Sharp DV-SR45U User Manual

DVD RECORDER
• Remote control (9HSNB006UD) with two “AA” size batteries
• Round Coaxial cable (9HSWPZ0901TM003)
• Audio/Video cables (9HSWX1E56B5-001)
• Operation Manual (9HS
1VMN20185)
• Quick Use Guide (9HS1VMN20228)
Operation Manual
Recording Playing discs EditingBefore you start Connections Getting started
Changing the SETUP menu
Others Español
Supplied Accessory
OPERATION MANUAL
Please read this Operation Manual carefully before using your DVD recorder.
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
