Sharp HRO00029 User Manual
Your Phone
Please check the following carefully. Your phone
should come complete with:
• GSM 900/1800/1900 GPRS phone
• Rechargeable Li-ion battery
• AC charger
• Hands free
•CD-ROM
• User guide
Accessories
• Li-ion spare battery (XN-1BT11)
• Cigarette lighter charger (XN-1CL10)
• Car holder (XN-1CH11)
• Data cable (RS232C cable: XN-1DC10)
Some of the above accessories may not be offered by
region.
For details, please contact your dealer.
7 Your Phone
(option)
Getting Started
Getting Started 8
1. Earpiece
2. Navigation Keys (Arrow Keys):
Move the cursor to select
menu items, adjust the
earpiece volume, etc.
Up/Down arrow keys:
Search the Phonebook
entries in stand-by mode.
Left arrow key: Adjusts the earpiece
volume in stand-by mode.
Right arrow key: Displays the Phonebook
menu in stand-by mode.
3. Centre Key: Displays the Main Menu
and executes the functions.
in this manual indicates
this key.
4. Left Soft Key: Executes the function at the
bottom left on the screen.
5. Send Key: Makes or accepts calls,
views the call in stand-by
mode.
6. Voice Mail Key: Used to connect to Voice
mail centre. (Depends on
the SIM card.)
7. * /Shift Key: Used to enter * or switch
the text mode.
9 Getting Started
8. Main-Screen Display
9. Hands free Connector
10. Right Soft Key: Executes the function at the
bottom right on the screen.
11. End/Power Key: Ends a call, turns power on/
off.
12. Keypad
13. Microphone
14.
External Connector
: Used to connect either the
charger or data cable.
15. Aerial
16.
Sub-Screen Display
17. Camera
18. Mirror: For self portraits.
19. LED Indicator
20. Infrared Port: Sends and receives data via
infrared.
21. Speaker
22. Side Keys
Up/Down keys: Move the cursor to select
menu items, etc.
23. Battery Cover
Inserting the SIM Card and the
Battery
1. Slide off the battery cover.
2. Slide the SIM card into the SIM holder.
SIM card
Getting Started 10
3. Hold the battery so that the metal contacts of the
battery are facing down, slide the guides on the top
of the battery into the battery slots , and then
insert it .
11 Getting Started
4. Replace the battery cover so that the marks are
aligned and slide it as shown.
Note
• Make sure that only 3V SIM cards are used.
• Use only the approved battery (XN-1BT11).
Removing the SIM Card and the Battery
1. Make sure to turn off your phone and disconnect
charger and other accessories. Slide off the battery
cover.
2. Pick up the battery using the protruding edge and
remove the battery from the phone.
3. Slide the SIM card by pushing the back of the card
and remove it from the SIM holder.
Getting Started 12
Battery Disposal
The device is supported by a battery. In order to protect
the environment, please read the following points
concerning battery disposal:
• Take the used battery to your local waste depot,
dealer or customer service centre for recycling.
• Do not expose the used battery to an open flame, into
water or dispose with the household waste.
Charging the Battery
You must charge the battery for at least 2 hours before
using your phone for the first time.
13 Getting Started
To Charge Using the Charger
1. Connect the charger to the external socket located at
the bottom of the phone with the charger’s “PUSH
TOP” mark facing towards you, and to an AC
outlet.
LED indicator
The LED indicator lights in red.
Standard charging time: Approx. 2 hours.
Note
• Charging time may be longer than above depending
on the state of a battery and a surrounding situation.
(See “Battery” on page 125.)
To disconnect the charger
Push and hold the side buttons of the charger, then
disconnect the charger from the external socket of the
phone.
2. When charging is complete, the LED indicator turns
off. Unplug the charger from the AC outlet, then
unplug the charger connector from the phone.
Note
• Do not use any non approved charger, this may
damage your phone and invalidate any warranty,
please see “Battery” on page 125 for details.
• When the phone is charging, the animated battery
status icon ( ) will be displayed in the upper right
of the screen.
To Charge Using the Cigarette Lighter Charger
The cigarette lighter charger (option) supplies power
for charging from the cigarette lighter socket of a car.
Battery Level Indicator
The current battery level is displayed in the upper right
hand side of the screen and the Sub-screen.
Low Battery During Use
When the battery is running low, an alarm will sound
and the “ ” will appear on the screen and the Subscreen.
If you are using your phone and you hear the “low
battery” alarm, attach your charger as soon as possible.
The phone may not be able to continue normal
operation if you continue to use it. The battery may only
last five minutes before the phone itself powers down
during a call.
Charge Level Indicators
Full level (greater than 60%)
Partial level (less than 60%)
Partial level (less than 30%)
Low level (less than 10%)
Empty
Charging the battery is
recommended.
Charge the battery.
Getting Started 14
Turning Your Phone On and Off
To turn the power on, press and hold for
approximately 2 seconds.
The stand-by screen appears.
To turn the power off, press and hold for
approximately 2 seconds.
Entering the PIN Code
If activated you will be asked to enter a PIN (Personal
Identification Number) code after turning on your
phone.
1. Enter your PIN code.
2. Press .
Note
• If your PIN code is entered incorrectly three times in
a row, the SIM card is locked. See “Enabling/
Disabling the PIN Code” on page 100.
15 Getting Started
Display Indicators
Left
softkey
Status
Indicators
Right softkey
1. / : Indicates the strength of received
signal/the service is out of range.
2. : Appears when in call.
3. ///:
Indicates the input mode (Upper case
only the first letter of the word mode/
Upper case mode/Lower case mode/
Numeric mode).
4. : Appears when the T9 text input mode
is activated.
5. / / : Appears when a new SMS, MMS
Alert or WAP Alert has arrived.
6. / : Appears when viewing secured WAP
browser.
7. / : Appears when a picture or image/
sound is attached to MMS.
8. : Indicates a Phonebook entry stored in
the phone memory.
9. : Indicates a Phonebook entry stored on
the SIM card.
10. : Indicates the battery level.
11. : Appears when your phone is roaming
outside of your network.
12. : Appears when your phone is in data
communication mode.
13. : Appears when your phone is in fax
communication mode.
14. : Appears when your phone is GPRS
enabled and within range.
Flashes during GPRS transmission.
15. : Appears when Alarm is set.
16. : Appears when “Diverts” (p. 82) is set
to “All Calls”.
17. : Appears when the data cable is
connected to your phone.
18. : Appears when “Ringer Volume”
(p. 64) is set to “Silent”.
19. : Appears when Vibration alert is set.
Getting Started 16
20. (No display)/ / / / :
Indicates the phone’s mode (Normal
mode/Meeting mode/Activity mode/
Car mode/Silent mode).
21. : Appears when a voicemail message is
stored.
22. : Appears when up, down, right or left
navigation is available.
23. / : Appears when “Infrared” is on/during
connection.
TM
24. / : Appears when the Java
application
is executed/suspended.
Softkey Indicators
To execute the operation indicated, press each
corresponding key.
25. Area at the lower left of a screen:
Displays the operation executed by
left softkey.
26. Area at the lower right of a screen:
Displays the operation executed by
right softkey.
17 Getting Started
Sub-Screen
Status Indicators
Status
Indicators
1. : Indicates the received signal strength.
2. : Appears when GPRS is within range
and can be used.
Flashes during in GPRS
communication mode.
3. : Appears when a new SMS, MMS
Alert or WAP Alert has arrived.
4. : Appears when Alarm is set.
5. : Indicates the battery level.
6. / : Appears when “Infrared” is on/during
connection.
7. : Appears when “Diverts” (p. 82) is set
to “All Calls”.
8. : Appears when the data cable is
connected to your phone.
9. : Appears when “Ringer Volume”
(p. 64) is set to “Silent”.
Getting Started 18
Call Functions
Making a Call
1. Enter the area code and the phone number you wish
to dial.
If you enter the wrong number, press [Clear] to
delete the number to the left of the cursor.
2. Press to dial.
Emergency Calls
1. Enter 112 (international emergency number) using
the keypad.
2. Press to dial.
Note
• Emergency calls may not be available on all mobile
phone networks when certain network services and/
or phone features are in use. Contact your network
operator for more information.
• This Emergency number can normally be used to
make an emergency call in any country, with or
without a SIM card inserted, if a GSM network is
within range.
19 Call Functions
International Calls
1. Press and hold until a “+” (international
dialling prefix) sign appears.
2. Enter the country code, followed by the area code
and the number.
3. Press to dial.
Note
• Enter the area code omitting the first 0 when making
international calls, in most cases. (It differs for some
countries.)
Speed Dialling
In the Speed Dial List, up to 9 phone numbers out of the
Phonebook can be set. You can call the numbers using
the digit keys ( to and ).
For details on setting the Speed Dial List, see “Speed
Dial List” on page 30.
1. Press and hold any of the digit keys ( to
and ).
The phone number stored in the Speed Dial List is
displayed, then dialled.
Redialling
You can redial the numbers in the call log list that you
may have missed, received or dialled. Each list can
contain up to 10 numbers.
1. Press during stand-by.
2. Press or to select a category between
“Dialled Numbers”, “Missed Calls” and “Received
Calls”.
3. Select the number you wish to call by pressing
or .
4. Press to redial the call.
Automatic Redialling
This setting allows you to automatically redial the
number if the first attempt was unsuccessful.
If you wish to stop redialling, press or [End].
To Set the Auto Redial Function
1. Press to display the Main Menu.
2.
Press or to select “Settings”, then press .
3. Press or to select “Call Settings”, then press
.
4. Press or to select “Auto Redial”, then press
.
5. Select “On” to enable the Auto Redial function or
“Off” to disable it, then press .
Note
• When you receive an incoming call, the Auto Redial
function will be interrupted.
• Automatic redialling is not available for fax and data
calls.
Ending a Call
1. Press to end the call.
Answering a Call
When an incoming call is detected, the phone rings and
the LED indicator flashes green.
1. Open your phone.
2. Press to answer the call.
or
Press any key except , [Reject], and
when the “Any Key Answer” function is enabled.
Set the Any Key Answer function in the profile in
each mode. (p. 68)
Call Functions 20
Tip
• When the hands free kit is connected to the phone,
you can answer calls by pressing the Side keys (up or
down).
• If you have subscribed to the Calling Line
Identification (CLI) service and the caller’s network
sends the number, the caller’s number will appear on
the screen. If the caller’s name and number are
stored in the Phonebook, the caller’s name will
appear on the screen.
• If the number is a restricted number, the display
shows “Withheld”.
• When receiving a call from the person whose picture
is registered in the Phonebook, receiving display and
the picture are displayed alternately.
Rejecting an Incoming Call
You can reject a call you do not wish to answer.
1. Press or [Reject] or press and hold the Side
keys (up or down) whilst the phone is ringing.
Incall Menus
Your phone has additional functions available whilst a
call is in progress.
21 Call Functions
Adjusting the Earpiece Volume
You can adjust the earpiece volume during a call.
1. During a call, press .
2. Press to increase the earpiece volume or press
to decrease the earpiece volume.
Each press of or adjusts the earpiece volume
by one of 5 levels.
3. Press [OK].
Tip
• You can also adjust the earpiece volume using the
Side keys (Volume up key or Volume down key)
during a call.
Putting a Call on Hold
This function allows you to manage two calls at the
same time. If you wish to make another call whilst you
are talking to someone, you can put the current call on
hold to call someone else.
To make another call during a call
1. During a call, press [Options] to display the
Options Menu.
2. Select “Hold”, then press .
The current call is put on hold.
To retrieve a call, press [Options] and
select “Retrieve”, then press .
3. Enter the phone number you wish to make another
call to, then press .
Tip
• You can also make another call by entering the phone
number during a call instead of steps 1 and 2. The
current call is automatically put on hold.
Call Waiting
This service notifies you of another incoming call
whilst you have a call in progress.
1. During a call, press [Answer] to answer the
second call.
The first call is put on hold and you can now talk to
the second caller.
2. Press [Options] and select “Swap” to switch
between the two calls.
3. Press [Options] and select “End Call”,
then press to end the current call and return to
the held call.
Note
• You need to set “Call Waiting” to “On” if you use
Call Waiting service (p. 89).
• Call Waiting service may not be available on all
networks. Contact your network operator for more
information.
• If you do not wish to answer the second call, press
[Reject] in step 1. The call log of the second call
will be saved as a missed call.
Conference Call
Conference call is a call with more than 2 participants.
You may include up to 5 participants in a conference
call.
Making a Conference Call
To make a conference call, you must have one active
call and one held call.
1. Press [Options] to display the Options Menu.
2. Press or to select “Multiparty”, then press
.
3. Press or to select “Join All”, then press
to join the conference call.
4. Press to end the conference call.
Note
• Conference call service may not be available on all
networks. Contact your network operator for more
information.
Call Functions 22
Adding New Participants to the Conference Call
1. Press [Options] to display the Options Menu.
2. Press or to select “Dial”, then press .
3. Enter the number you wish to include in the
conference call.
4. Press to dial.
5. Press [Options] to display the Options Menu.
6. Press or to select “Multiparty”, then press
.
7. Press or to select “Join All”, then press
to join the conference call.
If you wish to add other participants, repeat steps 1
to 7.
To End the Call with a Conference Call Participant
1. During a conference call, select the person who you
wish to disconnect the call by pressing or .
2. Press [Options] to display the Options Menu.
3. Press or to select “End Call”, then press
.
23 Call Functions
To Have a Private Conversation with one of the
participants
If you wish to have a private conversation with one of
the participants, you may select the participant from the
conference list and put the other participants on hold.
1. During the conference call, select the person that
you wish to talk to by pressing or .
2. Press [Options] to display the Options Menu.
3. Press or to select “Multiparty”, then press
.
4. Press or to select “Private”, then press .
5. Once you have finished the private conversation,
press [Options] and select “Multiparty”,
then press .
6. Press or to select “Join All”, then press
to return to the conference call.
Muting the Microphone
1. During a call, press [Mute] to mute the
microphone.
To unmute the microphone, press [Unmute].
Phonebook
You can store the phone numbers and E-mail addresses
of your friends, family and colleagues in the
Phonebook.
Group name (p. 26)
You can classify the phone numbers and names stored in
the Phonebook, such as “Family” and “Business”.
Entering Characters
When entering characters to create Phonebook entries,
SMS or MMS, etc., press the corresponding keys.
Table of Characters
Pressing each key scrolls characters in the following order.
Note
• Depending on the type of the data entry screen,
usable characters are limited.
Normal Mode
-
(hyphen)
Lower Case
Characters
? !
Numeric
1
Key
Upper Case Characters
.
(full-stop)
,
’
(apostrophe)
ABC2ГБАВДЕЖЗ abc2гбавдежз 2
DEF3ÉÊÈË def3éêèë 3
GHI4Í
(comma)
@ _ ( ) / ” :1
Î Ì Ï ghi4í î ì ï4
Key
Upper Case Characters
JKL5 jkl5 5
PQRS7 pqrs7ß 7
WXYZ9ÝÞ wxyz9ýþ 9
(space)+ = < > £ $ ¥ % &0
*+P?
Lower Case
Characters
Numeric
6
8
0
(space)
- : Press and hold to enter 0 - 9 numbers.
,
: Press and hold to shift to Sentence mode,
Capital letter, Small letter, Numeric.
: Press and hold to shift between Normal
and T9 mode.
Note
• When you send an SMS with Optimisation set “On
SMS Settings, characters with an accent will be sent
as characters with no accent.
For details, see “Optimisation” on page 115.
Phonebook 24
”
in
Changing the Input Mode
To change the input mode, press for
approximately 2 seconds.
T9 Text Input
T9 text input method is a shortcut to enter text easily
and quickly.
1. Press and hold until “
”
is displayed.
2. Press each key once for any letter you require on
that key.
To enter the word “How”, press .
3. Press or until the correct word is shown if
the character combination, that was initially
displayed, is not correct.
4. Press to select the word.
Note
• If the correct word is not shown in step 3, enter the
correct word again after switching to the normal
input mode.
Tip
• If you press instead of step 4, a space is
inserted next to the selected word.
Symbols and Punctuation
To enter symbols or punctuation, press .
25 Phonebook
Using Text Template
You can use the sentences registered in My Text
Templates when entering characters.
For details on creating the text template, see “Adding
Phrases to My Text Templates” on page 46.
1. Press [Options] to display the Options Menu.
2. Press or to select “Insert Template”, then
press .
3. Select a desired text template by pressing or
, then press .
The selected text template will be inserted.
Creating a New Entry
You can choose either the phone (up to 500) or SIM
card memory locations to store the new entry.
The amount of phone numbers that you can store to the
SIM card is dependant on its capacity. Contact your
network operator for SIM details.
Phonebook Memories
Select the location for storing the Phonebook memory
before storing a new entry.
1. Press to display the Phonebook menu.
2. Press or to select “Settings”, then press .
3. Press or to select “Save Nos. to”, then press
.
4. Select “SIM Card” to store the entry on the SIM
memory or “Phone Memory” by pressing or
, then press .
When selecting “Choice”, you can choose SIM card
or phone memory every time you store a new
Phonebook entry.
Storing Names and Numbers
1. Press to display the Phonebook menu.
2. Press or to select “Add New Name”, then
press .
3. If you select “Choice” in step 4 in “Phonebook
Memories”;
Select “SIM Card” or “Phone Memory” by pressing
or , then press .
The name entry prompt appears.
4. Enter a name, then press .
For details on entering characters, see “Entering
Characters” on page 24.
The phone number prompt appears.
5. Enter the phone number, then press .
Up to 40 digits can be entered.
6. Select a desired number type by pressing or ,
then press .
7. Press [Save].
You can divide the phone numbers of the
Phonebook into groups. You can also register Email address, personal data, and picture/image data.
(See “Storing Optional Data” for details.)
Storing Optional Data
You can store optional data after entering a phone
number. (See “Storing Names and Numbers” for
details.)
Note
• E-mail address, personal data, and picture/image
data cannot be stored on the SIM card.
Selecting Group Name
1. Press or to highlight the right side of
“ ”, then press .
2. Select a desired group name by pressing or ,
then press .
You can set to display the available group names
when you store/edit the Phonebook, see “View
Groups” on page 29.
Phonebook 26
Entering E-mail Address
3. Press or to highlight the right side of
“ ”, then press .
4. Enter the E-mail address, then press .
Up to 60 characters can be entered.
Entering Personal Data
5. Press or to highlight the right side of
“ ”, then press .
6. Enter the personal data, then .
Up to 60 characters can be entered.
Storing Picture/Image Data
You may store a picture/image for use with the
Phonebook.
When you receive a call from a person with a
Phonebook entry which also has a linked picture/image,
when the person calls, the linked picture/image will be
displayed.
7. Press or to highlight the right side of
“ ”, then press .
8. Select the desired picture/image, then press .
The selected picture/image will appear on the
screen.
27 Phonebook
9. Specify the range for displaying the picture/image
by pressing , , or , then press .
10. Press [Save].
Note
• The stored picture/image is automatically saved
under the “in Phonebook” section of the Saved
Pictures.
• The picture/image cannot be deleted in the Saved
Pictures. Remove the picture/image data from the
Phonebook.
Adding the Phone Number from the Call Log
Entries
1. Display the call log entry you wish to store (p. 77).
2. Press .
3. Press or to select “Save to Phonebook”, then
press .
4. Follow the procedure from step 3 in “Storing Names
and Numbers” on page 26.
Storing after Inputting a Phone Number
1. Enter the phone number, then press [Save].
2. Follow the procedure from steps 3 to 7 in “Storing
Names and Numbers” on page 26.
Finding a Name and Number
Two methods of searching through the Phonebook are
available:
Search by Name
1. Press to display the Phonebook menu.
2. Select “View Names”, then press .
3. Enter a name or the first character(s) of the name.
Matched results will be displayed alphabetically.
If there is no entry in the Phonebook that satisfies
the exact search criteria, the name that is nearest
alphabetically matching will be displayed.
4. Scroll through list by pressing or to select
the desired name, then press [Select].
The detailed screen of the Phonebook appears.
5. Press .
6. Press or to select the desired phone number,
then press to dial.
Tip
• If you press and select “Search” after step 2, you
can also search the name and number.
• You can also dial the desired phone number by
pressing the digit key corresponding to the list
number instead of step 6.
Search in Alphabetical Order
1. Press or whilst in stand-by to open the
Phonebook.
2. Scroll the list by pressing or to find the
desired name.
3. If you wish to do a name search, perform steps 3 and
4 in “Search by Name”.
Editing Phonebook Entries
You can edit Phonebook entries.
1. Search for the desired Phonebook entry.
For details on searching through Phonebook entries,
see “Finding a Name and Number” .
2. Press .
3. Press or to select “Edit”, then press .
4. Select an entry you wish to change by pressing
or , then press [Edit].
Phonebook 28
5. Edit entry as required.
6. Press .
If you wish to edit another item, repeat steps 4 to 6.
7. Press [Save] to save the change(s).
Deleting Phonebook Entries
1. Search for the desired Phonebook entries.
For details on searching through Phonebook entries,
see “Finding a Name and Number” on page 28.
2. Press .
3. Press or to select “Delete”, then press .
4. Select “Yes”, then press .
The selected entry will be deleted.
To cancel deletion, select “No” at step 4, then press
.
Checking Your Own Numbers
You can check and edit your own voice, data and fax
phone numbers in the Phonebook.
1. Press to display the Phonebook menu.
2. Press or to select “Own Numbers”,
then press .
29 Phonebook
3. Press or to select the phone number you
wish to check from either “Voice”, “Data” or “Fax”,
then press .
Note
• “Data” or “Fax” may not be displayed depending on
SIM card.
Editing Your Phone Numbers
1. Perform steps 1 to 3 in “Checking Your Own
Numbers”.
2. Press .
3. Press [Clear] to erase the phone number and
enter a new phone number.
4. Press to save the phone number.
View Groups
You can set the available group names when you store/
edit the Phonebook.
1. Press to display the Phonebook menu.
2. Press or to select “Settings”, then press .
3. Select “View Groups”, then press .
4. Select a desired group name by pressing .
“ ” indicates that the group has been selected.
To cancel the selected group, press again.
The checkbox becomes blank again.
Memory Status
This function helps you to check the number of entries
stored in the Phonebook.
1. Press to display the Phonebook menu.
2. Press or to select “Settings”, then press .
3. Press or to select “Memory Status”, then
press .
You can check the following memory status.
“SIM Card : xxx/xxx”
“Speed Dial : xx/xx”
“Phone : xxx/500”
Note
• The number of locations available on the SIM is
dependant on its capacity.
Speed Dial List
You can set a maximum of 9 phone numbers to the
Speed Dial List.
Use the phonebook entries on the SIM card.
Adding Phonebook entries to the Speed Dial
List
1. Search for the desired Phonebook entries.
For details on searching through Phonebook entries,
see steps 1 to 4 in “Search by Name” on page 28.
2. Press or to select the phone number.
3. Press .
4. Press or to select “Add to Speed”, then press
.
5. Select the number you wish to add by pressing
or , then press .
Viewing the Speed Dial List
1. Press to display the Phonebook menu.
2. Press or to select “Settings”, then press .
3. Press or to select “Speed Dial List”, then
press .
The stored names and phone numbers in the
selected entry are displayed in order.
Phonebook 30
Sending Messages
1. Search for the desired Phonebook entries.
For details on searching through Phonebook entries,
see steps 1 to 4 in “Search by Name” on page 28.
2. Press or to highlight the right side of
“”, “” or “”, then press
or
Press or to highlight the right side of
“ ”, then press .
3. Press or to select “Send Message”, then
press .
If you highlight the right side of “ ”, “ ” or
“ ” in step 2:
4. Press or to select “MMS” or “SMS”, then
press .
5. Enter your message.
For details on creating a message, see “Creating a
New MMS” on page 107 or “Creating a New SMS”
on page 115.
31 Phonebook
Using the Menu
Using the Main Menu
1. Press during stand-by mode.
2. Press or to navigate to required location.
3. Press or to access function.
To Select Another Item within the Main Menu
To return to the previous screen after selecting a
function from the Main Menu or Sub Menu, press .
Every time you press , the screen goes back one by
one.
Operation Guidance
Your phone uses softkeys to help you to navigate the
phone ( and ). These keys change usage
depending on the situation. The function of each
softkey at any given time is highlighted at the bottom
left and bottom right of the screen.
Shortcut Keys
When pressing several key combinations during standby mode, you can shortcut to the specified menus.
To access the desired menu directly, press and digit
keys for the menu’s corresponding number during
stand-by mode. See the following table as reference.
Example: To access “Language” Sub Menu using
shortcut keys
Press .
Note
• The shortcut keys work for the first three menu levels
only.
Side Keys
The Side keys (up or down) function the same as
pressing or .
Using the Menu 32
List of Menu Functions
Menu No./
Main Menu
1 Camera
2 My Phone
3 Fun & Games
4 Profiles
5 Organiser
6 Call Manager
33 Using the Menu
1 My Java
2 My Pictures
3 My Sounds
4 My Bookmarks
5 My Text Templates
6 Memory Status
1 Java
2 Other Games
3 Melody Editor
4 Tone Editor
1 Normal
2 Meeting
3 Activity
4 Car
5 Silent
1 Calculator
2 Calendar
3 Clock & Alarm
4 Voice Memo
5 Help List
1 Phonebook
2 Call Register
3 Diverts
Menu No./
Sub Menu1
TM
TM
Games
Games
Menu No./
Main Menu
7 Settings
8 Vodafone live!
9 Info-Service
0 Messages
*
1 Phone Settings
2 Call Settings
3 Network Settings
4 Internet Settings
5 Infrared
6 Security
7 Master Reset
1 Vodafone live!
2 New
3 Chat
4 Games
5 Find & Seek
6 News
7 Sport
8 Shopping
9 Search
1 MMS
2 SMS
3 Cell Broadcast
4 Cell Info
5 Vodafone Messenger
6 Vodafone Mail
* Depends on the contents of SIM card.
Menu No./
Sub Menu1
Camera
Your phone incorporates an integrated digital camera.
This allows you to take and send pictures wherever you
are.
Taking Pictures
Put the phone into the camera mode to take a picture.
You can send the pictures registered in the Saved
Pictures with your message.
(M 1)
1. Press and hold for approximately 2 seconds
whilst stand-by.
The phone switches to the camera mode.
The camera view can be seen through the “on
screen” viewer.
2. Press or the Side keys (up or down) to take the
picture.
The shutter sound occurs and the static image of the
taken picture is displayed.
3. Press [Save].
“Save to My Phone” is displayed, then the picture is
registered.
If you send a picture by MMS after taking the
picture, press in step 3.
The camera returns to step 1 repeat process as
desired.
4. Press to return to stand-by.
Tip
• To leave Camera Mode without registering the taken
picture after step 2 in “Taking Pictures”:
Press and select “Yes”, then press .
• To take a picture of yourself, press or the Side
keys (up or down) whilst checking the image reflected
on the mirror on the back of the phone. Place/Hold
the phone at least 40 cm away from yourself.
Using the Zoom Function
Press [Zoom] to magnify the photographic subject.
Press [Wide] to restore the original magnification.
Note
• When “Select Picture Size” is set to “Large”, you
cannot use the zoom function.
To select the picture size
1. Press [Options] before step 2 in “Taking
Pictures” to display the Options Menu.
2. Press or to select “Select Picture Size”, then
press .
3. Select the picture size by pressing or , then
press .
Camera 34
To select the mode
1. Press [Options] before step 2 in “Taking
Pictures” on page 34 to display the Options Menu.
2. Press or to select “Select Mode”, then press
.
3. Select the mode by pressing or , then press
.
Note
• Vertical stripes may be reflected to a picture by light
source. Change the mode in this case.
Retaking Pictures
After steps 1 and 2 in “Taking Pictures” on page 34,
press [Back].
Further shooting is available.
Note
• The Digital Camera Uses a C-MOS Sensor. Although
this camera has been manufactured to the highest
specification, some pictures may still appear too
bright or too dark.
• If the phone has been left in a warm place for a long
time before taking or registering a picture, the
picture quality may be poor.
35 Camera
In the Case of No Available Memory
When the number of pictures that can be taken becomes
5 or less, or when the remaining capacity becomes 27.5
Kbytes (when “Medium” is selected as the picture size)
or less, “ ” will appear on screen. The screen returns
to step 2 in “Taking Pictures” on page 34. The number
of pictures that can be taken is displayed in the upper
left of the screen. (The number of pictures that can be
taken is approximate.)
When the number of pictures that can be taken becomes
0, and when you try to take a picture again, “Can not
take a picture. Maximum Capacity” is displayed.
Meanings of Indicators in Camera Mode
Delay timer indicator (p. 36)
: Whilst the timer setting is on.
Picture brightness indicators (p. 36)
:Bright
:
:Normal
:
:Dark
Picture size indicators (p. 34)
Large: 288 × 352 dots
Medium (default): 120 × 160 dots
Small: 60 × 80 dots
Mode indicator (p. 35)
: Mode 1
: Mode 2
Making Adjustments According to Lighting
Conditions
Adjusting the Brightness of the Picture
Adjust the brightness of the picture by pressing or
.
Once the phone has returned to the stand-by screen the
brightness settings return to default.
Viewing the Taken Pictures
The taken pictures can be viewed in the Saved Pictures.
1. In camera mode, press [Options].
The Options Menu is displayed.
2. Select “Existing Pictures”, then press .
The list of Saved Pictures is displayed.
3. Select the file name you wish to view by pressing
or , then press .
The selected picture is displayed.
4. Once you have finished, press [Back] to return
to the list.
Tip
• Your pictures are given file names which show the
time and date when the picture was taken.
Example:
The file name “13-05-03_12-34-56” is displayed for
the picture taken at 12:34:56 of 13th May 2003. The
file names of your pictures can be changed (p. 41).
Using the Timer
Taking a Picture with the Timer
1. In camera mode, press [Options].
The Options Menu is displayed.
2. Press or to select “Delay Timer”, then press
.
3. Press or to select “On”, then press .
“ ” appears on the screen and the phone returns
to camera mode.
4. Press to take the picture.
Delay timer begins.
10 seconds after the timer sound occurs, the camera
takes a picture, and sounds a tone.
Camera 36
Loading...
