PARTS GUIDE
CODE:00ZARM450/P1E
LASER PRINTER
(MULTI FUNCTION)
AR-M350
AR-M450
OPTION: AR-EF1
AR-M11
MODEL AR-RK1
CONTENTS
1 Exteriors
H Controller BOX unit
M Packing material & Accessories
V MFP Control PWB
(ARM350/M450/350M/450M/ARM11)
W Exteriers[AR-EF1]
X Original detect unit[AR-EF1]
Y Operation panel unit[AR-EF1]
Z Optical unit 1[AR-EF1]
[ Optical unit 2[AR-EF1]
\ Lamp unit[AR-EF1]
] DSPF Assembly section[AR-EF1]
^ DSPF Paper feed unit[AR-EF1]
_ DSPF Upper transfer unit[AR-EF1]
. DSPF CIS unit[AR-EF1]
a Packing Material & Accessories[AR-EF1]
b MFP OPE PWB[AR-EF1]
c Scanner control PWB[AR-EF1]
d CIS Control PWB[AR-EF1]
e MFP Controler PWB[AR-M11]
f Packing material & Accessories[ARM11]
g Packing Material & Accessories[AR-RK1]
■ Index
The AR-M350 / AR-M450 Parts Guide describes only the parts change from AR-P350 / AR-P450 Parts Guide.
for the common parts,please refer to the AR-P350 / AR-P450(CODE : 00ZAR350LPP1/) Parts Guide.
This document has been published to be
SHARP CORPORATION
used for after sales service only.
The contents are subject to change without
notice.
DEFINITION
The definition of each Rank is as follows and also noted in the lis t
A : Parts necessary to be stocked as High usage parts.
B : Parts necessary to be stocked as Standard usage parts.
C : Low usage parts.
D : Parts necessary for refurbish.
E : Unit parts recommended to be stocked for efficient after sales service.
Please note that the lead time for the said parts may be longer than normal parts.
S : Consumable parts.
Please note that the following parts used in Copier under the same description are classi fied into A or B Rank depending
upon the place used.
Example : Gear made of Metal, Sprocket, Beari ng, Belt made of Rubber, Spring clutch mechanism.
A Rank : The parts which may be with the revolution or loading.
B Rank : Parts similar to A Rank parts, but are not included in Rank A.
Because parts marked with "!" is indispensable for the machine safety maintenance and operati on, it must be replaced with
the parts specific to the product specification.
F Other than this Parts Guide, please refer to documents Service Manual (including Circuit Diagram) of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
[Note] ∗ These parts are supplied by SMF.
1Exteriors
PRICE
NO. PARTS CODE
GCAB-0940FCZ2 BA
5
HPNLC0243FCZ1 AP
11
CPNLH0020QS12 AK
CPNLH0020QS13 AK
26
CPNLH0020QS22 AK
CPNLH0020QS23 AK
RANK
NEW
MARK
N D Paper exit tray exterior
N D Operation cabinet
N D Model panel M350 [ARM350]
N D Model panel M450 [ARM450]
N D Model panel 350M [AR350M]
N D Model panel 450M [AR450M]
12 Controller BOX unit
PRICE
NO. PARTS CODE
LX-BZ0921FCZ1 AE
25
XBPSD26P06000 AA
26
LPLTM5765FCZ1 AH
35
PCOVP1560FCZZ AC
37
PCOVP1557FCZZ AC
38
XBPSD30P06000 AA
47
XHBSE30P06000 AA
50
XBBSD30P06000 AA
51
VHI28F322L01F BE
54
VHI28F322L03F BF
VHI28F322L02F BF
55
VHI28F322L04F BL
LX-BZ0828FCZZ AD
56
RANK
NEW
MARK
N C Scanner Screw
N C Control joint plate
N C FAX I/F cover
N B MFP flash ROM A J (28F322L01F) [Japan]
N B MFP flash ROM A EX (28F322L03F) [except Japan]
N B MFP flash ROM B J (28F322L02F) [Japan]
N B MFP flash ROM B EX (28F322L04F) [except Japan]
PART
RANK
PART
RANK
C Screw (2.6×6)
C LAN/option cover
CScrew (3×6)
CScrew (3×6)
CScrew (3×6)
C Handle fixing screw
DESCRIPTION
DESCRIPTION
– 1 –
12 Controller BOX unit
50
26
17 Packing material & Accessories
PRICE
NO. PARTS CODE
SPAKC6122DS18 AU
SPAKC6122DS19 AU
SPAKC6122DS17 AU
SPAKC6122DS21 AU
5
SPAKC6122DS22 AU
SPAKC6122DS20 AU
SPAKC6118DS12 AU
SPAKC6118DS13 AU
PSHEP4927FCZZ AM
PSHEP4927FCZ1 AR
PSHEP4927FCZ2 AM
PSHEP4927FCZ3 AR
PSHEP4927FCZ4 AR
PSHEP4927FCZ5 AR
13
PSHEP4927FCZ6 AR
PSHEP4927FCZ7 AR
PSHEP4927FCZ8 AR
PSHEP4927FCZ9 AR
PSHEP4927FC10 AR
PSHEP4927FC11 AR
TINSE2181FCZZ AT
TINSJ2076FCZZ AQ
TINSE2077FCZZ AQ
TINSE2078FCZZ AW
} TINSG2080GHZZ AS
} TINSE2081GHZZ AS
} TINSI2083GHZZ AS
} TINSH2084GHZZ AS
} TINSW2089GHZZ AS
} TINSZ2090GHZZ AS
} TINSZ2091GHZZ AS
} TINSD2092GHZZ AS
} TINSZ2093GHZZ AS
} TINSZ2094GHZZ AS
} TINSZ2095GHZZ AS
} TINSG2122GHZZ AS
} TINSE2123GHZZ AS
} TINSI2125GHZZ AS
} TINSH2126GHZZ AS
} TINSW2131GHZZ AS
} TINSZ2132GHZZ AS
} TINSZ2133GHZZ AS
} TINSD2134GHZZ AS
} TINSZ2135GHZZ AS
} TINSZ2136GHZZ AS
} TINSZ2137GHZZ AS
TINSF2079FCZZ AW
TINSS2082FCZZ AW
CINSR2085FC51 AS
CINSZ2086FC51 AS
TINSE2087FCZZ AX
20
TINSJ2118FCZZ AN
TINSE2119FCZZ AN
TINSE2120FCZZ AV
TINSF2121FCZZ AV
TINSS2124FCZZ AV
CINSR2127FC51 AR
CINSZ2128FC51 AR
TINSE2129FCZZ AV
RANK
NEW
MARK
38
26
47
51
37
47
47
25
51
50
38
56
55
54
51
51
51
51
56
51
35
PART
RANK
N D Packing case [ARM350][STCL,SRS,SRSSC]
N D Packing case [ARM350][China]
N D Packing case [ARM350][other countries]
N D Packing case [ARM450][STCL,SRS,SRSSC]
N D Packing case [ARM450][China]
N D Packing case [ARM450][other countries]
N D Packing case [AR350M][Japan]
N D Packing case [AR450M][Japan]
N D Key sheet [French]
N D Key sheet [Germany]
N D Key sheet [Spanish]
N D Key sheet [Italian]
N D Key sheet [Dutch]
N D Key sheet [Swedish]
N D Key sheet [Norwegian]
N D Key sheet [Finnsh]
N D Key sheet [Danish]
N D Key sheet [Hungarian]
N D Key sheet [Czechoslovakia]
N D Key sheet [Polish]
N D Operation manual [USA]
N D Operation manual COPY [Japan]
N D Operation manual COPY [USA]
N D Operation manual COPY [English]
N D Operation manual COPY [French]
N D Operation manual COPY [German]
N D Operation manual COPY [U Kingdom]
N D Operation manual COPY [Spanish]
N D Operation manual COPY [Italian]
N D Operation manual COPY [Dutch]
N D Operation manual COPY [Russian]
N D Operation manual COPY [Arabic]
N D Operation manual COPY [Hong Kong]
N D Operation manual COPY [Swedish]
N D Operation manual COPY [Norwegian]
N D Operation manual COPY [Finnsh]
N D Operation manual COPY [Danish]
N D Operation manual COPY [Hungarian]
N D Operation manual COPY [Czechoslovakia]
N D Operation manual COPY [Polish]
N D Operation manual SCANNER [Japan]
N D Operation manual SCANNER [USA]
N D Operation manual SCANNER [English]
N D Operation manual SCANNER [French]
N D Operation manual SCANNER [German]
N D Operation manual SCANNER [U Kingdom]
N D Operation manual SCANNER [Spanish]
N D Operation manual SCANNER [Italian]
N D Operation manual SCANNER [Dutch]
N D Operation manual SCANNER [Russian]
N D Operation manual SCANNER [Arabic]
N D Operation manual SCANNER [Hong Kong]
N D Operation manual SCANNER [Swedish]
N D Operation manual SCANNER [Norwegian]
N D Operation manual SCANNER [Finnsh]
N D Operation manual SCANNER [Danish]
N D Operation manual SCANNER [Hungarian]
N D Operation manual SCANNER [Czechoslovakia]
N D Operation manual SCANNER [Polish]
51
51
FCP05045
DESCRIPTION
– 2 –
26 MFP Control PWB (ARM350/M450/350M/450M/ARM11)
PRICE
NEW
NO. PARTS CODE
PCAPH0010GCZZ AD
1
PCOVP1468FCZZ AD
2
QCNCM0041QSZZ AP
3
QCNCM1146FCZZ AE
4
QCNCM1148FCZZ AP
5
QCNCW0946FCZZ AH
6
QCNCW1147FCZZ AL
7
QCNCW1149FCZZ AN
8
QFS-D132CQCZZ AG
9
QFSHB0028FCZZ AC
10
QPIN-0003GCZZ AC
11
QSOCZ0001QSZZ AL
12
QSOCZ0073FCZZ AL
13
QSOCZ0079FCZZ AN
14
QSOCZ6428ACZZ AE
15
RCRSP6676RCZZ AG
16
RCRUA0005FCZZ AP
17
RCRUA0007FCZZ AP
18
RCRUA0008FCZZ AP
19
RCRUA0009FCZZ AP
20
RCRUA0012FCZZ AP
21
RFILN0048FCZZ AC
22
RFILN0051FCZZ AC
23
RMPTR4100ACZZ AB
24
RMPTR4100ACZZ AB
RMPTR4103ACZZ AB
25
RMPTR4103ACZZ AB
RMPTR4330ACZZ AB
26
RMPTR4472ACZZ AB
27
UBATI0014FCZZ AN
28
VCCCCZ1HH101J AA
29
VCCCCZ1HH101J AA
VCCCCZ1HH220J AA
30
VCEAPH1HC105M AC
31
VCEAPS1AC227M AD
32
VCEAPS1CC106M AC
33
VCEAPS1CC106M AC
VCEAPS1CC226M AC
34
VCEAPS1CC476M AC
35
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
36
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1HB102K AA
37
VCKYCZ1HF103Z AA
38
VHDDAP202U/-1 AB
39
VHDRB451F//-1 AD
40
VHDRLS73///-1 AA
41
VHI65946P07-1 BA
42
VHI74LCX08MTC AE
43
VHI74LCX14MTC AE
44
VHI74LCX244MT AG
45
VHI74LCX32MTC AE
46
VHI74LVX16128 AP
47
VHI90LV17AW-1 AP
48
VHIDS14C238// AT
49
VHIEEP64-120P AW
50
VHIHG73C095-1 AY
51
VHIKS0U1347-1 BN
52
VHILCX157MT-1 AG
53
VHILCX16244-1 AM
54
VHILCX16245-1 AM
55
VHILCX16373-1 AM
56
VHILCX74MTC-1 AE
57
VHILM393D++-1 AE
58
VHILVT240MT-1 AL
59
VHIM87J4810-1 BK
60
VHIN2370R04-1 AF
61
VHIN2370R33-1 AF
62
RANK
PART
MARK
RANK
D Jumper (JM-2W-96) [JP2,3,4,5,6,7]
D FAX battery cover
C Connector (TX25-100P12) [CN2,9,12]
N C Connector (9A12-1034) [CN14]
N C Connector (TX25100P6ST) [CN16]
C Connector (36pin) [CN1]
N C Connector (TX2450RLTH1) [CN13]
N C Connector (8AL068S305C) [CN8]
A Fuse (1.25/250T) [F1]
C Fuse holder (TP00351-31) [F1]
C Pin (T3B-SQ) [JP2,3,4,5,6,7,]
C Socket (DMM168-FLAA2-3A133) [CN3]
C Connector (72pin) [CN4,5,6]
C Connector (100pin) [AR350M/450M][CN7]
C IC socket (28pin) [IC36]
B Crystal (32.768KHz) [X6]
B Crystal (14.745) [X7]
B Crystal (31.554) [X4]
B Crystal (40.57M) [X2]
B Crystal (66.666MHZ) [X3,5]
B Crystal (66M) [X1]
C Coil (BLM10B121SB) [L2,3]
N C Coil (MMZ1608D121B) [L25∼30,33,34]
B Block resistor (10Ω×4) [BR6∼13,15∼25,28,29]
B Block resistor (10Ω×4) [BR33∼44,46,48,53∼72]
B Block resistor (10KΩ×4) [BR1∼5,14,26,27,30,31,32]
B Block resistor (10KΩ×4) [BR74,76,78,80∼102]
B Block resistor (33Ω×4) [BR47,49,50,51,73,75,77,79]
B Block resistor (4.7KΩ×4) [BR52,45]
B Battery (CR2477-H01) [BT1]
C Capacitor (50WV 100pF) [C7,8,10,17,18,20,22,30,33]
C Capacitor (50WV 100pF) [C35,38,39,40,43,47,48,51]
C Capacitor (50WV 22pF) [C61]
C Capacitor (50WV 1µF) [C181,188,205,206]
C Capacitor (10WV 220µF) [C309,310]
C Capacitor (16WV 10µF) [C1,6,21,75,94,111,125,165]
C Capacitor (16WV 10µF) [C166,169,178,179,223,224]
C Capacitor (16WV 22µF) [C57,64,90,114,115,136,170,176]
C Capacitor (16WV 47µF) [C95,167,168,180]
C Capacitor (16WV 0.10µF) [C3,9,11,12,13,14,23∼29]
C Capacitor (16WV 0.10µF) [C31,32,34,36,37,41,42,44,45]
C Capacitor (16WV 0.10µF) [C46,49,50,52,53,54,55,56]
C Capacitor (16WV 0.10µF) [C58,59,60,62,63,65,66,67]
C Capacitor (16WV 0.10µF) [C68,70,71,72,73,74,76∼82]
C Capacitor (16WV 0.10µF) [C85,86,87,88,89,91,92,93]
C Capacitor (16WV 0.10µF) [C96,97,98,99,100,102∼108]
C Capacitor (16WV 0.10µF) [C110,112,113,116∼124,126]
C Capacitor (16WV 0.10µF) [C127,128,130,131,132,133]
C Capacitor (16WV 0.10µF) [C134,135,137,139,140∼145]
C Capacitor (16WV 0.10µF) [C149,151,153∼164,172,173]
C Capacitor (16WV 0.10µF) [C177,182,183,185,186,187]
C Capacitor (16WV 0.10µF) [C189∼199,201,202,204]
C Capacitor (16WV 0.10µF) [C208∼222,235∼262]
C Capacitor (16WV 0.10µF) [C264∼279,292∼303]
C Capacitor (50WV 1000pF) [C129]
C Capacitor (50WV 0.01µF) [C69,109]
B Diode (DAP202U) [D7,10]
B Diode (RB451F) [D12,14,20,21]
B Diode (RLS73) [D8,9]
B IC (65946P07) [IC32]
B IC (74LCX08MTC) [IC46,26]
B IC (74LCX14MTC) [IC43]
B IC (74LCX244MT) [IC12]
B IC (74LCX32MTC) [IC11]
B IC (74LVX16128) [IC15]
B IC (90LV17AW) [IC18]
B IC (DS14C238) [IC42]
B IC (EEP64-120P) [IC36]
B IC (HG73C095) [IC53]
B IC (KS0U1347) [IC19]
B IC (LCX157MT) [IC14]
B IC (LCX16244) [IC21,49,50]
B IC (LCX16245) [IC16,24,31,51,52]
B IC (LCX16373) [IC34]
B IC (LCX74MTC) [IC10]
B IC (LM393D) [IC39]
B IC (LVT240MT) [IC8]
B IC (M87J4810) [IC25]
B IC (N2370R04) [IC23]
B IC (N2370R33) [IC54]
DESCRIPTION
– 3 –
26 MFP Control PWB (ARM350/M450/350M/450M/ARM11)
PRICE
NEW
NO. PARTS CODE
VHIN2391D25-1 AG
63
VHINJM317DL-1 AK
64
VHINJU6356E-1 AK
65
VHIPI6C2309-1 AR
66
VHIPM2500++-1 BP
67
VHIPST598DN-1 AF
68
VHIPST598IN-1 AF
69
VHISD4M16L1-1 AZ
70
VHISD8M16L1-1 BB
71
VHISR1024-7LL AU
72
VHIT4955A20-1 BF
73
VHITD62503F-1 AF
74
VHP1LHEE-002A AC
75
VHV1608C080-1 AC
76
VHVICPS1.2/-1 AF
77
VRS-CZ1JD000J AA
VRS-CZ1JD000J AA
VRS-CZ1JD000J AA
78
VRS-CZ1JD000J AA
VRS-CZ1JD000J AA
VRS-CZ1JD100J AA
79
VRS-CZ1JD100J AA
VRS-CZ1JD101J AA
80
VRS-CZ1JD101J AA
VRS-CZ1JD102J AA
81
VRS-CZ1JD102J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
82
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
VRS-CZ1JD183J AA
83
VRS-CZ1JD220J AA
VRS-CZ1JD220J AA
84
VRS-CZ1JD220J AA
VRS-CZ1JD221J AA
85
VRS-CZ1JD222J AA
86
VRS-CZ1JD222J AA
VRS-CZ1JD330J AA
VRS-CZ1JD330J AA
VRS-CZ1JD330J AA
87
VRS-CZ1JD330J AA
VRS-CZ1JD330J AA
VRS-CZ1JD332J AA
88
VRS-CZ1JD333J AA
89
VRS-CZ1JD470J AA
90
VRS-CZ1JD472J AA
VRS-CZ1JD472J AA
91
VRS-CZ1JD472J AA
VRS-CZ1JD472J AA
VRS-CZ1JD511J AA
92
VRS-CZ1JD750J AA
93
VRS-CZ1JD823J AA
94
VSDTC114EK/-1 AB
95
VSDTC114YK/-1 AC
96
VSUPA502T//-1 AD
97
RANK
MARK
PART
RANK
B IC (N2391D25) [IC35,33]
B IC (NJM317DL) [IC2]
B IC (NJU6356E) [IC40]
B IC (PI6C2309) [IC9,29]
B IC (PM2500) [IC13]
B IC (PST598DN) [IC47]
B IC (PST598I) [IC48]
B IC (SD4M16L1) [IC22]
B IC (SD8M16L1) [IC4,5,6,7,27]
B IC (SR1024-7LL) [IC55,56]
B IC (T4955A20) [IC20]
B IC (TD62503F) [IC38,41,44,45]
B LED (Red) (1LHEE-002A) [D13]
B Varistor (1608C080) [RV1∼6]
B IC protecrot (ICPS1.2) [Q1]
C Resistor (1/16W 0Ω ±5%) [R1,3,32,33,49,77,94,97,106]
C Resistor (1/16W 0Ω ±5%) [R108,120,141,166,198,220,222]
C Resistor (1/16W 0Ω ±5%) [R225,229,232,233,290∼307]
C Resistor (1/16W 0Ω ±5%) [R310∼348,399,400,406]
C Resistor (1/16W 0Ω ±5%) [R407,409,410,413,414]
C Resistor (1/16W 10Ω ±5%) [R36,59,64,65,96,116,118,126]
C Resistor (1/16W 10Ω ±5%) [R127,136,137,149,161,170,177,185]
C Resistor (1/16W 100Ω ±5%) [R9,10,101,102,109,180]
C Resistor (1/16W 100Ω ±5%) [R181,183,235,236]
C Resistor (1/16W 1.0KΩ ±5%) [R11,129,130,134,151,204]
C Resistor (1/16W 1.0KΩ ±5%) [R205,243,244,253,268,279]
C Resistor (1/16W 10KΩ ±5%) [R12,13,15,16,18,20,44,45]
C Resistor (1/16W 10KΩ ±5%) [R60,61,62,70,72,73,86,91]
C Resistor (1/16W 10KΩ ±5%) [R93,112,115,123,131,139]
C Resistor (1/16W 10KΩ ±5%) [R144,154,158,159,160,163]
C Resistor (1/16W 10KΩ ±5%) [R165,167,168,203,207,208]
C Resistor (1/16W 10KΩ ±5%) [R213,216,217,230,237,238]
C Resistor (1/16W 10KΩ ±5%) [R239,240,241,242,245,246]
C Resistor (1/16W 10KΩ ±5%) [R249,254,259,260,261,263]
C Resistor (1/16W 10KΩ ±5%) [R264,267,269,271,272,273]
C Resistor (1/16W 10KΩ ±5%) [R274,282,283,284,285]
C Resistor (1/16W 18KΩ ±5%) [R275,280]
C Resistor (1/16W 22Ω ±5%) [R14,17,19,24,27,30,31,34]
C Resistor (1/16W 22Ω ±5%) [R35,37,39,40,43,46,51,54]
C Resistor (1/16W 22Ω ±5%) [R57,247,252]
C Resistor (1/16W 220Ω ±5%) [R403,404]
C Resistor (1/16W 2.2KΩ ±5%) [R199,200,209,210,211,212]
C Resistor (1/16W 2.2KΩ ±5%) [R218,223,248,265,266,276]
C Resistor (1/16W 33Ω ±5%) [R25,38,41,47,48,52,56,58,66]
C Resistor (1/16W 33Ω ±5%) [R67,68,69,92,117,138,142]
C Resistor (1/16W 33Ω ±5%) [R143,147,148,152,153,173]
C Resistor (1/16W 33Ω ±5%) [R174,175,176,187,188,]
C Resistor (1/16W 33Ω ±5%) [R214,288,289]
C Resistor (1/16W 3.3KΩ ±5%) [R215,119]
C Resistor (1/16W 33KΩ ±5%) [R179,107]
C Resistor (1/16W 47Ω ±5%) [R53,55,308,309]
C Resistor (1/16W 4.7KΩ ±5%) [R63,71,74,76,87,100,111,121]
C Resistor (1/16W 4.7KΩ ±5%) [R122,124,128,133,146,162,164]
C Resistor (1/16W 4.7KΩ ±5%) [R184,206,221,224,226,227,228]
C Resistor (1/16W 4.7KΩ ±5%) [R231,250,251,262,270,277]
C Resistor (1/16W 510Ω ±5%) [R278]
C Resistor (1/16W 75Ω ±5%) [R114,145]
C Resistor (1/16W 82KΩ ±5%) [R202]
B Transistor (DTC114EK) [Q3]
B Transistor (DTC114YK) [Q4]
B Transistor (UPA502T) [Q5,6,7]
DESCRIPTION
– 4 –
27 Exteriers[AR-EF1]
NO. PARTS CODE
GCAB-0943FCZZ AK
1
XHBSE40P08000 AA
2
PCOVP1566FCZZ AS
3
LX-BZ0842FCZZ AG
4
GCAB-0942FCZZ AP
5
LX-BZ0776FCZZ AG
6
GCAB-0945FCZZ AR
7
DUNT-7133DSZZ CZ
8
DUNT-7132DSZZ CY
LFIX-0544FCZZ AG
9
CGLSP0003RS51 BC
10
CGLSP0003RS52 BF
XBTSC50P16000 AA
11
LFIX-0543FCZZ AG
12
CGLSP0102DS51 BF
13
XHBSD30P06000 AA
14
XBTSE40P06000 AA
15
PGIDM1900FCZZ AR
16
PGIDM1901FCZZ AQ
17
NROLP0011QSZZ AD
18
PSPO-0001QSZZ AB
19
NSFTZ2601FCZZ AH
20
MSPRC2865FCZ1 AB
21
XEBSE30P08000 AA
22
PCOVP1624FCZZ AC
23
LX-BZ0465FCZZ AA
24
XHBSD30P08000 AA
25
CPNLC0244DS51 CV
26
CPNLC0244DS52 CT
LDAIU0627FCZZ AZ
27
XEBSE40P08000 AA
28
PMLT-1256FCZZ AC
29
PMLT-1257FCZZ AB
30
RCORF0041FCZZ AH
31
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
N D Rear lower cabinet
CScrew (4×8)
N D Upper cabinet rear cover
C SPF screw
N D Upper cabinet rear
C Screw R
N D Upper cabinet right
N E DSPF unit
N E SPF unit
N D Glass fixing right
N B Table glass (Japan)
N B Table glass EX (Except Japan)
CScrew (5×16)
N D Glass fixing left
N B White datum glass unit
CScrew (3×6)
CScrew (4×6)
N C Delivery upper PG SPF
N C Delivery lower PG
C Delivery support roller
C Sponge
N C Delivery support roller shaft 1
N C Delivery support spring
CScrew (3×8)
N D Stanp cover
CScrew (4×6)
CScrew (3×8)
N D MFP operation panel (Japan)
N D MFP operation panel (Except Japan)
N D Operation base
CScrew (4×8)
N C Dustproof cushion 1
N C Dustproof cushion 2
N C Core (UFR25-12-15)
27 Exteriers[AR-EF1]
8
11
29
2
2
16
1
2
2
4
30
15
12
13
23
14
31
3
6
2
15
11
7
5
9
10
15
26
2
24
18
19
20
17
2
18
21
19
22
18
21
22
2
2
25
20
19
18
27
28
FCP05046
– 5 –
28 Original detect unit[AR-EF1]
PRICE
NO. PARTS CODE
MARMP0148FCZ2 AK
1
XBPSD30P06KS0 AA
2
LBSHZ1102CCZZ AC
3
PSLDH0178FCZZ AD
4
NSFTZ1805FCZZ AE
5
XRESP30-06000 AA
6
MSPRT1563FCZZ AC
7
LHLDZ1085FCZ2 AD
8
CPWBF1453FCE1 BN
9
MARMP0147FCZ2 AK
10
XEPSD30P05000 AA
11
GCAB-0942FCZZ AP
12
CARMP0147DS51 BA
501
RANK
NEW
MARK
28 Original detect unit[AR-EF1]
501
PART
RANK
N C Original detect arm lower
CScrew (3×6KS)
C Rubber roller bushing 1
C Original detect shield plate
C Original detect fulcrum shaft
C E type ring
C Original detect spring
N C Original detect fulcrum TIG
N E ORS emission PWB
N C Original detect arm upper
CScrew (3×5)
N D Upper cabinet rear
N E ORS emission unit
2
1
DESCRIPTION
3
4
9
5
7
10
8
6
12
11
11
11
FCP05047
– 6 –
29 Operation panel unit[AR-EF1]
PRICE
NO. PARTS CODE
CPWBN1471FCE1 BF
1
MSPRP3009FCZZ AD
2
XEPSD30P08000 AA
3
CPWBF1470DS51 BN
4
DHAI-3192FCZZ AD
5
DHAI-3191FCZZ AF
6
LHLDZ1459FCZZ AE
7
VVLLM065HB1-1 CB
8
LHLDZ1458FCZZ AF
9
HPNLH0246FCZZ BF
10
CPWBF1469FCE1 BN
11
CBTN-0253FC01 AN
12
CBTN-0252FC01 AP
13
CFILW0284FC01 AF
14
CBTN-0251FC01 AF
15
CFILW0282FC01 AF
16
CFILW0283FC01 AF
17
CBTN-0250FC01 AH
18
HPNLC0244FCZZ AZ
19
CPNLC0245FC01 AY
20
CPNLC0245FC02 AY
LPINS0014QSGZ AC
21
DHAI-3193FCZZ AC
22
PSHEZ4906FCZZ AC
24
QCNW-0166FCZZ AE
25
RANK
NEW
MARK
N E LVDS PWB
N C LCD earth plate spring
N E Inverter PWB
N C INV interface harness
N C ORS PD harness
N C LCD holder B
N B LCD mojule
N C LCD holder A
N D Touch panel
N E MFP OPE PWB
N E Change key Assy
N E Ten key Assy
N D C key smoke Assy
N E C key Assy
N D Copy key smoke Assy
N D CA key smoke Assy
N E Copy key Assy
N D Operation panel A
N D Operation panel B (Japan)
N D Operation panel B EX-E (Except Japan)
N C Fixing pin C
N C Panel earth harness
N C Touch panel sheet
N C LCD interface FFC
29 Operation panel unit[AR-EF1]
22
PART
RANK
CScrew (3×8)
3
A
2
DESCRIPTION
3
2
18
17
11
16
3
5
1
8
4
3
7
25
3
9
6
3
22
3
12
3
3
24
24
10
A
13
15
19
14
21
21
– 7 –
20
21
FCP05048
30 Optical unit 1[AR-EF1]
NO. PARTS CODE
PCOVP1599FCZZ AG
1
XHBSD30P04000 AA
2
LHLDW1115FCZZ AD
3
QCNW-0168FCZZ AE
4
QCNW-0167FCZZ AM
5
PCOVP1600FCZZ AF
6
PSHEP4932FCZZ AD
7
XBBSE30P06000 AA
9
LPLTM5723FCZZ AG
10
XHBSE40P08000 AA
11
VHI28F081L02C BB
12
CPWBN1450FCE1 BF
13
LHLDW1115FCZZ AD
14
QCNW-0165FCZZ AH
15
QCNW-0181FCZZ AH
16
XBBSD40P06000 AA
17
CPWBN1451DS51 BF
18
DHAI-3152FCZZ AF
19
LPLTM5720FCZZ AK
20
LPLTM5927FCZZ AF
22
LPLTM5877FCZZ AE
24
XHBSD30P06000 AA
25
PCOVP1598FCZZ AL
26
PSHEZ4842FCZZ AD
27
DHAI-3303FCZZ BC
28
PGUMS0283FCZ1 AA
29
LDAIU0610FCZZ AE
30
LRALM0183FCZZ AG
31
PSHEZ4843FCZZ AC
32
LHLDW1007LCZZ AD
34
LHLDW0595FCZZ AC
35
LHLDW1264FCZZ AD
36
LBNDJ0043FCZZ AA
37
DHAI-3153FCZZ AC
38
LFIX-0537FCZZ AD
39
PSHEZ4841FCZ1 AD
40
LRALM0184FCZZ AG
41
LX-BZ0004QSZZ AB
42
PSHEZ4836FCZZ AB
43
LPLTP5960FCZZ AE
44
LHLDW1201CCZZ AA
45
LFIX-0569FCZZ AD
46
PMLT-1282FCZZ AE
47
PRICE
RANK
NEW
PART
MARK
RANK
N D Harness cover B
CScrew (3×4)
C Edge bushing
N C CL interface FFC
N C CCD interface FFC
N D Harness cover C
N C Harness fixing sheet 4
CScrew (3×6)
N C SCN PWB fixing plate
CScrew (4×8)
N B Scanner flash unit
N E Scanner control PWB
C Edge bushing
N C MFPOP interface FFC
N C LVDS interface FFC
CScrew (4×6)
N E Scanner interface PWB
N C Stanp interface harness
N C OC fixing plate
N C Dry heater fixing plate
N C Base rainforce plate
CScrew (3×6)
N D Harness cover A
N C Harness fixing sheet 2
N C MFP interface cable
N C Table glass cushion
D Harness fixing base
N C MB-B rail F
N C Harness fixing sheet 3
C Mini clamp (MN-1)
C Edge holder (EDS2)
C Wire holder (LWS-8S-2.5W)
C Snap band (SG-130)
N C PNC harness
C Harness fixing plate
N C Harness fixing sheet 1
N C MB-B rail R
CScrew
N C Screw protect sheet
N C SCN cable fixing plate
C SK holder
N C SCN fixing cable
N C FFC fixing cushion
DESCRIPTION
30 Optical unit 1[AR-EF1]
36
2
1
2
45
17
9
44
46
11
25
35
25
17
10
20
25
25
35
24
40
3
17
11
14
28
13
25
22
20
35
25
38
12
17
37
19
17
37
18
35
26
37
25
29
29
41
43
29
34
43
43
3
5
4
6
2
2
15
17
29
27
29
43
25
43
2
7
47
16
39
17
30
42
31
43
29
43
32
FCP05049
– 8 –
31 Optical unit 2[AR-EF1]
NO. PARTS CODE
! CDAIU0619DS51 BF
1
LHLDZ1505FCZZ AC
2
XBBSD40P06000 AA
3
LBSHC0161FCZZ AB
4
CCOVP1541FC02 AT
5
XHBSD30P04000 AA
6
PCUSU0203FCZZ AE
7
PGIDM1890FCZZ AC
8
NPLYZ0399FCZZ AG
9
XBPSD40P06KS0 AA
10
LFIX-0284FCZZ AC
12
PMIR-0165FCZZ AP
13
MSLI-0138FCZZ AC
15
PWIR-0192FCZZ AQ
16
PWIR-0191FCZZ AQ
17
NBLTH0329FCZZ AG
18
LX-BZ0049FCZZ AB
19
NPLYZ0338FCZZ AN
20
XRESP70-08000 AA
21
LX-BZ0324FCZZ AA
22
NPLYZ0013QSZZ AL
23
NPLYZ0005QSZZ AG
24
NSFTZ2586FCZZ AS
25
NPLYZ0006QSZZ AD
26
RMOTS0857FCZZ AZ
27
XBPSD30P05K00 AA
28
XBPSD40P16KS0 AA
29
MSPRT2846FCZZ AC
30
CPLTM5719FC01 AG
31
PGUMS0002QSZZ AL
32
NGERH0027QSZZ AH
33
XRESP70-08000 AA
34
LX-WZ0119FCZZ AA
35
VHPGP3A38//-1 AH
36
XBBSD40P14000 AA
37
VHPGP1A22LC-1 AK
38
XBBSD40P10000 AA
39
DHAI-3150FCZZ AD
40
CPLTM0031RS51 BS
41
NBRGC0133FCZ1 AC
42
XRESP40-05000 AA
43
LHLDZ1381FCZZ AL
44
CPWBF1454FCE1 BN
45
XHBSD40P06000 AA
46
XEPSD40P06000 AA
47
XHBSD30P06000 AA
48
MSPRD3020FCZ1 AG
49
PGIDM1964FCZZ AC
50
CHLDZ1446FC31 BC
501
CSFTZ2586FC31 AZ
502
PRICE
RANK
NEW
PART
MARK
RANK
N E Lamp unit
N C Wire holder
CScrew (4×6)
C Bushing
N D Dark box Assy
CScrew (3×4)
C Protection cushion
N C CL guide
N C W pulley T
CScrew (4×6KS)
C 2nd,3rd mirror fixing plate F
N B 2nd,3rd mirror
C Slider
N B MB wire F
N B MB wire R
N B Winding drive belt
CScrew
C Pulley (36T)
C E type ring
CScrew
C Winding pully PAN
C Pulley
N C Winding drive shaft
C L pulley
N B Scanner motor
CScrew (3×5K)
CScrew (4×16KS)
N C Belt tenshion spring
N C Mirror motor fixing plate
C Protection rubber
C Mirror motor idle gear
C E type ring
C Washer
B Photo transistor (GP3A38)
CScrew (4×14)
B Photo interupter (GP1A22LC)
CScrew (4×10)
N C MHPS interface harness
N E CCD unit
C PF bearing (M8)
C E type ring
C ORS PWB holder
N E ORS PD PWB
CScrew (4×6)
CScrew (4×6)
CScrew (3×6)
N C Wire stopper spring
N C Rack adjusting guide
N E 2,3 Mirror unit
N E Winder drive shaft unit
DESCRIPTION
– 9 –
31 Optical unit 2[AR-EF1]
3
501
12
2
1
3
5
6
2
16
6
25
21
19
502
22
23
19
4
19
19
17
18
20
21
22
23
19
19
21
9
13
10
7
15
8
11
10
9
12
7
15
29
30
28
36
40
37
31
49
27
24
32
29
26
48
33
32
35
43
34
26
24
39
48
38
21
42
50
49
44
46
45
47
41
42
21
46
FCP05050
– 10 –
32 Lamp unit[AR-EF1]
NO. PARTS CODE
! RLMPD0658FCZZ BA
1
XEBSD30P08000 AA
2
PREFL0172FCZZ AK
3
XBBSD30P12000 AA
4
LDAIU0619FCZZ AT
5
PCUSU0203FCZZ AE
6
QCNW-0168FCZZ AE
7
MSLI-0138FCZZ AC
8
CPWBF1449FC31 BH
9
PCUSF0334FCZZ AP
10
LSTYM0261FCZZ AB
11
LFIX-0545FCZZ AC
12
PMIR-0164FCZZ AP
13
MSPRP2825FCZZ AC
14
TLABZ4335FCZZ AB
15
! CDAIU0619DS51 BF
(Unit)
901
PRICE
RANK
NEW
PART
MARK
RANK
N B Lamp
CScrew (3×8)
B Reflector
CScrew (3×12)
N C Lamp base
C Protection cushion
N C CL interface FFC
C Slider
N E Inverter PWB
C Mirror cushion
N C Wire support plate
N C CL read harness fixing
N B 1st mirror
N C Mirror spring
D HV caution label
N E Lamp unit
DESCRIPTION
32 Lamp unit[AR-EF1]
15
6
8
11
14
2
33 DSPF Assembly section[AR-EF1]
PRICE
NEW
NO. PARTS CODE
PSHEZ4845FCZZ AV
1
PMLT-1286FCZZ AD
2
PCOVP1595FCZZ AG
3
XHBSE30P06000 AA
4
PCOVP1615FCZZ AE
5
XEBSE40P10000 AA
6
MHNG-0208FCZZ BA
7
PCOVP1518FCZZ AE
9
LPLTM5887FCZZ AL
10
XHBSE40P08000 AA
11
LFIX-0568FCZZ AC
12
PTPE-0265FCZZ AC
13
PCOVP1644FCZZ AD
14
PGUMS0298FCZZ AC
15
CPWBF1501DS51 BN
16
LPLTP5743FCZZ AF
17
XEBSD30P08000 AA
18
MSPRP2830FCZZ AA
19
PGUMS0296FCZZ AD
20
NGERR1386FCZZ AE
21
NGERP1385FCZZ AF
22
XEPSD30P06X00 AA
23
PCOVP1645FCZZ AH
24
PGUMS0299FCZZ AH
25
CPWBF1459DS51 BN
26
RANK
PART
MARK
RANK
N C OC mat
N C OC cushion
N D Rack cover
CScrew (3×6)
N D Length detect cover N
CScrew (4×10)
N C SPF hinge R
D ICU ROM cover
N C Hinge joint plate
CScrew (4×8)
N C Original detect fixing
N C Cover tape
N C F cover L
N C Cover rubber L
N E SPF VR PWB
C Width detect fixing plate
CScrew (3×8)
C Width detect spring
N C Cushion
C Width detect rack
C Width detect pinion
CScrew (3×6X)
N C F cover R
N C Cover rubber R
N E SPF PWB
2
1
2
3
2
4
10
7
9
13
12
14
2
5
8
6
8
11
FCP05051
DESCRIPTION
– 11 –
33 DSPF Assembly section[AR-EF1]
PRICE
NEW
NO. PARTS CODE
DHAI-3166FCZZ AY
27
XESSE30P08000 AA
28
DHAI-3161FCZZ AK
29
XEBSE30P10000 AA
30
VHPGP1A73A+-1 AG
33
MLEVP0794FCZZ AC
34
XEBSD40P16000 AA
35
LPLTP5778FCZZ AG
37
LPLTP5777FCZZ AG
38
PCOVP1549FCZZ AU
39
XEBSE30P08000 AA
40
MARMP0243FCZZ AD
41
PRNGP0090FCZZ AA
42
LPLTM2573FCZ1 AD
43
LPLTP5938FCZZ AC
44
TLABH4440FCZZ AF
45
RANK
PART
MARK
RANK
N C DSPF body interface harness
CScrew (3×8)
N C SPF size detect harness
CScrew (3×10)
B Photo sensor (GP1A73A)
N C Length detect actuator
CScrew (4×16)
N D Adjust plate R
N D Adjust plate F
N D Upper cover
CScrew (3×8)
C Manual feeding tray arm
C Ring (E5)
C ADF MG plate
N C Shading plate N
D Original read label (Japan)
33 DSPF Assembly section[AR-EF1]
2
DESCRIPTION
1
6
4
3
11
11
5
11
9
7
6
12
11
6
6
6
6
6
6
18
16
18
12
33
33
34
18
30
20
29
30
30
11
44
40
11
28
43
23
21
21
17
19
18
22
23
15
4
14
13
25
10
27
18
29
30
26
35
4
41
18
38
37
42
24
– 12 –
40
39
45
FCP05052
34 DSPF Paper feed unit[AR-EF1]
PRICE
NO. PARTS CODE
PCOVP1594FCZZ AG
1
XHBSE30P06000 AA
2
PMLT-1272FCZZ AB
3
PGIDM1953FCZZ AS
4
PSHEP4915FCZZ AE
5
PCLR-0471FCZZ AG
6
NSFTZ2600FCZZ AM
7
MSPRP2878FCZZ AC
8
XEBSD30P08000 AA
9
NSFTZ2599FCZ1 AW
10
XRESP40-06000 AA
11
NBRGC0136FCZZ AC
12
LHLDZ1483FCZZ AF
13
PCLC-0303FCZZ AT
14
NSFTZ2678FCZZ AL
15
NPLYZ0398FCZZ AC
16
NBRGM0096FCZ1 AB
17
NBLTH0363FCZZ AG
18
NROLR1312FCZZ AN
19
NPLYZ0397FCZZ AK
20
NROLR1317FCZZ AP
21
PCLC-0302FCZZ AT
22
LPLTM5928FCZZ AG
23
XBBSD30P06000 AA
24
RPLU-0336FCZZ AS
25
MARMP0284FCZZ AC
26
XRESP50-06000 AA
27
NROLP1364FCZZ AC
28
XRESP70-08000 AA
29
NROLR1318FCZZ AR
30
LSTYM0288FCZZ AK
31
LHLDZ1485FCZZ AC
32
MSPRD3002FCZZ AC
33
MHNG-0209FCZZ BC
34
RMOTS0876FCZZ BD
35
LFRM-1022FCZZ AK
36
NGERH1477FCZZ AC
37
PSHEZ4949FCZZ AE
38
MSPRP3011FCZZ AC
39
LHLDW1009ACZZ AA
40
XHBSE40P08000 AA
41
NGERH1476FCZZ AD
42
NGERH1478FCZZ AE
43
NBLTH0364FCZZ AG
44
LHLDZ1486FCZZ AC
45
NPLYZ0375FCZZ AC
46
CPLTM5882FC02 AN
47
LPINS1031HCZZ AA
48
PCLR-0426FCZZ AD
49
NROLR1320FCZZ AQ
50
LPLTM5884FCZZ AW
51
LHLDW0429FCZZ AB
52
LPLTM5785FCZZ AC
53
XRESP20-04000 AA
54
PMLT-1270FCZZ AB
55
JKNBZ0141FCZZ AH
56
LPLTM5889FCZZ AC
57
PSHEP4846FCZZ AD
58
LHLDW2101SCZZ AB
59
LHLDW1009ACZZ AA
60
LPLTM5929FCZZ AR
61
DHAI-3281FCZZ AH
62
QSW-Z0531FCZZ AL
63
PCUSS0372FCZZ AD
64
LSTPP0359FCZZ AE
65
XHBSD30P14000 AA
66
LHLDZ1484FCZZ AC
67
VHPGP1A73A+-1 AG
68
MSPRC3001FCZZ AB
69
MLEVP0837FCZZ AC
70
XHBSE30P10000 AA
71
PCUSS0373FCZZ AB
72
PSHEP4916FCZ1 AF
73
PGIDH1897FCZZ AT
74
PGLSP0103FCZZ AV
75
LX-BZ0931FCZZ AC
76
PBRSS0209FCZZ AG
77
PSHEZ4957FCZZ AC
78
DHAI-3336FCZZ AB
79
RANK
NEW
MARK
N D Roller cover
N C Damper cushion 3
N C Paper feed PG SPF
N C PS rear mylar
N C PS support roller
N C PS support shaft
N C PS support plate spring
N C Separate roller shaft SPF
N B Separate clutch
N C Pick up shaft
N B Belt (S2M120)
N B PS clutch SPF
N C Paper feed base plate SPF
N B Pick up solenoid
N C Pick up joint arm N
N C PS roller SPF
N C CIS stay
N C SP holder F
N C Spring N
N C DSPF hinge L
N B SPF motor N
N D Drive frame
N C Gear (24T)
N C Motor sheet
N C Earth plate spring
N C Gear (35T/18T)
N C Gear (55T/28T/18P)
N B Belt (S2M130)
N C SP holder R
N C Drive plate
N C Delivery roller SPF
N C Base tray reinforce plate N
N C MG plate
N C Damper cushion 1
N C Jam release knob
N C Datum plate
N C OC mat mylar R
N C Delivery roller fixing plate
N C SPF delivery sensor harness
N C CIS cushion 1
N C PS fornt stopper
N C Open/close holder
N C Open/close detect spring N
N C Open/close actuator N
N C CIS cushion 2
N C White mylar
N C CIS paper guide
N C CIS glass
N C Screw (M3)
N B Discharger blass SPF
N C Delivery sheet
N C ESD harness DSPF
PART
RANK
CScrew (3×6)
CScrew (3×8)
C E type ring
C Bearing (M6)
C Paper feed rotation plate
C Pick up roller pulley (22P)
C Bearing
C Pick up roller
C Paper feed roller pulley (28P)
C Separate roller
CScrew (3×6)
C E type ring
C Delivery roller M
C E type ring
CClamp
CScrew (4×8)
C Pulley (22T)
C Spring pin
C Slide roller
C Wire holder (WS-2NS)
C E type ring
C Cable clamp
CClamp
B Delivery jam sensor
CScrew (3×14)
B Photo sensor (GP1A73A)
CScrew (3×10)
DESCRIPTION
– 13 –
34 DSPF Paper feed unit[AR-EF1]
35
46
38
24
27
49
48
24
54
17
43
44
24
36
1
2
5
3
2
2
4
6
8
9
7
65
32
9
24
30
8
12
11
26
13
17
15
16
18
19
27
20
21
28
29
10
A
34
B
11
11
14
27
17
22
29
28
A
24
42
27
37
2
B
40
31
45
27
17
66
33
23
27
12
C
25
2
37
50
47
52
59
41
51
33
2
C
55
41
62
77
41
68
71
61
69
67
70
62
60
79
2
78
41
41
2
63
39
57
17
27
77
– 14 –
58
2
76
72
75
2
58
53
56
27
39
2
17
2
57
2
64
72
73
74
76
FCP05053
35 DSPF Upper transfer unit[AR-EF1]
PRICE
NEW
NO. PARTS CODE
LPLTM5891FCZZ AE
1
PMLT-1272FCZZ AB
2
LSTPP0353FCZZ AE
3
LPLTM5930FCZZ AD
5
XEBSD30P08000 AA
6
CPLTM5746FC01 AE
7
LPLTP5747FCZZ AC
8
MSPRT2864FCZZ AC
9
VHPGP1A73A+-1 AG
10
PMAGT0072FCZZ AF
11
RPLU-0347FCZZ AQ
12
DHAI-3162FCZZ AK
13
MLEVP0796FCZZ AC
14
MARMP0248FCZZ AE
15
MLEVP0804FCZZ AC
16
MSPRP2832FCZZ AC
17
PSHEZ4878FCZZ AC
18
PSHEZ4847FCZZ AL
19
PSHEP4848FCZZ AB
20
LSTPP0314FCZZ AA
21
MSPRD2870FCZ1 AC
22
NSFTZ2659FCZZ AR
23
LPLTM5932FCZZ AC
24
XEBSE40P10000 AA
25
MLEVP0797FCZZ AC
26
MSPRD2879FCZZ AB
27
PMLT-1271FCZZ AB
28
PSHEP4937FCZZ AB
29
PGIDM1899FCZZ AY
30
MSPRT2863FCZZ AB
31
LPLTP5748FCZZ AD
32
XHBSE30P06000 AA
34
XBBS230P10000 AA
35
RANK
PART
MARK
RANK
N C Upper delivery rainforce plate
N C Damper cushion 3
N C Original stopper
N C Separate pad rainforce plate
CScrew (3×8)
N C Separate pad fixing plate AS
N C Separate plate
N C Pressure spring
B Photo sensor (GP1A73A)
C Magnet catch
N B Gate solenoid
N C SPF paper feed harness
N C Set detect actuator
C MF gate joint arm
N C Stopper lever
N C Separate assistance plate spring
N C Separate mylar upper
N C Separate sheet
N C Separate mylar lower
C E3 stopper
N C Stopper spring
N C Fulcrum shaft
C Tray 2 sensor fixing plate
CScrew (4×10)
N C PS front actuator
N C PS front actuator spring
N C Damper cushion 2
N C Fixing mylar
N C Upper delivery PG
N C Paper feed plate spring
N C Paper feed plate
CScrew (3×6)
CScrew (3×10)
DESCRIPTION
35 DSPF Upper transfor unit[AR-EF1]
6
11
13
25
24
A
12
26
10
6
10
1
10
15
27
14
16
28
6
34
17
21
28
A
6
9
8
18
19
20
22
23
34
3
6
2
6
5
7
35
6
11
– 15 –
30
31
29
32
FCP05054
36 DSPF CIS unit[AR-EF1]
NO. PARTS CODE
CPWBN1458FCE1 BF
1
XBBSD30P06000 AA
2
PCOVP1593FCZZ AF
3
DUNT-7079FCZZ CC
4
LX-BZ0680FCZZ AB
5
QCNW-0170FCZZ AH
6
XBBSD40P08000 AA
7
PMLT-1284FCZZ AE
8
PRICE
RANK
36 DSPF CIS unit[AR-EF1]
NEW
PART
MARK
RANK
N E CIS control PWB
CScrew (3×6)
N D CIS PWB cover N
N E CIS unit
CScrew
N C CIS interface FFC
CScrew (4×8)
N C Interface FFC fixing cushion
DESCRIPTION
2
2
3
2
1
7
8
2
6
5
2
7
4
5
– 16 –
FCP05055
37 Packing Material & Accessories[AR-EF1]
PRICE
NEW
NO. PARTS CODE
SPAKA6075DSZZ AA
1
LSOU-0177FCGZ AP
2
LSOU-0179FCZZ AR
SPAKA0307QSZZ AD
3
TCADZ1178FCZZ AB
4
LX-BZ0787FCZZ AH
5
SPAKA6132FCZZ AT
6
SSAKZ0003QSZZ AF
7
SPAKA6133FCZZ AU
8
SPAKC6131DSZZ AF
9
SPAKC6131DS11 AF
SPAKA6265FCZZ AC
10
RANK
PART
MARK
RANK
N D RSPF protect sheet 1
D Delivery tray T
D Delivery tray 1
D Protect sheet FN5
D Screw caution card
C Screw for 2/3 mirror lock
N D Packing add upper EF1
D Body vinyl bag
N D Packing add botom EF1
N D Packing case (Japan)
N D Packing case (Except Japan)
N D Fusing protect add
37 Packing Material & Accessories[AR-EF1]
DESCRIPTION
6
10
1
7
8
2
3
5
4
9
FCP05056
– 17 –
38 MFP OPE PWB[AR-EF1]
NO. PARTS CODE
QCNCM1171FCZZ AE
1
QCNCW1134FCZZ AH
2
QSW-P0005QSZZ AC
QSW-P0005QSZZ AC
3
QSW-P0005QSZZ AC
RALMB1002LCZZ AE
4
RC-KZ0008QCZZ AB
5
RCRS-0007FCZZ AD
6
RH-DZ0016FCZZ AB
7
VCEAJU1CW476M AB
8
VCKYPU1EB223Z AB
9
VCKYPU1HB101K AA
10
VHD1SS133//-1 AA
11
VHIS1340AF+-1 AH
12
VHP1LHLE-002A AC
13
VHP1LHLE-002A AC
VHPLT9400E/-1 AK
14
VRD-HT2EY101J AA
15
VRD-HT2EY102J AA
16
VRD-HT2EY302J AA
17
VRD-HT2EY331J AA
18
VRD-HT2EY471J AA
19
VS2SC1740SR-1 AB
20
VSDTC114YS/-1 AB
21
(Unit)
CPWBF1469FCE1 BN
901
PRICE
RANK
NEW
PART
MARK
RANK
N C Connector (6pin) [CN2]
C Connector (24pin) [CN1]
B Tact switch (B3F-6102) [PRK,FAK,COK,JOK,CUK,1K,2K]
B Tact switch (B3F-6102) [3K,4K,5K,6K,7K,8K,9K]
B Tact switch (B3F-6102) [*K,K,#K,CLK,CAK,PSW]
B Alarm (PKM13EPY-4000-TF01) [BZ1]
N C Capacitor (UP050F ZABZ) [C6]
B Crystal (CSB480EB) [X1]
B Diode (MA700) [D1]
C Capacitor (16WV 47µF) [C1]
C Capacitor (25WV 0.022µF) [C2,3]
C Capacitor (50WV 100PF) [C4,5]
B Diode (1SS133) [D2,3]
B IC (S1340AF) [IC1]
B LED(Green) (LTL-1LHLE-002A) [PRT,FAX,COPY,JOB,PONL]
B LED(Green) (LTL-1LHLE-002A) [PDATA,FCM,FDATA]
B LED (LT9400E) [RPL]
C Resistor (1/4W 100Ω ±5%) [R1]
C Resistor (1/4W 1.0KΩ ±5%) [R8]
C Resistor (1/4W 3.0KΩ ±5%) [R2]
C Resistor (1/4W 330Ω ±5%) [R3]
C Resistor (1/4W 470Ω ±5%) [R4,5,6,7]
B Transistor (2SC1740SR) [Q2]
B Transistor (DTC114YS) [Q1]
N E MFP OPE PWB
DESCRIPTION
39 Scanner control PWB[AR-EF1]
PRICE
NO. PARTS CODE
QCNCM0828FCZZ AE
1
QCNCM0829FCZZ AG
2
QCNCM1166FCZZ AK
3
QCNCM1167FCZZ AP
4
QCNCM7014SC1C AC
5
QCNCM7022SC0C AB
6
QCNCM7022SC0E AB
7
QCNCM7022SC0F AB
8
QCNCW0885FCZZ AG
9
QCNCW7040XC8J AP
10
QSOCZ0002QSZZ AD
11
QSOCZ0071FCZZ AP
12
QSOCZ6428ACZZ AE
13
RCRMZ6007RCZZ AD
14
RCRSZ0001QSZZ AG
15
RFILN0049FCZZ AE
16
RFILN6012RCZZ AB
17
RFILZ1005LCZZ AB
18
RH-IX2196SCZZ AG
19
RMPTR4103ACZZ AB
RMPTR4103ACZZ AB
RMPTR4103ACZZ AB
20
RMPTR4103ACZZ AB
RMPTR4103ACZZ AB
VCCCCZ1HH220J AA
21
VCEAGA1AW476M AA
22
VCEAGA1AW477M AB
23
VCEAGA1CW477M AB
24
VCEAGA1HW224M AA
25
VCEAGA1VW476M AB
26
VCEAZU1VW477M AD
27
VCKYCZ1CB103K AA
28
VCKYCZ1EF223Z AA
VCKYCZ1EF223Z AA
VCKYCZ1EF223Z AA
29
VCKYCZ1EF223Z AA
VCKYCZ1EF223Z AA
VCKYCZ1HB102K AA
VCKYCZ1HB102K AA
30
VCKYCZ1HB102K AA
VCKYCZ1HB102K AA
VCKYCZ1HB222K AA
31
VCKYCZ1HF103Z AA
32
VCQYNA1HM103K AA
33
VHDDAN202K/-1 AB
34
VHDDAN202K/-1 AB
RANK
NEW
MARK
N C Connector (20pin) [CN18]
N C Connector (50pin) [CN19]
N C Filter [NF5,NF6,NF7,NF8,NF9,NF10]
PART
RANK
C Connector (26pin) [CN13]
C Connector (28pin) [CN12]
C Connector (13pin) [CN5]
C Connector (3pin) [CN10]
C Connector (5pin) [CN6]
C Connector (6pin) [CN7]
C Connector (12pin) [CN14]
C Connector (80pin) [CN16]
C IC socket (8pin) [IC13]
C Socket (72pin) [SOCKET1]
C IC socket (28pin) [IC14]
B Resonator (4.19MHz) [X1]
B Crystal (19.6608MHz) [X2]
C EMI filter [NF1,NF4]
C EMI filter [NF3]
B Regulator [IC5]
B Block resistor (10KΩ×4) [BR9,BR3,BR4,BR7,BR8,BR10]
B Block resistor (10KΩ×4) [BR12,BR11,BR6,BR13,BR14,BR15]
B Block resistor (10KΩ×4) [BR16,BR17,BR18,BR20,BR21,BR22]
B Block resistor (10KΩ×4) [BR23,BR24,BR25,BR26,BR27,BR28]
B Block resistor (10KΩ×4) [BR29,BR30,BR5,BR19,BR1]
C Capacitor (50WV 22pF) [C58,C60]
C Capacitor (10WV 47µF) [C46,C36]
C Capacitor (10WV 470µF) [C20,C24]
C Capacitor (16WV 470µF) [C10]
C Capacitor (50WV 0.22µF) [C73,C74]
C Capacitor (35WV 47uF) [C63]
C Capacitor (35WV 470µF) [C16]
C Capacitor (16WV 0.010µF) [C76,C77,C78,C80]
C Capacitor (25WV 0.022µF) [C1,C11,C13,C14,C22,C23]
C Capacitor (25WV 0.022µF) [C26,C19,C12,C37,C40,C41]
C Capacitor (25WV 0.022µF) [C42,C47,C48,C49,C51,C57]
C Capacitor (25WV 0.022µF) [C59,C61,C65,C66,C67,C68]
C Capacitor (25WV 0.022µF) [C69,C71,C72,C21,C35,C50,C82]
C Capacitor (50WV 1000pF) [C2,C3,C4,C5,C6,C7]
C Capacitor (50WV 1000pF) [C8,C9,C25,C27,C28,C29]
C Capacitor (50WV 1000pF) [C30,C31,C32,C33,C34,C39]
C Capacitor (50WV 1000pF) [C43,C44,C53,C64,C75,C79,C84]
C Capacitor (50WV 2200pF) [C45,C54,C55,C62]
C Capacitor (50WV 0.01µF) [C15,C18,C70,C81,C83]
C Capacitor (50WV 0.01µF) [C56]
B Diode (DAN202K) [D1,D3,D4,D18,D19,D20]
B Diode (DAN202K) [D22,D23,D15,D14]
DESCRIPTION
– 18 –
39 Scanner control PWB[AR-EF1]
PRICE
NO. PARTS CODE
VHDDAP202K/-1 AB
35
VHDDAP202K/-1 AB
VHDDSM1D1//-1 AB
36
VHDM1FL20U+-1 AC
37
VHDMA704A//-1 AC
38
VHEHZS3B3//-1 AB
39
VHI74VHC04M-1 AE
40
VHI74VHC32M-1 AD
41
VHI90LV17AW-1 AP
42
VHID65943GJ-1 AY
43
VHIEES04L400P AG
44
VHIH8S2322R-1 AZ
45
VHIHN58V65A-1 AW
46
VHILM324D++-1 AE
47
VHILM339D++-1 AE
48
VHILV25612J-1 AQ
49
VHIMTD1361F-1 AR
50
VHITD62003AP1 AG
51
VHITD62503F/- AG
52
VHIVHC244SJ-1 AG
53
VRD-HT2EY163J AA
54
VRD-HT2EY911J AA
55
VRS-CZ1JD000J AA
56
VRS-CZ1JD101J AA
57
VRS-CZ1JD102J AA
58
VRS-CZ1JD103F AA
59
VRS-CZ1JD103J AA
VRS-CZ1JD103J AA
60
VRS-CZ1JD103J AA
VRS-CZ1JD122J AA
61
VRS-CZ1JD151J AA
62
VRS-CZ1JD203J AA
63
VRS-CZ1JD222J AA
64
VRS-CZ1JD222J AA
VRS-CZ1JD303F AA
65
VRS-CZ1JD303J AA
66
VRS-CZ1JD561J AA
67
VRS-CZ1JD562J AA
68
VRS-CZ1JD621J AA
69
VRS-CZ1JD624J AA
70
VRS-CZ1JD681J AA
71
VRS-CZ1JD752J AA
72
VRS-CZ1JD911J AA
73
VRS-RE3DA1R0J AB
74
VS2SB1197//-1 AC
75
VS2SK3065++-1 AG
76
VSDTA114YK/-1 AC
77
VSDTC114YK/-1 AC
78
VSUPA502T//-1 AD
79
(Unit)
CPWBN1450FCE1 BF
901
RANK
NEW
MARK
N B Diode (M1FL20U) [D8,D9,D10,D11]
N B IC (74VHC04M) [IC8,IC18]
N B IC (74VHC32M) [IC6]
N B IC (D65943GJ) [IC7]
N B IC (VHC244SJ) [IC2,IC3]
N C Resistor (1/16W 30KΩ ±5%) [R51]
N C Resistor (1/16W 620KΩ ±5%) [R23]
N C Resistor (1/16W 910Ω ±5%) [R38,R36]
N B Transistor (2SK3065) [Q11]
N E Scanner control PWB
PART
RANK
B Diode (DAP202K) [D5,D16,D17,D24,D25,D26]
B Diode (DAP202K) [D13,D12]
B Diode (DSM1D1) [D21,D6]
B Diode (MA704A) [D2]
B Zener diode (HZS3B3) [D7]
B IC (90LV17AW) [IC21]
B IC (EES04L400P) [IC13]
B IC (H8S2322R) [IC11]
B IC (HN58V65A) [IC14]
B IC (LM324D) [IC1]
B IC (LM339D) [IC10]
B IC (LV25612J) [IC19]
B IC (MTD1361F) [IC9]
B IC (TD62003AP1) [IC4,IC15,IC20]
B IC (TD62503F) [IC12,IC17]
C Resistor (1/4W 16KΩ ±5%) [R8,R9]
C Resistor (1/4W 910Ω ±5%) [R10]
C Resistor (1/16W 0Ω ±5%) [R37]
C Resistor (1/16W 100Ω ±5%) [R39]
C Resistor (1/16W 1.0KΩ ±5%) [R7,R21,R47,R56]
C Resistor (1/16W 10KΩ ±1%) [R46,R1]
C Resistor (1/16W 10KΩ ±5%) [R5,R31,R29,R3,R6,R22]
C Resistor (1/16W 10KΩ ±5%) [R24,R25,R30,R41,R4,R55]
C Resistor (1/16W 10KΩ ±5%) [R28,R69]
C Resistor (1/16W 1.2KΩ ±5%) [R16,R13,R19,R33,R52,R53]
C Resistor (1/16W 150Ω ±5%) [R27]
C Resistor (1/16W 20KΩ ±5%) [R48,R59,R62,R65]
C Resistor (1/16W 2.2KΩ ±5%) [R12,R14,R15,R17,R18,R32]
C Resistor (1/16W 2.2KΩ ±5%) [R54,R11]
C Resistor (1/16W 30KΩ ±1%) [R2]
C Resistor (1/16W 560Ω ±5%) [R35]
C Resistor (1/16W 5.6KΩ ±5%) [R57,R58,R60,R61,R63,R64]
C Resistor (1/16W 620Ω ±5%) [R34]
C Resistor (1/16W 680Ω ±5%) [R68]
C Resistor (1/16W 7.5KΩ ±5%) [R26,R43,R44]
C Resistor (2W 1.0Ω ±5%) [R20,R42]
B Transistor (2SB1197) [Q8,Q9,Q10]
B Transistor (DTA114YK) [Q2,Q3,Q6]
B Transistor (DTC114YK) [Q4,Q5,Q7]
B Transistor (UPA502T) [Q1]
DESCRIPTION
40 CIS Control PWB[AR-EF1]
NO. PARTS CODE
QCNCM0880FCZZ AF
1
QCNCM0923FC12 AE
2
QCNCW1160FCZZ AD
3
RFILN6012RCZZ AB
4
RFILZ1005LCZZ AB
5
VCCCCZ1HH101J AA
VCCCCZ1HH101J AA
6
VCCCCZ1HH101J AA
VCEAYU1EC476M AC
7
VCEAYU1VC476M AC
8
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
9
VCKYCZ1CF104Z AB
VCKYCZ1CF104Z AB
VCKYCZ1HB102K AA
10
VCKYCZ1HF103Z AA
11
VHI74VHC04M-1 AE
12
VHI74VHCT240X AF
13
VHI7SZ125M5-1 AE
14
VHI90LV27AW-1 AQ
15
VHID82825GM-1 BK
16
PRICE
RANK
NEW
PART
MARK
RANK
C Connector (26pin) [CN100]
C Connector (12pin) [CN1]
N C Connector (FFC9604S35F) [CN2]
C EMI filter (E103) [NF2,11]
C EMI filter (EXC-EMT103DT) [NF100,4,10,12,13]
C Capacitor (50WV 100pF) [C4,5,8,9,10,11,22]
C Capacitor (50WV 100pF) [C23,24,25,31,32,33,34]
C Capacitor (50WV 100pF) [C40,48,49,51,52,53,60,61,62]
N C Capacitor (25WV 47µF) [C3,15,26,28,41,54]
N C Capacitor (25WV 47µF) [C18]
C Capacitor (35WV 0.10µF) [C100,1,2,7,12,13,17,27]
C Capacitor (35WV 0.10µF) [C29,30,35,36,37,42,43]
C Capacitor (35WV 0.10µF) [C45,46,50,55,58,63,64]
C Capacitor (35WV 0.10µF) [C65,66]
C Capacitor (50WV 1000pF) [C16,20,21,57,59]
C Capacitor (0.01µF/50V) [C6,14,19,38,39,44,56]
N B IC (74VHC04M) [IC4]
B IC (74VHCT240X) [IC100]
N B IC (7SZ125M5) [IC2]
N B IC (90LV27AW) [IC5]
N B IC (D82825GM) [IC1]
DESCRIPTION
– 19 –
40 CIS Control PWB[AR-EF1]
PRICE
NO. PARTS CODE
VHIFS781BZB-1 AP
17
VHIM3064ATC-1 AX
18
VHIVHC244SJ-1 AG
19
VRS-CZ1JD000J AA
VRS-CZ1JD000J AA
20
VRS-CZ1JD000J AA
VRS-CZ1JD101J AA
VRS-CZ1JD101J AA
21
VRS-CZ1JD101J AA
VRS-CZ1JD102J AA
22
VRS-CZ1JD102J AA
VRS-CZ1JD222J AA
23
VRS-CZ1JD332F AA
24
(Unit)
CPWBN1458FCE1 BF
901
RANK
NEW
MARK
N B IC (M3064ATC) [IC7]
N B IC (VHC244SJ) [IC3]
N E CIS control PWB
41 MFP Controler PWB[AR-M11]
PRICE
NO. PARTS CODE
VHI28F322L01F BE
1
VHI28F322L03F BF
VHI28F322L02F BF
2
VHI28F322L04F BL
LX-BZ0828FCZZ AD
3
LX-BZ0921FCZ1 AE
4
PCOVP1557FCZZ AC
5
PCOVP1560FCZZ AC
6
XBBSD30P06000 AA
7
XBPSD26P06000 AA
8
XBPSD30P06000 AA
9
XHBSE30P06000 AA
11
LPLTM5765FCZ1 AH
12
RANK
NEW
MARK
N B MFP flash ROM A J (28F322L01F) [Japan]
N B MFP flash ROM A EX (28F322L03F) [except Japan]
N B MFP flash ROM B J (28F322L02F) [Japan]
N B MFP flash ROM B EX (28F322L04F) [except Japan]
N C Scanner Screw
N C FAX I/F cover
N C Control joint plate
PART
RANK
B IC (FS781BZB) [IC6]
C Resistor (1/16W 0Ω ±5%) [R5,15,18,19,20,21,34]
C Resistor (1/16W 0Ω ±5%) [R35,43,44,45,46,48,49]
C Resistor (1/16W 0Ω ±5%) [R50,51,52,53,54,55,59]
C Resistor (1/16W 100Ω ±5%) [R1,2,3,4,9,10,14,22]
C Resistor (1/16W 100Ω ±5%) [R23,24,25,37,38,39,40]
C Resistor (1/16W 100Ω ±5%) [R41,47,56,57]
C Resistor (1/16W 1.0KΩ ±5%) [R100,17,26,27,28,29,30]
C Resistor (1/16W 1.0KΩ ±5%) [R31,32,33,36,42]
C Resistor (1/16W 2.2KΩ ±5%) [R6,7,8,11,12,13]
C Resistor (1/16W 3.3KΩ ±1%) [R58]
PART
RANK
C Handle fixing screw
C LAN/option cover
CScrew (3×6)
C Screw (2.6×6)
CScrew (3×6)
CScrew (3×6)
DESCRIPTION
DESCRIPTION
41 MFP Controler PWB[AR-M11]
7
9
11
8
4
8
3
12
5
6
7
9
7
11
9
5
3
2
7
1
7
7
7
7
7
7
7
FCP05057
– 20 –
42 Packing material & Accessories[ARM11]
PRICE
NEW
NO. PARTS CODE
SPAKP2792RCZZ AE
2
SPAKA6144FCZZ AH
4
SPAKA6143FCZZ AN
5
SPAKC6142FCZZ AP
SPAKC6142FC11 AP
6
SPAKC6142FC12 AP
SPAKC6142FC13 AP
RANK
PART
MARK
RANK
D Vinyl bag (460×500mm)
N D Packing add B
N D Packing add A
N D Packing case [Japan]
N D Packing case [USA]
N D Packing case [Europe]
N D Packing case [Other countries]
42 Packing material & Accessories[ARM11]
DESCRIPTION
2
4
5
6
– 21 –
FCP05058
43 Packing Material & Accessories[AR-RK1]
PRICE
NEW
NO. PARTS CODE
SPAKA6136FCZZ AE
1
SPAKC6134DSZZ AT
SPAKC6134DS11 AT
2
SPAKC6134DS12 AT
SPAKC6134DS13 AT
SPAKA6135FCZZ AK
7
SPAKA6137FCZZ AK
8
RANK
PART
MARK
RANK
N D Protect add
N D Packing case (Japan)
N D Packing case (U.S.A Other countries)
N D Packing case (Europe,U.Kngdom,Australia,New Zealand)
N D Packing case (China)
N D Sleeve
N D Spacer
43 Packing Material & Accessories[AR-RK1]
DESCRIPTION
1
8
2
7
1
FCP05059
– 22 –
■ Index
PARTS CODE NO.
[C]
CARMP0147DS51
CBTN-0250FC01
CBTN-0251FC01
CBTN-0252FC01
CBTN-0253FC01
CCOVP1541FC02
CDAIU0619DS51
"
CFILW0282FC01
CFILW0283FC01
CFILW0284FC01
CGLSP0003RS51
CGLSP0003RS52
CGLSP0102DS51
CHLDZ1446FC31
CINSR2085FC51
CINSR2127FC51
CINSZ2086FC51
CINSZ2128FC51
CPLTM0031RS51
CPLTM5719FC01
CPLTM5746FC01
CPLTM5882FC02
CPNLC0244DS51
CPNLC0244DS52
CPNLC0245FC01
CPNLC0245FC02
CPNLH0020QS12
CPNLH0020QS13
CPNLH0020QS22
CPNLH0020QS23
CPWBF1449FC31
CPWBF1453FCE1
CPWBF1454FCE1
CPWBF1459DS51
CPWBF1469FCE1
"
CPWBF1470DS51
CPWBF1501DS51
CPWBN1450FCE1
"
CPWBN1451DS51
CPWBN1458FCE1
"
CPWBN1471FCE1
CSFTZ2586FC31
[D]
DHAI-3150FCZZ
DHAI-3152FCZZ
DHAI-3153FCZZ
DHAI-3161FCZZ
DHAI-3162FCZZ
DHAI-3166FCZZ
DHAI-3191FCZZ
DHAI-3192FCZZ
DHAI-3193FCZZ
DHAI-3281FCZZ
DHAI-3303FCZZ
DHAI-3336FCZZ
DUNT-7079FCZZ
DUNT-7132DSZZ
DUNT-7133DSZZ
[G]
GCAB-0940FCZ2
GCAB-0942FCZZ
"
GCAB-0943FCZZ
GCAB-0945FCZZ
[H]
HPNLC0243FCZ1
HPNLC0244FCZZ
HPNLH0246FCZZ
[J]
JKNBZ0141FCZZ
[L]
LBNDJ0043FCZZ
LBSHC0161FCZZ
LBSHZ1102CCZZ
28-501
29- 18
29- 15
29- 13
29- 12
31- 5
31- 1
32-901
29- 16
29- 17
29- 14
27- 10
27- 10
27- 13
31-501
17- 20
17- 20
17- 20
17- 20
31- 41
31- 31
35- 7
34- 47
27- 26
27- 26
29- 20
29- 20
1- 26
1- 26
1- 26
1- 26
32- 9
28- 9
31- 45
33- 26
29- 11
38-901
29- 4
33- 16
30- 13
39-901
30- 18
36- 1
40-901
29- 1
31-502
31- 40
30- 19
30- 38
33- 29
35- 13
33- 27
29- 6
29- 5
29- 22
34- 62
30- 28
34- 79
36- 4
27- 8
27- 8
1- 5
27- 5
28- 12
27- 1
27- 7
1- 11
29- 19
29- 10
34- 56
30- 37
31- 4
28- 3
PRICE
RANK
BA
AH
AF
AP
AN
AT
BF
BF
AF
AF
AF
BC
BF
BF
BC
AS
AR
AS
AR
BS
AG
AE
AN
CV
CT
AY
AY
AK
AK
AK
AK
BH
BN
BN
BN
BN
BN
BN
BN
BF
BF
BF
BF
BF
BF
AZ
AD
AF
AC
AK
AK
AY
AF
AD
AC
AH
BC
AB
CC
CY
CZ
BA
AP
AP
AK
AR
AP
AZ
BF
AH
AA
AB
AC
NEW
PART
MARK
RANK
NE
NE
NE
NE
NE
ND
NE
NE
ND
ND
ND
NB
NB
NB
NE
ND
ND
ND
ND
NE
NC
NC
NC
ND
ND
ND
ND
ND
ND
ND
ND
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NE
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NE
NE
NE
ND
ND
ND
ND
ND
ND
ND
ND
NC
C
C
C
PARTS CODE NO.
LDAIU0610FCZZ
LDAIU0619FCZZ
LDAIU0627FCZZ
LFIX-0284FCZZ
LFIX-0537FCZZ
LFIX-0543FCZZ
LFIX-0544FCZZ
LFIX-0545FCZZ
LFIX-0568FCZZ
LFIX-0569FCZZ
LFRM-1022FCZZ
LHLDW0429FCZZ
LHLDW0595FCZZ
LHLDW1007LCZZ
LHLDW1009ACZZ
"
LHLDW1115FCZZ
"
LHLDW1201CCZZ
LHLDW1264FCZZ
LHLDW2101SCZZ
LHLDZ1085FCZ2
LHLDZ1381FCZZ
LHLDZ1458FCZZ
LHLDZ1459FCZZ
LHLDZ1483FCZZ
LHLDZ1484FCZZ
LHLDZ1485FCZZ
LHLDZ1486FCZZ
LHLDZ1505FCZZ
LPINS0014QSGZ
LPINS1031HCZZ
LPLTM2573FCZ1
LPLTM5720FCZZ
LPLTM5723FCZZ
LPLTM5765FCZ1
"
LPLTM5785FCZZ
LPLTM5877FCZZ
LPLTM5884FCZZ
LPLTM5887FCZZ
LPLTM5889FCZZ
LPLTM5891FCZZ
LPLTM5927FCZZ
LPLTM5928FCZZ
LPLTM5929FCZZ
LPLTM5930FCZZ
LPLTM5932FCZZ
LPLTP5743FCZZ
LPLTP5747FCZZ
LPLTP5748FCZZ
LPLTP5777FCZZ
LPLTP5778FCZZ
LPLTP5938FCZZ
LPLTP5960FCZZ
LRALM0183FCZZ
LRALM0184FCZZ
LSOU-0177FCGZ
LSOU-0179FCZZ
LSTPP0314FCZZ
LSTPP0353FCZZ
LSTPP0359FCZZ
LSTYM0261FCZZ
LSTYM0288FCZZ
LX-BZ0004QSZZ
LX-BZ0049FCZZ
LX-BZ0324FCZZ
LX-BZ0465FCZZ
LX-BZ0680FCZZ
LX-BZ0776FCZZ
LX-BZ0787FCZZ
LX-BZ0828FCZZ
"
LX-BZ0842FCZZ
LX-BZ0921FCZ1
"
LX-BZ0931FCZZ
LX-WZ0119FCZZ
[M]
MARMP0147FCZ2
MARMP0148FCZ2
30- 30
32- 5
27- 27
31- 12
30- 39
27- 12
27- 9
32- 12
33- 12
30- 46
34- 36
34- 52
30- 35
30- 34
34- 40
34- 60
30- 3
30- 14
30- 45
30- 36
34- 59
28- 8
31- 44
29- 9
29- 7
34- 13
34- 67
34- 32
34- 45
31- 2
29- 21
34- 48
33- 43
30- 20
30- 10
12- 35
41- 12
34- 53
30- 24
34- 51
33- 10
34- 57
35- 1
30- 22
34- 23
34- 61
35- 5
35- 24
33- 17
35- 8
35- 32
33- 38
33- 37
33- 44
30- 44
30- 31
30- 41
37- 2
37- 2
35- 21
35- 3
34- 65
32- 11
34- 31
30- 42
31- 19
31- 22
27- 24
36- 5
27- 6
37- 5
12- 56
41- 3
27- 4
12- 25
41- 4
34- 76
31- 35
28- 10
28- 1
PRICE
RANK
AE
AT
AZ
AC
AD
AG
AG
AC
AC
AD
AK
AB
AC
AD
AA
AA
AD
AD
AA
AD
AB
AD
AL
AF
AE
AF
AC
AC
AC
AC
AC
AA
AD
AK
AG
AH
AH
AC
AE
AW
AL
AC
AE
AF
AG
AR
AD
AC
AF
AC
AD
AG
AG
AC
AE
AG
AG
AP
AR
AA
AE
AE
AB
AK
AB
AB
AA
AA
AB
AG
AH
AD
AD
AG
AE
AE
AC
AA
AK
AK
NEW
PART
MARK
RANK
D
NC
ND
C
C
ND
ND
NC
NC
NC
ND
C
C
C
C
C
C
C
C
C
C
NC
C
NC
NC
C
NC
NC
NC
NC
NC
C
C
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
C
C
NC
NC
ND
ND
NC
NC
NC
NC
D
D
C
NC
NC
NC
NC
C
C
C
C
C
C
C
C
C
C
NC
NC
NC
C
NC
NC
– 23 –
PARTS CODE NO.
MARMP0243FCZZ
MARMP0248FCZZ
MARMP0284FCZZ
MHNG-0208FCZZ
MHNG-0209FCZZ
MLEVP0794FCZZ
MLEVP0796FCZZ
MLEVP0797FCZZ
MLEVP0804FCZZ
MLEVP0837FCZZ
MSLI-0138FCZZ
"
MSPRC2865FCZ1
MSPRC3001FCZZ
MSPRD2870FCZ1
MSPRD2879FCZZ
MSPRD3002FCZZ
MSPRD3020FCZ1
MSPRP2825FCZZ
MSPRP2830FCZZ
MSPRP2832FCZZ
MSPRP2878FCZZ
MSPRP3009FCZZ
MSPRP3011FCZZ
MSPRT1563FCZZ
MSPRT2846FCZZ
MSPRT2863FCZZ
MSPRT2864FCZZ
[N]
NBLTH0329FCZZ
NBLTH0363FCZZ
NBLTH0364FCZZ
NBRGC0133FCZ1
NBRGC0136FCZZ
NBRGM0096FCZ1
NGERH0027QSZZ
NGERH1476FCZZ
NGERH1477FCZZ
NGERH1478FCZZ
NGERP1385FCZZ
NGERR1386FCZZ
NPLYZ0005QSZZ
NPLYZ0006QSZZ
NPLYZ0013QSZZ
NPLYZ0338FCZZ
NPLYZ0375FCZZ
NPLYZ0397FCZZ
NPLYZ0398FCZZ
NPLYZ0399FCZZ
NROLP0011QSZZ
NROLP1364FCZZ
NROLR1312FCZZ
NROLR1317FCZZ
NROLR1318FCZZ
NROLR1320FCZZ
NSFTZ1805FCZZ
NSFTZ2586FCZZ
NSFTZ2599FCZ1
NSFTZ2600FCZZ
NSFTZ2601FCZZ
NSFTZ2659FCZZ
NSFTZ2678FCZZ
[P]
PBRSS0209FCZZ
PCAPH0010GCZZ
PCLC-0302FCZZ
PCLC-0303FCZZ
PCLR-0426FCZZ
PCLR-0471FCZZ
PCOVP1468FCZZ
PCOVP1518FCZZ
PCOVP1549FCZZ
PCOVP1557FCZZ
"
PCOVP1560FCZZ
"
PCOVP1566FCZZ
PCOVP1593FCZZ
PCOVP1594FCZZ
PCOVP1595FCZZ
PCOVP1598FCZZ
33- 41
35- 15
34- 26
33- 7
34- 34
33- 34
35- 14
35- 26
35- 16
34- 70
31- 15
32- 8
27- 21
34- 69
35- 22
35- 27
34- 33
31- 49
32- 14
33- 19
35- 17
34- 8
29- 2
34- 39
28- 7
31- 30
35- 31
35- 9
31- 18
34- 18
34- 44
31- 42
34- 12
34- 17
31- 33
34- 42
34- 37
34- 43
33- 22
33- 21
31- 24
31- 26
31- 23
31- 20
34- 46
34- 20
34- 16
31- 9
27- 18
34- 28
34- 19
34- 21
34- 30
34- 50
28- 5
31- 25
34- 10
34- 7
27- 20
35- 23
34- 15
34- 77
26- 1
34- 22
34- 14
34- 49
34- 6
26- 2
33- 9
33- 39
12- 38
41- 5
12- 37
41- 6
27- 3
36- 3
34- 1
33- 3
30- 26
PRICE
RANK
AD
AE
AC
BA
BC
AC
AC
AC
AC
AC
AC
AC
AB
AB
AC
AB
AC
AG
AC
AA
AC
AC
AD
AC
AC
AC
AB
AC
AG
AG
AG
AC
AC
AB
AH
AD
AC
AE
AF
AE
AG
AD
AL
AN
AC
AK
AC
AG
AD
AC
AN
AP
AR
AQ
AE
AS
AW
AM
AH
AR
AL
AG
AD
AT
AT
AD
AG
AD
AE
AU
AC
AC
AC
AC
AS
AF
AG
AG
AL
NEW
PART
MARK
RANK
C
C
NC
NC
NC
NC
NC
NC
NC
NC
C
C
NC
NC
NC
NC
NC
NC
NC
C
NC
NC
NC
NC
C
NC
NC
NC
NB
NB
NB
C
C
C
C
NC
NC
NC
C
C
C
C
C
C
C
C
C
NC
C
C
C
C
NC
NC
C
NC
NC
NC
NC
NC
NC
NB
D
NB
NB
C
NC
D
D
ND
C
C
NC
NC
ND
ND
ND
ND
ND
PARTS CODE NO.
PCOVP1599FCZZ
PCOVP1600FCZZ
PCOVP1615FCZZ
PCOVP1624FCZZ
PCOVP1644FCZZ
PCOVP1645FCZZ
PCUSF0334FCZZ
PCUSS0372FCZZ
PCUSS0373FCZZ
PCUSU0203FCZZ
"
PGIDH1897FCZZ
PGIDM1890FCZZ
PGIDM1899FCZZ
PGIDM1900FCZZ
PGIDM1901FCZZ
PGIDM1953FCZZ
PGIDM1964FCZZ
PGLSP0103FCZZ
PGUMS0002QSZZ
PGUMS0283FCZ1
PGUMS0296FCZZ
PGUMS0298FCZZ
PGUMS0299FCZZ
PMAGT0072FCZZ
PMIR-0164FCZZ
PMIR-0165FCZZ
PMLT-1256FCZZ
PMLT-1257FCZZ
PMLT-1270FCZZ
PMLT-1271FCZZ
PMLT-1272FCZZ
"
PMLT-1282FCZZ
PMLT-1284FCZZ
PMLT-1286FCZZ
PREFL0172FCZZ
PRNGP0090FCZZ
PSHEP4846FCZZ
PSHEP4848FCZZ
PSHEP4915FCZZ
PSHEP4916FCZ1
PSHEP4927FC10
PSHEP4927FC11
PSHEP4927FCZ1
PSHEP4927FCZ2
PSHEP4927FCZ3
PSHEP4927FCZ4
PSHEP4927FCZ5
PSHEP4927FCZ6
PSHEP4927FCZ7
PSHEP4927FCZ8
PSHEP4927FCZ9
PSHEP4927FCZZ
PSHEP4932FCZZ
PSHEP4937FCZZ
PSHEZ4836FCZZ
PSHEZ4841FCZ1
PSHEZ4842FCZZ
PSHEZ4843FCZZ
PSHEZ4845FCZZ
PSHEZ4847FCZZ
PSHEZ4878FCZZ
PSHEZ4906FCZZ
PSHEZ4949FCZZ
PSHEZ4957FCZZ
PSLDH0178FCZZ
PSPO-0001QSZZ
PTPE-0265FCZZ
PWIR-0191FCZZ
PWIR-0192FCZZ
[Q]
QCNCM0041QSZZ
QCNCM0828FCZZ
QCNCM0829FCZZ
QCNCM0880FCZZ
QCNCM0923FC12
QCNCM1146FCZZ
QCNCM1148FCZZ
QCNCM1166FCZZ
QCNCM1167FCZZ
30- 1
30- 6
33- 5
27- 23
33- 14
33- 24
32- 10
34- 64
34- 72
31- 7
32- 6
34- 74
31- 8
35- 30
27- 16
27- 17
34- 4
31- 50
34- 75
31- 32
30- 29
33- 20
33- 15
33- 25
35- 11
32- 13
31- 13
27- 29
27- 30
34- 55
35- 28
34- 3
35- 2
30- 47
36- 8
33- 2
32- 3
33- 42
34- 58
35- 20
34- 5
34- 73
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
17- 13
30- 7
35- 29
30- 43
30- 40
30- 27
30- 32
33- 1
35- 19
35- 18
29- 24
34- 38
34- 78
28- 4
27- 19
33- 13
31- 17
31- 16
26- 3
39- 1
39- 2
40- 1
40- 2
26- 4
26- 5
39- 3
39- 4
PRICE
RANK
AG
AF
AE
AC
AD
AH
AP
AD
AB
AE
AE
AT
AC
AY
AR
AQ
AS
AC
AV
AL
AA
AD
AC
AH
AF
AP
AP
AC
AB
AB
AB
AB
AB
AE
AE
AD
AK
AA
AD
AB
AE
AF
AR
AR
AR
AM
AR
AR
AR
AR
AR
AR
AR
AM
AD
AB
AB
AD
AD
AC
AV
AL
AC
AC
AE
AC
AD
AB
AC
AQ
AQ
AP
AE
AG
AF
AE
AE
AP
AK
AP
NEW
PART
MARK
RANK
ND
ND
ND
ND
NC
NC
C
NC
NC
C
C
NC
NC
NC
NC
NC
NC
NC
NC
C
NC
NC
NC
NC
C
NB
NB
NC
NC
NC
NC
NC
NC
NC
NC
NC
B
C
NC
NC
NC
NC
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
C
C
NC
NB
NB
C
C
C
C
C
NC
NC
NC
NC
– 24 –
PARTS CODE NO.
QCNCM1171FCZZ
QCNCM7014SC1C
QCNCM7022SC0C
QCNCM7022SC0E
QCNCM7022SC0F
QCNCW0885FCZZ
QCNCW0946FCZZ
QCNCW1134FCZZ
QCNCW1147FCZZ
QCNCW1149FCZZ
QCNCW1160FCZZ
QCNCW7040XC8J
QCNW-0165FCZZ
QCNW-0166FCZZ
QCNW-0167FCZZ
QCNW-0168FCZZ
"
QCNW-0170FCZZ
QCNW-0181FCZZ
QFS-D132CQCZZ
QFSHB0028FCZZ
QPIN-0003GCZZ
QSOCZ0001QSZZ
QSOCZ0002QSZZ
QSOCZ0071FCZZ
QSOCZ0073FCZZ
QSOCZ0079FCZZ
QSOCZ6428ACZZ
"
QSW-P0005QSZZ
QSW-Z0531FCZZ
[R]
RALMB1002LCZZ
RC-KZ0008QCZZ
RCORF0041FCZZ
RCRMZ6007RCZZ
RCRS-0007FCZZ
RCRSP6676RCZZ
RCRSZ0001QSZZ
RCRUA0005FCZZ
RCRUA0007FCZZ
RCRUA0008FCZZ
RCRUA0009FCZZ
RCRUA0012FCZZ
RFILN0048FCZZ
RFILN0049FCZZ
RFILN0051FCZZ
RFILN6012RCZZ
"
RFILZ1005LCZZ
"
RH-DZ0016FCZZ
RH-IX2196SCZZ
RLMPD0658FCZZ
RMOTS0857FCZZ
RMOTS0876FCZZ
RMPTR4100ACZZ
RMPTR4103ACZZ
"
RMPTR4330ACZZ
RMPTR4472ACZZ
RPLU-0336FCZZ
RPLU-0347FCZZ
[S]
SPAKA0307QSZZ
SPAKA6075DSZZ
SPAKA6132FCZZ
SPAKA6133FCZZ
SPAKA6135FCZZ
SPAKA6136FCZZ
SPAKA6137FCZZ
SPAKA6143FCZZ
SPAKA6144FCZZ
SPAKA6265FCZZ
SPAKC6118DS12
SPAKC6118DS13
SPAKC6122DS17
SPAKC6122DS18
SPAKC6122DS19
SPAKC6122DS20
SPAKC6122DS21
38- 1
39- 5
39- 6
39- 7
39- 8
39- 9
26- 6
38- 2
26- 7
26- 8
40- 3
39- 10
30- 15
29- 25
30- 5
30- 4
32- 7
36- 6
30- 16
26- 9
26- 10
26- 11
26- 12
39- 11
39- 12
26- 13
26- 14
26- 15
39- 13
38- 3
34- 63
38- 4
38- 5
27- 31
39- 14
38- 6
26- 16
39- 15
26- 17
26- 18
26- 19
26- 20
26- 21
26- 22
39- 16
26- 23
39- 17
40- 4
39- 18
40- 5
38- 7
39- 19
32- 1
31- 27
34- 35
26- 24
26- 25
39- 20
26- 26
26- 27
34- 25
35- 12
37- 3
37- 1
37- 6
37- 8
43- 7
43- 1
43- 8
42- 5
42- 4
37- 10
17- 5
17- 5
17- 5
17- 5
17- 5
17- 5
17- 5
PRICE
RANK
AE
AC
AB
AB
AB
AG
AH
AH
AL
AN
AD
AP
AH
AE
AM
AE
AE
AH
AH
AG
AC
AC
AL
AD
AP
AL
AN
AE
AE
AC
AL
AE
AB
AH
AD
AD
AG
AG
AP
AP
AP
AP
AP
AC
AE
AC
AB
AB
AB
AB
AB
AG
BA
AZ
BD
AB
AB
AB
AB
AB
AS
AQ
AD
AA
AT
AU
AK
AE
AK
AN
AH
AC
AU
AU
AU
AU
AU
AU
AU
NEW
PART
MARK
RANK
NC
C
C
C
C
C
C
C
NC
NC
NC
C
NC
NC
NC
NC
NC
NC
NC
A
C
C
C
C
C
C
C
C
C
B
B
B
NC
NC
B
B
B
B
B
B
B
B
B
C
NC
NC
C
C
C
C
B
B
NB
NB
NB
B
B
B
B
B
NB
NB
D
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
PARTS CODE NO.
SPAKC6122DS22
SPAKC6131DS11
SPAKC6131DSZZ
SPAKC6134DS11
SPAKC6134DS12
SPAKC6134DS13
SPAKC6134DSZZ
SPAKC6142FC11
SPAKC6142FC12
SPAKC6142FC13
SPAKC6142FCZZ
SPAKP2792RCZZ
SSAKZ0003QSZZ
[T]
TCADZ1178FCZZ
TINSD2092GHZZ
TINSD2134GHZZ
TINSE2077FCZZ
TINSE2078FCZZ
TINSE2081GHZZ
TINSE2087FCZZ
TINSE2119FCZZ
TINSE2120FCZZ
TINSE2123GHZZ
TINSE2129FCZZ
TINSE2181FCZZ
TINSF2079FCZZ
TINSF2121FCZZ
TINSG2080GHZZ
TINSG2122GHZZ
TINSH2084GHZZ
TINSH2126GHZZ
TINSI2083GHZZ
TINSI2125GHZZ
TINSJ2076FCZZ
TINSJ2118FCZZ
TINSS2082FCZZ
TINSS2124FCZZ
TINSW2089GHZZ
TINSW2131GHZZ
TINSZ2090GHZZ
TINSZ2091GHZZ
TINSZ2093GHZZ
TINSZ2094GHZZ
TINSZ2095GHZZ
TINSZ2132GHZZ
TINSZ2133GHZZ
TINSZ2135GHZZ
TINSZ2136GHZZ
TINSZ2137GHZZ
TLABH4440FCZZ
TLABZ4335FCZZ
[U]
UBATI0014FCZZ
[V]
VCCCCZ1HH101J
"
VCCCCZ1HH220J
"
VCEAGA1AW476M
VCEAGA1AW477M
VCEAGA1CW477M
VCEAGA1HW224M
VCEAGA1VW476M
VCEAJU1CW476M
VCEAPH1HC105M
VCEAPS1AC227M
VCEAPS1CC106M
VCEAPS1CC226M
VCEAPS1CC476M
VCEAYU1EC476M
VCEAYU1VC476M
VCEAZU1VW477M
VCKYCZ1CB103K
VCKYCZ1CF104Z
"
VCKYCZ1EF223Z
VCKYCZ1HB102K
"
"
VCKYCZ1HB222K
17- 5
37- 9
37- 9
43- 2
43- 2
43- 2
43- 2
42- 6
42- 6
42- 6
42- 6
42- 2
37- 7
37- 4
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
17- 20
33- 45
32- 15
26- 28
26- 29
40- 6
26- 30
39- 21
39- 22
39- 23
39- 24
39- 25
39- 26
38- 8
26- 31
26- 32
26- 33
26- 34
26- 35
40- 7
40- 8
39- 27
39- 28
26- 36
40- 9
39- 29
26- 37
39- 30
40- 10
39- 31
PRICE
RANK
AU
AF
AF
AT
AT
AT
AT
AP
AP
AP
AP
AE
AF
AB
AS
AS
AQ
AW
AS
AX
AN
AV
AS
AV
AT
AW
AV
AS
AS
AS
AS
AS
AS
AQ
AN
AW
AV
AS
AS
AS
AS
AS
AS
AS
AS
AS
AS
AS
AS
AF
AB
AN
AA
AA
AA
AA
AA
AB
AB
AA
AB
AB
AC
AD
AC
AC
AC
AC
AC
AD
AA
AB
AB
AA
AA
AA
AA
AA
NEW
PART
MARK
RANK
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
D
D
D
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
ND
D
D
B
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
NC
NC
C
C
C
C
C
C
C
C
C
– 25 –
PARTS CODE NO.
VCKYCZ1HF103Z
"
"
VCKYPU1EB223Z
VCKYPU1HB101K
VCQYNA1HM103K
VHD1SS133//-1
VHDDAN202K/-1
VHDDAP202K/-1
VHDDAP202U/-1
VHDDSM1D1//-1
VHDM1FL20U+-1
VHDMA704A//-1
VHDRB451F//-1
VHDRLS73///-1
VHEHZS3B3//-1
VHI28F081L02C
VHI28F322L01F
"
VHI28F322L02F
"
VHI28F322L03F
"
VHI28F322L04F
"
VHI65946P07-1
VHI74LCX08MTC
VHI74LCX14MTC
VHI74LCX244MT
VHI74LCX32MTC
VHI74LVX16128
VHI74VHC04M-1
"
VHI74VHC32M-1
VHI74VHCT240X
VHI7SZ125M5-1
VHI90LV17AW-1
"
VHI90LV27AW-1
VHID65943GJ-1
VHID82825GM-1
VHIDS14C238//
VHIEEP64-120P
VHIEES04L400P
VHIFS781BZB-1
VHIH8S2322R-1
VHIHG73C095-1
VHIHN58V65A-1
VHIKS0U1347-1
VHILCX157MT-1
VHILCX16244-1
VHILCX16245-1
VHILCX16373-1
VHILCX74MTC-1
VHILM324D++-1
VHILM339D++-1
VHILM393D++-1
VHILV25612J-1
VHILVT240MT-1
VHIM3064ATC-1
VHIM87J4810-1
VHIMTD1361F-1
VHIN2370R04-1
VHIN2370R33-1
VHIN2391D25-1
VHINJM317DL-1
VHINJU6356E-1
VHIPI6C2309-1
VHIPM2500++-1
VHIPST598DN-1
VHIPST598IN-1
VHIS1340AF+-1
VHISD4M16L1-1
VHISD8M16L1-1
VHISR1024-7LL
VHIT4955A20-1
VHITD62003AP1
VHITD62503F/VHITD62503F-1
VHIVHC244SJ-1
"
26- 38
39- 32
40- 11
38- 9
38- 10
39- 33
38- 11
39- 34
39- 35
26- 39
39- 36
39- 37
39- 38
26- 40
26- 41
39- 39
30- 12
12- 54
41- 1
12- 55
41- 2
12- 54
41- 1
12- 55
41- 2
26- 42
26- 43
26- 44
26- 45
26- 46
26- 47
39- 40
40- 12
39- 41
40- 13
40- 14
26- 48
39- 42
40- 15
39- 43
40- 16
26- 49
26- 50
39- 44
40- 17
39- 45
26- 51
39- 46
26- 52
26- 53
26- 54
26- 55
26- 56
26- 57
39- 47
39- 48
26- 58
39- 49
26- 59
40- 18
26- 60
39- 50
26- 61
26- 62
26- 63
26- 64
26- 65
26- 66
26- 67
26- 68
26- 69
38- 12
26- 70
26- 71
26- 72
26- 73
39- 51
39- 52
26- 74
39- 53
40- 19
PRICE
RANK
AA
AA
AA
AB
AA
AA
AA
AB
AB
AB
AB
AC
AC
AD
AA
AB
BB
BE
BE
BF
BF
BF
BF
BL
BL
BA
AE
AE
AG
AE
AP
AE
AE
AD
AF
AE
AP
AP
AQ
AY
BK
AT
AW
AG
AP
AZ
AY
AW
BN
AG
AM
AM
AM
AE
AE
AE
AE
AQ
AL
AX
BK
AR
AF
AF
AG
AK
AK
AR
BP
AF
AF
AH
AZ
BB
AU
BF
AG
AG
AF
AG
AG
NEW
PART
MARK
RANK
C
C
C
C
C
C
B
B
B
B
B
NB
B
B
B
B
NB
NB
NB
NB
NB
NB
NB
NB
NB
B
B
B
B
B
B
NB
NB
NB
B
NB
B
B
NB
NB
NB
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
NB
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
NB
NB
PARTS CODE NO.
VHP1LHEE-002A
VHP1LHLE-002A
VHPGP1A22LC-1
VHPGP1A73A+-1
"
"
VHPGP3A38//-1
VHPLT9400E/-1
VHV1608C080-1
VHVICPS1.2/-1
VRD-HT2EY101J
VRD-HT2EY102J
VRD-HT2EY163J
VRD-HT2EY302J
VRD-HT2EY331J
VRD-HT2EY471J
VRD-HT2EY911J
VRS-CZ1JD000J
"
"
VRS-CZ1JD100J
VRS-CZ1JD101J
"
"
VRS-CZ1JD102J
"
"
VRS-CZ1JD103F
VRS-CZ1JD103J
"
VRS-CZ1JD122J
VRS-CZ1JD151J
VRS-CZ1JD183J
VRS-CZ1JD203J
VRS-CZ1JD220J
VRS-CZ1JD221J
VRS-CZ1JD222J
"
"
VRS-CZ1JD303F
VRS-CZ1JD303J
VRS-CZ1JD330J
VRS-CZ1JD332F
VRS-CZ1JD332J
VRS-CZ1JD333J
VRS-CZ1JD470J
VRS-CZ1JD472J
VRS-CZ1JD511J
VRS-CZ1JD561J
VRS-CZ1JD562J
VRS-CZ1JD621J
VRS-CZ1JD624J
VRS-CZ1JD681J
VRS-CZ1JD750J
VRS-CZ1JD752J
VRS-CZ1JD823J
VRS-CZ1JD911J
VRS-RE3DA1R0J
VS2SB1197//-1
VS2SC1740SR-1
VS2SK3065++-1
VSDTA114YK/-1
VSDTC114EK/-1
VSDTC114YK/-1
"
VSDTC114YS/-1
VSUPA502T//-1
"
VVLLM065HB1-1
[X]
XBBS230P10000
XBBSD30P06000
"
"
"
XBBSD30P12000
XBBSD40P06000
"
XBBSD40P08000
XBBSD40P10000
XBBSD40P14000
26- 75
38- 13
31- 38
33- 33
34- 68
35- 10
31- 36
38- 14
26- 76
26- 77
38- 15
38- 16
39- 54
38- 17
38- 18
38- 19
39- 55
26- 78
39- 56
40- 20
26- 79
26- 80
39- 57
40- 21
26- 81
39- 58
40- 22
39- 59
26- 82
39- 60
39- 61
39- 62
26- 83
39- 63
26- 84
26- 85
26- 86
39- 64
40- 23
39- 65
39- 66
26- 87
40- 24
26- 88
26- 89
26- 90
26- 91
26- 92
39- 67
39- 68
39- 69
39- 70
39- 71
26- 93
39- 72
26- 94
39- 73
39- 74
39- 75
38- 20
39- 76
39- 77
26- 95
26- 96
39- 78
38- 21
26- 97
39- 79
29- 8
35- 35
12- 51
34- 24
36- 2
41- 7
32- 4
30- 17
31- 3
36- 7
31- 39
31- 37
PRICE
RANK
AC
AC
AK
AG
AG
AG
AH
AK
AC
AF
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AB
AC
AB
AG
AC
AB
AC
AC
AB
AD
AD
CB
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
NEW
PART
MARK
RANK
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
NC
C
C
C
C
C
C
C
C
C
C
NC
C
C
C
C
NC
C
B
B
NB
B
B
B
B
B
B
B
NB
C
C
C
C
C
C
C
C
C
C
C
– 26 –
PARTS CODE NO.
XBBSE30P06000
XBPSD26P06000
"
XBPSD30P05K00
XBPSD30P06000
"
XBPSD30P06KS0
XBPSD40P06KS0
XBPSD40P16KS0
XBTSC50P16000
XBTSE40P06000
XEBSD30P08000
"
"
"
XEBSD40P16000
XEBSE30P08000
"
XEBSE30P10000
XEBSE40P08000
XEBSE40P10000
"
XEPSD30P05000
XEPSD30P06X00
XEPSD30P08000
XEPSD40P06000
XESSE30P08000
XHBSD30P04000
"
XHBSD30P06000
"
"
XHBSD30P08000
XHBSD30P14000
XHBSD40P06000
XHBSE30P06000
"
"
"
"
XHBSE30P10000
XHBSE40P08000
"
"
"
XRESP20-04000
XRESP30-06000
XRESP40-05000
XRESP40-06000
XRESP50-06000
XRESP70-08000
"
"
30- 9
12- 26
41- 8
31- 28
12- 47
41- 9
28- 2
31- 10
31- 29
27- 11
27- 15
32- 2
33- 18
34- 9
35- 6
33- 35
27- 22
33- 40
33- 30
27- 28
33- 6
35- 25
28- 11
33- 23
29- 3
31- 47
33- 28
30- 2
31- 6
27- 14
30- 25
31- 48
27- 25
34- 66
31- 46
12- 50
33- 4
34- 2
35- 34
41- 11
34- 71
27- 2
30- 11
33- 11
34- 41
34- 54
28- 6
31- 43
34- 11
34- 27
31- 21
31- 34
34- 29
PRICE
RANK
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
NEW
MARK
PART
RANK
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
PARTS CODE NO.
PRICE
RANK
NEW
MARK
PART
RANK
– 27 –
CAUTION FOR BATTERY REPLACEMENT
(Danish) ADVARSEL !
Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.
(English) Caution !
Dispose of used batteries according to manufacturer’s instructions.
(Finnish) VAROITUS
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan
(French) ATTENTION
de la batterie. Remplacer uniquement avec une batterie du
Mettre au rébut les batteries usagées conformément aux
(Swedish) VARNING
(German) Achtung
Explosionsgefahr bei Verwendung inkorrekter Batterien.
Als Ersatzbatterien dürfen nur Batterien vom gleichen Typ oder
vom Hersteller empfohlene Batterien verwendet werden.
Entsorgung der gebrauchten Batterien nur nach den vom
Udskiftning må kun ske med batteri
Levér det brugte batteri tilbage til leverandoren.
Danger of explosion if battery is incorrectly replaced.
Paristo voi räjähtää,jos se on virheellisesti asennettu.
tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden
ll y a danger d’explosion s’il y a remplacement incorrect
même type on d’un type équivalent recommandé par
typ som rekornmenderas av apparattillverkaren.
af samme fabrikat og type.
Replace only with the same or equivalent type
recommended by the manufacturer.
mukaisesti.
le constructeur.
instructions du fabricant.
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent
Kassera använt batteri enligt fabrikantens
Hersteller angegebenen Anwerisugen.
Instruktion.
CAUTION FOR BATTERY DISPOSAL
(For USA,CANADA)
Contains lithium-ion battery. Must be disposed of properly.
Remove the battery from the product and contact
agencies for information on recycling and disposal options.
federal or state environmental
– 28 –
COPYRIGHT C 2001 BY SHARP CORPORATION
All rights reserved.
Printed in Japan.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted,
in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise,
without prior written permission of the publisher.
SHARP CORPORATION
Digital Document Systems Group
Quality & Reliability Control Ce nter
Yamatokoriyama, Nara 639-1186, Japan
2001 June Printed in Japan t
Loading...
