Sharp DMR0152 Users Manual

DOUBLE GRILL

Convection Microwave Oven

OPERATION MANUAL

AND

COOKBOOK

R-820JS R-820BC

FOR CUSTOMER ASSISTANCE

To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference.

Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem.

MODEL NUMBER ________________________ SERIAL NUMBER ______________ DATE OF PURCHASE ______________________ DEALER ____________________________ TELEPHONE ________________ SERVICER ___________________________ TELEPHONE ________________

TO PHONE:

DIAL 1-800- BE-SHARP ( 237-4277 ) for :

SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ADDITIONAL CUSTOMER INFORMATION

DIAL 1-800-642-2122 for :

ACCESSORIES and SHARP CAROUSEL COOKBOOK

TO WRITE:

Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091

TO ACCESS INTERNET:

www.sharpusa.com

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door operation can

result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or cleaner

residue to accumulate on sealing surfaces.

properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

(d) The oven should not be adjusted or repaired by anyone except properly qualified service

personnel.

CONTENTS

For Customer

Assistance .............................. Inside cover

Precautions to Avoid Possible

Exposure to Excessive

Microwave Energy ................. Inside cover

Limited Warranty .........................................1

Product Information Card........................... 1

Important Safety Instructions .................... 2

Installation Instructions.............................. 3

Grounding Instructions ..............................3

Information You Need to Know.............. 4-6

About Your Oven ....................................... 4

About Food ................................................ 4

About Utensils and Coverings .................... 5

About Children and the Microwave ............6

About Microwave Cooking ......................... 6

About Safety .............................................. 6

Part Names .............................................. 7-8

Before Operating .........................................9

To Set the Clock ........................................ 9

Stop/Clear ..................................................9

Manual Operation .................................. 9-13

Microwave Cooking .................................... 9

Convection Cooking..................................

10-11

Other Convenient Features ................ 20-22

Custom Help ............................................ 20

1. Child Lock

2. Audible Signal Elimination

3. Auto Start

4. Language Selection

5. Weight / Temperature Selection

Help .......................................................... 20

Minute Plus .............................................. 20

Manual Defrost ......................................... 21

Touch On ................................................. 21

Multiple Sequence Cooking ..................... 21

More or Less Time Adjustment ................21

Kitchen Timer ........................................... 22

Demonstration Mode ................................ 22

Cleaning and Care..................................... 22

Service Call Check ....................................23

Specifications ............................................23

Cooking Guide..................................... 24-39

Introduction ...............................................24

Foods and Best Cooking Methods .. 25 - 26

Roasting .....................................................27

Roasting Chart .......................................... 27

Main Dish Recipes .............................. 28-30

Grill Cooking ............................................ 12

Roast Cooking ......................................... 12

Helpful Hints ............................................. 13

Special Features.................................. 14-19

Popcorn .................................................... 14

Reheat ............................................... 14-15

AutoDefrost ..............................................16

AutoCook ........................................... 17-18

AutoBake ........................................... 17-18

AutoPizza ........................................... 17-18

AutoGrill .............................................. 17,19

AutoRoast ........................................... 17,19

Grilling........................................................ 31

Grilling Chart .............................................31

Grilling Recipes ................................... 32-33

Baking ........................................................34

Baking Chart ..............................................34

Baking Recipes ................................... 35-39

Cookbook Order Form ........................ 38-39

Guia Auto-Touch ................................. 41-42

Auto-Touch Guide .......... Inside Back Cover,

Back Cover

LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Your Product Model Number & Description:

Warranty Period for this Product:

Additional Item(s) Excluded from Warranty Coverage (if any):

Where to Obtain Service:

What to do to Obtain Service:

TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL

1-800-BE-SHARP OR VISIT www.sharpusa.com.

Save the proof of purchase as it is needed should your oven ever require warranty service.

R-820J, R-820B Home Use Carousel Microwave Oven. (Be sure to have this information available when you need service for your Product.)

One (1) year parts and labor. The warranty period continues for an additional four (4) years, for a total of five (5) years, with respect to the magnetron tube in the Product for parts only; labor and service are not provided free of charge for this additional period.

Accessories, rubber or plastic parts, the turntable, light bulbs, glass parts or any printed materials.

From a Sharp Authorized Servicer located In the United States. To find the location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP (1-800-237-4277).

Ship prepaid or carry in your Product to a Sharp Authorized Servicer. Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and packaged securely.

PRODUCT INFORMATION CARD

The product information card which is on the inside of the microwave oven carton should be completed within ten days of purchase and returned. We will keep it on file and help you access the information in case of loss, damage or theft. This will also enable us to contact you in the unlikely event that any adjustments or modifications are ever required for your oven.

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances basic safety precautions should be followed, including the following:

WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to

excessive microwave energy:

1. Read all instructions before using the

appliance.

2. Read and follow the specific “PRECAU-

TIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”

3. This appliance must be grounded. Connect only to properly grounded outlet. See

on inside front cover.

“GROUNDING INSTRUCTIONS” on

page 3.

4. Install or locate this appliance only in accordance with the provided installation instructions.

5. Some products such as whole eggs and sealed containers —for example, closed glass jars — are able to explode and should not be heated in this oven.

6. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook or dry food. It is not designed for industrial or laboratory use.

7. As with any appliance, close supervision is necessary when used by children.

8. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped.

9. This appliance should be serviced only by qualified service personnel. Contact nearest Sharp Authorized Servicer for examination, repair or adjustment.

10. Do not cover or block any openings on the appliance.

11. Do not store or use this appliance outdoors. Do not use this product near water—for example, near a kitchen sink, in a wet basement, near a swimming pool or similar locations.

12. Do not immerse cord or plug in water.

13. Keep cord away from heated surfaces.

14. Do not let cord hang over edge of table or counter.

15. See door surface cleaning instructions on page 22.

16. To reduce the risk of fire in the oven cavity: a. Do not overcook food. Carefully attend

appliance when paper, plastic or other combustible materials are placed inside the oven to facilitate cooking.

b. Remove wire twist-ties from paper or

plastic bags before placing bag in oven.

c. If materials inside the oven ignite,

keep oven door closed, turn oven off and disconnect the power cord or shut off power at the fuse or circuit breaker panel.

d. Do not use the cavity for storage pur-

poses. Do not leave paper products, cooking utensils or food in the cavity when not in use.

17. Liquids, such as water, coffee or tea are able

to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to persons:

a. Do not overheat the liquid. b. Stir the liquid both before and halfway

through heating it.

c. Do not use straight-sided containers

with narrow necks. Use a wide-mouthed container.

d. After heating, allow the container to

stand in the microwave oven at least for 20 seconds before removing the container.

e. Use extreme care when inserting a

spoon or other utensil into the container.

18. If the oven light fails, consult a SHARP

AUTHORIZED SERVICER.

19. Do not operate any heating or cooking ap-

pliance beneath this appliance.

20. Do not mount unit over or near any portion of

a heating or cooking appliance.

21. Do not mount over a sink.

22. Do not store anything directly on top of the

appliance surface when the appliance is in operation.

SAVE THESE

INSTRUCTIONS

INSTALLATION INSTRUCTIONS

Unpacking and Examining Your Oven

Remove:

1. all packing materials from inside the oven cavity; however, DO NOT REMOVE THE WAVEGUIDE COVER, which is located on the right cavity wall. Read enclosures and SAVE

the Operation Manual.

2.the feature sticker, if there is one, from the outside of the door.

Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surfaces, broken or loose door hinges and

latches and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact your dealer or SHARP AUTHORIZED SERVICER.

Choosing a Location for Your Oven

You will use your oven frequently so plan its location for ease of use. The oven must be placed

on a countertop which is a minimum of 36 inches from the floor. Allow at least 2 inches on the sides, top and at the rear of the oven for air circulation. Be sure to position oven so that the rear cannot be touched inadvertently.

Do not place or install the oven in any area where heat and steam are generated; for example, next to or above a conventional gas or electric range or above a conventional wall oven. Heat and steam may damage the electronics or the mechanical parts of the oven.

Built-in Kit

Your oven can be built into a cabinet or wall—not near or above a heat source—using Sharp’s Builtin Kit, Model RK-82K(black). If your dealer does not stock the kit, it can be ordered directly from the Sharp Accessories and Supplies Center. Have your credit card number available and call tollfree: 1-800-642-2122 for ordering the kit to be sent to your address.

The kit includes ducts and finish trim strips and easy-to-follow instructions for installation as well as the location of the power supply.

GROUNDING INSTRUCTIONS

This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded in accordance with the National Electrical Code and local codes and ordinances. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current.

WARNING – Improper use of the grounding plug can result in a risk of electric shock. Electrical Requirements

The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. or more protected electrical supply. It is recommended that a separate circuit serving only this appliance be provided.

The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. Should you only have a 2-prong outlet, have a qualified electrician install a correct wall receptacle.

A 3-prong adapter may be purchased and used temporarily if local codes allow. Follow package directions.

A short power-supply cord is provided to reduce risk of becoming entangled in or tripping over a longer cord.

Extension Cord

If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the microwave oven. The marked rating of the extension cord should be AC 115-120 volt, 15 amp. or more.

Be careful not to drape the cord over the countertop or table where it can be pulled on by children or tripped over accidentally.

Notes:1. If you have any questions about the grounding or electrical in-

Radio or TV Interference

Should there be any interference caused by the microwave oven to your radio or TV, check that the microwave oven is on a different electrical circuit, relocate the radio or TV as far away from the oven as feasible or check position and signal of receiving antenna.

structions, consult a qualified electrician or service person.

2. Neither Sharp nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedures.

INFORMATION YOU NEED TO KNOW

ABOUT YOUR OVEN

This Operation Manual is valuable: read it carefully and always save it for reference.

A good microwave cookbook is a valuable asset. Check it for microwave cooking principles, techniques, hints and recipes. See pages 38 and 39 for ordering the Sharp Carousel Microwave Cookbook.

NEVER use the oven without the turntable and support nor turn the turntable over so that a large dish could be placed in the oven. The turntable will turn both clockwise and counterclockwise.

ALWAYS have food in the oven when it is on to absorb the microwave energy.

When using the oven at power levels below 100%, you may hear the magnetron cycling on and off. It is normal for the exterior of the oven to be warm to the touch when cooking or reheating.

Condensation is a normal part of microwave cooking. Room humidity and the moisture in food will influence the amount of moisture that condenses in the oven.

ABOUT FOOD

Generally, covered foods will not cause as much condensation as uncovered ones. Vents on the oven back must not be blocked.

After using convection, grill, roast, AutoBake, AutoPizza, AutoGrill or AutoRoast, you will hear the sound of the cooling fan. The fan may operate depending on the oven temperature.

Be aware that, unlike microwave-only ovens, convection microwave ovens have a tendency to become hot.

The oven is hot whenever the top grill, both grill or convection symbols are lighted in the display

The oven is for food preparation only. It should not be used to dry clothes or newspapers.

Your oven is rated 900 watts by using the IEC Test Procedure method. In using recipes or package directions, check food a minute or two before the minimum time and add time accordingly.

FOOD

Eggs, sausages, nuts, seeds fruits & vegetables

POPCORN

Baby food

General

• Puncture egg yolks before cooking to prevent “explosion”.

• Pierce skins of potatoes, apples, squash, hot dogs and sausages so that steam escapes.

• Use specially bagged popcorn for the microwave oven.

• Listen while popping corn for the popping to slow to 1 or 2 seconds or use special Popcorn pad.

• Use an overturned 9 or 10 inch oven proof glass pie plate on top of the turntable when popping bagged microwave popcorn.

• Transfer baby food to small dish and heat carefully, stirring often. Check temperature before serving.

• Put nipples on bottles after heating and shake thoroughly. “Wrist” test before feeding.

• Cut baked goods with filling after heating to release steam and avoid burns.

• Stir liquids briskly before and after heating to avoid “eruption”.

• Use deep bowl, when cooking liquids or cereals, to prevent boilovers.

DON’T

• Cook eggs in shells.

• Reheat whole eggs.

• Dry nuts or seeds in shells.

• Pop popcorn in regular brown bags or glass bowls.

• Exceed maximum time on popcorn package.

• Heat disposable bottles.

• Heat bottles with nipples on.

• Heat baby food in original jars.

• Heat or cook in closed glass jars or air tight containers.

• Can in the microwave as harmful bacteria may not be destroyed.

• Deep fat fry.

• Dry wood, gourds, herbs or wet papers.

ABOUT UTENSILS AND COVERINGS

It is not necessary to buy all new cookware. Many pieces already in your kitchen can be used successfully in your new convection microwave oven. The chart below will help you decide what utensils and coverings should be used in each mode. Make sure the utensil does not touch the interior walls during cooking.

Utensils and

Coverings

Aluminum foil

Aluminum containers

Browning dish

Glass ceramic (Pyroceram.®)

Glass, heat-resistant

Glass, non-heat-resistant

Lids, glass

Lids, metal

Metal cookware

Metal, misc: dishes with metallic trim, screws, bands, handles. Metal twist ties

Oven cooking bags

Paper plates

Paper towels

Paper, ovenable

Yes

smoothly on food can be used to shield areas from cooking or defrosting too quickly. Keep foil at least 1 inch from walls of oven.

Yes

inch away from walls and do not cover with foil.

Yes

time. Follow manufacturer's directions.

Yes

for popping popcorn.

Yes

tenderizing. DO NOT use metal twist ties.

Yes

not use recycled paper towels which may contain metal filings.

Yes

Microwave Only

Small flat pieces of aluminum foil placed

Can be used if 3/4 filled with food. Keep 1

Do not exceed recommended preheating

Excellent

Excellent. Overturned pie plate necessary

Yes

Good for large meats or foods that need

For reheating

To cover for reheating and cooking. Do

Convection

Grill

For shielding

Yes

cover

Grill-No

Yes

filled with food. Keep 1 inch away from walls and do not cover with foil.

Yes Yes

Excellent

Yes

Excellent

Grill-No

Yes

cover

Grill-No

Yes

cover

Yes

covering.

Yes

Grill-No

Yes

twist ties.

Yes

For

temperatures up

Yes

to 400°F.

Roast

For shielding

Can be used if 3/4

Excellent

Yes

Do not use metal

DO NOT use metal

For temperatures up

Microwave-safe plastic containers

Yes

Use for reheating and defrosting. Some

microwave-safe plastics are not suitable for

No No

cooking foods with high fat and sugar content. Follow manufacturer's directions.

Plastic, Thermoset

Yes

Are heat

Yes

resistant up to 425°F

Plastic wrap

Yes

Use brands specially marked for

microwave use. DO NOT allow plastic wrap to touch food. Vent so steam can escape.

Pottery, porcelain stoneware

Styrofoam Wax paper

Wicker, wood, straw

Yes

Check manufacturer's recommendation for

being microwave safe.

Yes

For reheating

Yes

Good covering for cooking and reheating

Yes

May be used for short periods of time. Do

Yes

Must be microwave

safe AND ovenable.

not use with high fat or high sugar content foods. Could char.

DISH CHECK. If you wish to check if a dish is safe for microwaving, place the empty dish in the oven and microwave on HIGH for 30 seconds. If the dish becomes very hot, do NOT use it for microwaving.

ACCESSORIES There are many microwave accessories available for purchase. Evaluate carefully before you purchase so that they meet your needs. A microwave-safe thermometer will assist you in determining correct doneness and assure you that foods have been cooked to safe temperatures when using microwave-only cooking. Sharp is not responsible for any damage to the oven when accessories are used.

INFORMATION YOU NEED TO KNOW

ABOUT CHILDREN AND THE MICROWAVE

Children below the age of 7 should use the microwave oven with a supervising person very near to them. Between the ages of 7 and 12, the supervising person should be in the same room.

The child must be able to reach the oven comfortably; if not, he/she should stand on a sturdy stool.

At no time should anyone be allowed to lean or swing on the oven door.

ABOUT MICROWAVE COOKING

• Arrange food carefully. Place thickest areas towards

outside of dish.

• Watch cooking time. Cook for the shortest amount

of time indicated and add more as needed. Food severely overcooked can smoke or ignite.

• Cover foods while cooking. Check recipe or cook-

book for suggestions: paper towels, wax paper, microwave plastic wrap or a lid. Covers prevent spattering and help foods to cook evenly.

• Shield with small flat pieces of aluminum foil any

thin areas of meat or poultry to prevent overcooking before dense, thick areas are cooked thoroughly.

• Stir foods from outside to center of dish once or twice

during cooking, if possible.

• Turn foods over once during microwaving to

speed cooking of such foods as chicken and hamburgers. Large items like roasts must be turned over at least once.

Children should be taught all safety precautions: use potholders, remove coverings carefully, pay special attention to packages that crisp food because they may be extra hot.

Don’t assume that because a child has mastered one cooking skill he/she can cook everything.

Children need to learn that the microwave oven is not a toy. See page 20 for Child Lock feature.

• Rearrange foods such as meatballs halfway

through cooking both from top to bottom and from the center of the dish to the outside.

• Add standing time. Remove food from oven and

stir, if possible. Cover for standing time which allows the food to finish cooking without overcooking.

• Check for doneness. Look for signs indicating that

cooking temperatures have been reached.

Doneness signs include:

- Food steams throughout, not just at edge.

- Center bottom of dish is very hot to the touch.

- Poultry thigh joints move easily.

- Meat and poultry show no pinkness.

- Fish is opaque and flakes easily with a fork.

ABOUT SAFETY

• Check foods to see that they are cooked to the United States Department of Agriculture's recommended temperatures.

TEMP FOOD

160°F

165°F

170°F

180°F

To test for doneness, insert a meat thermometer in a thick or dense area away from fat or bone. NEVER leave the thermometer in the food during cooking, unless it is approved for microwave oven use.

• ALWAYS use potholders to prevent burns when handling utensils that are in contact with hot food. Enough heat from the food can transfer through utensils to cause skin burns.

... for fresh pork, ground meat,

boneless white poultry, fish, seafood, egg dishes and frozen prepared food.

... for leftover, ready-to-reheat

refrigerated, and deli and carryout “fresh” food.

... white meat of poultry.

... dark meat of poultry.

• Avoid steam burns by directing steam away from the face and hands. Slowly lift the farthest edge of a dish's covering and carefully open popcorn and oven cooking bags away from the face.

• Stay near the oven while it's in use and check cooking progress frequently so that there is no chance of overcooking food.

• NEVER use the cavity for storing cookbooks or other items.

• Select, store and handle food carefully to preserve its high quality and minimize the spread of foodborne bacteria.

• Keep waveguide cover clean. Food residue can cause arcing and/or fires.

• Use care when removing items from the oven so that the utensil, your clothes or accessories do not touch the safety door latches.

• Keep aluminum foil used for shielding at least 1 inch away from walls, ceiling and door.

• Use potholders and be careful when using convection, grill, roast, CompuBake, CompuPizza, CompuGrill or CompuRoast as cabinet, interior and door may be too hot to touch.

PART NAMES

MICROWAVE OVEN PARTS

17 15 10

1 One touch door open button

Push to open door.

2 Oven door with see-through window

3 Safety door latches

The oven will not operate unless the door is securely closed.

4 Door hinges

5 Door seals and sealing surfaces

6 Turntable motor shaft

7 Removable turntable support

Carefully place the turntable support in the center of the oven floor.

8 Removable turntable

Place the turntable on the turntable support securely. The turntable will rotate clockwise or counterclockwise.

51610123

112

9 Rack

Place on the turntable. The rack is designed especially for use in this oven only for convection, roast or grill cooking. DO NOT USE FOR MICROWAVE ONLY COOKING. Do not substitute a similar rack for this specially designed one.

10 Ventilation openings

11 Oven light

It will light when oven is operating or door is open.

12 Waveguide cover: DO NOT REMOVE.

13 Auto-Touch control panel

14 Time display: 99 minutes, 99 seconds

15 Top heater

16 Bottom heater

17 Menu label

NOTE:

display, the oven may become very hot. Use caution when removing any item from the oven. Use heavy potholders or oven mitts.

Whenever the top heater, bottom heater or convection symbols are lighted in the

INTERACTIVE DISPLAY

The two-line, Interactive Display spells out operating steps and shows cooking hints. When HELP is lighted in the display, touch the Custom Help pad to read a specific hint which may assist you.

1.TOP HEATER SYMBOL

The symbol will light when the top heater is in use.

2.BOTTOM HEATER SYMBOL

The symbol will light when the bottom heater is in use.

3.CONVECTION SYMBOL

The symbol will light during convection cooking.

123

PART NAMES

R-820J R-820B

17,18

10,11

14,15

9, 22

17,19

9,21

17,18

10,11

14,15

9, 22

17,19

9,21

Number next to the control panel illustration indicates page on

which there are a feature description and usage information.

BEFORE OPERATING

MANUAL OPERATION

• Before operating your new microwave oven make

sure you read and understand this operation manual completely.

• Before the oven can be used, follow these

procedures:

1. Plug in the oven. Close the door. The oven display

will show SHARP SIMPLY THE BEST PRESS CLEAR AND PRESS CLOCK.

2. Touch the Stop/Clear pad.

will appear.

3. Set clock.

TO SET THE CLOCK

• Suppose you want to enter the correct time of day

12:30 (A.M. or P.M.).

PROCEDURE DISPLAY

This is a 12 hour clock. If you attempt to enter an incorrect clock time, ERROR will appear in the display. Touch the Stop/Clear pad and re-enter the time.

• If the electrical power supply to your microwave

oven should be interrupted, the display will intermittently show SHARP SIMPLY THE BEST PRESS CLEAR AND PRESS CLOCK after the power is reinstated. If this occurs during cooking, the program will be erased. The time of day will also be erased. Simply touch Stop/Clear pad and reset the clock for the correct time of day.

NOTE:

CLOCK

Touch Clock pad.

1 2 3 0

Enter the correct time of day by touching the numbers in sequence.

CLOCK

Touch Clock pad again.

Your oven can be programmed with the door open except for Start/Touch On and Minute Plus.

ENTER

TIME OF DAY

12:30

STOP/CLEAR

MICROWAVE COOKING

Your oven can be programmed for 99 minutes 99 seconds (99.99). Always enter the seconds after the minutes, even if they are both zeros.

• Suppose you want to cook for 5 minutes at 100%.

PROCEDURE DISPLAY

There are eleven preset power levels.

Using lower power levels increases the cooking time which is recommended for foods such as cheese, milk and long slow cooking of meats. Consult cookbook or recipes for specific recommendations.

• Suppose you want to cook for 5 minutes at 30%.

5 0 0

Enter cooking time.

START

TOUCH ON

Touch Start/ Touch On pad.

TOUCH POWER

LEVEL PAD ONCE

THEN TOUCH

Power Level 100% High

9 90% 8 80%

7 70% Medium High 6 60%

5 50% Medium 4 40%

3 30% Med Low/Defrost 2 20%

1 10% Low

00%

APPROXIMATE

PERCENTAGE

OF POWER

5.00

COMMON WORDS

FOR

POWER LEVELS

PROCEDURE DISPLAY

5 0 0

Enter cooking time.

POWER

LEVEL

Touch Power Level pad. Enter power level.

5.00

30 PERCENT

COOK

Touch the Stop/Clear pad to:

1. Erase if you make a mistake during programming.

2. Cancel kitchen timer.

3. Stop the oven temporarily during cooking.

4. Return the time of day to the display.

5. Cancel a program during cooking, touch twice.

You can program up to 4 automatic cooking sequences. Follow directions on page 21. Note that Power Level must be entered first when programming multiple sequences.

START

TOUCH ON

Touch Start/ Touch On pad.

5.00

COOK

MANUAL OPERATION

CONVECTION COOKING

During convection heating, hot air is circulated throughout the oven cavity to brown and crisp foods quickly and evenly. This oven can be programmed for ten different convection cooking temperatures for up to 99 minutes, 99 seconds.

The oven should not be used without the turntable in place, and it should never be restricted so that it cannot rotate. You may remove the turntable when preheating the oven and when preparing food to be cooked directly on the turntable.

Warning:

All of the oven parts, including the bottom heater as well as the rack and cooking containers, may become very hot. Use caution when removing any item from the oven. Use heavy potholders or oven mitts to PREVENT BURNS.

2 5 0 0

Enter cooking time.

START

When the oven reaches the programmed temperature, a signal will sound 4 times.* The oven will stop, and directions will be displayed. Follow the indicated message.

TOUCH ON

Touch Start/ Touch On pad.

START

TOUCH ON

Touch Start/ Touch On pad.

25.00 350F

PREHEAT 350F

COOK

CONVECTION SETTINGS

SETTING

CONVECTION SETTINGS

1. Convection with preheat

2. Convection without preheat

SPECIAL CONVECTION SETTINGS

3. Cakes

4. Angel food cake

5. Yeast bread

1. To Preheat and cook with Convection

Your oven can be programmed to combine preheating and convection cooking operations. You can preheat to the same temperature as the convection temperature.

• Suppose you want to preheat to 350° F. and then cook 25 minutes at the same temperature.

PROCEDURE DISPLAY

CONVEC

Touch Convec pad.

SELECT

NUMBER

SEE

CONVEC

LABEL

* If the oven door is not opened, the oven will auto-

matically hold at the preheat temperature for 30 minutes. After this time has elapsed, an audible signal will sound, and the oven will turn off.

NOTE:

1. To program only preheat, touch the Start/Touch on pad after step 3. Preheating will start. When the oven reaches the programmed temperature, follow the indicated message.

2. If you are in the process of preheating and wish to check the actual oven temperature, simply touch the Convec pad. The actual oven temperature will be displayed as long as the Convec pad is touched. If the oven temperature is below 100°F at this time,

LO F will be displayed.

2. Cook with Convection without Preheat

To cook without preheat, touch 2 in step 2. Select the cooking temperature, time and press Start/Touch On pad, following the indicated message. Oven starts to cook immediately.

Touch number pad for

selected Convec setting.

Select preheat temperature.

SELECT TEMP

350F

MANUAL OPERATION

3. 4. 5 Special Convection Settings

Your oven has pre-programmed settings which are ideal for special baking. All that is necessary is to enter cooking time. Use them as indicated to ensure baking success.

• Suppose you want to bake a cake for 20 minutes.

PROCEDURE DISPLAY

START

TOUCH ON

Touch Start/ Touch On pad.

20.00 BAKE

COOK

HELP

CONVEC

Touch Convec pad.

Select desired convec setting by touching the number pad.

2 0 0 0

Enter cooking time.

START

When the oven reaches the temperature, a signal will sound 4 times*. The oven will stop, and directions will be displayed. Follow the indicated message.

TOUCH ON

Touch Start/ Touch On pad.

SELECT

NUMBER

SEE

CAKES

ENTER

20.00

PREHEAT 350F

CONVEC

LABEL

COOKING TIME

HELP

COOK HELP

CONVEC CHART

SETTING

1. With preheat

2. Without preheat

3. Cakes

4. Angel food cake

5. Yeast bread

OPTIONS

Any temperature listed on number pads: 100, 150, 275, 300, 325, 350, 375, 400, 425 or 450°F.

Same as above

None

Most baking for items requiring preheat.

Baking when no preheating is acceptable.

Special setting for baking cakes--especially good for bundt and tube cakes.

Mix or your own recipe for angel food cake.

Bread loaves and specialty shapes. May need additional time than recipe suggests if baking extra large loaves or bread made with whole grain flours.

* If the oven door is not opened, the oven will

automatically hold at the preheat temperature for 30 minutes. After this time has elapsed, an audible signal will sound, and the oven will turn off.

NOTE:

Should additional time be needed on the special convection settings, simply enter the additional time and touch Start/Touch On. This step must be done within 2 minutes of the original cycle end and before touching Stop/Clear.

USED FOR

MANUAL OPERATION

GRILL COOKING

Your oven has two grill cooking options. Select the desired grill setting by touching the Grill pad.

It is not necessary to preheat for grill cooking.

GRILL SETTING

SETTING

1. Top and Bottom Grill

2. Top Grill only

• Suppose you want to cook for 20 minutes using the top and bottom heaters.

PROCEDURE DISPLAY

GRILL

Touch Grill pad.

Select desired grill setting by touching the number pad.

2 0 0 0

Enter grilling time.

START

Warning:

TOUCH ON

Touch Start/ Touch On pad.

TOP AND

PRESS 1

TOP GRILL

ENTER

20.00

20.00 grill

BOTTOM GRILL

PRESS 2

COOKING TIME

COOK

ROAST COOKING

Your oven has a pre-programmed setting that makes it easy to cook with both convection heat and microwave automatically.

The marriage of these two cooking methods produces juicy meats, as well as tender, flavorful poultry, all with just the right amount of browning and crispness.

ROAST SETTING

SETTING

Oven temperature 325°F

Microwave power 30%

• Suppose you want to cook a roast for 25 minutes on Roast.

PROCEDURE DISPLAY

ROAST

Touch Roast pad.

2 5 0 0

Enter roasting time.

START

NOTE:

Warning:

TOUCH ON

Touch Start/ Touch On pad.

The temperatures can be changed; however, the microwave power cannot. The oven temperature can be changed from 100°F. t o

450°F. To change the temperature, touch ROAST twice. When the display says SELECT TEMP, touch desired temperature pad.

ROAST 325F

ENTER

25.00 325F

COOKING TIME

COOK
