Sharp C-40LE362EN, C-32LE360EN, LC-32LE361EN, LC-32LE362EN, LC-32LE363EN User Manual
...
DEUTSCH
LC-32LE360EN / LC-32LE361EN
LC-32LE361K / LC-32LE362EN
LC-32LE363EN / LC-40LE360EN
LC-40LE361EN / LC-40LE361K
LC-40LE362EN / LC-40LE363EN
LCD COLOUR TELEVISION OPERATION MANUAL
LCD-FARB-TV BEDIENUNGSANLEITUNG
TÉLÉVISEUR LCD COULEUR
TELEVISIONE A COLORI LCD MANUALE DI FUNZIONAMENTO
TELEVISOR LCD A COLOR MANUAL DE INSTRUCCIONES
TELEVISÃO LCD A CORES MANUAL DE INSTRUÇÕES
LCD RENKLİ TELEVİZYON
LCD FÄRG-TV BRUKSANVISNING
LCD FARGE-TV
LCD FARVE-TV BRUGSANVISNING
LCDVÄRI-TV KÄYTTÖOHJE
LCD KLEURENTELEVİSİE GEBRUIKSAANWIJZING
ΧΕΙΡΟΚΊΝΗΤΗ ΛΕΙΤΟΥΡΓΊΑ ΧΕΙΡΟΚΊΝΗΤΗ ΛΕΙΤΟΥΡΓΊΑ
TELEVIZOR LCD COLOR MANUAL DE UTILIZARE
BAREVNI LCD TELEVİZOR NÁVOD K POUŽİTÍ
LCD SZÍNES TELEVÍZİÓ HASZNÁLATI ÚTMUTATÓ
LCD COLOUR TELEVISION OPERATION MANUAL
LCD TELEVIZOR U BOJI KORISNIČKI PRIRUČNIK
BARVNİ LCD TELEVİZOR NAVODILA ZA UPORABO
LCD COLOUR TELEVISION OPERATION MANUAL
LCD ЦВЕТНЫЕ ТЕЛЕВИЗОРЫ ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
ЦВЕТЕН LCD ТЕЛЕВИЗОР РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ
КОЛЬОРОВИЙ РК-ТЕЛЕВІЗОР ПОСІБНИК З КОРИСТУВАННЯ
КАЛЯРОВЫ ВК-ТЭЛЕВIЗАР
SPALVOTAS LCD TELEVIZORIAUS NAUDOTOJO VADOVAS
LCD KRĀSU TELEVIZORS LIETOŠANAS INSTRUKCIJA
LCD VÄRVITELEVIISOR KASUTUSJUHEND
LCD ךסמ םע תינועבצ היזיוולט הלעפה ךירדמ
MODE D’EMPLOI
KULLANIM KILAVUZU
BRUKERHÅNDBOK
PRIRUČNIK O RADULCD TELEVİZOR U BOJİ
ІНСТРУКЦЫЯ ПА ЭКСПЛУАТАЦЫІ
FRANÇAİS
ITALIANO ENGLISH
ESPAÑOL
PORTUGUÊS
TÜRKÇENORSK
DANSK
SUOMİ SVENSKA
NEDERLANDS
EΛΛΗVΙΚROMÂNĂMAGYAR
POLSKİ
HRVATSKİ ČEŠTİNA
SLOVENŠČİNA
SLOVENČİNASRPSKİ
РУССКИЙ
БЪЛГАРСКИ
УКРАЇНСЬКА
БЕЛАРУСКАЯ
LİETUVİŲ
LATVİEŠUEESTİ
Contents
TV - Features ......................................................... 2
Dear SHARP customer ........................................... 3
Important safety precautions .................................. 3
Environmental Information ..................................... 6
Package Contents .................................................. 6
TV Control button & Operation ............................... 6
Connect Power ....................................................... 7
Antenna/Cable/Satellite Connection ....................... 7
Installing The Batteries Into The Remote ............... 7
Angle of the remote control unit .......................... 7
Cautions regarding the remote control unit ........ 7
Switching On/Off ..................................................... 7
To Switch the TV On ........................................... 7
To Switch the TV to Standby ............................... 7
To Switch the TV Off ........................................... 7
Viewing remote control - TV ................................... 8
Viewing the Connections ........................................ 9
Using a Conditional Access Module ..................... 10
Standby Notications ............................................ 10
First Time Installation.............................................11
Aerial Installation ...............................................11
Cable Installation ...............................................11
Satellite Installation (depends on the model) .....11
Media Playback via USB Input ..............................11
Media Browser Menu .........................................11
Changing Image Size: Picture Formats ................ 12
Using the Channel List ......................................... 12
Quick Menu .......................................................... 12
CEC and CEC RC Passthrough ........................... 12
System Audio Control ....................................... 12
FollowMe TV ..................................................... 12
FollowMe TV to DMR ........................................ 12
Menu Features and Functions .............................. 13
Picture Menu Contents ..................................... 13
Advanced Settings ............................................ 13
Menu Features and Functions .............................. 14
Sound Menu Contents ...................................... 14
Settings Menu Contents ................................... 14
Other Settings: Displays other setting options of
the TV set ......................................................... 14
Menu Features and Functions .............................. 15
Install and Retune Menu Contents ................... 15
Electronic Programme Guide (EPG) .................... 16
Programme Options.......................................... 16
Teletext ................................................................. 16
Digital Teletext (for UK only) ............................. 16
Recording a Programme ...................................... 16
Timeshift Recording ............................................. 17
Instant Recording ................................................. 17
Watching Recorded Programmes ....................... 17
Available playback options ............................... 17
English - 1 -
Recording Conguration ....................................... 17
Connectivity Functions ......................................... 17
Connecting TV to a Home Network .................. 17
Conguring Network Settings ........................... 18
Connecting to your mobile device via WiFi ....... 18
Using MIRACAST ............................................. 18
Using DLNA Network Service ........................... 19
Internet Portal ....................................................... 19
Netix.................................................................... 19
HBBTV System..................................................... 20
Connectivity Troubleshooting ............................... 21
Wireless Network Not Available ........................ 21
Connection is Slow ........................................... 21
Distruption during playback or slow reactions .. 21
Software Upgrade................................................. 21
Troubleshooting & Tips ......................................... 21
Image persistence - ghosting............................ 21
No power .......................................................... 21
The TV cannot be operated .............................. 21
Poor picture ...................................................... 21
No picture ......................................................... 22
No sound .......................................................... 22
Remote control - does not operate .................. 22
Power is suddenly turned off ............................ 22
Input sources - can not be selected .................. 22
Recording Unavailable ..................................... 22
USB Is too Slow ............................................... 22
Internet Connection Not Available / DLNA Mode
Not Operating ................................................... 22
Invalid Domain ................................................. 22
The TV sometimes makes a cracking sound. ... 22
Miracast image/audio cannot be output to the TV. .. 22
PC Typical Display Modes ................................... 23
AV and HDMI Signal Compatibility (Input Signal
Types) ................................................................... 23
Supported File Formats for USB Media Browser . 24
Supported File Formats for by MKV ..................... 25
Supported DVI Resolutions .................................. 25
Specications .............................................................26
Licence Notications............................................. 26
EC Declaration of Conformity ............................... 27
Disclaimers for services using the Internet ........... 27
Nero MediaHome Installation ............................... 28
End of life disposal ............................................... 29
Dimensional Drawings .......................................... 30
Installing the Stand ............................................... 31
Uninstalling the Stand........................................... 32
Screw Dimensions Wall Mounting ........................ 33
SPECIAL NOTE FOR USERS IN THE U.K.
The mains lead of this product is tted with a non-
rewireable (moulded) plug incorporating a 5A fuse.
Should the fuse need to be replaced, a BSI or ASTA
approved BS 1362 fuse marked
same rating as above, which is also indicated on the
pin face of the plug, must be used.
Always ret the fuse cover after replacing the fuse.
Never use the plug without the fuse cover tted.
In the unlikely event of the socket outlet in your home
not being compatible with the plug supplied, cut off
the mains plug and t an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and
the cut-off plug destroyed immediately and disposed
of in a safe manner.
Under no circumstances should the cut-off plug be
inserted elsewhere into a 5A socket outlet, as a
serious electric shock may occur.
To t an appropriate plug to the mains lead, follow the
instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this
product may not correspond with the coloured
markings identifying the terminals in your plug,
proceed as follows:
• The wire which is coloured blue must be connected
to the plug terminal which is marked N or coloured
black.
• The wire which is coloured brown must be connected
to the plug terminal which is marked L or coloured
red.
Ensure that neither the brown nor the blue wire is
connected to the earth terminal in your three pin plug.
Before replacing the plug cover make sure that:
• If the new tted plug contains a fuse, its value is the
same as that removed from the cut-off plug.
• The cord grip is clamped over the sheath of the
mains lead, and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED
ELECTRICIAN.
ASA
or and of the
English - 2 -
TV - Features
• Remote controlled colour LED TV.
• Fully integrated digital/cable TV (DVB-T-T2/C-
S-S2).
HD DVB-T/C/S2(MPEG4) :
LC-40LE362EN / LC-32LE362EN
HD DVB-T2/C/S2(MPEG4) :
LC-40LE363EN / LC-32LE363EN
HD DVB-T/CABLE(MPEG4) :
LC-40LE360EN / LC-32LE360EN
HD DVB-T2/CABLE(MPEG4) :
LC-40LE361EN / LC-32LE361EN
HD DVB-T2/CABLE(MPEG4):
LC-40LE361K / LC-32LE361K
• DVB-T2, DVB-S/S2 compliance and support is
depending on the model
• HDMI connectors for digital video and audio.This
connection is also designed to accept high denition
signals.
• USB input.
• Programme recording.
• Programme timeshifting.
• 1000 programmes.
• OSD menu system.
• Scart socket for external devices (such as video, video
games, audio set, etc.).
• Stereo sound system.
• Teletext, fastext, TOP text.
• Headphone connection.
• Automatic programming system.
• Forward or backward manual tuning.
• Automatic power down after up to eight hours.
• Sleep timer.
• Child lock.
• Automatic sound mute when no transmission.
• NTSC playback.
• AVL (Automatic Volume Limiting).
• PLL (Frequency Search).
• PC input.
• Plug&Play for Windows 98, ME, 2000, XP, Vista,
Windows 7.
• Game Mode.
• Picture off function.
• Ethernet (LAN) for Internet connectivity and service.
• 802.11n built in WIFI Support
• DLNA (DMP, DMR)
• HBBTV (This feature is not available for UK models)
• Miracast.
The illustrations and the OSD in this operation manual
are for explanation purposes and may vary slightly
from the actual operations.
Dear SHARP customer
Thank you for your purchase of the SHARP LCD
colour TV product. To ensure safety and many years
of trouble-free operation of your product, please read
Important safety precautions carefully before using
this product.
This device is intended to receive and display TV
programs. The different connection options make
an additional expansion of the reception and display
sources possible (receiver, DVD player, DVD recorder,
VCR, PC etc.). This device is only suitable for the
operation in dry interiors. This appliance is intended
solely for private domestic use and may not be used
for industrial and commercial purposes. We exclude
liability in principle, if the device is not used as
intended, or unauthorized modications have been
made. To operate your LCD TV in extreme ambient
conditions may cause the damage of the device.
Important safety precautions
• Use a soft damp cloth to gently wipe the panel when
it is dirty. To protect the panel, do not use a chemical
cloth to clean it. Chemicals may cause damage or
cracks in the cabinet of the TV.
• Water and moisture—Do not use the product near
water, such as bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in a wet basement.
• Do not place vases or any other
water-filled containers on this
product. The water may spill onto
the product causing re or electric
shock.
• To prevent any fault and unsafe
situations, please do not place any objects on top
of the set.
• If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualied
personnel before operating it any further.
• Stand—Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as damage
to the product. Use only a cart,
stand, tripod, bracket or table
recommended by the manufacturer or sold with the
product. When mounting the product on a wall, be
sure to follow the manufacturer’s instructions. Use
only the mounting hardware recommended by the
manufacturer.
• When relocating the product placed on a cart, it
must be moved with utmost care. Sudden stops,
excessive force and uneven oor surface can cause
the product to fall from the cart.
• Ventilation—The vents and other openings in the
cabinet are designed for ventilation. Do not cover
or block these vents and openings since insufcient
ventilation can cause overheating and/or shorten
the life of the product. Do not place the product on
a bed, sofa, rug or other similar surface, since they
can block ventilation openings. This product is not
designed for built-in installation; do not place the
product in an enclosed place such as a bookcase
or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
• Use this device in moderate climates.
For ventilation, leave a free space of at least 10 cm
all around the set. To prevent any fault and unsafe
situations, please do not place any objects on top
of the set.
• The LCD panel used in this product is made of glass.
Therefore, it can break when the product is dropped
or impact applied. If the LCD panel is broken, be
careful not to be injured by broken glass.
• Heat sources—Keep the product
away from heat sources such as
radiators, heaters, stoves and other
heat-generating products (including
ampliers).
• To prevent re, never place any type
of candle or naked ames on the top
or near the TV set.
• To prevent re or shock hazard, do not place the AC
cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this
could cause an afterimage to remain.
• There is power consumption always if main plug
is connected.
• Servicing—Do not attempt to service the product
yourself. Removing covers can expose you to high
voltage and other dangerous conditions. Request a
qualied person to perform servicing.
Precautions when transporting the TV
When transporting the TV, never carry it by holding
onto the speakers. Be sure to always carry the TV by
two people holding it with two hands—one hand on
each side of the TV.
English - 3 -
WARNING
To prevent the spread of re, keep
candles or other open ames away
from this product at all times.
Power Source
The TV set should be operated only from a 220-240V
AC, 50Hz outlet. Ensure that you select the correct
voltage setting for your convenience.
Power Cord
Do not place the set, a piece of furniture, etc. on the
power cord (mains lead) or pinch the cord.
Handle the power cord by the plug. Do not unplug the
appliance by pulling from the power cord and never
touch the power cord with wet hands as this could
cause a short circuit or electric shock. Never make a
knot in the cord or tie it with other cords. The power
cords should be placed in such a way that they are
not likely to be stepped on. A damaged power cord
can cause re or give you an electric shock. When it
is damaged and needs to be replaced, it should be
done by qualied personnel.
Moisture and Water
Do not use this device in a humid and damp place
(avoid the bathroom, the sink in the kitchen, and near
the washing machine). Do not expose this device to
rain or water, as this may be dangerous and do not
place objects lled with liquids, such as ower vases,
on top. Avoid from dripping or splashing. If any solid
object or liquid falls into the cabinet, unplug the TV
and have it checked by quali ed personnel before
operating it any further.
Cleaning
Before cleaning, unplug the TV set from the wall
outlet. Do not use liquid or aerosol cleaners. Use
soft and dry cloth.
Heat and Flames
The set should not be placed near to open ames and
sources of intense heat such as an electric heater.
Ensure that no open ame sources, such as lighted
candles, are placed on top of the TV. Batteries should
not be exposed to excessive heat such as sunshine,
re or the like.
Caring for the cabinet
• Use a soft cloth (cotton, annel, etc.) and gently wipe
the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth,
etc.) may deform the components of the main unit
cabinet or cause cracking.
• Wiping with a hard cloth or using strong force may
scratch the surface of the cabinet.
English - 4 -
• If the cabinet is very dirty, wipe with a soft cloth
(cotton, annel, etc.) soaked in neutral detergent
diluted with water and thoroughly wrung out, and
then wipe with a soft dry cloth.
• Avoid using benzene, thinner, and other solvents,
as these may deform the cabinet and cause the
paint to peel off.
• Do not apply insecticides or other volatile liquids.
Also, do not allow the cabinet to remain in contact
with rubber or vinyl products for a long period of
time. Plasticizers inside the plastic may cause the
cabinet to deform and cause the paint to peel off.
Caring for the front panel
• Turn off the main power and unplug the AC cord
from the wall outlet before handling.
• Gently wipe the surface of the front panel with a
soft cloth (cotton, annel, etc.). To protect the front
panel, do not use a dirty cloth, liquid cleaners, or a
chemical cloth (wet/dry sheet type cloth, etc.). This
may damage the surface of the front panel.
• Wiping with a hard cloth or using strong force may
scratch the surface of the front panel.
• Use a soft damp cloth to gently wipe the front panel
when it is really dirty (It may scratch the surface of
the front panel when wiped strongly).
• If the front panel is dusty, use an anti-static brush,
which is commercially available, to clean it.
Lightning
In case of storm and lightning or when going on
holiday, disconnect the power cord from the wall outlet.
Replacement Parts
When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specied by the manufacturer or have the
same specications as the original one. Unauthorized
substitutions may result in re, electrical shock or
other hazards.
Servicing
Please refer all servicing to qualied personnel. Do
not remove the cover yourself as this may result in
an electric shock.
Waste Disposal
• Packaging and packaging aids are recyclable and
should principally be recycled. Packaging materials,
such as a foil bag should be kept away from children
• Batteries, including those which are heavy metal
free, should not be disposed of with household
waste. Please dispose of used batteries in an
environmentally friendly manner. Find out about the
legal regulations which apply in your area.
• Do not try to recharge batteries, there is a danger
of explosion. Replace batteries only with the same
or equivalent type.
• Batteries should not be exposed to excessive heat
such as sunshine, re or the like.
This symbol on the product or on its
packaging means that your electrical
and electronic device should be disposed
at the end of its service life separately
from your household wastes. There are
separate collection systems for recycling
in the EU. For more information, please
contact the local authority or the dealer
where you purchased the product.
Disconnecting the Device
The mains plug is used to disconnect the TV set
from the mains and therefore it must remain readily
operable.
Headphone Volume
Excessive sound pressure from earphones and
headphones can cause hearing loss.
Installation
To prevent injury, this device must be securely
attached to the wall in accordance with the installation
instructions when mounted to the wall (if the option
is available).
LCD Screen
The LCD panel is a very high technology product with
about a million thin lm transistors, giving you ne
picture details. Occasionally, a few non-active pixels
may appear on the screen as a xed blue, green or
red point. Please note that this does not affect the
performance of your product.
Warning
Do not leave your TV in standby or operating mode
when you leave your house.
Connection to a Television Distribution
System (Cable TV etc.) from Tuner
Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using
coaxial cable, may in some circumstances create a
re hazard.
Connection to a cable distribution system has
therefore to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator, see EN 60728-11).
Note:The HDMI connection between PC and TV may cause
radio interference in which case it is recommended to use
VGA(DSUB-15) connection.
The Standby Off/On button doesn´t separate this
device completely from mains. Moreover the device
consumes power in the standby operation. In order to
separate the device completely from mains, the mains
plug has to be pulled from the mains socket. Because
of that the device should be set up in a way, that an
unobstructed access to mains socket is guaranteed,
so that in case of emergency the mains plug can be
pulled immediately. To exclude the danger of re, the
power cord should principally be separated from the
mains socket prior to a longer period of non-usage,
i.e. during vacations.
Electrical device not in the hands of
children
Never let children use any electrical device
unsupervised. Children cannot always recognise
possible dangers. Batteries / accumulators can be
life threatening when swallowed. Store batteries out
of the reach of small children. In case of swallowing
a battery medical aid has to be sought immediately.
Also keep the packaging foils away from children as
there is danger of suffocation.
English - 5 -
Environmental Information
This television is designed to consume less energy
to help save the environment. To reduce energy
consumption, you should take the following steps:
You can use Power Save Mode setting, located
in the Picture menu. If you set Power Save Mode
as Eco, the TV will switch to energy-saving mode
and luminance level of TV set will be decreased to
optimum level. Note that some picture settings will be
unavailable to be changed when the TV is in Power
Save Mode.
When you press the right button on the remote while
Power Save Mode is set to “Eco”, “Screen will be
off in 15 seconds.” message will be displayed on
the screen. If the Power Save Mode option is set to
“Disabled” press the left button. Select PROCEED
and press OK to continue. The screen will turn off
immediately. If you do not press any buttons the
screen will turn off after 15 seconds.
If you disable Power Save Mode, the picture mode
will be automatically set to Dynamic except the Mode
is set to Game or Sports.
When the TV is not in use, please switch off or
disconnect the TV from the mains plug. This will also
reduce energy consumption.
Disconnect power when going away for longer time.
It is highly recommended to activate Power Save Mode
setting to reduce your annual power consumption. And
also it is recommended to disconnect the TV from the
mains plug to save energy more when you do not use.
Please help us to save environment by following
these steps.
Package Contents
TV
LCD TV
Quick Guide
Remote Control
Note: You should check the accessories after purchasing.
Make sure that each accessory is included.
As the manufacturer’s specification supports
communication on cable lengths shall be smaller
than 3m.
Batteries: 2 X AAA
1 X Video & Audio Connection
Cable
TV Control button & Operation
1. Up direction
2. Down direction
3. Volume / Info / Sources List selection and
Standby-On switch
The Control button allows you to control the Volume
/ Programme / Source and Standby-On functions of
the TV.
The position of the power switch may differ depending
on the model.
English - 6 -
, switch is used for turning the TV on or off.
Connect Power
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket. After unpacking, allow
the TV set to reach the ambient room temperature
before you connect the set to the mains. Plug the
power cable to the mains socket outlet.
Antenna/Cable/Satellite Connection
Connect the aerial or cable TV plug to the AERIAL
INPUT (ANT.) or satellite lead to the SATELLITE
INPUT(LNB) located on the rear side of the TV.
“Satellite is only available in 362/363 series”.
Rear side of the TV:
SATELLITE
AERIAL
CABLE
Note: Satellite support is depending on the model.
(only available in LC-32LE363EN / LC-32LE362EN
/ LC-40LE363EN / LC-40LE362EN series)
Installing The Batteries Into The
Remote
• Remove the back cover to reveal the battery
compartment.
• Insert two size AAA batteries. Note the correct
polarity(+ or -). Do not mix old and new batteries.
Replace only with same or equivalent type.
• Place the cover back on.
• Do not install or place the remote control unit under
direct sunlight. The heat may cause deformation
of the unit.
• The remote control unit may not work properly if
the remote control sensor of the TV is under direct
sunlight or strong lighting. In such cases, change the
angle of the lighting or the TV, or operate the remote
control unit closer to the remote control sensor.
Switching On/Off
To Switch the TV On
Connect the power cord to the mains socket. Switch
the “ ” button on the TV to position “|” so the TV
will switch to standby mode. Then the standby LED
lights up.
To switch on the TV from standby mode either:
• Press the “ ” button, P+ / P- or a numeric button
on the remote control.
• Press the side function switch on the TV until the TV
comes on from standby.
The TV will then switch on.
To Switch the TV to Standby
To switch the TV to low power standby press the
“ ” button on the remote control or press the side
function switch on the TV until the TV switches into
standby mode.
To Switch the TV Off
Switch the “ ” button on bottom of the TV to
position 2 as illustrated - “ ”, to isolate the TV from
the mains, the LED will go out.
Angle of the remote control unit
Use the remote control unit by pointing it towards the
remote control sensor.
Objects between the remote control unit and sensor
may prevent proper operation.
Cautions regarding the remote control unit
• Do not expose the remote control unit to shock.
In addition, do not expose the remote control unit
to liquids, and do not place in an area with high
humidity.
English - 7 -
Viewing remote control - TV
1. Standby / On
2. Channel list
3. Volume up / down
4. Menu on/off
5. OK / Conrm
6. Return / Back
7. Internet Portal
8. My button / YouTube (*)
9. Press this button to launch the Netix application.
(Netix service is only available in certain countries)
10. Coloured buttons (Red, Green, Yellow, Blue)
11. Mono-Stereo Dual I-II / Current language
12. Fast rewind (in media browser mode)
13. Pause (in media browser mode) / Timeshift
recording
14. Programme recording
15. Play (in media browser mode)
16. Stop (in media browser mode)
17. Fast forward (in media browser mode)
18. Subtitle on-off / Subtitle (in media browser
mode)
19. Image size
20. Teletext - Mix
21. Media Browser
22. Electronic programme guide
23. Exit
24. Navigation buttons
25. Quick menu On-Off
26. Info / Reveal (in TXT mode)
27. Programme up / down
28. Mute
29. Previous programme
30. Numeric buttons
31. AV / Source
TV
Note: The Remote Control range is approximately 7m / 23ft.
Using My button (*)
This button’s main function is to run YouTube link.
However, if you want to change this function, you can
press MY BUTTON 1 for ve seconds when on a
desired source or channel, until the “MY BUTTON IS
SET” message is displayed on the screen. This conrms
that the selected MY BUTTON is now associated with
the selected function. Note that if you perform rst time
installation, MY BUTTON 1 will return to its default
function.
English - 8 -
Viewing the Connections
Connector Type Cables Device
Scart
Connection
(back)
VGA
Connection
(back)
PC/YPbPr
Audio
LAN
Connection
(side)
HDMI (1,2,3)
Connection
(back)
SPDIF
(Coaxial Out)
Connection
(back)
Side AV
(Audio/Video)
Connection
(side)
Headphone
Connection
(side)
YPbPr Video
Connection
(back)
USB
Connection
(side)
CI
Connection
(side)
Ethernet (LAN)
Connection
(back)
Side Audio/Video
Connection Cable
(Supplied)
Side AV
Connection Cable
(supplied)
Connection Cable
PC to YPbPr
(Not supplied)
PC Audio Cable
(Not supplied)
CAM
module
Note: When connecting a device
via the YPbPr or Side AV input,
you must use connection
cables to enable connection.
For Side AV input you should
use the supplied cable. See the
illustrations on the left side. | You
can use YPbPr to VGA cable (not
supplied) to enable YPbPr signal
via VGA input. | You cannot use
VGA and YPbPr at the same
time.| To enable PC/YPbPr
audio, you will need to use the
SIDE AV socket with a PC audio
cable (not supplied) for audio
connection, using the supplied
Side AV connection cable’s
RED and WHITE inputs.| If an
external device is connected
via the SCART socket, the TV
will automatically switch to AV
mode.| When receiving DTV
channels (Mpeg4 H.264) or
while in Media Browser mode,
output will not be available via
the scart socket. | When using
the wall mounting kit (available
from third party in the market),
we recommend that you plug
all your cables into the back
of the TV before mounting on
the wall. | Insert or remove
the CI module only when the
TV is SWITCHED OFF. You
should refer to the module
instruction manual for details of
the settings. | Each USB input
of your TV supports devices up
to 500mA. Connecting devices
that have current value above
500mA may damage your TV.
| By connecting an HDMI cable
to your TV, you have to use
only a shielded HDMI cable to
guarantee a sufcient immunity
against parasitic frequency
radiation.
If you want to
connect a device to
the TV, make sure
that both the TV and the
device are turned off before
making any connection. After
the connection is done, you
can turn on the units and use
them.
English - 9 -
Using a Conditional Access Module
IMPORTANT: Insert or remove the CI module only when
the TV is SWITCHED OFF.
In order to watch certain digital channels, a conditional
access module (CAM) can be necessary. This module
must be inserted in the CI slot of your TV.
1. Obtain the Conditional Access Module (CAM) and
the viewing card by subscribing to a pay channel
company, then insert those to the TV using the
following procedure.
2. Insert the CAM and then the viewing card to the
slot that is located in the terminal cover at the
rear side of the TV.
3. The CAM should be correctly inserted, it is
impossible to insert fully if reversed. The CAM
or the TV terminal may be damaged if the
CAM is forcefully inserted.
4. Connect the TV to the mains supply, switch
on and then wait for few moments until the
card is activated.
5. When no module is inserted, “No Common
Interface module detected” message
appears on the screen.
You can refer to the module instruction manual for
details of the settings.
Note: It takes a few minutes to certify the licence key when
you insert a CA card into the CI+ compatible CI module for
the rst time. This process may fail when there is no antenna
input or you have never run “Auto installation”. If the old CAM
is used, authentication may fail. In such cases, contact the
contracted service provider.
Standby Notications
If the TV does not receive any input signal (e.g. from
an aerial or HDMI source) for 5 minutes, the TV will go
into standby. When you next switch-on, the following
message will be displayed:
“TV switched to stand-by mode automatically
because there was no signal for a long time.”
Press OK to continue.
If the TV has been left on and not been operated for
a while, the TV will go into standby. When you next
switch-on, the following message will be displayed:
“TV switched to stand-by mode automatically
because no operation was made for a long time.”
Press OK to continue.
When the Auto TV OFF timeout is reached, the
following message will be displayed on the screen:
“Shut Down?”
Select Yes to shut down the TV. Select No to cancel.
The TV will switch off as well, if you do not make a
selection on this screen.
CAM
module
English - 10 -
Loading...
