrier or network. Refer to the DOCOMO “International Services website” for information on available countries and regions, and telecommunications carriers.

Overseas packet transmission charges differ from those in Japan (Free

call in Japan does not apply).

඾םๅཱུ࿫ for SH (J-E Speech Translation for SH) is

available overseas (nP. 267).

GPS function is not available overseas. An error screen appears and

packet transmission charges are incurred when the site of GPS Service settings is accessed overseas.

Before use overseas

The following items must be checked before departure, at your country of stay, and after homecoming.

Preparation before departure

Prepare below in Japan before using the FOMA terminal overseas.

ɡ About contract

If subscribed to the FOMA service after September 1, 2005, a

subscription for “WORLD WING” is not required. However, if a subscription for “WORLD WING” is canceled at or after a subscription for the FOMA service, a subscription for “WORLD WING” is required again.

Overseas Use

Continued on next page

431

Overseas Use

If subscribed to the FOMA service before August 31, 2005 but not

subscribed to “WORLD WING”, a subscription for “WORLD WING” is required. Some payment plans are not available.

Insert the WORLD WING compatible FOMA card (other than blue) to the

FOMA terminal (nP. 41).

ɡ About charging batteries

Precautions for handling the AC adapter nP. 16 Methods for charging the AC adapter nP. 45

ɡ About browsing i-mode sites

To browse i-mode site overseas, the settings for overseas use must be made from iMenu in advance. i-mode site: Select [iMenu]/[English]/[Options]/[International Settings]/[i-mode services Settings]. Refer to “Mobile Phone User’s Guide [International Services]” and

“Mobile Phone User’s Guide [i-mode] FOMA version” for details.

ɡ About setting network service

If subscribed to network services, Voice Mail Service, Call Forwarding Service or other services can be used overseas. Some network services may not be set or checked depending on

overseas telecommunications carrier. In addition, some network services are available only in Japan. Refer to “Mobile Phone User’s Guide [International Services]” and “Mobile Phone User’s Guide [Network Services]” before departure.

To use network services overseas, set Remote Control (nP. 422,

P. 438) to “Activate”.

ɡ About inquiries overseas

For lost, stolen, and cost settlement, or malfunction of the FOMA terminal overseas, refer to “Loss or theft of FOMA terminal or payment of cumulative cost overseas” or “Failures encountered overseas” on the back of this manual. Note that any call or transmission charges incurred after the FOMA terminal is lost or stolen are charged to the subscriber. Add the “International call access code (Table 1)” or “International prefix

number for the universal number (Table 2)” that is assigned to your country of stay, to the head of your phone number for inquiries.

For the latest information of the international call access code and the

international prefix number for the universal number, refer to the DOCOMO “International Services website”.

International call access codes of major countries (Table 1)

The following shows the International call access codes of major countries. Communication charges to Japan will apply.

Country/Region Code Country/Region Code

Australia 0011 Monaco 00 Belgium 00 Netherlands 00 Brazil 0021/

0014

Canada 011 Philippines 00 China 00 Poland 00 Czech 00 Portugal 00 Denmark 00 Russia 810 Finland 00 Singapore 001 France 00 South Korea 001 Germany 00 Spain 00 Greece 00 Sweden 00 Hong Kong 001 Switzerland 00 Hungary 00 Taiwan 002 India 00 Thailand 001 Indonesia 001 Turkey 00 Ireland 00 U.A.E. 00 Italy 00 U.K. 00 Luxemburg 00 U.S.A. 011 Macau 00 Vietnam 00 Malaysia 00

New Zealand 00 Norway 00

432

International prefix number for the universal number (Table 2)

The following shows the International prefix number for the universal number of each country. Communication charges or other charges to your country of stay will

apply.

Communication charges to your country of stay will apply when calling

from the mobile phone.

Country/Region Code Country/Region Code

Argentina 00 Luxemburg 00 Australia 0011 Malaysia 00 Austria 00 Netherlands 00 Belgium 00 New Zealand 00 Brazil 0021 Norway 00 Bulgaria 00 Peru 00 Canada 011 Philippines 00 China 00 Portugal 00 Columbia 009 Singapore 001 Denmark 00 South Africa 09 Finland 990 South Korea 001 France 00 Spain 00 Germany 00 Sweden 00 Hong Kong 001 Switzerland 00 Hungary 00 Taiwan 00 Ireland 00 Thailand 001 Israel 014 U.K. 00 Italy 00 U.S.A. 011

Some codes may not be used. Note that the universal number may not be used for calls from a mobile

phone, payphone or hotel.

The universal number can be used only for countries listed above. Calling from a hotel may cost you extra call charges requested by the

hotel (You are responsible for the call charges). Confirm with the hotel before making calls.

Using at your country of stay

The service is available in the 3G network and GSM/GPRS network service areas. The FOMA terminal is set to automatically search for the network when the power is turned on, and to be connected to the available telecommunications carrier in your country of stay. When Auto time correction (nP. 51) is set to [ON], if information with

time and time differences is received from overseas telecommunications carrier which is being connected, time and time differences on the FOMA terminal clock are corrected. The correction timing differs depending on the telecommunications carrier.

Auto time correction may not be available overseas. In such case,

correct the time manually (nP. 51).

If the connected telecommunications carrier is changed when Auto time

correction is set to [ON], a screen notifying that time difference is adjusted may appear.

When Operator name display (nP. 437) is set to [Display on], the

telecommunications carrier connected appears in stand-by.

When Clock display (nP. 100) is set to [ON(Large)], the local time and

Japan time appear (excluding regions keeping the same standard time as Japan time).

Talk time or stand-by time may be reduced to half the normal time

depending on the network condition of your country of stay.

Setting after homecoming

By default, the FOMA terminal is set to automatically search for the network and to be connected to the FOMA network when the power is turned on after homecoming. If the Network search mode is set to [Manual], switch to the FOMA

network (DOCOMO) manually or change to [Auto].

Set the 3G/GSM setting to [AUTO] or [3G].

Overseas Use

433

Making a call at your country of stay

Make a call from overseas using the international roaming service.

Making a call outside your country of stay

ɡ Making a call to the phone in country saved in Set country

code

Save a country code using Set country code (nP. 63) to select a country code before making an international call. The following operation is available overseas only.

In stand-by, press s/enter a phone number/

[Submenu]/[Add prefix setting]/[International Call].

Overseas Use

(including Japan)

Make a call from your country of stay to Japan or other countries.

In stand-by, press s/keep touching [0(+)]/enter

country code, area code (city code) and other party’s phone number.

: When the area code (city code) begins with 0, omit the 0 when

dialing (However, include 0 when making a call to landline phones in some countries or regions such as Italy).

Select [B] or press s (Phone)/select [V.phone].

ɡ Making an international call outside your country of stay

using Country code conversion

Set Country code conversion (nP. 62) to [ON] and set the country code frequently called to easily make an international call. 0 at the beginning of a phone number is automatically converted to the

country code set in Country code conversion.

Example: Make a call from phonebook

In the Stand-by Display Touch Launcher, select

[6]/select the other party. Select [Phone] or press s (Phone)/select [V.phone].

Select [Call].

: To dial a phone number as stored in the phonebook: Select [Original

number].

Select the country code.

Press s (Phone)/select [V.phone].

Making a call in your country of stay

Make a domestic call at your country of stay in the same way as you do in Japan.

In stand-by, press s/enter a phone number.

Press s (Phone)/select [V.phone].

: Always dial the area code (city code), even when the number is in the

same area.

: When making a domestic call at your country of stay using the

phonebook, select [Original number] in step 3 of “Making an international call outside your country of stay using Country code conversion” on P. 434.

Refer to the DOCOMO “International Services website” for details on

available countries, country codes and telecommunications carriers.

Even when Notify caller ID of the network service (nP. 52) is set to

“Send ID”, [Unavailable] or [User unset] appears depending on the telecommunications carrier, and the caller ID may not be displayed correctly.

434

Making a call to a WORLD WING subscriber

Having calls to your FOMA terminal

overseas

When making a call to a “WORLD WING” subscriber overseas, make an international call to Japan regardless of your country of stay.

In stand-by, press s/keep touching [0(+)]/enter

country code 81 (Japan) and the other party’s mobile phone number excluding 0.

Select [B] or press s (Phone)/select [V.phone].

Receiving a call overseas

Receive a call overseas in the same way as you do in Japan.

Press s to receive an incoming call.

: Speak to the caller.

Even when a caller tried to notify of caller ID, it might not be notified

depending on the used telecommunications carrier.

When a call is received during international roaming, the call is

forwarded from Japan. Call charges to Japan are incurred by the caller and receiving charges by the receiver.

ɡ Having calls made to your FOMA terminal from Japan

To receive an international call from Japan, have your phone number dialed just as a domestic call in Japan. 090 (or 080)-XXXX-XXXX Calling from Received calls may not be available since the phone

number may not be displayed correctly.

ɡ Having calls made to your FOMA terminal from countries

other than Japan

Have the international call access code and 81 (Japan) added to the beginning of your phone number, and 0 excluded as an international call to Japan regardless of your country of stay.

International call access code of the country of the caller-81-90 (or

80)-XXXX-XXXX

3G/GSM setting

Setting network communication system

Set the communication system supporting your area and telecommunications carrier.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/

Overseas Use

[3G/GSM setting].

Select the communication method.

435

Network search mode

PLMN setting

Overseas Use

Setting a search method of telecommunications carrier

Set to manually select a telecommunications carrier. Re-search a network to set another telecommunications carrier. Check that the Network search mode is set to [Auto] when A appears

even after homecoming.

If telecommunications carrier is selected with [Manual] set abroad,

manually set to the FOMA network (DOCOMO) again or change to [Auto] after homecoming.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/ [Network search mode].

Select the setting.

; Select [Auto]/[Yes].

• When [Auto] is set: Select [Auto].

; Select [Manual]/select a telecommunications carrier.

• The telecommunications carrier is changed.

; Select [Network re-search].

• The host network is changed automatically if the Network search mode is set to [Auto]. If set to [Manual], select a telecommunications carrier.

Checking communication services available

<In-area status>

Check the status whether making a call, data transmission or packet transmission is available.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[In-area status]/[Agree].

Setting a telecommunications carrier to preferentially connect to

Specify the priority order of telecommunications carriers connected to when the Network search mode is set to [Auto]. Save up to 20.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/ [Network search mode]/[PLMN setting].

: To check the saved telecommunications carrier’s detailed

information: Select the telecommunications carrier.

Point the cursor to the priority order/[Submenu].

Select the saving method.

; Select [PLMN manual select]/enter a country code (MCC)/

[OK]/enter a network code (MNC)/[OK]/select a communication method.

; Select [UPLMN by list]/select a telecommunications carrier/

select a communication method.

• To search a telecommunications carrier from country name: Select

[UPLMN by list]/[Search]/select a country name/select a telecommunications carrier/select a communication method.

; Select [Set VPLMN to PLMN].

• Save the telecommunications carrier currently connected to.

; Select [Change priority]/select a destination. ; Select [Delete]/[Delete one]. ; Select [Delete]/[Delete all]/enter the terminal security code/

[OK].

Select [Yes].

436

Operator name disp

Call barring

Displaying a telecommunications carrier during roaming

Set whether to display a telecommunications carrier name currently connected to in stand-by during international roaming.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/ [Operator name disp].

Select the setting/[Yes].

ɡ When displaying a telecommunications carrier

Telecommunications carrier name

Roaming guidance

Activating roaming guidance

When a call is received during international roaming, the caller hears the guidance stating that international roaming is activated.

Make this setting while still in Japan.

Setting incoming call to reject during roaming

Set the FOMA terminal to reject calls during roaming. Select whether to bar all incoming calls or only the Videophone and 64K data communication calls.

Depending on the overseas telecommunications carrier, the setting

cannot be made.

Unable to use 64K data communication overseas.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/ [Call barring].

Select an item.

; Select [Activate]/[Yes]/select the barring method/enter the

network security code/[OK].

; Select [Deactivate]/[Yes]/enter the network security code/

[OK].

; Select [Check setting].

Overseas Use

In the Custom menu, select [Settings]/[Other NW

Services]/[Roaming guidance].

Select an item.

Select [Yes].

437

Missed Call Notice

Int’l services

Overseas Use

Using Missed Call Notice function during roaming

When the FOMA terminal is outside the service area, turned off, or a received call cannot be answered during International roaming, the information of the call (Received date and time or caller ID) is notified with SMS.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/ [Missed Call Notice].

Select an item.

; Select [Activate]/[Yes]. ; Select [Deactivate]/[Yes]. ; Select [Check setting].

Using network services during roaming

Use network services such as Voice Mail and Call Forwarding from overseas.

Set at a country to stay. Voice Mail and Call Forwarding subscription are required to use Voice

Mail (Int.) and Call Forward (Int.).

To use network services overseas, set Remote Control (nP. 422) to

“Activate” in advance.

If operated from overseas, international call charges for your country of

stay are incurred.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.].

Select an item.

; Select [Voice Mail(Int.)]/select an item of Voice Mail Service. ; Select [Call Forward (Int.)]/select an item of Call Forwarding

Service.

; Select [Remote access (Int.)]. ; Select [Caller ID req (Int.)]. ; Select [Roam. guidance(Int.)]. ; Select [MissedCallNoticeInt.].

Select [Yes]/operate according to the voice

guidance.

438

Appendix/Troubleshooting

Introduction of options and related devices

Combine the FOMA terminal with various optional accessories (sold separately) for expanded personal and business use. Some products may not be available in certain areas. Contact a docomo Shop or retailer for details. Refer to the user’s guide of each product for more details.

Wireless Earphone Set 02 FOMA AC Adapter 01 for Global

use

FOMA DC Adapter 01/02

FOMA Indoor Booster Antenna

In-Car Hands-Free Kit 01 FOMA In-Car Hands-free Cable

/02

In-Car Holder 01

FOMA Dry Battery Adapter 01 Carry Case L 01 Bone conduction microphone/

receiver 01

FOMA USB Cable with Charge

Function 02

FOMA Portable Charging

Adapter 01

FOMA Indoor Booster Antenna

(Stand Type)

FOMA AC Adapter 01*1/02 Battery Pack SH18 Back Cover SH29 Desktop Holder SH24 Earphone Terminal P001 Flat-plug Stereo Earphone Set

P01

Flat-plug Earphone/Microphone

/P002

/P02

with Switch P01

Stereo Earphone Set P001 Earphone/Microphone with

Switch P001

Earphone/Microphone 01 Stereo Earphone Set 01 Earphone Plug Adapter P001 Earphone Plug Adapter for

External connector terminal 01

Earphone Plug Adapter 01 FOMA USB Cable

*1 Refer to P. 43 for details on charging with an AC adapter. *2 Connect Earphone Plug Adapter for External connector terminal

01 and Earphone Plug Adapter to use these options and accessories.

*3 Connect Earphone Plug Adapter for External connector terminal

01 to use these options and accessories. *4 The use of USB HUB may not work correctly. *5 For use only in Japan. *6 FOMA In-Car Hands-Free Cable 01 is required to charge and

connect with the USB cable. *7 Activate Touch panel/Side key lock to use the In-Car Holder 01.

Interfacing to external devices

Play back movies saved on microSD Cards on the FOMA terminal by using supported external devices. microSD Cards are sold separately. Purchase microSD Cards at home electronics shops (nP. 345). For details on compatible devices, refer to http:// k-tai.sharp.co.jp/support/d/sh-04a/. Or, contact the number below.

Play i-motion created on external devices (including music data in

AAC format) on the FOMA terminal (nP. 260).

* Some movies cannot be played back depending on the file format

or the type of external device.

Sharp Data Communication Support Center TEL: 03-5396-2351 Hours: 10:00 A.M. to 12:00 noon, 1:00 P.M. to 5:00 P.M., Monday through Friday (Closed on weekends, national holidays, and company holidays)

Check the phone number carefully before dialing.

482

Specific Absorption Rate (SAR) of

Hereby, Sharp Telecommunications of Europe Ltd, declares that this SH-04A is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the original declaration of conformity can be found at the following Internet address: http://www.sharp.co.jp/k-tai/

Declaration of Conformity

mobile phone

This model phone SH-04A meets the MIC’s* technical regulation for exposure to radio waves.

The technical regulation established permitted levels of radio frequency energy, based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The regulation employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg) grams of tissue. The limit includes a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The value of the limit is equal to the international guidelines recommended by ICNIRP All phone models should be confirmed to comply with the regulation, before they are available for sale to the public. The highest SAR value for this model phone is 0.928 W/kg. It was taken by the Telecom Engineering Center (TELEC), a Registered Certification Agency on the Radio Law. The test for SAR was conducted in accordance with the MIC testing procedure using standard operating positions with the phone transmitting at its highest permitted power level in all tested frequency bands. While there may be differences between the SAR levels of various phones and at various positions, they all meet the MIC’s technical regulation. Although the SAR is determined at the highest certified power level, the actual SAR of the phone during operation can be well below the maximum value. For further information about SAR, please see the following websites:

World Health Organization (WHO) http://www.who.int/peh-emf/

ICNIRP http://www.icnirp.de/

MIC http://www.tele.soumu.go.jp/e/ele/body/index.htm

TELEC http://www.telec.or.jp/ENG/Index_e.htm

NTT DOCOMO http://www.nttdocomo.co.jp/english/product/

averaged over ten

***

SHARP Corporation http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.html

* Ministry of Internal Affairs and Communications

** The technical regulation is provided in Article 14-2 of the Ministry

Ordinance Regulating Radio Equipment.

*** International Commission on Non-Ionizing Radiation Protection

European RF Exposure Information

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health. The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was 0.683 W/kg As SAR is measured utilizing the devices highest transmitting power the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the network.The World Health Organization has stated that present scientific information does not indicate the need for any special precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so by limiting the length of calls or using a hands-free device to keep the mobile phone away from the head.

* The tests are carried out in accordance with international guidelines for

testing.

Appendix/Troubleshooting

515

FCC Notice

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the manufacturer

responsible for compliance could void the user’s authority to operate the equipment.

Information to User

This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the

Appendix/Troubleshooting

equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient/relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

FCC RF Exposure Information

Your handset is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The guidelines are based on standards that were developed by independent scientific organisations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless handsets employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model handset when tested for use at the ear is 0.685 W/kg and when worn on the body, as described in this user guide, is 0.582 W/kg. Body-worn Operation; This device was tested for typical body-worn operations with the back of the handset kept 1.5 cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 1.5 cm separation distance between the user’s body and the back of the handset. The use of beltclips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. The FCC has granted an Equipment Authorization for this model handset with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model handset is on file with the FCC and can be found under the Display Grant section of http:// www.fcc.gov/oet/fccid after searching on FCC ID APYHRO00088. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) Website at http://www.phonefacts.net.

Export Administration Regulations

The Japan Export Administration Regulations (“Foreign Exchange and International Trade Law” and its related laws) will be applied to this product and its accessories under certain conditions. The Export Administration Regulations are also applied. To export or reexport this terminal and its accessories, conduct all legally required procedures at your own risk and expense. For details on the procedures, contact the Ministry of Economy, Trade and Industry or the US Department of Commerce.

516

Intellectual property rights

Copyrights and rights of portrait

Data with third party copyrights such as text, images, music and software

that is downloaded or acquired via Internet web pages, shot by the FOMA terminal, or acquired from TV or other video cannot be duplicated, altered or publicly transmitted without rightful party’s consent. Only duplicating, quoting, etc. for personal use is permitted under copyright laws. Even if for personal use, filming and recording may be prohibited for demonstrations, performances and exhibitions. Also, shooting another’s image or posting another’s image on Internet web pages without their consent may constitute a violation of one’s right to their image.

Registered trademarks and trademarks

“FOMA”, “mova”, “ToruCa”, “PushTalk”, “PushTalkPlus”, “mopera”,

“mopera U”, “FirstPass”, “Chara-den”, “Deco-mail”, “Chaku-motion”, “i-motion mail”, “i-appli”, “i-appliDX”, “i-motion”, “i-mode”, “i-Channel”, “iD”, “DCMX”, “WORLD WING”, “Public mode”, “DoPa”, “WORLD CALL”, “Dual Network”, “visualnet”, “V-live”, “Security Scan”, “musea”, “sigmarion”, “OFFICEED”, “IMCS”, “i-area”, “2in1”, “Chokkan Game”, the “i-mode” logo, the “FOMA” logo, the “i-appli” logo, the “DCMX” logo, the “iD” logo, the “HIGH-SPEED” logo are trademarks or registered trademarks of NTT DOCOMO, INC.

Free Dial logo mark is a registered trademark of NTT Communications

Corporation.

This product includes software licensed from Symbian

Catch Phone (Call Waiting) is a registered trademark of Nippon

Telegraph and Telephone Corporation.

Multitask is a registered trademark of NEC Corporation. This product is equipped with NetFront Browser, NetFront Sync Client

and NetFront Browser DTV Profile Wireless Edition by ACCESS Co., Ltd. for an internet browser or other application software.

This product adopts Media: specifications of ACCESS CO., Ltd. for

ACCESS, NetFront and Media: are trademarks or registered trademarks

of ACCESS Co., Ltd. in the United States, Japan and other countries.

Microsoft

Media Corporation in the U.S.A. and other countries.

Microsoft Excel and Microsoft Word are product names of Microsoft

Corporation in the U.S.A.

Java and all Java-based trademarks and logos are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S.A. and other countries.

QuickTime is a registered trademark of Apple Inc., in the US and other

countries.

QR code is a registered trademark of Denso Wave Inc. microSDHC Logo is a trademark.

, Windows®, Windows Vista®, PowerPoint® and Windows

are trademarks or registered trademarks of Microsoft

Appendix/Troubleshooting

Continued on next page

509

Appendix/Troubleshooting

Document Viewer and the Picsel cube logo are trademarks or registered trademarks of Picsel Technologies and/or its affiliates.

“AXISFont” is a trademark of AXIS Inc. in Japan. This handset features LCFONT, developed by Sharp Corporation, to

make the LCD easier to view and read. LCέ΁ϋΠ/LCFONT and

are registered trademarks of Sharp Corporation.

Heisei font is an intellectual property of Font Development and Promotion

Center of Japanese Standards Association, and “SH Heisei Mincho” is a font developed by DynaComware Corp. with a license.

DynaFont is a registered trademark of DynaComware Taiwan Inc.

McAfee

its affiliates in the U.S.A. and other countries.

G΄ͼΡ, G-GUIDE, G΄ͼΡκΨͼσ, G-GUIDE

MOBILE and the G-GUIDE related logos are registered trademarks of Gemstar-TV Guide International, Inc. and/ or its affiliates in Japan.

Google and Google Map for Mobile are trademarks of Google Inc. IrSimple™, IrSS™ or IrSimpleShot™ are trademarks of Infrared Data

Association

ˢ˟˽, which uses non-contact IC card technology, was created

by Sony Corporation.

ˢ˟˽ is a registered trademark of Sony Corporation. b is a registered trademark of FeliCa Networks, Inc.

Napster is a registered trademark of Napster, LLC. and/or its affiliates in

the US and/or other countries.

Dolby and the double-D symbol are registered trademarks of Dolby

Laboratories.

FlashFX

Inc. in the US. (U.S.Patent Office 5,860,082/6,260,156)

is registered trademarks or trademarks of McAfee, Inc. and/or

Pro™ is a trademark or registered trademark of the Datalight,

Document Viewer is powered by Picsel

Technologies. Picsel, Picsel Powered, Picsel Viewer, Picsel

PhotoSolid

ImageSurf™ are the trademarks or the registered trademarks of Morpho, Inc.

“AQUOSΉȜΗͼ”, “Desktop clock”, “VeilView”, “Egao focus shutter”,

“Furimuki shutter”, “Shotdeco”, “Wakeup TV”, “Stand-by Display Touch Launcher”, “Long Touch Menu”, “Quick Settings”, and “Quick Stand-by Display Setting” are trademarks or registered trademarks of Sharp Corporation.

All other company names and product names are trademarks or

registered trademarks of the respective companies.

, FaceSolid™, FrameSolid®, ImageScouter™, and

Others

Under the MPEG-4 Visual Patent Portfolio License, customers have

licensed permission for the following use of this product to engage in non-profit personal use. Other uses are not permitted.  Encoding MPEG-4 standard video (henceforth referred to as MPEG-4

video).

 Decoding an MPEG-4 video that a customer not engaged in personal

commercial activities has encoded.  Decoding an MPEG-4 video obtained from a licensed provider. For details on other intended uses, contact MPEG LA, LLC.

This product is licensed under the MPEG-4 Systems Patent Portfolio

License for encoding in compliance with the MPEG-4 Systems Standard. An additional license and payment of royalties are necessary in the following cases.  Data stored or replicated in physical media which is paid for on a title

by title basis.  Data which is paid for on a title by title basis and is transmitted to an

end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. Contact MPEG LA, LLC for additional details.

510

This product is licensed under the AVC patent portfolio license for the

personal and noncommercial use of a consumer to (i) encode video in compliance with the AVC standard (henceforth referred to as AVC video) and/or (ii) decode AVC video that was encoded by a consumer engaged in a personal and noncommercial activity and/or was obtained from a video provider licensed to provide AVC video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, L.L.C. See HTTP://WWW.MPEGLA.COM

This product is licensed under the VC-1 Patent Portfolio License for the

personal and noncommercial use of a consumer to (i) encode video in compliance with the VC-1 standard (henceforth referred to as VC-1 video) and/or (ii) decode VC-1 video that was encoded by a consumer engaged in a personal and noncommercial activity and/or was obtained from a video provider licensed to provide VC-1 video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, L.L.C. See HTTP://WWW.MPEGLA.COM

Contains Adobe

Flash® Lite™ and Adobe Reader

LE technology by Adobe Systems Incorporated Adobe Flash Lite Copyright © 2003-2008 Adobe System Incorporated. All rights reserved. Adobe Reader LE Copyright © 1993-2007 Adobe Systems Incorporated. All rights reserved. Adobe, Adobe Reader, Flash, and Flash Lite are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

This product includes modules developed by the Independent JPEG

Group.

This product uses the GestureTek technology.

This product is equipped with “Fugue” by Kyoto Software Research, Inc.

for a file system function.

Manufactured under license from Dolby Laboratories. Bluetooth software stack of this product is developed by TOSHIBA

CORPORATION, and contains Toshiba Embedded Bluetooth Stack for Symbian with the copyright of TOSHIBA CORPORATION.

Content owners use Windows Media digital rights management

(WMDRM) technology to protect their intellectual property, including copyrights. This device uses WMDRM software to access WMDRM-protected contents. If the WMDRM software fails to protect the content, content owners may ask Microsoft to revoke the software’s ability to use WMDRM to play or copy protected content. Revocation does not affect unprotected content. When you download licenses for protected content, you agree that Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

CP8 PATENT This manual refers to each OS (Japanese version) as follows.

 Windows Vista is an abbreviation of Windows Vista

(Home Basic,

Home Premium, Business, Enterprise, Ultimate).

 Windows XP is an abbreviation of Microsoft

Professional operating system or Microsoft

Windows® XP

Windows® XP Home

Edition operating system.

 Windows 2000 is an abbreviation of Microsoft

Windows® 2000

Professional operating system.

The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc.

and any use of such marks by NTT DOCOMO, INC. is under license. Other trademarks and trade names are those of their respective owners.

Appendix/Troubleshooting

Continued on next page

511

Appendix/Troubleshooting

Internet dictionary embedded in this product uses the BSD license.

• Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

• Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

• Neither the name of the <ORGANIZATION> nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

512

Quick Manual

How to use Quick Manual

Remove the Quick Manual attached to the end of this manual by cutting along the perforations and fold it as shown below. Carry the Quick Manual “Overseas Use” when the mobile phone is used with the International Roaming (WORLD WING) overseas.

ɡ Folding Quick Manual

Be careful of injuries when cutting out the Quick Manual.

Cut along the perforations.

(Completed)

Index/Quick Manual

This manual is produced using recyclable material. Please recycle when no longer needed.

526

SH-04

Quick Manual

Registration/Contacts

General Inquiries <docomo Information Center>

0120-005-250 (toll free)

ɦ Service available in: English, Portuguese, Chinese, Spanish, Korean. ɦ Available from mobile phones and PHSs.

For DOCOMO mobile phones (In Japanese only)

(No prefix) 151 (toll free)

ɦ Unavailable from fixed-line telephones, etc.

For fixed-line telephones (In Japanese only)

0120-800-000 (toll free)

ɦ Available from mobile phones and PHSs.

Ple ase confirm the phone number before you dial.

If you have problems with your FOMA

For DOCOMO mobile phones (In Japanese only)

(No prefix) 113 (toll free)

ɦ Unavailable from fixed-line telephones, etc.

For fixed-line telephones (In Japanese only)

0120-800-000 (toll free)

ɦ Available from mobile phones and PHSs.

Please confirm the phone number before you dial.

Adding entries to phonebook (Phone)

1 In the Stand-by Display Touch Launcher, select

[6]/[Submenu]/[New]/[Phone].

2 Enter a name/[OK]/9/enter a phone

number/[OK]/select a phone type icon/S/ enter a mail address/[OK]/select a mail address type icon/[Complete]/[OK]/select Add to PushTalk PB.

ɡ Other save items

Q : Group F : Secret code a : Company/school < : Select ring tone q : Department V : Mail ring tone r : Title q : Called LED color N : Postal code - : Called LED pattern O : Postal address : : Mail/Message LED color j : Location info + : Mail LED pattern P : Birthday 8: Picture call set G : Memo 1 : Substitute image ; : Secret

Adding entries to phonebook from

Redials/Received calls

1 In the Stand-by Display Touch Launcher, select

[2]/[1]/point the cursor to a phone number/ [Submenu]/[Add to phonebook]/[Save new to phone]/add to the phonebook.

Editing phonebook entries

In the Stand-by Display Touch Launcher, select [6]/point the cursor to a name/[Submenu]/ [Edit data]/[Edit]/select an item/edit.

Text input

Changing input mode

1 In the text input screen, select [Chara]/select

the input mode.

Switching upper/lower case

1 Enter a character/[YZA/a].

Deleting text

1 Point the cursor to the text and press z.

Using phrases

1 In the text input screen, select [Submenu]/

[Phrase(Hold F4)]/select a phrase/[OK].

–1– –2–

Entering pictographs/symbols

1 In the text input screen, select [Pict/Sym].

: To enter symbols: Select [Symbol]. : To enter pictographs: Select [Pict]. : To switch between pictograph and Deco-mail

pictograph: Select [Pict]/[Pict-D].

: To switch between single- and double-byte symbols:

Select [Fulpitch]/[Hlfpitch].

Entering emoticons

1 In the text input screen, select [Submenu]/

[Emoticon(Hold F3)]/select an emoticon.

Cutting/Copying/Pasting text

Ex.) When entering a message

1 In the text input screen, select [Submenu]/

[Copy]/[Cut]/move the cursor to the start position/[Start].

2 Move the cursor to the end position/[Copy]/

[Cut].

3 Select [Submenu]/[Paste]. 4 Move the cursor to the paste position/[Paste].

Text input example

Ex.) ࣽ඾ΞΣΑ3শt

1 In the text input screen,

select [] (twice)/ [Conv]/[ࣽ඾].

: As each hiragana character is

entered, conversion candidates appear and they can be selected.

2 Select [Conv]/[]. 3 Select [][][]/[1-tch]/[ΞΣΑ].

: Select [1-tch] for One-touch conversion.

4 Select [Chara]/[1]/[3].

–4––3– –5–

: Select [Chara] (five times) for single-byte

alphanumeric mode.

5 Select [Chara]/[]/[] (twice)/[YZA/a]/

[Conv]/[শ].

: Select [YZA/a] for dakuten mark.

6 Select [Pict/Sym]/t.

Changing font (font style)

1 In the Custom menu, select [Settings]/[Disp/

LED/Power saver]/[Font style]/[Font style setting]/select the font.

–6– –8–

Changing font size

1 In the Custom menu, select [Settings]/[Disp/

LED/Power saver]/[Font style]/[Font size]/ [Individual setting]/select the [Input] field/ select the font size/[Yes].

: To change collectively: In stand-by, press 5 (for 1+

seconds).

Camera

Shooting still pictures

1 In the Stand-by Display Touch Launcher, select

[#]/& (q)/& (q).

ɡ Shooting panoramic pictures

1 In the still picture shooting screen, select

[Submenu]/[Select size]/ [Panorama(2560×640)]/& (q)/move the FOMA terminal to either direction of left or right/& (q)/& (q).

–7–

Shooting movies

1 In the still picture shooting screen, select

[Submenu]/[Switch camera-mode]/[Movie]/ & (q)/& (q)/[Save].

Displaying still pictures

1 In the Custom menu, select [Data box]/[My

picture]/select a still picture.

Playing back movies

1 In the Custom menu, select [Data box]/

[i-motion]/select a movie.

Watching 1Seg

Performing Automatic channel setting

1 In the Custom menu, select [1Seg]/[Channel

setting].

2 Point the cursor to the save destination/

[Submenu]/[Auto channel set]/[Yes].

3 Select an area/select a prefecture/district/

[OK]/[Yes]/[Yes].

Selecting a channel list

1 In the Custom menu, select [1Seg]/[Channel

setting]/select a channel list.

Watching 1Seg

1 In the Custom menu, select [1Seg]/[Activate

1Seg].

: To record a movie of 1Seg programs: While watching

1Seg, keep touching [

: To record 1Seg programs as a still picture: While

watching 1Seg, touch [

X].

Watching videos

1 In the Custom menu, select [Data box]/[1Seg]/

select a video.

Music playback

Using MUSIC Player

1 In the Custom menu, select [Data box]/

[MUSIC]/select music data.

Operations for MUSIC Player

To pause/play

To stop

To adjust the volume

To play previous song/return to the beginning of song

–10–

& (q) or [

[

[V]/[W]

[

To play next song

To end MUSIC Player H/[Yes]

[c]

Mail

Composing and sending i-mode mail

1 In the Stand-by Display

Touch Launcher, select [7]/[Compose message]/select the [To] field/select the input method.

; Select [Search

phonebook]/select a recipient.

; Select [Sent messages]/select a recipient. ; Select [Rcvd messages]/select a recipient.

Select [Mail members]/select a mail member.

; ; Select [Direct input]/enter an address/[OK].

–11––9–

2 Select the [Sub] field/enter a subject/[OK]/

[Msg]/enter the message text/[OK]/[Send].

Sending Deco-mail

1 In the text input screen, select [Submenu]/

[Decorate mail]/select a decoration type/ specify decoration/input text/[OK]/[Send].

Attaching a file

1 In the Stand-by Display Touch Launcher, select

[7]/[Compose message]/select the attachment field (No attachment)/select the file to attach.

;

Select [Image]/point the cursor to the image/[OK].

;

Select [Melody]/point the cursor to the melody [OK].

;

Select [i-motion]/point the cursor to i-motion [OK].

;

Select [ToruCa]/point the cursor to ToruCa/[OK].

;

Select [PDF]/point the cursor to the PDF/[OK].

–12–

;

Select [Phonebook]/select a save destination select a name.

;

Select [Schedule]/select a save destination ( select a day)*/

* No operation is needed if [microSD] is selected as the

save destination

;

Select [Bookmark]/select a save destination select a bookmark.

;

Select [Document]/point the cursor to the file [OK].

;

Select [Other]/select a file.

;

Select [Start cam (still)]/[A]/& (q)/[Save]/& (q).

;

Select [Start cam (movie)]/[Rec]/& (q)/[Stop]/

q)/

[Save].

(

select a schedule.

Composing and sending SMS

1 In the Stand-by Display Touch Launcher, select

[7]/[Compose SMS]/select the [To] field/ [Direct input]/enter an address/[OK]/[Msg]/ enter the message/[OK]/[Send].

–13– –14–

Receiving mail automatically

1 Mail is automatically received.

2 Select [Mail]/select the mail.

Checking new i-mode mail

1 In the Stand-by Display Touch Launcher, select

[7]/[Check new messages].

SMS: In the Stand-by Display Touch Launcher, select

7]/

[Check new SMS].

[

Replying to i-mode mail

1 In the received message details screen, select

[Submenu]/[Reply/Forward].

2 Select the reply method. 3 Compose and send a mail.

Forwarding i-mode mail

1 In the received message details screen, select

[Submenu]/[Reply/Forward]/[Forward].

2 Enter an address and send a mail.

Menu list

Retrieving functions from the Custom menu/

Basic menu

1 In the Stand-by Display Touch Launcher, select

[$].

2 In the Custom menu/Function menu, select the

function.

3 In the Menu list, select the function.

Switching between the Custom menu/Basic menu

1 In the Custom menu/Basic menu, select [Basic]/

[Custom].

Snd/Vibrator/Manner

Select volume Received call volume, phone ring vol,

Mail ring vol, PushTalk tone vol, Key/ Touch sound, Standby i-motion, Charge start sound, Charge end sound, Timer sound, GPS volume

Snd/Vibrator/Manner Disp/LED/Power saver

Select sound Select ring tone, Select mail tone,

PushTalk tone, Shutter sound, Timer sound, GPS tone

Vibrator Vibration mode, Mail vibration, GPS

vibrator, Touch vibrator Manner mode ON (Normal, Silent, Original), OFF Headset setting Ring time setting Mail ring time set, PT ring time set,

GPS ring time set Set mute ring time Hold/On hold tone Set on hold tone, Set hold tone Sound playback Melody stereo fx, Melody equalizer,

Pref playback sound

–16––15– –17–

Set screen Stand-by display, Clock display,

Calendar display, Stand-by memo disp, Stdby toch lnch disp, Desktop

clock, Stdby slide-link set Font style Font style setting, Font size Themes Kisekae Tool, Call/Rcv display, Send/

Rcv display, Animate notices, Signal/

batt/s clock, Machi-chara, Color theme

setting LED settings Called LED, Mail LED, Notice LED,

In-call LED, Alarm/Timer LED, IC card

LED, Slide-linked LED, GPS LED Display img

quality

Vibrant image mode, Control by scene

Disp/LED/Power saver General settings

Light/Power saver Norm (auto bright), Norm (fixed bright),

Eco mode (Pwr saver), Original Eco mode

VeilView Linked manner, Pattern, Pattern

density

Menu priority

Check status Owner Information, Check memory,

Battery level, Check settings

Text input setting User dictionary, Dwnld dictionary, Edit

phrase, Clear memory terms

Auto power ON/

OFF Date settings Select language USB mode setting Scanning function Update, Set auto-update, Set scan,

Software update Reset settings

Auto power ON, Auto power OFF, Link alarm/power ON

Version

NW Services

Voice Mail Check messages, Play Messages,

Activate VoiceMail, Set ring time, Deactivate VoiceMail, Check setting, Voice Mail setting, Notification setting,

Notification, V.phone Voice Mail Call waiting Activate, Deactivate, Check setting Forwarding Activate, Deactivate, Register number,

If FWD number busy, Check setting Nuis. call blocking Register caller, Register selected No,

Delete all entries, Delete last entry,

Check No of entries

–18– –20–

NW Services Other NW Services

Notify caller ID Check setting, Activate/Deactivate Caller ID request Activate, Deactivate, Check setting Talk time/cost 2in1 setting Mode switching, Phonebook 2in1 set,

Stand-by display, Set call/receive No., 2in1 function OFF, Receive avoidance

In-call arrival act Set arrival act, Arrival Call Act

–19–

Remote Control Activate, Deactivate, Check setting Dual network Switching, Check setting English guidance Guidance setting, Check setting Service Numbers

Additional service USSD, Reply message Multi number Set multi number, Check setting,

Chaku-moji Create message, Message display Roaming

guidance

Ρ΋κ࡬વ࿚ࣣ, Ρ΋κ௙ࣣմඤȆ ັ

Number setting

Activate, Deactivate, Check setting

Phone settings

In-call settings Noise reduction, Reconnect signal,

Quality alarm Headset sw to call Incoming settings Auto answer setting, Melody Call

setting Videophone set Redial voice call, Set sending image,

Display setting, Subscreen position,

Visual preference, Notify switch mode,

Hands-free V.phone, V-phone while

packet Record message Record message, Answering duration,

Reply message, V.phone reply image Set PushTalk Set PT arrival act, Hands-free PT Setting when slid Self mode Other settings Int’l prefix, Sub address, Int’l dial

assist, International Roam., In-area

status

–22–

–23––21–

Security

Secret mode UIM Settings PIN1 code input set, Change PIN1

code, Change PIN2 code

Accept/Reject calls

Show call/ received

Show sent/ received

Lock settings All lock, Keypad dial lock,

Change security code Writing authentic Delete all data Delete user data, Del secret data

Accept calls, Reject calls, Reject unknown, User unset, Reject payphone, Reject not support

Show rcvd calls, Show redial

Show sent messages, Show rcvd messages

Function lock, Multi lock set, IC card lock, Multi lock auto-set

–24–

i-concier settings

Incoming settings Select volume, Select sound, Vibrator,

Ring time setting, LED setting

Information display

Other settings

Initial setting Own number

–25– –26–

Quick Settings

VeliView Bluetooth Location Public mode RcvCall vol Manner mode Rec msg Self mode Alarm Lock select Vibrator Eco mode

Stand-by Display Touch Launcher

9 Quick search 0 Full Browser (Google) ! Mapping appli ( i-concier $ Start menu 8 i-mode menu ) 1Seg % i-Widget (longways) = Program guide i-appli (sideways)

# Shoot still picture 7 Mail menu 6 Phonebook 5 Dial input screen 1 Received calls 2 Redial / Manner mode setting

Other functions

Activate Multi Assistant (Multitask)

s (for 1+ seconds)

Network services

ɦ When the confirmation screen appears, select [Yes].

Voice Mail Service

Voice Mail Service is a paid option (monthly fees apply) that requires subscription.

1 In the Custom menu, select [Settings]/[NW

Services]/[Voice Mail].

2 Select [Activate VoiceMail]/[Activate

VoiceMail].

: To deactivate: Select [Deactivate VoiceMail]. : To play messages: Select [Play Messages]/

[Play(voice call)]/[Play(videophone)].

: To check messages: Select [Check messages].

Call Waiting

Call Waiting is a paid option (monthly fees apply) that requires subscription.

1 In the Custom menu, select [Settings]/[NW

Services]/[Call waiting].

–28––27– –29–

2 Select [Activate].

: To deactivate: Select [Deactivate]. : To check settings: Select [Check setting].

Call Forwarding Service

Call Forwarding Service is a free option (no monthly fees) that requires subscription.

1 In the Custom menu, select [Settings]/[NW

Services]/[Call Forwarding].

2 Select [Activate]/[Activate].

: To deactivate: Select [Deactivate]. : To check settings: Select [Check setting].

Caller ID Request Service

Subscription is not required (no monthly fees).

1 In the Custom menu, select [Settings]/[NW

Services]/[Caller ID request].

2 Select [Activate].

: To deactivate: Select [Deactivate]. : To check settings: Select [Check setting].

Icon list

12345 7 b c

pmlkjihgnq or fe

tus

6 a89

1 ] Signal status 2 "

{

3 7=AABNO i-mode/Full Browser 4 o 5 GNIQ 6 AB GPS 7

J#Ntu

UhHv[

9 ABJ Message R/F received a WGIX

STKL

b ^ (gray)

^ (pink) microSD Card is being used

Battery level Charging

SSL i-appli

Ir communication/Bluetooth communication/External device

i-mode mail/SMS/Area Mail received

Storage status of i-mode center

microSD Card is inserted

c Clock display d a e ]

D to Pk

f [ Silent g b h Z i _ Public mode (Drive mode) j a k H l RSTUVW

m ;

M Bluetooth hands-free

1Seg being recorded

Record message

Vibrator Manner mode

i-appli call IC card lock

Restriction indicator

Hands-free Mute in progress (only when in the

open position)

> <z

–30– –32–

n \ Alarm o

p =; q s Earphone/Microphone connection r x USB mode s

B Non-FOMA card is inserted t g Self mode u a v L Bluetooth w P VeilView

Music&Video Channel program reservation

i-mode mail send reservation

FOMA card is malfunctioning or not inserted

PushTalk

–31–

x 4KJ 3G/GSM yIH Status of Comics setting z Q < C Receiving information > Multitask

ɦ Refer to P. 28 to P. 31 of the manual for detailed explanations

of displayed icons.

ToruCa

<Emergency contacts in case of

loss or other accidents>

Omakase Lock

ɦ Omakase Lock is a paid service. However, if Omakase

Lock is subscribed while or at the same time as when the use of FOMA terminal is suspended, or if the user is a member of docomo Premier Club, the usage fee of Omakase Lock is not charged. Additionally, if Keitai Anshin Pack (Mobile Phone Security Package) is subscribed, Omakase Lock is available for a flat-rate.

Enable/Disable Omakase Lock

0120-524-360 Office hours: 24hours

Other contacts

<Contacts: >

ɦ Please confirm the phone number before you dial.

–34–

–35––33–

SH-04

Quick Manual “Overseas Use”

Loss or theft of FOMA terminal or payment of

cumulative cost overseas

<docomo Information Center> (24-hour service)

For DOCOMO mobile phones

International call access code of your country of stay (Table 1)

* Communication charges to Japan will apply when you make a call

from a fixed-line telephone.

ɦ If you use the SH-04A, you should dial the number

+81-3-5366-3114. For fixed-line telephones <Universal number>

International prefix number for the universal number (Table 2)

Communication charges or other charges to your country of stay will apply.

ɦ See P.19 to P.20 and P.21 to P.22 for international call access

codes of major countries (Table1) and international prefix

number for the universal number (Table2).

-81-3-5366-3114* (toll free)

-800-0120-0151*

Failures encountered overseas

(24-hour service)

For DOCOMO mobile phones

International call access code of your country of stay (Table 1)

* Communication charges to Japan will apply when you make a call

from a fixed-line telephone.

ɦ If you use the SH-04A, you should dial the number

+81-3-6718-1414. For fixed-line telephones <Universal number>

International prefix number for the universal number (Table 2)

Communication charges or other charges to your country of stay will apply.

ɦ See P.19 to P.20 and P.21 to P.22 for international call access

codes of major countries (Table1) and international prefix

number for the universal number (Table2).

-81-3-6718-1414* (toll free)

-800-5931-8600*

–1– –2–

Preparing for overseas use

Refer to the following before using the FOMA terminal overseas.

 “Mobile Phone User’s Guide [International Services]”  “Mobile Phone User’s Guide [Network Services]”

 PDF file “٬ٸ၌ဥ΄ͼΡ” pre-installed in [My Documents] of

Data box

Setting i-mode

ɡ Setting in Japan

1 In the Stand-by Display Touch Launcher, select

[8]/[iMenu]/[English]/[Options]/ [International Settings]/[i-mode services Settings]/[Yes]/select the [Enter i-mode Password] field/enter the i-mode password/ [OK]/[OK].

ɡ Setting in overseas

1 In the Stand-by Display Touch Launcher, select

[8]/[iMenu]/[English]/[International Settings]/[i-mode services Settings]/[Yes]/ select the [Enter i-mode Password] field/enter the i-mode password/[OK]/[OK].

Setting remote access

ɡ Setting in Japan

1 In the Custom menu, select [Settings]/[Other

NW Services]/[Remote Control]/[Activate]/ [Yes].

ɡ Setting in overseas

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Remote access (Int.)]/[Yes]/operate according to the voice guidance.

Correcting date and time automatically

1 In the Custom menu, select [Settings]/[General

settings]/[Date settings]/select the [Auto time correction] field/[ON]/[Complete].

Setting time zone manually

1 In the Custom menu, select [Settings]/[General

settings]/[Date settings]/select the [Auto time

correction] field/[OFF].

2 Select [City]/select a city/[Complete].

Available network

3G network Available GSM network Available GPRS network Available

Setting network communication system

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International

Roam.]/[3G/GSM setting]/select the

communication method.

–4––3– –5–

Available services overseas

Communication

service

Voice call Videophone i-mode mail i-mode i-Channel i-concier i-Widget SMS Packet transmission by

connecting a PC, etc.

Unable to use 64K data communication by connecting a PC,

etc. overseas.

3G GSM GPRS

AAA ABB ABA ABA ABA ABA ABA AAA

ABA

Setting a search method of

Telecommunications carrier name

telecommunications carrier

Network search mode

Default setting: Auto (Automatically switches telecommunications carriers)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Network search mode].

2 Select [Auto]/[Yes].

: To manually switch telecommunications carriers:

Select [Manual]/select a telecommunications carrier.

: To re-search for the host network: Select [Network

re-search].

Setting a telecommunications carrier to

preferentially connect to

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Network search mode]/[PLMN setting]/point the cursor to the number of the priority order/[Submenu].

2 Select [PLMN manual select]/enter a country

code (MCC)/[OK]/enter a network code (MNC)/[OK]/select a communication method/[Yes].

: To save from a telecommunications carrier list: Select

[UPLMN by list]/select a telecommunications carrier/select a communication method/[Yes].

: To save the telecommunications carrier currently

connected to: Select [Set VPLMN to PLMN]/[Yes].

: To change the priority: Select [Change priority]/

select a destination/[Yes].

Displaying a telecommunications carrier

name in stand-by

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Operator name disp]/[Display on]/ [Yes].

–6– –8–

Setting after homecoming Making a call

If Network search mode is set to [Auto], reset Network search mode to the FOMA network (DOCOMO) automatically when the power is turned on after homecoming.

ɡ Setting to FOMA network (DOCOMO) manually

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Network search mode]/[Manual]/ [DOCOMO].

–7–

Making a call outside your country of stay

(including Japan)

ɡ Using + to make an international call

1 In stand-by, press s/keep touching [0(+)]/

enter the country code, area code (city code) and other party’s phone number/[B] or s (Phone)/ [V.phone].

When the area code (city code) begins with 0, omit the

when dialing. However, include landline phones in some countries or regions such as Italy.

when making a call to

ɡ Making an international call outside your country

of stay using country code conversion

0 at the beginning of a phone number is automatically converted to the country code set in Country code conversion. Example: Make a call from the phonebook

1 In the Stand-by Display Touch Launcher, select

[6]/select the other party/ [Phone] or s (Phone)/[V.phone]/[Call].

–10–

ɡ Making an international call

Save a country number using Set country code to select a country code before making an international call. The following operation is available overseas only.

1 In stand-by, press s/enter a phone number/

[Submenu]/[Add prefix setting]/[International Call]/select the country code/[B] or s (Phone)/[V.phone].

Making a call in your country of stay

1 In stand-by, press s/enter a phone number/

[B] or s (Phone)/[V.phone].

ɡ Making a call to the phone in your country of

stay using phonebook

1 In the Stand-by Display Touch Launcher, select

[6]/select the other party/[Phone] or s (Phone)/[V.phone]/[Original number].

–11––9–

Making a call to a WORLD WING subscriber overseas

Even when making a call to the phone in your country of stay, make an international call to Japan if the call recipient is a “WORLD WING” subscriber overseas.

1 In stand-by, press s/keep touching [0(+)]/

enter 81/enter the other party’s mobile phone number excluding the first 0/[B] or s (Phone)/ [V.phone].

Receiving calls

1 Press s to answer an incoming call.

ɡ Having calls made to your FOMA terminal from

Japan

Enter the phone number in the same way as it is entered in Japan and make a call.

ɡ Having calls made to your FOMA terminal from

countries other than Japan

Enter international call access code of the country of the caller-81-user’s phone number excluding the first 0 and make a

call.

Setting roaming guidance Call barring

Make this setting while still in Japan. ɦ When the confirmation screen appears, select [Yes].

1 In the Custom menu, select [Settings]/[Other

NW Services]/[Roaming guidance].

2 Select [Activate].

: To deactivate: Select [Deactivate]. : To check settings: Select [Check setting].

Depending on the overseas telecommunications carrier, the

setting cannot be made.

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Call barring].

2 Select [Activate]/[Yes]/select the barring

method/enter the network security code/[OK].

: To deactivate: Select [Deactivate]/[Yes]/enter the

network security code/[OK].

: To check settings: Select [Check setting].

Missed Call Notice

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Missed Call Notice].

2 Select [Activate]/[Yes].

: To deactivate: Select [Deactivate]/[Yes]. : To check settings: Select [Check setting].

–12–

Using network service

Set in your country of stay. To use network service overseas, set Remote Control to

“Activate”.

ɦ When the confirmation screen appears, select [Yes]. ɦ Operate according to the voice guidance.

Voice Mail (Int.)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International Roam.]/[Voice Mail(Int.)].

2 Select [Activate Voice Mail].

: To deactivate: Select [Deactivate]. : To play messages: Select [Play Messages]. : To set the service: Select [Voice Mail settings].

–13– –14–

Call Forward (Int.)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International

Roam.]/[Call Forward (Int.)].

2 Select [Activate].

: To deactivate: Select [Deactivate]. : To set the service: Select [Settings].

Roaming guidance (Int.)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International

Roam.]/[Roam. guidance(Int.)].

Missed Call Notice (Int.)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[International

Roam.]/[MissedCallNoticeInt.].

Country codes of major countries

The following shows “Country code” used when making international calls or setting International dial assist.

Country/Region Code Country/Region Code

Australia 61 Hong Kong 852 Austria 43 Hungary 36 Belgium 32 India 91 Brazil 55 Indonesia 62 Canada 1 Italy 39 China 86 Japan 81 Czech 420 Macau 853 Egypt 20 Malaysia 60 Fiji 679 Maldives 960 Finland 358 Netherlands 31 France 33 New Caledonia 687 Germany 49 New Zealand 64 Greece 30 Norway 47

–16––15– –17–

Country/Region Code Country/Region Code

Peru 51 Tahiti Philippines 63 Russia 7 Taiwan 886 Singapore 65 Thailand 66 South Korea 82 Turkey 90 Spain 34 U.K. 44 Sweden 46 U.S.A. 1 Switzerland 41 Vietnam 84

ɦ For other country codes and details, refer to the DOCOMO

“International Services website”.

(French Polynesia)

689

International call access codes of major

countries (Table 1)

The following shows the International call access codes of major countries.

Country/Region Code Country/Region Code

Australia 0011 Hungary 00 Belgium 00 India 00 Brazil 0021/

0014

Canada 011 Italy 00 China 00 Luxemburg 00 Czech 00 Macau 00 Denmark 00 Malaysia 00 Finland 00 Monaco 00 France 00 Netherlands 00 Germany 00 New Zealand 00 Greece 00 Norway 00 Hong Kong 001 Philippines 00

Indonesia 001 Ireland 00

Country/Region Code Country/Region Code

Poland 00 Taiwan 002 Portugal 00 Thailand 001 Russia 810 Turkey 00 Singapore 001 U.A.E. 00 South Korea 001 U.K. 00 Spain 00 U.S.A. 011 Sweden 00 Vietnam 00 Switzerland 00

–18– –20–

International prefix number for the

universal number (Table 2)

The following shows the International prefix number for the universal number of each country.

Country/Region Code Country/Region Code

Argentina 00 Hong Kong 001 Australia 0011 Hungary 00 Austria 00 Ireland 00 Belgium 00 Israel 014 Brazil 0021 Italy 00 Bulgaria 00 Luxemburg 00 Canada 011 Malaysia 00 China 00 Netherlands 00 Columbia 009 New Zealand 00 Denmark 00 Norway 00 Finland 990 Peru 00 France 00 Philippines 00 Germany 00 Portugal 00

–19–

Country/Region Code Country/Region Code

Singapore 001 Switzerland 00 South Africa 09 Taiwan 00 South Korea 001 Thailand 001 Spain 00 U.K. 00 Sweden 00 U.S.A. 011

About inquiries overseas

For lost, stolen, and cost settlement, or malfunction of the FOMA terminal overseas, refer to “Loss or theft of FOMA terminal or payment of cumulative cost overseas” on the cover of Quick Manual “Overseas Use” or “Failures encountered overseas” on P.1.

Add the “International call access code (Table 1)” or

“International prefix number for the universal number (Table 2)” that is assigned to your country of stay, to the head of your phone number for inquiries.

–22–

–23––21–

Check/change the subscription, apply for various services, and request various information materials online.

From i-mode

From a PC

ɦ You will need your “Network Security Code” to access the site from i-mode. ɦ No packet communication charges are incurred when accessing the site from i-mode. Accessing from overseas will incur charges. ɦ You will need your “docomo ID/Password” to access the site from PC. ɦ If you do not have or you have forgotten your “Network Security Code” or “docomo ID/Password”, contact the number listed in General Inquiries on the back of this manual. ɦ The site may not be available depending upon the content of your subscription. ɦ You may not be able to access some site services due to system maintenance, etc.

iMenu/ݖအ΍εȜΠ

Packet communication charges free

My docomo (http://www.mydocomo.com/)/ڎ૭ࣺȆ௽ (Various Applications/Procedures)

(User Support)/૭ࣺȆ௽

(Applications/Procedures)/ڎ૭ࣺȆ௽

(Various Applications/Procedures)

Please follow proper etiquette

When using your FOMA terminal, please be considerate of those around you.

Turn off your FOMA terminal in the following places

ɡ When in an area where use is prohibited

There are places where the use of mobile phones is prohibited. Be sure to turn off your FOMA terminal in the following places.

ɚOn an aircraft ɚIn a hospital ɦ There are people outside hospital wards who also use electric medical

equipment. Please make sure that your FOMA terminal is turned off in the lobby and waiting room.

ɡ While driving

Using a mobile phone in hand while driving is regarded as a punishable act. ɦ If there is no choice but to receive a call, use Hands-free and tell the caller

that you will “call back”, and then pull over to a safe place to make a call.

ɡ When in crowded places such as rush-hour trains in case

somebody nearby is using an implanted cardiac pacemaker or implanted cardioverter-defibrillator

Your FOMA terminal may affect the operation of such equipment.

ɡ When in public places such as theaters, movie theaters, or

museums

Use of your FOMA terminal in quiet public places will annoy others.

Be careful of where you use your FOMA terminal and the

volume of your voice and the ring tone

ɡ When using your FOMA terminal in a restaurant or a hotel

lobby, lower your voice. In crowded places, be careful not to obstruct other pedestrians.

Be considerate of the privacy of the individuals around you

Please be considerate of the privacy of individuals around you when taking and sending images using a

camera-enabled mobile phones.

The following functions will help you to keep your

manners in public

There are useful functions you can use to set your FOMA terminal not to answer incoming calls, and to silence all sounds.

ɜ Manner mode (nP. 98)/Original manner mode (nP. 99)

Silences the Key/Touch sound and all the sounds from the FOMA terminal, and Record message is set (Manner mode). When in the Manner mode, automatically set functions (Record message, Vibrator, Mic sensitivity up, Ring tone, Mail ring tone, alarm tone, Key/Touch sound and Low battery alarm) can be set to ON (enable)/OFF (disable) (Original manner mode).

ɜ Public mode (Drive mode/Power OFF) (nP. 67, P. 68)

The caller hears a guidance message stating that the receiver is driving, or in the place where the receiver should refrain from using the mobile phone or turn off the power. The call is disconnected.

ɜ Vibration mode (nP. 97)

Notifies incoming calls by vibration.

ɜ Record message (nP. 68)

When you are unable to take a call, the Record message function records the caller’s message.

ɦ You can also use optional services such as Voice Mail Service

(nP. 414) and Call Forwarding Service (nP. 417).

Sharp HRO00088 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
