Sharp DV-SL10W, DV-SL10, DV-SL10X Schematic

e

SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS

(

Standard Notes

WARNING

Many electrical and mechanical parts in this chassis
have special characteristics. These characteristics often
pass unnoticed and the protection afforded by them
cannot necessarily be obtained by using replacement
components rated for higher voltage, wattage, etc.
Replacement parts that have these special safety
characteristics are identified in this manual and its
supplements; electrical components having such
features are identified by the mark " ! " in the schematic
diagram and the parts list. Before replacing any of these
components, read the parts list in this manual carefully.
The use of substitute replacement parts that do not
have the same safety characteristics as specified in the
parts list may create shock, fire, or other hazards.

Capacitor Temperature Markings

Mark

(B)
(F)

(SR)

(Z)

Capacity

change rate

±10%

+30 - 80%

±15%

+30 - 80%

Standard

temperature

20°C
20°C

20°C
20°C

Temperatur

range

-25~+85°C

-25~+85°C

-25~+85°C

-10~+70°C

Notes:

1. Do not use the part number shown on these draw­ings for ordering. The correct part number is shown
in the parts list, and may be slightly different or
amended since these drawings were prepared.

2. All resistance values are indicated in ohms (K=103,
M=106).

3. Resistor wattages are 1/4W or 1/6W unless other­wise specified.

4. All capacitance values are indicated in µF
(P=10-6 µF).

5. All voltages are DC voltages unless otherwise speci­fied.

6. Electrical parts such as capacitors, connectors, di­odes, IC's, transistors, resistors, switches, and fuses
are identified by four digits. The first two digits are
not shown for each component. In each block of the
diagram, there is a note such as shown below to
indicate these abbreviated two digits.

Capacitors and transistors are represented by the
following symbols.

CBA Symbols

(Top View) (Bottom View)

+

Electrolytic Capacitor

Bottom View)

Transistor or Digital Transistor

E C B

(Top View)

E C B

(Top View)

E C B

NPN Transistor

NPN Digital Transistor

(Top View)

E C B

(Top View)

E C B

PNP Transistor

PNP Digital
Transistor

Schematic Diagram Symbols

Digital Transistor

1-3-1

SC-FN2

LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING

1

".

".

3

2

1

PAGES:

1. CAUTION:

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE.

2. CAUTION:

Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, first check to see that all components in the power supply circuit are not defective

before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power
supply circuit to fail.

3. Note:

(1)Do not use the part number shown on the drawings for ordering. The correct part number is shown in the parts

list, and may be slightly different or amended since the drawings were prepared.

(2)To maintain original function and reliability of repaired units, use only original replacement parts which are listed

with their part numbers in the parts list section of the service manual.

4. Wire Connectors
(1)Prefix symbol “CN” means “connector” (can disconnect and reconnect).
(2)Prefix symbol “CL” means “wire-solder holes of the PCB” (wire is soldered directly).

5. Voltage indications for PLAY modes on the schematics are as shown below:

Unit: Volts

5.0

231

5.0

PLAY mode

Indicates that the voltage
is not consistent here.

6. How to read converged lines

-D3
Distinction Area

Line Number

(1 to 3 digits)

Examples:

1. "1-D3" means that line number "1" goes to area "D3

2. "1-B1" means that line number "1" goes to area "B1

7. Test Point Information

: Indicates a test point with a jumper wire across a hole in the PCB.
: Used to indicate a test point with a component lead on foil side.
: Used to indicate a test point with no test pin.

AREA D3

1-B1

AREA B1

1-D3

ABCD

: Used to indicate a test point with a test pin.

1-3-2

SC-FN2

DVD Main 2/3 Schematic Diagram (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

1-3-3

1-3-4 E5754SCD2

DVD Main 3/3 Schematic Diagram (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

Note:

*

IC103 is not supplied separately.
Be sure to replace with the DVD Main CBA unit when servicing IC103.

DVD MAIN 3/3

Ref No. Position

ICS
IC102 O-4
IC103 O-3
IC104 N-3
IC105 N-1
IC451 P-3
IC601 Q-1

CONNECTOR

CN601 R-1

1-3-5 1-3-6

E5754SCD3

AV 1/3 Schematic Diagram (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

CAUTION !

Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

CAUTION

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,
REPLACE ONLY WITH THE SAME TYPE FUSE.

NOTE :
The voltage for parts in hot circuit is measured
using hot GND as a common terminal.

AV 1/3

Ref No. Posi tion

ICS
IC1001 B-1
IC1002 D-4
IC1006 C-1

TRANSISTORS
Q1001 B-3
Q1002 D-3
Q1003 B-2
Q1004 E-3
Q1005 D-2
Q1006 D-1
Q1008 A-1
Q1010 D-2
Q1011 D-1
Q1012 D-2
Q1014 E-3
Q1015 D-2
Q1016 E-2
Q1050 D-3

CONNECTOR

CN1001 F-4

1-3-7 1-3-8

E5754SCAV1

AV 2/3 Schematic Diagram (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

1-3-9

1-3-10

AV 2/3

Ref No. Posi tion

ICS
IC1201 H-1
IC1402 I-3

TRANSISTORS
Q1201 J-1
Q1202 J-1
Q1203 I -2
Q1204 I -1
Q1351 K-4
Q1352 H-2

CONNECTOR

CN1601 G-3

E5754SCAV2

AV 3/3 & Function Schematic Diagram (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

7G 6G 5G 4G 3G 2G 1G
a
b
c
d
e

f

g

c
d
e
f
g

c
d
e

f

g

c
d
e

f

g

c
d
e

f

g

c
d
e

f

g

h

i

a
b

a
b

a
b

a
b

a
b

FL2001 MATRIX CHART

STANDBY

TITLE CHP. TRK. CD

V

PBC

DVD

REPEAT

A

-B

1

3

2

4

5

7G 5G 3G 1G4G6G 2G

STANDBY
REPEAT

A-B

TRK.CHP.TITLE

DVD

a

cb

VCD

d

PBC

ef

g

1

2

3

4

5

AV 3/3

Ref No. Position

ICS
IC2001 O-3
IC2002 P-2

TRANSISTOR

Q2007 P-2

CONNECTOR

JP2001 P-3

1-3-11 1-3-12

E5754SCAV3

AV CBA Top View (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

CAUTION !

Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

CAUTION

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,
REPLACE ONLY WITH THE SAME TYPE FUSE.

NOTE :
The voltage for parts in hot circuit is measured
using hot GND as a common terminal.

AV CBA

Ref No. Position

ICS
IC1001 C-2
IC1002 B-2
IC1006 C-2
IC1201 D-3
IC1204 E-2
IC1402 E-4
IC2001 A-2
IC2002 C-3

TRANSISTORS
Q1001 C-1
Q1002 B-1
Q1003 D-2
Q1004 B-2
Q1005 A-1
Q1006 A-1
Q1008 D-2
Q1010 A-1
Q1011 A-1
Q1012 A-1
Q1014 B-2
Q1015 A-1
Q1016 A-1
Q1050 B-1
Q1201 E-3
Q1202 E-3
Q1203 E-3
Q1204 E-3
Q1351 E-2
Q1352 D-2
Q2007 C-3

CONNECTORS

CN1001 B-4
CN1601 D-4
JP2001 A-4

1-3-13

1-3-14

BE5716F01011

AV CBA Bottom View (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

WF3

PIN 21 OF
IC1402

WF1

PIN 5 OF
CN1601

WF2

PIN 7 OF
CN1601

WF4

PIN 11 OF
CN1601

WF5

PIN 13 OF
CN1601

WF6

PIN 16 OF
CN1601

CAUTION !

Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

CAUTION

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,
REPLACE ONLY WITH THE SAME TYPE FUSE.

NOTE :
The voltage for parts in hot circuit is measured
using hot GND as a common terminal.

1-3-15

1-3-16

BE5716F01011

FUNCTION CBA Top View (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

FUNCTION CBA Bottom View (DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU))

1-3-17

1-3-18

BE5716F01011

WAVEFORMS ( DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU) )

WF1

Pin 5 of CN1601

VIDEO-Y 0.2V 20µsec

WF2 Pin 7 of CN1601

WF5

Pin 13 of CN1601

AUDIO-R

WF6

Pin 16 of CN1601

1V 0.5msec

NOTE:

Input
CD: 1kHz PLAY
(WF4~WF6)
DVD: POWER ON (STOP) MODE
(WF1~WF3)

VIDEO-C 0.2V 20µsec

WF3 Pin 21 of IC1402

VIDEO-CVBS 0.5V 20µsec

WF4

Pin 11 of CN1601

SPDIF

1V 0.1µsec

AUDIO-L

1V 0.5msec

1-4-1

1-4-2

E5754WF

VIDEO-Y
OUT

VIDEO-Cb
OUT

VIDEO-Cr
OUT

VIDEO
OUT

AUDIO-L
OUT

AUDIO-R
OUT

CN1001

WIRING DIAGRAM ( DV-SL10W, DV-SL10, DV-SL10X, DV-SL10(RU) )

DV-SL10X

DIGITAL
AUDIO OUT

S-VIDEO
OUT

2222

OPTICAL
AUDIO OUT

AV CBA

(BE5716F01011)

AC CORD

CN1601

JP2001 JP2002

K2 1

1

KEY-2 2

2

NU 3

3

NU 4

4

KEY-4 5

5

KEY-3 6

6

KEY-1 7

7

K1 8

8

FUNCTION CBA
(BE5716F01011)

FG
SENSOR

FG CBA

W1001

EV+1.5V 11

EV+1.5V 22

EV+3.3V 44

EV+3.3V 55

GND 66

GND 77

GND 88

GND 99

GND 1010

GND 1111

GND 1212

P-ON+5V 1313

EV+9V 1414

EV+9V 1515

FP-STB 1616

P-ON+3.3V 1717

FP-DIN 1818

EV+1.5V 33

CN401

PWRCON 1919

REMOTE

FP-DOUT 2020

FP-CLK 2121

W1601

AUDIO-L 1111

A-L-MUTE 1212

VIDEO-Cb 33

VIDEO-Y 55

VIDEO-Cr 11

GND 22

GND 66

GND 44

VIDEO-C 77

GND 88

CN601

GND 99

A-MUTE 1010

AUDIO-R 1313

SPDIF 1616

A-R-MUTE 1414

AUDIO+5V 1515

DVD MAIN CBA UNIT

CN201CN301

FG-IN
123

SP(-)7SP(+)

P-ON+3.3V(D)

TRAY-OUT

TRAY-IN

GND

4

5

6

8 SL(-)

9 SL(+)

SLED
MOTOR

M

SPINDLE
MOTOR

M

GND
123456789

VREF

P-ON+5VFE

CBD

A

PD-MONI

GND(LD)

CD/DVD

101112131415161718

DVD-LD

CD-LD

GND(DVD-PD)

TS(+)

FS(-)

FS(+)

TS(-)

GND(CD-PD)

19

20

FS

TS

TRAY-OUT

TRAY-IN

DRIVE CBA

1-5-1

DVD MECHA

11 2 3 5 6 4 7

DETECTOR

PICK UP UNIT

1-5-2

E5754WI

LEAD IDENTIFICATIONS

e

E C B

MM1567AJ

34

1

2SA1015-Y (TPE2)
KTA1266 (Y)
KTC3198 (Y)
2SC2120-Y(TPE2)
KTC3205 (Y)
2SC2236-Y-TPE6,C
2SA966(Y)

18

17

PT6313-S-TP

28

1

15

14

E C B

2SC2785 (H)
KTC3199 (GR)
KRA110M
KTA1267 (Y)
BN1L3Z (P)

MM1622XJBE

24

1

2SK3566

G D S

KIA431-AT

13

12

M34506M4-504FP

20

1

11

10

0C-0805T*002
GP1FA513TZ

123

PQ070XF01SZ

1234

1: Vin
2: Vo
3: GND
4: Vc

LTV-817(B,C)-F

A
K

NJM4558D
KIA4558P

8 5

1 4

K A R

C

E

Note:

A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Referenc
G: Gate
D: Drain
S: Source

1-6-1

E5753LE

Cabinet

1

EXPLODED VIEWS

2L011

Comparison Chart of
Models and Marks

Model Mark

DV-SL10S(G)
DV-SL10W
DV-SL10
DV-SL10X
DV-SL10S(Q)
DV-SL10S(S)
DV-SL10(RU)

A
B
C
D
E
F
G

FUNCTION CBA

A2

2L101

2L021

2L105

2L011

DVD Main
CBA Unit

W1001

2L021

W1601

2L031

AV CBA

2L011

2L031

2L031

A16

2L011

[ A,E,F ]

JK1401

2L011

JK1401

JK1404

JK1401

[ D ]

JK1404

JK1202

IC1204

[ B,C,G ]

JK1404

JK1202

JK1402

F1001

2L042

2B11

[ B,C,G ]

2B3

See Electrical Parts List
for parts with this mark.

Some Ref. Numbers are
not in sequence.

A1X

A13

2L021

1B1

A15

A17

A21

[ B,C,G ]

A13

[ D ]

2L071

[ A,E,F ]

[ B,C,D,G ]

AC100

2L041

2B23

1-7-1

E5753EX

Packing

[ B,C,D,G ]

X2

X4

X5

X10

Some Ref. Numbers are not in sequence.

S2

X1

S8

S4

Unit

S5

S2

Comparison Chart of
Models and Marks

Model Mark

DV-SL10S(G)
DV-SL10W
DV-SL10
DV-SL10X
DV-SL10S(Q)
DV-SL10S(S)
DV-SL10(RU)

A
B
C
D
E
F
G

S1

1-7-2

A22

A30

E5753EX

DIFFERENT PARTS FROM ORIGINAL MODEL (DV-SL10H)

PRODUCT SAFETY NOTE: Products marked with a ! have special characteristics important to safety. Before

replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade
the safety of the product through improper servicing.

NOTES:

1. Parts that not assigned part numbers (---------) are not available.

2. Tolerance of Capacitors and Resistors are noted with the following symbols.

C.....±0.25% D.....±0.5% F.....±1% G.....±2% J......±5% K.....±10%

M.....±20% N.....±30% Z.....+80/-20%

DV-SL10S(G)

Ref. No. Description Part No. Code

A21! LABEL, RATING E5753ED ---------- --­A22 LABEL, BAR CODE E5753ED ---------- --­A30 CASE MARK LABEL E5753ED ---------- --­S1 GIFT BOX CARTON E5753ED 9HS0VM306277 AV
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X10! OWNER'S MANUAL E5753ED 9HS0VMN03661 AH
X17 Not Used

DV-SL10W

Ref. No. Description Part No. Code
Mechanical Parts

2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E5754HD 9HS0VM204230 AK
A21! LABEL, RATING E5754HD ---------- --­A22 LABEL, BAR CODE E5754HD ---------- --­A30 CASE MARK LABEL E5754HD ---------- --­S1 GIFT BOX CARTON E5754HD 9HS0VM306332 AN
X5 AV CORD 9HSX1E56B5-001 AL
X10! OWNER'S MANUAL E5754HD 9HS0VMN03662 AG
X17 Not used

Electrical Parts

DVD MAIN CBA UNIT 9HSN79SFGHP
CN601 FFC/FPC CONNECTOR, 16P 04 6232 116 103 800 9HSC62D16TM003 AE
CN601 FFC/FPC CONNECTOR, 16P 10008HR-16 9HSCHRD16YEE02 --­IC102 IC(SDRM) P2V64S50DTP-75 9HSSZBA0R0M002 AZ
IC102 IC(SDRM) 2X32Y3VTW-6 9HSSZBA0R3S001 AX
L616 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R608 Not Used

AV CBA ASSEMBLY 9HS0VSA14186 BW

AV CBA 9HS0VSA14186A ---

FUNCTION CBA 9HS0VSA14186B ---

AV CBA 9HS0VSA14186A --­2B11 HEATSINK E5717QD 9HS0VM415264 AD
2L042 SCREW, S-TIGHT M3X8 BIND + CHROME 9HSGBMS3080 --­C1004 ELECTROLYTIC CAP. 100µF/400V M 9HSA2H101NC084 --­C1007 ELECTOLYTIC CAP. 1000µF/6.3V M(105C) 9HSE0KMASDH102 ---
C1010 Not used
C1017 Not used
C1035 ELECTROLYTIC CAP. 470µF/16V M(105C) 9HSE1CMASTH471 ---
C1070 Not used

1-8-1

E5753PL

Ref. No. Description Part No. Code

C1486 Not used
C1487 Not used
C1491 Not used
C1492 Not used
C1533 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1434 Not used
C1435 Not used
CN1601 FMN CONNECTOR, TOP 16P 16FMN-BTK 9HSCFNG16JG001 AD
CN1601 FFC/FPC CONNECTOR, 16P 00 6232 016 000 800 9HSC62G16TM009 --­CN2101 Not used
D1070 ZENER DIODE DZ-33BSDT265 9HSDTD00DZ33BS --­D1070 ZENER DIODE MTZJT-7733D 9HSDTD00MTZJ33 --­D1072 Not used
D1073 SWITCHING DIODE 1N4148M 9HSDTZ01N4148M --­D1073 SWITCHING DIODE 1SS133(T-77) 9HSDTZ001SS133 --­D1074 Not used
D1075 Not used
D1201 Not used
D1202 Not used
D1203 Not used
D1204 Not used
D1401 Not used
D1402 Not used
D1501 Not used
D1502 Not used
D1503 Not used
D1504 Not used
D1505 Not used
D1506 Not used
D1507 Not used
IC1401 Not used
IC1402 DRIVER FOR DVD MM1622XJBE 9HSSZBA0TMM085 AL
JK1202 RCA JACK(BLACK) MSP-251V-01 NI 9HSXRL010LY070 AC
JK1402 Not used
JK1404 RCA JACK MSD-246V-65NI/PBSN 9HSXRL060LY069 AG
JP2001 PARALLEL WIRE (8P)250MM WX1E57S0-003 9HSX1E57S0-003 AF
L1405 Not used
L1441 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1461 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1462 Not used
L1481 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1482 Not used
L1492 Not used
L1522 CHIP BEAD MMZ1608R102CT 9HSL06001TE002 --­L1522A Not used
Q1003 TRANSISTOR KTC3199(BL) 9HSQS50KTC3199 --­Q1003 TRANSISTOR 2SC2785(K) 9HSQSK02SC2785 --­Q1003 TRANSISTOR 2SC1815-BL(TPE2) 9HSQS202SC1815 --­Q1050 Not used
Q1521 Not used
Q1522 Not used
R1005 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1006 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1008 CARBON RES. 1/4W J 910 Ω 9HSCX4JATZ0911 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8ZU001 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8KE009 ---
R1015 Not used
R1016 Not used
R1023 CHIP RES. 1/16W F 3.9k Ω 9HSRXGFR5Z0392 ---
R1023 CHIP RES.(1608) 1/10W F 3.9k Ω 9HSRXAFR5Z3901 ---

1-8-2

E5753PL

Ref. No. Description Part No. Code

R1029 CARBON RES. 1/4W J 470k Ω 9HSCX4JATZ0474 ---
R1034 PCB JUMPER D0.6-P5.0 9HSJW5.0T --­R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154ZU001 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154KE010 ---
R1097 Not used
R1098 Not used
R1256 Not used
R1257 Not used
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
T1001! POWER TRANSFORMER CSA-SW0308A 9HSTT00ZPSA144 AH
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used

FUNCTION CBA 9HS0VSA14186B --­SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---

DV-SL10

Ref. No. Description Part No. Code

Mechanical Parts

2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E5754HD 9HS0VM204230 AK
A21! LABEL, RATING E5755PD ---------- --­A22 LABEL, BAR CODE E5755PD ---------- --­A30 CASE MARK LABEL E5755PD ---------- --­S1 GIFT BOX CARTON E5755PD 9HS0VM306333 AM
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X5 AV CORD 9HSX1E56B5-001 AL
X10! OWNER'S MANUAL E5754HD 9HS0VMN03662 AG
X17 Not used

Electrical Parts

DVD MAIN CBA UNIT 9HSN79SFGHP
CN601 FFC/FPC CONNECTOR, 16P 04 6232 116 103 800 9HSC62D16TM003 AE
CN601 FFC/FPC CONNECTOR, 16P 10008HR-16 9HSCHRD16YEE02 --­IC102 IC(SDRM) P2V64S50DTP-75 9HSSZBA0R0M002 AZ
IC102 IC(SDRM) 2X32Y3VTW-6 9HSSZBA0R3S001 AX
L616 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R608 Not Used

AV CBA ASSEMBLY 9HS0VSA14189 BW

1-8-3

E5753PL

Ref. No. Description Part No. Code

AV CBA 9HS0VSA14189A ---

FUNCTION CBA 9HS0VSA14189B ---

AV CBA 9HS0VSA14189A ---

AC1001! AC CORD PE8G2CG9G0A-055 9HSAE0162LW001 AG
2B11 HEATSINK E5717QD 9HS0VM415264 AD
2L042 SCREW, S-TIGHT M3X8 BIND + CHROME 9HSGBMS3080 --­C1004 ELECTROLYTIC CAP. 100µF/400V M 9HSA2H101NC084 --­C1007 ELECTOLYTIC CAP. 1000µF/6.3V M(105C) 9HSE0KMASDH102 ---
C1010 Not used
C1017 Not used
C1035 ELECTROLYTIC CAP. 470µF/16V M(105C) 9HSE1CMASTH471 ---
C1070 Not used
C1486 Not used
C1487 Not used
C1491 Not used
C1492 Not used
C1533 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1434 Not used
C1435 Not used
CN1601 FMN CONNECTOR, TOP 16P 16FMN-BTK 9HSCFNG16JG001 AD
CN1601 FFC/FPC CONNECTOR, 16P 00 6232 016 000 800 9HSC62G16TM009 --­CN2101 Not used
D1070 ZENER DIODE DZ-33BSDT265 9HSDTD00DZ33BS --­D1070 ZENER DIODE MTZJT-7733D 9HSDTD00MTZJ33 --­D1072 Not used
D1073 SWITCHING DIODE 1N4148M 9HSDTZ01N4148M --­D1073 SWITCHING DIODE 1SS133(T-77) 9HSDTZ001SS133 --­D1074 Not used
D1075 Not used
D1201 Not used
D1202 Not used
D1203 Not used
D1204 Not used
D1401 Not used
D1402 Not used
D1501 Not used
D1502 Not used
D1503 Not used
D1504 Not used
D1505 Not used
D1506 Not used
D1507 Not used
IC1401 Not used
IC1402 DRIVER FOR DVD MM1622XJBE 9HSSZBA0TMM085 AL
JK1202 RCA JACK(BLACK) MSP-251V-01 NI 9HSXRL010LY070 AC
JK1402 Not used
JK1404 RCA JACK MSD-246V-65NI/PBSN 9HSXRL060LY069 AG
JP2001 PARALLEL WIRE (8P)250MM WX1E57S0-003 9HSX1E57S0-003 AF
L1405 Not used
L1441 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1461 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1462 Not used
L1481 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1482 Not used
L1492 Not used
L1522 CHIP BEAD MMZ1608R102CT 9HSL06001TE002 --­L1522A Not used
Q1003 TRANSISTOR KTC3199(BL) 9HSQS50KTC3199 --­Q1003 TRANSISTOR 2SC2785(K) 9HSQSK02SC2785 ---

1-8-4

E5753PL

Ref. No. Description Part No. Code

Q1003 TRANSISTOR 2SC1815-BL(TPE2) 9HSQS202SC1815 --­Q1050 Not used
Q1521 Not used
Q1522 Not used
R1005 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1006 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1008 CARBON RES. 1/4W J 910 Ω 9HSCX4JATZ0911 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8ZU001 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8KE009 ---
R1015 Not used
R1016 Not used
R1023 CHIP RES. 1/16W F 3.9k Ω 9HSRXGFR5Z0392 ---
R1023 CHIP RES.(1608) 1/10W F 3.9k Ω 9HSRXAFR5Z3901 ---
R1029 CARBON RES. 1/4W J 470k Ω 9HSCX4JATZ0474 ---
R1034 PCB JUMPER D0.6-P5.0 9HSJW5.0T --­R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154ZU001 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154KE010 ---
R1097 Not used
R1098 Not used
R1256 Not used
R1257 Not used
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
T1001! POWER TRANSFORMER CSA-SW0308A 9HSTT00ZPSA144 AH
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used

FUNCTION CBA 9HS0VSA14186B ---

SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---

DV-SL10X

Ref. No. Description Part No. Code
Mechanical Parts

2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E5756AD 9HS0VM204231 AR
A21! LABEL, RATING E5756AD ---------- --­A22 LABEL, BAR CODE E5756AD ---------- --­A30 CASE MARK LABEL E5756AD ---------- --­S1 GIFT BOX CARTON E5756AD 9HS0VM306334 AV
S2 STYROFOAM E5714BD 9HS0VM101289 AE

1-8-5

E5753PL

Ref. No. Description Part No. Code

X5 AV CORD 9HSX1E56B5-001 AL
X10! OWNER'S MANUAL E5756AD 9HS0VMN03664 AH
X17 Not used

Electrical Parts

DVD MAIN CBA UNIT 9HSN79SGGAP

CN601 FFC/FPC CONNECTOR, 16P 04 6232 116 103 800 9HSC62D16TM003 AE
CN601 FFC/FPC CONNECTOR, 16P 10008HR-16 9HSCHRD16YEE02 --­IC102 IC(SDRM) P2V64S50DTP-75 9HSSZBA0R0M002 AZ
IC102 IC(SDRM) 2X32Y3VTW-6 9HSSZBA0R3S001 AX
L616 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R608 Not Used

AV CBA ASSEMBLY 9HS0VSA14247 BW

AV CBA 9HS0VSA14247A ---

FUNCTION CBA 9HS0VSA14247B ---

AV CBA 9HS0VSA14247A ---

AC1001! AC CORD PS8B5S4980A-065 9HSAA0192LW006 AE
C1004 ELECTROLYTIC CAP. 33µF/400V M(L•Z) 9HSE2HMZATH330 --­C1004 ELECTROLYTIC CAP. 33µF/400V M 9HSA2H330S6021 ---
C1004 ELECTROLYTIC CAP. 33µF/400V M(105C) 9HSA2H330NC162 ---
C1007 ELECTOLYTIC CAP. 1000µF/6.3V M(105C) 9HSE0KMASDH102 ---
C1010 CERAMIC CAP.(AX) CH J 560PF/50V 9HSA1J561TU008 --­C1017 Not used
C1035 ELECTROLYTIC CAP. 470µF/16V M(105C) 9HSE1CMASTH471 ---
C1070 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1361 ELECTROLYTIC CAP. 22µF/6.3V M 9HSE0KMASDL220 --­C1362 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1486 Not used
C1487 Not used
C1491 Not used
C1492 Not used
C1533 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1434 Not used
C1435 Not used
CN1601 FMN CONNECTOR, TOP 16P 16FMN-BTK 9HSCFNG16JG001 AD
CN1601 FFC/FPC CONNECTOR, 16P 00 6232 016 000 800 9HSC62G16TM009 --­CN2101 Not used
D1072 ZENER DIODE DZ-10BSBT265 9HSDTB00DZ10BS --­D1072 ZENER DIODE MTZJT-7710B 9HSDTB00MTZJ10 --­D1073 PCB JUMPER D0.6-P5.0 9HSJW5.0T --­D1074 Not used
D1075 Not used
D1201 Not used
D1202 Not used
D1203 Not used
D1204 Not used
D1401 Not used
D1402 Not used
D1501 Not used
D1502 Not used
D1503 Not used
D1504 Not used
D1505 Not used
D1506 Not used
D1507 Not used
IC1204 FIBER OPTIC TRANS.MODULE 0C-0805T*002 9HSWHHA00JD002 AL
IC1204 FIBER OPTIC TRANS.MODULE GP1FA513TZ 9HSWHHA00SH005 AK
IC1401 Not used
IC1402 DRIVER FOR DVD MM1622XJBE 9HSSZBA0TMM085 AL

1-8-6

E5753PL

Ref. No. Description Part No. Code

JK1202 RCA JACK(BLACK) MSP-251V-01 NI 9HSXRL010LY070 AC
JK1402 Not used
JK1404 RCA JACK MSD-246V-65NI/PBSN 9HSXRL060LY069 AG
JP2001 PARALLEL WIRE (8P)250MM WX1E57S0-003 9HSX1E57S0-003 AF
L1405 Not used
L1441 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1461 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1462 Not used
L1481 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1482 Not used
L1492 Not used
L1522 CHIP BEAD MMZ1608R102CT 9HSL06001TE002 --­L1522A Not used
Q1003 TRANSISTOR KTC3199(GR) 9HSQS10KTC3199 --­Q1003 TRANSISTOR 2SC2785(H) 9HSQSH02SC2785 --­Q1521 Not used
Q1522 Not used
R1011 METAL OXIDE FILM RES. 1W J 2.2 Ω 9HSN012R2ZU001 ---
R1011 METAL OXIDE FILM RES. 1W J 2.2 Ω 9HSN012R2KE009 ---
R1023 CHIP RES. 1/16W F 3.9k Ω 9HSRXGFR5Z0392 ---
R1023 CHIP RES.(1608) 1/10W F 3.9k Ω 9HSRXAFR5Z3901 ---
R1029 CARBON RES. 1/4W J 390k Ω 9HSCX4JATZ0394 ---
R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 --­R1095 CARBON RES. 1/4W J 1.5M Ω 9HSCX4JATZ0155 ---
R1256 Not used
R1257 Not used
R1361 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1366 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used

FUNCTION CBA 9HS0VSA14186B ---

SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---

1-8-7

E5753PL

DV-SL10S(Q)

Ref. No. Description Part No. Code
Mechanical Parts

A21! LABEL, RATING E5758FD ---------- --­A22 LABEL, BAR CODE E5758FD ---------- --­A30 CASE MARK LABEL E5758FD ---------- --­S1 GIFT BOX CARTON E5753ED 9HS0VM306277 AV
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X10! OWNER'S MANUAL E5758FD 9HS0VMN03703 AG
X17 Not used

Electrical Parts

AV CBA ASSEMBLY 9HS0VSA14106 BW

AV CBA 9HS0VSA14106A ---

FUNCTION CBA 9HS0VSA14106B ---

AV CBA 9HS0VSA14106A ---

AC1001! AC CORD PE8G2CG9G0A-055 9HSAE0162LW001 AG

DV-SL10S(S)

Ref. No. Description Part No. Code
Mechanical Parts

A21! LABEL, RATING E57B2ED ---------- --­A22 LABEL, BAR CODE E57B2ED ---------- --­A30 CASE MARK LABEL E57B2ED ---------- --­S1 GIFT BOX CARTON E5753ED 9HS0VM306277 AV
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X10! OWNER'S MANUAL E57B2ED 9HS0VMN03706 AG
X17 Not used

Electrical Parts

AV CBA ASSEMBLY 9HS0VSA14106 BW

AV CBA 9HS0VSA14106A ---

FUNCTION CBA 9HS0VSA14106B ---

AV CBA 9HS0VSA14106A ---

AC1001! AC CORD PE8G2CG9G0A-055 9HSAE0162LW001 AG

DV-SL10(RU)

Ref. No. Description Part No. Code
Mechanical Parts

2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E57B5RD 9HS0VM204232 AR
A21! LABEL, RATING E57B5RD ---------- --­A22 LABEL, BAR CODE E57B5RD ---------- --­A30 CASE MARK LABEL E57B5RD ---------- --­S1 GIFT BOX CARTON E57B5RD 9HS0VM306336 AV
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X5 AV CORD 9HSX1E56B5-001 AL
X10! OWNER'S MANUAL E57B5RD 9HS0VMN03709 AH
X17 Not used

Electrical Parts

DVD MAIN CBA UNIT 9HSN79SHGRP

CN601 FFC/FPC CONNECTOR, 16P 04 6232 116 103 800 9HSC62D16TM003 AE
CN601 FFC/FPC CONNECTOR, 16P 10008HR-16 9HSCHRD16YEE02 --­IC102 IC(SDRM) P2V64S50DTP-75 9HSSZBA0R0M002 AZ
IC102 IC(SDRM) 2X32Y3VTW-6 9HSSZBA0R3S001 AX
L616 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R608 Not Used

1-8-8

E5753PL

Ref. No. Description Part No. Code

AV CBA ASSEMBLY 9HS0VSA14189 BW

AV CBA 9HS0VSA14189A ---

FUNCTION CBA 9HS0VSA14189B ---

AV CBA 9HS0VSA14189A ---

AC1001! AC CORD PE8G2CG9G0A-055 9HSAE0162LW001 AG
2B11 HEATSINK E5717QD 9HS0VM415264 AD
2L042 SCREW, S-TIGHT M3X8 BIND + CHROME 9HSGBMS3080 --­C1004 ELECTROLYTIC CAP. 100µF/400V M 9HSA2H101NC084 --­C1007 ELECTOLYTIC CAP. 1000µF/6.3V M(105C) 9HSE0KMASDH102 ---
C1010 Not used
C1017 Not used
C1035 ELECTROLYTIC CAP. 470µF/16V M(105C) 9HSE1CMASTH471 ---
C1070 Not used
C1486 Not used
C1487 Not used
C1491 Not used
C1492 Not used
C1533 CHIP CERAMIC CAP. F Z 0.1µF/50V 9HSHD1JZ30F104 --­C1434 Not used
C1435 Not used
CN1601 FMN CONNECTOR, TOP 16P 16FMN-BTK 9HSCFNG16JG001 AD
CN1601 FFC/FPC CONNECTOR, 16P 00 6232 016 000 800 9HSC62G16TM009 --­CN2101 Not used
D1070 ZENER DIODE DZ-33BSDT265 9HSDTD00DZ33BS --­D1070 ZENER DIODE MTZJT-7733D 9HSDTD00MTZJ33 --­D1072 Not used
D1073 SWITCHING DIODE 1N4148M 9HSDTZ01N4148M --­D1073 SWITCHING DIODE 1SS133(T-77) 9HSDTZ001SS133 --­D1074 Not used
D1075 Not used
D1201 Not used
D1202 Not used
D1203 Not used
D1204 Not used
D1401 Not used
D1402 Not used
D1501 Not used
D1502 Not used
D1503 Not used
D1504 Not used
D1505 Not used
D1506 Not used
D1507 Not used
IC1401 Not used
IC1402 DRIVER FOR DVD MM1622XJBE 9HSSZBA0TMM085 AL
JK1202 RCA JACK(BLACK) MSP-251V-01 NI 9HSXRL010LY070 AC
JK1402 Not used
JK1404 RCA JACK MSD-246V-65NI/PBSN 9HSXRL060LY069 AG
JP2001 PARALLEL WIRE (8P)250MM WX1E57S0-003 9HSX1E57S0-003 AF
L1405 Not used
L1441 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1461 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1462 Not used
L1481 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­L1482 Not used
L1492 Not used
L1522 CHIP BEAD MMZ1608R102CT 9HSL06001TE002 --­L1522A Not used

1-8-9

E5753PL

Ref. No. Description Part No. Code

Q1003 TRANSISTOR KTC3199(BL) 9HSQS50KTC3199 --­Q1003 TRANSISTOR 2SC2785(K) 9HSQSK02SC2785 --­Q1003 TRANSISTOR 2SC1815-BL(TPE2) 9HSQS202SC1815 --­Q1050 Not used
Q1521 Not used
Q1522 Not used
R1005 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1006 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1008 CARBON RES. 1/4W J 910 Ω 9HSCX4JATZ0911 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8ZU001 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8KE009 ---
R1015 Not used
R1016 Not used
R1023 CHIP RES. 1/16W F 3.9k Ω 9HSRXGFR5Z0392 ---
R1023 CHIP RES.(1608) 1/10W F 3.9k Ω 9HSRXAFR5Z3901 ---
R1029 CARBON RES. 1/4W J 470k Ω 9HSCX4JATZ0474 ---
R1034 PCB JUMPER D0.6-P5.0 9HSJW5.0T --­R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154ZU001 --­R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154KE010 ---
R1097 Not used
R1098 Not used
R1256 Not used
R1257 Not used
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 --­R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 --­R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
T1001! POWER TRANSFORMER CSA-SW0308A 9HSTT00ZPSA144 AH
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used

FUNCTION CBA 9HS0VSA14186B ---

SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---

1-8-10

E5753PL

DV-SL10S(G)/DV-SL10W/DV-SL10/DV-SL10X/DV-SL10S(Q)/DV-SL10S(S)/DV-SL10(RU)

COPYRIGHT © 2003 BY SHARP CORPORATION

ALL RIGHTS RESERVED.

No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.

Jul. 2003 Printed in JAPAN

SHARP CORPORATION
AV Systems Group
Quality & Reliability Control Center
Yaita, Tochigi 329-2193, Japan

1
