Date: Feb. 18, 1994
DUPLICATOR: SD-2075
No. : DTE-122
[Service information]
1. TROUBLE SHOOTING RDH JAMS.
2. CHANGE IN THE SCANNER CONTROL ROM
(OPD06 JAM T ROUB L E SHO OTING).
1. Trouble shooting RDH JAMs.
1.Model name: SD-2075 / 3076 / 3075
2.General: The shaft socket of the clutch gear area of the clutch used by the RDH sometimes
becomes disengaged, disrupting the clutch and causing an RDH timing jam. In
particular, when the OTRC2 is disrupted a OPD06JAM error occurs.
Note: Concerning the OTRC2 of model SD-3076 / 3075, the construction of the clutch
shaft socket is different and does not become disengaged.
3.Cause: The friction created by the spinning of the clutch shaft causes thermal expansion of the
plastic gears, the shaft socket disengages, and disruption occurs.
Clutch gear.
Shaft socket.This shaft socket disengages.
Armature plate.
Clutch gear.
Shaft socket, changed to a single unit.
4.Description:
Machine.
Shaft socket.
The quantity of shaft sockets employed in the clutch area has been changed from 2 to 1.
Armature plate.
Machine.
The parts code of the clutch has also been changed in accordance with the changes
described above. The clutch label has been changed from blue to red.
SHARP CORPORATION Reprography Division
1/3
Green
C
OR Resistance clutch 1:
PCLC-0178FCZZ → PCLC-0178FCZ1 ORRC, OTRC2, ORC1 SD- 2075
OR Belt clutch :
PCLC-0183FCZZ → PCLC-0183FCZ1 OBC, OHC1, OHC2 SD- 2075
OR Stopper Clutch 1:
PCLC-0180FCZZ → PCLC-0180FCZ1 OSC1, OSC2, ORC2 SD- 2075
Note 1. J ams can happen when the clutches underlined above have problems.
2. There can be clutch problems when there is no clutch gap (except for the OHC1
and OHC2)
3. Please check when the clutch gap is cold.
4. The new clutch bearing looks smaller because there is no spar.
5.Action: (Factory action)
Model SD-2075: Service parts only.
Model SD-3076 / 3075: From 1993 October production.
Employment location: (RDH unit).
3076
3075
2. Change in the scanner control ROM.
1.Model name: SD-3076 / 3075
2.General: The scanner control PWB ROM has been changed as a trouble shooting measure for
OPD06 JAMs. (Measures for the slave ROM have already been carried out from the
start of mass production. This change thus effects a double protection.)
3.Description: Fluctuations in the fixed revolutions of the mirror motor or RDH motor caused by
changes in the load of the switch back clutch related to OPD06 are decreased.
(A sample of the motor revolution fluctuations caused by load deviations is taken.
These interval and rotation samples are checked much more carefully than in the past,
and are used for feedback data for the motor revolution control.)
ROM: 0DM4A03927KA/ 0DM4A03927KC/
(Ver. 04) (Ver. 05)
PWB: CPWBN0948FC31 CPWBN0948FC32
4.Action: (Factory action)
From 1993 November production.
2/3
Ref.
No.
1
Model
name
SD-2075
SD-2075
3076
3075
Version P/G No.
39 -22
40 -7
41 -17
41 -7
42 -29
All
40 -18
41 -11
Current parts New parts
Parts code Parts code
Price
rank
PCLC-0178FCZZ PCLC-0178FCZ1 BD
Parts name
OR Resistance
clutch 1
Effec-
tive
time
Service
parts.
Inter-
change-
ability
3 Q’ty: 3
Note
PCLC-0183FCZZ PCLC-0183FCZ1 BD OR Belt clutch 3 Q’ty: 3
PCLC-0180FCZZ PCLC-0180FCZ1 BA
OR Stopper
clutch 1
’93/10 3 Q’ty: 3
ROM
(HN27C256GJ-20)
’93/11
Scanner Control
PWB
2
SD-3076
3075
58 -11 0DM4A03927KA/ 0DM4A03927KC/ BQ
33 -38
CPWBN0948FC31 CPWBN0948FC32 CE
58 -901
<Interchange>
1. Interchang ea ble. 4. N ot i nt er ch an ge ab l e.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with “ ” is important for maintaining the safety of the set. Be sure to replace these parts with
speci fied ones fo r m ai n ta ini ng t he s a fe ty an d pe r fo rma nc e o f the set .
!
5. Interchangeable if replaced with same types of
relate d parts in use .
6. Others .
3 IC615
6
3/3
