Sharp HRO00065 Users Manual

Introduction

Congratulations on your new Sharp SX862 phone.
About This User Guide
This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.
NOTICE
• We strongly recommend that you keep separate permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rendered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.
• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.
• All company and/or product names are trademarks and/or registered trademarks of their respective holders.
• Screen layout may differ from that illustrated in this user guide. The information described in this user guide is subject to change without notice.
• All the functions described in this user guide may not be supported by all networks.
• We assume no responsibility for downloaded contents, information, etc. from the network.
Intellectual Property Rights
According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from the copyright owner to reproduce, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Introduction 1
Powered by JBlend™ Copyright 1997-2008 Aplix Corporation. All rights reserved. JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.
microSD Logo is a trademark.
Bluetooth is a trademark of the Bluetooth SIG, Inc.
Powered by Mascot Capsule Mascot Capsule
©2002-2008 HI Corporation. All Rights Reserved.
Licensed by Inter Digital Technology Corporation under one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pending, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450: 4,811,420: 5,228,056: 5,420,896: 5,799,010: 5,166,951: 5,179,571 & 5,345,467
T9 Text Input is covered by the Hong Kong Standard Patent No. HK0940329 and HK1010924. T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are pending worldwide.
®
®
/Micro3D Edition™
is a registered trademark of HI Corporation
CP8 PATENT
2 Introduction
The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sharp is under license. Other trademarks and trade names are those of their respective owners.
Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations ; 4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754 5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338
This product contains NetFront Browser and NetFront Messaging Client of ACCESS CO.,LTD. ACCESS and NetFront are trademarks or registered trademarks of ACCESS CO., LTD. in Japan and other countries. NetFront Browser © Copyright 1996-2007 ACCESS CO., LTD. NetFront Messaging Client © Copyright 2000-2007 ACCESS CO., LTD. This software is based in part on the work of the Independent JPEG Group.
®
Word is a product name of Microsoft Corporation in the United
Microsoft States. Microsoft, PowerPoint and Microsoft Excel are registered trademarks of Microsoft Corporation in the United States and/or other countries.
®
and Acrobat® are trademarks of Adobe Systems Incorporated.
Adobe
®
This product employs Adobe
®
Flash
Lite™ technology developed by Adobe Systems Incorporated.
®
Adobe
Flash® Lite™ Copyright © 2003-2007 Adobe Systems Incorporated. All rights reserved. Adobe and Flash are either trademarks or registered trademarks of Adobe Systems Incorporated in the United States and/or other countries.
“Document Viewer” is powered by Picsel Technologies. Picsel, Picsel Powered, Picsel Cube Logo,
Viewer are Trademarks or Registered Trademarks of the Picsel Group of Companies.
CYCLOID is a registration-pending trademark of SHARP Corporation in Hong Kong.
IrSimple™, IrSS™ and IrSimpleShot™ are trademarks of the Infrared Data Association
This product is licensed under the MPEG-4 Visual Patent Portfolio License for the personal and non-commercial use of a consumer to (i) encode video in compliance with the MPEG-4 Video Standard (“MPEG-4 Video”) and/or (ii) decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a licensed video provider. No license is granted or implied for any other use. Additional information may be obtained from MPEG LA. See http://www.mpegla.com.
This product is licensed under the MPEG-4 Systems Patent Portfolio License for encoding in compliance with the MPEG-4 Systems Standard, except that an additional license and payment of royalties are necessary for encoding in connection with (i) data stored or replicated in physical media which is paid for on a title by title basis and/or (ii) data which is paid for on a title by title basis and is transmitted to an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. See http://www.mpegla.com for additional details.
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
®
.
Picsel File Viewer and Picsel Document
Introduction 3
Useful Functions and Services
Your phone offers you the following features:
• Video Calling. You can talk while viewing images of each other on respective screens.
• 3D and colour Java™ games. You can also download various games and applications from SmarTone-Vodafone via the mobile Internet.
• Cycloid position. You can rotate the display 90° clockwise for viewing images in a 3.2-inch full wide VGA LCD.
• Advanced Super View (ASV) colour LCD main display with images that are clearer and easier to view.
• A built-in digital camera with an auto focus function for taking pictures and video clips.
• A message function for reading and creating SMS messages.
• MMS (Multimedia Messaging Services) for sending picture, sound and video messages to brighten someone’s day.
• Email for sending up to 300 KB and receiving mail with attachments.
• A colour WAP/Web browser for accessing information on the mobile Internet.
• Your own ringtones and ring video clips. You can use sound or video clip files as a ringtone or ring video clip.
4 Introduction
• A music player that can play back MP3, MPEG-4 and 3GPP format sound files (supported codec of MPEG-4 or 3GPP are AMR, AAC, AAC+, and AAC+e).
• Playback of downloaded sound and video clip files.
• A voice recorder function for recording and playing back voice clips.
•A
Bluetooth
®
wireless technology interface for establishing contact and transmitting data with certain devices. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.
• An infrared interface for data communication. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.
• A schedule alarm for creating and sending schedule entries with alarm settings.
• A microSD™ memory card slot that expands connectivity with a PC using the memory card.

Contents

Introduction .............................................................. 1
List of Menu Functions ............................................ 7
Getting Started ......................................................... 9
Inserting/Removing the SIM/USIM Card and the
Battery ............................................................ 13
Charging the Battery ........................................ 14
Inserting/Removing the Memory Card ...............15
Connecting the Handsfree Kit ........................... 16
Turning Your Phone On and Off ........................ 17
Cycloid Position ............................................... 18
Display Indicators (Main Display) ....................... 20
Display Indicators (External Display) ..................22
Navigating Functions ............................................. 23
Voice Call/Video Calling Functions ........................24
Entering Characters ............................................... 32
Changing the Input Language ........................... 33
Changing the Input Method .............................. 33
Chinese User Dictionary ...................................38
Using Templates .............................................. 41
Copying, Cutting and Pasting Text .....................41
Insert Phonebook Entries ..................................41
Using the Menu .......................................................42
Main Menu ......................................................42
Shortcut Keys ...................................................42
Shortcuts .........................................................43
Call Manager ...........................................................44
Sending a Message from the Phonebook ...........46
Multimedia ..............................................................52
Camera ....................................................................58
Taking Pictures ................................................58
Recording Video Clips .......................................59
Common Functions in the Photo and Video
Camera Modes ................................................59
Functions in Photo Camera Mode ......................62
Functions in Video Camera Mode ......................66
Messages ................................................................67
SMS ................................................................67
MMS ...............................................................67
Email ...............................................................67
Area Info ..........................................................75
Browser ...................................................................80
Navigating a WAP or Web Page .........................81
Contents 5
Gallery ....................................................................84
Games & Applications ............................................ 92
Organiser ................................................................ 97
SIM Application .................................................... 113
Settings ................................................................114
Call Log ................................................................. 139
Connectivity ......................................................... 141
Bluetooth ......................................................141
Infrared ......................................................... 144
Mass Storage ................................................ 145
USB Charge .................................................. 145
Card Settings ................................................145
Connecting SX862 to Your PC .............................. 147
System Requirements .................................... 147
3G/GSM Modem ............................................ 147
Handset Manager .......................................... 149
Music Manager ............................................. 150
Sync Manager ............................................... 152
Troubleshooting ................................................... 153
Safety Precautions and Conditions of Use .......... 155
Conditions of Use ........................................... 155
Mobile Light LED Properties ........................... 156
Environment .................................................. 158
6 Contents
Precautions Concerning Vehicle Use ................158
SAR ...............................................................159
FCC NOTICE ..................................................159
Out of Warranty List .............................................161
Index .....................................................................162

List of Menu Functions

SX862 functions are listed below. See relevant page for details of each function. The menu’s corresponding number is used for shortcuts. For details, see page 42.
1 Games & Applications
1 GSX™ & Java™ 2 Java™ Settings 3 Java™
Information
2 Browser
1 Homepage 2 Go to URL 3 Bookmarks 4 Alert Inbox 5 My Saved Page 6 Access History 7 Browser Settings 8 www 9 PLUS 10 News 11 Music 12 Games 13 Sports 14 Email
p. 92 p. 94 p. 96
p. 80 p. 80 p. 80 p. 80 p. 80 p. 80 p. 82
– – – – – – –
3 Organiser
(Tab 1: Tools 1)
1 Calendar 2 Alarms 3 Tasks 4 Calculator 5 Expenses Memo
(Tab 2: Tools 2)
1 Stopwatch 2 Countdown Timer 3 World Clock 4 Hour Minder
(Tab 3: Tools 3)
1 Document Viewer 2 Tex t Templ ate s 3 Voice Recorder 4 Phone Help
p. 97 p. 101 p. 103 p. 106 p. 107
p. 108 p. 109 p. 109 p. 110
p. 110 p. 111 p. 112 p. 112
4 Messages
1 Create Message 2 Message 3 Email 4 Alert Inbox 5 Voice Mail 6 Cell Broadcasts 7 Area Info 8 Messaging
Settings
9 Memory Status
5 Camera
p. 67 p. 71 p. 71
– p. 74 p. 75 p. 75
p. 58
6 Gallery
1 Pictures 2 Videos 3 SD Video 4 Music and Sounds 5 Themes 6 GSX™ & Java™
®
7 Flash 8 Other Documents 9 Memory Status
7 Multimedia
1 FoneTV 2 www 3 Videos 4 Music
p. 84 p. 85 p. 85 p. 86 p. 86 p. 92 p. 87 p. 88 p. 91
p. 52 p. 52 p. 52 p. 55
List of Menu Functions 7
8 Call Manager
1 Phonebook 2 Add New 3 Call Voicemail 4 Manage Groups 5 My Card 6 Speed Dial List 7 Message Groups 8 Phonebook
Settings
9 Service Dialling
*
No.
10 Advanced
p. 44 p. 44
p. 50 p. 44 p. 51 p. 47 p. 44
p. 46
p. 49
8 List of Menu Functions
9 Settings
(Tab 1: Phone Settings)
1 Profiles 2 Display Settings 3 Themes 4 Sound Settings 5 Date & Time 6 Language 7 Display Rotation 8 Switch ringtone
output
9 Earpiece Volume 10 Change Menu 11 Security Settings 12 Master Reset
(Tab 2: Call/Video Call) 1 Voicemail &
Diverts
2 Video Calling
Settings
3
Show Your Number
4 Restrict Calls 5 Minute Minder 6 Auto Answer 7 Call Waiting 8 Display Call Timer 9 Display Call Cost 10 Auto Redial
p. 114 p. 115 p. 119 p. 119 p. 123 p. 124 p. 124 p. 124
– p. 125 p. 125 p. 127
p. 127
p. 129
p. 131 p. 131 p. 134 p. 134 p. 134 p. 134 p. 135 p. 135
(Tab 3: Network Settings)
1 Network Settings 2 Off Line Mode 3 Internet Settings
10 SIM Application
11 Call Log
1 All Calls 2 Dialled Numbers 3 Missed Calls 4 Received Calls 5 Call Timers 6 Call Costs 7 Data Counter
*
p. 135 p. 136 p. 136
*
p. 113
p. 139 p. 139 p. 139 p. 139 p. 139 p. 140 p. 140
12 Connectivity
1 Bluetooth 2 Infrared 3 Mass Storage 4 USB Charge 5 Card Settings
* Depends on SIM/USIM card
contents.
p. 141 p. 144 p. 145 p. 145 p. 145

Getting Started

1
2
3
4 5 6 7
8 9
10
11 12
13 14
15 16 17
18 19
20
21
22
27
28
23
24
25
26
29
30
31
Getting Started 9
1. Earpiece
2. Light Sensor
3. Main Display
4. Speaker
5. Navigation Keys (Arrow Keys): abcd
Moves cursor to highlight a menu item, etc. Up arrow key (a) displays the Bookmarks when pressed in standby. Down arrow key (b) displays the Phonebook entries when pressed in standby. Left arrow key (c) displays the list of GSX™ & Java™ when pressed in standby. Right arrow key (d) displays Gallery when pressed in standby.
6. Centre Key: B
Displays Main menu in standby, and executes functions. Long press in standby to initiate video camera.
7. Left Soft Key: A
Executes the function in the lower left of the screen. Displays Message menu in standby.
8. Send/Redial Key: D
Makes voice calls or accepts calls, and displays the call logs in standby.
10 Getting Started
9. Shortcut Key: E
Displays Shortcut menu.
10.Voicemail Key: G
Long press to connect to the Voicemail centre. (Depending on the SIM/USIM card.)
11.* /Shift Key: P
Switches character input method as follows on the text entry screen. In English mode: Abc, ABC, abc and 123. In T9 mode, T9 Abc, T9 ABC, T9 abc and 123. In Traditional Chinese mode: Abc, ABC, abc, 123, and T9 Stroke In Simplified Chinese mode: Abc, ABC, abc, 123, T9 PinYin, and T9 Stroke Press to enter P, ? or * in standby. Long press in standby to lock the keypad.
12.Multiple Functions Key: S
Press in standby to switch Profiles settings. Long press in standby to switch Profiles settings between the mode most recently activated and Silent mode. Switches displays when multiple applications are launched.
13.Right Soft Key: C
Executes the function in the lower right of the screen. Accesses “SmarTone
iN!
” by opening the browser in
standby.
14.End/Power Key: F
Ends a call and turns power on/off.
15.Clear/Back Key: U
Clears the characters before the cursor, returns to the previous screen, etc.
16.Multimedia Key: T
Displays Multimedia menu.
17.Keypad
18.#/Silent Key: R
Displays symbol screen on the text entry screen. Long press to switch languages on the text entry screen. Long press in standby to switch Profiles settings between the mode most recently activated and Silent mode.
19.Microphone
20.External Connector:
Used to connect either the charger or a USB data cable.
21.Sub Display
22.Small Light:
Flashes when an incoming call or a new message is received or missed, if Event Light (p. 114) or Status Light (p. 115) is enabled.
23.Built-in Aerial:
Warning: Do not cover the top of the phone with your hand when in use as this may interfere with the performance of the built-in aerial.
24.microSD Card Slot
25.Side Keys: VW
Press in standby or during a call to increase or decrease the earpiece volume. Press while listening to music (or video) to increase or decrease the earpiece volume.
26.Camera Key: X
Long press in standby to activate the camera. Takes a picture or starts recording video when the camera is active. Press when the phone is closed to turn on the sub display. Long press when the phone is closed to turn on the Small Light.
27.Mobile Light:
Used as a flash in camera mode or as an auxiliary light.
Getting Started 11
28.Battery Cover
29.Camera
30.Handsfree Kit/Microphone Connector
31.Infrared Port:
Sends and receives data via infrared.
12 Getting Started

Inserting/Removing the SIM/USIM Card and the Battery

1. Slide off the battery cover ( ).
2
1
3. Hold the battery so that the metal contacts of the battery
are facing down, slide the guides on the top of the battery into the battery slots , and then insert it .
4
5
2. Slide the SIM/USIM card into the SIM/USIM holder .
SIM/USIM card
3
4. Replace the battery cover.
Note
Make sure that only 3V SIM/USIM cards are used.
Make sure that the standard accessory battery is used.
Battery Disposal
The device is battery-powered. In order to protect the environment, please read the following points concerning battery disposal:
• Take the used battery to your local waste depot, dealer or customer service centre for recycling.
• Do not expose the used battery to a naked flame, immerse in water or dispose with the household waste.
Getting Started 13

Charging the Battery

You must charge the battery for at least 150 minutes before using your phone for the first time.
Using the Charger
1. Open the cover of the external connector, and connect
the charger horizontally to the external socket located at the bottom of the phone until it clicks.
To Disconnect the Charger
When charging is completed, the battery indicator ic on displays the full charge status. The Small Light also turns off when completed.
1. Unplug the charger from the AC outlet.
2. Push and hold the side buttons of the charger , then
disconnect the charger from the external socket of the phone .
2. Connect the charger to an AC outlet.
When the phone is charging, the battery status icon ( ) displays the current status. The Small Light also lights up. Standard charging time: Approx. 150 minutes
Note
Charging time may v ary depending on the state of the b attery and other conditions. (See “Battery” on page 156.)
14 Getting Started
3. Close the cover.
Note
Do not use any non-approved chargers as they may damage your phone and invalidate any warranties, see “Battery” on page 156 for details.
Forcibly disconnecting the charger may cause malfunction.
To Charge Using the Cigarette Lighter Charger
The optional cigarette lighter charger supplies power for charging from the cigarette lighter socket of a car.
Battery Level Indicator
The current battery level is displayed in the upper right of the main and external displays.
Low Battery during Use
When the battery is running low, an alarm will sound and “ ” or “ ” is displayed on the main and external displays respectively.
If you are using your phone and you hear the low battery alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it.
Battery Indicators Charge Level
Sufficiently charged
Charging recommended
Charging required
Empty

Inserting/Removing the Memory Card

Note
Make sure that the phone is turned off before inserting/ removing the memory card.
Be sure to insert the card in the correct direction and orientation.
Keep all memory cards out of the reach of small children.
1. Turn off the phone.
2. Open the microSD card slot cover.
Getting Started 15
3. Insert the memory card until it clicks. (To remove the
memory card, push the memory card until it clicks.)
4. Close the cover.
Tip
You see the following indicators when the memory card is in use:
: Appears when the card is inserted. : Appears when the card is damaged or unusable. Make
sure the card is properly inserted. : Appears when the card is being written to or read. : Appears when the card is being formatted.
16 Getting Started

Connecting the Handsfree Kit

1. Open the connector cover.
2. Connect the handsfree kit.

Turning Your Phone On and Off

To turn the power on or off, long press F for approximately 2 seconds.
To Enter the PIN Code
If the PIN (Personal Identification Number) code is enabled you are asked to enter the PIN code each time the phone is switched on. For details on setting the PIN code, see “Enabling/ Disabling the PIN Code” on page 125.
1. Enter your PIN code.
The PIN code is 4 to 8 digits.
2. Press B.
Note
If your PIN code is entered incorrectly three times in a row, the SIM/USIM card is locked. See “Enabling/Disabling the PIN Code” on page 125.
If the clock settings have not b een entered, the date and time entry screen is displayed (p. 123).
To Copy All Phonebook Entries from the SIM/USIM Card
When you insert the SIM/USIM card into your phone for the first time and start the Phonebook application, you are asked whether you wish to copy Phonebook entries on the SIM/USIM card. Follow the on-screen instructions, or you can do it later using the Phonebook menu as follows:
“Call Manager”
“Advanced” → “Copy All Entries”
1. Select “From SIM to Handset”.
Getting Started 17

Cycloid Position

You can rotate the display 90° clockwise to view images in landscape orientation.
Rotating the Display
1. Open the phone into portrait position as illustrated.
18 Getting Started
2. Turn the display 90° clockwise.
Note
Do not turn the display anticlockw ise as this may damage the phone.
Do not carry the phone in the cycloid position as this may damage the display.
Assigning a Function
You can assign a function to activate automatically when the display is rotated to the cycloid position in standby.
When the display is rotated for the first time, the “Rotate 90° to” screen is displayed.
Select a function to assign from the following items:
• Show Multimedia Menu
• Open Received Msg
• Activate Camera/Video
• Show Main Menu
• Off (Standby)
Note
You can change the assigned function by pressing [Rotate 90° to] on the screen, or from the Display Rotation menu (p. 124).
Some functions remain active even if the display is rotated from the portrait position while a function is active.
Getting Started 19

Display Indicators (Main Display)

Indicator area
Right soft keyCentre keyLeft soft key
20 Getting Started
1. / : Strength of received signal/Service out of range
: HSDPA : EDGE : 3G (UMTS)/GPRS
: GPRS enabled : Roaming outside network
2. / : Connection to the server [established/ communicating]
3. / : Voice call [incoming/in progress]
4. / / : Video calling communication mode enabled [voice/video/voice and video]
5. / : Alerts [text message and multimedia message/Email]
6. / / /#: Mailbox full [SIM/USIM card only/handset only/both SIM/USIM card and handset/Email only]
7. : “Voice Calls” diverts set to “Always”
8. ///////: Connection status [USB cable [standby/exchanging information]/IrDA setting [standby/ exchanging information]/
Bluetooth
wireless
setting [standby/exchanging information/
Bluetooth
talking with the
headset/Hide my
phone]]
9. / / : Java™ application [executed (colour)/ suspended (grey)]/Music
10. : Secure WAP/Web page displayed
11. / / : Silent/vibration setting [silent/vibration enabled/silent and vibration enabled]
12. / / : Speaker mode [speaker phone/speaker activated/microphone muted]
13. : Memory card inserted
14. / : Battery level [normal position/cycloid position]
15. : Daily alarm enabled
16. / : Schedule entry enabled [with/without reminder alarm]
17. : Outbox contains unsent messages [text message/multimedia/Email]
18. / / : WAP/OTA provisioning alerts [WAP alert/OTA provisioning alert/WAP and OTA provisioning alerts]
19. : Voicemail message alert
20. : “Show Secret Data” set to “On”
21. : Function Lock enabled
22. : Keypad Lock enabled
23.(No display)///: Current profile [Normal/Car/Silent/Original]
24. : Hour minder enabled
25. : Auto answer enabled
Getting Started 21

Display Indicators (External Display)

Status Indicators
1. ///: Battery level [sufficiently charged/charging recommended/charging required/empty]
2. : Clock
3. / : Strength of received signal/Service out of range
4. / : Missed events
5. : Voice call incoming
6. : Video call incoming
7. : Call in progress
8. / : Alerts [messages/Delivery Report]
22 Getting Started
9. / / : Alarm enabled [Daily alarm/Schedule alarm/ Task alarm]
10. : Sound file being played
11. : Streaming
12. : Stopwatch/countdown timer
13. : OBEX data incoming
14. : Voice Recorder activated

Navigating Functions

All applications are accessed from the Main menu. To open the Main menu, press the centre key B in standby.
To launch applications, you will need to highlight menu items, and make selections. To select a menu item (indicated in quotation marks), move the cursor using a, b, c and d, and press B to select.
In certain procedures, you will need to press one of the soft keys (indicated in square brackets), which are displayed in the lower left and right of the screen. Press the corresponding soft key (A or C).
To return to the previous screen, press the right soft key if it
Back
displays if it displays
Each section in this user guide starts with a list of items you will need to select in order (indicated in italics) before performing the procedures shown. Select each item to reveal the next set of items that you have to choose from. Open subsection items after opening those listed in the main section.
Example:
“Games & Applications”
. To close the Main menu, press the right soft key
Back
.
“Java™ Settings”
The following menus have tabs - Organiser and Settings. You can select the desired tab with the c/d key, and after
that you can select the item you wish to set in the selected tab with the a/b key.
Example:
“Settings” Settings”
“Call/Video Call” tab → “Video Calling
Navigating Functions 23

Voice Call/Video Calling Functions

Making a Voice Call
1. Enter the area code and the phone number you wish to
dial, and then press D to dial.
If you enter the wrong number, press U to delete the number to the left of the cursor.
Emergency Calls
1. Enter 999 or 911 (international emergency number)
using the keypad and press D to dial.
Note
Emergency calls may not be able to be made on all mobile phone networks when certain network services and/or phone features are in use. Contact your service provider for more information.
This emergency number can normally be used to make an emergency call in any country, with or without a SIM/USIM card inserted, if a 3G (UMTS)/GSM network is within range.
24 Voice Call/Video Calling Functions
International Calls
1. Long press Q until a + (international dialling prefix)
sign is displayed.
2. Enter the country code, followed by the area code
(without the leading zero) and the phone number, and press D to dial.
Adding an Entered Phone Number to the Phonebook
1. After entering a phone number, press [Options] and
select “Save Number”.
For details on creating a new entry, see “Adding a New Entry” on page 44.
Showing or Hiding My Phone Number on the Display of the Called Party
1. After entering a phone number, press [Options], select
“Show My ID” or “Hide My ID” and press D to dial.
Speed Dialling
Up to 8 phone numbers from the Phonebook memory (Handset and SIM/USIM) can be assigned to speed dials. You can call the numbers using the digit keys (G to O). The phone number of the Voicemail centre is assigned to G.
For details on setting the speed dial list, see “Speed Dial List” on page 51.
1. To dial a number using the speed dial, long press any of
the digit keys (G to O).
The phone number saved in the speed dial list is dialled.
Redialling
You can redial numbers in the call log. Select from specific categories or “All Calls”. Specific categories contain up to 30 numbers and the “All Calls” list contains up to 90.
1. Press D in standby.
2. Select the category from “All Calls”, “Dialled Numbers”,
“Missed Calls” or “Received Calls”.
To switch logs, press c or d.
3. Highlight the phone number you wish to call.
4. Press D to redial a voice call or long press D to redial
a video calling.
Answering a Voice Call
When an incoming call is detected, the phone rings.
1. Press D or B to answer the call.
Or press any key ex cept F, U, S, [Options] or [Busy] when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile of each mode (p. 115).
Tip
If you have subscribed to the Calling Line Identification (CLI) service and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Phonebook, the caller’s name is displayed on the screen.
If the number is a restricted number, the display shows “Withheld”.
When you receive a call from the person whose picture is registered in the Phonebook, the picture and name are displayed.
Voice Call/Video Calling Functions 25
Rejecting an Incoming Call
1. Press F while the phone is ringing to reject a call you do
not wish to answer.
Letting the Caller Know You are Unavailable
1. Press [Busy] while the phone is ringing to send a busy
tone to the caller.
In Call Menu (Voice Call)
Your phone has additional functions available while a call is in progress.
Adjusting the Earpiece Volume
You can adjust the earpiece volume (and handsfree kit volume, if connected) to five levels.
1. Press V or W to display the Earpiece Volume screen.
2. Press V (or a/d) to increase the volume of the call or
press W (or b/c) to decrease the volume.
3. Press B when the volume is set to the desired level.
Turning the Speaker On and Off
You can talk via the loudspeaker on the phone when it is on.
1. During a call, press B.
26 Voice Call/Video Calling Functions
Putting a Call on Hold
This function allows you to manage two calls at the same time. If you wish to make another call while you are talking to someone, you can put the current call on hold to call someone else.
To Make Another Call during a Call
1. During a call, press [Options] and select “Hold”.
The current call is put on hold.
2. Press [Options] and select “Dial New Number”.
3. Enter the phone number you wish to make another call
to, then press D.
Tip
You can also make another call by entering the phone number during a call instead of step 1. The current call is automatically put on hold.
Accessing SMS/MMS Menu during a Call
1. During a call, press [Options] and select “Messaging”.
The following options are available: “Create Message” to make an SMS and MMS, or “Inbox”, “Sent” or “Drafts” to access these folders. For details on SMS and MMS, see “SMS” and “MMS” on page 67.
Call Waiting
This service notifies you of another incoming call while you have a call in progress.
1. During a call, press [Options] and select “Hold &
Answer” to answer the second call.
The first call is put on hold and you can now talk to the second caller. You can also answer the second call by pressing D.
Note
You need to set “Call Waiting” to “On” if you wish to use the Call Waiting service (p. 134).
Call Waiting service may not be available on all networks. Contact your service provider for more information.
If you do not wish to answer the second call, press [Options] and select “Busy” in step 1. If “Reject” is selected, the log of the second call is saved as a missed call.
Conference Call
Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.
To Make a Conference Call
You must have one active call and one held call.
1. During a call, press [Options] and select “Conference
All” to join the conference call.
2. Press F to end the conference call.
Note
The conference call service may not be available on all networks. Contact your service provider for more information.
To end the call with all participants, press [Options] and select “End All Call(s)”.
To reject adding more participants to the current party, press [Options] and select “Reject”, or you can send the busy tone by selecting “Busy”.
You have more options for the Conference call after selecting “Conference All” in step 1:
To put all participants on hold, select “Hold All”.
To put all participants except the current call on hold,
select “Private”.
Voice Call/Video Calling Functions 27
To Add New Participants to the Conference Call
1. Press [Options] and select “Dial New Number”.
2. Enter the number you wish to include in the conference
call and press D to dial.
3. Press [Options] and select “Conference All” to join the
conference call.
If you wish to add other participants, repeat steps 1 to 3.
To End the Call with a Conference Call Participant
1. During a conference call, highlight the person that you
wish to disconnect from the conference call.
2. Press [Options] and select “End This Call”.
To Have a Private Conversation with One of the Participants
If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.
1. During a conference call, select the person that you wish
to talk to.
2. Press [Options] and select “Private”.
3. Once you have finished the private conversation, press
[Options] and select “Conference All” to return to the conference call.
28 Voice Call/Video Calling Functions
Muting the Microphone
1. During a call, press [Mute].
To use the microphone again, press [Unmute].
Making a Video Calling
Note
Video callings can only be made and received if both parties have 3G capable phones and 3G coverage. See “Display Indicators (Main Display)” on page 20.
Make sure that the battery is fully charged and the signal is strong before using this function.
Turn the loudspeaker on or use a handsfree kit so that you can talk while looking at the video calling screen on the display.
Use the camera to send live video images.
Making a Video Calling
To Make a Video Calling by Entering the Phone Number First
1. Enter the area code and the phone number you wish to
dial, and then long press D to dial.
If you enter the wrong number, press U to delete the number to the left of the cursor. When connected, the image of the called party is displayed in the upper part of the screen and yours in the lower left.
Tip
If the called party’s phone is not video calling enabled, you can press F and enter the phone number again to make a voice call.
Answering a Video Calling
When an incoming call is detected, the phone rings.
1. Press D to answer the call with video, or press B or
[Options] and select “Camera Off” to answer with voice only.
Tip
If you have subscribed to the Calling Line Identification (CLI) service and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Phonebook, the caller’s name is displayed on the screen.
Rejecting an Incoming Call
1. Press F while the phone is ringing to reject a call you do
not wish to answer.
Letting the Caller Know You are Unavailable
1. Press [Busy] while the phone is ringing to send a busy
tone to the caller of an incoming call letting them know that you cannot answer the call.
Voice Call/Video Calling Functions 29
In Call Menu (Video Calling)
Muting the Microphone
1. During a video calling, press [Mute].
To use the microphone again, press [Unmute].
Swapping Images
You can swap images between the main and sub screens.
1. During a video calling, press [Options] and select
“Switch Images”.
2. Select “Priority to Incoming”, “Priority to Outgoing”,
“Incoming” or “Outgoing”.
Changing the Outgoing Image
During a video calling, you can switch the image shown to the caller between the camera image and an alternative image.
1. During a video calling, press [Options] and select
“Camera Picture”.
2. Select “External Camera” or “Alternative Image”.
“External Camera”: The image through the camera
is displayed and sent to the receiver.
“Alternative Image”: The camera is turned off and the
image selected in “Alternative Image” of “Video Calling Settings” (p. 129) is used.
30 Voice Call/Video Calling Functions
Turning the Speaker On and Off
You can talk via the loudspeaker on the phone when it is on.
1. During a video calling, press [Options] and select
“Loudspeaker On”.
Note
In a high-noise environment, you may not be able to continue a call or make a clear call. We recommend that you use the handsfree kit.
With this option, ther e may be interruption if you in crease the earpiece volume. We recommend that you decrease the earpiece volume or use the handsfree kit.
Loading...
+ 133 hidden pages
