Sharp DS 24D User Manual

TABLE OF CONTENTS

ABOUT THIS BOOK ..........................................................1

THINGS YOU SHOULD KNOW ............................2–5

OUTSIDE CALLS

Making an Outside Call ......................................................................6

Answering an Outside Call..................................................................6

Universal Answer ................................................................................6

Recall Dial Tone ..................................................................................7

Sending a Flash ..................................................................................7

Busy Line Queuing with Callback ......................................................7

Canceling Callback..............................................................................7

INTERCOM CALLS

Calling Other Stations..........................................................................8

Answering Intercom Calls....................................................................8

Voice Announce Mode

........................................................................8

Auto Answer Mode ..............................................................................8

Busy Station Callback ........................................................................9

Busy Station Camp-on

........................................................................9

Calling Your System Operator ............................................................9

CALL PROCESSING

Holding Calls................................................................................10–11

Transferring Calls ........................................................................12–13

Transfer with Camp-On......................................................................12

Transfer to Voice Mail ........................................................................13

Call Waiting........................................................................................13

Conference Calls ..............................................................................13

orwarding Calls..........................................................................14–16

Call Pickup ........................................................................................16

Group Call Pickup ............................................................................16

SAMSUNG DS 616 SYSTEM

June 2004

DS 24D

KEYSET USER GUIDE

Samsung Telecommunications America reserves the right without prior notice to revise information in this guide for any reason. Samsung Telecommunications America also reserves the right without prior notice to make changes in design or components of equipment as engineering and manufacturing may warrant. Samsung Telecommunications America disclaims all liabilities for damages arising from the erroneous interpretation or use of information presented in this guide.

CUSTOMIZING YOUR KEYSET

AME P

assword ..................................................................................30

Select Ring Tone................................................................................30

Change Your Passcode ....................................................................30

Set Answer Mode ..............................................................................

Automatic Hold ..................................................................................31

Headset Operation ............................................................................

Hot Keypad ........................................................................................32

Key Confirmation Tone ......................................................................32

Rejoining a Page ..............................................................................32

Ring Preference ................................................................................32

DISPLAY FEATURES

Interactive Display Keys ....................................................................

Directory Information ...................................................................... 33

Dial by Directory ................................................................................34

Call Progress Displays

......................................................................34

Display Number Dialed......................................................................34

Call Duration Timer............................................................................34

Auto T

imer..........................................................................................35

Timer Function ..................................................................................35

Viewing Message Indications............................................................35

Alarm Reminder Messages

..............................................................35

Personal Speed Dial Names ............................................................36

Station Names ..................................................................................37

Managing Key Assignments ..............................................................37

Caller ID .......................................................................................38–41

LCR with Clear....................................................................................41

PERSONAL SPEED DIAL NUMBERS ........42–43

DIALING FEATURES

Speed Dialing ....................................................................................17

Programming Personal Speed Dial Numbers ............................17–18

One Touch Speed Dialing ................................................................18

Last Number Redial ..........................................................................

Save Number with Redial..................................................................18

Chain Dialing ....................................................................................

Automatic Redial/Retry ......................................................................19

Pulse to Tone Changeover................................................................19

PAGING AND MESSAGING

Making an Internal Page

....................................................................20

Making an External Page ..................................................................20

All Page..............................................................................................20

Meet Me P

age....................................................................................21

Call Park and Page............................................................................21

Messages—Set and Cancel..............................................................22

Returning Messages

..........................................................................22

Programmed Messages ....................................................................23

CONVENIENCE FEATURES

Do Not Disturb ..................................................................................24

One Time DND ..................................................................................24

Mute ..................................................................................................24

Background Music ............................................................................24

Appointment Reminder/Alarm Clock ................................................25

Door Phone Calls ..............................................................................25

Executive/Secretary Hotline ..............................................................26

Group Listening

................................................................................26

Account Codes ..................................................................................27

Locking Your Keyset..........................................................................27

Off-Hook Voice Announce ..........................................................27–28

OHVA Block ......................................................................................28

OHVA Reject ......................................................................................28

In Group/Out of Group ......................................................................28

ABOUT THIS BOOK

Your DS 24D keyset is the most visible part of your telephone system.

Please take the time to study this guide and to become familiar with the operation of your keyset. Keep this guide handy. You may need to look up instructions for infrequently used features.

Learning to use your keyset correctly will make everyday telephone communications a breeze.

This book is written based on the factory default settings for the feature access codes. Sometimes, due to programming requirements, these codes may be changed. If you find that a feature code does not work as described in this book, please contact your installation and service company to determine the correct code.

NOTE: DS 24D keysets are available only for Samsung DS 616 phone systems.

Your outside calls will light green on your keyset and red on other keysets. You never lose sight of your calls while they are on hold. They stay right where you put them and are identified with a green flashing light.

Some simple rules to remember:

• Any steady LED indicates the line or feature is in use.

• A fast flashing green LED indicates a new call ringing in.

• A slow flashing green or red LED indicates a call is on hold.

• A slow flashing amber LED indicates a recall to your keyset.

SPEAKERPHONE

DS 24D keysets are speaker phones. Pressing the SPEAKER key will answer or release a call on the speakerphone. Switching from the handset to the speakerphone is easy. Simply press the SPEAKER key and hang up the handset.

VOLUME CONTROLS

The DS 24D keyset uses the UP and DOWN keys to adjust the ringer volume while the keyset is ringing, the speaker volume while the speakerphone is in use and the handset volume while you are listening. These three levels will be stored in memory until changed. If background music is turned on at your keyset, the volume keys will also control the level of music. The volume of pages heard through the speaker of a keyset can be adjusted during a page announcement by using the volume keys. There are 16 levels for each volume setting, except Ring volume, Off-Hook volume, and Handset volume. The are 8 levels for Ring volume, Off-Hook volume, and Handset volume. The volume of Off-Hook ring is controlled by a user-programmable setting.

FEATURE ACCESS CODES

This user guide is written based on the default access code for using system features. If the system numbering plan has been changed some of the access codes may not be correct. Your installing company can inform you of the correct codes.

THINGS YOU SHOULD KNOW

USER ORIENTATION

DS 24D telephones are called “keysets.” They contain buttons or “keys” that are used to access or activate the many features of your office phone system. The keys with paper designation strips are programmable keys. This means they can be programmed for a specific function on your keyset and that same button can be something different on another keyset. See the system manager to get your most frequently used features assigned to your programmable keys. When changes are made, be sure that your programmable keys are relabeled properly.

Lines from the telephone company are “C.O. lines.” Calls on these lines are referred to as “outside calls.” Your system can have individual C.O. line keys or lines may be assigned to groups. When they are in a group, you access a line by dialing an access code or pressing a route button. For example, dial 9 or press a “LOCAL” key to get a local outside line. If Least Cost Routing is used, pressing the “LCR” key will automatically select a preprogrammed C.O. line according to what digits are dialed. Each line in the system is numbered, beginning with 701, then 702, 703, etc.

Direct Station Selection (DSS) keys are programmed to ring specific stations. You can press a DSS key instead of dialing the extension number. A DSS key lights red when that station is busy (Busy Lamp Indication).

DS 24D keysets provide distinctive ring patterns:

• Outside calls have a single ring tone repeated.

• Internal calls have a double ring tone repeated.

• Door phone calls and alarm/appointment reminders have a triple ring

tone repeated.

CALL INDICATIONS

The keys on your phone have light emitting diodes (LEDs). These are tri-colored LEDs that light green, red or amber (green and red together).

Intercom calls, also called internal calls, always appear on your CALL buttons. They will always light green. You can have up to eight CALL buttons, but at least two are recommended.

Outside calls appear on individual line keys if they are assigned. When an individual line is not assigned to its own key, it will appear on a CALL button.

DS 24D KEYSET

SYSTEM TONES

The system provides several tones to assist you. Some of these tones are already familiar to you.

32 CHARACTER DISPLAY

Two lines with 16 characters each.

SOFT KEYS

Used to activate features via the display.

SCROLL KEY

Used to scroll through displays.

8 PROGRAMMABLE KEYS WITH TRI-COLORED LIGHTS

Keys 1-3 (1-6) are automatically assigned as Direct Trunk keys. Key #8 is a message key, by default. Although all 8 keys may be programmed for any system features/functions.

16 PROGRAMMABLE KEYS WITH TRI-COLORED LIGHTS

Used to call stations directly, to indicate busy conditions of other stations, for One Touch dialing and many other system features.

VOLUME CONTROL KEYS

Used to set independent levels for handset, speaker, background music, ring and page volumes.

MICROPHONE

For handsfree operation.

SPEAKER KEY

HOLD KEY

SPEAKER

For handsfree operation and ringing.

TRANSFER KEY

REDIAL KEY

Intercom Dial Tone—A steady tone that indicates you can begin dialing.

DIAL TONE—CONTINUOS

CONTINUOUS

Ringback Tone—Indicates the station you dialed is ringing.

RINGBACK TONE—400 ms ON/200 ms OFF/400 ms ON/2000 ms OFF

CONTINUOUS

Busy Tone—Indicates the station you dialed is busy.

DS 24D

Scroll

BUSY TONE—350 ms ON/350 ms OFF

CONTINUOUS

DND/No More Calls Tone—Fast busy tone indicates the station you

dialed is in the Do Not Disturb mode or cannot receive any more calls.

DND/NO MORE CALLS TONE—250 ms ON/250 ms OFF

FOR TEN SECONDS

Transfer/Conference Tone—Indicates your call is being held and you can dial another party.

TRANSFER/CONF TONE—100 ms ON/100 ms OFF

CONTINUOUS

Confirmation Tone—Very short beeps followed by dial tone indicate you have correctly set or canceled a system feature.

CONFIRMATION TONE—100 ms ON/100 ms OFF

FOR ONE SECOND

Error Tone—A continuous single level tone indicates you have done something incorrectly. Try again.

ERROR TONE—CONTINUOUS

CONTINUOUS

12ABC

4 GHI

7 PRS

5 JKL 6 MNO

8 TUV 9 WXYZ

Volume

Transfer Redial Hold Speaker

3 DEF

NOTE: If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before dialing.

RECALL DIAL TONE

Press the NEW button to disconnect your existing call, wait for dial tone and then make a new call on the same line.

NOTE: If this button does not appear on your keyset, the FLASH key may be programmed to recall dial tone.

SENDING A FLASH

While on an outside call, press the FLASH key to send a flash to the telephone company. This is required for some custom calling features or CENTREX use.

BUSY LINE QUEUING WITH CALLBACK

If you receive a busy signal when you are selecting an outside line, this means that the line or group of lines is busy.

• Press the CBK key or dial 44. You will hear confirmation tone.

• When the line becomes free, the system will call you back.

• Lift the handset or press the SPEAKER key to answer, wait for dial tone and dial the telephone number or speed dial number again.

NOTES:

1. A callback will be canceled if not answered within 30 seconds. If you have set a callback, your CBK key will light.

2. If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before dialing.

CANCELING CALLBACK

A callback will be canceled if not answered within 30 seconds. If you have set a callback, your CBK key will light.

Your phone may have a maximum of five callbacks to lines and/or stations set at a time. To cancel a callback:

• Press the CBK key or dial 44. You will hear confirmation tone.

• While you are listening to confirmation tone, press the HOLD key. This will cancel the oldest set callback that you have set.

NOTES:

1. If the hot keypad feature is turned off, you must first lift the handset or press the SPEAKER key before dialing.

OUTSIDE CALLS

MAKING AN OUTSIDE CALL

• Lift the handset and press an idle outside line button, line group button or dial a line access code to receive dial tone—OR—press an idle outside line button, line group button or dial a line access code to receive dial tone through the speaker—OR—press SPEAKER, receive intercom dial tone and dial a line access code.

• Dial the telephone number.

• Finish the call by replacing the handset or pressing the SPEAKER key.

NOTE: You will receive No More Calls tone when you attempt to make a call and there is no key available for that line.

• If Least Cost Routing is enabled on your phone system, this button may be labeled LCR or accessed by dialing an access code (usually 9).

• If your system is programmed to require an authorization code before making a call, dial 4 plus a valid code before selecting a C.O. line.

• If your system is programmed to require an account code before making a call, press the ACCT button or dial 47 plus a valid code, press the ACCT button again and then select a C.O. line.

For more information on authorization and account codes, see your system administrator.

NOTE: If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before dialing.

ANSWERING AN OUTSIDE CALL

• Lift the handset and you are automatically connected to the ringing call.

See Ring Preference under Customizing Your Keyset—OR—press the

SPEAKER key to automatically answer on the speakerphone.

NOTE: If a call is flashing at your keyset but not ringing, you must press the flashing button to answer.

UNIVERSAL ANSWER

Outside lines may be programmed to ring a general alerting device. To answer calls ringing this device, dial 67 or press the UA key. This device can operate in the Day or Night mode.

BUSY STATION CALLBACK

When you call another station and receive a busy signal:

• Press the CBK key or dial 44.

• When the busy station becomes free, your keyset will ring.

• Lift the handset or press SPEAKER to call the now idle station.

NOTES:

1. A callback will be canceled if not answered within 30 seconds. If you have set a callback, your CBK key will light.

2. If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before dialing.

BUSY STATION CAMP-ON

When you call another station and receive a busy signal but you do not want to wait for a callback:

• Press the CAMP key or dial 45.

• The called station will receive off-hook ring tone repeated every few seconds and its first available CALL button will flash green to indicate your call is waiting.

• Wait for the called party to answer.

• The called station must release its first call or place it on hold before answering your camp-on.

NOTES:

1. If you receive No More Calls tone, that station has no available key to accept your call. Hang up or leave a message.

2. If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before dialing.

CALLING YOUR SYSTEM OPERATOR

• Dial 0 to call your system operator or group of operators.

• If you want to call a specific operator, dial that person’s extension number.

NOTE: If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before you begin dialing.

INTERCOM CALLS

CALLING OTHER STATIONS

• Dial the extension number or group number.

• Wait for the party to answer. If you hear a brief tone burst instead of ringback tone, the station you called is set for Voice Announce or Auto Answer. Begin speaking immediately after the tone.

• Finish the call by replacing the handset or pressing the SPEAKER key.

NOTES:

1. If you have a DSS key assigned to an extension or station group, you may press this key instead of dialing the number.

2. If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before you begin dialing.

ANSWERING INTERCOM CALLS

• When your keyset rings, simply lift the handset—OR—press the SPEAKER key to be connected to the calling station.

• Finish the call by replacing the handset or pressing the SPEAKER key.

See

Ring Preference under Customizing Y

our Keyset

VOICE ANNOUNCE MODE (INTERCOM CALLS ONLY)

When another station calls you, your keyset will sound a brief attention tone and you will hear the caller’s announcement.

• Press SPEAKER to turn on the microphone and speak handsfree— OR— lift the handset to reply.

• To finish the call, replace the handset or press the SPEAKER key.

AUTO ANSWER MODE (INTERCOM CALLS ONLY)

When another station calls you, your keyset will sound a brief attention tone and then automatically answer the call.

• Your microphone and speaker are turned on and you can speak handsfree. For privacy, use the handset.

• To finish the call, replace the handset or press the SPEAKER key.

• If you do not answer this recall within a pre-programmed period of time, it will go to the system operator.

CONSULTATION HOLD

When you are talking on an outside line and it is necessary to consult with another extension:

• Press the TRANSFER key; you will receive transfer dial tone. Your call is placed on transfer hold.

• Dial the extension number.

• Consult with the internal party.

• Press TRANSFER to return to the outside party or hang up to transfer the call.

NOTE: Repeatedly pressing the TRANSFER key will toggle between the outside party and internal extension.

RETRIEVING CALLS HELD AT ANOTHER STATION

When a line is on hold and it appears on your keyset, press the line button with the red flashing light.

When a line is on hold and it does not appear on your keyset, dial 12 plus the line number or the extension number of the station that placed the call on hold.

NOTE: If the Hot Keypad feature has been turned off, you must first lift the handset or press the SPEAKER key before you begin dialing.

CALL PARK

You can park an outside call in one of 10 “parking orbits”.

• Press the PARK key and dial the orbit number required (0-9); the key which the call was on will flash.

• Press a dedicated PARK key which will also flash.

• To have the call picked up by another station notify the station user of the parking orbit number.

To pick up a parked call.

• Press the PARK key followed by the orbit number required or press the flashing PARK key.

1110

CALL PROCESSING

SYSTEM HOLD

• When you are connected to any call, press HOLD. The call will flash green at your keyset. If this call appears on a line key at other keysets, it will flash red at those keysets.

• To take the caller off hold, press that key and the green flashing light will go steady green again. Resume the conversation.

NOTE: While on a call, pressing a line key, route key or flashing CALL button will automatically put your first call on hold and connect you to the new call. See

Automatic Hold under Customizing Your Keyset.

EXCLUSIVE HOLD

To place an outside call on hold at your phone so that other users cannot get it:

• Press the HOLD button twice. The call will flash green on your keyset and this line will show a steady red light on other keysets.

• To retrieve the call, press the flashing green line button or press the HOLD button a third time.

NOTE: Intercom calls will always be placed on exclusive hold.

REMOTE HOLD

When you wish to place a call on hold at another station. Press TRANSFER and a dial the station number (or press the appropriate DSS key). Press the HOLD key. This will place the call on system hold on an available CALL but- ton or Line Key at the remote station and return you to dial tone.

NOTES:

1. If the destination station does not have any free CALL buttons or line keys you will hear No More Calls tone and must return to the other party by pressing the TRANSFER key (or the RETURN soft key in the display).

2. Intercom calls cannot be remote held.

HOLD RECALL

If you leave a call on hold longer than the hold timer, it will recall your station. The button that the call appears on will have a slow flashing amber light.

• When your phone rings, lift the handset or press the SPEAKER key to answer the recall.

+ 16 hidden pages
