Sharp HRO00040 User Manual

Declaration of Conformity

DRAFT

Hereby, Sharp Telecommunications of Europe Ltd, declares that this 703SH is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the original declaration of conformity can be found at the following Internet address: http://www.sharp-mobile.com

Introduction

Congratulations on your new 3G/UMTS 703SH phone.

About This User Guide

This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.

NOTICE

• We strongly recommend th at you keep separate permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rendered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.

• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.

• All company and/or product names are trademarks and/or registered trademarks of their respective holders.

• Screen layout may differ from that illustrated in this user guide. The information described in this user guide is subject to change without notice.

• All the functions described in this user guide may not be supported by all networks.

• We assume no responsibility for downloaded contents, information, etc. from the network.

• Occasionally, a few black or bright pixels may appear on the screen. Please note that this will not have any impact on any of the features or on performance.

According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from th e copyright owner to reproduc e, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Introduction 1

Powered by JBlend™ Copyright 1997-2004 Aplix Corporation. All rights reserved. JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.

Licensed by Inter Digital Technology Corporation under one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pending, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450: 4,811,420: 5,228,056: 5,420,896: 5,799,010: 5,166,951: 5,179,571 & 5,345,467

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are pending worldwide.

/Micro3D Edition™

is a registered trademark of HI Corporation

SD logo is a trademark.

Bluetooth is a trademark of the Bluetooth SIG, Inc.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sharp is under license. Other trademarks and trade names are those of their respective owners.

CP8 PATENT

2Introduction

This product is licensed under the MPEG-4 Visual Patent Portfolio License for the personal and non-commercial use of a consumer to (i) encode video in compliance with the MPEG-4 Video Standard (“MPEG-4 Video”) and/or (ii) decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a licensed video provider. No license is granted or implied for any other use. Additional information may be obtained from MPEG LA. See http://www.mpegla.com.

This product is licensed under the MPEG-4 Systems Patent Portfolio License for encoding in compliance with the MPEG-4 Systems Standard, except that an additional license and payment of royalties are necessary for encoding in connection with (i) data stored or replicated in physical media which is paid for on a title by title basis and/or (ii) data which is paid for on a title by title basis and is transmitted to an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. See http://www.mpegla.com for additional details.

Useful Functions and Services

Your phone offers you the following features:

• Video calls. You can talk while viewing each other on respective screens.

• 3D and colour Java™ games and applications with a graphic accelerator. You can also download various games and applications from Vodafone via the mobile Internet.

• Thin Film Transistor (TFT) colour LCD main display with images that are clearer and easier to view.

• A built-in digital camera for taking pictures and video clips.

• A message function for reading and creating SMS messages.

• MMS (Multimedia Messaging Services) for personalising your phone in various ways.

• A colour WAP browser for accessing information on the mobile Internet.

• Your own ringtones and ringvideos. You can use downloaded sound or video clip files as a ringtone or ring video clip.

• Playback of the downloaded sound and video clip files.

• A voice recorder function for recording and playing back voice clips.

•A Bluetooth

wireless technology interface for establishing contact and transmitting data with certain devices. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.

• An Infrared interface for data communication. You can transmit pictures, sounds and video clips to OBEX-enabled phones.

Introduction 3

• A data synchronisation function for updating Contacts List entries on the Internet.

• A schedule alarm for creating and sending schedule entries with alarm settings.

•A miniSD™* memory card slot that expands connectivity with a PC using the memory card.

* miniSD™ is a trade mark of SD Card Association.

4Introduction

Contents

Introduction ......................................................................1

Your Phone ........................................................................9

Getting Started ................................................................ 11

Inserting the SIM Card and the Battery .......................14

Removing the SIM Card and the Battery ..................... 15

Charging the Battery ................................................. 16

Inserting the Memory Card ........................................17

Removing the Memory Card ......................................18

Turning Your Phone On and Off .................................18

Keypad Lock ............................................................ 18

Display Indicators (Main Display) ...............................19

Display Indicators (External Display) ...........................20

Navigating Functions ......................................................21

Voice Call/Video Call Functions .....................................23

Making a Voice Call ..................................................23

Speed Dialling ..........................................................23

Redialling ................................................................. 24

Answering a Voice Call .............................................24

Incall Menu (Voice Call) .............................................24

Making a Video Call ..................................................27

Answering a Video Call ............................................. 27

Incall Menu (Video Call) ............................................. 28

Entering Characters ........................................................31

Changing the Input Language ...................................32

Changing the Input Mode ..........................................32

My Dictionary ...........................................................32

Using Templates .......................................................33

Using the Menu ...............................................................35

Top Menu ................................................................35

Shortcut Keys ...........................................................35

Contacts List ...................................................................37

Changing the Name Order .........................................37

Changing the List Displayed ......................................37

Selecting the Storage Memory ...................................37

Sorting the Contacts List Entries ................................38

Add New Contact ......................................................38

Viewing My Contact Details .......................................38

Copying Contacts List Entries between SIM Card and

Handset ...................................................................38

Finding a Name ........................................................39

Dialling from the Contacts List ...................................39

Editing Contacts List Entries ......................................39

Deleting Contacts List Entries ....................................39

Manage Category .....................................................40

Contact Groups ........................................................40

Memory Status .........................................................41

Speed Dial List .........................................................41

Sending a Contacts List Entry ....................................41

Receiving a Contacts List Entry ..................................42

Contents 5

Sending a Voice Clip Message or Video Clip Message

Using the Address in the Contacts List .......................42

Synchronising Contacts List Entries with Those on the

Internet ....................................................................42

Camera ............................................................................43

Taking Pictures .........................................................43

Recording Video Clips ...............................................44

Common Options Menu Indicators .............................44

Common Functions in the Photo and Video Camera

Modes .....................................................................45

Functions in the Photo Camera Mode .........................46

Functions in the Video Camera Mode .........................48

Messaging .......................................................................49

SMS ........................................................................49

MMS ........................................................................49

Email .......................................................................49

Creating a New Message ..........................................50

Messaging Settings ..................................................55

Vodafone live! .................................................................59

Navigating a WAP Page .............................................60

Music ...............................................................................63

Music Player ............................................................63

My Items ..........................................................................65

Pictures ...................................................................65

Sounds & Ringtones ..................................................66

Videos ......................................................................67

Other Documents .....................................................68

Common Option Menus ............................................68

Games & Applications .............................................. 70

Text Templates ........................................................ 71

Memory Status ........................................................ 71

Entertainment ................................................................. 73

Games & Applications .............................................. 73

Settings ................................................................... 75

TV & Video .............................................................. 77

Video Player ............................................................ 78

Organiser & Tools ........................................................... 81

Calendar ................................................................. 81

Alarms .................................................................... 83

Calculator ................................................................ 85

Voice Recorder ........................................................ 85

E-Book .................................................................... 86

Stopwatch ............................................................... 87

Tasks ...................................................................... 87

World Clock ............................................................. 89

Countdown Timer .................................................... 89

Expenses Memo ...................................................... 90

Phone Help .............................................................. 90

SIM Application .............................................................. 91

Settings ........................................................................... 93

Profiles .................................................................... 93

Setting the Display ................................................... 95

Sound Settings ........................................................ 98

Date & Time ............................................................ 98

Language Setting ..................................................... 99

Call Settings ............................................................ 99

6 Contents

Video Call Settings .................................................103

Security .................................................................104

Master Reset .........................................................106

Call Log .........................................................................107

Call Timers ............................................................107

Data Counter ..........................................................107

Call Costs .............................................................. 108

Connectivity .................................................................. 109

Bluetooth ...............................................................109

Infrared ..................................................................111

Network Settings ....................................................112

Flight Mode ............................................................ 112

Internet Settings .....................................................113

Memory Card .........................................................114

Connecting 703SH to Your PC ...................................... 117

System Requirements .............................................117

3G/GSM/GPRS Modem ...........................................117

Handset Manager ...................................................118

Software Installation ...............................................118

Note ......................................................................118

Troubleshooting ............................................................119

Safety Precautions and Conditions of Use ...................121

CONDITIONS OF USE ..............................................121

ENVIRONMENT .......................................................124

PRECAUTIONS CONCERNING VEHICLE USE ..............124

SAR ....................................................................... 124

Information on Proper Disposal ................................ 125

PRECAUTIONS FOR USE IN USA ..............................126

Specifications and Optional Accessories .................... 129

Specifications .........................................................129

Optional Accessories ..............................................129

Index ..............................................................................131

List of Menu Functions ................................................. 135

Contents 7

8 Contents

Your Phone

Please check the following carefully. Your phone should come complete with:

• 3G (UMTS)/GSM 900/1800/1900/GPRS phone

• Lithium Ion Battery

• Battery Cover

• AC Charger

• Stereo Earphone/Microphone

•User Guide

• Quick Start Guide

Your Phone 9

10 Your Phone

Getting Started

4 5

6 7

8 9

14 15

21 22

Getting Started 11

1. Earpiece

2. Navigation Keys (Arrow Keys):

a b c d Moves cursor to highlight a menu

item, etc.

Up/Down arrow keys: Displays Contacts List entries in

standby.

Left arrow key: Displays the message inbox in

standby.

Right arrow key: Displays the monthly or weekly

calendar in standby.

3. Centre Key: Displays Main menu in standby, and

executes functions.

4. Left Soft Key:

5. Send/Redial Key:

6. Shortcut Key:

7. Voice Mail Key:

Executes a function at the bottom left of the screen. Displays Messaging menu in standby.

Makes or accepts calls, displays the call logs in standby.

Press to open the shortcut menu to access the desired applications.

Press and hold to connect to the Voice Mail centre. (Depending on the SIM card.)

8. * /Shift Key:

Switches character case between four modes: Abc, ABC, 123 and abc on the text entry screen. Press to enter P, ?, – or * in standby. Press and hold in standby to lock the keypad.

9. Microphone

10. Sub Camera (Internal Camera)

11. Main Display

12. Right Soft Key:

Executes the function at the bottom right of the screen. Accesses to “Vodafone live!” by opening the browser in standby.

13. End/Power Key:

Ends a call and turns power on/off.

14. Clear/Back Key:

15. Multimedia Key:

Clears the characters before the cursor, returns to the previous screen, etc.

Opens the Media Player screen.

16. Keypad

12 Getting Started

17. #/Silent Key:

Switches symbol screens on the text entry screen. Press and hold to switch languages on the text entry screen. Press and hold in standby to switch Profiles settings between the mode most recently activated and Silent mode.

18. Camera (External Camera)

19. Built-in Aerial: Warning: Do not cover the top of the

phone with your hand when in use as this may interfere with the performance of the built-in aerial.

20. Battery Cover

21. Small Light: Used as a battery charge indicator.

22. External Display

23. Speaker

24. Memory Card Slot Cover

25. Camera Key: Displays the Main menu when

pressed in standby, then executes a highlighted function. Press and hold to activate the camera. Press during an incoming call to answer the call.

26. Handsfree Microphone Connector

27. Side Keys (V/W):

Moves the highlight up or down. Press in standby or during a call to increase or decrease the earpiece volume. Press during a call to launch “Messaging” or “Calculator” application.

28. Infrared Port: Sends and receives data via infrared.

External Connector

29.

: Used to connect either the charger or

a USB data cable.

Getting Started 13

Inserting the SIM Card and the Battery

1. Slide off the battery cover ( ).

3. Hold the battery so that the metal contacts of the battery are

facing down, slide the guides on the top of the battery into the battery slots ( ), and then insert it ( ).

2. Slide the SIM card holder to unlock ( ). Lift and put the SIM

card in ( ). Then, push and slide the SIM card holder back to lock ( ).

SIM card

14 Getting Started

4. Replace the battery cover.

Note

• Make sure that only 3V SIM cards are used.

• Make sure that the standard accessory battery (XN-1BT90) is

used.

Removing the SIM Card and the Battery

1. Ensure that the phone is turned off and that the charger and

other accessories are disconnected. Slide off the battery cover ().

3. Slide the SIM card holder to unlock ( ). Lift and remove the

SIM card ( ). Then, push and slide the SIM card holder back to lock ( ).

2. Lift the battery using the protruding edge and remove the

battery from the phone.

Battery Disposal

The device is battery-powered. In order to protect the environment, please read the following points concerning battery disposal:

• Take the used battery to your local waste depot, dealer or customer service centre for recycling.

• Do not expose the used battery to a naked flame, immerse in water or dispose with the household waste.

Getting Started 15

Charging the Battery

You must charge the battery for at least 135 minutes before using your phone for the first time.

Using the Charger

1. Open the cover of the external connector, connect the charger

to the external socket located at the bottom of the phone by pressing both sides indicated with arrows, and connect to an AC outlet.

The small light turns on. Standard charging time: Approx. 135 minutes

Note

• Charging time may vary depending on the state of the battery and

other conditions. (See “Battery” on page 121.)

To Disconnect the Charger

When charging is complete, the small light turns off.

1. Unplug the charger from the AC outlet, then unplug the

charger connector from the phone.

2. Close the cover.

Note

• Do not use any non-approved chargers as they may damage your

phone and invalidate any warranties, see “Battery” on page 121 for details.

To Charge Using the Cigarette Lighter Charger

The optional cigarette lighter charger supplies power for charging from the cigarette lighter socket of a car.

Battery Level Indicator

The current battery level is displayed in the upper right of the main and the external displays.

16 Getting Started

Low Battery during Use

When the battery is running low, an alarm will sound and “ ” is displayed on the main and external displays.

If you are using your phone and you hear the low battery alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it.

Battery Indicators Charge Level

Sufficiently charged

Charging recommended

Charging required

Empty

Inserting the Memory Card

1. Turn off the phone.

2. Open the memory card slot cover.

3. Insert the memory card all the way in.

4. Close the cover.

Note

• Make sure that the ph one is turned off before inserting the memory card.

• Be sure to insert the card in the correct direction and orientation.

• Do not open the memory card cover while the memory card is

being formatted or written to. The card may be damaged beyond use.

• Keep all memory cards out of the reach of small children.

Tip

• You see the following indicators when the memory card is in use:

: Appears when the card is inserted. : Appears when the card is damaged or unusable. : Appears when the card is being written or read. : Appears when the card is being formatted.

Getting Started 17

Removing the Memory Card

1. Open the memory card slot cover, remove the card, and close

the cover.

Note

• Make sure that the phone is turned off before removing the

memory card.

• Do not remove the memory card while the memory card is being

formatted or written to.

Turning Your Phone On and Off

To turn the power on or off, press and hold F for approximately 2 seconds.

To Enter the PIN Code

If activated you are asked to enter a PIN (Personal Identification Number) code and handset lock code after turning on your phone.

1. Enter your PIN code.

The PIN code is 4 to 8 digits.

2. Press .

Note

• If your PIN code is entered incorrectly three times in a row, the SIM

card is locked. See “Enabling/Disabling the PIN Code” on page 104.

• If the clock settings have not been made, the date and time entry

screen is displayed (p. 98).

To Copy All Contacts List Entries from the SIM Card

When you insert the SIM card into your phone for the first time and start the Contacts List application, you are asked whether you wish to copy Contacts List entries on the SIM card. Follow the on-screen instructions, or you can do it later using the Contacts List menu as follows:

→

“Contacts”

“Advanced” → “Copy All Entries”

1. Select “From SIM to Handset”.

Keypad Lock

You can lock the keypad to prevent it from being pressed accidentally.

Locking the Keypad

1. Press and hold P in standby.

To unlock, press and hold P.

Tip

• Emergency numbers (112, etc.) can be entered and dialled

regardless of the keypad lock.

18 Getting Started

Display Indicators (Main Display)

Indicator area

Centre key

01.01.05

Right soft key

12:00

Left soft key

1. / : Strength of received signal/Service out of range : 3G (UMTS)/GPRS

: GSM/GPRS

: Roaming outside network

2. : Flight mode

3. : Data exchange with external device

4. / : Connection to the server [established/ communicating]

5. : Memory card inserted

6. / : Voice call [incoming/in progress]

7. //: Video call communication mode enabled

8. : Diverts set to “Voice Calls” of “Always”

9. : Secure WAP page displayed

10. / / : Alerts [text message/multimedia message/Email]

11. /////: Connection status [USB cable/IrDA ON/IrDA exchanging information/ Bluetooth wireless setting [enabled (in standby or except in standby)/exchanging information/talking with the Bluetooth headset]]

12. / : Java™ application [executed (colour)/suspended (grey)]

Getting Started 19

13.(No display)/////: Current profile [Normal/Meeting/Activity/Car/ Headset/Silent]

14. ////: Silent/vibration setting [silent/increasing volume/ vibration enabled/silent and vibration enabled/ increasing volume and vibration enabled]

15. / / : Speaker mode [speaker phone/speaker activated/ microphone muted]

16. : Battery level

17. : Daily alarm enabled

18. / : Schedule entry enabled [with/without reminder alarm]

19. : Outbox contains unsent messages [text message/ multimedia/Email]

20. / / : WAP/OTA provisioning alerts [WAP alert/OTA provisioning alert/WAP and OTA provisioning alerts]

21. : Voicemail message alert

22. : Connection status [1st IrDA communication [enabled/exchanging information]]

23. : Function Lock enabled

24. : Keypad Lock enabled

25. /(blank): IrDA setting [enabled/disabled]

Display Indicators (External Display)

12:00

Status Indicators

1. : Battery level

2. //: Strength of received signal/Service out of range/ Flight mode

3. / : Missed events

4. : Voice call incoming

5. : Video call incoming

6. : Call in progress

7. : Alerts [messages/Delivery Report]

8. : WAP Push service

9. : Daily alarm enabled

20 Getting Started

Navigating Functions

All applications are accessed from the Main menu. To open the Main menu, press the centre key ( ) in standby.

To launch applications, you will need to highlight menu items, and make selections. To select a menu item (indicated in quotation marks), move the cursor using a, b, c and d, and press to select.

In certain procedures, you will need to press one of the soft keys (indicated in square brackets), which are displayed at the bottom left and right of the screen. Press the corresponding soft key (A or C).

To return to the previous screen, press the right soft key if it displays

Back. To close the Main menu, press the right soft key if it displays Exit.

Each section in this user guide starts with a list of items you will need to select in order (indicated in italics) before performing the procedures shown. Select each item to reveal the next set of items that you have to select. Open subsection items after opening those listed in the main section.

Example:

→

“Contacts”

“Contacts List” → “Add New Contact”

Navigating Functions 21

22 Navigating Functions

Voice Call/Video Call Functions

Making a Voice Call

1. Enter the area code and the phone number you wish to dial

and press D to dial.

If you enter the wrong number, press U to delete the number to the left of the cursor.

Emergency Calls

1. Enter 112 (international emergency number) using the keypad

and press D to dial.

Note

• Emergency calls may not be able to be made on all mobile phone

networks when ce rtain network services and/or phone features are in use. Contact your network operator for more information.

• This emergency number can normally be used to make an

emergency call in any country, with or without a SIM card inserted, if a 3G (UMTS)/GSM network is within range.

International Calls

1. Press and hold Q until a + (international dialling prefix) sign

is displayed.

2. Enter the country code, followed by the area code (without the

leading zero) and the phone number, and press D to dial.

Adding an Entered Phone Number to the Contacts List

1. After entering a phone number, press [Options] and select

“Save Number”.

For details on creating a new entry, see “Add New Contact” on page 38.

Showing or Hiding My Phone Number on the Display of the Called Party

1. After entering a phone number, press [Options] and select

“Show My ID” or “Hide My ID”.

Speed Dialling

Up to 8 phone numbers from the Contacts List memory (Handset and SIM) can be assigned to speed dials. You can call the numbers using the digit keys (G to O). The phone number of the Voice mail centre is assigned to G.

For details on setting the speed dial list, see “Speed Dial List” on page 41.

1. To dial a number using the speed dial, press and hold any of

the digit keys (G to O).

The phone number saved in the speed dial list is dialled.

Voice Call/Video Call Functions 23

Redialling

You can redial numbers in the call log. Select from specific categories or “All Calls”. Specific categories contain up to 10 numbers and the “All Calls” list contains up to 30.

1. Press D in standby.

2. Select the category from “All Calls”, “Dialled Numbers”,

“Missed Calls” or “Received Calls”.

To switch logs, press c or d.

3. Highlight the phone number you wish to call.

4. Press D to redial the call.

Answering a Voice Call

When an incoming call is detected, the phone rings.

1. Press D or [Answer] to answer the call.

Or press any key except F, , U and [Busy] when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile of each mode (p. 95).

Tip

• If you have subscrib ed to the Calling Line Identification (CLI) service

and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Contacts List, the caller’s name and phone number are displayed on the screen.

• If the number is a restricted number, the display shows “W ithheld”.

• When you receive a call from the person whose picture is

registered in the Contacts List, the picture, name and phone number are displayed.

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call you do not

wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a busy tone to

the caller.

Incall Menu (Voice Call)

Your phone has additional functions available while a call is in progress.

Adjusting the Earpiece Volume

You can adjust the earpiece volume (and handsfree volume, if connected) from five levels.

1. Press V or W to display the Earpiece Volume screen.

2. Press V (or a/d) to increase the volume of the call or press

W (or b/c) to decrease the volume.

3. Press when the volume is set to the desired level.

24 Voice Call/Video Call Functions

Turning the Speaker On and Off

You can talk via the loudspeaker on the clamshell cover of the phone when it is on.

1. During a call, press [Options] and select “Loudspeaker On”.

Putting a Call on Hold

This function allows you to manage two calls at the same time. If you wish to make another call while you are talking to someone, you can put the current call on hold to call someone else.

To Make Another Call during a Call

1. During a call, press [Options] and select “Hold”.

The current call is put on hold.

2. Press [Options] and select “Dial New Number”.

3. Enter the phone number you wish to make another call to, then

press D.

Tip

• You can also make another call by entering the phone number

during a call instead of step 1. The current call is automatically put on hold.

Accessing SMS/MMS Menu during a Call

1. During a call, press [Options] and select “Send Message”.

The following options are available: “Create New” to make an SMS and MMS, or “Inbox”, “Sent Messages” or “Drafts” to access these folders. For details on SMS, see “SMS” and “MMS” on page 49.

Call Waiting

This service notifies you of another incoming call while you have a call in progress.

1. During a call, press [Options] and select “Hold & Answer” to

answer the second call.

The first call is put on hold and you can now talk to the second caller.

2. Press [Options] and select “Release & Answer” to end the

current call and return to the held call.

Note

• You need to set “Call Waiting” to “On” if you use the Call Waiting

service (p. 101).

• Call Waiting service may not be available on all networks. Contact

your network operator for more information.

• If you do not wish to answer the second call, press [Options] and

select “Busy” in step 1. If “Reject” is selected, the log of the second call is saved as a missed call.

Conference Call

Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.

Voice Call/Video Call Functions 25

To Make a Conference Call

You must have one active call and one held call.

1. During a call, press [Options] and select “Multi Party”.

2. Select “Conference All” to join the conference call.

3. Press F to end the conference call.

Note

• The conference call service may not be available on all networks.

Contact your network operator for more information.

• You have more options for the Conference call in step 2:

• To put all participants on hold, select “Hold All”.

• To put all participants except the current call on hold, select

“Private”.

• To end the call with all participants, select “End Active Call(s)”

or “End Held Call(s)”.

• To reject adding more participants to the current party, press

[Options] and select “Reject”, or you can send the busy tone by selecting “Busy”.

To Add New Participants to the Conference Call

1. Press [Options] and select “Dial New Number”.

2. Enter the number you wish to include in the conference call

and press D to dial.

3. Press [Options] and select “Multi Party”.

4. Select “Conference All” to join the conference call.

If you wish to add other participants, repeat steps 1 to 4.

To End the Call with a Conference Call Participant

1. During a conference call, highlight the person that you wish to

disconnect from the conference call.

2. Press [Options] and select “End Active Call(s)” or “End Held

Call(s)”.

To Have a Private Conversation with One of the Participants

If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.

1. During a conference call, select the person that you wish to

talk to.

2. Press [Options] and select “Multi Party”.

3. Select “Private”.

4. Once you have finished the private conversation, press

[Options] and select “Multi Party”.

5. Select “Conference All” to return to the conference call.

Muting the Microphone

1. During a call, press [Options] and select “Mute Microphone”.

2. Select “On”.

To unmute the microphone, select “Off”.

26 Voice Call/Video Call Functions

Making a Video Call

Note

• Use this function with only the video call enabled phones.

• Make sure that the battery is fully charged and the signal length is

greater before using this function.

• Turn the loudspeaker on or use a switch-equipped earphone

microphone or handsfree kit so that you can talk while looking at the video call screen on the main display.

Status Indicators

1. Sub screen for your image

2. Elapsed time (hour:minute:second)

3. Main screen for the calling party’s screen

4. Calling party’s name

5. Calling party’s phone number

Making a Video Call

1. Enter the area code and the phone number you wish to dial

and press [Options] and select “Video Call” to dial.

If you enter the wrong number, press U to delete the number to the left of the cursor. When the line is connected, the image of the called party is displayed upper on the screen, and yours lower left.

Tip

• If the called party’s phone is not video call enabled, you can press

F and enter the phone number again to make a voice call.

• When the call ends, the last call cost is displayed.

Answering a Video Call

When an incoming call is detected, the phone rings.

1. Press D to answer the call by video or A [Answer] to

answer the voice only.

Tip

• When the call is ended, the call cost is displayed.

• If you have subscribed to the Calling Line Identification (CLI) service

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call you do not

wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a busy tone to

the caller of an incoming call letting them know that you cannot answer the call.

Voice Call/Video Call Functions 27

Incall Menu (Video Call)

Muting the Microphone

1. During a video call, press [Options] and select “Mute

Microphone”.

2. Select “On”.

To unmute the microphone, select “Off”.

Swapping Images

You can swap images between the main and sub screens.

1. During a video call, press [Options] and select “Swap Images”.

Changing the Image of Yourself

1. During a video call, press [Options] and select “Camera

Picture”.

2. Select from “Int. Camera”, “Camera” or “Alternative Image”.

“Int. Camera”: The image through the sub camera is

displayed and sent to the party.

“Camera”: The image through the camera is

displayed and sent to the party.

“Alternative Image”: The camera is turned off and the

image selected in “Alternative Image” of “Video Call Settings” is used.

Turning the Speaker On and Off

You can talk via the loudspeaker on the clamshell cover of the phone when it is on.

1. During a video call, press [Options] and select “Loudspeaker

On”.

Note

• In a high-noise environment, you may not be able to continue a

call, or make a clear call. We recommend that you use the Stereo Earphone/Microphone Unit.

• With this option, you may not be able to continue a call without

interruption if you increase the earpiece volume. We recommend that you decrease the earpiece volume or use the Stereo Earphone/Microphone Unit.

Video Call Settings

To Change the Quality of the Incoming Image

You can adjust the quality of the called party’s image.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Incoming Format”.

3. Select “Normal”, “Quality Prio.” or “Frame Rate Prio.”.

“Normal”: The standard quality is used. “Quality Prio.”: The quality of the picture takes

precedence over the frame rate.

“Frame Rate Prio.”: The frame rate takes precedence over

the quality.

28 Voice Call/Video Call Functions

To Turn the Backlight On or Off

You can turn on the backlight of your screen.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Backlight”.

3. Select from “On”, “As Normal Setting” or “Off”.

When “On” is selected, the backlight will always be on during a video call. When “As Normal Setting” is selected, the backlight will time out depending on the Backlight setting (p. 97).

To Adjust the Video Exposure

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Exposure”.

3. Press a (Light) or b (Dark).

Voice Call/Video Call Functions 29

30 Voice Call/Video Call Functions

Entering Characters

When entering characters to create Contacts List entries, text messages or multimedia messages, etc., press the corresponding keys.

In multi-tap input method, press each key until the desired character is displayed. For example, press H once for the letter A or twice for the letter B.

Table of Characters

Pressing each key scrolls characters in the following o rder. The order varies depending on the language selected.

English Mode

Key

G H

I J K L M N

Upper Case

Characters

. (full-stop) , (comma) - (hyphen) ? ! ’ (apostrophe) @ :1

ABC2 abc2 2

DEF3 def3 3

GHI4 ghi4 4

JKL5 jkl5 5

MNO6 mno6 6

PQRS7 pqrs7 7

TUV8 tuv8 8

Lower Case

Characters

Numeric

Key

O Q

G-O

: Press and hold to shift betwee n multi-tap and T9

: Press and hold to display the Input Language

Upper Case

Characters

WXYZ9 wxyz9 9

(space) + = < > € £ $ ¥ % & 0 0

Switches character case between four modes: Abc, ABC, 123 and abc.

.,?!:;-+#∗ @' " ( )_&€£$ %/ ˜<>§=\ | ¥

¿¡^[ ]{ }¤ÅÄ

Æ еджаЗЙийм

СсЦШцштЯЬь

ù ∆ΦΓΛΩΠΨΣΘ

Ξ (space) ↵

:QPress and hold to enter 0 - 9 numbers.

mode.

screen.

Lower Case

Characters

Numeric

Entering Characters 31

Changing the Input Language

1. On the text entry screen, press [Options] and select “Input

Language”.

2. Select the desired language.

Symbols and Punctuation

1. On the text entry screen, press [Options] and select “Add

Symbol”.

2. Select the desired symbol.

Changing the Input Mode

T9 Text Input

T9 text input method is a shortcut to enter text easily and quickly.

1. On the text entry screen, press and hold P to enter T9 mode.

2. Press [Options] and select “Input Mode”.

3. Select the input mode (Abc, ABC, abc, 123).

4. Press each key once for any letter you require on that key.

To enter the word “How”, press J L O.

5. If the word shown isn’t the one you want, press a or b until

you highlight the correct one.

6. Press to select the word.

Note

• If the correct word is not shown in step 5, enter the correct word

again after switching to the multi-tap input method.

Tip

• If you press Q instead of step 6, a space is inserted next to the

selected word.

32 Entering Characters

My Dictionary

You can create your own word list for T9 text input.

1. On the text entry screen in T9 mode, press [Options] and select

“My Dictionary”.

2. Select “Add New Word” and enter a new word.

Editing a word in the list

1. On the text entry screen in T9 mode, press [Options] and select

“My Dictionary”.

2. Highlight the desired word.

3. Press [Options] and select “Edit”.

4. Modify the word.

Using Templates

You can use the phrases registered in Text Templates when entering characters.

For details on creating the text template, see “Adding Phrases to Text Templates” on page 71.

1. On the text entry screen, move the cursor to the point you wish

to insert the template.

2. Press [Options] and select “Advanced”.

3. Select “Insert Template”.

4. Select the desired text template.

Copying, Cutting and Pasting Text

1. On the text entry screen, press [Options] and select

“Advanced”.

2. Select “Copy” or “Cut”.

3. Move the cursor to the first letter to be copied or to be cut, then

press .

4. Move the cursor to the last letter to highlight the area, then

press .

5. Move the cursor to the point you wish to paste the letters.

6. Press [Options] and select “Advanced”.

7. Select “Paste”.

Entering Characters 33

34 Entering Characters

Using the Menu

Top Menu

Camera

Select Exit

1. Press in standby.

The Main menu is displayed.

2. Press a, b, c or d to highlight the desired menu, then

press to access the function.

For details on the menu options, see the table on pages 135 and

136.

Shortcut Keys

You can access menus by pressing and digit keys for the corresponding number on the Main menu. For numbers 10 to 12, press and P (10), Q (11) or R (12). See the following table for reference.

Shortcuts are listed in the headings of this user guide. For example: “M 6-2”.

Examples: To Access “Videos” Sub Menu (M 6-4 ) Using

Shortcut Keys

Press L J.

To Access “Totals” Sub Menu (M 7-10-2) Using Shortcut Keys

Press M P H.

To Access “Vibration” Sub Menu (M 12-3-4) Using Shortcut Keys

Press R I J.

Note

• The shortcut keys work for the first three menu levels only.

Using the Menu 35

36 Using the Menu

Contacts List

You can store the phone numbers and Email addresses of your friends, family and colleagues in the Contacts List.

Your phone can store up to 500 entries. In a Contacts List, you can save the following items:

Items Saved in the Handset Memory

First Name up to 16 characters Last Name up to 16 characters Telephone Number up to 3 phone numbers (up to 32 digits

Email Address up to 3 Email addresses (up to 128

Category up to 16 categories Street & Number up to 64 characters City up to 64 characters State/Province up to 64 characters Postcode up to 20 characters Country up to 32 characters Note up to 256 characters Birthday (date) Picture (file name) Assign Tone/Video (file name) Secret (On or Off)

(M 8-1)

each)

characters each)

Items Saved in the SIM Memory

Name up to 16 characters Telephone Number up to 2 phone numbers (up to 32 digits

Email Address up to 80 characters Category up to 16 categories (depending on the SIM

Changing the Name Order

“Contacts” → “Settings” → “Name Order”

1. Select “First-Last Name” or “Last-First Name”.

Changing the List Displayed

“Contacts” → “Settings” → “Contacts Location”

1. Select “Handset Memory” or “SIM Memory”.

Selecting the Storage Memory

“Contacts” → “Settings” → “Save New Contact”

1. Select from “To Handset”, “To SIM” or “Choose before

Saving”.

each)

card)

(M 8-7-1)

(M 8-7-2)

(M 8-7-3)

Contacts List 37

Tip

• “Choose before Saving” prompts you to choose the memory every

time you save a new entry.

Sorting the Contacts List Entries

You can change the listing order of the Contacts List entries between by alphabetical order or by category.

“Contacts”

→

“Settings” → “Sort Contacts”

(M 8-7-4)

1. Select “By Alphabet” or “By Category”.

Add New Contact

You can choose either the phone or SIM card memory locations to store the new entry. For switching locations, see “Selecting the Storage Memory”.

The amount of phone numbers that you can store to the SIM card is dependent on its capacity. Contact your network operator for details.

→

“Contacts”

If you select the “Choose before Saving” option for the memory to be used, the selection is between “To Handset” and “To SIM”.

1. Select the field you wish to fill in, and enter the relevant

information.

2. Press [Save] when finished.

Tip

• To create an entry, at least one field must be filled (“First Name”,

“Last Name”, “Telephone Number” or “Email Address” for the handset memory; “Name”, “Telephone Number” or “Email Address” for the SIM memory).

“Contacts List” → “Add New Contact”

Viewing My Contact Details

You can register and edit your own contact as other Contacts List entries.

“Contacts”

→

“My Contact Details”

(M 8-4)

Copying Contacts List Entries between SIM Card and Handset

“Contacts” → “Advanced” → “Copy All Entries”

1. Select “From SIM to Handset” or “From Handset to SIM”.

Note

• When you insert the SIM card into your phone for the first time and

start the Contacts List application, the confirmation screen is displayed automatically, asking you if you wish to copy or not. The number of Contacts List entries to be copied varies depending on the SIM capacity.

• If the memory space is not enough to save all entries, you cannot

complete copying.

(M 8-8-1)

38 Contacts List

Finding a Name

“Contacts” → “Contacts List”

1. Enter the first few letters of the name.

Search results are displayed in alphabetical order.

Tip

• You can select the Contacts location from “Handset” or “SIM”

before searching.

Dialling from the Contacts List

“Contacts” → “Contacts List”

1. Highlight the desired entry and press D.

Tip

• If more than on e phone number is register ed for the entry, highlight

the desired phone number after step 1 and press D.

• You can also dial from the details screen of the Contacts List. On

the details screen, select the desired phone number and press D.

Editing Contacts List Entries

“Contacts” → “Contacts List”

1. Highlight the entry you wish to edit.

2. Press [Options] and select “Edit”.

3. Modify the information.

To add a thumbnail to entries, select “Picture” and then “Assign Picture”. Select the desired picture.

To assign a ringtone or a ring video clip to each contacts list entry, select “Assign Tone/Video” and then “For Voice Call”, “For Video Call” or “For New Message”. Select “Assign Tone” or “Assign Video”, and then “Preset Sounds” or “My Sounds” when you select “Assign Tone”. Select the desired tone or video clip.

4. Press [Save] when finished.

Note

• If you delete a picture in the handset memory, the corresponding

thumbnail is also deleted.

Deleting Contacts List Entries

Deleting All Contact Entries

“Contacts”

→

“Advanced” → “Delete All Entries”

1. Select “Handset Entries” or “SIM Entries”.

2. Enter your handset code.

The default handset code is “9999”. For details on changing the handset code, see “To Change the Handset Code” on page 105.

Deleting a Contact Entry

“Contacts”

→

“Contacts List”

1. Highlight the desired entry.

2. Press [Options] and select “Delete”.

(M 8-8-3)

Contacts List 39

Manage Category

Different ringtones can be set for each category. If you do not change a category ringtone, the ringtone assigned in the Profiles menu is used.

“Contacts”

→

(M 8-2)

“Manage Category”

1. Highlight the desired category.

2. Press [Options] and select “Assign Tone/Video”.

3. Select from “For Voice Call”, “For Video Call” or “For New

Message”.

4. Select “Assign Tone” or “Assign Video”.

When selecting “Assign Video”, go to step 6.

5. Select “Preset Sounds” or “My Sounds”.

6. Select the desired tone or video clip.

For details on selecting a ringtone or a ring video clip, see “Assigning a Ringtone” on page 93 or “Assigning a Ring Video Clip File” on page 94.

Note

• You can only edit category names in the SIM card. You cannot edit

the ringtone or ring video settings.

Editing the Category Name

You can edit category names to be assigned to the Contacts List entries. First, change the Contacts List displayed (p. 37).

→

“Contacts”

“Manage Category”

1. Highlight the desired category name.

2. Press [Options] and select “Edit Name”.

3. Modify the name.

Contact Groups

You can create a mailing list to send the same message to a group of recipients at once.

Creating a New Mailing List

“Contacts”

(M 8-5)

→

“Contact Groups” → “Add New Group”

1. Enter the group name.

The new group name is displayed following the last group on the Group List screen.

Adding Recipients to a Group

Up to xx recipients can be registered in each list.

→

“Contacts”

“Contact Groups”

1. Select the desired group name.

2. Select “Assign New Entry”.

3. Select the desired entry.

The detailed screen is displayed.

4. Press .

40 Contacts List

Tip

• If you modify the entry assigned in the group, you need to re-

assign it to the group. Press [Options] and select “Re-assign Entry” in step 2.

• To remove an entry from the group, highlight the entry and select

“Remove Entry” in step 2.

• To remove a group, highlight a group name and press [Options]

and then select “Delete” in step 2.

Sending a Message Using a Mailing List

→

“Contacts”

“Contact Groups”

1. Highlight the desired group name.

2. Press [Options] and select “Create Message” or “Create

Email”.

For further procedures, see “Creating a New Message” on page 50.

Memory Status

This function helps you to check the memory used in the Contacts List.

“Contacts”

Speed Dial List

You can set a maximum of 8 phone numbers in the Speed Dial list (p. 23).

Setting Contacts List Entries in the Speed Dial List

“Contacts”

(M 8-8-2)

→

“Advanced” → “Memory Status”

(M 8-3)

→

“Speed Dial List”

1. Select the desired entry.

2. Highlight the desired phone number.

3. Press [Options] and select “Add to Speed Dial”.

4. Select the desired location.

Tip

• The nine digit keys correspond to list numbers.

To Edit the Speed Dial List

→

“Contacts”

“Speed Dial List”

1. Highlight the entry you wish to edit.

2. Press [Options] and select “Re-Assign” (or “Assign”).

Sending a Contacts List Entry

“Contacts” → “Contacts List”

1. Highlight the desired entry.

2. Press [Options] and select “Send Contact”.

3. Select “As Message”, “Via Bluetooth” or “Via Infrared”.

For “As Message”

For details, see “MMS” on page 49.

For “Via Bluetooth”

For details, see “Bluetooth” on page 109.

For “Via Infrared”

For details, see “Infrared” on page 111.

Contacts List 41

Receiving a Contacts List Entry

When the phone receives a Contacts List entry, a confirmation message is displayed in standby.

1. Press [Yes].

The received entry is saved in the Contacts List. Press [No] to reject.

Tip

• For details on making Infrared or Bluetooth wireless settings, see

“Connectivity” on page 109.

Sending a Voice Clip Message or Video Clip Message Using the Address in the Contacts List

“Contacts” → “Contacts List”

1. Select the desired entry including the phone number or Email

address you wish to use.

2. Press [Options] and select “Create Message”.

3. Select “Voice Message” or “Video Message”.

For further procedures, see “Creating a New Message” on page 50.

Synchronising Contacts List Entries with Those on the Internet

The data synchr onisation function is a network s ervice and allows you to save your Contacts List entries in the handset memory on the Internet server. The data in the SIM card will not be saved. Subscribe to a synchronisation service by contacting your network service centre.

(M 8-6)

Synchronising the Contacts List

→

“Contacts”

“Synchronise”

1. Select the desired synchronisation profile.

2. Select “Normal” for synchronisation.

Note

• To make or restore a backup file, select “Backup” or “Restore”,

and press [Yes].

Synchronisation Settings

→

“Contacts”

“Profile Name”: Synchronisation profile name (Unique

“Server Name”: Server address “User ID”: User ID for authentication “Password”: Password for authentication “Proxy”: Proxy setting for synchronisation

Note

• In normal operations, you do not need to change the settings.

• Internet settings have already been made in your phone depending

on your network operator. You may have restrictions on viewing, deleting, copying or modifying the settings. Contact your network operator for details.

“Synchronise” → “Sync Settings”

name)

42 Contacts List

Camera

Your phone has a built-in digital camera that allows you to take pictures and video clips wherever you are. This section starts with basic functions and operational procedures to take, save and send pictures and video clips, followed by common and unique functions to camera and video modes.

(M 5)

Taking Pictures

“Camera”

1. Press to take the picture.

The shutter sounds and the still image of the taken picture is displayed.

2. Press [Save].

The taken picture is saved in My Items. To cancel, press [Cancel]. To send the taken picture, press in step 2 and select “As Message” or “As Postcard” from the send option. (The Postcard service is not available with some service providers. Contact your service provider for more information.)

Note

• When the video camera is launched, press [Options] and select

“Go to Photo Camera”, or press c.

• When you try to send the picture that has too large a file size, the

picture size is resized for the message. The original sized picture is saved in My Items.

Taking a Self-Portrait

You can take a self-portrait while looking at the main display.

“Camera”

1. Press [Options] and select “Switch to Int. Camera”.

2. Press to take the picture.

3. Press [Save].

To return to the external camera, press [Options] and select “Switch to Ext. Camera”. You can also switch the camera by pressing P in the viewfinder mode. The taken picture is saved in My Items.

Camera 43

Recording Video Clips

You can record a video clip with your phone.

Recording Video Clips

“Camera”

The preview is displayed through the screen.

1. Press .

2. To stop recording, press .

To view the preview before saving, select “Preview”.

3. Select “Save”.

The video clip is saved in My Items. To send the video clip, press in step 3 and select “Save and Send”. Then select the desired way you wish to send. For further procedures, see “Creating a New Message” on page 50.

Note

• You can only send video clips when “For Message” is selected for

the recording time. For details, see “Selecting the Recording Size” on page 48.

Common Options Menu Indicators

On-screen indicators are provided for various camera mode settings.

1. Press the camera key.

The Options menu is displayed graphically as shown.

2. Press V or W to highlight the desired option and then press

the camera key to make the selection.

44 Camera

Common Functions in the Photo and Video Camera Modes

Using the Digital Zoom Function

To Adjust the Zooming Ratio

1. In the viewfinder mode, press a or b.

Once the phone has returned to the standby screen, the zoom settings return to default.

Adjusting the Exposure

“Camera”

1. Press a (Bright) or b (Dark).

Once the phone has returned to the standby screen, the brightness settings return to default.

Using the Self-Timer

“Camera”

1. Select “On” or “Off”.

Switching between the Photo and Video Camera Modes

You can switch between the camera and video camera modes by pressing c or d.

Select the appropriate option.

“Camera” “Camera”

→

[Options] → “Exposure”

: (Bright → Normal → Dark)

→

[Options] → “Modes” → “Self-timer”

“ ” is displayed on the screen when you select “On”.

→

[Options] → “Go to Video Camera”

→

[Options] → “Go to Photo Camera”

Selecting the Picture or Video Quality

Select the appropriate option.

→

“Camera” “Camera”

[Options] → “Picture Quality”

→

[Options] → “Video Quality”

1. Select the desired picture or video quality.

: Super Fine :Fine :Normal

Note

• The better quality you select, the larger file size is needed.

Selecting the Storage Memory

Select the appropriate option.

→

“Camera” Pictures”

“Camera”

[Options] → “Settings” → “Save New

→

[Options] → “Settings” → “Save New Videos”

1. Select the desired location from “To Handset Memory”, “To

Memory Card” or “Choose before Saving”.

Note

• If you select “Choose before Saving”, select the desired location

every time you save.

Camera 45

Focus Setting

“Camera”

→

[Options] → “Modes” → “Focus”

1. Select the desired option.

:Normal : Manual Focus

Auto Save

You can set the phone to save pictures and video clips automatically.

→

“Camera”

[Options] → “Settings” → “Auto Save”

1. Select “On” or “Off”.

Using the Help Function

“Camera”

Common Shortcut Keys

If multiple options exist, they switch each time you press each following key.

→

[Options] → “Help”

G Max Zoom/Min Zoom H Exposure I Focus Setting J Save New Pictures to Handset/to SD Card/Choose

before Saving

K Picture Size/Record Size L Scene Select (or Microphone On/Off) M Picture Quality (or Video Quality) N Self-Timer On/Off P Change External Camera/Internal Camera Q Full Viewfinder/Normal Viewfinder

Functions in the Photo Camera Mode

Selecting the Picture Size

You can select the size of pictures. All taken pictures are saved in the JPEG format.

→

“Camera”

1. Select the desired size.

Picture Sizes: 960 × 1280 dots/768 × 1024 dots/

Selecting the Scene

You can select the appropriate mode by scene when you take the picture.

“Camera”

1. Select the desired scene.

The following four modes are available: “Automatic”: Automatically adjusted to surroundings “Night”: Suited for night photography “Sports”: Suited for moving objects “Characters”: Suited for high-contrast subjects such as text

[Options] → “Picture Size”

480 × 640 dots/240 × 320 dots/ 120 × 160 dots

→

[Options] → “Modes” → “Scene”

46 Camera

Continuous Shoot

You can take continuous shoots in various options.

→

“Camera”

[Options] → “Modes” → “Continuous Shoot”

1. Select the desired mode.

The following continuous shoot modes are available: “Off”: The continuous shoots are cancelled. “4 Pictures”/“9 Pictures”:

“Overlapped”: Overlaps continuous pictures into one

Note

• When you select “Manual” to take continuous pictures, press

manually in the desired speed.

• When the Timer and Continuous Shoot functions are

simultaneously set, “ ” (for “4 Pictures”, for example) is displayed instead.

Takes 4 or 9 pictures continuously. After selecting this mode, select from five types of speed or “Manual”.

picture and makes an afterimage. After selecting this mode, select “Fast” or “Normal”.

Selecting a Frame

You can select the frame from preset patterns or My Pictures.

→

“Camera”

[Options] → “Modes” → “Add Frame”

1. Select “Preset Frames” or “My Pictures”.

2. Select the desired frame.

The selected frame is confirmed on the display.

3. Press .

Note

• Images larger than 240 dots [W]

Using the Full Screen

You can display the preview on the full screen without the soft key area and indicator area.

→

“Camera”

[Options] → “Settings”

320 dots [H] cannot be used.

1. Select “Full Viewfinder”.

To return to the normal viewfinder, select “Normal Viewfinder”.

Camera 47

Selecting the Shutter Sound

“Camera”

→

[Options] → “Settings” → “Shutter Sound”

1. Select the desired shutter sound from 3 preset patterns.

Note

• Continuous Shoot uses the specialised shutter sound that cannot

be changed from the above settings.

• The shutter sound remains active even when “Ringer Volume”

(p. 93) is set to “Silent” to prevent unauthorised use.

Functions in the Video Camera Mode

Selecting the Recording Size

“Camera”

1. Select “For Message” or “Extended Video”.

2. Select “QCIF” or “SubQCIF” video format for “For Message”

Note

• If you select “For Message” for the recording size, the file size is

• “Save and Send” is not displayed after recording in the Extended

→

[Options] → “Record Size”

For Message: Limits the size to send a message

Extended Video: Less than 30 minutes (depending on the

and “QCIF”, “SubQCIF” or “QVGA(MPEG4)” format for “Extended Video”.

limited depending on the service provider. Therefore, the quality is also limited for the setting.

Video mode.

depending on service providers.

memory).

Setting the Picture Size

You can change the picture size during playback/recording.

→

“Camera”

[Options] → “Advanced” → “Picture Size”

1. Select “Large(QCIF)” or “Small(SubQCIF)”.

Recording Video Clips with the Sound

To record a video clip with the sound, the microphone needs to be activated.

→

“Camera”

[Options] → “Settings” → “Microphone”

1. Select “On” or “Off”.

Note

• The microphone is already turned on in the default setting. Select

“Off” to record a video clip without the sound.

• The file size of a video clip can be reduced if the sound is not

recorded.

Video Encoding

→

“Camera”

[Options] → “Settings” → “Video Encode”

1. Select the appropriate format.

48 Camera

Messaging

Your phone allows you to send and receive text, multimedia and Email, and receive WAP alerts as well.

(M 4)

SMS

SMS allows you to send text messages up to 765 characters long. If you send a mess age more than 160 characters, it is split into several segments.

MMS

MMS allows you to send and receive multimedia messages of up to 300 KB with images, sound, or video clips attached.

Email allows you to send messages of up to 300 KB.

Note

• Some MMS functions may not always be available depending on

your network. Contact your network operator for more information.

• Maximum message size varies depending on the settings by the

network operator.

1. Recipient field

2. Message field

3. Send indicator

4. Attachment indicators (from left: picture, sound, video clip,

others)

Messaging 49

Creating a New Message

(SMS/MMS)

→

“Create Message” → “Message”

A (Email) A

→

“Create Message” → “Email”

(M 4-1)

1. Enter the message.

2. Select the address field.

3. Enter or select the phone number from the Contacts List.

(MMS)

Enter or select the Email address or phone number from the Contacts List.

(Email)

Enter or select the Email address from the Contacts List.

• To add multiple Email addresses or phone numbers, highlight the recipient field, press [Options], select “ Edit Recipient”, then select “Add Contact”. Enter or select the Email address or phone number from the existing Contacts List.

• To change the recipient types, press [Options], select “Edit Recipients” then select “Change to TO”, “Change to CC” or “Change to BCC”.

• To add a subject, press [Options] and select “Add Subject”.

4. Highlight “Send”, then press to send.

After the message is sent, the message is moved to the Sent box.

Tip

• To send the same message to a group of recipients, select “Select

Group” in step 3, then select the desired group name. For details on creating a mailing list, see “Creating a New Mailing List” on page 40.

To Add a Slide Show

1. In step 2 in “Creating a New Message”, press [Options] and

select “Add Slide”.

If you wish to add more slides, select “Add Slide Before” or “Add Slide After”.

2. Enter the message.

If you wish to set the duration of each slide, press [Options] and select “Slide Duration”, then select the desired duration.

Tip

• You can create messages up to 300 KB. Each slide can contain

one picture and/or one sound file or video clip.

To Remove or Replace Attachments

1. In step 2 in “Creating a New Message”, press [Options] and

select the corresponding remove option for each attachment.

50 Messaging

To Attach My Items Data

1. In step 2 in “Creating a New Message” on page 50, press

[Options] and select from “Pictures”, “Sounds” or “Videos”.

2. Select the desired file.

If you wish to take new pictures, record sounds or video clips, select “Take Picture”, “Record Voice” or “Record Video”.

• For attached pictures, select the appropriate resize option, as the maximum message size for sending varies depending on the network operator.

To Attach a Contacts List Entry

1. In step 2 in “Creating a New Message” on page 50, press

[Options] and select “Attach Contact”.

2. Select the desired entry.

If you wish to select your own Contacts List entry, select “My Contact Details”.

3. Select the desired field.

The selected information is entered.

To Attach a Schedule Entry

1. In step 2 in “Creating a New Message” on page 50, press

[Options] and select “Attach Appointment”.

2. Select the desired day including a schedule entry you wish to

add.

3. Select the desired schedule entry.

Using the Sending Options

You can use the message sending options for each type of message.

1. Press [Options] and select “Advanced”.

• “Message type” (“SMS”, “MMS”): Sets the transportation type.

• “Read Report” (“Yes”, “No”) (SMS/MMS): Enables or disables Read Report when the recipient is required to inform the sender that the message has been read.

• “Delivery Report” (“Yes”, “No”) (SMS/MMS): Enables or disables Delivery Report when the message is successfully sent to the recipient.

• “Expiry Time” (“Never delete”, “30 minutes”, “1 hour”, “6 hours”, “1 day”, “1 week”) (SMS/MMS): Sets Expiry Time for a message to be saved in the server.

• “Priority” (“High”, “Normal”, “Low”): Prioritises composed messages.

• “Delivery Time” (“No delay”, “30 minutes”, “1 hour”, “6 hours”, “1 day”, “1 week”) (MMS): Sets the time the message is delivered after the Send key is pressed.

2. Highlight “Send”, then press to send.

After the message is sent, the message is moved to the Sent box.

Messaging 51

Note

• The current message size displayed while you are creating the

message is an approximation.

• If a message cannot be sent for some reason, the message stays

in the Outbox and the “ ” is displayed in standby.

Tip

• To save the message without sending, press [Options] and select

“Save to Drafts” in step 2 in “Creating a New Message” on page 50.

• You can send the following items attached to multimedia

messages. Details are given in the following sections.

• My Items data

• Contacts List entry

• File (Schedule entry created by Calendar, Contacts List entry),

etc.

• You can use the template option to help you compose messages.

For details on using this option, see “Using Templates” on page 33.

Sending a Message in the Drafts Box

→

“Drafts”

1. Select the desired tab, SMS/MMS or Email.

2. Press [Options] and select “Edit & Send”.

3. Modify the message, if necessary.

4. Select “Send”.

5. Highlight “Send”, then press to send.

Sending a Voice Clip Message or Video Clip Message

You can record a new voice or video clip when creating a new message.

Select the appropriate option.

→

“Create Message” → “Voice Message”

→

“Create Message” → “Video Message”

1. Press to start recording.

2. Press to stop recording.

3. Select “Accept” to attach to the new message.

The file is saved in the corresponding folder in My Items. For further procedures, see “Creating a New Message” on page 50.

Reading MMS

Messages you receive are saved in the Inbox.

→

“Inbox”

1. Select the message you wish to view.

52 Messaging

Storing the Phone Number of a Sender in the Contacts List

→

“Inbox”

1. Highlight the message from which you wish to store the phone

number or Email address.

2. Press [Options] and select “Save address”.

The new Contacts List entry screen including the phone number is displayed. For details on creating a new Contacts List entry, see “Add New Contact” on page 38.

Calling the Phone Number of a Sender Embedded in the Message

→

“Inbox”

1. Highlight the message including the phone number you wish

to dial.

2. Press [Options] and select “Call Sender”.

Downloading a Single MMS

→

“Inbox”

1. Highlight the message alert ( ) you wish to download.

2. Press [Options] and select “Download”.

Tip

• You can download multiple messages at the same time. See the

next section.

Downloading Multiple MMS

→

“Inbox”

1. Press [Options] and select “Advanced”.

2. Select “Multiple Select”.

3. Select the desired message alert using the “Select” or “Select

All” option.

4. Select “Download”.

The selected messages are downloaded at the same time.

Replying to a Message or to All Addresses

→

“Inbox”

1. Highlight the message the sender of which you wish to reply

to.

2. Press [Options] and select “Reply” or “Reply all”.

3. Enter the message.

4. Press “Send”.

5. Highlight “Send” then press to send.

Messaging 53

Forwarding a Message

→

“Inbox”

1. Highlight the message you wish to forward.

2. Press [Options] and select “Forward”.

3. Perform steps 2 to 4 in “Creating a New Message” on

page 50.

Remote Forward

You can transfer your Email messages saved in the mail server directly to other recipients.

→

“Inbox”

1. Highlight the message alert ( ) you wish to transfer.

2. Press [Options] and select “Forward”.

3. Perform steps 2 to 4 in “Creating a New Message” on

page 50.

Sorting the Messages in the List

→

“Inbox”

1. Press [Options] and select “Advanced”.

2. Select “Sort”.

3. Select the desired sort type.

Locking or Unlocking the Messages

→

“Inbox”

1. Highlight the message you wish to lock or unlock.

2. Press [Options] and select “Advanced”.

3. Select “Lock” or “Unlock”.

Sending a Picture File with Postcard

Your phone allows you to send multimedia messages to a Vodafone specific Postcard service centre that prints the picture and mails it to the recipient’s home address specified in the MMS message. (Your phone is initially provided with the address of a Vodafone specific Postcard service centre, and its address cannot be changed.)

Note

• This service is not available with some service providers. Please

contact your service provider for more information.

To Create a New Postcard

→

“Create Message” → “Postcard” → “Saved Pictures”

(M 4-1-4)

1. Select a picture you wish to send.

If you wish to take new pictures, select “Take Picture”.

2. Enter your message.

3. Enter or select the recipient.

See the note below for details.

• “Name” (mandatory): Name of the recipient for a postcard up to 50 characters

54 Messaging

• “Additional Information” (optional): Additional information of the recipient up to 50 characters

• “Street & Number” (mandatory): Street and number up to 50 characters

• “City” (mandatory): City up to 50 characters

• “Postal Code” (optional): Postal code up to 20 characters

• “State/Province” (optional): State, province, and region up to 50 characters

• “Country” (optional): Country up to 20 characters

4. Press [Options] and select “Send Postcard”.

Note

• The items “Name”, “Street & Number” and “City” are necessary to

complete sending Postcards.

• The items displayed differ according to the service. Please contact

your service provi der for more information. The item “Country” may not be displayed, so you cannot send Postcards overseas from your phone.

• Files in Animation GIF format cannot be used for the Postcard

service.

• The picture quality of Postcards varies depending on the picture

size.

Messaging Settings

General Settings

→

“Messaging Settings” → “General Settings”

(M 4-10)

(M 4-10-1)

1. Select the item you wish to set up.

•“Home Download”: Controls message download timing inside your network area.

“Always download”: Downloads messages immediately

“Always defer”: Defers message download.

• “Roam. Download”: Controls message download timing when roaming outside of your network.

“Always download”: Downloads messages immediately

“Always defer”: Defers message download.

•“Delivery Report”: Enables or disables Delivery Report request.

• “Read Report”: Enables or disables Read Report request.

from the server.

Messaging 55

• “Expiry Time”: This indicates the number of days and hours for which a message you send may remain undelivered to the message recipient. During this period, the message service centre will continually try to deliver the message to the recipient.

• “Delivery Rep. Allow”: Enables or disables Delivery Rep. Allow when receiving a message, which applies to the Delivery Report function.

• “Read Report Allow”: Enables or disables Read Report Allow when the recipient is required to inform the sender that the message has been read.

• “Edit Signature”: Opens the screen to enter the signature.

• “Reply History”: Disables or enables whether the message will be added to your reply message or not.

• “Speed Mail List”: xxx

• “Auto Delete”: Deletes the oldest message automatically, when the Inbox, Sent Messages or both (Inbox and Sent Messages) is full.

SMS Settings

→

(M 4-10-2)

“Messaging Settings” → “SMS Settings”

1. Select the item you wish to set up.

• “Message Centre”: Enter the message centre number.

If you wish to enter a country code for a message to an international number, press and hold Q until a + sign is displayed.

• “Message Format”: Select the message format to be used when creating a new message.

•“Reply Path”: Accepts or rejects the same reply path with the send path when receiving the reply message for your message.

•“Optimisation”: When set “On” (default), double-byte characters such as European characters with an accent are converted into single-byte characters and sent.

When “Off”, double-byte characters are sent as displayed. Please note that you may be charged double for double-byte

characters sent in an SMS when Optimisation is set “Off”.

56 Messaging

MMS Settings

→

(M 4-10-3)

“Messaging Settings” → “MMS Settings”

1. Select the item you wish to set up.

• “MMS Accounts”: xxx

• “Slide Duration”: Sets the duration of the slide.

• “Max Message Size”: Defines the maximum size of messages that are downloaded.

• “Creation Mode”: When set to “Free”, you can attach files of any format to the mail. When set to “Restricted”, only certain formats can be attached.

Email Settings

→

(M 4-10-4)

“Messaging Settings” → “Email Settings”

1. Select the item you wish to set up.

•“Email Accounts”: xxx

• “Download Interval”: Sets the download interval.

• “Max Message Size”: Defines the maximum size of messages that are downloaded.

Cell Broadcasts

You can receive cell broadcast messages or general messages such as weather foreca sts and traffic reports. This inform ation is broadcast to subscribers in certain network areas.

This function may not be available on all mobile phone networks. Contact your network operator for more information.

To Enable/Disable Cell Broadcasts

→

A “Switch On/Off”

(M 4-10-5)

“Messaging Settings” → “Cell Broadcasts” →

1. Select “On” or “Off”.

To Read Cell Broadcast Messages

→

“Messaging Settings” → “Cell Broadcasts” → “Read

Messages”

1. Select the desired subject.

2. Scroll the screen to read the message.

3. Press [Back].

Messaging 57

To Set Languages for Cell Broadcast Messages

→

“Messaging Settings” → “Cell Broadcasts” →

→

“Settings”

The current language is displayed.

“Language”

1. Press .

2. Check to select the desired language by pressing .

3. Press [Save].

To Subscribe to Cell Broadcasts

Select the page of the cell broadcast message that you want.

→

“Messaging Settings” → “Cell Broadcasts” →

A “Settings”

→

“Set Info Subjects”

→

[Options]

1. Select “Add/Remove”.

2. Select the desired page.

3. Press [Back].

Tip

• If the desired page is not in the list that appears in step 2, select

“Create Subject” in step 1, then enter the subject code to add a page. For details on the subject code, contact your service provider.

(M 4-10-6)

Area Info

The Area Info is the message information that operators send to subscribers in certain areas. When you receive Area Info, the message (area code) is displayed in standby.

To Enable/Disable Area Info

→

“Messaging Settings” → “Area Info”

1. Select “On” or “Off”.

Note

• This function may not be available on all mobile phone networks.

Contact your network operator for more information.

• If Area Info is set to “On”, the standby time will decrease.

58 Messaging

Vodafone live!

Your phone is already configured to access Vodafone live! and the mobile internet*.

Vodafone live! is a new mobile internet portal which is your gateway to a new world of information, games, music and services.

Because your phone uses 3G (UMTS), it has a system that is much faster than previous ways of getting mobile information. Also, the connection is ‘always on’ which means there is no need to wait for dialling up. You only have to pay for the data you send or receive, not how long you’re connected.

* If you have problems getting connected, please phone Vodafone

Customer Support.

Your phone contains a WAP browser used for surfing on the Mobile Internet, where you can get a lot of useful information. Normally, pages are designed for a mobile phone.

Your phone is already setup to Vodafone site for WAP/MMS Settings.

(M 2)

Top Menu

→

“Vodafone live!”

The Vodafone live! service page is displayed.

“Vodafone live!”

The URL entry screen is displayed, allowing you to jump to the site.

“Vodafone live!”

See page 60.

“Vodafone live!”

WAP Push alerts are displayed.

“Vodafone live!”

The saved screenshots are displayed.

“Vodafone live!”

The history of pages you have recently browsed is displayed.

“ Vodafone live!”

→

“Enter URL”

→

“Bookmarks”

→

“Alert Inbox”

→

“My Saved Page”

→

“History”

Vodafone live! 59

Navigating a WAP Page

• a b c d:

Move the highlights around in the screen.

• : Executes the option displayed in the lower centre of the screen.

• A: Launches the browser option menu.

• C: Selects an action displayed in the lower right of the screen. Used to access “Vodafone live!” by opening the browser.

• F (short press): Exits the browser.

(press and hold):

Turns off the phone.

Editing Bookmarks

“Vodafone live!”

(M 2-3)

→

“Bookmarks”

1. Select the desired URL, and press [Options].

You can edit the list of Bookmarks by the following options: “Select”: Selects a bookmark. “Details”: Displays detailed information of the

“Send page”: Sends the URL address to recipients. “New”: Creates new folders or bookmarks. “Rename”: Renames bookmarks. “Edit URL”: Edits URL address of the bookmark. “Move”: Moves Bookmarks to another location. “Delete”: Deletes bookmarks. “Delete All”: Deletes all bookmarks.

WAP page.

60 Vodafone live!

Browser Settings

“Vodafone live!”

“Font Size”: Sets the size of the browsing font. “Scroll Step”: Sets the speed of scrolling. “Send Referrer”: Enables or disables the notification of

“Cookies”: Adjusts the setting of cookies. “Downloads”: Categorises downloading data from

“Security”: Adjusts the security prompt level. “WAP Push”: Sets whether you need confirmation

“Download to”: Sets the download location.

(M 2-7)

→

“Browser Settings”

the referrer.

the images/sounds/objects.

for push message.

The Browser Options

You can use various options of the WAP browser.

→

[Options]

“Select”: Selects a WAP page. “Home”: Goes to the homepage. “Bookmarks”: (see page 60.) “Mark Page”: Marks the selected WAP page. “Save items”: Saves items from WAP pages. “Go to URL”: Goes to the WAP page that you enter

“Access History”: Shows the history where you have

“Forward”: Goes to the next page of the pages

“Reload Page”: Reloads the WAP page again to get

“Advanced”: Displays the advanced menus. “Exit”: Exits the browser.

the URL address.

browsed.

displayed.

new information.

Vodafone live! 61

The Advanced Options

→

[Options] → “Advanced”

“My Saved Page”: The saved screenshots are displayed. “Save this page”: Saves the WAP page as the local file. “Send page”: Sends the WAP page data. “Details”: Shows deta iled information of the WAP

“Browser Data”: Edits the browser data. You can clear

“Search This Page”: Searches specific words in the WAP

“Alert Inbox”: Displays WAP Push alerts. “Copy Text”: Copies the text on the web page. “Settings”: Displays the Settings menus. “Restart browser”: Restarts the browser. “About”: Displays the browser information.

page.

the cache/cookies/history.

page.

62 Vodafone live!

Music

(M 3)

Music Player

Music Player can play MP3, AAC and AAC+ format sound files. While playing back sound files in the background, you can use other menus.

Playing Back Sound Files

→

“Music”

1. Select “Handset Memory” or “Memory Card”.

2. Select “All Music” or the desired playlist.

3. Select the desired file.

Note

• You are asked whether or not to play sounds when the Silent mode

• To play the last played file, select “Last Played Music”. “Currently

Tip

• You can return to the Main menu screen while playing back the file

• You can create your playlist listing only the desired files (p. 64).

“My Music”

The tab switches the file displayed between the handset memory and the memory card.

To pause playback, press . To stop playback press [Back].

is activated.

Playing” is displayed when the file is being played back.

in the background.

• You can select the playback pattern in step 1. Press [Options] and

select “Playback Pattern”. “Normal”: Plays back all files in the selected folder once

and stops playback. “Repeat”: Continues to play back the selected file. “Repeat All”: Plays back all files in the selected folder. “Random”: Plays back files in the selected folder at

random.

• You can control the Music Player by using the following keys:

a/ b : Increases or decreases the volume. b: (press and hold): Mute d: Jumps to the next file. c: Returns to the top portion of the current file. d (press and hold): Fast-forwards. c (press and hold): Rewinds. F: Plays back the file in the background.

Music 63

Searching a File to Be Played Back

“Music”

→

“My Music”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select “All Music” or the desired playlist.

3. Press [Options] and select “Search”.

4. Enter the first few letters of the title.

Search results are displayed in alphabetical order and the matching file is highlighted.

Adding a File to the Playlist

You can create a playlist registering desired files.

→

“Music”

“My Music”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to add to the playlist.

3. Press [Options] and select “Add to Playlist”.

The playlists are displayed. For details on adding a playlist, see “Adding a New Playlist” on page 64.

4. Select the desired folder.

5. Press .

The file highlighted in step 2 is saved. To delete the playlist, highlight the playlist and press [Options]. Then select “Delete Playlist”.

Adding a New Playlist

→

“Music”

“My Music”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Press [Options] and select “Add New Playlist”.

3. Enter the desired playlist name.

4. Press .

Downloading the Music Files

“Music”

→

“Download Music”

The music file download site is displayed. For details, see “Downloading Sound Files” on page 67.

(M 3-3)

64 Music

My Items

My Items contains several types of picture, sound and video clip data. Also included in My Items are frequently used text message phrases and accessed WAP pages (addresses) which you can use. You can also transmit picture, sound and video clip data via infrared or

Bluetooth

Pictures

Pictures that are taken by a digital camera or images that are downloaded from mobile Internet sites can be managed. You can register pictures in the following formats: JPEG, PNG, WBMP and GIF.

Viewing Pictures

“My Items”

(M 6)

wireless technology to OBEX-enabled phones.

(M 6-1)

→

“Pictures”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select the file you wish to view.

The selected picture is displayed. To display the list from the memory card press d. To go back to the handset memory press c.

Using Images as Wallpaper

→

“My Items”

“Pictures”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to use as wallpaper.

3. Press [Options] and select “Set as Wallpaper”.

Saving an Image to Contacts List Entries

You can use this option only for pictures saved in the handset memory.

→

“My Items”

“Pictures”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to add to Contacts List.

3. Press [Options] and select “Add to Contact”.

To overwrite, select the data you wish to save. To save as a new entry, select “As New Contact”. For details on entering a name, see “Add New Contact” on page

38.

My Items 65

Editing Pictures

“My Items”

→

“Pictures”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to edit.

3. Press [Options] and select “Picture Editor”.

4. Select the desired option.

Note

• “Picture Editor” may not be available depending on the original

picture and copyright issued.

Adjusting the Size

You can adjust the picture to an appropriate size depending on the scene.

→

“My Items”

“Pictures”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to adjust the size of.

3. Press [Options] and select “Resize”.

4. Select the desired option.

Note

• “Resize” may not be available depending on the original picture

and copyright issued.

Tip

• For other option menus, see page 68.

Downloading Picture Files

→

“My Items”

“Pictures” → “Get new”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card. The picture file download site is displayed.

Sounds & Ringtones

The downloaded sound files and the AMR data recorded by Voice Recorder are managed in Sounds & Ringtones. The default ringtones are not contained within Sounds & Ringtones. Only the sound files you can play back with the phone are stored in Sounds & Ringtones.

Playing Back Sound Files

→

“My Items”

“Sounds & Ringtones”

(M 6-2)

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select the file you wish to play back.

To stop playback, press .

Note

• Playback may not be available for some sound files.

66 My Items

Using the Sound Files as a Ringtone

“My Items”

→

“Sounds & Ringtones”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the file you wish to use as a ringtone.

3. Press [Options] and select “Set as Ringtone”.

Note

• AMR format music files cannot be used for ringtones.

Tip

• For other option menus, see page 68.

Downloading Sound Files

→

“My Items”

“Sounds & Ringtones” → “Get new”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card. The sound file download site is displayed.

(M 6-4)

Videos

Video clips that are recorded by a video camera or video clips that are downloaded from mobile Internet sites can be managed.

Playing Back Video Clip Files

→

“My Items”

“Videos”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select the file you wish to play back.

3. Press .

To resume, press again. To stop playback, press [Back]. To display the list from the memory card press d. To go back to the handset memory press c.

Using a Video Clip as a Ring Video

You can set your video clip to play back when the phone rings.

→

“My Items”

“Videos”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Highlight the desired video clip.

3. Press [Options] and select “Set as Ring Video”.

Tip

• For other option menus, see page 68.

Downloading Video Clip Files

→

“My Items”

“Videos” → “Get new”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card. The video clip file download site is displayed.

My Items 67

Other Documents

Some types of files excluding picture files are stored in the Other Documents folder of the phone. You can edit and use these files as My Items data.

Opening the Document File

“My Items”

→

(M 6-6)

“Other Documents”

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select the desired file.

Tip

• For other option menus, see page 68.

Common Option Menus

Activating Files with Copyright Protection (DRM)

Some pictures, sound files, and video clips have a digital copy protection program, which is called DRM (Digital Rights Management). You need to activate the digital licence permission to open the files. Files protected with DRM are displayed with .

Select the appropriate option.

→

“My Items” “My Items” “My Items”

1. Highlight the file you wish to activate.

2. Press [Options] and select “Activate”.

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

Note

• Some pictures with DRM may not open even when an attempt is

made to activate it.

• Pictures with DRM cannot be sent attached to a message, with the

exception of Separate Delivery files.

Sending My Items Data

Select the appropriate option.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the desired file.

2. Press [Options] and select “Send”.

3. Select “As Message”, “Via Bluetooth” or “Via Infrared”.

For details on creating a message, see “” on page 49. For details on For details on Infrared settings, see “Infrared” on page 111.

Note

• Pictures/Sounds/Video clips protected by copyright cannot be sent

attached to a message, with the exception of Separate Delivery files.

• When pairing, you need to enter your passcode when establishing

contact with a Bluetooth wirele ss technology enabled dev ice for the first time.

Bluetooth

settings, see “Bluetooth” on page 109.

68 My Items

• When you send a picture file, select “As Postcard” in step 3. The

Postcard service is not available with some providers. Contact your service provider for more information.

Receiving My Items Data

When the phone receives My Items data, a confirmation message is displayed in standby.

1. Press [Yes].

The received data is saved in the corresponding My Items folder.

Tip

• For details on Infrared or Bluetooth wireless settings, see

“Connectivity” on page 109.

Using My Items Data

You can copy, move, sort, rename, and delete the saved My Items data.

Select the appropriate option.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the desired file.

2. Press [Options] and select “Advanced”.

3. Select the desired option.

“Move”: Moves the files to another folder. Select the

“Copy”: Copies the file. Select the desired folder to

desired folder to move.

copy.

“Create Folder”: Creates a new folder. “Sort”: Sorts the file. Select the desired files to sort.

To Rename the File

Select the appropriate option.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the desired file.

2. Press [Options] and select “Rename”.

Note

• The following procedure applies when the entries other than “Get

new” are highlighted.

1. Select the desired order.

To Delete the File

“My Items” “My Items” “My Items” “My Items”

→

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the desired file.

2. Press [Options] and select “Delete”.

My Items 69

To See the My Items Details

Select the appropriate option.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the file desired to view the detail information.

2. Press [Options] and select “Details”.

Uploading My Items Data

You can upload your sound or video clip files to the Media Album.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures”

→

“Sounds & Ringtones”

→

“Videos”

→

“Other Documents”

1. Highlight the file you wish to upload.

2. Press [Options] and select “Send”.

3. Select “To Album”.

Note

• This service is not available with some service providers. Please

contact your service provider for more information.

• Sound and video clip files protected with a copyright cannot be

uploaded, with the exception of Separate Delivery files.

Selecting Multiple Files

You can select more than one item from My Items for moving, copying and deleting.

Note

• The following procedure applies when the entries other than “Get

new” are highlighted.

Select the appropriate option.

→

“My Items” “My Items” “My Items” “My Items”

“Pictures” → [Options]

→

“Sounds & Ringtones” → [Options]

→

“Videos” → [Options]

→

“Other Documents” → [Options]

1. Select “Advanced”.

2. Select “Multiple Select”.

3. Check to select the desired file names.

4. Press [Options] and select the desired menu.

Tip

• To remove the check, select the file again or select “Unselect” in

step 4.

• If you wish to select all files, select “Select All” in step 3. To

unselect all, select “Unselect All”. Then press [Options] to select the desired menu.

Games & Applications

For details on Vodafone specific applications, see “Games & Applications” in “Entertainment” on page 73.

(M 6-3)

70 My Items

Text Templates

You can register up to 50 text templates for use in text messages and multimedia messages. A maximum of 256 characters can be used for a single text template.

Adding Phrases to Text Templates

“My Items”

(M 6-5)

→

“Text Templates” → “Add New Template”

1. Enter the text and press .

Editing Text Templates

“My Items”

→

“Text Templates”

1. Highlight the text template you wish to edit.

2. Press [Options] and select “Edit”.

To view the text template, press [Options] and select “View”. To delete the text template, press [Options] and select “Delete”.

3. Modify the text and press .

Sending Text Templates

“My Items”

→

“Text Templates”

1. Highlight the text template you wish to send.

2. Press [Options] and select “Send Template”.

Memory Status

This function helps you to check the memory status of the handset memory or memory card. Memory status covers the following.

Handset Memory: Applications, Pictures, Videos, Sounds and

Memory Card: Pictures, Videos, Sounds and Others

“My Items”

(M 6-7)

Others

→

“Memory Status”

1. Select “Handset Memory” or “Memory Card”.

My Items 71

72 My Items

Entertainment

Games & Applications

Using Applications

Various kinds of Vodafone specific applications can be used on this phone. To use applications, download the applications via the mobile Internet. Some applications offer the ability to connect to a network either within a game or a network based application.

Note

• Applications may be both localised (no connectivity) and network

based (using the mobile Internet to update information/play games). The network may charge you more for using networkbased applications. Please contact your service provider for more information.

Downloading Applications

“Entertainment” “My Games & Applications”

(M 1)

(M 1-1)

→

“Games & Applications” →

→

“More Games”

1. Select the desired application.

Before downloading the application you are asked to confirm what you are about to receive. After checking the information on the confirmation screen, the application can be downloaded.

2. Press to start downloading.

3. Press when finished.

Note

• User authentication may be required before downloading the

application on some information screens.

Executing Applications

→

“My Items”

“Games & Applications”

1. Select the title of the application you wish to execute.

The selected application is executed. When using network connection type applications, connection to the network can be selected.

2. To end the application, press F and select “End”.

To Set a Screensaver Application

“My Items”

→

“Games & Applications”

1. Highlight the desired screensaver application.

2. Press .

3. Press [Yes] to set a screensaver.

Entertainment 73

Setting Permission

You can set permission for selected Java™ applications.

→

“Entertainment” “My Games & Applications”

“Games & Applications” →

1. Highlight the desired Java™ application.

2. Press [Options] and select “Permission”.

3. Select one of the following options:

“Phone Call”: Sets permission to make voice calls. “Network Access”: Sets permission to access the network. “Messaging”: Sets permission to perform MMS and

“Auto Run”: Sets permission to perform the Auto Run

“Local Connection”: Sets permission to connect to local

“Read User Data”: Sets permission to read user data, such

“Write User Data”: Sets permission to write entries in your

“Use Multimedia”: Sets permission to use the multimedia

“Location Access”: Sets permission to update the

“Reset”: Clears all the above settings.

SMS messaging.

function.

devices.

as Contacts List entries, mailbox (Inbox) and My Items data.

phone, such as Contacts List entries, mailbox (Inbox) and My Items data.

recording.

positioning function.

4. Select one of the following options:

“Per Session”: The confirmation message is not

displayed until you exit the application, while execution of the API of the specified function group is authorised.

“Every Time”: The confirmation message is displayed

every time the API of the specified function group is executed.

“First Time”: The confirmation message is not

displayed until the application is deleted or you change the settings, while execution of the API of the specified function group is authorised.

“Not Permit”: Execution of the API of the specified

function group is not authorised.

74 Entertainment

Setting as a Screensaver for the Main Display

“Entertainment” & Applications”

→

“Games & Applications” → “My Games

→

[Options] → “Set as Screensaver”

1. Highlight the file you wish to use as a screensaver.

2. Press [Options] and select “Set as Screensaver”.

Viewing Application Information

You can check the information of Java™ applications.

“Entertainment” & Applications”

→

“Games & Applications” → “My Games

1. Highlight the desired Java™ application.

2. Press [Options] and select “Application Details”.

Deleting an Application

You can delete an application from the handset memory.

→

“Entertainment” & Applications”

“Games & Applications” → “My Games

1. Highlight the desired Java™ application.

2. Press [Options] and select “Delete”.

Settings

Application Volume

You can set the volume of the application such as the sound effect to one of the five levels or silent. When “Ringer Volume” (p. 93) is set to “Silent”, this setup has priority.

“Entertainment” “Application Volume”

(M 1-1-2)

→

“Games & Applications” → “Settings” →

1. Press a (or d) to increase the volume or press b (or c) to

decrease the volume and then press .

Backlight

“Entertainment” “Backlight”

→

“Games & Applications” → “Settings” →

→

“Switch On/Off”

1. Select from “Always On”, “Always Off” or “Default Settings”.

“Always On”: Lit while the application is operated. “Always Off”: Unlit while the application is operated even

“Default Settings”: Works with the main backlight setting

if a key is pressed.

(p. 97).

Entertainment 75

To Set the Blinking Operation

This setting enables the backlight to be controlled by the application. If set to “Off”, the backlight cannot be turned on from the application.

→

“Entertainment” “Backlight”

“Games & Applications” → “Settings” →

→

“Blink”

1. Select “On” or “Off”.

Vibration

When the vibrator is set in the application, you can choose whether the operation is enabled or disabled.

When a SMAF file is specified in the application, you can operate the vibrator set in the SMAF file.

Note

• SMAF (Synthetic music Mobile Application Format) is a music data

format for mobile phones.

→

“Entertainment” “Vibration”

“Games & Applications” → “Settings” →

1. Select from “On”, “On & Link to Sound” or “Off”.

When you set “On & Link to Sound”, the vibration is synchronised with the sound of SMAF file in the application.

Calls & Alarms

You can set the priority of incoming calls and alarms while an application is operating.

→

“Entertainment” “Calls & Alarms”

“Games & Applications” → “Settings” →

1. Select “Voice Call”, “Video Call”, “Incoming Message” or

“Alarm”.

2. Select the desired method.

• “Call Priority”, “Message Priority” or “Alarm Priority”: The application is suspended automatically, and you can receive a call or a message, or the alarm will sound. After finishing the call or the message, or the alarm ends, the suspend indicator ( ) is displayed letting you know there is a suspended application.

• “Call Notice”, “Message Notice” or “Alarm Notice”: The marquee (character scrolls) is displayed on the first line of the screen while the application continues. If you press D, the application is suspended, and you can receive a call or a message. After finishing the call or the message, the suspend indicator ( ) is displayed letting you know there is a suspended application.

76 Entertainment

Screensavers

You can download screensaver applications for the standby screen and set the time period for the screensaver to activate.

→

“Entertainment” “Screensavers”

“Games & Applications” → “Settings” →

→

“Switch On/Off”

1. Select “On” or “Off”.

To Set the Activation Time

“Entertainment” “Screensavers” → “Activation Time”

→

“Games & Applications” → “Setting s” →

1. Enter the activation time in two digits using the keypad.

To Set the Suspend Time

“Entertainment” “Screensavers”

→

“Games & Applications” → “Setting s” →

→

“Suspend Time”

1. Set the desired time period from “15 min.” to “6 hours”.

Java™ Information

“Entertainment” Information”

The information about the licences belonging to Java™ is displayed.

(M 1-1-3)

→

“Games & Applications” → “Java™

To Play Back the Files in the Handset Memory or Memory Card

→

“Entertainment”

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

Tip

• For details on using the Video Player, see “Video Player” on

page 78.

• You can control the Video Player by using the following keys:

a/b: Increases or decreases the volume. C: Jumps to the next file. A: Returns to the top portion of the current file. C (press and hold): Fast-forwards. A (press and hold): Rewinds.

TV & Video

Playing Back the TV Live Video Clip or Video Clip Files

To Play Back the Last File

“Entertainment”

(M 1-2)

(M 1-2-1)

→

“TV & Video” → “Last Played Video”

Entertainment 77

Streaming

You can play back video clip files while downloading them from the mobile network.

You can also register the address of the Web site as a bookmark.

→

“Entertainment”

“TV & Video” → “Mobile TV”

1. Select from “Last Played Streaming”, “Enter URL”,

“Favourites” or “Access Log”.

“Last Played Streaming”:

“Enter URL”: Enter the desired addres s of the Web site. The

“Favourites”: The address of the Web site is registered. “Access Log”: Shows the logs of the Web site you accessed.

Shows the last streaming file.

browser opens, starts downloading and plays back.

From the log you can start streaming.

Video Player

Playing Back Video Clip Files

“Entertainment”

→

1. Select “Handset Memory” or “Memory Card”.

The tab switches the file displayed between the handset memory and the memory card.

2. Select the desired file.

To pause playback, press . To stop playback, press [Back].

(M 1-2-3)

“TV & Video” → “My Videos”

Searching a File to Be Played Back

→

“Entertainment”

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

2. Select “All Music” or the desired playlist.

3. Press [Options] and select “Search”.

4. Enter the first few letters of the title.

Search results are displayed in alphabetical order and the matching file is highlighted.

Adding a File to the Playlist

You can create a playlist registering desired files.

→

“Entertainment”

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

2. Highlight the file you wish to add to the playlist.

3. Press [Options] and select “Add to Playlist”.

The playlists are displayed. For details on creating a playlist, see “Adding a New Playlist”.

4. Select the desired folder.

5. Press .

The file highlighted in step 2 is saved. To delete files from the playlist, highlight the playlist and press [Options]. Then select “Delete from Playlist”.

78 Entertainment

Adding a New Playlist

“Entertainment”

→

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

2. Press [Options] and select “Open Video”.

3. Press [Options] and select “Add New Playlist”.

4. Enter the desired playlist name.

5. Press .

Editing the Video Clip File

“Entertainment”

→

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

2. Select the file you wish to edit.

3. Press [Options] and select “Edit”.

4. Select the desired option.

“Crop”: Select the desired area to be cropped. “Subtitle”: Create a subtitle to add to the file.

Settings

You can select a play mode for “Playback Pattern”, “Backlight” and “Display Size” when playing back video clip files.

→

“Entertainment”

“TV & Video” → “My Videos”

1. Select “Handset Memory” or “Memory Card”.

2. Select the file for which you wish to adjust the play mode.

3. Press [Options] and select “Settings”.

4. Select from “Playback Pattern”, “Backlight” or “Display Size”.

5. Select from the following:

• “Playback Pattern”: “Repeat”: Continues playback in the selected

“Repeat All”: Plays back all files in the selected folder. “Random”: Plays back files in the selected folder at

“Normal”: Plays back all files in the selected folder

folder.

random.

once and stops playback.

Entertainment 79

• “Backlight”: “Always On”: Lit while the file is played back. “Always Off”: Unlit while the file is played back even if

“Normal Settings”: Works with the main backlight setting

• “Display Size”: “Original Size”: Displays the file in its original size. “Enlarge”: Displays the file in an enlarged size. “Full Screen”: Displays the file on the full screen.

(M 1-2-4)

SD VIDEO

“Entertainment”

a key is pressed.

(p. 97).

→

“TV & Video” → “SD VIDEO”

80 Entertainment

Organiser & Tools

Calendar

Calendar allows you to easily schedule appointments or events, which are associated with the date and time.

These entries can also be sent via Infrared or Bluetooth wireless technology to a PC to share the same schedules. When you exchange entries with other devices, the date and time displayed may be different to that of the original data depending on the data format of the receiving device.

Creating a New Entry

“Organiser & Tools”

(M 7-1)

(M 7)

→

“Calendar”

1. Select the desired day to which you want to add an event.

2. Select “Add New Entry”.

3. Enter the subject.

4. Enter the location.

5. Select the desired category.

6. Enter the start date and then enter the start time.

7. Select the duration.

8. Select the reminder time or date.

9. Press [Save].

Note

• If the date and time settings have not been made, the date and

time entry screen is displayed (p. 98).

• The reminder wi ll not sound when “Ringer Volume” (p. 93) is set to

“Silent”.

To Change the Type of the Reminder Tone or Video

1. On the New Entry screen, select “Reminder”.

2. Select “Assign Tone/Video”.

3. Select “Assign Tone” and then select “Preset Sounds” or “My

Sounds”, or select “Assign Video”.

4. Select the desired sound or video clip file.

For details on selecting a tone, see “Assigning a Ringtone” on page 93.

To Change the Duration of the Reminder Tone or Video

1. On the New Entry screen, select “Reminder”.

2. Select “Duration”.

3. Select the time period.

When you select “Other” in step 3, you can enter the desired time in two digits using the keypad.

To Change the Repeat Option of the Reminder

1. On the New Entry screen, select “Repeat”.

2. Select the desired repeat option.

Organiser & Tools 81

To Enter the Description

1. On the New Entry screen, select “Description”.

2. Enter a memo for the schedule entry.

To Make the Entry Secret

1. On the New Entry screen, select “Secret”.

2. Select “On” to make the data secret or select “Off” to leave as

is.

Viewing a Schedule Entry

→

“Organiser & Tools”

“Calendar”

1. Select the day you wish to view.

To Search By Date

1. In any view, press [Options] and select “Go to”.

2. Select “Today” to display today or “Enter Date” to enter the

desired date.

Tip

• In the monthly or weekly view, you can control the view by using

the following: Monthly view

P: Displays the previous month. R: Displays the next month. Q: Displays the weekly view. c/d: Moves the cursor to left (the previous day) or to right

a/b: Moves the cursor upward (last week) or downward

(the next day).

(next week).

Weekly view

P: Displays the previous week. R: Displays the next week. Q: Displays the monthly view. c/d: Moves the cursor to left (the previous day) or to right

a/b: Moves the weekly view up or down (the previous hour

Editing a Schedule Entry

“Organiser & Tools”

(the next day).

or next hour).

→

“Calendar”

1. Select the day you wish to edit.

2. Press [Options] and select “Edit”.

3. Select the desired item and modify the entry.

4. Press [Save].

Deleting Schedule Entries

1. In any view, press [Options] and select “Delete”.

2. Select the desired option.

“This Appointment” (daily view):

“All This Day”: Deletes all entries for the selected day. “All This Week” (weekly view):

Deletes the selected entry.

Deletes all entries for the selected week.

82 Organiser & Tools

“Up to Last Week” (weekly view):

“All This Month” (monthly view):

“Up to Last Month” (monthly view):

“All Appointments” (weekly and monthly view):

Sending a Schedule Entry

“Organiser & Tools”

Deletes all entries before this week.

Deletes all entries for the selected month.

Deletes all entries before this month.

Deletes all entries in this application.

→

“Calendar”

1. Select the day including schedule entries you wish to send.

2. Press [Options] and select “Send”.

3. Select “As Message”, “Via Bluetooth” or “Via Infrared”.

For “Via Bluetooth”

For details, see “Bluetooth” on page 109.

For “Via Infrared”

For details, see “Infrared” on page 111.

Note

• When pairing, you need to enter your passcode when establishing

contact with a Bluet ooth wireless technology enabl ed device for the first time.

Receiving a Schedule Entry

When the phone receives a schedule entry, a confirmation message is displayed in standby.

1. Press [Yes].

The received entry is saved in the Calendar. Press [No] to reject.

Tip

• For details on making Infrared or Bluetooth wireless settings, see

“Connectivity” on page 109.

Viewing the Memory Status

1. In any view, press [Options] and select “Memory Status”.

Alarms

(M 7-2)

Setting the Alarms

The alarm function allows you to be alerted at a specified time. Note that you need to set the current date and time before setting the

alarm function if it has not been done already.

Note

• The alarm will not ring when “Ringer Volume” (p. 93) is set to

“Silent”.

→

“Organiser & Tools”

“Alarms”

1. Select the blank setting.

2. Enter the desired time.

3. Press [Save].

To Change the Type of Repeat Options

1. On the Set Alarm screen, select “Repeat”.

Organiser & Tools 83

2. Select from “Once Only”, “Every Day” or “Selected Days”.

“Once Only”: The alarm sounds once only. “Every Day”: The alarm sounds every day at the specified

time.

“Selected Days”: The alarm so unds on the selected day of the

week at the specified time.

To Change the Type of Alarm Tone or Video Clip File

1. On the Set Alarm screen, select “Assign Tone/Video”.

2. Select “Assign Tone” and then select “Preset Sounds” or “My

Sounds”, or select “Assign Video”.

3. Select the desired tone or video clip file.

For details on selecting a tone, see “Assigning a Ringtone” on page 93.

To Change the Snooze of the Alarm Tone

1. On the Set Alarm screen, select “Snooze”.

2. Select the desired snooze option.

To Change the Alarm Volume

1. On the Set Alarm screen, select “Alarm Volume”.

2. Press a (or d) to increase the volume or press b (or c) to

decrease the volume.

To Change the Vibration of Alarm Tone

1. On the Set Alarm screen, select “Vibration”.

2. Select “On”, “On & Link to Sound” or “Off”.

For details on selecting a vibration, see “Vibration” on page 95.

To Change the Duration of the Alarm Tone

1. On the Set Alarm screen, select “Duration”.

2. Select the desired duration.

Resetting an Alarm Setting

“Organiser & Tools”

→

“Alarms”

1. Highlight the alarm you wish to reset.

2. Press [Options] and select “Reset Alarm”.

Resetting All Alarm Settings

“Organiser & Tools”

→

“Alarms” → “Clear All”

84 Organiser & Tools

Calculator

The calculator function performs the 4 arithmetic calculations using up to 12 digits.

“Organiser & Tools”

Key operations for calculation are as follows:

(M 7-3)

→

“Calculator”

To Set a Currency Conversion Rate

→

“Organiser & Tools” “Currency Converter”

“Calculator” → [Options] →

→

“Exchange Rate”

1. Select “Domestic” or “Foreign”.

2. Enter the currency conversion rate.

To Convert a Value

“Organiser & Tools”

→

“Calculator”

1. Enter the value to be converted.

2. Press [Options] and select “Currency Converter”.

3. Select “Convert to Domestic” or “Convert to Foreign”.

To enter a decimal point, press P. To clear the entered number or function, press U. To do the calculations, press . To start a new calculation, press U.

Rate Conversion

You can also use the calculator as a currency calculator to convert from/to a home currency using a conversion rate that you enter.

Voice Recorder

This allows you to record a voice clip, which can be used to remind you of schedule entries or be sent within a multimedia message. The recorded voice clip is saved in Saved Sounds. Voice clips are saved in .amr format.

Recording a Voice Clip

“Organiser & Tools”

(M 7-4)

→

“Voice Recorder”

1. Press to start recording.

To stop recording before the recording time is over, press .

2. Select “Save” to save the voice clip.

Organiser & Tools 85

Note

• Press a (or V) or b (or W) to adjust the sound volume when

playing back the recorded file.

Sending Voice Clips

→

“Organiser & Tools”

“Voice Recorder”

1. Press to start recording.

2. Press to stop recording.

3. Select “Save and Send”.

For details on creating a message, see “Creating a New Message” on page 50.

Selecting the Record Size

“Organiser & Tools” “Record Size”

→

“Voice Recorder” → [Options] →

1. Select “For Message” or “Extended Voice”.

When selecting “Extended Voice”, you can save the voice clip only in a memory card automatically.

Selecting Storage Memory

→

“Organiser & Tools” “Save New Sound”

“Voice Recorder” → [Options] →

1. Select the desired location.

When selecting “Choose before Saving”, you can select the location when saving a voice clip.

E-Book

This function allows you to view book files (XMDF or Text files) stored in an SD card.

“Organiser & Tools”

(M 7-5)

→

“E-Book”

1. A folder list is displayed, followed by a file list.

2. Select the desired file and press .

To search for dictionary contents, enter the title on the Search screen.

3. Enter a password if required.

4. Press to view.

To scroll the screen up and down (to previous or new line), press

a or b. To jump to the previous or the following pages, press c or d.

5. Press F when finished.

Tip

• When a call arrives while the viewer is on or when you exit the

E-Book, up to two markers are automatically added.

• While viewing, you can also add up to two markers to each file. The

page with the marker automatically opens when you select the file the next time.

86 Organiser & Tools

Note

• E-Book files cannot be viewed while “Music Player” or “Games &

Applications” is in use.

• If you remove the memory card while the E-Book function is

activated, a confirmation message appears and your phone returns to the standby screen.

Stopwatch

You can store 4 lap times when using the stopwatch function.

“Organiser & Tools”

(M 7-6)

→

“Stopwatch”

1. Press to start.

Press [LAP] to view the lap time before the stopwatch stops. Last 4 lap times are saved.

2. Press to stop.

Tip

• You can save a record of lap time and stop time in Text Templates

by pressing [Options] and selecting “Save to Templates”.

Resetting Time

1. After stopping the stopwatch, press [Options] and select

“Reset”.

(M 7-7)

Tasks

You can register your schedule as task entries which are associated with the date and time.

Creating a New Entry

→

“Organiser & Tools”

“Tasks”

1. Select “Add New Entry”.

2. Enter the subject.

3. Enter the due date and then due time.

4. Select the reminder time.

When selecting “Other”, enter the desired reminder date and time.

5. Press [Save].

Note

• If the date and time settings have not been made, the date and

time entry screen is displayed (p. 98).

To Change the Type of Alarm Tone or Video Clip File

1. On the Reminder screen, select “Assign Tone/Video”.

2. Select “Assign Tone” and then select “Preset Sounds” or “My

Sounds”, or select “Assign Video”.

Organiser & Tools 87

3. Select the desired tone or video clip file.

For details on selecting a tone, see “Assigning a Ringtone” on page 93.

To Change the Duration of Alarm Tone or Video

1. On the Reminder screen, select “Duration”.

2. Select the desired duration.

To Change the Description

1. On the New Entry screen, select “Description”.

2. Enter a memo for the task entry.

To Make the Entry Completed or Uncompleted

“Organiser & Tools”

→

“Tasks”

1. Highlight the desired entry.

2. Press [Options] and select “Check”.

To make the entry uncompleted, select “Uncheck”.

To Make the Entry Secret

1. On the New Entry screen, select “Secret”.

2. Select “On” to make the data secret or select “Off” to leave as

is.

Sending a Task Entry

“Organiser & Tools”

→

“Tasks”

1. Highlight the task entry you wish to send.

2. Press [Options] and select “Send”.

3. Select “As Message”, “Via Infrared” or “Via Bluetooth”.

For “Via Bluetooth”

For details, see “Bluetooth” on page 109.

For “Via Infrared”

For details, see “Infrared” on page 111.

Note

• When pairing, you need to enter your passcode when establishing

contact with a Bluetooth wirele ss technology enabled dev ice for the first time.

Viewing the Memory Status

→

“Organiser & Tools”

“Tasks”

1. Highlight the task entry you wish to view the memory status of.

2. Press [Options] and select “Memory Status”.

Deleting Entries

“Organiser & Tools”

→

“Tasks” → [Options] → “Delete”

1. Select the desired option.

“This Task”: Deletes the selected entry. “All Completed Tasks”: Deletes all checked entries. “All Tasks”: Deletes all entries.

88 Organiser & Tools

World Clock

Setting the Time Zone

“Organiser & Tools”

(M 7-8)

→

“World Clock”

1. Press [Edit] and select “Set Time Zone”.

The current time zone is indicated by red line on the world map.

2. Press c or d to change the time zone.

3. Press .

To Set the Custom Time Zone

“Organiser & Tools”

→

“World Clock”

1. Press [Edit] and select “Set Time Zone”.

2. Press [Options] and select “Set Custom Zone”.

3. Enter the desired city name and time.

Setting the Daylight Saving

“Organiser & Tools”

→

“World Clock”

1. Press [Edit] and select “Daylight Saving”.

2. Select “On” or “Off”.

Countdown Timer

“Organiser & Tools” → “Countdown Timer”

(M 7-9)

1. Enter the time to count.

You can set the time from 1 second to 60 minutes.

2. Press to start counting.

3. Press to pause.

Press again to continue counting.

4. If the countdown has finished, press [Cancel] and then press

to start the countdown again.

Editing the Countdown Time

1. In the countdown start screen, press [Options] and select

“Edit”.

2. Modify the desired time.

Organiser & Tools 89

Expenses Memo

You can record an expenses memo with predefined or edited categories.

Recording in the Expenses Memo

“Organiser & Tools” Expense”

(M 7-10)

(M 7-10-1)

→

“Expenses Memo” → “Add New

1. Enter the expenses using the digit keys.

2. Select the desired category.

Expenses memo is registered.

Viewing Totals

“Organiser & Tools”

Recorded expenses are displayed on the screen.

To Change Amount

(M 7-10-2)

→

“Expenses Memo” → “Totals”

1. In the total view, select the desired item.

2. Press [Options] and select “Change Amount”.

3. Enter the desired amount using the digit keys.

To Delete a Recorded Item or All Items

1. In the total view, select the desired item.

2. Press [Options] and select “Delete Item” or “Delete All”.

Editing the Category Name

“Organiser & Tools”

(M 7-10-3)

→

“Expenses Memo” → “Edit Category”

1. Select the desired category name.

2. Modify the name.

Phone Help

You can view the help list and use it to guide you in the phone’s functions.

“Organiser & Tools”

(M 7-11)

→

“Phone Help”

1. Press a or b.

90 Organiser & Tools

SIM Application

You can refer to the information on the SIM/USIM. Contact your service provider for further details.

(M 11)

SIM Application 91

92 SIM Application

Settings

Profiles

The tone sound and vibration settings can be customised for each profile according to your environment.

There are 6 profiles: “Normal”, “Meeting”, “Activity”, “Car”, “Headset” and “Silent”.

Activating a Profile

“Settings”

(M 12)

(M 12-1)

→

“Profiles”

1. Select the desired profile.

Note

• When a profile is set, the corresponding indicator described on

page 19 is displayed in standby.

Tip

• Press and hold R to switch Profiles settings between the mode

most recently activated and Silent mode in standby.

Resetting Profile Settings

→

“Settings”

“Profiles”

1. Highlight the profile you wish to reset.

2. Press [Options] and select “Set to Default”.

3. Enter your handset code.

The default handset code is “9999”. For details on changing the handset code, see “To Change the Handset Code” on page 105.

Ringer Volume

You can adjust the ringer volume to one of six levels or to an increasing volume.

→

“Settings”

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Ringer Volume”.

4. Press a (or d) to increase the ringer volume or press b (or

c) to decrease the ringer volume and then press .

To select “Increasing Volume”, press a (or d) at level 5. To select “Silent”, press b (or c) at level 1.

Tip

• You can select from two levels or an increasing volume, when

selecting the “Silent” profile.

Assigning a Ringtone

You can select the ringtone from 28 tones including 5 patterns, 13 sound effects and 10 melodies. You can also select a sound in Saved Sounds as the default ringtone excluding the AMR or WAVE format.

→

“Settings”

“Profiles”

Settings 93

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Ringtone/Ringvideos”.

4. Select “For Voice Call” or “For Video Call”.

5. Select “Assign Tone”.

6. Select “Preset Sounds” or “My Sounds”.

7. Highlight the ringtone you wish to use.

To hear the demo play, press [Options] and select “Play”.

8. Press [Options] and select “Assign”.

Note

• Even if you delete a ringtone that uses a sound in Saved Sounds,

the setting remains the same and the default ringtone sounds. If you delete a ringtone assigned for the ringtone, the default ringtone is set.

Assigning a Ring Video Clip File

You can select a video clip file in Saved Videos as the default ring video clip file.

→

“Settings”

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Ringtone/Ringvideos”.

4. Select “For Voice Call” or “For Video Call”.

5. Select “Assign Video”.

6. Highlight the ring video clip file you wish to use.

To preview the file, press [Options] and select “Play”.

7. Press [Options] and select “Select”.

Message Notification

When receiving messages, your phone will notify you of their arrival with the ringtone or ring video you specify.

→

“Settings”

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Ringtone/Ringvideos”.

4. Select “For New Message”.

5. Select “Assign Tone” or “Assign Video”.

If “Assign Tone” is selected, select “Preset Sounds” or “My Sounds”.

6. Highlight the desired ringtone or ring video clip.

For details on selecting a ringtone or a ring video, see “Assigning a Ringtone” on page 93 or “Assigning a Ring Video Clip File”.

7. Press [Options] and select “Assign” (for a ringtone) or “Select”

(for a video clip).

8. Select “For New Message” and select “Duration”.

9. Enter the desired duration.

94 Settings

Keypad Tones

When the keypad tone is set on, you will hear a confirmation tone each time you press any keys.

→

“Settings”

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “System Sounds”.

4. Select “Keypad Tones”.

5. Highlight the desired tone pattern.

6. Press [Options] and select “Assign”.

Vibration

“Settings”

→

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Vibration”.

4. Select “On”, “On & Link to Sound” or “Off”.

Tip

• When the “On & Link to Sound” option is selected in step 4, the

vibrator synchronises with your selected melody to pulse in time with the melody. Please note that not all melodies support the “On & Link to Sound” option.

• When you select “On” or “On & Link to Sound” in step 4, “ ” is

displayed in standby.

Any Key Answer

You can answer a call by pressing any key except F, , U and [Busy]. For details, see page 24.

→

“Settings”

“Profiles”

1. Highlight the profile you wish to customise.

2. Press [Options] and select “Personalise”.

3. Select “Any Key Answer”.

4. Select “On” or “Off”.

Setting the Display

You can change the settings of the display.

Setting the Wallpaper

For the standby screen, 5 pictures are provided. Pictures taken with the digital camera or images downloaded from a WAP site can be used for wallpapers.

To Set My Pictures

→

“Settings”

“Display Settings” → “Wallpaper”

(M 12-2)

(M 12-2-1)

1. Select “My Pictures”.

2. Select the desired picture.

3. After displaying the picture, press .

Note

• Some pictures cannot be used because of their picture and data

types.

• If the picture in My Pictures is already set, it is displayed in step 1.

Press [Change] and select the desired picture.

Settings 95

System Graphics

Pictures can be displayed when turning the power on or off, when receiving an incoming call, or when operating the alarm.

Pictures taken with the digital camera or images downloaded from a WAP site can be used.

To Set Preset Animation

“Settings”

(M 12-2-2)

→

“Display Settings” → “System Graphics”

1. Select the desired scene to set the picture to.

2. Select “Preset Animation”, “My Pictures” or “Other

Documents” when you select “Power On” or “Power Off” in step 1.

Select “Pattern 1”, “Pattern 2”, “Pattern 3”, “My Pictures” or “Other Documents” when you select “Incoming Call” or “Alarm” in step 1.

To Set My Pictures

→

“Settings”

“Display Settings” → “System Graphics”

1. Select the desired scene to set the picture to.

2. Select “My Pictures”.

3. Select the desired picture.

4. After displaying the picture, press .

5. Specify the area you wish to display using the navigation keys.

Note

• Some pictures cannot be used because of their picture and data

types.

• If the picture in My Pictures is already set, it is displayed in step 2.

Press [Change] and select the desired picture.

Setting the Font Weight

→

“Settings”

“Display Settings” → “Font Settings”

(M 12-2-3)

1. Select “Thin”, “Normal”, “Bold” or “Bolder”.

The preview image is displayed in the selected weight.

Setting the Greeting Message

You can set the message which is displayed when the phone is turned on.

→

“Settings” “Switch On/Off”

“Display Settings” → “Greeting Message” →

(M 12-2-4)

1. Select “On” or “Off”.

2. Select “Edit Message” and enter the message (up to 10

characters).

Setting the External Display

To Turn On/Off the External Display

You can turn the external display on or off when the phone is closed.

→

“Settings” “Switch On/Off”

“Display Settings” → “External Display” →

(M 12-2-5)

1. Select “On” to turn external display on or “Off” to turn external

display off.

96 Settings

To Select the Backlight Time Out

“Settings” “Backlight”

→

“Display Settings” → “External Display” →

1. Select the desired time out.

Select “Off” to shut the backlight off.

To Adjust the LCD Contrast

You can adjust the LCD contrast to suit certain lighting conditions.

“Settings” “LCD Contrast”

→

“Display Settings” → “External Display” →

1. Press a (Light) or b (Dark) to switch between 9 levels of

clarity.

2. Press .

To Set Incoming Indication

Caller number or registered caller name can be displayed on the external display when receiving an incoming call.

→

“Settings” “Caller Display”

Select “On” or “Off”.

Backlight

The backlight will shut off if you do not press the keypad for a certain length of time. You can specify a desired time to elapse before the backlight shuts off, which will help conserve battery life.

Tip

• When you purchase this phone, Backlight is set to 15 seconds.

To Select the Backlight Time Out

“Settings” “Timeout”

“Display Settings” → “External Display” →

(M 12-2-6)

→

“Display Settings” → “Backlight” →

1. Select the desired time.

Select “Off” to shut it off.

To Adjust the Brightness of the Backlight

→

“Settings” “Brightness”

“Display Settings” → “Backlight” →

1. Press a (Light) and b (Dark) to switch between 4 levels of

clarity.

2. Press .

Setting the Display Saving

The screen of this phone will automatically turn off after a given amount of time. You can change the length of time before the Display Saving goes into effect, which will help conserve battery life.

Tip

• When you purchase this phone, Display Saving is set to 2 minutes.

→

“Settings”

“Display Settings” → “Display Saving”

(M 12-2-7)

1. Select the desired time.

Note

• Display Saving does not work while you are making a call, using

WAP, or using an application.

• To cancel the Display Saving: The display saving continues until

either a key is pressed or there is an incoming alert. The first key press only cancels this function. You must press another key in order to enter any numerical or text value.

Settings 97

Sound Settings

You can use this menu to check or edit the current Profiles settings (except “Any Key Answer”).

Date & Time

You need to set the correct time and date in order for your phone’s various time-based functions to work correctly.

“Settings”

(M 12-3)

(M 12-4)

→

“Date & Time” → “Set Date/Time”

1. Enter the day, month and year using the digit keys.

2. Enter the time using the digit keys.

Tip

• When you enter the time in the 12-hour format, press a or b

to switch between am and pm. The order in which the date and time is displayed is based on the format setting.

Setting the Daylight Saving

→

“Settings”

“Date & Time” → “Daylight Saving”

(M 12-4-2)

1. Select “On” or “Off”.

Setting the Time Zone

“Settings”

→

(M 12-4-3)

“Date & Time” → “Set Time Zone”

1. Press c or d to select the home city to set.

2. Press .

Customising the Time Zone

→

“Settings”

→

“Set Custom Zone”

“Date & Time” → “Set Time Zone” → [Options]

1. Enter the city name.

2. Enter the time-zone differences using the digit keys.

Press a or b to switch between − and +.

3. Press .

Display Date & Time

You can display the calendar or the current date and/or time in standby.

To Set the Clock Display

“Settings” “Show Clock”

(M 12-4-4)

→

“Date & Time” → “Display Date & Time” →

1. Select the desired clock type or “Off” to set clock display off.

Tip

• When you select “Calendar”, you can display one or two

consecutive calendars by selecting “1 month” or “2 months”.

World Clock

Setting the Time Zone

“Settings”

(M 12-4-5)

→

“Date & Time” → “World Clock”

1. Press [Edit] and select “Set Time Zone”.

The current time zone is indicated by red line on the world map.

2. Press c or d to change the time zone.

3. Press .

98 Settings

To Set the Custom Time Zone

“Settings”

→

“Date & Time” → “World Clock”

1. Press [Edit] and select “Set Time Zone”.

2. Press [Options] and select “Set Custom Zone”.

3. Enter the desired city name and time.

Setting the Daylight Saving

“Settings”

→

“Date & Time” → “World Clock”

1. Press [Edit] and select “Daylight Saving”.

2. Select “On” or “Off”.

Selecting the Time Format

“Settings”

→

“Date & Time” → “Time Format”

(M 12-4-6)

1. Select “24 Hour” or “12 Hour”.

Selecting the Date Format

“Settings”

→

“Date & Time” → “Date Format”

(M 12-4-7)

1. Select from “D.M.Y”, “M-D-Y” or “Y/M/D”.

Setting the Calendar Format

“Settings”

→

“Date & Time” → “Calendar Format”

(M 12-4-8)

1. Select “Sunday-Saturday” or “Monday-Sunday”.

Setting the Wake-up Alarm

“Settings”

→

“Date & Time” → “Wake-up Alarm”

(M 12-4-9)

1. Select “On” or “Off”.

Language Setting

You can change the language that the phone uses to display messages.

“Settings”

→

(M 12-5)

“Language”

1. Select the desired language.

Tip

• You can also change the input language on the text entry screen

(p. 32).

Note

• If you select “Aut omatic” in step 1, the language preset on the SIM/

USIM card is selected.

• If the language preset on the SIM/USIM card is not supported, then

the default language of the phone is selected.

Call Settings

Voicemail & Diverts

This service is used to divert incoming calls to another phone number depending on certain conditions in which you cannot answer a call or to your voice mail system.

Note

• This service may not be available on all mobile phone networks.

Contact your network operator for more information.

(M 12-6)

(M 12-6-1)

Settings 99

Sharp HRO00040 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
