Sharp CS-2635RH Operating Manual

ELECTRONIC PRINTING CALCULATOR DRUCKENDER TISCHRECHNER CALCULATRICE IMPRIMANTE ÉLECTRONIQUE CALCULADORA IMPRESORA ELECTRÓNICA CALCOLATRICE ELETTRONICA STAMPANTE ELEKTRONISK SKRIVANDE OCH VISANDE RÄKNARE ELEKTRONISCHE REKENMACHINE MET AFDRUK CALCULADORA ELETRÔNICA COM IMPRESSORA ELEKTRONISESTI TULOSTAVA LASKIN
ENGLISH ............................................................... Page 2
CALCULATION EXAMPLES ................................. Page 121
DEUTSCH .............................................................. Seite 15
RECHNUNGSBEISPIELE ..................................... Seite 121
FRANÇAIS .............................................................Page 29
EXEMPLES DE CALCULS .................................... Page 122
ESPAÑOL .............................................................. Página 42
EJEMPLOS DE CÁLCULOS ................................. Página 122
ITALIANO .............................................................. Pagina 55
ESEMPI DI CALCOLO ...........................................Pagina 123
SVENSKA .............................................................. Sida 68
RÄKNEEXEMPEL ..................................................Sida 123
NEDERLANDS ...................................................... Pagina 81
REKENVOORBEELDEN ....................................... Pagina 124
PORTUGUÊS ........................................................ Página 95
EXEMPLOS DE CÁLCULO ................................... Página 124
SUOMI ................................................................... Sivu 108
LASKENTAESIMERKKEJÄ ................................... Sivu 125
CS-2635RH
OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE MANEJO MANUALE DI ISTRUZIONI BRUKSANVISNING GEBRUIKSAANWIJZING MANUAL DE INSTRUÇÕES KÄYTTÖOHJE
Notes for handling Lithium batteries:
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
Hinweise zur Handhabung von Lithium-Batterien:
VORSICHT
Bei Verwendung einer uneeigneten Ersatzbatterie besteht Explosionsgefahr. Nur durch den gleichen oder einen vom Hersteller empfohlenen gleichwertigen Typ ersetzen. Verbrauchte Batterien gemäß Herstelleranleitung entsorgen.
Remarques sur la manipulation des piles au lithium:
ATTENTION
Danger d’explosion de la pile si elle n’est pas remplacée correctement. Remplacez-la uniquement par le même type de pile ou un type équivalent recommandé par le fabricant. Débarrassez-vous des piles usagers en respectant les instructions du fabricant.
Notas para el manejo de las baterías de litio:
PRECAUCIÓN
Peligro de explosión si reemplaza incorrectamente la batería. Reemplácela por otra igual o de tipo equivalente recomendada por el fabricante. Deshágase de las baterías de acuerdo con las instrucciones del fabricante.
Note concernenti le batterie al litio:
AVVERTENZA
Se la batteria non viene sostituita in modo corretto c’è pericolo di esplosioni. Sostituire la batteria con una dello stesso tipo o con una equivalente raccomandata dalla fabbrica. Smaltire le batterie usate seguendo le istruzioni della fabbrica.
Observera om hantering av litiumbatterier:
OBSERVERA!
Felaktigt batteribyte medför risk för explosion. Byt endast ut batteriet mot ett batteri av samma eller motsvarande typ rekommenderat av tillverkaren. Kassera ett förbrukat batteri enligt tillverkarens anvisningar.
Opmerkingen betreffende de behandeling van lithiumbatterijen:
LET OP
Ontploffingsgevaar indien de batterij verkeerd wordt aangebracht. Vervang uitsluitend door een batterij van hetzelfde of een gelijkwaardig type, aanbevolen door de fabrikant. Gooi gebruikte batterijen weg overeenkomstig de instructies van de fabrikant.
Notas para o manuseio de pilhas de lítio:
PRECAUÇÃO
Existe o perigo de explosão se a pilha for trocada incorretamente. Troque apenas com o mesmo tipo ou equivalente recomendado pelo fabricante. Descarte-se das pilhas usadas de acordo com as instruções do fabricante.
Huomautuksia litiumparistojen käsittelystä:
HUOMAUTUS
Räjähdysvaara, jos paristo vaihdetaan väärin. Paristo tulee vaihtaa vain samaniaiseen tai valmistajan suosittelemaan vastaavaan tyyppiin. Hävitä käytetyt paristot valmistajan antamien ohjeiden mukaisesti.
Caution! The socket outlet shall be installed near the equipment and shall be easily accessible.
Vorsicht! Die Netzsteckdose muß in der Nähe des Gerätes angebracht und leicht zugänglich sein.
Attention! La prise de courant murale doit être installée à proximité de l’appareil et doit être facilement accessible.
Aviso! El tomacorriente debe estar instalado cerca del equipo y debe quedar bien accesible.
Attenzione! La presa della corrente deve essere installata in prossimità dell’apparecchio ed essere facilmente accessibile.
Observera! Anslut till ett vägguttag som återfinns nära enheten och är lätt åtkomligt.
Let op! Het stopcontact moet in de buurt van het apparaat zijn en ook gemakkelijk toegankelijk zijn.
Atenção! A tomada elétrica deve estar perto do equipamento e ser de fácil acesso.
Huomautus! Pistorasia tulee asentaa laitteen lähelle paikkaan, jossa sen käyttöä on helppoa.
1
ENGLISH
OPERATIONAL NOTES
To insure trouble-free operation of your SHARP calculator, we recommend the following:
1. The calculator should be kept in areas free from extreme temperature changes, moisture, and dust.
2. A soft, dry cloth should be used to clean the calculator. Do not use solvents or a wet cloth.
3. Since this product is not waterproof, do not use it or store it where fluids, for example water, can splash onto it. Raindrops, water spray, juice, coffee, steam, perspiration, etc. will also cause malfunction.
4. While the memory protection battery is not installed, the tax / discount rate and conversion rate set up will be cleared upon terminating the AC power supply. The tax / discount rate and conversion rate set up will also be cleared when the memory protection battery is removed from the unit.
5. If service should be required on this equipment, use only a SHARP servicing dealer, a SHARP approved service facility or SHARP repair service where available.
6. Do not wind the AC cord around the body or otherwise forcibly bend or twist it.
CONTENTS
Page
• INSTALLING OF BATTERY FOR MEMORY
PROTECTION ...................................................3
• OPERATING CONTROLS ................................ 4
• INK RIBBON REPLACEMENT ......................... 8
• PAPER ROLL REPLACEMENT ........................9
• ERRORS ......................................................... 10
• REPLACEMENT OF BATTERY FOR
MEMORY PROTECTION ................................ 11
• SPECIFICATIONS........................................... 12
• RESETTING THE UNIT .................................. 14
• CALCULATION EXAMPLES ......................... 121
• CONVERSION CALCULATION
EXAMPLES ................................................... 144
• TAX RATE CALCULATIONS ......................... 146
• DISCOUNT RATE CALCULATION ............... 149
SHARP will not be liable nor responsible for any incidental or consequential economic or property damage caused by misuse and/or malfunctions of this product and its peripherals, unless such liability is acknowledged by law.
2
INSTALLING OF BATTERY FOR MEMORY PROTECTION
Before using for the first time, remove the attached lithium battery, and install it in the equipment according to the following procedure. If the power cord is unplugged by accident when operating with AC power only, the tax / discount rate and conversion rate set up will be lost.
1) Turn the power switch “OFF” and unplug the power supply plug from the outlet.
2) Remove the battery cover on the back of the unit. (Fig. 1)
3) Wipe the battery well with a dry cloth and place the plus “+” side upward. (Fig. 2)
4) Replace the battery cover by reversing the removal procedure.
5) Press the RESET switch on the back of the unit (See page 14).
1
2
Fig. 1 Fig. 2
After battery installation
Connect the power supply plug to an outlet and
turn the power switch “ON”. Check that “0.” is displayed. If “0.” is not displayed, remove the battery, reinstall it, and check the display again.
On the battery replacement date label found on
the back of the unit, write down the month and year when the battery is installed, as a reference for the next battery replacement.
3
OPERATING CONTROLS
POWER SWITCH; PRINT / ITEM COUNT MODE SELECTOR:
“OFF”: Power OFF. “”: Power ON. Set to the non-
print mode. (“• • • ... • • • –P” will be printed.)
“P”: Power ON. Set to the print
mode. (“• • • ... • • • +P” will be printed.)
“P•IC”: Power ON. Set to the print
and item count mode. The counter will count the number of times that has been pressed in addition.
Notes: Each time is used in
subtraction, 1 will be subtracted from the count.
The count is printed when
the calculated result is obtained.
Pressing of , or
clears the counter.
The counter has a
maximum capacity of 3 digits (up to ±999). If the count exceeds the maximum, the counter will recount from zero.
RATE SETTING MODE SELECTOR:
This selector is used to set the conver­sion rate or the tax / discount rate.
”: Set this selector to the “RATE
SET” position before storing an each rate.
Conversion rate:
Enter the conversion rate,
then press .
A maximum of 6 digits can be
stored (decimal point is not counted as a digit).
Tax / discount rate:
Enter the adding tax rate, then
press .
To store a discount rate, press
before pressing .
A maximum of 4 digits can be
stored (decimal point is not
4
” : Set this selector to the “” posi-
counted as a digit).
tion before starting calculations.
Note: Be sure to set this selector to
the “” position after storing an each rate.
For the conversion rate and
the tax / discount rate, a single value can be stored for each. If you enter a new rate, the previous rate will be cleared.
CONSTANT / ADD MODE SELECTOR:
“K” : The following constant functions
will be performed:
Multiplication: The calculator will
automatically re­member the first number entered (the multiplicand) and instruction.
Division: The calculator will
automatically re­member the second number entered (the divisor) and instruction.
”: Neutral “A”: Use of the Add mode permits
addition and subtraction of numbers without entry of the decimal point. When the Add mode is activated, the decimal point is automatically positioned according to the decimal selector setting. Use of , , and will automatically override the Add mode and decimally correct answers will be printed at the preset decimal position.
5
5/4
ROUNDING SELECTOR:
Example: Set decimal selector to “2”. 4 ÷ 9 = 0.444 ... , 5 ÷ 9 = 0.555 ...
4 9 5 9
0.45 0.56
5/4 0.44 0.56
0.44 0.55
Note: The decimal point floats during
successive calculation by the use of or . If the decimal selector is set to “F” then the answer is always rounded down ( ).
DECIMAL SELECTOR:
Presets the number of decimal places in the answer. In the “F” position, the answer is displayed in the floating decimal system.
PAPER FEED KEY
CONVERSION KEY:
This key is used to obtain a value by dividing a given number with a specified conversion rate.
CONVERSION KEY:
This key is used:
to store the conversion rate (by the
use of the rate setting mode selector).
obtains a value by multiplying a given
number with a specified conversion rate.
to recall the presently stored rate for
check. Press first to clear the calculation register and reset an error condition, then press . The conversion rate is printed with the symbol “TC”.
LAST DIGIT CORRECTION KEY
CLEAR ENTRY KEY:
Clears numbers entered prior to use of a function key. Also used to clear an overflow error caused by an entry.
6
NON-ADD / SUBTOTAL KEY: Non-Add – When this key is pressed
right after entry of a number in the Print mode, the entry is printed on the left-hand side with “#”. This key is used to print out numbers not subject to calculations such as codes, dates, etc.
Subtotal – Used to get subtotal(s) of
additions and / or subtrac­tions. When pressed following or , the subtotal is printed with “◊” and the calculation may be continued.
By pressing this key even in the Non-print mode, the displayed number is printed with “P”.
TOTAL KEY:
Prints the total of addition and subtraction with “ ”. This key also serves as a clear key for the calculation register and resets an error condition.
FIRST RECALL MEMORY KEY
FIRST RECALL AND CLEAR MEMORY KEY
SECOND RECALL AND CLEAR MEMORY KEY
SECOND RECALL MEMORY KEY
CHANGE SIGN KEY:
Changes the algebraic sign of a number (i.e. positive to negative or negative to positive).
MULTIPLE USE KEY:
Performs mark-ups, percent change and automatic add-on / discount.
TAX-INCLUDING KEY:
This key is used for calculations with the tax/discount rate. To recall the presently stored rate for check, press to clear the calculation register and reset an error condition, then press . The tax / discount rate is printed with the symbol “TX”.
7
DISPLAY
Display format:
Symbols: M : First memory symbol
Appears when a number has been stored in First memory.
: Second memory symbol
Appears when a number has been stored in Second memory.
– : Minus symbol
Appears when a number is a negative.
E : Error symbol
Appears when an overflow or other error is detected.
* Although all available symbols are shown here
for instruction purposes, these symbols will not appear on the screen simultaneously.
INK RIBBON REPLACEMENT
1. Remove the paper roll from the calculator. (Tear the paper and remove it from the print mechanism by using .)
2. Set the power switch to OFF. Make sure that the print wheel has stopped.
3. Remove the printer cover by sliding it towards the back of the calculator. (Fig. 1)
4. Remove the used ribbon.
5. Install the new ribbon.
6. With the black side of the ribbon facing upwards, place one of the reels on the reel shaft on the right. (Fig. 2) Make sure that the reel is securely in place.
7. Thread the ribbon around the outside of the metal guides. (Fig. 3)
8. Take up any slack by manually turning one of the reels.
9. Replace the printer cover.
10. Replace the paper roll.
8
Printer cover
Fig. 1
Reel
Ink ribbon
Fig. 2
PAPER ROLL REPLACEMENT
1. Lift the paper holder up. (Fig. 1)
2. Fold the leading edge of the paper roll 3 to 5 cm. (Do not fold it slantwise.) (Fig. 2)
3. Insert the paper roll from the left side of the paper holder and make sure the paper roll is set in the proper direction (with the paper feeding from the bottom). (Fig. 3)
4. Insert the leading edge of the paper into the opening directly behind the print mechanism. (Fig. 4)
5. Press the paper feed key and feed the paper under the edge of the paper cutter. (Fig. 5)
Reel shaft
Ink ribbon
Fig. 3
Paper holder
3 cm – 5 cm (1-3/16 to 1-31/32″)
Fig. 1
Fig. 2
9
Fig. 3
Paper cutter
Fig. 4
DO NOT PULL PAPER BACKWARDS AS THIS MAY CAUSE DAMAGE TO PRINTING MECHANISM.
Fig. 5
ERRORS
There are several situations which will cause an overflow or an error condition. When this occurs, the error symbol “E” will be displayed and all keys will electronically lock. The contents of the memory at the time of the error are retained. If an “0•E” is displayed at the time of the error, must be used to clear the calculator. If an “E” with any numerals except zero is displayed, the error may be cleared with or and the calculation can still be continued.
Error conditions:
1. Entry of more than 12 digits or 11 decimals. This error can be cleared with or .
2. When the integer portion of an answer exceeds 12 digits.
3. When the integer portion of the contents of the memory exceeds 12 digits. (Ex. 999999999999 1 )
4. When any number is divided by zero. (Ex. 5 0 )
10
REPLACEMENT OF BATTERY FOR MEMORY PROTECTION
1
2
Time for battery replacement
Replace with a new battery once 2 year.
Method of battery replacement
Use one lithium battery (CR2032). Note: When replacing the battery, the set tax /
discount rate and conversion rate, the memory contents will be lost. You may want to write down the tax / discount rate and conversion rate, other important numbers on a sheet of paper.
1) Turn the power switch “OFF” and unplug the power supply plug from the outlet.
2) Remove the battery cover on the back of the unit. (Fig. 1)
3) Remove the exhausted battery and install one new lithium battery. Wipe the battery well with a dry cloth and place the plus “+” side upward. (Fig.
2)
4) Replace the battery cover by reversing the removal procedure.
5) Press the RESET switch on the back of the unit (See page 14).
Fig. 1
Fig. 2
After battery replacement
Connect the power supply plug to an outlet and
turn the power switch “ON”. Check that “0.” is displayed. If “0.” is not displayed, remove the battery, reinstall it, and check the display again.
Reset the tax / discount rate and conversion rate.
On the battery replacement date label found on
the back of the unit, write down the month and year when the battery is replaced, as a reference for the next battery replacement.
11
Precautions on battery use
Do not leave an exhausted battery in the
equipment.
Do not expose the battery to water or flame, and
do not take it apart.
Store batteries out of the reach of small children.
SPECIFICATIONS
Operating capacity: 12 digits Power supply: Operating:
AC: 220V–230V, 50Hz Memory backup: 3V (DC) (Lithium battery CR2032 ×
1)
Memory Protection Battery lifespan:
Approx. 2 years. (tested and confirmed at 25°C (77°F); may change due to usage environment)
Calculations: Four arithmetic calcula-
tions, constant multiplica­tion and division, power calculation, add-on / dis­count calculation, repeat addition and subtraction, reciprocal calculation, item count calculation, markup calculation, memory cal­culation, etc.
12
PRINTING SECTION
Printer: Mechanical printer Printing speed: Approx. 4.3 lines/sec. Printing paper: 57 mm (2-1/4") ~ 58 mm
(2-9/32") wide 80 mm (3-5/32") in
diameter (max.) Operation temperature: 0°C ~ 40°C (32°F ~ 104°F) Power consumption: 53 mA Dimensions: 250 mm (W) × 345 mm (D)
× 78 mm (H)
9-27/32" (W) × 13-19/32"
(D) × 3-1/16" (H) Weight: Approx. 2.0 kg (4.41 lb.)
(with battery) Accessories: 1 lithium battery, 1 battery
replacement date label
(attached on the unit’s
back body), 1 paper roll, 1
ink ribbon (installed) and
operation manual
WARNING
THE VOLTAGE USED MUST BE THE SAME AS SPECIFIED ON THIS CALCULATOR. USING THIS CALCULATOR WITH A VOLTAGE HIGHER THAN THAT SPECIFIED IS DANGEROUS AND MAY RESULT IN A FIRE OR OTHER TYPE OF ACCIDENT CAUSING DAMAGE. SHARP WILL NOT BE HELD RESPONSIBLE FOR ANY DAMAGE RESULTING FROM USE OF THIS CALCULATOR WITH OTHER THAN THE SPECIFIED VOLTAGE.
13
Loading...
+ 35 hidden pages
