Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your SHARP
product.
DVD PLAYER
MODEL
DV-SL1200W
DV-SL2200W
OPERATION MANUAL
(DV-SL1200W)
(DV-SL2200W)
DV-SL1200W
DV-SL2200W
Special notes
WARNINGS:
I When the ON/STAND-BY button is set at STAND-BY position, mains voltage
is still present inside the unit. When the ON/STAND-BY button is set at
STAND-BY position, the unit may be brought into operation by remote control.
I This unit contains no user serviceable parts. Never remove covers unless
qualified to do so. This unit contains dangerous voltages, always remove
mains plug from the wall socket before any service operation and when not
in use for a long period.
I To prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, shall be placed on
the apparatus.
CAUTION:
I This product is classified as a CLASS 1 LASER product.
I Use of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure. As the laser
beam used in this compact disc player is harmful to the eyes, do not attempt
to disassemble the cabinet. Refer servicing to qualified personnel only.
Notes:
Copyright Information:
I Unauthorised copying, broadcast, public display, transmission, public
performance and rental (regardless of whether or not such activities
are for profit) of disc contents are prohibited by law.
I This system is equipped with copy protection technology that causes
Important Instruction
substantial degradation of images when the contents of a disc are
copied to a video tape.
Copy Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the DVD
disc are copied using a VCR, the copy protection code prevents the videotape
copy from playing normally.
Supply of this product does not convey a license nor imply any right to
distribute content created with this product in revenue-generating broadcast
systems (terrestrial, satellite, cable and/or other distribution channels),
revenue-generating streaming applications (via Internet, intranets and/or other
networks), other revenue-generating content distribution systems (pay-audio
or audio-on-demand applications and the like) or on revenue-generating
physical media (compact discs, digital versatile discs, semiconductor chips,
hard drives, memory cards and the like). An independent license for such
use is required. For details, please visit
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and
Thomson.
NOTE
Audio-visual material may consist of copyrighted works which must not be
recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
http://mp3licensing.com
Accessories
Please confirm that the following accessories are included.
I Please ensure that the equipment is positioned in a well ventilated area
II
and ensure that there is at least 10 cm (4") of free space along the sides,
top and back.
10 cm (4")
II
I Use the unit on a firm, level surface free from vibration.
II
II
I Keep the unit away from direct sunlight,
II
strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which
generate electrical noise.
II
I Do not place anything on top of the unit.
II
II
I Do not expose the unit to moisture, to temperatures higher than 60°C (140°F)
II
or to extremely low temperatures.
II
I If the unit does not work properly, disconnect the AC power lead from the
II
wall socket. Plug it back and turn on the unit.
II
I In case of an electrical storm, unplug the unit for safety.
II
II
I Hold the AC power plug by the head when removing it from the wall socket,
II
as pulling the lead can damage internal wires.
II
I The AC power plug is used as a disconnect device and shall always remain
II
readily operable.
II
I Do not remove the outer cover, as this may result in electric shock.
II
Refer internal service to your local SHARP service facility.
10 cm (4")
(DV-SL1200W)
15 cm (6")
10 cm (4")
II
I The ventilation should not be impeded by covering
II
the ventilation openings with items, such as
newspapers, tablecloths, curtains, etc.
II
I No naked flame sources, such as lighted candles, should be placed on the
II
apparatus.
II
I Attention should be drawn to the environmental aspects of battery disposal.
II
II
I This unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
II
Warning:
The voltage used must be the same as that specified on this unit. Using this
product with a higher voltage other than that which is specified is dangerous
and may result in a fire or other type of accident causing damage. SHARP will
not be held responsible for any damage resulting from use of this unit with a
voltage other than that which is specified.
H Care of DVD/CD discs
DVD/CD discs are fairly resistant to damage, however mistracking can occur
due to an accumulation of dirt on the disc surface. Follow the guidelines below
for maximum enjoyment from your DVD/CD collection and player.
II
I Do not write on either side of the disc, particularly the non-label side from
II
which signals are read. Do not mark this surface.
II
I Keep your discs away from direct sunlight, heat, and excessive moisture.
II
II
I Always hold the DVD/CDs by the edges. Fingerprints, dirt, or water on the
II
DVD/CDs can cause noise or mistracking. If a DVD/CD is dirty or does not
play properly, clean it with a soft, dry cloth, wiping straight out from the
centre, along the radius.
NO
YES
Correct
General Information
(DV-SL1200W)
4
DV-SL1200W
DV-SL2200W
Types of playable discs
The DVD player can play back discs bearing any of the following marks:
Disc type
DVD Video Disc
Video CD
Audio CD
CD-R/CD-RW (*1)
Or CD-R/CD-RW recorded in
JPEG format (*2)
®
DivX
Video disc
(*1): The CD-R/CD-RW may not be played back properly depending on the
recording equipment or the disc.
(*2): JPEG or JPG picture discs also play on this unit. However, pictures
General Information
may not be clear (depends on resolution and recording method).
I I
I For unplayable discs, see page 6.
I I
Types of playable DVD discs vary depending on the region. This unit can play
back only DVDs with the same region number as written on the back of the
unit.
(DV-SL1200W)
Disc contents
Audio and video
(movies)
Audio and video
(movies)
Audio
Audio, picture and video
Audio and video
(movies)
or
23or5
(DV-SL2200W)
or
23or5
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons
indicate the discs that can be used in the section.
... Indicates DVDs.
... Indicates video CDs.
... Indicates audio CDs.
... Indicates CD-R/RW with JPEG recording.
... Indicates
DivX® Video.
I Some operations may not be performed depending on discs even if they
are described in this manual.
I During operation, “Depending on the disc, this operation may be
prohibited” or “This operation cannot be performed” may be displayed on
the screen. This means that the operations described in this manual are
not possible.
Copyright Information:
I Unauthorised copying, broadcast, public display, transmission, public
performance and rental (regardless of whether or not such activities are for
profit) of disc contents are prohibited by law.
I This system is equipped with copy protection technology that causes
substantial degradation of images when the contents of a disc are copied to
a videotape.
I This system is protected by U.S. patents and other intellectual property
rights, the copyright for which belongs to Macrovision Corporation. The use
of Macrovision’s copy protection technology in the system is authorised by
Macrovision and is intended for home use only, unless otherwise authorised
in writing by Macrovision. Reverse engineering or disassembly is prohibited.
5
Description of discs
DV-SL1200W
DV-SL2200W
H Discs that cannot be played
II
I
DVDs without the region number on
II
the back of the unit or “ALL”.
I I
I DVDs with SECAM system
I I
I I
I DVD-ROM
I I
I I
I DVD-RAM
I I
I I
I DVD-Audio
I I
II
I The discs above cannot be played at all, or no sound is heard although
II
images appear on the screen or vice versa.
II
I You cannot play illegally produced discs.
II
Notes:
II
I A disc which has scratches or fingerprints may not play properly. Refer to
II
“Care of DVD/CD discs (page 4)” and clean the disc.
II
I Do not play the discs of special shapes (heart or octagon shaped) as they
II
can be ejected whilst rotating and cause injury.
I I
I CDG
I I
I I
I CDV
I I
I I
I Photo CD
I I
I I
I CD-ROM
I I
I I
I SACD
I I
II
Discs recorded in special formats, etc.
I
II
H Title, chapter and track
DVDs are divided into “titles” and “chapters”. If the disc has more than one
movie on it, each movie is a separate “title”. “Chapters” are subdivisions of
titles.
Title 1Title 2
Chapter 1
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Audio CDs consist of “tracks”.
A “track” is each tune on an audio CD.
Track 1 Track 2 Track 3 Track 4 Track 5
Note:
Title, chapter, or track numbers may not be recorded on some discs.
H Icons used on DVD discs
Check the icons on the DVD case before playing your discs.
Display
Region number
(playable area number)
352
Format recorded on the DVD
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV, and
letterbox size images on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV and
4:3 images with the side edges cut on the 4:3 size TV.
Type of subtitles recorded Recorded subtitle languages.
2
Language can be selected with the
SUBTITLE button.
Number of camera angles
2
Number of audio tracks and audio
recording systems
Example:
1: English
2: French
Example:
1: Original <English>
(DTS 5.1 Surround)
2: English (Dolby
Digital 5.1 Surround)
Description
DVD discs are programmed with
region numbers indicating countries
in which they can be played. This
system can play discs with region
number on the back of the unit.
To adopt the video format to the
connected TVs (“wide-screen TV” or
“4:3 size TV”).
Number of angles recorded on the
DVD.
Angles can be selected with the
ANGLE button.
The number of audio tracks and
audio recording systems are
indicated.
II
I The audio recorded on the DVD
II
can be switched by using the
AUDIO button.
II
I The number of audio tracks and
II
recording systems vary
depending on the DVD. Check
them in the DVD’s manual.
I Please refer to your TV instruction manual.
I When you connect the DVD player to your TV, be sure to turn off the power
and disconnect both units from the wall socket until all the connections have
been made.
I If your TV has one audio input socket, connect the AUDIO OUT sockets of
System Connections
the DVD player to a Y-cable adaptor (not supplied), then connect it to the TV
Audio input. Please consult your local audio/video dealer.
I Do not connect the DVD player to a VCR directly. The playback picture will
be distorted because DVD discs are copy protected.
Using the COMPONENT VIDEO OUT sockets
Notes:
Please follow the steps before turn on the power.
1. If your TV has the component video input sockets, connect the DVD player
to these sockets. (The VIDEO OUT socket connection is not necessary.)
You can enjoy high quality picture playback.
2. You also need to connect the left and right audio cables to the AUDIO OUT
sockets of DVD player and the Audio input sockets of the TV.
DVD player
(DV-SL1200W)
TV
COMPONENT VIDEO INPUT
Y
PBP
Blue
R
Red
Red
Blue
Green
Green
*Component video cable (not supplied)
System Connections
10
DV-SL1200W
DV-SL2200W
Connecting to a conventional TV (continued)Connecting to a conventional)
Using RF Modulator
If your TV does not have a Video input socket and has an aerial terminal only,
please purchase the *RF Modulator (not supplied).
(*Please consult your audio/video dealer.)
Example: DVD player, TV and RF Modulator connections
To AUDIO
OUT sockets
Audio/Video cable (supplied)
3
DVD player
(Red) R
To VIDEO OUT
socket (Yellow)
(White) L
RF Modulator
(DV-SL1200W)
System Connections
1. Connect the aerial cable (not supplied) to the ANT. IN terminal of the RF
Modulator.
2. Connect the 75-ohm coaxial cable (not supplied) between the TO TV
terminal of the RF Modulator and the VHF/UHF AERIAL IN terminal of the
TV.
3. Connect the Audio/Video cable (supplied) between the AUDIO OUT and
VIDEO OUT sockets of the DVD player and the AUDIO INPUT and VIDEO
INPUT sockets of the RF Modulator.
To video input
socket (Yellow)
To audio input
sockets
1
(Red) R
(White) L
TV
A/V INPUT
R-AUDIO-LVIDEO
TO TV
4
CHANNEL
34
ANT. IN
VHF/UHF
AERIAL
IN
2
4. Turn on the TV, and set the channel number (CHANNEL 3 or CHANNEL 4)
on both TV and RF Modulator, whichever is not used for regular broadcast
in your area.
Note:
For more details, please refer to the instruction manual of the RF Modulator.
System Connections
11
Example: DVD player, VCR, TV and RF Modulator connections
DV-SL1200W
DV-SL2200W
To AUDIO OUT
Audio/Video cable (supplied)
sockets
4
DVD player
To VIDEO OUT
socket (Yellow)
(DV-SL1200W)
(Red) R
(White) L
System Connections
1. Connect the aerial cable (not supplied) to the VHF/UHF FROM
AERIAL IN terminal of the VCR.
2. Connect the 75-ohm coaxial cable (not supplied) between the TO TV OUT
terminal of the VCR and the ANT. IN terminal of the RF Modulator.
3. Connect the 75-ohm coaxial cable (not supplied) between the TO TV
terminal of the RF Modulator and the VHF/UHF AERIAL IN terminal of the
TV.
To video input
RF Modulator
TV
To audio input
sockets
(Red) R
(White) L
1
socket (Yellow)
VHF/UHF
VHF/UHF
AERIAL
IN
A/V INPUT
2
ANT. INTO TV
R-AUDIO-LVIDEO
CHANNEL
34
5
5
34
CHANNEL
FROM ANT.
TO TV
IN
OUT
3
VCR
4. Connect the Audio/Video cable (supplied) between the AUDIO OUT and
VIDEO OUT sockets of the DVD player and the AUDIO INPUT and VIDEO
INPUT sockets of the RF Modulator.
5. Turn on the TV, and set the channel number (CHANNEL 3 or CHANNEL
4) on all TV, VCR and RF Modulator, whichever is not used for regular
broadcasts in your area.
Note:
For more details, please refer to the instruction manual of the RF Modulator.
System Connections
12
DV-SL1200W
DV-SL2200W
Connecting to a TV with progressive-scan capability
Your TV must be capable of handling progressive scanning and have component video input capability.
To COMPONENT VIDEO
OUT sockets
DVD player
(DV-SL1200W)
*Audio cable (supplied)
Red
(Red) R
(White) L
System Connections
1. Connect the DVD player to the component video input sockets of the TV.
(The VIDEO OUT sockets connection is not encourage.)
2. You also need to connect the left and right audio cables to the AUDIO OUT
sockets of DVD player and the Audio input sockets of the TV.
3. Set the DVD player to the PROGRESSIVE position. (See page 14)
Note:
Reset the component setting to INTERLACE using front panel controls.
I To perform reset function, see “Clearing all the memory (reset)” on page 49.
13
Blue
Green
R
LYPBP
AUDIO INPUT COMPONENT VIDEO INPUT
(Red) R
(White) L
*Component video cable (not supplied)
To COMPONENT VIDEO INPUT sockets
Blue
Green
To audio input
sockets
*Please consult your local audio/video dealer.
Red
R
TV with progressive-scan
capability
System Connections
Interlaced scanning
DV-SL1200W
DV-SL2200W
+
Progressive scanning
Progressive scanning
Whilst interlaced scanning produces one frame of video in two fields, progressive scanning creates one frame in one field.
Conventional interlaced scanning constitutes one second with 30 frames (60 fields), but progressive scanning constitutes it with 60 frames from scratch.
Progressive scanning can reproduce sharper picture with high resolution for still image or other picture containing long texts or horizontal lines.
This model has compliance with 576p (progressive) system.
Notes:
I Please refer to your TV instruction manual.
I When you connect the DVD player to your TV, be sure to turn off the power and disconnect both units from the wall socket until all the connections have been
made.
I Do not connect the DVD player to a VCR directly. The playback picture will be distorted because DVD video discs are copy protected.
System Connections
Notes:
I For VIDEO connection, please refer to “System Connections”.
I Please refer to the instruction manual of your amplifier.
I When you connect the DVD player to your amplifier, be sure to turn off the power and disconnect both units from the wall socket until all the connections
have been made.
\
System Connections
14
DV-SL1200W
DV-SL2200W
Additional connections
H Connecting to an Audio System and TV
Connect the DVD player to an Audio System and a TV.
DVD player
(DV-SL1200W)
System Connections
Notes:
I Please refer to the instruction manual of your Audio System and
TV.
I When you connect the DVD player to other equipment, be sure to
turn off the power and disconnect all of the equipment from the wall
socket until all the connections have been made.
I Do not connect the DVD player to a VCR directly. The playback
picture will be distorted because DVD discs are copy protected.
15
(Red) R
To AUDIO OUT sockets
*Audio cable
(supplied)
(White) L
To VIDEO OUT
socket (Yellow)
*Video cable
(supplied)
(White) L
(Red) R
To video input (Yellow)
R-AUDIO-L VIDEO
AUDIO
VIDEO
INPUT
1
To audio
input sockets
L
AUDIO
INPUT
R
* Please consult your local audio/video dealer.
TV with Audio/Video input sockets
Audio System
System Connections
H Connecting to an Amplifier with Dolby Digital Decoder or DTS Decoder
DV-SL1200W
DV-SL2200W
To digital audio input
*Coaxial audio cable
(not supplied)
To COAXIAL DIGITAL
OUT socket
(DV-SL1200W)
To enjoy Dolby Digital or DTS
System Connections
Select “On” in “Digital Out” on the “Digital Audio Out” (See page 23).
Amplifier with Dolby Digital Decoder, DTS Decoder or MPEG 2 Decoder
Centre speaker
Front left
speaker
Surround left
speaker
* Please consult your local audio/video dealer.
Front right
speaker
Surround
right speaker
Subwoofer
System Connections
16
