Date: Jun. 24,1998
DUPLICATOR: SD-2275
1. Change of quantity of screws used in the paper
discharge section (for better productivity)
2. Screw crimping countermeasure in the transfer
section (for better productivity)
3. Change of part material and shape in the duplex
section (for better productivity)
1. Change of quantity of screws used in the paper
discharge section (for better productivity)
No. : DTE-379
1. Model Name: SD-2060/2260/2275
2. General: For better productivity, two screws which fasten the paper discharge frame T in the paper
discharge section are changed to one screw which fastens the center.
3. Action: From the middle of the production in May, 1998(Running change)
SHARP CORPORATION Reprography Division
1/3
Green
C
2. Screw crimping countermeasure in the transfer section
(for better productivity)
1. Model Name: SD-2060/2260/2275/3062
2. General: For better productivity, the screws which fasten the lens and the paper guide rotary plate R on
the transfer frame in the transfer section are abolished, and the crimping (press-fitting) method
is employed.Moreover, the material of the transfer stay RA is changed.
3. Action: From the middle of the production in May, 1998(Running change)
3. Change of part material and shape in the duplex section
(for better productivity)
1. Model Name: SD-2060/3062/2260/2275
2. General: For better productivity, the material and shape are changed on some parts in the duplex
section.
For the changed parts and the change content, refer to the parts list.
3. Action: From the middle of the production in May, 1998(Running change)
2/3
Ref.
Model
No.
name
SD-2060
SD-2260
2275
1
SD-2060 16
SD-2260
2275
SD-2060
3062
SD-2260
2275
SD-2060
3062
2
SD-2260
2275
SD-2060
3062
SD-2260
2275
SD-2060
3062
SD-2260
2275
SD-2060
3062
SD-2260
2275
SD-2060
3062
3
SD-2260
2275
SD-2060
3062
SD-2260
2275
SD-2060
3062
SD-2260
2275
Version P/G No.
16 - 18
17 - 18
17
15 - 70
16 - 70
15 - 141
16 - 141
15 - 47
16 - 47
ALL
31 - 49
30 - 49
31 - 91
30 - 91
32 - 39
31 - 39
32 - 36
31 - 36
32 - 37
31 - 37
Current parts New parts
Parts code
LFRM-0790FCZZ LFRM-0790FCZ1 AV
LX-BZ0320FCZZ
(Quantity 4)
CFRM-0759FC01 CFRM-0759FC02
CFRM-0758FC01 CFRM-0758FC02
LSTYM0193FCZZ LSTYM0193FCZ1
LPLTM4278FCZZ LPLTM4278FCZ1
TLABZ3416FCZZ TLABZ4311FCZZ
CPLTM4269FC03 CPLTM4269FC04
NGERH0612FCZZ NGERH1228FCZZ
NBRGC0344FCZZ NBRGY1032HCZZ
Parts code
LX-BZ0320FCZZ
(Quantity 2)
Price
Parts name
rank
Delivery
Frame T
AA Screw(M4X6)
Transport
Frame R
AX
Transport
Frame F
Transfer
Stay RA
AP
Dunacc Fixing
Plate L
AC NO.label K
AT Fixing Plate
AD Belt gear
AB Bearing
Effec-
tive
time
Mid-
’98/5
Inter-
change-
ability
5
1
Note
Material
change
Vendor
change
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones
for maintaining the safety and performance of the set.
5. Interchangeable if replaced with same types of related
parts in use.
6. Others.
3/3
