Sharp Compact Image Sensor Camera Line Up Manual

■ Product Line-up of Compact Image Sensor Camera



IV-S30 Series

IV-S50 Series

Character Inspection System

Common to the Series

Item

Controller

Standard

Camera

Camera Converter

Camera Converter Cable

LCD monitor for IV-S50

IV Parameter Setting Support Software

Monochrome Monitor

Micro

High-speed

Micro and High-speed

Color

Camera Cable

Controller

Camera lens

Remote Keypad

LCD monitor
LED Lighting

IV-S31M
IV-S32M
IV-S33M
IV-S31MX
IV-S32MX
IV-S33MX
IV-C35M
IV-S30C1
IV-S30C2
IV-S30C3
IV-S30C4
IV-C30C5
IV-S30EA1
IV-S30HC
IV-S30KC3
IV-S30KC5
IV-S30KC7
IV-S51M
IV-08MP

IV-S20L16
IV-S30RK1
IV-S30SP
IV-09MT
IV-08MTV
IV-60LD

Model

Compact Image Sensor Camera

Grey search time 18 ms*, 16 object types registered
Grey search time 12 ms*, 32 object types registered
Grey search time 9 ms*, 64 object types registered
New menu screen, Grey search time 18 ms*, 16 object types registered
New menu screen, Grey search time 12 ms*, 32 object types registered
New menu screen, Grey search time 9 ms*, 32 object types registered
Color/monochrome camera (up to 2 cameras) available, USB I/F
C mount
Custom Φ17mm mount
C mount, Two/four-times faster
Custom Φ17mm mount, Two/four-times faster
Camera for IV-C35M, Single-plate CCD Camera
Connect with two EIA camera (commercially available)
Cable to connect Camera for IV-S20 (IV-S20C1) and controller
Cable for camera (IV-S30C1/C2/C3/C4, and IV-C30C5) (3m)
Cable for camera (IV-S30C1/C2/C3/C4, and IV-C30C5) (5m)
Cable for camera (IV-S30C1/C2) (7m)
New flow menu screen, Grey search time 8 ms*, 64 object types registered

---

8.4-inch TFT color LCD monitor, Touch panel system
Configured by a controller, camera cable, LCD monitor, remote keypad
Focal distance 16mm C mount lens
Cable length 3 m
Available for Windows95/98/Me/NT4.0/2000
Monochrome 9-inch monitor

8.4-inch TFT color LCD monitor with mounting frame
Lighting controller one-unit type

Specification

Find out Columbus's egg!

Line Up Guide

Item

Common to the series Lens

When search area is 256×256, model is 64×64, and compression is 3

*

Sharp will contribute to the automation of the inspection field by utilizing its know-how and experience in fabricating automated equipment such as
inspection devices with high performance image processor, automated machine for assembling devices, and image sensors with limited functions, which
can be used just as sensors.

- Windows 2000/XP/98 are registered trademarks of the Microsoft Corporation, USA. - Company names, product names, and merchandise names described in this leaflet
are the trademarks or registered trademarks of each respective company. - The specifications may be changed without prior notice. The color of the actual product may vary
from that shown in this brochure. - Some models in this leaflet may be out of stock. Please contact your sales agent for selection of currently available models. - Image
used in the leaflet is the image combine, therefore it may be different from the image actually displayed on the monitor.

IV-1A0101 (ML-0614)
IV-1A0102 (ML-0813)
IV-1A0103 (ML-1214)
IV-1A0104 (ML-2514)
IV-1A0105 (ML-3519)
IV-1A0106 (ML-5018)
IV-1A0107 (ML-7527)
IV-1A0201 (ML-EXR)
IV-1A0301 (MML1-65D)
IV-1A0302 (MML2-65D)
IV-1A1101 (ML17-07516)
IV-1A1102 (ML17-1520)
IV-1A1103 (ML17-2431)
IV-1A1301 (MML1-65D-CM1)

Model

CCTV lens (C mount, f-6 mm)

Specification

CCTV lens (C mount, f-8 mm)
CCTV lens (C mount, f-12 mm)
CCTV lens (C mount, f-25 mm)
CCTV lens (C mount, f-35 mm)
CCTV lens (C mount, f-50 mm)
CCTV lens (C mount, f-75 mm)
Close-up ring (set of 7 middle rings; 0.5, 1, 2, 5, 10, 20, and 40 mm)
Telecentric lens (C mount magnification 1 time)
Telecentric lens (C mount magnification 2 times)
CCTV lens (phi 17 mm mount, f-7.5 mm)
CCTV lens (phi 17 mm mount, f-15 mm)
CCTV lens (phi 17 mm mount, f-24 mm)
Telecentric lens (phi 17 mm mount magnification 1 time)

Concepts of Compact
Image Sensor Camera

Compact Easy to operate Low cost

Standard products

Compact Image Sensor Camera

IV-S33M/S33MX

IV-S32M/S32MX

IV-S31M/S31MX

Low Cost Compact

Image Sensor Camera

IV-S30J

High-Speed

Image Sensor Camera

IV-S200X

Image Sensor Camera

IV-S51M

To use this device effectively and safely!

- Read the instruction manual before use. Make sure to supply the specified power and voltage.

- When using our control equipment (hereinafter referred as "the product"), please be noted that the product shall be used in the way that any
trouble or failure of the product does not lead to any serious, and systematic backup or fail-safe functions shall be executed externally in case of
trouble or failure.

- Our product is designed and manufactured to be used as multi-purpose product for general industrial applications. Therefore, our product shall not
be used in the applications where a major impact to nuclear power plants or any power plants of utility companies may be anticipated and the
special quality assurance system is required. However, even in the above cases, if you acknowledge limiting the usage and not requiring a special
quality assurance system, our product may be used. Please consult with our Sales division to agree on the necessary specification when you
consider using the product in the applications where a major impact may be anticipated to human lives and properties such as in aviation, medical
services, railway service, fuels, fueling devices, manned carrier devices, entertainment devices, and safety machines, and where high-reliability is
required for safety and control system.

4-1-33 Atobe Honmachi, Yao, Osaka, 581-8581, Japan
TEL: [phone] FAX: [phone]

ThedetailsinthispamphletwerecorrectasofJanuary2006.

● Information about SHARP control equipments is available at our

web site http://sharp-world.com/sms/

SMS-076E11201O.5

Color Image Sensor Camera

IV-C35M

Applied products

Character Inspection Device

Character Inspection System

Glue Inspection System

ISO-9001

certification

ＪＱＡ-１３８５

Sharp Manufacturing Systems Co., Ltd.
Our headquarters has received
ISO14001 certification
(environmental management system).

Line-up of Sharp Compact Image Sensor Camera

Standard products Peripherals

IV-S30 Series

Compact Image Sensor Camera High-Speed

[High function, High speed, Customize, Setting wizard, Tree type menu]

IV-S30 Series

IV-S33M/S33MX

・Tree type's menu display

(S33MX)

・64 object types (S33M)
・32 object types (S33MX)
・Gray search time 9ms
・High speed camera available (Two/four-times faster)
・Another camera available other than Sharp

IV-S32M/S32MX

・Tree type's menu display

(S32MX)

・32 object types
・Gray search time 10ms

Low Cost Compact Image Sensor Camera

[High cost-performance, A set product, Compact]

IV-S30J

A set product: Configured

High performance, Multiple functionHigh performance, Multiple function

by units as shown right

・Tree type's menu display
・16 object types
・Gray search time 12ms

Color Image Sensor Camera

[Used for the application are not possible using monochrome camera]

IV-C35M

・Tree type's menu display
・32 object types
・Gray search time 9ms
・Color extraction function
・Color filter function
・Color camera
・Monochrome camera available

Even if monochrome camera is used, color display
of measurement's result is available by color
monitor.

＊

IV-S31M/S31MX

・Tree type's menu display

(S31MX)

・16 object types

＊

・Gray search time 11ms

IV-S30J Units configuration

・Controller (IV-S30 Main body)
・Remote keypad (IV-S30RK1)
・Camera (IV-S30C1)
・Camera cable (IV-S20HC3)

＊

＊

＊

IV-S200X

Image Sensor Camera

High-speed capturing/High-speed processing
& Custom flow editing function for customizing
your performance flow and operation screen

IV-S200X

・

High-speed frame capturing in 5ms

・Grey search about 15 times the

speed of conventional models

・Custom flow editing function for

customizing a performance flow
and operation screen for your use

・GigaBit Ethernet is equipped for

large volume & high-speed
communication

・Repeatability of +/- 0.05 pixel has

been realized

IV-S51M

Image Sensor Camera

Usability, Visibility, and Comprehensibility,
Suitable setting with no difference among
individuals

IV-S51M

・64 object types
・Gray search time 8ms
・Direct setting by finger or stylus

pen (Also handy mouse available)

・Flow type menu, no need of

procedure sheet

・Free style drawing for setting

measurement area

・Automatically camera inclination

and lens distortion

＊

Applied products

Character Inspection Device

Character Inspection System

・16 object types
・Inspects not only alphanumeric

and symbol, also Chinese
characters and Kana/others

・Verify not only touched

characters, also different size
characters

Image Positioning Controller

IV-A33M4

・Adaptable to triaxial and

quadaxial structure

・High-speed camera can be

connected (double
speed/quadruple speed)

・Auto calibration function

Glue Inspection System

・Inspects "Glue condition" and

"Folding" of printed packages

・No need of rotary encoder by

using CCD trigger function

・Connect with two cameras

available

IV-60LD

Parameter setting
support software

IV-S50SPM

・Use for Windows９８/XP/2000
・Function to store parameter
・

Function to gather measurement data

・Function to version-up
・Use for IV-S51M

IV-S30SP

・Use for Windows９５/９８/Me/

NT4.0/XP/2000

・Function to store parameter
・

Function to edit parameter setting list

・

Function to gather measurement data

・Function to version-up
・Use for IV-C35M
・

Use for all models of IV-S30 series

※

Comparison

Gray search time

No. of assignable

object types

Connect with high

speed camera

Connect with general

marketed EIA camera

Menu customize

Full customize

Store NG image

Communication

Calendar timer

IV-S30J

12ms

＊

16

×

×

○

○

×

×

×

IV-S31M

/S31MX

＊

11ms

16/16

×

×

×/○

Customized

bySMS

×

USB

×

MonitorLED lighting

−2modelsall−

CCTV lens

(C mount)

−IV-S20L16etc,8modelsall−

Telecentric lens

(C mount)

−2modelsall−

CCTV lens

(17φ mount)

−3modelsall−

Telecentric lens

(17φ mount)

−2modelsall−

※Please contact with our sales staff if
 you need.

IV-S32M

/S32MX

10ms

32/32

×/○

USB

IV-S33M

/S33MX

＊

9ms

64/32

×

×

×/○

○

○

USB

○

IV-C35M

(Color)

＊

9ms

○

○

○

○

USB

○

＊

32

○

×

○

○

○

○

IV-S51M

8ms

64

○

×

○

Customized

bySMS

○

Ether-net

○

＊

IV-S200X

＊

0.6ms

32

○

×

○

○

○

Ether-net

○

＊In case of: search area 256x256, model 64x64, compression 3.
